A Software Tools Catalogue to Support the Statistical Process

Control on the Software Context

Aluízio Ramos Pereira Neto and Sandro Ronaldo Bezerra Oliveira

Graduate Program in Computer Science, Institute of Exact and Natural Sciences, Federal University of Pará,

Belém, Pará, Brazil

Keywords: Statistical Process Control, Software Tools, Empirical Software Engineering.

Abstract: Statistical Process Control (SPC) is applied to the software context in process analysis and improvement in

high level maturity organizations. There are some studies that talk about the SPC in the context of software,

however, these do not yet describe in depth the approaches related to it. The main goal of this study is to

present the results of a Systematic Review of Literature, aiming to identify the SPC-related approaches (in

this work, approaches are understood as techniques, frameworks, methods and tools to support the

implementation of a process), which were put together in the form of a catalog. In this study, only the tools

that implement the SPC will be presented, describing its characteristics, example of use, availability and

ownership. With this study researchers will obtain valuable information for the possible future application of

these tools in their development contexts.

1 INTRODUCTION

Software Engineering is a research area that has

several study subareas. Among the most complex are

Statistical Process Control (SPC), which depends on

information generated by the execution of the

Measurement process, which demands operational

effort and cost for the collection, analysis and

decision making. The SPC is executed in

organizations with High Maturity (which implement

levels A and B of MR-MPS-SW – Reference Model

of Brazilian Software Process Improvement for

Software, and 4 and 5 of CMMI-DEV – Capability

Maturity Model Integration for Development), whose

focus is on the ability of the process to be measured

and optimized, which depends on a implementation

of more institutionalized management, engineering

and support processes among the different sectors

(Rocha et al., 2012).

The SPC came into the industry with the use of

descriptive statistics and began to be applied in the

software context in the mid 1980's (Santos and Silva,

2013). In general, it investigates the capability and

performance of a software process, adding the

measurement process, descriptive statistics of data

and control charts to analyze the aspects and assets

related to a software process, to create mechanisms of

improvement and quality of software process,

establishing performance and capacity models

(Rocha et al., 2012).

Many studies, such as (Santos and Silva, 2013;

Zhang and Hou, 2010; Pettersen, 2011), on Statistical

Process Control in the software engineering area,

focus on the research methodology used, with few or

no examples of implementation of SPC-related

approaches identified.

The correct implementation of the SPC in an

organization requires the knowledge and application

of its related approaches (techniques, methods,

frameworks, models and software tools). The lack of

a knowledge repository about these approaches is a

strong motivation for this work. Greater

understanding of these approaches can enhance their

performance and competitiveness. In addition, the use

of SPC in the analysis of software processes in

projects with high levels of maturity fosters the

competitive advantages of the market (Rocha et al.,

2012).

Thus, a study was proposed based on a Systematic

Literatura Review (SLR) with the objective of

identifying SPC-related approaches (techniques,

methods, frameworks, models and software tools),

whose methodology and previous results were

published in (Neto et al., 2017) and gathered in a

catalogue of approaches.

In this paper, a summary of the results obtained in

the review that gave rise to the catalogue of

510

Neto, A. and Oliveira, S.

A Software Tools Catalogue to Support the Statistical Process Control on the Software Context.

DOI: 10.5220/0007759505100517

In Proceedings of the 14th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2019), pages 510-517

ISBN: 978-989-758-375-9

approaches and the cataloging of the identified

software tools will be presented, describing their

characteristics, example of use, availability,

ownership and tendency of adoption of the software

tool. In addition, the work described in this document

provides information about the catalogue evaluation

process.

The SLR was chosen as a research methodology

for the following reasons: it classifies primary studies

and identifies approaches, has a specific focus (in this

work to identify approaches to SPC) and provides a

detailed analysis regarding the description and forms

of use of the approaches (Travassos e Biolchini,

2007); is a non-biased, comprehensive, fair research

that uses a reliable and rigorous methodology

(Kitchenham et al., 2015); about the purpose, it is

conducted according to a planning described in a

review protocol, previously evaluated by an expert

(Mafra and Travassos, 2006).

In addition to this introductory section, this paper

has the following sections: Section 2 describes the

theoretical foundation on SPC, Section 3 describes

related works, Section 4 presents a brief summary of

the SLR performed, Section 5 describes the catalogue

of SPC-related software tools, Section 6 describes the

catalogue evaluation process, Section 7 briefly

describes the application of the catalogue and, finally,

Section 8 presents the final considerations of this

work.

