Cracking Biometric Authentication Cryptosystems

Maryam Lafkih

1,2

SmartiLab, National School of Engineering Sciences, Rabat, Morocco

LRIT (Associated Unit with the CNRST), Faculty of Sciences, Mohammed V University, Rabat, Morocco

Keywords: Biometric Cryptosystems, Security Evaluation, Framework Conception, Attacks.

Abstract: Biometric systems are becoming an alternative solution to replace traditional authentication systems.

However, security and privacy concerns against these systems arise from the direct storage and the misuse of

biometric information. In order to overcome these problems, biometric cryptosystems are proposed as

template protection solution improving the confidentiality and the security. Biometric cryptosystems present

a secret key mechanism where a secret key is used to overlap biometric data. Several approaches using

biometric cryptosystems have been proposed, however a few works have been published giving detailed

analysis of these systems and their security. In this paper we give a rigorous discussion on biometric

cryptosystems taking into account their security evaluation. Besides, a conception framework of different

attacks on biometric cryptosystems is proposed. On the other hand, several measures that can be exploited to

decrease the probability of such type of attacks are also presented.

1 INTRODUCTION

The use of biometric

systems is becoming a necessity in

the world, these systems are proposed to hamper the

problems of traditional authentication systems.

Biometrics ensures the user’s identification and

reduces the theft and menaces. However, biometric

system can be attacked using different threats such as

correlation of stored templates and spoofing attacks.

In order to overcome these weaknesses, the

cryptography domain is investigated to protect

different information and data. Then, Biometric

cryptosystems are proposed as biometric data

protection technologies. As basic biometric systems,

biometric cryptosystems are based on both steps to

ensure the authentication process. In the first step, a

secret key is used to generate the intermediated data

referred to as helper data. This data must not reveal

significant information about the user’s information.

The second step is the enrollment process where the

secret keys must be derived using the helper data and

the user’s request. Based on how the helper data are

derived, biometric cryptosystems are categorized on

two kinds: the key binding and the key generation

biometric cryptosystems (A. K. Jain et al,1999).

1) Key Binding Systems: this type aim to binding a

random secret key with biometric data to generate the

helper data in the enrollment step. During

authentication processes, the Key is obtained from the

helper data and the biometric request (C. Soutar et al,

1998). Fuzzy Vault (K. Nandakumar et al, 2007) and

Fuzzy Commitment (

. Juels and M. Wattenberg,

1999) are examples of these systems. This mode is

considered as more tolerant to biometric variations

due to the use of error correcting code in order to

generate the secret key (Figure 1).

2) Key Generation: In this mode, helper data are

generated only from biometric data. Biometric

template can be recovered from the helper data and

the given biometric request (Yongjin Wang et al,

2007). Fuzzy extractors and secure sketches are

considered famous formalisms of these systems (C.

Soutar, 1998

)

(Figure 2).

Figure 1: Key Binding process.

Although the proposed modes are considered to

secure the biometric information, biometric

cryptosystems still suffer from several security and

privacy concerns; where several attacks can be

performed on different system level. In this paper, we

explored different proposed approaches of biometric

cryptosystems in both binding and generation mode.

514

Lafkih, M.

Cracking Biometric Authentication Cryptosystems.

DOI: 10.5220/0009169405140522

In Proceedings of the 15th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2020) - Volume 4: VISAPP, pages

514-522

ISBN: 978-989-758-402-2; ISSN: 2184-4321

Hybrid approaches which make the fusion of different

basic concepts have been also presented. The

comparison of proposed approaches is presented

accompanying to the rigorous analysis of the

weakness and powerful points. The evaluation of the

security and privacy is also discussed where a

conception framework of different attacks is

proposed to summarize different attacks possible in

biometric cryptosystems. In this paper, we present a

general Attack conception framework, this

framework regroup different type of attack that can

affect any biometric cryptosystems. Classification of

existing security evaluation is firstly proposed and the

overall possible attacks are then discussed in order to

present detailed security evaluation. New types of

attacks are also proposed in this framework. The goal

of this framework is to let researchers to easily

evaluate their systems in a quantitative manner, to

enhance the presented database of common threats.

