Predictive Technologies and Biomedical Semantics: A Study of

Endocytic Trafficking

Radmila Juric

, Elisabetta Ronchieri

, Gordana Blagojevic Zagorac

, Hana Mahmutefendic

and Pero Lucin

University of South Eastern Norway, Kongsberg, Norway

CNAF/ INFN, Bologna, Italy

University of Rijeka, Faculty of Medicine, Rojeka, Croatia

Keywords: Training Data Set, Machine Learning, Endocytic Pathways.

Abstract: Predictive technologies with increased uptake of machine learning algorithms have changed the landscape of

computational models across problem domains and research disciplines. With the abundance of data available

for computations, we started looking at the efficiency of predictive inference as the answer to many problems

we wish to address using computational power. However, the real picture of the effectiveness and suitability

of predictive and learning technologies in particular is far from promising. This study addresses these concerns

and illustrates them though biomedical experiments which evaluate Tf/TfR endosomal recycling as a part of

cellular processes by which cells internalise substances from their environment. The outcome of the study is

interesting. The observed data play an important role in answering biomedical research questions because it

was feasible to perform ML classifications and feature selection using the semantic stored in the observed

data set. However, the process of preparing the data set for ML classifications proved the opposite. Precise

algorithmic predictions, which are ultimate goals when using learning technologies, are not the only criteria

which measure the success of predictive inference. It is the semantic of the observed data set, which should

become a training data set for ML, which becomes a weak link in the process. The recognised practices from

data science do not secure any safety of preserving important semantics of the observed data set and

experiments. They could be distorted and misinterpreted and might not contribute towards correct inference.

The study can be seen as an illustration of hidden problems in using predictive technologies in biomedicine

and is applicable to both: computer and biomedical scientists.

1 INTRODUCTION

This study explores the benefits and pitfalls of various

types of data pre-processing, carried out under the

umbrella of data science. The focus is on the role of

data preparation for running machine learning (ML)

algorithms and its role in assessing the quality of

precision of ML classifiers, which has an impact on

predictive inference. The case study is in the

biomedical domain. It explores diverse endocytic

routes of endosomal cargo molecules and recycling

(Blagojevic et al., 2017)), (Karleusa et al. 2018),

(Mahmutefendic, et al., 2017). It would be beneficial

to discover new knowledge on endocytic trafficking

https://orcid.org/ 0000-0002-0441-0694

https://orcid.org/0000-0002-7341-6491

https://orcid.org/0000-0003-1249-3802

by using predictive technologies and ML algorithms.

Data science practices are needed for preparing

biomedical data for at least ML classification, and

running a selection of classifiers in order to find out

if they biomedical data sets can be semantically

labelled to fit supervised ML.

However popular the Data Science discipline is,

we must not forget a few important concerns. The

most obvious is the lack of the definition and an

academic consensus on what exactly Data Science

would mean and what it could do for biomedical

science. Computations created under the umbrella of

data science started diverging from main principles of

computer science, built over the last 70 years.

260

Juric, R., Ronchieri, E., Zagorac, G., Mahmutefendic, H. and Lucin, P.

Predictive Technologies and Biomedical Semantics: A Study of Endocytic Trafﬁcking.

DOI: 10.5220/0009375702600267

In Proceedings of the 13th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2020) - Volume 3: BIOINFORMATICS, pages 260-267

ISBN: 978-989-758-398-8; ISSN: 2184-4305

Problems are numerous and could be collated into:

 Lacking of formalism in terms of defining which

type of computational models data science

generates and why;

 Shortcomings of practices of preparing huge data

sets for training and testing, which very often

legitimately distort the semantic of them

(Danilchanka and Juric, 2020), (Juric et al.,

2020);

 Looking at missing data values as places to be

either eliminated or filled with “something”,

without semantic justification for such changes;

 Assuming that noisy data in training data sets

have no semantic and we wish to remove them;

 Using software tools for data science operations

upon our data, without telling us exactly how

they deal with the semantic of data. (Juric, 2018)

(Ronchieri et al., 2019),

 Lacking an agreement, amongst computer

scientists, on the role of predictive inference,

after decades of successful applications of logic

reasoning and inference (Newgard, 2015).

