Secure Intersection with MapReduce

Radu Ciucanu

, Matthieu Giraud

, Pascal Lafourcarde

and Lihua Ye

INSA Centre Val de Loire, Univ. Orl

eans, LIFO EA 4022, Bourges, France

LIMOS, UMR 6158, Universit

e Clermont Auvergne, Aubi

ere, France

Harbin Institute of Technology, China

Keywords:

Intersection, Database, Privacy, Security, MapReduce.

Abstract:

Relation intersection is a fundamental problem, which becomes non-trivial when the relations to be intersected

are too large to ﬁt on a single machine. Hence, a natural approach is to design parallel algorithms that are

executed on a cluster of machines rented from a public cloud provider. Intersection of relations becomes even

more difﬁcult when each relation belongs to a different data owner that wants to protect her data privacy. We

consider the popular MapReduce paradigm for outsourcing data and computations to a semi-honest public

cloud. Our main contribution is the SI protocol (for Secure Intersection) that allows to securely compute the

intersection of an arbitrary number of relations, each of them being encrypted by its owner. The user allowed

to query the intersection result has only to decrypt the result sent by the public cloud. SI does not leak (to the

public cloud or to the user) any information on tuples that are not in the ﬁnal relation intersection result, even

if the public cloud and the user collude i.e., they share all their private information. We prove the security of

SI and provide an empirical evaluation showing its efﬁciency.

1 INTRODUCTION

The outsourcing of data and computation to the

cloud is a frequent scenario in modern applications.

While many cloud service providers with an impor-

tant amount of data storage and of power computation

(e.g., Google Cloud Platform, Amazon Web Services,

Microsoft Azure) are available for a reasonable price,

they do not usually address the fundamental problem

of protecting the privacy of users’ data.

We consider the problem of intersection of an ar-

bitrary number of relations, each of them belonging

to a different data owner. We rely on the popular

MapReduce (Dean and Ghemawat, 2004) paradigm

for outsourcing data and computations to a semi-

honest public cloud. Our goal is to compute the re-

lations’ intersection while preserving the data privacy

of each of the data owners. We develop a protocol

based on public-key cryptography where each par-

ticipant encrypts and sends their respective relation

on the public cloud. The public cloud cannot learn

neither the input nor the output data, but may learn

only the number of tuples in the intersection. At the

end of the computation, the public cloud sends the

result to the ﬁnal user, who only has to decrypt the

received data. Moreover, if the public cloud and the

user collude, i.e., the public cloud knows the user’s

private key, then they cannot learn other information

than the intersection result. Secure intersection has a

lot of applications such that privacy-preserving data

mining (Aggarwal and Yu, 2008), homeland secu-

rity (Cristofaro and Tsudik, 2010), human genome re-

search (Baldi et al., 2011), Botnet detection (Nagaraja

et al., 2010), social networks (Mezzour et al., 2009),

and location sharing (Narayanan et al., 2011).

1.1 Intersection with MapReduce

A protocol to compute the intersection between two

relations with MapReduce is presented in Chapter 2

of (Leskovec et al., 2014). We note that intersection

between relations can be viewed as intersection be-

tween sets where elements of these sets correspond

to the tuples of relations having the same schema. In

Chapter 2 of (Leskovec et al., 2014), the public cloud

receives two relations from their respective owner. A

collection of cloud nodes has chunks of these two re-

lations. The Map function creates for each tuple t a

key-value pair (t,t) where key and value are equal to

the tuple. Then, the key-value pairs are grouped by

key, i.e., key-value pairs output by the map phase that

have the same key are sent to the same reducer (i.e.,

236

Ciucanu, R., Giraud, M., Lafourcarde, P. and Ye, L.

Secure Intersection with MapReduce.

DOI: 10.5220/0007918902360243

In Proceedings of the 16th International Joint Conference on e-Business and Telecommunications (ICETE 2019), pages 236-243

ISBN: 978-989-758-378-0

the application of the Reduce function to a single key

and its associated values). For each key, the Reduce

function checks if the considered key is associated to

two values. If it is the case, i.e., tuple t is present

in both relations, then the public cloud produces and

sends the pair (−,t) to the user. The dash value “−”

corresponds to the empty value, we use it to be con-

sistent with the key-value result form required by the

MapReduce paradigm. Hence, all tuples received by

the user correspond to the tuples that are in both rela-

tions. However, the key is irrelevant at the end of the

protocol, hence we often omit to write it. We illustrate

this approach with the following example considering

three relations.

