Reproducibility, Transparency and Evaluation of Machine Learning

in Health Applications

Janusz Wojtusiak

Health Informatics Program, Department of Health and Policy, George Mason University, U.S.A.

Keywords: Machine Learning, Health Informatics, Clinical Decision Support, Reproducibility, Transparency.

Abstract: This paper argues for the importance of detailed reporting of results of machine learning modeling applied in

medical, healthcare and health applications. It describes ten criteria under which results of modeling should

be reported. The ten proposed criteria are experimental design, statistical model evaluation, model calibration,

top predictors, global sensitivity analysis, decision curve analysis, global model explanation, local prediction

explanation, programming interface and source code. The criteria are discussed and illustrated in the context

of existing models. The goal of the reporting is to ensure that results are reproducible, and models gain trust

of end users. A brief checklist is provided to help facilitate model evaluation.

1 INTRODUCTION

Application of Machine Learning (ML) and more

broadly Artificial intelligence (AI) methods require

careful reporting of results. The current gold standard

for reporting results in the field is statistical model

evaluation reported as area under receiver-operator

curve, accuracy, precision, recall, F1-score and their

variants. While these metrics are useful in assessing

one aspect of model performance, they are

insufficient for assessing model applicability,

reproducibility of results and deployment of models.

Even machine learning models that have very high

testing scores, tend to make obvious mistakes that can

be immediately spotted by human experts. Thus,

researchers and data scientists need to better

understand their models’ behavior and limitations.

The presented work discusses ten criteria that in the

authors’ view should be used to report results of

machine learning modeling. They include specific

technical aspects of models, but models need to make

sense to domain experts and data scientists alike.

Recent significant interest in machine learning

and artificial intelligence methods, also outside

scientific community, have led to renewed focus on

trust in these approaches. Consequently, people

started questioning quality of many works,

reproducibility of results and criteria that are needed

for model evaluation. Such detailed reporting is

needed for review of methods, reproducibility and

meaningful application of the results. It is a wide

belief among non-machine learning experts that the

created models “do not generalize” and thus are

essentially useless. While the truth cannot be farther

from this statement, authors of many published works

fail to sufficiently report properties of their models.

The lack of generalizability refers to the fact that

models trained on one data, do not perform well on

different data, i.e., data from another institution, but

it also means that models built on historical data do

not work in practice.

More generally, transparency of science and

reproducibility of results are among the most

important aspects of scientific discovery. In order for

the results to be widely accepted by scientific

community and consequently applied, there needs to

be trust in how they were obtained. The results may

be reproduced by other groups on the same or

different data, or simply accepted when sufficient

evidence is provided in relation to quality of the work.

One can argue that there are many reasons for the

lack of details and sufficient reporting in published

works. Scientists are under constant pressure to

produce and publish results and faster. Many journals

and almost all conferences have space limits for

submitted manuscripts, and only some allow for

submission of supplemental material. Many scientists

report results in a standard way as most others do and

do not even consider the need for more detailed

studies. Finally, there is a strong bias for presenting

only positive results, thus some scientist may decide

not to present selected results that may negatively

affect review process of their work.

Wojtusiak, J.

Reproducibility, Transparency and Evaluation of Machine Learning in Health Applications.

DOI: 10.5220/0010348306850692

In Proceedings of the 14th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2021) - Volume 5: HEALTHINF, pages 685-692

ISBN: 978-989-758-490-9

685

1.1 Recent Interest

Within the past few years many works have been

published on the topic of transparency of machine

learning methods, reproducibility of results, and

overall reliance on these methods. Medical,

healthcare and health application areas of ML are of

special interest with results of modeling directly

affecting patients’ lives (Liu et al., 2019).

The need for detailed reporting of methods and

results is critical in science, yet has often be ignored

in ML, AI, and more broadly data science

(Gundersen, 2020) and only gained attention recently.

The problem is also being recognized in medical

applications (i.e., Beam et al., 2020).

