Forensic Analysis of Heterogeneous Social Media Data

Aikaterini Nikolaidou, Michalis Lazaridis, Theodoros Semertzidis, Apostolos Axenopoulos

and Petros Daras

Information Technologies Institute, CERTH, Thessaloniki, Greece

Keywords:

Social Media Analytics Forensic Platform, Heterogeneous Social Media Data, Ontology, Labeled Property

Graph.

Abstract:

It is a challenge to aggregate and analyze data from heterogeneous social media sources not only for busi-

nesses and organizations but also for Law Enforcement Agencies. The latter’s core objectives are to monitor

criminal and terrorist related activities and to identify the ”key players” in various networks. In this paper,

a framework for homogenizing and exploiting data from multiple sources is presented. Moreover, as part of

the framework, an ontology that reﬂects today’s social media perceptions is introduced. Data from multiple

sources is transformed into a labeled property graph and stored in a graph database in a homogenized way

based on the proposed ontology. The result is a cross-source analysis system where end-users can explore

different scenarios and draw conclusions through a library of predeﬁned query placeholders that focus on

forensic investigation. The framework is evaluated on the Stormfront dataset, a radical right, web community.

Finally, the beneﬁts of applying the proposed framework to discover and visualize the relationships between

the Stormfront proﬁles are presented.

1 INTRODUCTION

Social media sites constitute a rich pool of evolving

content along with personal data, preferences, activi-

ties and relationships. Due to their affordability and

accessibility, social media is a means of communi-

cation and action for criminal and terrorist organiza-

tions. At earlier times, most crimes left breadcrumbs

of evidence in the real world. Nowadays, through

the interactive social media platforms, offenders en-

gage in illicit practices such as fraud, cyber stalking,

cyber bullying etc. (Gambhir, 2018). Terrorists ex-

ploit social media to reach audiences for potential re-

cruits, disseminate messages and organize strategic

operations (Bertram, 2016). Furthermore, social me-

dia play a key role in political socialization in terms

of inﬂuencing individual behavior and preparedness

to participate in collective actions (Passy, 2000).

Law Enforcement Agencies (LEAs) wish to take

advantage of these information sources for the sake

of security. For monitoring and analyzing criminal-

related activity in social media networks, one major

question is to identify the most inﬂuential proﬁles,

known also as ”key player” discovery (Zenou, 2016).

LEAs are also interested in answering the so called

six W’s: Who, What, When, Where, Why and How.

These questions are fundamental and are traditionally

raised during criminal investigations (Carrier et al.,

2003).

Social media evidence provides information about

a suspect’s or a victim’s proﬁle that can be mined

in close-to-real-time. The contacts, messages, geo-

location data, photos and generally their daily activi-

ties are offered in a chronological order. Monitoring

and analyzing the abundance of information shared by

social media users and social media metadata should

theoretically facilitate LEAs to gain insights into mass

communication and come to fruitful conclusions in an

inquiry. However, this kind of exploration is by no

means a straightforward task.

A recent research by Arshad et al. (Arshad et al.,

2019) explains the challenges that law enforcement

personnel face when handling social media data for

forensic investigation. The ﬁrst issue the authors ob-

serve is that in a single social media investigation,

some data elements are considered out of context and

not taken into account. Moreover, the components of

data which they consider important are stored sepa-

rately. All fragmented and unstructured social me-

dia information, although it may seem to be of little

importance, would be very useful if it was in a co-

herent representation and in chronological order. Be-

Nikolaidou, A., Lazaridis, M., Semertzidis, T., Axenopoulos, A. and Daras, P.

Forensic Analysis of Heterogeneous Social Media Data.

DOI: 10.5220/0008347803430350

In Proceedings of the 11th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2019), pages 343-350

ISBN: 978-989-758-382-7

343

sides, due to the separate storage of data, data analy-

sis is limited to keyword search which is inadequate

for a forensic investigation. The second challenge in

a social media forensic tool development, is to deal

with the heterogeneity of different social media plat-

forms. There are also several references in the lit-

erature that emphasize the need for cyber forensic

tools that support heterogeneous research in an au-

tomated way (Caviglione et al., 2017), (Soltani and

Seno, 2017), (Montasari and Hill, 2019). A forensic

tool developed for one social media platform, may not

be suitable for another platform because they differ in

concepts, structure, data formats, and access methods.