Since researchers may overestimate the efficiency of

their developed systems.

Figure 2: Key generation process.

The rest of this paper is organized as follows:

Section 2 provides security evaluation of biometric

systems without protection. Different existing

security evaluation of biometric cryptosystems is

discussed in Section3. In Section 4, the proposed

conception framework is proposed to detail different

points of threads in biometric cryptosystems.

Discussion of possible solution is also presented in

Section 5. Finally, Section 6 concludes the paper and

a number of future works.

2 BIOMETIC CRYPTOSYSTEMS

Security has become increasingly a concern in

biometric systems, it ensure confidentiality by

providing a robust authentication process against any

type of threats (Ross, A., Jain, A., 2003). For this

purpose biometric cryptosystems are proposed as

cryptography based technology to minimize the

vulnerabilities exploited illegitimately to gain access

to a system (Ratha, N. et 2001). Several biometric

cryptosystems are developed and demonstrated a high

security; this security is variable depending on the

used technologies and also the variation of biometric

characteristics. Biometric Cryptosystems are

considered as techniques that incorporate the benefits

of using biometric characteristics and secret key to

encrypt the biometric data of the user (Ross, A., Jain,

A. 2003). The error correction codes are used in such

systems to retrieve the key from biometric

characteristics at the authentication stage. There are

several approaches developed in the field of biometric

cryptosystems. These approaches are based on two

modes to generate the secret key, Key binding and

Key generation (Li, Q et al, 2006). In Key binding

cryptosystem, biometric template is linked with a

secret key in a single entity to build a helper data. This

data reveals no information on the key or biometric

template. It is, therefore difficult to decode the key or

the model without any prior knowledge of biometric

data of the user. The key is recovered after a

successful authentication. This mode is tolerant to

variations of biometric data and this tolerance is

determined by the ability of associated error

correction code word. Using Key generation, the key

is derived from the biometric data. Authentication is

successful if the key is retrieved. During the

authentication phase, the biometric data cannot be

reproduced exactly. For this purpose a data-derived

model called Secure sketch is also stored in the

database. This allows recovering the model if the

current model and that recorded in the database are

close. Fuzzy Commitment method, proposed by Juels

and Wattenberg (Juels, A., Wattenberg, M., 1999) is

one of the main approaches for biometric

cryptosystems. This method is based on the use of a

secret key with the biometric characteristics of the

user to construct the helper data that will be stored

with the encrypted key. During the authentication, the

secret key must be recovered using the auxiliary data

and characteristics of the request. This approach

requires that the data must have a canonical format

which is not the case for some biometric traits (e.g

fingerprint).

To address the weakness of the Fuzzy

Commitment, another main approach is proposed by

Juels and Sudan named Fuzzy Vault (Juels, A.,

Sudan, M, 2006). This method is based on the use of

biometrics with a secret key that will be converted

into polynomial, after a series of false points added to

build a ’vault’. The ’vault’ will be stored in the

database instead of the user biometric template. To

have access to the system, the authentication secret

key must be retrieved using characteristics of the

request and the ’vault’ already stored in the database.

Cracking Biometric Authentication Cryptosystems

515

For a good illustration of the approach let’s consider

this example (Scheirer, W. J., Boult, T. E., 2007), if

Alice has a secret K, she encodes it using a set A and

publishes the result to know if someone has the same

secret without revealing her own secret. Suppose that

Bob uses another set B, if B overlaps substantially

with A, then Bob can find the Alice secret, else the

secret cannot be revealed by Bob because B not

identical to A. Fuzzy Vault method allows Bob to

recover the secret K if his set largely superimposes

with the set of Alice. In this approach the protection

of K requires to represent it by a polynomial P at first;

to generate the set R using features U and P(U) at

second, and finally to add false points to construct the

vault. If characteristics of Bob are approximately

close to Alice characteristics, he can find enough real

point in R, using error correction coding to recover

the secret K.