To address this issue several sets of criteria have

been proposed. Luo et al. (2016), developed a set of

guidelines for reporting machine learning results in

biomedical research. They developed 12 reporting

criteria to be directly utilized in preparing

manuscripts, but do not discuss what specific metrics

should be used. Similarly, Stevens et al. (2020)

discuss reporting criteria split into main categories:

study design, data sources and processing, and model

development and validation. Vollmer et al., discuss a

framework consisting of 20 criteria (questions)

intended to guide ML and statistical research, split

into six categories: inception, study, statistical

methods, reproducibility, impact evaluation and

implementation. The authors argue for the need for

interdisciplinary teams to address these questions.

Reproducibility and quality of work has also been

addressed in the context of clinical trials (Wicks et al.,

2020). The criteria are described in Liu et al., (2020)

who provided guidelines for reporting results of

clinical trials that involve AI as an extension to the

standard CONSORT reporting (Moher et al., 2010).

Many authors describe criteria of reproducibility

in the context of other work or specific types of data.

For example, Wojtusiak and Baranova (2011) argue

that accuracy, transparency, acceptability, efficiency

and exportability are main criteria for machine

learning to be deployed in health applications. Kim et

al. (2020) describe reproducibility in the context of

genomic data. Ronald et al. (2020) as well as Yu et al.

(2020) focus on image data and reproducibility of ML

methods. Several more examples of such works are

available in the literature.

1.2 Focus of This Work

While several sets of criteria for reproducibility and

reporting of results exist, often much broader than the

work presented here, it is opinion of the author that

they are hard to follow in practice as they are too

general. The focus of this work is to list specific

metrics along with examples that are essential to

include in the reported results. The presented ten

machine learning reporting items, denoted MLI-1 to

MLI-10, include information about: experimental

design, statistical model evaluation, model

calibration, top predictors, sensitivity analysis,

decision analysis, global model explanation, local

prediction explanation, programming interface, and

source code. The criteria are intended to help guide

data scientists provide sufficient level of information

on the modeling process. The ten criteria are not

intended to be the only way reporting should be done.

Instead, they consist of a minimal set of criteria that

need to be addressed. While focus of this work is on

structured data (EHR, claims, etc.), the criteria are

also applicable to unstructured data.

Further, the presented work is not novel in terms

of the specific criteria used. All these criteria are

known and long used by machine learning

community, but often ignored. This work is intended

to contribute to discussion about reproducibility and

transparency of models and provide the authors’ view

on the topic.

2 REPORTING CRITERIA

2.1 Experimental Design

Complete understanding of how models were

constructed require detailed explanation of

experimental design in a broad sense including cohort

selection, data preprocessing, final data description,

hyperparameter tuning, and testing procedures. Most

importantly, one needs to carefully describe what is

being modeled (i.e., predicted), including the

relationship between the real world and its data

representation. The later is investigated by Cabitza et

al. (2020) in the context of relationship between the

ground truth and labeling of data as one measure to

assess the quality of data used for modeling.

Inclusion: Detailed information about inclusion

criteria to the study need to be presented. Johnson et

al. (2017) demonstrated that information included in

published ICU mortality prediction studies based on

MIMIC III data are insufficient to even reproduce

exact cohort. In most cases, the reproduced cohort is

much larger than one implied by publication, in many

cases because some exclusions applied while

preprocessing data are forgotten or buried in the

description.

There are different ways to report on how the

cohort was selected. The author’s preference is a

HEALTHINF 2021 - 14th International Conference on Health Informatics

686

flowchart that shows all exclusion steps along with

counts of included and excluded cases.

Cohort: The most commonly present way of

describing data is what is often referred to in

biomedical literature as “Table 1” that shows

characteristics of the data, typically as simple

descriptive statistics. The data are typically split

between different groups that correspond to

experimental work. Often, the data may be split based

on the predicted classes (values of output attributes).

While informative description of the population, such

table is not intended to provide detailed description of

the data. Such description should include as detailed

as possible description of how data were transformed

from the original form to the final analytic file fed into

ML algorithms.

Attributes & preprocessing: More specifically,

details of construction of derived attributes should be

described, including details of coding used. Such

descriptions are typically very complex and may

require presentation of source code (see MLI-10).