According to one of the most accepted approaches

for Social Media Analytics (SMA) proposed in

(Stieglitz et al., 2014), a typical procedure for SMA

consists of the following four steps: i) Discovery of

the topics that should be tracked; ii) Tracking, which

involves data source selection, approach, method and

output; iii) Preparation of the data and iv) Analysis.

Regarding analysis step, Karabiyik et al. (Karabiyik

et al., 2016) point out that Social Network Analysis

(SNA) is crucial during a digital forensic research for

understanding the links between proﬁles. SNA uses

graph algorithms to analyze the structure of the net-

work, discovers strategic positions and speciﬁc sub-

networks. Through SNA, LEAs would discover in-

valuable hidden associations and knowledge in the so-

cial data. Decomposing a social graph to communi-

ties yields a deeper insight to these seemingly chaotic

interactions. The results from SNA in digital forensic

investigations can solve criminal cases, prevent terror-

ist attacks, track frauds, classify and match social net-

work accounts etc. However, despite the great need

to identify and analyze network structures of terrorist

and criminal groups, existing digital forensic tools do

not provide such functionality.

The objective of this paper is to bridge the gap

between the dispersed social media data and the so-

cial media forensic applications. This study deﬁnes

a uniﬁed framework to exceed the heterogeneity of

different social media platforms and to homogenize

their data. The security-oriented framework will per-

mit both the preservation as well as the search and the

correlation while providing automated tools for data

analysis and visualization. The main goals and con-

tribution of this paper are the following:

• A new ontology is introduced to reﬂect the major-

ity of today’s social media perceptions. Based on

this uniﬁed ontology, heterogeneous social media

data is integrated into a single, structured, cohe-

sive representation. The ultimate goal is to aggre-

gate data not only from social media sites but also

from other relevant physical or cyber data sources.

• The uniﬁed framework that uses the aforemen-

tioned ontology is presented. The framework al-

lows the homogenization of data from multiple

sources and thus the consolidated handling and

querying of the data for further forensic analysis.

It focuses on the three last steps of a SMA pro-

cess: tracking, preparation and analysis for data

from various social media sources.

• The cross-source analysis system, as part of

the framework, that supports advanced custom

queries and SNA methods for discovery of hid-

den knowledge. LEAs would use it for investiga-

tion and evidence-building through a predeﬁned

set of query placeholders that hide all technical

complexities.

As a demonstration, the framework is applied to

discover and visualize the relationships between the

proﬁles associated with Stormfront

. Stormfront is

one of many examples of radical right wing virtual

communities, but it is the oldest ”hate” website.

The implementation is based entirely on open-

source tools. The framework’s procedures are de-

veloped in Python. Choosing an appropriate soft-

ware architecture and storage technology is one of the

major challenges in social media analytics (Stieglitz

et al., 2018). Social networks can be very big but

sparse since a user is likely to interact with a small

percentage of users (Leung and Jiang, 2017). The

proposed framework’s use case demands a reliable

graph storage and retrieval technology that supports

efﬁcient execution of complex queries in large and

sparse graphs that can scale up to billions of nodes.

The labeled property graph database Neo4j

fulﬁlls

these requirements, and was therefore chosen for this

work. The predeﬁned query placeholders have been

implemented in Cypher

query language. It must be

stressed that the proposed ontology at this stage pro-

vides the conceptualization of the given domain.

This paper is organized as follows. Related work

is reviewed in Section 2. In Section 3 the proposed

framework for tracking, preparing and analyzing the

social media data is illustrated. Section 4 describes

the proposed ontology. Section 5 provides the experi-

mental steps using real data from Stormfront. Section

6 presents the conclusion.

https://www.stormfront.org/forum/index.php

https://neo4j.com/

https://neo4j.com/developer/cypher-query-language/

KEOD 2019 - 11th International Conference on Knowledge Engineering and Ontology Development

344

2 RELATED WORK

Research in social media forensic analysis can be

divided into two parts: a) general investigative ap-

proaches and b) ontology-based approaches.

