A Scene Division Method Based on Theme

Fuping Yang

, Zhichun Yuan

and Xi Cheng

Department of Computer Science and Technology, Chongqing University of Posts and Telecommunications

NanShan Street, Chongqing, China

Keywords: Text-to-scene, Scene division, Multi-scene text, Scene features, Scene themes.

Abstract: The text-to-scene conversion is such a process that converts the input text to 3D scenes automatically based

on the natural language processing. The scene division is one of the basic research contents of the text-to-

scene conversion, and it mainly identifies and divides the number and structure of scenes in multi-scene text.

In this paper, the general expression of the scene is obtained through the analysis of scene features, and then

the method for divide multi-scene text which to use scene themes has been proposed. In the experiment, the

LDA model is used to divide the multi-scene text, and this method is applied to the standard data set. The

experiments show that the expected results are achieved.

1 INTRODUCTION

Language is an important communication tool for

human beings, and it can convey people’s thoughts

and display visual scenes that are imagined in the

brain. The concept of “text-to-scene” was first

proposed by Coyne and Sproat (Coyne, 2001),

which refers to the process of automatically

converting a natural language text description into a

three-dimensional static scene or animation. Manual

building a 3D scene is a time-consuming and

intensive process that requires users to adopt and

learn professional graphics tools and interfaces, and

such requirements limit the number of potential

users (Seversky, 2006). The purpose of text-to-scene

conversion is to enable people for the non-graphics

professional field to realize the scenes in their minds

through simple text descriptions, to make

communication between each other faster and more

intuitive, reduce the process of manually

constructing scenes, and improve work efficiency.

At present, the research of the text-to-scene

conversion is in its infancy and has not yet formed a

complete theoretical system. Some scholars have

made a preliminary exploration of the text-to-scene

conversion, and there are already a lot of prototype

systems. Story Picturing Engine (Joshi, 2004) refers

to the process of illustrating a story with suitable

pictures. NALIG (Giovanni, 1984) is one of the

early projects on generating static 2D scenes from

natural language descriptions. Put (Clay, 1996) is a

rule-based spatial placement system jointly

researched by Silicon and the University of

California, which generates an object's placement

scene through restricted natural language input.

WordsEye (Coyne, 2001) is such a system for

automatically converting text into 3D scenes. It

relies on a large database of 3D models and poses to

depict entities and actions. Compared to previous

systems, the system developed at Stanford

University (Chang, 2014a 2014b) can infers the

implicit relations and partially supports interactive

scene manipulation and active learning. SHRLDU

(Winograd, 1971) is one of the pioneer systems

developed by the Artificial Intelligence Laboratory

of the Massachusetts Institute of Technology in the

natural language to direct robot movements. It can

realize the spatial placement of simple geometry,

which is also a significant research result in the field

of natural language processing and artificial

intelligence. Carsim (Johansson, 2004) is a domain-

specific system developed by Lund University that

generates simple car accident animations based on a

series of Swedish accident reports, victim narratives

and official records of officials collected from news

articles. Combining the above systems, it can be

finded that they all generated the scenes without

considering the division of the scene. However, the

text language usually contains multiple scenes. It is

necessary to divide the scene in the multi-scene text

when generating the scenes. In order to resolve the

Yang, F., Yuan, Z. and Cheng, X.

A Scene Division Method Based on Theme.

DOI: 10.5220/0008098000440048

In Proceedings of the International Conference on Advances in Computer Technology, Information Science and Communications (CTISC 2019), pages 44-48

ISBN: 978-989-758-357-5

problem of dividing the multi-scene text, this paper

made a preliminary attempt.

The paper is organized as follows. The first

section introduces the research background, purpose

and significance of text-to-scene conversion. The

second section is an overview of the relevant

foundations of text-to-scene conversion. The third

section is the feature analysis of the scene in the

text-to-scene conversion, which contains the concept

of the scene and its constituent elements. The fourth

section is an introduction of the scene division

method based on theme, which includes algorithms,

data sets, and analysis of experimental results. The

fifth section is the summary of this paper.