Experimental setup: Experimental setup description

includes a detailed description about how learning

and testing of the models was set up. For example,

was data split into training, validation and testing sets

and how was the split done, was cross-validation used

to tune hyperparameters and select algorithms, and

what specific methods and libraries were used at each

step of model construction.

In summary, MLI-1 is a broad category with

multiple items to be reported. Essentially, it is about

describing every step that was performed so that the

final models are constructed.

2.2 Statistical Model Evaluation

Statistical classification model evaluation results are

a gold standard of reporting results of ML modeling.

They typically include reporting of metrics such as

Area Under Receiver-Operator Curve (AUC),

Accuracy, Precision, Recall, and their derivatives.

For regression learning problems, reported values

typically include Mean Square Error (MSE), Mean

Absolute Error (MAE), and correlation coefficient.

Such metrics should be calculated on both training

and testing datasets, including results from cross-

validation, if performed.

The model accuracy is defined as the total number

of correctly classified exampled divided by the total

number of examples in the test set. In many cases,

accuracy is the most important metric reported. It is a

direct count how many times a model is correct or

incorrect. In other cases, when data are imbalanced or

one class is important than others, measures

additional measures are used. Model recall (known as

sensitivity in biomedical literature) is defined as the

number of correctly classified positive examples

divided by the total number of positive examples in

the test set. Similarly, model precision is defined as

the proportion of true positives to the total number of

examples classified as positive.

There is an obvious tradeoff between recall and

precision. Precision ad recall are often combined to

create one metric, such as F1-score and their

continuous relationship is related to the concept of

receiver-operator curve (ROC) and Area under

Receiver-Operator Curve (AUC or AROC),

sometimes referred to as C-statistic, represents

integration of all possible true and false positive rates

for a given model. In many application domains AUC

is considered as impractical as it shows overall

relationship between true positives and false

positives, but not precision and recall at the final

threshold. It is most often used to compare models.

There are many other statistical measures of

model quality. For example, the pattern quality

measure, q(w), (Michalski and Kaufman, 2001b)

allows weighting model recall and precision. Other

measures that rely on counting positive and negative

examples exist and are frequently used in the

literature: sensitivity, specificity, positive predictive

value, negative predictive value, and others. In

addition to the statistical model quality measures,

characteristics of learning algorithms should be

presented, including learning curves, attribute

selection curves, and hyperparameter tuning curves

accompanied by relevant statistical measures.

2.3 Model Calibration

There is a common misunderstanding that machine

learning methods return a probability of the target

event, or probabilities of classes in a multiclass

prediction problem. In fact, most models return a

score that is typically in 0 – 1 range and resembles

probability. Yet, probabilities have a well-defined

frequency interpretation, i.e., exactly 20% of

examples that receive score of 0.2 should really

belong to the predicted class. Model calibration is a

process that aims at changing the output scores, so

they are closer to the actual probabilities. Calibration

can be assessed numerically by metrics such as the

Brier Score, that is defined as the mean squared error

between the provided values and actual probabilities

(score zero means perfect calibration). Calibration is

often visually presented using calibration plots

(reliability curves). An example calibration curve

along with Python code is available at Scikit-learn

Reproducibility, Transparency and Evaluation of Machine Learning in Health Applications

687

website (2020). Below the actual calibration curves,

there is typically a histogram of distribution of output

values from the model.

Calibration curves as well as ROC are closely

related to the probabilistic interpretation of models

further discussed in later sections.

2.4 Top Predictors

Domain experts often want to see a list of “top

predictors” or attributes with highest scores according

to some metrics. This is in part related to their need to

understand models, and in part due to training in

standard statistics that clinicians often receive. The

attribute quality metrics can be specifically related to

models, such as coefficients in logistic regression

models or average GINI scores in random forests, or

based on criteria used in attribute selection methods

such as information gain, likelihood ratio or

Pearson’s correlation coefficient.

While listing of top predictors is often done and

should be done to provide some information to

domain experts, it is not necessarily a correct way of

presenting models and may be misleading. This is

particularly the case for nonlinear models for which

strength of each attribute/predictor needs to be

assessed locally in the neighborhood of a specific

example for which a prediction is made. This is

further discussed in sections 2.5 and 2.8.