Example: We consider three relations: NSA,

GCHQ, and Mossad. Each relation is owned by their

respective data owner. These three relations have the

same schema composed of only one attribute, namely

“Suspect’s ID”. They are deﬁned as follows: NSA =

{F654,U840, X098}, GCHQ = {F654, M349,P027},

and Mossad = {F654,M349,U840}. An external user,

called Interpol, wants to receive the intersection of

these three relations denoted Interpol. We illus-

trate the execution of intersection computation with

MapReduce for this setting in Figure 1. First, each

data owner outsources their respective relation into

the public cloud. Then, the public cloud runs the

map function on each relation and sends the output to

the master controller in order to sort key-value pairs

by key. Then, the master controller sends key-value

pairs sharing the same key to the same reducer. In

our example, we obtain 5 reducers since there are 5

different suspect’s identities. The reducer associated

to the key F654 has three values since the identity

F654 is present in the three relations NSA, GCHQ,

and Mossad. The reducer associated to the key M349

has two values since the identity M349 is only present

in relations GCHQ and Mossad. Other reducers are

associated to only one value since the corresponding

suspect’s identity is present in only one relation. For

each reducer, the public cloud runs the reduce func-

tion and sends the tuple (−, ID) to the user if the sus-

pect’s identity ID is present is the three relations, else

the public cloud sends nothing. In our example, we

observe that the user Interpol only receives the pair

(−,F654) since the suspect’s identity F654 is present

in the three relations NSA, GCHQ, and Mossad.

1.2 Problem Statement

We assume n + 2 parties: n data owners, the public

cloud, and the external user (simply referred as user

in the following). Each data owner is trusted (i.e.,

they dutifully follow the protocol and do not collude

with other party) and outsources a relation R

, with

i ∈ J1,nK, to the public cloud, denoted C . We denote

by R

the owner of the relation R

for i ∈ J1,nK. A

user, denoted U, and who does not know the individ-

ual relations R

is authorized to query the intersection

of these n relations.

We assume that the public cloud is semi-

honest (Lindell, 2017), i.e., it executes dutifully the

computation task but tries to learn the maximum of

information on relations R

and on their intersection.

In the original protocol (Leskovec et al., 2014), tuples

of each relation are not encrypted, hence the public

cloud learns all the content of each relation and the

result of the intersection that it sends to the user as

illustrated in Figure 1. To preserve data owners’ pri-

vacy, the cloud should not learn any plain input data,

contrary to what happens for the original protocol.

Moreover, we assume that the public cloud can

collude with the user, i.e., they share all their respec-

tive private information. We want that the user that

queried the intersection of these n relations may learn

nothing else than the intersection of the n relations,

even in case of collusion with the public cloud.

1.3 Contributions

We revisit the standard protocol for the computa-

tion of intersection with MapReduce (Leskovec et al.,

2014) and propose a new protocol called SI (for Se-

cure Intersection) that satisﬁes our aforementioned

problem statement. More precisely:

• Our protocol SI guarantees that the user who

queries the intersection of the n relations learns

only the ﬁnal result. Moreover, the public cloud

does not learn information about the input data

that belongs to the data owners, it learns only the

cardinal of each relation and of the intersection.

SI also satisﬁes the problem setting in the pres-

ence of collusion between the user and the public

cloud. The security proof of our protocol is given

in the extended version available online

• To show the practical scalability of SI, we present

experimental results using the MapReduce open-

source implementation Apache Hadoop 3.2.0.

• Our protocol SI is efﬁcient from both computa-

tion and communication points of view. The over-

head for the computation complexity is linear in

the number of tuples by relation while the com-

munication complexity is the same as in the stan-

dard protocol (Leskovec et al., 2014). Our tech-

nique is based on classical cryptographic tools

such that pseudo-random function, asymmetric

https://hal.archives-ouvertes.fr/hal-02129141

Secure Intersection with MapReduce

237

Data owners

Relations

NSA

GCHQ

Mossad

Map

NSA

GCHQ

Mossad

Master Controller

Public cloud

Key F654

Values

F654

Key M349

Values

M349

Key P027

Value P027

Key U840

Value U840

Key X098

Value X098

Reduce

User

Relation Interpol

(−,F654)

Figure 1: Example of intersection with MapReduce between three relations.