To secure the user characteristics fX

; X

;..; Xrg,

a random key K is generated of length l, and

converted into polynomial P of degree d. Using this

polynomial we obtain the set f(Xi; P(X

))gri=1 that is

secured by hiding a set of random chaff points (aj ;

bj)j=1 q where b

6= P(a

) and aj 6= Xi. The resulting

set is considered as the vault V. In the authentication

phase if the characteristics of query X

query

are

approximately close to the abscissas of the vault

vault

. The secret can be recovered using the code

correcting error with capacity n. Fuzzy Vault

approach was presented as solution for protecting

biometric template and preserving privacy, however

the security of several existing Fuzzy Vault schemes

cannot be valid for biometric systems, where an

attacker could link several vaults generated from the

same biometric trait or submit his own biometric

template in the database in order to gain illegitimate

access. Ratha et al. [7] have identified eight locations

of possible attacks in a generic biometric system. In

the case of biometric cryptosystems, other kinds of

attack can be appeared. Even if different studies

discuss the biometric cryptosystems security, this

assessment does not follow a formal framework,

hence to this end, we aim to propose a conception

framework in order to generalize the possible attacks

on biometric cryptosystems. This framework is

independent to the used modalities and the used

protection approach.

3 BIOMETRIC

CRYPTOSYSTEMS

EVALUATION

Biometric crypto-systems evaluation is considered as

a major issue for several reasons. It offers researchers

and developers a tool to better test and evaluates these

systems taking into account the user’s behavior.

Furthermore, Evaluation and security analysis allows

understanding the needs and deploying this

technology with efficiency manner. On the other

hand, the biometric cryptosystems analysis allows the

identification of industrial applications base on

various criteria as the performance, usage, security

and deployment cost. Despite the obvious advantages

of biometric cryptosystems, they are still vulnerable

to several kinds of attacks which may deeply affect

their utility and functionality. In order to improve the

security of biometric cryptosystems, the evaluation of

their security presents a necessity. Therefore, it is

important that biometric cryptosystems be designed

to withstand the presented threats when employed in

security-critical applications and to achieve an end to

end security. Towards this goal, the aim of this work

is to present a general framework towards the security

threats of biometric authentication cryptosystems.

The goal of this framework is to regroup all the

possible threats on biometric cryptosystems. These

threats are classified on already discussed threats and

other new threats which are not yet studied. On the

other hand, this framework let researchers to easily

evaluate their systems in a formal manner, and to

enhance the presented evaluation of common threats

and vulnerabilities.

3.1 Classification of Existing

Evaluation

Security evaluation of biometric cryptosystems has

been discussed in several studies. In order to classify

the possible threats we first categorize existing

evaluation literature work on four categories: (1)

Classical evaluation, (2) Evaluation based on

Information theory, (3) Secret key evaluation, (4)

Evaluation using attacks.

3.1.1 Evaluation based on Information

Theory

Xuebing (Xuebing Zhou, 2011) propose a framework in

order to analyze the security of protection approaches

using mutual information and entropy. Zhou et al. are

studied the security of fuzzy commitment using 3D

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

516

Figure 3: Biometric Cryptosystems attacks Framework.

face recognition system based on the mutual

information. Authors are studied the security and the

privacy using entropy in order to evaluate the

independence and biometric features distribution.

The distribution of the iris codes and Markov

proprieties are then generated. Besides, the security

of fuzzy commitment is measured by Nagar

(Abhishek Nagar

2012

)

using the entropy taking into

account the biometric features distribution and the

probability to steal the auxiliary data. Wang et al. (Ye

Wang, 2011) are proposed a comparative study using

both approach secure helper data and fuzzy

commitment. This analysis is based on the

information theory and False Acceptance and False

Rejection Rates (FAR, FRR). The Quatratic Reny

Entropy is used by Hidano et al.(Seira Hidano,

2012

)

to estimate the quantity of information in fingerprints

features. Meenakshi and Padmavathi (VS Meenakshi

2009) have proposed a new Fuzzy Vault approach

and analyze the security using minimal entropy. Al-

Assam and Jassim (Hisham Al-Assam, 2012)] are

combined the Kullback-Leibler divergence and the

entropy in order to create a new entropy formula.