2 THE STATISTICAL PROCESS

CONTROL (SPC)

The SPC is able to identify variations in the behavior

of the processes and to allow the analysis of their

stability and the establishment of their capacity. For

this, it uses graphs that associate methods of statistical

control and graphical representation (control graphs)

in order to detect signs of variation (unacceptable,

special causes that need to be analyzed) in the

behavior of the processes and differentiate them from

the noises (acceptable, are the common causes)

(Barcellos, 2009).

The stability of the process indicates that it is

described within the established control limits.

However, being a stable process does not mean being

a good performing process. To verify that a stable

process performs well, it is necessary to check its

capacity. A process is considered capable when it:

meets or exceeds organizational and customer

expectations; and meets the strategic objectives of the

organization and business. The performance of the

process is indicated by the performance baseline

(process voice) that the process has compared to the

performance expected by the process (customer

voice) (Rocha et al., 2012).

In order to identify and analyze the capacity of a

process it is necessary to use the frequency histogram.

It represents the values collected of process during its

stability period. In the histogram, the control limits of

the process baseline (process voice) and range

specification limits (customer voice) are represented

(Rocha et al., 2012). The performance baseline

describes the selection of data collected in processes

of several projects with the same characteristics and

represented in a control chart. These graphs present

the limits of performance control, which are the

expected values for the process (Wheeler and

Chambers, 2010).

The first step in using control charts is to select

the type of measure to be analyzed. The data are

collected by the measurement process and plotted on

the charts where the control limits are defined, based

on the organization's strategic objectives (business

goals) (Rocha et al., 2012). The control charts have

an Upper Control Limit (UCL) and Lower (LCL),

which are at a distance of three standard deviations

(σ) from the central line (Control Limit - CL). The

centerline and boundaries can not be arbitrary, since

they reflect the current behavior of the process. Their

values are obtained by applying the expressions and

constants defined by the type of control chart applied.

The central tendency of a control chart is the

central indication of the measures. The key measures

are the process inputs that have been "chosen" for

analysis in the control charts. This analysis takes into

account the process control charts, guided by the

strategic objectives, which point out the upper and

lower limits of an acceptable process. These

objectives are formed by the customer's voice (market

view) and the voice of the process (organization's

process capability). They must be established and

ensured by the organization in order for the process

to achieve the expected stability (Rocha et al., 2012).

Control charts are the main tools used to analyze

the data collected in the processes. Each chart type

has its characteristics and specifications related to one

or more contexts of use. This choice takes into

account its purpose, context and type of data

distribution (Barcellos, 2009).

3 RELATED WORKS

In order to identify studies on Systematic Review in

the Statistical Process Control context, a literature

A Software Tools Catalogue to Support the Statistical Process Control on the Software Context

511

search about the work related to the topic was carried

out. An ad hoc search was performed on the Google

Scholar search engine, due to its favorable index

resulting from other searches and to enable the

identification of publications originating in the IEEE

and ACM repositories. Some terms used in the search

were: "Systematic Literature Review", "Statistical

Process Control", "Techniques", "Approaches" and

"Software Tools".

In the search it was identified that the book

(Kitchenham et al., 2015) describes the methodology

to perform an SLR in the software context. The works

(Pettersen, 2011; Baldassarre et al., 2007) use the

SLR as a research methodology and additionally

inform some considerations about Statistical Process

Control, presenting its theory in general. These three

studies focus more on the SLR methodology than on

its results.

The study (Garcés and Pino, 2014) is the closest

to the objective of this paper. This paper presents a

systematic review on Statistical Process Control with

the objective of identifying the main approaches

related to the SPC.

The study proposal reported in this paper has the

differentials: (i) it is based on the accomplishment of

an SLR, formalized in a protocol previously

evaluated by an expert; (ii) execution of the SLR

methodology, with planning (search strings, source,

exclusion and quality criteria), execution (collection,

selection of primary and secondary studies, quality

evaluation), extraction and presentation of results;

presents the results of SLR in a descriptive and

bibliographical way (by means of graphics); the

recommendations proposed in the catalogue detail

present assets that were proposed or applied only in

the context of software projects; describes in detail

the approaches related to the SPC and presents

examples of their use.