This study of endosomal trafficking detected all the

problems itemised in the bullets above. In some of

the problem domains, they might not be seen as

serious concerns. However, in the field of biomedical

science, when we strive for new discoveries, they

should be taken seriously. Therefore this research,

which initially focused on the problem of discovering

more knowledge on endosomal trafficking through

learning and predictive technologies, diverged into

something different. We started questioning

a) the process of preparing biomedical data sets

from endocytic as required by data science,

b) the lack of semantics in training data sets because

of missing data values and

c) the assumption that ML would help to find out

what is missing in the puzzle of endosomal

recycling.

The purpose of this paper is twofold.

We would like to draw attention of computer

scientists and statisticians to the fact that the current

climate of using various statistic inference upon

learning data sets, without understanding the impact

of the changes in the semantic of the data, is not

advisable. Whenever we prepare data sets for running

even a simple linear regression or classification, we

have to understand what happens to the semantic of

the data prepared for them.

We would also like to draw attention of

biomedical scientists to the fact that the

computational power is hidden in the data generated

through biomedical experiments. The power is in the

semantic of data observed in and recorded from these

experiments. We have to pay attention to

computations before we start collecting data and

formatting data sets.

In this study, in spite of our concerns, we have

managed to create a set of quite reliable ML

classifiers for endosomal trafficking. We are not

convinced that the technology is a definitive answer

to getting trustworthy insights into collected data and

answering research questions. Therefore, the

ultimate goal of this study is to initiate a debate across

disciplines for assessing the future of predictive

inference, and its reliability in biomedical science.

The paper is organised as follows. In section 2 we

give the scenario of endosomal trafficking and define

a hypothesis which would be of interest to biomedical

scientists. In section 3 we analyse the semantic of the

observed data set outline observations which might

affect the definition of ML classifiers. In section 4

we illustrate the way data has been prepared for

running ML classifiers and focus on the way the

content of the data set changes in order to fit essential

requirement of any ML classifier: definitions of

features and semantics of data labelling. Section 5 we

define ML classifiers and debate the problem of

missing data values in the training data set. In section

6 we illustrate results of running a two set of

classifiers, with and without missing data values in

the training data set. Sections 7 debates the results and

outlines what the future of ML algorithms in

biomedical science research might hold.

2 ENDOCYTOSIS AND Tf/TfR

ENDOCYTIC ROUTES

Endocytosis is an essential cellular process when cells

internalize substances from their environment. There

are two main types of endocytosis: clathrin dependent

endocytosis (CDE) and clathrin independent

endocytosis (CIE). The best model for studying CDE

is the model of Transferrin/Transferrin receptor

(Tf/TfR) endocytosis.

Transferrin (Tf) is a protein produced by liver that

has high affinity for binding the iron and as such it

has the most important role in regulating iron

metabolism. Upon binding of Tf to its receptor (TfR)

on the cell surface, the Tf/TfR complex is rapidly

endocytosed by CDE. Following endocytosis Tf/TfR

complex is transported into early endosomes (EE)

where acid pH affects the release of iron. Tf/TfR

complex can then either be recycled back to the cell

surface (fast recycling) or directed to the

jukstanuclear recycling compartment (JNRC). From

Predictive Technologies and Biomedical Semantics: A Study of Endocytic Trafﬁcking

261

the JNRC, Tf/TfR complex is recycled back to the

cell surface (slow recycling). In contrast to TfR,

recycled Tf can not be detected on the cell surface

because it is released to the medium.

The difference between endocytosis and

internalization is important. Endocytosis means

entering into the cell and internalization means

disappearance from the cell surface . The latter is a

net result of endocytosis and recycling

(internalization = endocytosis – recycling).

Consequently Tf can be used to track the endocytosis

and TfR to track the internalization.

It is known that CDE is very fast and thus these

biomedical experiments must have very short time

intervals for collecting/observing data in each

experiment. It is technically impossible to read

results below 2 minutes of a time stamp, but the first

10 minutes of the experiment can be monitored

carefully. TfR recycled from the EE can be early

detected on the cell surface, even after the first 3

minutes from the beginning of the experiment. TfR,

recycled from the JNRC is visible after 8-10 minutes

from the beginning of the experiment.