There is a signiﬁcant number of recent studies

in the literature that analyze social media data for

investigative purposes. In (Mouhssine and Khalid,

2018), a framework is proposed that performs senti-

ment analysis and detects extremist content on Face-

book. A security alert mechanism making use of a

supervised machine learning approach for real-time

phishing tweet detection on Twitter is presented in

(Liew et al., 2019). Alghofaili and Almishari (Algho-

faili and Almishari, 2018) detect Arabic-based Twit-

ter proﬁles that incite terrorism by categorizing ac-

counts as either inciting or non-inciting of terrorism.

To do so, they extract relevant features, which are

later fed to machine learning-based classiﬁers to dif-

ferentiate inciting from non-inciting accounts. Nouh

et al. (Nouh et al., 2019) use textual and psycholin-

guistic signals derived by ISIS for recruitment pur-

poses to detect extremist content on Twitter. An ap-

proach for detecting radical users of social network

among unknown ones is presented by Petrovskiy and

Chikunov (Petrovskiy and Chikunov, 2019). The au-

thors analyse the relationships and features of the

users as of vertices of social graph. However accord-

ing to their method, a part of the network commu-

nity must be labeled as dangerous, safe or unknown.

In (S

anchez-Rebollo et al., 2019), a methodology is

developed to detect the leaders orchestrating terror-

ist networks and their followers that remain partially

hidden. They use fuzzy clustering to point out the

dangerous proﬁles and they focus on the analysis of

Twitter messages.

The use of ontologies is an approach for mod-

eling social networks that offers several advantages

(Oellinger and Oezden Wennerberg, 2006). Mas-

moudi et al. (Masmoudi et al., 2018) propose a

method for mining radicalization indicators from on-

line messages. The social messages are annotated

with concepts from a domain ontology the authors

designed. The ontology focuses on the users and

their messages. During an inference phase the mes-

sages exhibiting a radicalization indicator are iden-

tiﬁed by exploiting the annotations. An ontology

named ”SC-Ont” that focuses on data that can be ob-

tained from Facebook and Google is published by

Kalemi and Yildirim-Yayilgan (Kalemi and Yildirim-

Yayilgan, 2016). The ontology serves for cataloging

online information regarding suspects and informa-

tion from witnesses. Tserpes et al. (Tserpes et al.,

2012) developed an ontology called ”SocIoS” on top

of the concept that entities in the various online so-

cial network sites have largely similar notions. Their

ontology is an effort to cover most of the concepts

of the social networks. However, the model does not

cover some today’s important concepts and it is not

explained how to use it. Fang et al. (Fang et al.,

2019) also proposed an ontology to aggregate data

from different social network sites for event analysis

purposes. The design of a speciﬁc analysis applica-

tion is out of the scope of their work.

In this paper we expand on the previous work

in (Tserpes et al., 2012) and propose an ontology to

cover the concepts of modern social media platforms.

Social media data and interactive behaviours com-

mon to heterogeneous social media platforms will be

stored on the basis of the ontology in a structured and

coherent way in a common graph database. The result

will be a sophisticated security-oriented cross-source

forensic analysis application. LEAs will have the op-

portunity to explore all aspects of the information pro-

vided by the social media sources. The investigators

do not need to have technical knowledge since a set

of predeﬁned query placeholders related to forensic

inquiry will be at their disposal.

3 PROPOSED FRAMEWORK

The proposed framework is depicted in Figure 1, and

mainly corresponds to the three last steps of a Social

Media Analytics process: tracking, preparation and

analysis for data from multiple social media sources.

After data tracking by platform-speciﬁc APIs pro-

vided by online social networks such as Facebook,

Twitter, LinkedIn and others, or crawlers, the prepa-

ration phase follows. In this work, a new ontology

is introduced to reﬂect the majority of today’s social

media perceptions. The new ontology will be called

Uniﬁed Social Network Ontology (USNO). To easily

adapt the proposed approach, social-media-speciﬁc

plugins have been developed for some social media

sites: Skype, Twitter, Stormfront. A separate plugin

can be developed for each social media site of inter-

est. Each social-media-speciﬁc plugin, takes as input

the corresponding social media data. The USNO de-

scribes in detail how the social media data must be

stored in the graph database. It depicts the node la-

bels, the node properties and the relationships that

will link the nodes/entities in the graph. The data is

processed according to each social media site to re-

trieve implicit knowledge related to the uniﬁed ontol-

ogy we introduced. Then, the data is mapped to the

USNO.