4 THE SYSTEMATIC

LITERATURE REVIEW

The main objective of a systematic review is to

evaluate and interpret the available research data.

These are related to research questions from a

thematic area or from a phenomenon of interest. SLR

is a non-biased, comprehensive, fair research that

uses a reliable and rigorous methodology

(Kitchenham et al., 2015).

From the systematic literature review we can cite

other characteristics: it is formulated from systematic

and explicit research methods; evaluates and selects

the most relevant searches for the research objective;

is a transparent search (allows selection and quality

criteria), comprehensive (selects the most relevant

studies the research question) and non-biased (has a

review protocol, free of charge and financial interest);

and replicable (Mafra and Travassos, 2006).

The methodology of systematic review applied to

carry out this study obeyed the norms defined by

Kitchenham et al. (2015). Initially, revision planning

was carried out, where search sources, search strings,

quality criteria and other information were defined. In

the next phase, the data were collected in the defined

research sources and the selection and quality criteria

were applied. Next, the selection of the primary

studies was carried out and, with the selected works,

the data extraction was performed.

This systematic review aimed to identify the

approaches that support Statistical Process Control

(SPC), in the context of software projects, regarding

processes, methods, models, frameworks,

methodologies, techniques, software tools and other

ones Based on the research objective of this review

the following research question was defined, which

guided this Systematic Literature Review:

 (QP1): What standards exist to support

Statistical Process Control activities?

And the following secondary questions:

 (QS1): What assets (roles, artifacts) are involved?

 (QS2): Are there software tools to support the

Statistical Process Control?

 (QS3): If there are support software tools, what

is the license to use?

A bibliometric analysis of the data generated by

the systematic review was performed. We defined the

scope (work in English, available by the UFPA

domain, free search engine and others), constraints

(duplicate studies, works that do not present key

words and others) and research resources (4

researchers involved).

Manual search was performed on events and

journlas, and automatic search from the search string.

The sources selected for the research were: ACM, El

Compendex, IEEE Xplore Digital Library and

Scopus. For each search source a search string was

defined. These data can be seen in (Neto et al., 2017).

Next, the selection of the primary studies was

carried out, which consists in evaluating the studies

by means of Inclusion criteria (available for

download, duplicate articles, repeated and others) and

Exclusion of Primary Studies (SPC-related works).

More detailed information about the planning and

results obtained with the systematic literature revie

can be obtained from the work already published

(Neto et al., 2017).

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

512

5 THE SOFTWARE TOOLS

CATALOGUE

The Catalogue of Approaches related to Statistical

Process Control (whose access is available at the

following link:https://drive.google.com/file/d/0B_PD

f6-qXCFcMHRvcXJWbUdCNkk/view?usp=sharing

was developed based on the results extracted of the

systematic literature review, described in Section 4,

whose main objective was to identify the SPC-related

approaches.

The catalogue was organized in two parts: the first

presents techniques, methods, frameworks and

models related to the SPC; and the second, which

focuses the objective of this paper, presents the SPC

support software tools cataloged in this study.

Each software tool presents: its type, which can be

1 - Statistics, which refer to techniques derived from

descriptive statistics, 2 - Quality, which are

techniques from software evaluation processes, and 3

- Software Measurement, measure and evaluate the

software processes of an organization; an example of

using the software tool described in the literature; and

information on their availability.

5.1 Minitab

The Minitab proprietary software tool, cited in the

works (Zhang and Hou, 2010; Rahman et al., 2008),

is a computer program applied in statistical studies,

developed in 1972. Its interface is similar to

Microsoft Excel or Calc of OpenOffice, used in

universities and in companies, has specific functions

focused on process management and analysis of the

Six Sigma suite. Minitab offers Quality Control tools,

Experiment Planning (DOE), Reliability Analysis

and General Statistics.

According to its official website

(http://www.minitab.com/pt-BR/), Minitab has the

following control charts available: X-bar-R chart,

Xbarra-S chart, I-MR-R / S, Zone Chart, P Cards,

EWMA Chart, and more.