It is important to note that there is a possibility of

pre-EE (rapid) recycling, which occurs before EE

(during the first 3 minutes). After 20 minutes TfR

reaches its steady state (homeostasis)

(Mahmutefendic, et al., 2018) and thus there is no

need collect results of these experiments very

frequently. Short time stamps are important at the

beginning, but not after 20 minutes. Furthermore,

considering that 2 min time stamp is expensive it is

not necessary to perform them after 20 min. This

means that during the first 20 minutes we can detect

fast and slow recycling, kinetics of the endocytosis

and after 20 minutes TfR reaches its homeostasis.

Each experiment uses fluorescently labeled

antibodies for the detection of Tf and TfR. Antibodies

can bind only Tf and TfR that are on the cell surface,

regardless of their status. We do not know from the

number of molecules on the cell surface if (a) they

have not been endocytosed yet or (b) they have been

endocytosed but they are recycled to the cell surface.

If antibody binds Tf or TfR, there is fluorescent

signal, which is detected by flow cytometer. When

cells are analyzed by flow cytometer, the number that

represents mean fluorescence intensity (MFI) is read.

MFI represents average fluorescent signal given by a

single cell. The higher MFI value, the more

molecules are present on the cell surface. Their

presence is an indication of either slow endocytosis

or fast recycling. The highest fluorescent signal is

read at the beginning of each experiment (minute

ZERO). After that, the signal slowly decreases due

to endocytosis. All the numbers given by flow

cytometer are percentages calculates as MFI values.

The example is given in Table 1.

Table 1: Calculating percentages from MFI Values.

0 2 4 6 8

MFI VAL.

354 298 250 178 100

PERCENT.

100 84 70,6 50,3 28,2

The observed data set contains a set of numeric

values, which show the presence of molecules on the

cell surface in the relevant time stamp. Table 1 says

that, after the beginning of the experiment (after

minute 0), in which 354, i.e. 100% of molecules were

present on the cell surface, in minute 8, there will be

only 28% of them available on the cell surface. As

mentioned earlier, this percentage does not indicate

exactly how many of these molecules are present

because of either slow endocytosis or fast recycling.

Considering results from the literature and earlier

publications (Blagojevic et al., 2017), we would be

interested in finding out if pre-EE does exists as a part

of Tf/TfR endocytic routes, because it has not been

proved in the literature yet. The question is could

predictive and learning technologies help?

3 THE SEMANTIC OF THE

OBSERVED DATA SET

The observed data set consisted of the rows of data,

stored in a spreadsheet, where rows contained

numeric values from each experiment (as shown in

the second row of Table 1), and columns correspond

to a time stamp at which the data was collected.

However, we stumbled upon first problem

immediately. Description of each experiment, in

terms of the names of cells and molecules involved,

data related either endocytosis or internalization, and

data which describe conditions in which each

experiment was conducted, are not part of the data set.

This means that significant and semantically rich data

form these experiments are of a descriptive nature, i.e.

they are NOT numeric values, and as such, they were

not entered into data set. The other problems are:

Labelling data set in classifications is extremely

important and we had to ask if time stamps, i.e. the

exact MINUTES in which the data is collected, would

be suitable for defining features and deciding about

labelling for ML classifiers?

Missing values in the data set is a result of not

collecting data in all available minutes between 1 and

BIOINFORMATICS 2020 - 11th International Conference on Bioinformatics Models, Methods and Algorithms

262

180. This might not be an obstacle, because NO

DATA is semantic itself, according to the argument

in the previous section. However, if a software

automated tool is used for data preparation and

processing, how can we be sure if the results of

running ML algorithms upon data sets with more than

50% of missing data values, are good or bad. How

could we know that if a software tool is in charge?

Removing columns or rows with missing data

might be a double-edged sword: we may manually

add semantic by removing “column headings” and

converting them into the data values (Danilchanka

and Juric, 2019). We may delete rows and columns

with excessive amounts of missing information, or

merge them following any justifiable prediction

theory rules, but how do we know how much

semantics we might lose or gain?