3.1.2 Secret Key Evaluation

Biometric cryptosystems link a secret key to

biometric features. This key must have a sufficient

size and entropy. On the other hand, biometric

cryptosystems performance can be presented using

the FAR and FRR, these measures are linked to the

key entropy. For these reasons, a new relation

between the secret key and FAR / FRR is performed

by Andry et al. (Andy Adler,2003). Hence, an ideal

biometric cryptosystem must have FAR<2k, which is

not possible in practice. Kelkboom et al. (

Emile JC

Kelkboom, 2010

) have also proposed a new measure

based on the relation between the key and FAR/FRR

to measure the security of fuzzy commitment. The

security of this scheme is also discussed by Ignatenko

et Willems (Tanya Ignatenko, 2012), based on linked

information and the key’s maximum size.

3.1.3 Evaluation using Attacks

In (Christian Rathgeb, 2012), Rathgeb and Uhl are

applied statistic attack on iris Fuzzy Commitment;

this attack is based on the execution of error

correcting code in decoding mode in order to generate

the near codeword (A Stoianov,2009). This allows

correcting several errors which decrease the FRR and

Increase the FAR. The brute force attack is related to

the hardness to recover the polynomial from the vault,

and the probability that t vault points are in the

genuine features is 















. This attack is discussed

also in (Preda Mihailescu, 2007). Tams (Benjamin

Tams, 2013) have studied the impact of false

acceptation attack which is easier than brute force

attack because it depends directly to the average rate

necessary to execute attacker’s request. In

Correlation attacks, the attacker has two vaults of the

same user stored in different systems and tries to link

the both data. The aim of this attack is to derive the

biometric trait of the real user. These attacks are

particularly investigated on the fuzzy vault context in

(Soweon Yoon, 2012). In (Emile JC Kelkboom,

2010), Kelkboom et al have tested a correlation attack

using fingerprint. This attack consists to define the

real biometric from biometric models stored in

different systems using exhaustive research. Chang

et al. (T Charles Clancy, 2003) have identified the

location of chaff points; this was proved by the

observation of non-randomness of fuzzy vaults (i.e,

free zone in the vault). Scheirer et al. (Walter J

Scheirer, 2009

)

have proposed theoretical analysis of

Fuzzy Vault and biometric encryption Scheme

against several attacks without any criterion and any

Cracking Biometric Authentication Cryptosystems

517

implementation to represent these attacks (T Charles

Clancy, 2003

). Authors are proposed injection attack

where the attacker can inject his biometric data in the

database; On the other hand, correlation attack is also

discussed. Poon and Miri (Hoi Ting Poona, 2009

) are

proposed the collision attack against fuzzy vault,

where the attacker has different encoded values using

a secret key. This attack can be applied to distinguish

the genuine points in the vault.

3.2 Proposed Conception Framework

In order to compare different biometric

cryptosystems in term of the usability, performance,

security, the security analysis presents a necessity. To

evaluate the security of biometric cryptosystems with

rigorous and detailed manner, we propose a

generalized conception to schematize different

possible threats on biometric cryptosystems. Ratha et

al. (Ratha, N, 2001

) have identified eight points or

levels of attack in biometric authentication systems,

however, biometric cryptosystem are vulnerable to

the several threats. These threats (ex. filtrate attacks,

error correcting attacks) are not possible in biometric

systems without protection mechanism. To this

effect, we propose a generalized scheme which

regroups different threats that biometric

cryptosystems may consider. This scheme (Figure 3)

presents overall proposed attack studied and

discussed on literature and also other that no yet

proposed.

3.2.1 Sensor Attack

Biometric data are captured using the sensor which

scans the biometric trait to convert it into digital form.