The Minitab, characterized as a type of 2 - Quality

approach, was used in an experiment of an

organization A, under the software context, presented

in the work (Rahman et al., 2008). The organization

produces high quality components for automotive

engines. The company used several basic quality

tools, such as: Pareto Diagram, Control Charts, Check

Sheets. Ishikawa diagrams, among others, to analyze

its collected data. According to the organization's

managers, the team involved had a good

understanding of Statistical Process Control, but it

took a long time to implement this knowledge in the

company. The company wanted to increase its

knowledge and skills regarding the applicability of

the SPC in its processes. For this, they participated in

an experiment using Minitab version 13.2, where they

used the tool and reported the use, advantages and

disadvantages of the tool. The SPC was fully

implemented in the organization and the use of the

Minitab tool generated the following advantages: the

tool enables a complete and accessible use of the SPC

and provides the company with a quality process; the

SPC with support from Minitab is able to detect

abnormalities, critical parameters, variations and

increase the stability of the process. Main drawback:

Minitab version 13.2 did not bring the ease needed to

build bar or pie control charts. This was overcome by

using version 14.0 of the tool.

5.2 Clearquest

According to its official website (http://www-

03.ibm.com/software/products/pt/clearquest),

ClearQuest is a proprietary tool for error monitoring

and change control that creates multiple forms with

VB or PERL functions, which allow the development

team to manage changes and errors in the project. The

tool optimizes the software life cycle with an

application development system for workflow

management.

IBM Rational ClearQuest is a fully customizable

system for the production and development of a

database workflow application. It provides flexible

tracking of changes and defects, customizable

processes, near-real-time reporting, life cycle

traceability to improve visibility and control of the

software development lifecycle. IBM Rational

ClearQuest provides scalable and cross-platform

support for businesses of all sizes, allowing it to

continue customizing processes as development

needs evolve over time. The tool can be considered as

1 - Statistical approach; 2 - Quality; 3 - Measurement.

The work (Corrales et al., 2013) cites an example

of using the ClearQuest tool, which investigates the

validation unit of information technology of a

financial organization (development and support).

ClearQuest was used to archive the data used

(referring to identified defects) in the construction of

control charts. The organization used the

measurement and data analysis (MA) process,

implementing defect management and establishing

quality and performance limits. In addition, it used

process control and forecasting statistics.

A Software Tools Catalogue to Support the Statistical Process Control on the Software Context

513

5.3 7QC (PME)

The 7QC refers to the 7 major quality tools (Control

Diagram, Flowchart, Check Sheet, Pareto Diagram,

Fishbone Diagram, Histogram and Dispersion

Diagram) described in (Rahman et al., 2008), which

combined to SME, which are a set of small businesses

that provide business management services to larger

organizations, assists in implementing Statistical

Process Control in organizations, reducing cost,

increasing flexibility, and generating profit.

The work (Pettersen, 2011) does not detail how to

use this proprietary tool. However, the authors apply

the 7 quality tools and the business management

process, aiming to implement statistical process

control in organizations. The tool can be considered

as 1 - Statistical approach.

5.4 Spc Xl2000

The study (Rahman et al., 2008) presents the

description of the SPC XL2000 proprietary tool,

which implements techniques related to Statistical

Process Control. This study analyzes the use of the

SPC XL 2000 in the management of the production

of disposable medical assets, focusing on the software

development that automates this type of business.

This software is used in the organization to collect,

analyze and report on the processes of the

organization. The tool approach is 1 - Statistical.

The work (Rahman et al., 2008) describes an

experiment using the SPC XL2000 tool in an

organization in data analysis and monitoring of key

processes. The authors do not describe in detail the

use of the tool, however it provides their main

conclusions, where the SPC was implemented

efficiently in the organization, establishing the

capacity and stability of the processes, even when

working with large amounts of data. The tool's

website is http://www.winspc.com/.

5.5 SME-SPC

The construction of the SME-SPC proprietary tool is

described in the study (Zain et al., 2009), which was

proposed with the purpose of helping small and

medium organizations to implement the SPC. Its

development was based on a previous study on the

SPC and the data collection of organizations that

already used it. The second phase used the

collaboration of an automotive company, which

carried out the test phase of the tool, which

contributed several suggestions for improvement.

The tool approach is 1 - Statistical.

The work (Zain et al., 2009) describes the

structure of the SME-SPC system and its main

functionalities, such as: user system, configuration of

data collection and analysis, data entry and subgroup

characteristics, data status, specification of control

chart data, chart types, chart plotting, comment and

feedback space, frequency histogram definition and

performance curves, summary and change of data.