In the next step, the social media data is stored in

Forensic Analysis of Heterogeneous Social Media Data

345

the graph database Neo4j. For each element a new

node is created. For example a ”hashtag” shared by

multiple posts is represented by a single node. In

order to thoroughly analyze the interaction between

the proﬁles, an inference mechanism has been imple-

mented to create direct links between the proﬁles that

communicate with each other if these links are not ex-

plicitly provided. Also a mechanism to detect data in-

consistencies in the graph database is supported. For

example, we developed a Cypher rule to check the

validity of the proﬁle identiﬁcation numbers. A pro-

ﬁle identiﬁcation number must correspond to a unique

username for a single social media platform.

As for the analysis phase, we have developed

Cypher queries to retrieve information and relation-

ships related to forensic research on proﬁles. Queries

can take as arguments the inputs of the end-users. For

example the objective of a query could be the follow-

ing: Given the location of a crime and a time frame,

return all conversations and conversationalists, events

and media items that refer to the crime location dur-

ing this time frame. Furthermore, SNA can be per-

formed thanks to an efﬁciently implemented library

of common graph algorithms exposed as Cypher pro-

cedures provided by Neo4j (Amy E. Hodler, 2019).

They can provide insights on relevant proﬁles using

centrality algorithms, or implicit structures like com-

munities using community detection algorithms. The

result after the algorithms execution can be written

back as a node property and be used for further anal-

ysis. Investigators have the opportunity to perform

complex data analysis and visualize the results, at the

touch of a button. More examples on the analysis

phase are provided in section 5.

Figure 1: Proposed framework for data preparation and

analysis.

4 UNIFIED SOCIAL NETWORK

ONTOLOGY

Uniﬁed Social Network Ontology is depicted in Fig-

ure 2. It consists of 11 classes that are associated with

20 relationships. In the following section, the classes

along with their properties are presented.

Figure 2: Uniﬁed Social Network Ontology.

4.1 Classes and Properties

In addition to the attributes listed below, each class

has another property, its identiﬁcation number.

1. Social Network Site: It can be any social me-

dia site like Facebook, Instagram, Stormfront etc.

The properties include:

• Platform: The name of the social network plat-

form e.g. Facebook, Instagram, Stormfront etc.

2. SNS Proﬁle: A social network proﬁle. The prop-

erties include:

• Username: A proﬁle’s username.

• Proﬁle title: A proﬁle’s title e.g. member,

guest.

• Email: A proﬁle’s email address.

• Proﬁle lang: The speaking language of a pro-

ﬁle.

• Registered date: The date a proﬁle became

member of the social network.

• Ethnicity: The ethnicity of the proﬁle.

• Gender: The gender of the proﬁle.

• Birthday: The birthday of the proﬁle.

3. Real Entity: A real physical entity e.g. a person,

a business, a group of people. The properties in-

clude:

KEOD 2019 - 11th International Conference on Knowledge Engineering and Ontology Development

346

• Entity type: The real physical person(s) who

manage the proﬁle e.g. person, business, group

of people.

4. Message: Refers either to inbox or post. The

properties include:

• Msg type: The type of the message e.g. post or

inbox.

• Content: The full content of the message.

• Msg lang: The language in which the message

was written.

• Msg security: The security level of the mes-

sage e.g. public or private.

• Date sent: The date and time of sharing the

message.

• Num views: The number of views of the mes-

sage.

5. MediaItem: A media item can have different con-

tent formats such as embedded image, embedded

video, youtube video, hyperlink with clicking text

or image and it is attached to a message.

• Mediaitem type: The type of the media item

e.g. embedded image, embedded video,

youtube video, hyperlink with clicking text or

image.

• Mediaitem url: The url of the media item.