Protocol Comp. cost Com. cost

Standard 2nN (n + 1)N

· N

(n + 1)N+C

· (3n − 2)

⊕

· (2N · (n − 2))

Figure 2: Trade-offs between computation and communica-

tion costs for our secure protocol SI vs the standard MapRe-

duce protocol. Let N = max(|R

|,. .. ,|R

|). Let C

(resp.

, C

⊕

) be the computation cost of a pseudo-random func-

tion evaluation (resp. asymmetric encryption, xor opera-

tion).

and one-time-pad encryptions. We summarize in

Figure 2 the trade-offs between computation and

communication costs for our secure protocol SI vs

the standard MapReduce protocol computing the

intersection of n ≥ 2 relations. In our communica-

tion cost analysis, we measure the total size of the

data that is emitted from a map or reduce node.

1.4 Related Work

As previously mentioned, a relation can be seen as

a set where tuples are set’s elements. Private Set

Intersection (PSI) refers to the cryptographic prim-

itive where two parties compute the intersection of

their respective sets such that minimal information

is revealed during the process. It was introduced by

Freedman et al. (Freedman et al., 2004). The aim of

such a primitive is to allow the two parties to learn

the elements common to both sets and nothing else.

Such primitives where neither party has any advan-

tage over the other and where all parties know the

intersection are called mutual PSI (Cristofaro et al.,

2010). On the contrary, primitives where only one

party learns the intersection of the two sets while the

other learns nothing are called one-way PSI (Cristo-

faro et al., 2010). Contrary to these approaches, our

protocol SI does not reveal any information on the in-

tersection to the data owner. Only the user knows the

intersection.

The seminal work (Freedman et al., 2004) uses

two-party computation and partial homomorphic en-

cryption allowing two owners to securely compute

the intersection of two sets. The proposed protocol

is proven against semi-honest adversaries in the stan-

dard model and also proven for a malicious adversary

in random oracle model. Authors consider one client

and one server, each of them owning a secret dataset

where the client sends polynomial coefﬁcients associ-

ated to her dataset in an encrypted way to the server.

At the end of the protocol the server knows which ele-

ments are shared with the server while the later learns

nothing. In our protocol SI, we consider an arbitrary

number of clients owning different relations and using

a semi-honest public cloud to send the intersection of

the relations to the user.

Following this work, (Hazay and Nissim, 2010)

proposed an improved construction considering the

presence of a malicious adversaries in the standard

model. Contrary to us, the complexity of this con-

struction still remains not linear in the number of el-

ements in sets. (Cristofaro et al., 2010), and (Kissner

and Song, 2005) proposed protocols for mutual PSI

with linear complexity while in our protocol the user

does not have any set to intersect. The scheme pro-

posed by (Cristofaro et al., 2010) considers a mali-

cious adversary using zero-knowledge proofs. Their

scheme requires that the user performs computations

at the beginning and at the end of the protocol while

SECRYPT 2019 - 16th International Conference on Security and Cryptography

238

she has only to decrypt the ﬁnal result in our protocol.

In the scheme of (Kissner and Song, 2005), each data

owner learns the result of the intersection. In this pa-

per, we consider semi-honest adversary and prove the

security of our protocol in the random oracle model.

As remarked above, the intersection computed by our

protocol is only known by the user and not by the data

owners and the public cloud.

More recently, Hazay and Venkitasubrama-

niam (Hazay and Venkitasubramaniam, 2017) pro-

posed a protocol considering a star topology between

data owners where a designated party ﬁrst learns the

encrypted cross intersection with other parties, then

deduces the outcome. In our protocol, we consider a

different topology where a public cloud receives en-

crypted sets to intersect and sends the outcome to the

user. In (Kolesnikov et al., 2017), the authors pro-

posed a protocol based on oblivious programmable

PRF (OPPRF) where each party has to compute a

share of zero for each set’s element in a coordinate

way. The outcome is obtained by a centralized data

owner considering only OPPRF evaluations that are

equal to zero. In our protocol, the user that queries

the intersection is not a data owner, moreover, data

owners just have to share PRF secret keys and no to

perform secret sharing computation.