Regardless of this limitation, an abbreviated list of

the top predictors can be included in the description

of created models, typically as a table. If space

permits, an appendix with a complete or longer list of

all predictors can be presented.

2.5 Global Sensitivity Analysis

Global sensitivity analysis is intended to test if

models are behaving in a certain way they are

expected to. It is used to measure how uncertainty in

the output of the model can be derived from

uncertainty in the model inputs. The other way of

thinking about the sensitivity analysis is to measure

how much inputs to the model would need to change

for the output to significantly change so that results

are affected. In practice, this means to ensure a

relatively smooth behavior of the model and

minimize output fluctuation, i.e., small changes to

inputs cause small changes to outputs, as well as the

models are “smooth” (the output values do not jump

back and forth when inputs are changed). This is

exemplified in Figure 1 that shows predicted

probability of mortality calculated by C-LACE2

model (Wojtusiak et al., 2017) based on patient age.

The three lines with “spikes” in the data represent

average predicted probabilities for patients in the data

with a given age. As one can see, the model appears

unstable. However, when patients are taken from a 5-

year age window the model is smooth. This is because

the variation is caused by small number of patients at

every given age.

Figure 1: Sensitivity of C-LACE2 model presented as

predicted probability in relation to patient age.

2.6 Decision Curve Analysis

Fine-tuning of models for application on entire

population level data typically involves cost-benefit

analysis of correctly and incorrectly classified

objects. Whenever a model is employed to make a

prediction there is a potential cost and benefits

associated with correct and incorrect classification.

Here, the words cost and benefits are loosely defined

and may carry various meaning in the context of

specific applications. In the AI community these are

often referred to as a utility function, although more

often in the context of reinforcement learning.

Benefits and costs are positive and negative

consequences of predictions. Let us assume that these

are denoted C

– the cost of true positives, C

– the

cost of false positive, C

, - the cost of true negative,

and C

, - the cost of false negative. Typically, C

> C

, but most importantly C

>> C

To exemplify this idea, let’s consider a model that

is used to early detect a medical condition. Patients

who are identified by the model as likely to have the

condition receive additional screening (i.e., genetic

test). There are potential costs associates with all

possible outcomes of the prediction: patients who are

correctly predicted to have the condition (TP) are

subject to cost of additional testing and then cost of

treatment for early detected condition, C

. Patients

with the condition who are not tot correctly detected

by the model (FN) incur potentially large costs

associated with treatment of the condition at a late

stage, C

. The patients who are correctly identified

HEALTHINF 2021 - 14th International Conference on Health Informatics

688

as not having the condition (TN), do not undergo

additional testing and are healthy thus do not require

any treatment or testing. Their total associated cost

can be considered as zero. Finally, there are patients

who do not have the condition, but are identified by

the model as positive (FP) and receive additional

screening with cost C

. If cost of testing and early

treatment is much smaller than cost of late treatment,

it may be reasonable to early test everyone. However,

if the frequency of positive cases is very low, vast

majority of tests will be done unnecessarily.

In the example below, a model was created to

predict which elderly patients receiving a traditional

form of care may benefit from a new approach. The

model predicted probability of cost savings in the new

setting vs. traditional approach. The new setting is

cheaper for some patients, but not for all. The model

was applied to about 13,000 patients receiving

traditional care and identified patients who may be

moved to the new setting. The plots in Figure 2 were

constructed to visually demonstrate the potential

savings. The plot shows entire population of 13,000

patients and indicates that the benefit of moving to the

non-traditional program peaks at about 9,000 patients

after which the model predicts the traditional program

to be more beneficial.

Figure 2: Decision/utility curve that illustrate potential

savings based on numbers of people moved to a new

treatment approach.

2.7 Global Model Explanation

In order to gain trust in the models, decisionmakers

want to understand their internal working. Despite

transparency and interpretability being considered by

some authors as ill-defined concepts (Lipton, 2018),

there is a recently growing interest in the model

transparency that narrows down to two approaches:

(1) Construct models that are transparent in the first

place, or (2) generate an explanation for a black-box

model.