• Mediaitem text: The alternate text of an image

or the content of a clicking text.

• Filename: The ﬁlename of the media item.

• Lng lat: A text representation of the coordi-

nate data as latitude and longitude e.g. ”470999

1234300”.

6. Collection: A collection contains messages with

common elements e.g. topic, hashtag.

• Collection type: The collection’s type e.g.

topic, library, shared folder, hashtag.

• Collection name: The collection’s name.

7. Group: A group provides a space to communicate

about shared interests with certain people.

• Group title: Title of the group.

• Description: Description of the group.

• Group security: The security level of the group

e.g. public, closed or secret.

8. Tag: A link to a proﬁle along with a media item.

• Bounding box: A text representation of 2 lon-

gitudes and 2 latitudes coordinates of a tagged

proﬁle in a media item e.g ”6.73462 6.75652

-53.57835 -53.56289”.

9. Event: An event lets a proﬁle to organize and re-

spond to gatherings in the real world.

• Event title: The event’s title.

• Event location: An abstract region of space

(e.g. a geospatial point or region) where the

event will take place.

• Event security: The security level of the event

e.g. private or public.

• Event timestamp: The time and date of the

event.

10. Rating: A measurement of how good or popular a

message is.

• Num like: The score that depicts the positive

rating of a message.

• Num dislike: The score that depicts the nega-

tive rating of a message.

11. Extracted Entity: An entity that is extracted from

a message after performing named-entity recogni-

tion. It can be: location, person or organization.

• Extracted entity type: The extracted entity’s

type e.g. location, person or organization

• Extracted entity name: The extracted entity’s

name. e.g. for type ”location” the name could

be ”London”.

5 STORMFRONT CASE STUDY

To demonstrate our framework we have implemented

a plugin for Stormfront, the world’s oldest and largest

white supremacist internet forum, which has hosted

some of the most lethal hate criminals and mass mur-

derers of the right-wing extremist movement. Anal-

ysis for Stormfront data has gained a lot of atten-

tion. According to a two-year investigation by South-

ern Poverty Law Center in 2014, registered Storm-

front users have been responsible for approximately

100 murders (Beirich, 2014). The proposed model

is instantiated on Stormfront social case study to be

validated. Extensive Stormfront data collected by a

crawler are used, for the period from September 2001

to July 2017 totaling 4,488,476 posts and 355008

users. We will present how LEAs could explore this

dataset.

5.1 Stormfront Data Preparation

Data was initially in a raw form, thus it was very difﬁ-

cult to analyze and discover the ”key players”. In the

preparation phase, the ”Stormfront plugin”, takes as

input the data and analyzes the contents of the posts

to discover implicit information related to USNO. For

example the reply posts, the posts with media ﬁles,

the images and texts with hyperlinks are retrieved.

Forensic Analysis of Heterogeneous Social Media Data

347

Also named-entity recognition is supported. Every

post message is examined for named entity mentions

of type person, location and organization. After this

stage, the data is mapped to the USNO and stored

in the Neo4j. The ”Stormfront plugin”, creates all

the nodes, properties and relationships in the graph

database.

To directly associate proﬁles and perform SNA to

retrieve hidden knowledge, a Cypher rule has been

developed to create a new ”INTERACTS WITH”

relationship between proﬁles that have communica-

tion interaction. For example, proﬁle ”A” ”INTER-

ACTS WITH” proﬁle ”B” if ”A” has responded to a

post shared by ”B”, thus directly linking the two pro-

ﬁles. In order to detect potential inappropriate proﬁle

identiﬁcation numbers, a Cypher rule checks that each

proﬁle identiﬁcation number corresponds to a unique

username. Figure 3 illustrates the Stromfront Neo4j

schema.

Figure 3: Stormfront Neo4j schema.

5.2 Stormfront Data Analysis

Neo4j provides a library of common graph algorithms

exposed as Cypher procedures. Graph algorithms in

this case could be applied to the subgraph containing

nodes labeled ”SNS Proﬁle” and associated with the

relationship ”INTERACTS WITH”. The interaction

between social network proﬁles provides valuable in-

formation regarding their importance and respective

role within the subgraph. Since most graph algo-

rithms run better on a connected component, initially

the investigators could isolate the largest subgraph(s)

of proﬁles that interact with each other to understand

a graph’s structure. The Connected Components al-

gorithm is applied behind the scenes. After that, the

”islands” will be revealed where each node is acces-

sible from any other node in the same set.