Noisy labels, Synonyms, Duplications, and many

similar terms, are usually seen as obstacles in creating

quality training data sets. However, they are very

important semantically, i.e. why do we assume that

there is no semantics in noisy labels? Is it safe to

leave the interpretation of the meaning of noisy labels

in the observed data to automated tools?

Semantic significance of a training data set may

be confined to the data values stored in particular

column(s) and therefore the column’s definition and

its data values are essential in the precision of

classifiers/predictions. Do we have to single out

semantically significant columns of this training data

set, or treat all columns equally when defining our

own ML classifier suitable in this problem domain?

Classifier’s features are defined through the

semantic stored in columns and the combination of

columns of tabular formats, which could be chosen as

features. However, how do we balance this? Which

column will become a feature? What shall we do with

the semantic of non-numerical data in terms of feature

selection if we enter them into the training data set?

The above six observations appear after the

manual analysis of the observed data set from Tf/TfR

endosomal experiments. This means that

(a) the observed data set is not ready for any type of

ML processing and

(b) we need to find out which process we should use

for preparing the data set for ML classifiers.

In order to answer as many questions as possible,

regarding these observations, and address (a) and (b)

above, we had to involve human intervention in

restructuring the data set and focus on the following

three principles:

i. which semantic is relevant for preparing the data

set further for learning technologies? Are MFI

percentages sufficient?

ii. would new columns in the data set, which store

the semantic of conditions of each experiment,

be suitable for ML classification?

iii. how much could we trust our choice of features?

Is our selection of features (time stamps) the

adequate for data labelling/ defining classifiers?

An algorithm for data labelling is not difficult to

create because of the explanations given in the

previous section. Rich semantics are available

within/around the experiments, even if it is not

directly available in the observed data set. Human

intervention in the process of restructuring the data

set would take charge of that and it might enable the

definition of the labelling mechanism.

4 PREPARING THE DATA SET

FOR ML CLASSIFIERS

The observed data set was manually restructured

according to the explanations from Section 3. No

software tool could prepare the data set according to

our analysis and add more semantics to it. The data

set was restructured manually by

 Keeping the same time-stamps, which defined

columns with numeric (MFI) values,

 Adding new columns with literal data values,

which described additional semantics from the

experiments (not MFI values).

Therefore numeric values were concatenated with

strings: columns which explained conditions in which

experiments were performed. Table 2 illustrates the

additional semantic. There is a set of new columns,

coloured as yellow boxes, and a sample of values

stored in these columns are coloured as blue boxes.

Table 2: Additional columns in the observed data set.

Cell Experiment

Condition

MFI

Balb3T3 INTERNALIZATION around20‐25

Condition

MCMV

Condition

Temperature Period

No 37oC Long

CellStatus ConditionInterferon



Normal No



Tables 3, 4 and 5 show excerpts from the training

data set, i.e. only 11 interesting experiments. Each

experiment occupies one row.

Predictive Technologies and Biomedical Semantics: A Study of Endocytic Trafﬁcking

263

The top rows coloured in blue, green and amber

in Tables 3, 4 and 5, show the exact minute in which

data values are collected.

In Table 3, which shows the first 10 minutes of

each experiment, the maximum number of reading of

MFI values is 5, but in some cases not more than 2.

Table 4 shows the same 11 experiments for minutes

between 10 and 20. The time stamp changed and

frequency of collecting numeric data values is

decreasing: it is every 5 instead of 2 minutes. Table

5 shows the last 120 minutes of the same experiments.

Readings were not conducted after 60 minutes.

Tables 3,4 and 5 show that we kept numerical

values as they were observed in experiments. The

only change in the observed data set was added

semantics, which describes the experiments.

Adding more columns/semantic for describing

experiment means adding strings and not numeric

values: the types of cells chosen for experiments, their

status, temperature, infection with MVN, presence of

interferon and type of experiment (endocytosis or

internalization).