After converting it to digital form, the data is

transmitted to feature extraction module. The sensor

module is vulnerable to the “Attack at the sensor”. In

this attack (Figure 4), an attacker presents a fake

biometric trait such as an artificial finger or facial

image to the sensor in order to bypass recognition

systems. An attacker can also physically damage the

recognition system and flood the system with bogus

access requests. Sensors are unable to distinguish

between fake and real characteristics of an individual

and can be fooled easily by using synthetic

fingerprints or facial image of a person.

The most common attack is the one against the

sensor. When the samples acquisition process is fully

automated (e.g. no watching guard exists to monitor

the acquisition process) an impostor can easily bypass

the system by simply presenting a copy of biometric

data of a legitimate user in front of the sensor. The

attempt of breaking the biometric system using such

method is named spoofing attack. To date, there is no

commercial biometric technology that is robust

against such attacks. The copy may come in various

formats, depending on the biometric modality. In the

case of facial biometric, the impostor may present a

still image, video sequence playback, or even a 3D

silica or rubber mask of the genuine user. A

demonstration carried out using information from a

database stolen by the attacker which allows

illegitimate access to the system. This attack can be

made in several ways such as illustrated by Putte,

Keuning (Ton Van der Putte , 2000

Figure 4: Examples of Sensor Attacks.

Figure 5: Examples of Alteration Attacks.

In the case of fingerprints, authors did the

falsification of digital fingerprint with cooperation

(with liquid silicon) or without cooperation of the

user (creation of dummy finger by casting the finger

which filled with silicon). In the first case the

falsification is more efficient compared to the case of

non-cooperation. Matsumoto et al.(Tsutomu

Matsumoto, 2002

) have tested fingerprint falsified

with the help of real users in 11 biometric systems,

their results show’s that this attack can be performed

with a probability of 67%. A falsification data attack

is very used because it requires only false biometric

traits. For systems that are less secured, attacker can

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

518

soak the system in the first test, for systems that are

more secured access may be after several attempts

(Figure 5).

3.2.2 Trace Attack

Despite active research in recent years in the

evaluation of biometric-based applications, very few

studies have focused on the effect of alteration on the

security and robustness of these systems. Alteration

of fingerprints has been used to hide the identity of

the impostor and gain unauthorized access to the

biometric system. This alteration is classified into

three categories: obliteration, distortion, and

imitation. In the case of facial authentication, the

alteration is applied on the face via plastic surgery or

prosthetic make-up. With advances in technology, a

hacker was able to clone a politician’s fingerprint

using pictures taken at different angles with a

standard photo camera. In this paper, we present other

types of alterations that can be applied on different

biometric authentication systems, especially

biometric mobile applications. This attack can be

applied using different modalities, making it

dangerous not only in the case of mobile applications

based on fingerprint or facial authentication but also

in iris- and voice-based Mobile Information Systems

(Figure 6).

Figure 6: Illustration of Trace Attack.

3.2.3 Features Extraction Attack

During the features extraction attack, the attacker can

modify the extracted features; the attacker replaces

other characteristics by synthetic data (By pass

matcher Attack) on the channel. He could steal

biometric characteristics of the real user and submits

them to the matcher. This attack has a similar

treatment to the second attack; an attacker can give

characteristics generated depending on the purpose

desired as input to the correspondence. In this context

the more known attack system is developed by

Martinez who proposed a hill-climbing attack

(Martinez-Diaz 2006

) in a facial recognition system

using the correlation based on a filter. To have an

illegitimate access to the system he changed the input

image for obtaining the desired score.

This attack can disrupt the system by sending

random models; it has the principle of linking the

match score in the output. This attack can be

considered as type 2 or 4. Adler (Adler, A, 2003)

proposed a synthetic image of face to attack a face

recognition system. As a first step, an image was

randomly selected; it will be changed using the scores

returned by the matcher. The procedure is completed

if there is no improvement in score.