Outline. We introduce the needed cryptographic

tools in Section 2. We recall the standard MapReduce

set intersection protocol and present our secure proto-

col SI in Section 3. Before to conclude, we present in

Section 4 experimental evaluations of SI protocol.

2 CRYPTOGRAPHIC TOOLS

We recall deﬁnitions of public-key encryption scheme

and of pseudo-random function used in SI.

Deﬁnition 1 (Public-key encryption). Let η be a se-

curity parameter. A public-key encryption (PKE)

scheme consists of three algorithms.

• The randomized key generation algorithm G takes

the security parameter to return a public/secret

key pair (pk, sk).

• The encryption algorithm E takes a public key pk

and a plaintext m to return a ciphertext c. We de-

note by E(pk, m) the encryption of m.

• The deterministic decryption algorithm D takes a

secret key sk and a ciphertext c to return a corre-

sponding plaintext m or a special symbol ⊥ indi-

cating that the ciphertext was invalid. We denote

by D(sk,c) the decryption of c.

Deﬁnition 2 (Pseudo-random function). Let η be a

security parameter. A pseudo-random function (PRF)

F is a deterministic algorithm that has two inputs:

k ∈ {0, 1}

`(η)

(where `(·) is a polynomial function),

and x ∈ X . Its output is y := F(k,x) ∈ Y . We said

that F is deﬁned over ({0,1}

`(η)

,X ,Y ).

In the rest of the paper, we assume that data of par-

ticipants are included in X , and the size of Y is larger

enough to avoid collisions. Moreover, we denote by

(·) = F(k,·) an instance of F.

3 MAPREDUCE INTERSECTION

We consider n ≥ 2 data owners, each of them owning

a relation. These n relations have the same schema

and are denoted R

,. . . , R

. We ﬁrst recall in Sec-

tion 3.1 the standard MapReduce protocol to perform

the intersection of n relations, i.e., a simple general-

ization of the binary protocol presented in Chapter 2

of (Leskovec et al., 2014). This protocol obviously

does not verify privacy properties of our problem set-

ting since the public cloud learns all tuples of each

relation sent by the respective data owner, and the in-

tersection of these n relations sent to the user. Then

we present in Section 3.2 our secure protocol denoted

SI that computes the intersection of n relations using

MapReduce. We prove that contrary to the standard

protocol, SI guarantees that the public cloud learns

only cardinals of relations R

for i ∈ J1, nK. Moreover,

if the public cloud and the user collude, then they

learn the intersection of these n relations that the user

still knows, and cardinals of relations R

for i ∈ J1, nK

that the public cloud still knows, and nothing else.

3.1 Standard MapReduce Intersection

In the standard protocol (Leskovec et al., 2014), the

Map function creates for each tuple t of each relation

, with i ∈ J1,nK, a key-value pair where the key and

the value are equal to the tuple t. For a key t, the as-

sociated reducer receives a list of tuples t. Hence, if

a tuple t is only present in one relation, the reducer

receives a collection only composed of one tuple t.

On the contrary, if a tuple t

is present in all the n re-

lations, the reducer receives a collection of n tuples

equal to t

. If a key t is associated to a collection

of n tuples t, then the Reduce function produces the

key-value pair (−,t) and sends it to the user. Other-

wise, it produces nothing. All key-value pairs out-

putted by the Reduce function constitute the result

of the intersection of the n relations. We present the

standard protocol computing the intersection protocol

with MapReduce in Figure 3.

Secure Intersection with MapReduce

239

Map function:

// key: id of a chunk of R

// value: collection of tuples t ∈ R

foreach t ∈ R

emit (t,t).

Reduce function:

// key: tuple t ∈ ∪

i=1

// values: collection of tuples t

L = [ ]

foreach v ∈ values do

L ← L ∪ {v}

if |L| = n then

emit (−,t).

Figure 3: MapReduce protocol to compute the intersection

of n relations.