The approach (1) follows the concept of natural

induction (i.e., Michalski, 2004; Wojtusiak et al.,

2006) in which models are created directly in a

transparent representation and are based on early

ideas in machine learning. The following paragraph

is from Michalski (1983) and is part of the first

published machine learning book:

The results of computer induction should be

symbolic descriptions of given entities, semantically

and structurally similar to those a human expert

might produce observing the same entities.

Components of these descriptions should be

comprehensible as single “chunks” of information,

directly interpretable in natural language, and

should relate quantitative and qualitative concepts in

an integrated fashion.

This approach assumes that the models are created

in representations that are easy to interpret. Among

the best-known transparent representations are

decision rules, decision trees, linear models such as

logistic regression or naïve Bayes, and sometimes

Bayesian networks. While the idea of using

transparent representations is great in principle, many

statistical methods outperform the transparent ones in

terms of statistical measures described in Section 2.2.

Statistical methods are usually simply more accurate.

In fact, one of benefits of using machine learning

methods is the ability to select from wide selection

available algorithms.

Therefore, considerable efforts are made to create

solutions to approach (2) that aims at explaining

black-box models. It is important to note that one can

explain algorithms that are used to create a model, but

it is impossible to grasp the entire model. For

example, how to explain a random forest with 1000

trees or a deep neural network?

There are numerous methods for explaining

global models that have been investigated, including

surrogate models, lists of predictors, and a wide range

of visualization techniques. Guidotti et al., (2018)

define global explanation of a black-box model in

terms of finding a transparent model (surrogate

model) that is able to mimic the behavior of the black-

box model. The authors provide review and discuss

approaches available in the literature. Similarly, Du

et al. (2020) discuss global model explanation mainly

in the context of deep neural networks. An interesting

study of trust in machine learning by clinicians is

presented by Tonekaboni et al. (2019) in which the

authors surveyed ICU clinicians about specific

aspects of model explanations that are useful to them.

A special issue of BMC Medical Informatics and

Decision Making fully dedicated to explainable AI

includes a wide range of related works (BMC, 2020).

Reproducibility, Transparency and Evaluation of Machine Learning in Health Applications

689

2.8 Local Prediction Explanation

Local prediction explanation refers to the ability of a

model to inform decision makers about the reasons of

why a specific prediction was made. While related to

the global model explanation, prediction explanation

requires different approaches. Very often, local

prediction explanation is more important for decision

makers than global explanation. Knowing why a

specific prediction is made, increases chance of that

prediction being used. There are four main types of

local explanations: listing top predictors for an

individual case, demonstrating causality, building

local models, and visualization. There are also several

less frequently used approaches, often developed in

the context of specific methods or application areas.

Local Interpretable Model-agnostic Explanations,

LIME (Ribeiro et al., 2016), and Shapley

Additive exPlanations, SHAP (), are two of the most

frequently used local explanation methods. The

approaches and their many recently published

variants rely on generating synthetic data close to the

example being explained and fitting local models into

that synthetic data. Such a simple model can be used

to locally explain prediction.

There are a number of other works in the literature

that base explanations on listing top predictors,

including Luo and Ruminshisky (2016) and Ge et al.

(2018) that used this approach in models for

predicting mortality in intensive care units (ICU).

Some authors argue that to explain prediction, one

needs to identify causal mechanism that links input

attributes to the predicted outcome (output attribute).

This approach is often done in the context of

graphical models such as Bayesian or Gaussian

Networks, and builds upon long research of Judea

Pearl (i.e., Pearl, 2000). Pearl (2019) recently argued

for the need of causality in machine learning

providing list of approaches that allow for causal

reasoning.

Uncertainty should be part of explanation. There

are no events in the future that can be predicted with

100% accuracy. This is the nature of time. We can

know for certain only the past that have happened, but

the future is always uncertain. Except for trivial

problems one should not expect to achieve 100%

accuracy for constructed models. This fact needs to

be communicated to end users. Further, in

classification problems, the goal is to predict the most

likely answer, but models typically communicate a

level of uncertainty in that answer (i.e., probability for

well-calibrated models as discussed in section 2.3).