To discover communities in the ”islands” commu-

nity detection algorithms would be applied. Tsve-

tovat and Kouznetsov (Tsvetovat and Kouznetsov,

2011) report that Al Qaeda members are organized

in small cells during training and preparation for ter-

rorist attacks. The cells have a dense triadic structure,

with everyone embedded in triads with everyone else.

LEAs could use the cross-source analysis system to

discover the triangles in the network. A triangle is a

set of three nodes, where each node has a relationship

to all other nodes. They could also discover the num-

ber and density of the triangles to which a proﬁle is

a member. In these cases, the Triangle Counting and

Clustering Coefﬁcient algorithms are applied. Investi-

gators could also detect communities in the ”islands”

using the Louvain Modularity algorithm. Commu-

nities are groups of nodes within a network that are

more densely connected to one another than to other

nodes.

In order to detect the ”key players”, their role

and their impact on the network, centrality algorithms

would be used. To quantify the amount of inﬂuence

a node has over the ﬂow of information in the graph,

the Betweenness Centrality algorithm is applied. Be-

tweenness is appropriate to discover the most central

proﬁles, nodes that serve as a bridge from one part of

a graph to another. Closeness Centrality algorithm is

applied to detect the proﬁles that are able to spread in-

formation very efﬁciently through the graph. To mea-

sure the transitive inﬂuence of the proﬁles the PageR-

ank algorithm is used. This is a very important cen-

trality measure as it takes into account the inﬂuence

of a node’s neighbors, and their neighbors.

Querying the graph with Cypher gives important

insights to the discovery of important proﬁles, and in-

formation about them and their connection to other

proﬁles. The queries can focus on a particular known

proﬁle. Below are listed some examples of automated

queries provided by our platform:

• Given speciﬁc keywords, discover the proﬁle that

sent the most messages that started a conversation

related to the keywords.

• Given a speciﬁc proﬁle, list the proﬁles that he/she

will engage and respond.

• Discover the length of the conversations and the

number of people who are involved in them.

• Given a speciﬁc proﬁle, discover the number

of conversations started by him/her, the average

length of the conversations and the average par-

ticipants.

• Track conversations about a particular topic or for

a speciﬁc period of time.

KEOD 2019 - 11th International Conference on Knowledge Engineering and Ontology Development

348

• Discover post volume by day or month.

• Explore around certain entities of type person, lo-

cation and organization. For example, discover

which locations are mentioned for a speciﬁc date.

Our tool gives investigators the opportunity to an-

swer very complex custom queries at a touch of a

button. For example, the following query runs be-

hind the scenes to detect ”cliques”, that is, groups

of proﬁles that post to common topics. The investi-

gators would only give the input parameters. In this

case the parameters are ”number of common topics”,

”from period” and ”to period”.

MATCH

(u1:SNS_Profile)<-[:HAS_USER_SENDER]

-(m:Message)

-[:BELONGS_TO_COLLECTION]->(c:Collection)

<-[:BELONGS_TO_COLLECTION]-(m1:Message)

-[:HAS_USER_SENDER]->(u:SNS_Profile)

WHERE ID(u1) > ID(u)

AND m.date_sent > $from_period

AND m.date_sent < $to_period

AND m1.date_sent > $from_period

AND m1.date_sent < $to_period

WITH collect(DISTINCT c) AS topics,

u1.username AS user, u.username AS users

WHERE

size(topics)>$number_of_common_topics

WITH collect(users) AS group,topics,user

WITH collect(user)+group AS clique,

size(topics) AS number_of_topics

RETURN clique, number_of_topics

ORDER BY number_of_topics DESC

A similar but more concrete query could return the

cliques, where a speciﬁc ”targeted” proﬁle takes part,

revealing proﬁles in his/her circle.