We now consider a semi-honest public cloud per-

forming the intersection of n relations with MapRe-

duce. In such a scenario, the public cloud learns all

the content of each relation along with the intersec-

tion of these n relations.

3.2 Secure MapReduce Intersection

In order to compute intersection with MapReduce in a

privacy-preserving way between n ≥ 2 relations, our

protocol uses pseudo-random function, asymmetric

and one-time encryptions. We denote by F a secure

pseudo-random function deﬁned over (K , X ,Y ) and

by Π = (G,E,D) an IND-CPA asymmetric encryp-

tion scheme. We also assume that the length of val-

ues outputted by the pseudo-random function is equal

to the length of ciphertext outputted by the asymmet-

ric encryption scheme. In practice, we can use the

Advanced Encryption Standard (AES) (Daemen and

Rijmen, 2002) with the Cipher Block Chaining mode

on padded message in order to obtain a ciphertext of

the same length than the ciphertext obtained with the

asymmetric encryption.

Preprocessing of our Secure Protocol SI. Before

outsourcing their relation to the public cloud, data

owners perform a key setup and a preprocessing on

their respective relation R

to obtain a protected re-

lation denoted R

∗

. We present the key setup and the

preprocessing phase in Figure 4.

First, we need a secret key k

∈ X that is shared

between the n data owners. Moreover we need n − 1

other secret keys k

∈ K (for 2 ≤ i ≤ n) such that

6= k

for i 6= j. Key k

with i ≥ 2 is shared between

the owner of relation R

and the owner of relation R

Hence, the owner of relation R

has a set of secret

keys equals to {k

,. . . , k

} while the owner of re-

lation R

(for 2 ≤ i ≤ n) has a set of secret keys equals

to {k

}. We note that the choice of owner of rela-

tion R

knowing all the secret keys is arbitrary, and we

call the associated relation, i.e., R

, the main relation.

Preprocessing:

// input: relation R

with i ∈ J1,nK

// outputs: protected relation R

∗

for 1 ≤ i ≤ n do k

← K ;

∗

←

if i = 1 then

foreach t ∈ R

∗

← R

∗

∪ {( f

(t),(E(pk,t) ⊕

j=2

(t)))}

else

foreach t ∈ R

∗

← R

∗

∪ {( f

(t),( f

(t)))}

return R

∗

Figure 4: Preprocessing of our secure protocol SI run by

each data owner.

The aim of this preprocessing is to protect owners’

data in order to avoid the public cloud to learn tuples

of each relation and the result of the intersection sent

to the user. Moreover, this preprocessing is in agree-

ment with the MapReduce paradigm. Indeed, each

protected relation R

∗

is composed of tuples under the

key-value pair form.

First of all, each key of pairs of R

∗

is a pseudo-

random evaluation of a tuple using the secret key k

known by each data owner. Since a pseudo-random

function is deterministic, equal tuples share the same

value of key. Hence, the map phase sends these key-

value pairs to the same reducer as expected.

Moreover, each value of key-value pairs of the

protected relation R

∗

is equal to the encryption of

the tuple using the asymmetric encryption scheme Π

with the user public key pk xored by n − 1 pseudo-

random evaluations of the tuple using secret keys

,. . . , k

. More precisely, for each tuple t ∈ R

, the

preprocessing computes the key-value pair equals to

( f

(t),E(pk,t) ⊕

j=2

(t)). Hence, when the pub-

lic cloud receives such key-value pairs and colludes

with the user, it cannot learn the value of tuples since

the asymmetric encryption is protected by pseudo-

random evaluations, and secret keys k

,. . . , k

are not

known by the public cloud.

Map and Reduce Phases of SI Protocol. The pre-

processing presented in Figure 4 outputs an encrypted

relation whose tuples are of the key-value pair form.

Hence, once the public cloud receives the n encrypted

SECRYPT 2019 - 16th International Conference on Security and Cryptography

240

relations R

∗

(for i ∈ J1,nK) from the data owners, it

runs the Map function that is simply the identity func-

tion.

After the grouping by key, the Reduce function

checks if the current key f

(t), for t ∈ ∪

i=1

, is as-

sociated to a list of n values. If that is the case, it

means that the n relations contain the tuple associ-

ated to the current key. Then the Reduce function uses

these n values to perform an exclusive or, and obtains

the asymmetric encryption of the tuple E(pk,t) due

the property of the exclusive or.