For access to tool feature screens access the full

catalogue of approaches at: https://drive.google.

com/file/d/0B_PDf6-qXCFcMHRvcXJWbUdCNkk/

view?usp=sharing .

5.6 WebAPSEE

WebAPSEE is a Process-Centered Software

Engineering Environment (PSEE) developed as free

software by LABES-UFPA. The main purpose of the

environment is to meet organizational requirements

to assist in the coordination of activities related to

software development (Gonçalves et al., 2012). Its

main functionalities are: visual modeling of processes

and flexible execution of processes. WebAPSEE is

strongly based on the measurement process and

incorporates functionalities for SPC deployment such

as: planning, identifying critical processes, plotting

control charts, establishing baselines and identifying

improvements. The tool's website is

http://www.labes.ufpa.br. The tool presents the

approaches of 1 - Statistics, 2 - Quality and 3 -

Measurement.

The work (Gonçalves et al., 2012) describes an

example of use of the WebAPSEE tool, where it

analyzes the process of "productivity in the

requirements activity ". Initially, the data for the

control charts were selected and plotted on an XmR

chart. The incidence of a variation point was

investigated and subsequently solved. The tool has

fields, where it can describe causes, point of

deviations, problem status and action plans to be

executed. To get access to the tool's feature screens,

just go to the complete catalogue at: https://

drive.google.com/file/d/0B_PDf6-qXCFcMHRvcXJ

WbUdCNkk/view?usp=sharing .

5.7 MSChart

The work (Zhang and Hou, 2010) presents a study of

the construction of the MSChart proprietary tool. This

tool was proposed to meet the need of software

development companies in the treatment of cases of

statistical tolerance (ST), Statistical Process Control

(SPC) and in the design of control charts. The tool's

website is http://www.microsoft.com and is classified

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

514

as 1 - Statistical, 2 - Quality and 3 - Measurement

approaches.

MSChart consists of modules: presentation

(introduction), login, data collection, storage,

analysis and management, ST and SPC parameters,

design of control charts; data acquisition, data

processing, control chart design (choice of control

charts) and specification of statistical tolerance

(definition of control limits, quality indexes,

statistical tolerance and design of control charts). The

work (Zhang and Hou, 2010) does not describe an

example of tool use.

5.8 PAS System (Process Analysis

System)

The Process Analysis System (PAS) was developed

to meet the needs of small and medium enterprises of

the software manufacturing industry in the use of

quality control and the SPC. The PAS system

encourages the use of SPC, aims to reduce costs,

provides several types of control charts and accepts

most types of data (Chang and Lee, 2013). Its main

functionalities are: web service, user types, doubts

page, scenario choice (control chart type), type of

data storage and system procedures (history and data

configuration). It is considered as 1 - Statistical, 2 -

Quality and 3 - Measurement approaches.

The work (Chang and Lee, 2013) describes an

example of using the PAS system, where the user

initially defines the characteristics of the process, data

type and control chart to be analyzed. It then

configures the data to be inserted and can be viewed

and filtered into tables. The user must define the

number of data of each subgroup and the way the

system will calculate the generated data.

Subsequently, the charts are generated for analysis.

Data can be entered and changed at any time. If there

are more general doubts, the user can access the

"doubts" field, or in cases of doubts related to control

charts, the user must access "Control Guide". For

access to tool feature screens access the full catalogue

of approaches at: https://drive.google.com/

file/d/0B_PDf6-qXCFcMHRvcXJWbUdCNkk/view?

usp=sharing .

6 THE EVALUATION OF

SOFTWARE TOOLS

CATALOGUE

The catalogue of approaches was evaluated by means

of a peer review method. In this method one or more

experts of the researched area evaluate the study,

observing its relevance, correctness and contributing

with considerations for its improvement. Its choice is

justified by the need for a expert, who understands the

information provided in the catalogue, who has

experience in the area in question, can contribute to

the refinement of the catalogue and in the future put

it under evaluation in the industry.

This catalogue was evaluated by an expert in the

Software Engineering, Master in Computer Science

at Software Process Improvement (SPI), MR-MPS-

SW consultant and evaluator and with experience in

implementation, consulting and evaluation in

Software Process Improvement of more than 10

years, according to the models of CMMI and

MPS.BR – Brazilian Software Process Improvement,

and with more than 5 years experience with the use of

Statistical Process Control.