3.2.4 Intrusion Attack

In this attack we suppose that the attacker has the

secret key K

and the user’s helper data U enrolled

in the first systems S1, H

(U; K

)), then, the

attacker uses this information in order to estimate

user’s data in the second system S2 ( when the same

user’s is enrolled), the estimated data is then

presented to the system S2 as request in order to gain

illegitimate access (Figure 7).

Figure 7: Example of intrusion attack.

3.2.5 Correlation Attack

In this type of threats (Figure 8), the attacker try to

link several helper data His U (X

) when

1<i<n of the same user enrolled in different systems

in order to derive the original model Xu or the secret

key K

Figure 8: Example of Correlation attack.

3.2.6 Injection Attack

This attack aims to inject attackers biometric data in

the database (where the helper data H(U;K

) of the

Cracking Biometric Authentication Cryptosystems

519

real user U is stored in order to gain access to the

system (Figure 9).

Figure 9: Illustration of injection attack.

3.2.7 Combination Attack

The attacker has a part of user’s biometric features U

and try to create a complete request in order to gain

access to the system using the combination of some

data with the user’s stolen part ( U, A) (Figure 10).

Figure 10: Illustration of combination attack.

3.2.8 Filter Change Attack

In this attack (Figure 11), the attacker based on the

following observation, where the attacker uses the

helper data value to estimate the extracted features

which will be injected as user’s request. For example,

in Biometric cryptosystems based fuzzy vault

scheme, the attacker can detect the small free area in

the generated chaff point. Given the sketch PX of the

original X where |X| = s, the goal of an attacker is to

find X. The attacker can query a blackbox. On input

of a set Q of s points, the blackbox will return YES if

Q = X. The effectiveness of an attacker is measured

by the number of queries he sent. The blackbox is the

decryption of the file using the key Q. The output of

YES corresponds to the situation where the file is

successfully decrypted.

Figure 11: Filter change attack.

3.2.9 Error Correcting Parameter Attack

Instead of changing the error correcting module, the

attacker can change the error correcting parameters in

order to have high error correction capacity. For

example, we suppose that the system use RS(n, k)

where the coder uses the k symbol and added n

control symbol, resulting n-k , the RS can correct then

t symbol where 2t = nk.

3.2.10 Error Correcting Attack

Error correcting codes aim to cope with biometric

feature’s variations in biometric data. For these

reasons, Linear codes such as BCH, Reed Solom, are

used in the literature. However, these linear codes are

inflexible. Using these kinds of block codes requires

binary biometric vector having the same size of the

employed codeword, where some bits have to be

isolated, or a bits-padding has to be performed. On

the other hand, even if biometric cryptosystems are

provable secure in information theoretic sense, they

are indeed vulnerable to several dreadful security and

privacy attacks in practice. For example, the attacker

can change the error correcting module using error

correcting code with high error correction capacity.

3.2.11 Code Word Generation Attack

Attack based on error correction code histograms was

introduced in (Florence Jessie,1977). This attack aims

to run error correction in decoding mode which

returns always the nearest codeword. The attacker is

supposed in knowledge of applied error correction.

The decoder can correct more errors decreasing the

false rejection rate and increasing the false accept rate

is increased. Figure 14 explain the attack’s operation

mode. The binary biometric features are chosen by

the attacker and successive decommitment is applied

for each chunk in decoding mode. Based on counting

the number of possible codewords, the histogram is

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

520

stored and analyzed during the verification process

resulting the most likely codeword.

3.2.12 Key Generation Attack

In this attack the attacker can inject a generated series

as secret key so that he can gain access to the systems.

The key generation module can be also changed by

the attacker using another one that makes the

illegitimate access easier.

4 CONCLUSIONS

Biometric cryptosystems are proposed as secure

technologies for protecting biometric template.