Finally, the Reduce function produces the key-

value pair (−,E(pk,t)) and sends it to the user. The

output of the Reduce function is in a key-value form

to be consistent with the MapReduce paradigm since

at the end of the SI protocol keys are irrelevant. All

key-value pairs outputted by the Reduce function con-

stitute the intersection of the n relations. The user has

only to decrypt each value of key-value pair using her

secret key in order to obtain the intersection in plain

form. Our protocol SI is described in Figure 5.

Map function:

// key: id of a chunk of R

∗

with i ∈ J1,nK

// values: collection of ( f

(t),E(pk,t) ⊕

j=2

(t))

// or ( f

(t), f

(t)) with j ∈ J2,nK

foreach (k, v) ∈ values do

emit (k,v)

Reduce function:

// key: f

(t) such that t ∈ ∪

i=1

// values: collection of E(pk,t) ⊕

j=2

(t) or

(t) // with j ∈ J2,nK

L ← [ ]

foreach v ∈ values do

L ← L ∪ {v}

if |L| = n then

E(pk,t) ← E(pk,t) ⊕

j=2

(t) ⊕

j=2

(t)

emit (−, E (pk,t))

Figure 5: Map and Reduce functions of SI.

Example. We illustrate our SI protocol following

the example presented in Section 1. First, we perform

the preprocessing on relations: NSA, GCHQ, and

Mossad. We consider relation NSA as the main

relation. The three data owners share the secret key

, data owners of relations NSA and GCHQ share a

secret key k

, and data owners of relations NSA and

Mossad share a secret key k

. Hence, after the pre-

processing phase, we obtain three protected relations

denoted NSA

∗

, GCHQ

∗

, and Mossad

∗

: NSA

∗

has

tuples ( f

(F65),E (pk, F65) ⊕ f

(F65) ⊕ f

(F65)),

( f

(U84),E (pk, U84) ⊕ f

(U84) ⊕ f

(U84)), and

( f

(X09),E (pk, X09) ⊕ f

(X09) ⊕ f

(X09));

GCHQ

∗

has tuples ( f

(F65), f

(F65)),

( f

(M34), f

(M34)), ( f

(P02), f

(P02)); Mossad

∗

has tuples ( f

(F65), f

(F65)), ( f

(M34), f

(M34)),

( f

(U84), f

(U84)). We illustrate the execution of

intersection computation with MapReduce using our

secure protocol SI in Figure 6.

Proof of Correctness. We say that the protocol SI is

correct if for n ≥ 2 relations R

,. . . R

, SI returns

the correct intersection of the n ≥ 2 relations, i.e., the

encrypted relation composed of pairs (−,E (pk,t))

such that t ∈ R, where R := ∩

i=1

Lemma 1. Assume that the pseudo-random function

family F perfectly emulates a random oracle, then

protocol SI is correct.

Proof. Let R

,. . . R

be n relations. Let

∗

,. . . R

∗

be the corresponding encrypted relations

computed by the preprocessing phase of SI. We set

R := ∩

i=1

For each t ∈ R, there exists a key-value pair in rela-

tion R

∗

of the form ( f

(t),E(pk,t) ⊕

i=2

(t)), and

a key-value pair in relation R

∗

, with 2 ≤ j ≤ n, of

the form ( f

(t), f

(t)). Following the MapReduce

paradigm, the n values are sent to the same reducer

that sums the corresponding values. Thus, for each

key f

(t), with t ∈ R, we obtain:

E(pk,t) ⊕

i=2

(t) ⊕

i=2

(t) = E(pk,t) .

Hence, for each t ∈ R, reducer associated to the key

(t) emits the pair (−,E(pk,t)) to the user. More-

over, for each t ∈



∪

i=1



\R, the reducer associated

to the key f

(t) does not output the pair (−,E(pk,t))

since it is associated to less than n values. Finally,

SI produces pairs (−,E(pk,t)) such that t ∈ R corre-

sponding to the intersection of relations R

,. . . , R

which concludes the proof.