It is important to note, that we could not declare

the existence of any noisy labels for one obvious

reason: all our numeric values were carefully

collected / recorded and additional semantic was

added manually. Therefore, there was no need for

any other aspect of “cleaning” the data set, as a part

of data preparation. However, there is only one

serious concern in this particular case study: a

significant amount of missing data values in the

relatively semantically rich training data set.

5 DEFINING ML CLASSIFIERS

A significant number of missing data values in the

data set requires looking at this problem differently.

We are not confident that any of the existing data

science practices of imputations would work here.

The idea of imputations is both seductive and

dangerous (Dempster and Rubin, 1977).

Firstly, we have to define a set of ML classifiers

and we do not wish to replace missing data values,

using any of the recommended data science practices.

The reasons are obvious. These values are either not

feasible to obtain (in the first 10 minutes) or irrelevant

(after 20 minutes). Any other reasoning for imputing

data into missing values would be inappropriate (Juric

et al., 2020). How could we assume that the

simulations of missing data values in the first 2-5

minutes of each experiment would be appropriate for

answering the questions from the hypothesis?

Table 3: Excerpts from the observed numeric data (1).

0 1 2 3 4 5 6 7.5 8 10

100 24.8 18.9

11.5

100 48.7

37.4

100

100 28.8

23.8

100 82.4 70.8

60.6

52.4 44.5

100 77.3 65.1

55.4

48.6 43.3

100 68.2 45.9

47.6

34.1 32.3

100 78.7 49.3

29.1

100 38.3

100 49.9

51.6

100 47.4 34.4

Table 4: Excerpts from the observed numeric data (2).

20 25 30 35 40 45 50 60

14.1 11.9

3.71

31.4 29.9 27.9 27.2 26

35 18.1

13.5

5.28

29.8 14.3

7.8

38.1 22.1

25.2 15

20.4 18.1

7.4

4.53

41.9 43.6 42.2 39.41 38

66.8

Table 5: Excerpts from the observed numeric data (3).

35 40 45 50 60 75 90 105 120 180

3.71



27.2 26

18.1 13.5



5.28



7.8



4.53



39.4 38

However, simulating missing data values (after 20

minutes in each experiment) might be acceptable, but

these data values are almost irrelevant because of

homeostasis.

BIOINFORMATICS 2020 - 11th International Conference on Bioinformatics Models, Methods and Algorithms

264

Secondly, we know that we have to use software

tools for running ML algorithms, and therefore we

have an opportunity to perform imputations for

missing data values according to the options or

functionalities tools offer. Treating missing values

through software tools might give us at least an

indication whether we are able to define ML classifier

by doing something which is not semantically

justifiable. We may be able to test these tools to find

out if the imputation they performed would give good

precisions for a set of ML classifier(s).

Consequently, it would be prudent to define and

run ML classifiers twice: first time WITH missing

data values and second time with imputations for

replacing missing values with numbers generated by

the chosen tool.

In this study we used RStudio (version 1.2.1335)

for data visualisation and potential “cleaning” and the

Weka ML framework (version 3.8.3) for defining and

running ML classifiers. We decided to run ML

experiments with relatively small data set in order to

secure a variety of semantic for successful

classification. Considering that we had 34 columns in

our data set, then having 147 instances over 34

features, would not require the use of any other ML

frameworks, such as scikit-learn/R combination.

RStudio/Weka leaves us with a freedom to control the

definition of classifers and accommodate our

involvement in these ML experiments.

Many of the classification and regression

algorithms available in the Weka framework were

tried and examined, but we show results given by

Random Forest, REP Tree, JRIP, Bagging,

Classification via Regression, Random Committee

and Random Sub Space. They presented a kappa

statistic greater than 0.81, which is the minimum

value for which the agreement result can be

considered good for further investigation.

The definition of the classifier includes a feature

selection and an algorithm for labelling the data set,

as a part of supervised ML techniques.

The feature selection was not a problem for one

important reason. If we wished to run ML classifiers

with a data set which has a significant amount of

missing data values, than it would be unreasonable to

exclude some of the columns in the definition of the

classifier, due to nature of these experiments. Also,

we added more semantic assuming that it is relevant

for the definition and precision of classifiers.