Consequently, it is important to communicate and

explain that uncertainty as part of prediction. For

example, CBIT online calculator presents the

probability of a patient’s functional independence and

communicates that uncertainty in graphical form as

well as textual description (Wojtusiak et al., 2020).

Equipped with that information clinicians can make

informed decisions and decide on the appropriate

course of action.

2.9 Sharing Models and Programming

Interface

Models are created using a variety of computer

systems, programming languages, libraries, and tools.

Sharing only saved models is typically insufficient as

they need additional information to be properly

executed. For example, models that are saved in

scikit-learn library in Python can be safely loaded

only with the same version of the library, and all

dependent libraries. In addition, an ordered list of

inputs is needed so that the model is properly

executed. In practice, the most useful is to include a

part of source code that demonstrated how to load the

model, encode inputs, and execute the model on new

cases. When sharing models, complete information

needs to be given on how to load and execute them.

Sometimes models are accessible through an

application programming interface (API) allowing

remote computer systems to communicate with

models without the need for the need to depend on

specific computer implementation. Such

programming interfaces are typically based on a data

sharing standard such as XML or JSON.

2.10 Source Code

Full reproducibility of the experimental portion of the

work is even more complex. Inclusion of complete

source code for all parts of the work provides the

cleanest way of presenting steps taken to create

models. Full reproducibility may also require addition

of data used to train and test models, but data often

cannot be shared. Source code can be shared using a

public repository such as GitHub on an institutional

website. Some journals allow for submission of

additional materials, including data and source code.

In addition to reproducibility, sharing source code

allows for peer review of details of what has been

done. Others may find mistakes in the code that may

affect results. Fully opensource data analysis code

shared in a centralized repository may be the best way

to achieve transparency in the data analysis and

modeling.

HEALTHINF 2021 - 14th International Conference on Health Informatics

690

3 MLI CHECKLIST

The above criteria are summarized in the following

checklist intended to help organize reporting of

results. Even though there is no one-size-fits-all set of

evaluation criteria and metrics, the checklist is

intended to be a minimum set of reportable criteria.

MLI-1: Experimental Design

- Report inclusion criteria

- Provide descriptive statistics of data

- Describe data preprocessing & attribute construction

- Describe experimental setup, training & testing sets,

cross-validation

- Describe model training

MLI-2: Statistical Model Evaluation

- Calculate Accuracy, AUC, recall, precision, F1-score

MLI-3: Model Calibration

- Perform model calibration

- Report calibration curves and calibration measures

MLI-4: Top Predictors

- Report top-performing attributes in the model

MLI-5: Global Sensitivity Analysis

- Perform global sensitivity analysis for continuous and

discrete attributes

- Report sensitivity plots and analyze if models are stable

MLI-6: Decision Curve Analysis

- Assign costs to correctly and incorrectly classified

instances

- Construct decision curves and report on desirable

thresholds

MLI-7: Global Model Explanation

- If transparent representations are used, report entire

models

-Otherwise apply one of explanation methods to

describe models

MLI-8: Local Prediction Explanation

- Select and implement an approach to explain

predictions

MLI-9: Sharing Models and Programming

Interface

- Is sharing actual models include all needed information

to load and execute them

MLI-10: Source Code

- Share complete source code

4 CONCLUSION

Mature application of machine learning methods,

particularly in areas such as medicine and health care,

require detailed reporting on methods and results. The

presented ten MLI reporting criteria are based on

types of information typically present in the literature

(almost always separately) and are one step towards

gaining suers’ trust in the developed models and

increase their use. The presented criteria are focused

on data scientists and researchers who develop

models and contribute to scientific literature.

The presented work does not include many

additional criteria discussed in the literature, such as

ethical considerations of ML methods and their

applications in medicine, and legal requirements and

regulatory approvals. Instead, it focused on technical

concepts and research community.

Finally, the presented work is not nearly

complete. It represents one small piece of a larger

discussion on reproducibility, transparency, trust and

other related concepts in machine learning. The paper

presents current opinions of the author which are

likely to evolve.