For the evaluation of the catalogue an evaluation

questionnaire was created, composed of 16 objective

questions, divided into 2 groups: the first one

concerns the Profile of the Reviewer of the catalogue,

in which the questions aim to discover the level of

knowledge of the reviewer regarding of the

methodology, process improvement of the

implementation the SPC, implementation of models

for process improvement, methods of evaluation in

the models and time of experience in evaluation of

SPC processes.

The second group deals with the Proposal

Presentation, whose purpose is to verify the

evaluator's understanding of the work under

evaluation, having as a matter of fact the degree of

correctness and completeness of the catalogue and if

it can be used as a reference in aiding the

implementation of the SPC.

As an annex to the questionnaire, a subjective

evaluation was requested to review the submitted

material, based on (Neto et al., 2017), in which it was

allowed to record comments by a table filled out by

the evaluator, containing the identification of the

comment, its category (HT - High Technician,

indicating that a problem has been found in an item

that, if not changed, will compromise the

considerations; LT - Low Technician, indicating that

a problem has been found in an item that it would be

appropriate to change; , indicating that a Portuguese

error was found or that the text could be improved; Q

- Questioning, indicating that there were doubts as to

the content of the considerations; G - General,

indicating that the comment is general in relation to

the considerations, item a which corresponds (which

can be related to a phase, task or in general of the

catalog), the text of the comment itself, and a

A Software Tools Catalogue to Support the Statistical Process Control on the Software Context

515

suggestion with the proposal of the reviewer to

circumvent the problem. The defined evaluation

material and catalogue were sent to the selected

reviewer via e-mail contact.

In general, the feedback received after the

evaluation was very beneficial and favorable for the

improvement of the catalogue. The evaluator

considered the proposal of the catalogue complete

and profound. There were some editorial

considerations, referential and the inclusion of

example of use of some approaches. After receiving

the evaluation of the catalogue, the researchers made

the corrections and the necessary observations,

fulfilling all the mentioned considerations. The

evaluation form can be accessed at:

https://drive.google.com/file/d/1Y6vYRWuNTMep5X

RyPusy31Hi5J3sLHpo/view?usp=sharing.

7 THE APPLICATION OF

SOFTWARE TOOLS

CATALOGUE

The application of this catalogue can be in the

academic or industrial context in organizations that

aim to implement the approaches related to Statistical

Process Control and need clarification as to its

definition and examples of practical use. In the

catalogue we also mentioned some examples of

software tools that implement the SPC and its

methodology, with examples of use. The catalogue

aims to contribute to the process of building

knowledge of organizations regarding the SPC,

clarify more general doubts and offer possibilities for

improvement, in order to enhance its use and practical

application in future projects.

8 CONCLUSIONS

The work carried out focused on the investigation of

SPC-related approaches by a SLR. The software tools

included in this catalogue, its description, use

example, information about its availability and

information on the ownership of the tool have been

presented in this paper. The theoretical basis applied

in this study was presented, related works,

methodology and main results obtained by the

systematic literature review, which gave rise to the

catalogue of approaches, which, in this work, brought

information from the cataloged software tools.

On the software tools presented in the catalogue it

was possible to get a glimpse of how the SPC and its

related approaches have been implemented. The

catalogue can serve as a benchmark for future SPC

research in software organizations.

So, the main scientific contribution of this work

was to describe a set of software tools that can support

during the implementation of Statistical Process

Control in the software context from studies already

published in conferences and journals, using as a

means the application of a systematic review of the

literature.

This work is a contributing part of a Master's

Dissertation and other scientific productions (Neto et

al., 2017; Neto et al., 2018). As evolution for this

study some future work is defined: (i) reapplication

of the systematic review, expanding the collection

period and including new sources of research; (ii) the

application of this catalogue in the industry, with its

use in a software development project, and may be of

great value for the maturation of this, because

opportunities for improvement in relation to its

structure, presentation form or even content may be

found, in addition to its effectiveness as to what is

proposed can be evaluated; (iii) proposing a survey

with research teams in industry and academia to

collect information on how to use the approaches

identified in the catalogue, trying to describe the

differences between theory and practical application

of approaches, advantages, difficulties, social aspects

and others; (iv) expanding the catalogue including

new techniques, more examples of using approaches

and software tools.