2 TEXT-TO-SCENE

The text-to-scene conversion mainly involves scene

information extraction, establishment of mapping

relationship for text to scene and the generation of

3D scenes. First, natural language processing

methods are used to mine and extract the scene

information contained in the text. The scene

information includes the scene objects, the visual

attributes of the object, and the spatial relationship

between the objects, etc. Secondly, the extracted

scene information is associated with the model

library, which is a transition phase from computer

linguistics to computer graphics. Finally, scene

generation involves the production and presentation

of 3D scenes or animations. The basic theory of

existing text-to-scene conversion reasearch is not

sufficient, and the related papers mainly analyze the

various modules that constitute the text-to-scene

conversion system. Most of those research works

focus on constructing a standard expression of text

and mapping the expression to the relationship

between the three-dimensional world coordinates of

the graphics. This mapping reflects the entity noun

to the model and the layout information to the layout

of models. With the development of text-to-scene

conversion, people began to foucs on the modeling

of “scene”. Usually, a scene is complicated. The

natural language description of the scene is simple

and abstract, not enough to reflect every aspect of

the scene, which leads to the generated scene

sometimes does not satisfy people's common sense

of the real world. From the perspective of “scene”, it

is significant to discuss the composition of the scene.

3 SCENE FEATURE ANALYSIS

3.1 Scene Definition

A scene refers to a series of objects combination

associated with theme in a specific time and space

environment. A scene consists of a five-tuple,

mainly including scene theme, scene time, scene

space, scene objects, and scene relationships.

3.1.1 Scene Theme

The scene comes from the description of the text in

text-to-scene conversion. Scene theme is a general

expression of the connotation of the scene. In fact,

every text has a theme. The scene also should be the

same as the text, with the corresponding scene theme.

Most of the times, the scene theme is the same as the

text theme, but it is not all. For example, “John is

eating breakfast”, it can be finded that the theme of

the scene and the theme of the text are to eat

breakfast. There is usually no scene in the text

describing politics. Thus, there is no scene theme.

The scene theme is the core element of the scene,

and other elements are related to the scene theme.

The objects in the scene can be determined through

the scene theme. For example, the theme of the

scene is birthday, and there are cake and candles in

the scene, but there is no sea. Scene space and scene

time can also be inferred by scene theme. For

example, the theme of the scene is watching TV and

scene space may be in the living room. The theme of

the scene is snowing and it can be known that the

scene time is in winter.

3.1.2 Scene Time

Scene time refers to the time when the scene

occurred or appeared. Each Scene has a definite

scene time. The scene time of a static scene can be a

constant value, a positive interval, or expressed as

infinity. The scene time of the dynamic scene is a

positive interval. A static scene refers to a scene in

which the state of all objects does not change. For

example, the scene describing the campus layout is a

static scene. The scene time describing the campus

layout may be a certain day or a certain moment.

However, scene time does not generally appear in

scene texts that describe static scenes. A dynamic

scene refers to a scene in which at least one object's

state is changed. For example, the scene describing

the basketball game is a dynamic scene. The scene

time describing the basketball game may be a certain

time period.

A Scene Division Method Based on Theme

3.1.3 Scene Space

Scene space refers to the place where the scene

exists. Each Scene has a scene space. Scene space

can be divided into natural or artificial, indoor or

outdoor, etc. The scene space can be a country, a

city, or a particular location. For instance, we regard

the Great Wall as a scene, and then the scene space

is China, more specifically Beijing.

3.1.4 Scene Objects

Scene objects are things that can be visualized in the

scene. The scene objects usually refer to entities that

exist in the scene, and entity refers to things that can

be directly visualized in the scene. Scene objects are

crucial in the scene, and it is one of the most basic

factors that make up the scene. A scene without a

scene object is like a blank drawing paper. From the

perspective of part of speech, scene objects belong

to the category of nouns, but not all nouns represent

a scene object. The apple, table, wind, China, etc.

are called scene objects, scene objects are things that

exist in the world or can be represented by existing

things. The apple and table represent a kind of

existence and concrete things in the real world, so

they also are called entities. For entities, they have

their own visual attributes. The visual attributes of

the entity include color, size, shape, texture, etc. In

addition, there are some nouns that reflect the

process or result of humans’ cognitive in the

objective world. They are not referring to the

existence and specific things, but the invisible

concepts. They are not suitable for visualization. For

example, spiritual, material, and friendship are

typical of these words.

3.1.5 Scene Relationships

Scene relationship includes the spatial and non-

spatial relationship between objects in the scene.

The spatial relations are a crucial component in

descriptions of scenes. Spatial relations define the

basic layout information of scenes, which includes

the orientation relationship, the distance relationship,

and the topological relationship. For example, “the

computer is on the table”, “John is 5 feet in front of

the tree”, and “a picture is hanging on the wall”.