6 CONCLUSIONS

In this paper, we aim at homogenizing data from mul-

tiple social media sources to bring them into a uniﬁed

cross-source analysis system for forensic purposes.

The Uniﬁed Social Network Ontology has been intro-

duced as part of a framework for tracking, preparing

and analyzing data. The ontology covers the major-

ity of today’s social media perceptions. We have de-

veloped social-media-speciﬁc plugins to map the data

to the USNO and store them in a labeled property

graph database. As a result the raw data are associ-

ated and stored in a coherent representation based on

the USNO. The homogeneity of the data and its reten-

tion in a common database is the basis on which we

have implemented a sophisticated forensic tool to go

beyond keyword search and respond to complicated

investigation queries. We designed a number of pre-

deﬁned query placeholders which give insights into

the network structure and reveal the most important

proﬁles through SNA methods. In addition, LEAs

will easily detect any indication that could provide the

social media data. For example law enforcement per-

sonnel will track conversations and their frequency,

discover all information about a speciﬁc proﬁle, ex-

plore around a particular topic for a given location

and time frame, and so on. The automatic data ho-

mogenization, preservation and analysis will reduce

signiﬁcantly the investigation cost.

In the demonstration and case study, the proposed

framework has been applied to Stormfront internet fo-

rum. The plugin we developed for Stormfront is re-

sponsible for mapping the data to the USNO and im-

porting them into the graph database. After this stage,

we demonstrated how LEAs could explore the graph

to discover important proﬁles, relationships and evi-

dence through the library of predeﬁned query place-

holders. An advantage of the proposed framework is

that it can be easily adapted to represent data from

other social networks. As a proof of concept, it

has also been applied to Twitter dataset

to investi-

gate Twitter-related data like mentions, hashtags and

retweets.

In future work, we will investigate new analysis

algorithms such as proﬁle matching to be added to the

library with the predeﬁned query placeholders. Thus,

a new relationship ”MATCHES WITH” will be cre-

ated between the proﬁles that correspond to the same

person. Associating user proﬁles to many social net-

works would provide, among other things, the oppor-

tunity to better understand the interplay between the

different types of suspect’s operations.

ACKNOWLEDGEMENTS

The work presented in this paper was supported by the

European Commission under contract H2020-700381

ASGARD.

REFERENCES

Alghofaili, H. and Almishari, M. (2018). Countering ter-

rorism incitement of twitter proﬁles in arabic-context.

In 2018 21st Saudi Computer Society National Com-

puter Conference (NCC), pages 1–5.

Amy E. Hodler, M. N. (2019). Graph Algorithms: Practi-

cal Examples in Apache Spark and Neo4j. ” O’Reilly

Media, Inc.”.

https://www.kaggle.com/ﬁfthtribe/how-isis-uses-twitter

Forensic Analysis of Heterogeneous Social Media Data

349

Arshad, H., Jantan, A., and Omolara, E. (2019). Evidence

collection and forensics on social networks: Research

challenges and directions. Digital Investigation.

Beirich, H. (2014). White homicide worldwide. SPLC In-

telligence Report, (154).

Bertram, L. (2016). Terrorism, the internet and the so-

cial media advantage: Exploring how terrorist orga-

nizations exploit aspects of the internet, social me-

dia and how these same platforms could be used to

counter-violent extremism. Journal for Deradicaliza-

tion, (7):225–252.

Carrier, B., Spafford, E. H., et al. (2003). Getting physical

with the digital investigation process. International

Journal of digital evidence, 2(2):1–20.

Caviglione, L., Wendzel, S., and Mazurczyk, W. (2017).

The future of digital forensics: Challenges and the

road ahead. IEEE Security Privacy, 15(6):12–17.

Fang, M., Li, Y., Hu, Y., Mao, S., and Shi, P. (2019). A uni-

ﬁed semantic model for cross-media events analysis in

online social networks. IEEE Access.

Gambhir, A. (2018). Cyber crime and their impacts in vari-

ous aspects. International Journal of Technical Inno-

vation in Modern Engineering & Science (IJTIMES),

Kalemi, E. and Yildirim-Yayilgan, S. (2016). Ontologies

for social media digital evidence. International Jour-

nal of Computer, Electrical, Automation, Control and

Information Engineering, 10(2):335–340.