However, these systems stay vulnerable to several

attacks. Despite active research in recent years in the

evaluation of biometric cryptosystems, very few

studies have focused on the security and robustness

of these systems. Most of proposed biometric

cryptosystems evaluation studies are based on

information theory such as entropy, mutual

information etc, these measures are difficult to be

estimated when the distribution of biometric features

is unknown ( do the intra-class and inter-class

variability). On other hand, many studies consider the

false acceptance rate FAR to evaluate the security

when this criterion is considered as performance

measure and can’t be sufficient to measure the

security. Consequently, the proposed studies to

analyze the security of biometric cryptosystems are

very limited. In order to present a generalized study

to evaluate the security of biometric cryptosystems,

we proposed in this work a generalized conception

framework. This framework takes in into account all

the modules threats.

REFERENCES

A. K. Jain, R. Bolle, and S. Pankanti, Eds., Biometrics:

Personal Identification in Networked Society. Norwell,

MA: Kluwer, 1999.

C. Soutar, D. Roberge, S. A. Stojanov, R. Gilroy, and B. V.

K. Vijaya Kumar, “Biometric encryption using image

processing,” in Proc. SPIE, Optical Security and

Counterfeit Deterrence Techniques II, vol. 3314, 1998,

pp. 178–188.

K. Nandakumar, A. Nagar, and A. K Jain. Hardening

fingerprint fuzzy vault using password. In Advances in

biometrics, pages 927-937.Springer, 2007.

Ari Juels and Martin Wattenberg. A fuzzy commitment

scheme. In Proceedings of the 6th ACM conference on

Computer and communications security, pages 28-36.

ACM, 1999.

Yongjin Wang and KN Plataniotis. Fuzzy vault for face

based cryptographic key generation. In Biometrics

Symposium, pages 1-6. IEEE, 2007.

Ross, A., Jain, A. (2003). Information fusion in biometrics.

Pattern Recognition Letters, 24 (13) 2115–2125

Ratha, N., Connell, J., Bolle, R. (2001). An analysis of

minutiae matching strength. In: Audio-and Video-

Based Biometric Person Authentication, p. 223–228.

Springer.

Hao, F., Anderson, R., Daugman, J. (2006). Combining

crypto with biometrics effectively, IEEE Transactions

on Computers, 55 (9) 1081–1088.

Li, Q., Sutcu, Y., Memon, N. (2006). Secure sketch for

biometric templates. Advances in Cryptology–

ASIACRYPT 2006, p. 99–113.

Uludag, U., Pankanti, S., Prabhakar, S., Jain, A. K. (2004).

Biometric cryptosystems: issues and challenges. In:

Proceedings of the IEEE, 92 (6) 948–960.

Juels, A., Wattenberg, M. (1999). A fuzzy commitment

scheme. In: Proceedings of the 6th ACM conference on

Computer and communications security, p. 28–36.

ACM

Juels, A., Sudan, M. (2006). A fuzzy vault scheme.

Designs, Codes and Cryptography, 38 (2) 237–257.

Scheirer, W. J., Boult, T. E. (2007). Cracking fuzzy vaults

and biometric encryption. In: Biometrics Symposium,

p. 1–6.IEEE.

Xuebing Zhou, Arjan Kuijper, Raymond Veldhuis, and

Christoph Busch. Quantifying privacy and security of

biometric fuzzy commitment. In International Joint

Conference on Biometrics (IJCB), pages 1-8. IEEE,

2011.

Abhishek Nagar, Karthik Nandakumar, and Anil K Jain.

Multibiometric cryptosystems based on feature-level

fusion. IEEE Transactions on Information Forensics

and Security, 7(1) :255-268, 2012.

Ye Wang, Shantanu Rane, Stark C Draper, and Prakash

Ishwar. An information-theoretic analysis of

revocability and reusability in secure biometrics. In

Information Theory and Applications Workshop (ITA),

pages 1-10. IEEE, 2011. (Cité en pages 45 et 50.)

Seira Hidano, Tetsushi Ohki, and Kenta Takahashi.

Evaluation of security for biometric guessing attacks in

biometric cryptosystem using fuzzy commitment

scheme. In BIOSIG-Proceedings of the International

Conference of the Biometrics Special Interest Group

(BIOSIG), pages 1-6. IEEE, 2012.