Spatial relations are often denoted by prepositions

such as on, under, beyond, in front of, etc. In the

description of the spatial relationship, the specific

location information of the object is also related to

the size and shape of the object. Non-spatial

relationships are not obviously reflected in the scene,

but they are also important in the scene. The non-

spatial relationships between the objects have the

part-of relation, the container-of relation, etc. For

example, “arm of the chair” is the part-of relation.

“Bowl of cherries” is the container-of relation.

4 SCENE DIVISION

An article consists of a series of words, and the most

important words in multi-scene text are the entity

noun. Therefore, in order to divide the multi-scene

text, you must first annotate the entity noun with

topic IDs. It is not based on words, but on topic IDs

assigned by LDA model. This increases sparsity

because the word space is reduced to a lower

dimensional topic space. The topic model must be

trained on a document similar to the content of the

test document to make the method effective. A

sentence is assumed to be the smallest basic unit.

We introduced a window parameter that defines the

number of sentences contained in a window, and

then the similarity of two adjacent windows is

calculated. We cannot declare the value of window

parameter in advance, and this is conditioned on the

multi-scene text that is divided. To calculate the

similarity, we exclusively use the topic IDs assigned

to the entity noun. Assuming an LDA model with T

topics, the frequency of each topic in a window

block is counted to compose into a T-dimensional

vector. The cosine similarity between vectors is

calculated. If the value is close to zero, it denotes

that the two window block edges are not associated.

They belong to two different scenes. The value is

close to one, it indicates that the two window block

margins are associated. They belong to a scene. In

this experiment, we identify the scene boundaries by

setting a threshold.

4.1 LDA Model

LDA is a generative model for text and other

collections of discrete data introduced by Blei et al

(Blei, 2003), which is a classic probabilistic topic

model. LDA model contains three layers of words,

topics, and documents. Blei added the Bayesian

prior probability to the PLSA algorithm, which gave

birth to the LDA algorithm. LDA is an unsupervised

machine learning model that can be used to identify

potential topic information in large-scale document

sets or corpora. LDA has wide application in the

fields of natural language processing and document

classification. This method assumes that each word

in a document is extracted from the topic. Model

training evaluates two distributions: document-topic

distribution, topic-word distribution. Since LDA is a

CTISC 2019 - International Conference on Advances in Computer Technology, Information Science and Communications

probability generation model, for each document in

the corpus, the following generative process is

defined. For each document, a topic is extracted

from the topic distribution. Then a word is extracted

from the word distribution corresponding to the

extracted topic. Repeat the above process until each

word in the document is traversed.

4.2 Data Sets

The performance of the introduced method is

demonstrated using data sets from the primary

school compositions, which contains of 100

compositions depicting different scenes. The number

of sentences in each composition is 5 to 20 and they

are all made up of one theme.

4.3 Evaluation

The performance of the approach based on theme is

evaluated by accuracy, recall, and F1 values. In

addition to the method assessment, you also need to

specify the following parameters for the LDA model:

The number of topics T; the value of alpha, hyper-

parameter of LDA; the value of beta, also the hyper-

parameter of LDA; the number of Gibbs sampling

iterations. In this paper, the Bayesian statistical

standard method is used to analyse the fitting of the

model to the corpus by setting the number of

different scene topics, and finally determine the

number of optimal scene topics. Figure 1 illustrates

the experimental results of setting different topic

number. As shown in Figure 1, when the number of

topics T is 2, the value of log-likelihood is the

largest, and then begins to gradually decrease. At

this time, the model fits the corpus best. The values

of the remaining parameters in the experiment are as

follows: The value of alpha is 50/T; the value of beta

is 0.5; the number of Gibbs sampling iterations is

2000.

Figure 1: Number of Topic and log-likelihood curve.

The compositions from different topics are

combined to form a multi-scene text as a test set, the

number of sentences is 15 to 45 for each multi-scene

text. We extract the nouns in the sentence through

word segmentation and part-of-speech tagging, and

then manually choose the entity nouns in them. In

the experiment, we set up different windows for

comparison. For the same window, the accuracy,

recall and F1 value are compared by setting different

thresholds, as shown in the figure 2,3,4,5.

Figure 2: The window size is 3, the accuracy, recall and

F1 value when the threshold is different.