4 EXPERIMENTAL RESULTS

We present an experimental comparison between

the standard MapReduce set intersection proto-

col (Leskovec et al., 2014), and our secure protocol

SI. We run two types of experiments, where we vary

two different parameters: the number of tuples per re-

lation for a ﬁxed number of 2 relations, and the num-

ber of intersected relations.

Secure Intersection with MapReduce

241

Data owners

Relations

NSA

∗

GCHQ

∗

Mossad

∗

Map

NSA

∗

GCHQ

∗

Mossad

∗

Master Controller

Public cloud

Key f

(F65)

Values

E(pk,F65) ⊕

j=2

(F65)

Key f

(M34)

Values

(M34)

Key f

(P02)

Value f

(P02)

Key f

(U84)

Value f

(U84)

Key f

(X09)

Value E(pk,X09) ⊕

j=2

(X09)

Reduce

User

Relation Interpol

(−,F65)

Figure 6: Example of intersection with MapReduce between three relations using our secure protocol SI.

Settings. We have done all computations on a clus-

ter running Ubuntu Server 16.04 LTS with Hadoop

3.2.0 using Java 1.8.0. We use the Hadoop streaming

utility and implement the Map and Reduce functions

in Golang 1.6.2. The cluster is composed of one mas-

ter node and of ten slave nodes. Each node has four

CPU cadenced to 2.4 GHz, 80 GB of disk, and 8 GB

of RAM.

According to our SI protocol, we use as pseudo-

random function the Advanced Encryption Standard

(AES) symmetric encryption scheme in Cipher Block

Chaining (CBC) encryption mode with a key size of

128 bits. For the purpose of our protocol, the initial

vector is ﬁxed and common to all data owners. For

the asymmetric encryption scheme, we use the RSA-

OAEP scheme with a key size of 2048 bits and SHA-

256 as hash function.

For each experiment, we report average CPU

times over 8 runs. Since the cluster environment is

not isolated from other machines of the netword, we

do not give measures for the communication cost.

Varying the Number of Tuples. In the experiment

on the number of tuples, we consider two relations

of the same schema composed of only one attribute.

These two relations have the same cardinal C and

share C/2 elements. Tuples of the ﬁrst relation consist

in all integers from 1 to C, while tuples of the second

relation consist in all integers from C/2 to C +C/2.

We run the original protocol (Leskovec et al., 2014)

and our secure protocol SI on couples of relations of

cardinal 500,000 to 3, 000, 000, by step of 250, 000.

We remark in Figure 7 that the computation com-

plexity of our secure protocol is linear as determined

in the complexity study (cf. Figure 2).

0.5

1.5

2.5

1,000

2,000

Number of tuples (in millions).

CPU time (in seconds).

Standard

Figure 7: CPU time vs the number of tuples for the Standard

and SI protocols to compute the intersection between two

relations.

Varying the Number of Intersected Relations. In

the experiment on the number of intersected relations,

we consider intersection between different number of

relations of the same schema composed of only one

attribute. We start by computing the intersection of 2

relations to ﬁnish with the intersection of 10 relations.

In each case, relations have 500,000 tuples and shares

250,000 tuples. In practice, for the intersection of

2 ≤ n ≤ 10 relations, tuples of the ﬁrst relation consist

in integers from 1 to 500,000, and tuples of the i-th

relation, with 2 ≤ i ≤ n, consist in integers from 1 to

250,000 and integers from i · 250, 000 + 1 to (i + 1) ·

250,000.

We compare the standard protocol (Leskovec

et al., 2014) and our secure protocol SI for the ex-

periment on the number of intersected relations. As

shown in Figure 8, the computation complexity of our

secure protocol is linear as determined in the com-

plexity study (cf. Figure 2). We observe that the com-

putation complexity is less compare to the experiment

SECRYPT 2019 - 16th International Conference on Security and Cryptography

242

2 3 4

5 6

7 8 9 10

200

400

Number of tuples (in millions).

CPU time (in seconds).