Karabiyik, U., Canbaz, M. A., Aksoy, A., Tuna, T., Akbas,

E., Gonen, B., and Aygun, R. (2016). A survey of

social network forensics. Journal of Digital Forensics,

Security and Law (JDFSL), 11:55–128.

Leung, C. K. and Jiang, F. (2017). Efﬁcient mining

of’following’patterns from very big but sparse social

networks. In Proceedings of the 2017 IEEE/ACM In-

ternational Conference on Advances in Social Net-

works Analysis and Mining 2017, pages 1025–1032.

ACM.

Liew, S. W., Sani, N. F. M., Abdullah, M. T., Yaakob, R.,

and Sharum, M. Y. (2019). An effective security alert

mechanism for real-time phishing tweet detection on

twitter. Computers & Security, 83:201–207.

Masmoudi, A., Barhamgi, M., Faci, N., Saoud, Z., Belhaj-

jame, K., Benslimane, D., and Camacho, D. (2018).

An ontology-based approach for mining radicaliza-

tion indicators from online messages. In 2018 IEEE

32nd International Conference on Advanced Informa-

tion Networking and Applications (AINA), pages 609–

616.

Montasari, R. and Hill, R. (2019). Next-generation digital

forensics: Challenges and future paradigms. In 2019

IEEE 12th International Conference on Global Secu-

rity, Safety and Sustainability (ICGS3), pages 205–

212.

Mouhssine, E. and Khalid, C. (2018). Social big data min-

ing framework for extremist content detection in so-

cial networks. In 2018 International Symposium on

Advanced Electrical and Communication Technolo-

gies (ISAECT), pages 1–5.

Nouh, M., Nurse, J. R. C., and Goldsmith, M. (2019). Un-

derstanding the radical mind: Identifying signals to

detect extremist content on twitter.

Oellinger, T. and Oezden Wennerberg, P. (2006). Ontology

based modeling and visualization of social networks

for the web. volume 2, pages 489–497.

Passy, F. (2000). Socialization, recruitment, and the struc-

ture/agency gap. a speciﬁcation of the impact of net-

works on participation in social movements. In So-

cial Movement Analysis: The Network Perspective, a

workshop held at Ross Priory, Loch Lomond, Scot-

land, June, pages 22–25.

Petrovskiy, M. and Chikunov, M. (2019). Online extremism

discovering through social network structure analysis.

In 2019 IEEE 2nd International Conference on In-

formation and Computer Technologies (ICICT), pages

243–249.

anchez-Rebollo, C., Puente, C., Palacios, R., Piriz, C.,

Fuentes, J. P., and Jarauta, J. (2019). Detection of

jihadism in social networks using big data techniques

supported by graphs and fuzzy clustering. Complexity,

2019.

Soltani, S. and Seno, S. A. H. (2017). A survey on digi-

tal evidence collection and analysis. In 2017 7th In-

ternational Conference on Computer and Knowledge

Engineering (ICCKE), pages 247–253.

Stieglitz, S., Dang-Xuan, L., Bruns, A., and Neuberger, C.

(2014). Social media analytics - an interdisciplinary

approach and its implications for information systems.

Business & Information Systems Engineering, 6:89–

96.

Stieglitz, S., Mirbabaie, M., Ross, B., and Neuberger, C.

(2018). Social media analytics–challenges in topic

discovery, data collection, and data preparation. Inter-

national journal of information management, 39:156–

168.

Tserpes, K., Papadakis, G., Kardara, M., Papaoikonomou,

A., Aisopos, F., Sardis, E., and Varvarigou, T. A.

(2012). An ontology for social networking sites in-

teroperability. In KEOD, pages 245–250.

Tsvetovat, M. and Kouznetsov, A. (2011). Social Network

Analysis for Startups: Finding connections on the so-

cial web. ” O’Reilly Media, Inc.”.

Zenou, Y. (2016). Key players. Oxford Handbook on the

Economics of Networks, Oxford: Oxford University

Press, forthcoming.

KEOD 2019 - 11th International Conference on Knowledge Engineering and Ontology Development

350