ACKNOWLEDGEMENTS

The presented paper is partially based on early

content of technical report (Wojtusiak, 2020). The

author thanks Eman Elashkar and anonymous

reviewers who provided valuable comments that

helped improve the paper.

REFERENCES

Beam, A. L., Manrai, A. K., & Ghassemi, M. (2020).

Challenges to the reproducibility of machine learning

models in health care. Jama, 323(4), 305-306.

BMC (2020) call for papers on Explainable AI in Medical

Informatics and Decision Support:

https://www.biomedcentral.com/collections/explainableai

Cabitza, F., Campagner, A., & Sconfienza, L. M. (2020).

As if sand were stone. New concepts and metrics to

probe the ground on which to build trustable AI. BMC

Medical Informatics and Decision Making, 20(1), 1-21.

Du, M., Liu, N., & Hu, X. (2019). Techniques for

interpretable machine learning. Communications of the

ACM, 63(1), 68–77. https://doi.org/10.1145/3359786

Friedman, J. H. (2001). Greedy function approximation: a

gradient boosting machine. Annals of statistics, 1189-

1232.

Ge, Wendong, Jin-Won Huh, Yu Rang Park, Jae-Ho Lee,

Young-Hak Kim, and Alexander Turchin. "An

Interpretable ICU Mortality Prediction Model Based on

Logistic Regression and Recurrent Neural Networks

with LSTM units." In AMIA Annual Symposium

Proceedings, vol. 2018, p. 460. American Medical

Informatics Association, 2018.

Reproducibility, Transparency and Evaluation of Machine Learning in Health Applications

691

Guidotti, Riccardo, Anna Monreale, Salvatore Ruggieri,

Franco Turini, Fosca Giannotti, and Dino Pedreschi. "A

survey of methods for explaining black box

models." ACM computing surveys (CSUR) 51, no. 5

(2018): 1-42.

Gundersen, O. E. (2020). The Reproducibility Crisis Is

Real. AI Magazine, 41(3), 103-106.

Johnson, A. E., Pollard, T. J., & Mark, R. G. (2017,

November). Reproducibility in critical care: a mortality

prediction case study. In Machine Learning for

Healthcare Conference (pp. 361-376).

Kim, A. A., Zaim, S. R., & Subbian, V. (2020). Assessing

Reproducibility and Veracity across Machine Learning

Techniques in Biomedicine: A Case Study using TCGA

Data. International Journal of Medical Informatics,

104148.

Liaw, A., & Wiener, M. (2002). Classification and

regression by Random Forest. R news, 2(3), 18-22.

Lipton, Z. C. (2018). The mythos of model interpretability.

Queue, 16(3), 31-57.

Liu, Y., Chen, P. H. C., Krause, J., & Peng, L. (2019). How

to read articles that use machine learning: users’ guides

to the medical literature. Jama, 322(18), 1806-1816.

Liu, X., Rivera, S. C., Moher, D., Calvert, M. J., &

Denniston, A. K. (2020). Reporting guidelines for

clinical trial reports for interventions involving

artificial intelligence: the CONSORT-AI extension.

bmj, 370.

Lundberg, S. M., & Lee, S. I. (2017). A unified approach to

interpreting model predictions. In Advances in neural

information processing systems (pp. 4765-4774).

Luo, Yen-Fu, and Anna Rumshisky. "Interpretable topic

features for post-icu mortality prediction." In AMIA

Annual Symposium Proceedings, vol. 2016, p. 827.

American Medical Informatics Association, 2016.

Luo W, Phung D, Tran T, Gupta S, Rana S, Karmakar C,

Shilton A, Yearwood J, Dimitrova N, Ho TB,

Venkatesh S. Guidelines for developing and reporting

machine learning predictive models in biomedical

research: a multidisciplinary view. Journal of medical

Internet research. 2016;18(12):e323.

Michalski, R. S., "A Theory and Methodology of Inductive

Learning," Chapter in the book, Machine Learning: An

Artificial Intelligence Approach, R. S. Michalski, T. J.

Carbonell and T. M. Mitchell (Eds.), pp. 83-134,

TIOGA Publishing Co., Palo Alto, 1983.