Practically all columns from our data set must be

included in the feature selection. They are bulleted

below. The features correspond to top rows of Tables

2,3 and 4 and yellow boxes in Table 1.

 minutes when reading was obtained 1, 2, 3, 4, 5,

6, 7.5, 8, 10, 12.5, 15, 20, 25, 30, 35, 40, 45, 50,

60, 75, 90, 105, 120, 180;

 cell name (String: list of different cells);

 type of experiment (String, Endocytosis,

Internalisation);

 MFI level (String: low/normal/high/any range);

 Infection MCMV (String Yes / No)

 Cell temperature (String, number for Celsius)

 Interferon presence ((String Yes / No);

 Period of experiments (String: Short, Long);

 Cell status (String; normal).

Data Labelling has been done using a specific

algorithm which correspond to the hypothesis: are we

able to label each experiment into pre-EE, early-EE

and Late-EE?

We should be able to find minutes in which we

obtained either Min or Max MFI values of the Tf/TfR

complex on the cell surface. This would directly

imply that we should have an extra column in the data

set, for each experiment, which specifies a minute in

which these min and max values are obtained. The

algorithm devised in this study might not be the best

possible choice of reasoning needed for the labelling

and it could change if the semantic described in

Section 3 changes. What is important here is to see if

we can classify the labels from the data set which

were not aimed at being used for learning

technologies and leave the algorithm from Figure 1 to

serve only for illustration purpose.

Figure 1: Potential algorithm for data labelling.

6 RUNNING ML EXPERIMENTS

Tables 6 and 7 are results of running a set of

classifiers with and without missing data values. In

case of imputing data to replace missing values, the

tool replaced empty data values with the mean values

obtained for the various instances: the mean was

calculated by row. They show method, correct

classified instances % (CCI%), incorrect classified

For each cell and INTERNALISATION

If MAX Value is <=3 min label is pre-EE

If MAX Value is <=5 min label is EE

All others Max Values label is LE

For each cell and ENDOCYTOSIS

If MAX Value is <=3 min label is LE

If MAX Value is <=5 min label is EE

All other Max Values label is

re-EE

Predictive Technologies and Biomedical Semantics: A Study of Endocytic Trafﬁcking

265

instances % (ICI%), Kappa statistic (KS), mean

absolute error (MAE), root mean squared error

(RMSE), relative absolute error % (RAE%), and root

relative squared error % (RRSE%).

Table 6: Running ML Classifiers WITH Missing Data

Values.

Method CCI% ICI% KS MAE RMSE RAE% RRSE%

Random

Forest

91.836 8.163 0.870

0.175 0.236

41.175 51.220

REPTree 91.156 8.843

0.862 0.070 0.214 16.464 46.565

JRIP

98.639 1.360

0.978

0.070 0.101

16.560 21.925

Bagging 95.918 4.081 0.935

0.100 0.179

23.525 38.780

Class. Via

Regression 96.598 3.401 0.946

0.138 0.193

32.569 42.020

Random

Committee 91.156 8.843 0.860 0.126 0.2140 29.690 46.375

Random

Sub Space 93.877 6.122 0.903 0.193 0.244 45.488 52.917

Average 94.169 5.830 0.908 0.125 0.197 29.353 42.829

There are two important outcomes from Tables 6/7.

Firstly, the precision of ML classifiers WITH missing

data values is better than without them. Missing data

values, calculated by the chosen tool were replaced

by the tool. Secondly, in spite of having a significant

number of missing values, the precision of the

algorithms which include them is quite good. We

may say unexpectedly good.

Table 7: Running ML Classifiers WITH Imputations for

Missing Data Values.

Method CCI% ICI% KS MAE RMSE RAE% RRSE%

Random

Forest

88.435 11.564 0.816

0.184 0.258

43.215 56.062

REPTree 90.476 9.523

0.850 0.079 0.221 18.561 47.910

JRIP

95.238 4.761

0.924

0.048 0.169

11.432 36.686

Bagging 95.918 4.081 0.935

0.098 0.174

22.978 37.788

Class. Via

Regression 94.557 5.442 0.914

0.154 0.221

36.180 47.973

Random

Committee 89.115 10.884 0.829 0.139 0.256 32.702 55.627

Random

Sub Space 93.197 6.802 0.892 0.208 0.258 48.919 56.081

Average 92.419 7.580 0.805 0.130 0.222 30.569 48.304

7 DISCUSSION AND

CONCLUSIONS

This study could start debates on the future role of

learning and predictive technologies across the

disciplines of computer and biomedical sciences. The

message from the study goes to both sides.