Standard

Figure 8: CPU time of the experiment on the number of

intersected relation on the original protocol(Leskovec et al.,

2014) and of our secure protocol SI.

on the number of tuples. Indeed, when we run the SI

protocols with 10 relations of 500, 000 tuples (i.e., a

total of 5,000, 000 tuples), the CPU time is approx-

imately equals to 550 seconds while the CPU time

for the intersection of 2 relations of 2 millions (i.e.,

a total of 4, 000, 000 tuples) is approximately equals

to 1,500 seconds. This is due to number of common

elements of each relation. In the case of the inter-

section of 10 relations (each composed of 500,000

tuples), relations share 250,000 while in the case of

the intersection of the 2 relations (each composed of

2,000, 000 tuples), relations share 1, 000, 000 tuples.

Hence, the Reduce function has to performs a large

number of exclusive or on 2048-bits strings.

5 CONCLUSION

We have presented an efﬁcient privacy-preserving

protocol using the MapReduce paradigm to compute

the intersection between an arbitrary number of re-

lations. In fact, in the standard protocol (Leskovec

et al., 2014), the public cloud performing the compu-

tation learns all tuples of the data owners along the in-

tersection result that it sends to the user. In our proto-

col SI, the public cloud cannot learn such information

on the input sets. Moreover, if the cloud and the user

collude, then they cannot learn more than the result of

the intersection. If no such a collusion exists, then the

public cloud only learns cardinals of the relations sent

by the data owner, and the cardinal of their intersec-

tion. We have compared the standard and our secure

approach SI with respect to three fundamental criteria:

computation cost, communication cost, and privacy

guarantees. We also implemented SI with the Hadoop

framework and presented empirical results showing

the scalability of SI.

Looking forward to future work, we plan to study

secure set intersection with MapReduce while consid-

ering a malicious public cloud, i.e., the public cloud

can perform any operations on data that it process.

REFERENCES

Aggarwal, C. C. and Yu, P. S. (2008). A general survey

of privacy-preserving data mining models and algo-

rithms. In Privacy-Preserving Data Mining.

Baldi, P., Baronio, R., Cristofaro, E. D., Gasti, P., and

Tsudik, G. (2011). Countering GATTACA: efﬁ-

cient and secure testing of fully-sequenced human

genomes. In CCS.

Cristofaro, E. D., Kim, J., and Tsudik, G. (2010). Linear-

Complexity Private Set Intersection Protocols Secure

in Malicious Model. In ASIACRYPT.

Cristofaro, E. D. and Tsudik, G. (2010). Practical private

set intersection protocols with linear complexity. In

FC.

Daemen, J. and Rijmen, V. (2002). The Design of Rijn-

dael: AES. Information Security and Cryptography.

Springer.

Dean, J. and Ghemawat, S. (2004). Mapreduce: Simpliﬁed

data processing on large clusters. In OSDI.

Freedman, M. J., Nissim, K., and Pinkas, B. (2004). Efﬁ-

cient Private Matching and Set Intersection. In EU-

ROCRYPT.

Hazay, C. and Nissim, K. (2010). Efﬁcient Set Operations

in the Presence of Malicious Adversaries. In PKC.

Hazay, C. and Venkitasubramaniam, M. (2017). Scalable

multi-party private set-intersection. In PKC.

Kissner, L. and Song, D. X. (2005). Privacy-preserving set

operations. In CRYPTO.

Kolesnikov, V., Matania, N., Pinkas, B., Rosulek, M., and

Trieu, N. (2017). Practical multi-party private set in-

tersection from symmetric-key techniques. In CCS.

Leskovec, J., Rajaraman, A., and Ullman, J. D. (2014). Min-

ing of Massive Datasets, 2nd Ed. Cambridge Univer-

sity Press.

Lindell, Y. (2017). How to simulate it - A tutorial on the

simulation proof technique. In Tutorials on the Foun-

dations of Cryptography.

Mezzour, G., Perrig, A., Gligor, V. D., and Papadimitratos,

P. (2009). Privacy-preserving relationship path dis-

covery in social networks. In CANS.

Nagaraja, S., Mittal, P., Hong, C., Caesar, M., and Borisov,

N. (2010). Botgrep: Finding P2P bots with structured

graph analysis. In USENIX.

Narayanan, A., Thiagarajan, N., Lakhani, M., Hamburg,

M., and Boneh, D. (2011). Location privacy via pri-

vate proximity testing. In NDSS.

Secure Intersection with MapReduce

243