VS Meenakshi and G Padmavathi. Security analysis of

password hardened multimodal biometric fuzzy vault.

World Acad. Sci. Eng. Tech, 56 :312-320,2009.

Hisham Al-Assam and Sabah Jassim. Security evaluation

of biometric keys.computers & security, 31(2) :151-

163, 2012.

Andy Adler. Sample images can be independently restored

from face recognition templates. In CCECE Canadian

Conference on Electrical and Computer Engineering,

volume 2, pages 1163-1166. IEEE, 2003

Cracking Biometric Authentication Cryptosystems

521

Emile JC Kelkboom, Jeroen Breebaart, Ileana Buhan, and

Raymond NJ Veldhuis. Analytical template protection

performance and maximum key size given a gaussian-

modeled biometric source. In SPIE Defense, Security,

and Sensing, pages 76670D-76670D. International

Society for Optics and Photonics, 2010.

Tanya Ignatenko and Frans MJ Willems. Information

leakage in fuzzy commitment schemes. IEEE

Transactions on Information Forensics and Security,

5(2) :337-348, 2010. (Cité en page 46.)

Christian Rathgeb and Andreas Uhl. Statistical attack

against fuzzy commitment scheme. IET biometrics,

1(2) :94104, 2012. (Cité en pages 46 et 52.)

A Stoianov, T Kevenaar, and M Van der Veen. Security

issues of biometric encryption. In Toronto International

Conferenceon Science and Technology for Humanity

(TIC-STH), pages 3439. IEEE, 2009.

Preda Mihailescu. The fuzzy vault for fingerprints is

vulnerable to brute force attack. arXiv preprint arXiv

:0708.2974, 2007.

Benjamin Tams. Attacks and countermeasures in

fingerprint based biometric cryptosystems. arXiv

preprint arXiv :1304.7386, 2013

Soweon Yoon, Jianjiang Feng, and Anil K Jain. Altered

fingerprints : Analysis and detection. IEEE

Transactions on Pattern Analysis and

MachineIntelligence, 34(3) :451- 464, 2012.

T Charles Clancy, Negar Kiyavash, and Dennis J Lin.

Secure smartcard based fingerprint authentication. In

Proceedings of the ACM SIGMM workshop on

Biometrics methods and applications, pages 45-52.

ACM, 2003

Walter J Scheirer and Terrance E Boult. Cracking fuzzy

vaults and biometric encryption. In Biometrics

Symposium, pages 1-6. IEEE, 2007

Hoi Ting Poona and Ali Miria. A collusion attack on the

fuzzy vault scheme. The ISC Int'l Journal of

Information Security. Bd, 1(1), 2009.

Ton Van der Putte and Jeroen Keuning. Biometrical

fingerprint recognition : don't get your fingers burned.

In Smart Card Research and Advanced Applications,

pages 289-303. Springer, 2000 .

Tsutomu Matsumoto, Hiroyuki Matsumoto, Koji Yamada,

and Satoshi Hoshino. Impact of artificial gummy

fingers on fingerprint systems. In Electronic Imaging,

pages 275-289. International Society for Optics and

Photonics, 2002.

Martinez-Diaz, M., Fierrez-Aguilar, J., Alonso-Fernandez,

F., Ortega-Garcia, J., JA Siguenza. Hill-climbing and

brute-force attacks on biometric systems: A case study

in match-on-card fingerprint verification. In: Carnahan

Conferences Security Technology, Proceedings 2006

40th Annual IEEE International, p.151–159. IEEE

Adler, A. (2003). Sample images can be independently

restored from face recognition templates. In: Electrical

and Computer Engineering. IEEE CCECE 2003.

Canadian Conference on, 2, 1163–1166. IEEE

Florence Jessie MacWilliams and Neil James Alexander

Sloane. The theory of error correcting codes, volume

16. Elsevier,1977.

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

522