Computer scientists should be aware that current

data science practices need attention because they

may not guarantee the best possible semantic of

training data sets, which may affect ML results. In

this study, we avoided all well accepted principles of

removing rows/columns and noisy labels and address

missing data values in order to prepare a data set.

There was no justification for doing opposite. We

achieved better precision of ML classifiers by

keeping rows/columns with missing data values. We

also entered semantic in the data set from biomedical

experiments which was initially not considered. They

were essential in creating labeling algorithms for

supervised ML. Therefore human intervention was

essential in preserving the semantic of the data set.

Biomedical scientist should be aware that

biomedical experiments must be conducted with the

type of data processing in mind. Moving from the

statistical predictions towards learning technologies

requires different ways of collecting data and possibly

would need collaborations with computer scientists in

order to evaluate which hypothesis could be feasible

to (dis)approve. This takes us directly to the joint

definition of the features and algorithms for labelling

data set (as in Figure 1) with computer scientists.

This study also proved that we follow i.-iii. from

section 3. MFI values could have been sufficient for

defining classifiers, but the labelling of data set,

which took into account the additional semantic form

the experiments, outside the MFI values, was not

difficult to define. Current combination of features

with the labelling algorithms proved that it is feasible

to run ML classification on this data set even with a

significant amount of missing data values.

Our decision NOT to run imputations as described

in (Acuna and Rodriguez, 2004), (Batista and

Monard, 2003), might seem unusual but it is not

isolated: there are examples where better precision in

classification has been obtained by NOT removing

missing data values (Danilchanka and Juric, 2020),

(Danilchanka and Juric, 2018). Unfortunately, there

are not so many publications which focus on this

problem. Publications which are debating

probabilistic uncertainty are old and rare (Newgard,

2015) (Craddock, 1986), (Rubin, 1976). Currently,

Published papers are mostly concerned with

achieving high precision of ML algorithms, without

worrying that we might be scarifying the original

semantic of training data sets to increase precision.

One of the most important outcome of this study

is the fact that relatively good precision of our ML

classifiers must encourage us to work further on creat-

ing semantically richer training data set and use them

for example in unsupervised and deep learning. We can

assume that this study would warrantee more research

to be done in the field of predictive inference, as long

as we can mange the semantic of the training data set.

BIOINFORMATICS 2020 - 11th International Conference on Bioinformatics Models, Methods and Algorithms

266

There are two limitations.

Firstly, we were not able to answer one of the

crucial questions from endosomal trafficking: “does

pre-EE exists” for many reasons. In order to find out

what is happening in the first 2-3 minutes in each

experiment, we would need to use results from more

experiments (we used only 147 experiments) and try

some other ML algorithms. These are very expensive

experiments, and thus we might re-think the way they

are carried out. Simulating data for replacing values

which can not be measured/obtained for the first two

minutes, must be debated. Imputation used in the

second set of ML experiments did not help to improve

the precision. Also, Endocytosis and Internalizations

semantically overlap and thus they should be

addressed in future work, when defining the

additional semantics of the training data set and

revisiting the algorithm from Figure 1.

Secondly, we could have analyzed the results of

the second set of ML classifiers, which had imputed

mean values, calculated per each row. This would

mean that we are trying to achieve precision in

classification, but we will not know if we are

improving the quality of the data set at the same time.

Would this help us to find out if pre-EE existed?