When the window size is 3, as the threshold

increases, the accuracy decreases gradually, and the

recall rate gradually increases. The value of F1

increases first and then decreases. When the

threshold is 0.6, the value of F1 is the maximum. At

this time, the value of F1 is 0.66.

Figure 3: The window size is 4, the accuracy, recall and

F1 value when the threshold is different.

When the window size is 4, as the threshold

increases, the value of F1 increases first and then

decreases. When the threshold is 0.7, the value of F1

is the maximum. At this time, the value of F1 is 0.72.

A Scene Division Method Based on Theme

Figure 4: The window size is 5, the accuracy, recall and

F1 value when the threshold is different.

When the window size is 5, as the threshold

increases, the value of F1 increases first and then

decreases. When the threshold is 0.8, the value of F1

is the maximum. At this time, the value of F1 is 0.81.

Figure 5: The window size is 7, the accuracy, recall and

F1 value when the threshold is different.

When the window size is 7, as the threshold

increases, the value of F1 increases first and then

decreases. When the threshold is 0.9, the value of F1

is the maximum. At this time, the value of F1 is 0.76.

Comparing the maximum value of the F1 value

when the window size is 3, 4, 5, and 7, it can be

concluded that when the window size is 5 and the

threshold is 0.8, the F1 value is the maximum value,

and the experiment works best.

5 CONCLUSIONS

Scene division is the key component of the research

of text-to-scene conversion. In this paper, a scene

division method based on theme is proposed, and

this method divides multi-scene texts by LDA model.

The experiment results show that this method is

correct and feasible. At present, the study of scene

division in text-to-scene conversion is just some

preliminary exploration. In the future, it is intended

to use the objects in the scene to identify and divide

multi-scene text, and to use the time and space

elements in the scene as appropriate. The research of

scene division is not only to identify the number of

scenes in multi-scene text, but more importantly to

recognize the scene structure of multiple scenes and

the relationship between scenes. The reasoning of

the scene relationship will be the focus of future

work.

REFERENCES

Coyne, B., Sproat, R., 2001. WordsEye: An automatic

text-to-scene conversion system. In: 28th Annual

Conference on Computer Graphics and Interactive

Techniques, SIGGRAPH 2001, Los Angeles August 12

– 17, 2001, pp.487-496.

Seversky, L M., Yin, L., 2006. Real-time automatic 3D

scene generation from natural language voice and text

descriptions. In: 14th Annual ACM International

Conference on Multimedia, MM 2006, Santa

Barbara October 23 – 27, 2006, pp.61-64.

Joshi, D., Wang, J Z., Li, J., 2004. The story picturing

engine: Finding elite images to illustrate a story using

mutual reinforcement. In: MIR'04 - Proceedings of the

6th ACM SIGMM International Workshop on

Multimedia Information Retrieval, New York October

15 – 16, 2004, pp.119-126.

Giovanni, A., Mauro, D M., Fausto G., 1984. Natural

language driven image generation. In: 10th

International Conference on Computational

Linguistics and 22nd annual meeting on Association

for Computational Linguistics, Stanford,

California July 02 - 06, 1984, pp.495-500.

Clay, S R., Wilhelms, J., 1996. Put: language-based

interactive manipulation of objects. IEEE Computer

Graphics and Applications. 16, 31-39.

Chang, A X., Savva, M., Manning, C D., 2014. Interactive

Learning of Spatial Knowledge for Text to 3D Scene

Generation. In: Proceedings of the Workshop on

Interactive Language Learning, Visualization, and

Interfaces, January 2014, pp.14-21.

Chang, A X., Savva, M., Manning, C D., 2014. Learning

spatial knowledge for text to 3D scene generation.

In: 2014 Conference on Empirical Methods in Natural

Language Processing, EMNLP 2014, Doha,

Qatar October 25 – 29, 2014, pp.2028-2038.

Winograd T., 1971. Procedures as a Representation for

Data in a Computer Program for Understanding

Natural Language. Computational Linguistics. 20, 464.

Johansson, R., Williams, D., Berglund, A., Nugues, P.,

2004. Carsim: a system to visualize written road

accident reports as animated 3D scenes. In: 2nd

Workshop on Text Meaning and

Interpretation, Barcelona, Spain July 25 – 26, 2004,

pp.57-64.

Blei, D M., Ng, A Y., Jordan, M I., 2003. Latent Dirichlet

allocation. Journal of Machine Learning Research. 3,

993-1022.

CTISC 2019 - International Conference on Advances in Computer Technology, Information Science and Communications