REFERENCES

Baldassarre, M. T., Caivano, D, Kitchenham, B., Visaggio,

G., 2007. Systematic Review of Statistical Process

Control: An Experience Report. 11th EASE'07. Pg. 94-

102, Kele University, UK.

Barcellos, M. P., 2009. A Strategy for Software

Measurement and Measurement Basis for Statistical

Control of Software Processes in High Maturity

Organizations. Tese De Doutorado, UFRJ, Brasil.

Chang, Y. W., Lee, S. H., 2013. A development of a web-

based and user-centered process analysis system for

quality improvement. International Journal of

Precision Engineering and Manufacturing. Pg: 67 - 80.

Coreia do Sul.

Corrales, C. F., Jenkins, M., Villegas, J., 2013. Application

Of Statistical Process Control To Software Defect

Metrics: An Industry Experience Report. International

Symposium On Empirical Software Engineering And

Measurement. Pg:323–331. USA.

Garcés, B. Y., Pino, F. J., 2014. Statistical Control of

Software Process: A Systematic Review. Red de

Revistas Científicas de América Latina, el Caribe,

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

516

España y Portugal, Sistema de Información Científica.

Vol. 12, Pg: 55 -76, Portugal.

Gonçalves, L., Lima, L., Reis, R. Q., Nascimento, L.,

Ribeiro, T., 2012. Support for Statistic Process Control

of software process. CLEI. Pg:323 - 331. Brasil.

Kitchenham, B., Budgen, D., Brereton, P., 2015. Evidence-

Based Software Engineering and Systematic Reviews.

Chapman and Hall/CRC, ed. 1.

Mafra, S., Travassos, G., 2006. Primary and Secondary

Studies Supporting Evidence-Seeking in Software

Engineering. Programa De Engenharia De Sistemas E

Computação - Coppe/Ufrj. Brasil.

Neto, A. R. P., Furtado, J. C. C., Oliveira, S. R. B., 2017.

Statistical Process Control in Software Development

Projects: A Systematic Literature Review. CONTECSI

2017. Pág: 3283-3310. São Paulo – Brasil. Disponível

em: http://contecsi.fea .usp.br/envio/index.php/contecsi

/14CONTECSI/paper/view/4766, último acesso em:

Maio/2018.

Neto, A. R. P., Oliveira, S. R. B., 2018. The Statistical

Control Of Processes (Cep) In The Software Context:

A Catalog Of Approaches. CONTECSI 2018. Pág:

2979-3008. São Paulo – Brasil, 2018. Disponível em:

http://contecsi.fea.usp.br/index

.php/contecsi/15CONTECSI/paper/view/5800/3280,

último acesso em: Outubro/2018.

Pettersen, K., 2011. Measuring and predicting software

productivity: A systematic map and review.

Information and Software Technology. Vol.53, Pg: 317-

343. Suécia.

Rahman, M. N. A., Zain, R. M., Nopiah, Z. M., Ghani, J. A.

Deros, B. M., Mohamad, N., Ismail, A. R., 2008.

Statistical Process Control In Smes. A Case Study. 4th

WSEAS/IASME. Pag: 145 - 152. Malaysia.

Rocha, A. R. C, Souza, G. S, Barcellos, M. P., 2012.

Software Measurement And Statistical Process

Control. Ministry of Science, Technology and

Innovation. Secretary Of Information Technology, 1ª

Ed. Brasil.

Santos, R. E. S., Silva, F. Q. B., 2013. Motivation to

Perform Systematic Reviews and their Impact on

Software engineering Practice. ESEM. Pag: 292-295.

USA.

Travassos, G., Biolchini J., 2007. Applied Systematic

Reviews of Software Engineering. XXI SBES -

Brazilian Symposium On Software Engineering. Brasil.

Zain, R. M., Rahman, M. N. A., Nopiah, Z. M., 2009.

Design an Online SMEs-SPC Computer Based System.

ICIME. Pg: 67 - 80. 437–440. Malasya.

Zhang, Y., Hou, L., 2010. Software Design For Quality-

Oriented Statistical Tolerance And SPC. ICIC. Pg:127

-130. China.

Wheeler, D. J., Chambers, D. S., 2010. Understanding

Statistical Process Control. 3º Ed, SPC Press,

Knoxville – Tennessee.

A Software Tools Catalogue to Support the Statistical Process Control on the Software Context

517