Immediate future work should address our first set

of limitations. The second set of limitations is a

subject of more complicated debate: is predictive

inference desirable in biomedical science if we could

not guarantee that the semantic of the training data set

will not be distorted. For this particular problem of

endocytic trafficking, unfortunately the answer might

be NO. However, this should not discourage us from

searching for or finding more options where both

predictive and logic inference cohabit (Basulto et al.,

2017). In long term, this could lead towards

discovering new insights in biomedical data

REFERENCES

Acuna, E., Rodriguez, C., 2004. The treatment of missing

values and its effect in the classifier accuracy. Banks D.,

McMorris F. R., Arabie P., Gaul W. (eds)

Classification, Clustering, and Data Mining

Applications. Studies in Classification, Data Analysis,

and Knowledge Organisation. Springer, 2004

Basulto, V. G. Jung, J.C., Schroeder, L., 2017. Probabilistic

Description Logics for Subjective Uncertainty, Journal

of Artificial Intelligence Research 58 (2017) 1-66.

Batista, G., M., Monard, C., 2003. An Analysis of Four

Missing Data Treatment Methods for Supervised

Learning, In Applied Artificial Intelligence, Vol 17,

2003, Issue 5-6 pp 519-533.

Blagojević Zagorac, G., Mahmutefendić, H., G., Maćešić,

S., Karleuš, L. J., Lučin, P., 2017. Quantitative Analysis

of Endocytic Recycling of Membrane Proteins by

Monoclonal Antibody-Based Recycling Assays, In

Journal of Cellular Physiology 232(2017), 3; 463-476.

Craddock, A. J., Browse, R. A. 1986. Reasoning with

Uncertain Knowledge, in UAI'86, Second Conference

on Uncertainty in Artificial Intelligence, pp 57-62

Newgard, C. D. Lewis, R. J., 2015. Missing Data: How to

Best Account for What Is Not Known, Clinical

Review& Education, JAMAGuide to Statistics and

Methods

Danilchanka; N., Juric, R., 2020. The Process of Creating a

Training Data Set: Lessons Learned from Mechanical

Engineering, in SDPS 2018 Workshop of Accountability

of AI Bologna, Italy..

Danilchanka; N., Juric, R., 2020. Reliability of Training

Data Sets for ML Classifiers: a Lesson Learned from

Mechanical Engineering, in Proceedings of the 53

HICSS conference, January 2020.

Dempster, A. P., Ruibn, D. P. 1997. Incomplete Data in

Sample Surveys, Theory and Bibliography, Vol 2 (ed,

W.G. Madow, I. Olkin and D.B. Rubin), 3-10. New York

Academic Press.

Juric, R., 2018. How BIASED Could AI Be? In SDPS 2018

Workshop of Accountability of AI Bologna, Italy.

Juric, R., Ronchierri, E., Blagojević Zagorac, G.,

Mahmutefendić, H., Lučin, P. (20,20. Addressing the

Semantic of Missing Data Values in Training Data Sets

using MVL: A Study of Tf/TfR Endocytic Routes,

under review for the ISMVL 2020 Conference, Japan

May 2020.

Karleušaa, L J., Mahmutefendić,H., Ilić Tomaš, M.,

Blagojević Zagorac, G., Lucin, P., 2018. Landmarks of

endosomal remodelling in the early phase of

cytomegalovirus infection, in Virology 515 (2018) 108–

122

Mahmutefendić, H., Blagojević Zagora, G., Grabušić, K.,

Karleuš, L. J., Maćešić, S, Momburg F., Lučin, P.

(2017) Late endosomal recycling of open MHC-I

conformers, in Journal of cellular physiology, 2017

April, 232(4):872-887.

Mahmutefendić, H., Blagojević Zagora, G., Maćešić, S,

Lučin, P. (2018) Rapid Endosomal Recycling, Book

Chapter, in Open Access Peer Review Chapter,

IntechOpen, https://www.intechopen.com/books/peri

pheral-membrane-proteins/rapid-endosomal-recycling

Ronchieri, E., Juric, R., Canaparo, M., 2019. Sentiment

Analysis for Software Code Assessment. In

proceedings of the 2019 IEEE NPSS Conference,

Manchester, UK.

Rubin, D.B., 1976. “Inference and Missing Data”

Biometrika, Vol. 63, No. 3 (Dec., 1976), pp. 581-592.

Predictive Technologies and Biomedical Semantics: A Study of Endocytic Trafﬁcking

267