Michalski, R. S., "ATTRIBUTIONAL CALCULUS: A

Logic and Representation Language for Natural

Induction," Reports of the Machine Learning and

Inference Laboratory, MLI 04-2, George Mason

University, Fairfax, VA, April, 2004.

Michalski, R. S. and Wojtusiak, J., "Semantic and Syntactic

Attribute Types in AQ Learning," Reports of the

Machine Learning and Inference Laboratory, MLI 07-

1, George Mason University, Fairfax, VA, 2007.

Moher, D., Hopewell, S., Schulz, K. F., & Montori, V.

(2010). G? tzsche, PC; Devereaux, PJ; Elbourne, D;

Egger, M; Altman, DG; CONSORT 2010 explanation

and elaboration: updated guidelines for reporting

parallel group randomised trials. BMJ, 340, c869.

Morgan, S.L. and Winship C., Counterfactuals and Causal

Inference: Methods and Principles for Social Research,

2nd Edition, Cambridge University Press, 2015.

Pearl, J. Causality, Cambridge University Press, 2000.

Pearl, J. (2019). The seven tools of causal inference, with

reflections on machine learning. Communications of the

ACM, 62(3), 54–60. https://doi.org/10.1145/3241036

Pineau, J., Vincent-Lamarre, P., Sinha, K., Larivière, V.,

Beygelzimer, A., d'Alché-Buc, F., ... & Larochelle, H.

(2020). Improving Reproducibility in Machine

Learning Research (A Report from the NeurIPS 2019

Reproducibility Program). arXiv preprint

arXiv:2003.12206.

Renard, F., Guedria, S., De Palma, N., & Vuillerme, N.

(2020). Variability and reproducibility in deep learning

for medical image segmentation. Scientific Reports,

10(1), 1-16.

Ribeiro, Marco Tulio, Singh, Sameer, and Guestrin,

Carlos.“why should I trust you?”: Explaining the

predictions of any classifier. In Knowledge discovery

and Data Mining (KDD), 2016.

Sciikit-learn website, Probability Calibration: https://scikit-

learn.org/stable/modules/calibration.html

Stevens, L. M., Mortazavi, B. J., Deo, R. C., Curtis, L., &

Kao, D. P. (2020). Recommendations for reporting

machine learning analyses in clinical research.

Circulation: Cardiovascular Quality and Outcomes,

CIRCOUTCOMES-120.

Tonekaboni, S., Joshi, S., McCradden, M. D., &

Goldenberg, A. (2019). What clinicians want:

contextualizing explainable machine learning for

clinical end use. arXiv preprint arXiv:1905.05134.

Vollmer, S., Mateen, B. A., Bohner, G., Király, F. J., Ghani,

R., Jonsson, P., ... & Granger, D. (2020). Machine

learning and artificial intelligence research for patient

benefit: 20 critical questions on transparency,

replicability, ethics, and effectiveness. bmj, 368.

Wicks, P., Liu, X., & Denniston, A. K. (2020). Going on up

to the SPIRIT in AI: will new reporting guidelines for

clinical trials of AI interventions improve their rigour?.

BMC medicine, 18(1), 1-3.

Wojtusiak, J., Michalski, R. S., Kaufman, K. and

Pietrzykowski, J., "Multitype Pattern Discovery Via

AQ21: A Brief Description of the Method and Its Novel

Features," Reports of the Machine Learning and

Inference Laboratory, MLI 06-2, George Mason

University, Fairfax, VA, June, 2006.

Wojtusiak, J., Elashkar, E. and Mogharab Nia, R., "C-

LACE2: computational risk assessment tool for 30-day

post hospital discharge mortality," Health and

Technology, Springer, 2018.

Yu, K. H., Lee, T. L. M., Yen, M. H., Kou, S. C., Rosen,

B., Chiang, J. H., & Kohane, I. S. (2020). Reproducible

Machine Learning Methods for Lung Cancer Detection

Using Computed Tomography Images: Algorithm

Development and Validation. Journal of medical

Internet research, 22(8), e16709.

HEALTHINF 2021 - 14th International Conference on Health Informatics

692
