A View-invariant Framework for Fast Skeleton-based Action

Recognition using a Single RGB Camera

Enjie Ghorbel, Konstantinos Papadopoulos, Renato Baptista, Himadri Pathak, Girum Demisse,

Djamila Aouada and Bj

orn Ottersten

Interdisciplinary Centre for Security, Reliability and Trust, Luxembourg

Keywords:

View-invariant, Human Action Recognition, Monocular Camera, Pose Estimation.

Abstract:

View-invariant action recognition using a single RGB camera represents a very challenging topic due to the

lack of 3D information in RGB images. Lately, the recent advances in deep learning made it possible to

extract a 3D skeleton from a single RGB image. Taking advantage of this impressive progress, we propose a

simple framework for fast and view-invariant action recognition using a single RGB camera. The proposed

pipeline can be seen as the association of two key steps. The ﬁrst step is the estimation of a 3D skeleton from

a single RGB image using a CNN-based pose estimator such as VNect. The second one aims at computing

view-invariant skeleton-based features based on the estimated 3D skeletons. Experiments are conducted on

two well-known benchmarks, namely, IXMAS and Northwestern-UCLA datasets. The obtained results prove

the validity of our concept, which suggests a new way to address the challenge of RGB-based view-invariant

action recognition.

1 INTRODUCTION

Understanding human motion from a video repre-

sents a fundamental research topic in computer vi-

sion due to the diversity of possible applications

such as video surveillance (Baptista et al., 2018),

Human-Computer Interaction (Song et al., 2012), co-

aching (Lea et al., 2015), etc. A huge number of met-

hods have been proposed and have proven their ability

to efﬁciently recognize human actions as reﬂected in

these two surveys (Aggarwal and Xia, 2014; Poppe,

2010). Usually, it is important to note that classical

approaches assume ideal conditions. For example,

in (Wang et al., 2011; Wang and Schmid, 2013; Fer-

nando et al., 2015), the subject performing the action

is considered to be facing the camera. However, in a

real-world scenario, camera positioning as well as hu-

man body orientation can vary, and consequently af-

fect the recognition task if the used method does not

take into account the viewpoint variability. In fact,

viewpoint invariance represents one of the most im-

portant challenges in human action recognition. Sol-

ving view-invariance requires relating a given acquisi-

tion of the subject to its 3D representation. While it is

a simple task with RGB-D cameras, it is less obvious

using RGB cameras, which only provide 2D informa-

tion, and no explicit 3D. The development of low-cost

RGB-D cameras has made possible the real-time ex-

traction of 3D information via depth maps and skele-

tons. This has signiﬁcantly boosted the research on

viewpoint invariant action recognition (Haque et al.,

2016; Hsu et al., 2016; Xia et al., 2012). However, the

disadvantages of RGB-D based approaches are tied to

RGB-D sensors. First, the estimation of an accepta-

ble depth map and skeleton is limited within a speciﬁc

range. Second, RGB-D cameras show a high sensiti-

vity to external lighting conditions, making outdoor

applications potentially challenging. Both of these

reasons restrict their applicability in real-world sce-

narios such as in video surveillance.

There is therefore a need to solve the view-invariance

problem using RGB cameras. Among the most

successful state-of-the-art approaches are methods

based on knowledge transfer (Gupta et al., 2014;

Rahmani and Mian, 2015). To ensure view-

invariance, these methods ﬁnd a view-independent la-

tent space where the features are mapped and then

compared. To achieve that, they use 3D synthetic

data computed by ﬁtting cylinders to real data cap-

tured with a Motion Capture (MoCap) system, and by

projecting them to various viewpoints.

The aforementioned approaches make use of tra-

jectory shape descriptors (Wang et al., 2011). These

descriptors are, by deﬁnition, not view-invariant. In-

Ghorbel, E., Papadopoulos, K., Baptista, R., Pathak, H., Demisse, G., Aouada, D. and Ottersten, B.

A View-invariant Framework for Fast Skeleton-based Action Recognition using a Single RGB Camera.

DOI: 10.5220/0007524405730582

In Proceedings of the 14th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2019), pages 573-582

ISBN: 978-989-758-354-4

573

deed, motion shape in 2D can only be described as

points on the image grid; therefore, any radial mo-

tion information is mostly lost. In addition, some

actions include similar motion patterns from different

body parts, which can negatively impact the classiﬁ-

cation (Papadopoulos et al., 2017).

In this paper, instead of relying on a set of 2D pro-

jections of synthetic data, we propose to augment 2D

data by a third component. Motivated by the very re-

cent encouraging progress on pose estimation from

a single RGB image (Pavlakos et al., 2017; Mehta

et al., 2017; Yang et al., 2018), we introduce a no-

vel way of approaching the viewpoint invariant action

recognition problem using a single 2D or RGB ca-

mera. Our approach consists in estimating human

3D poses from 2D sequences, then directly using this

3D information with a robust 3D skeleton descrip-

tor. Using 3D skeleton-based descriptors makes the

approach fully view-invariant, since they involve 3D

points for describing the body structure. Such des-

criptors have been proven robust in multiple scena-

rios (Xia et al., 2012; Yang and Tian, 2012). The

main advantages of this framework are its simplicity

and its low computation time thanks to the use of

a high-level representation. In order to validate it,

we propose to use the Convolutional Neural Network

(CNN)-based approach referred to VNect for the esti-

mation of 3D skeletons from 2D videos (Mehta et al.,

2017). The VNect system was selected over rela-

ted ones (Pavlakos et al., 2017; Mehta et al., 2017;

Yang et al., 2018), because of its real-time perfor-

mance and its ability to ensure temporal coherence.

Two different view-invariant skeleton-based descrip-

tors are used to test this framework, namely, Kinema-

tic Spline Curves (KSC) (Ghorbel et al., 2018; Ghor-

bel et al., 2016) and Lie Algebra Representation of

body-Parts (LARP) (Vemulapalli et al., 2014). Fi-

nally, the experiments are conducted on two diffe-

rent cross-view action recognition benchmarks: the

Northwestern-UCLA (Wang et al., 2014) and the IX-

MAS (Weinland et al., 2006) datasets.

The main contributions of this paper may be sum-

marized as follows:

• A novel framework for fast view-invariant human

action recognition using a single RGB camera.

• Comparison of two different view-invariant

skeleton-based descriptors integrated into the pro-

posed framework.

• Extensive experimental evaluation on two well-

known datasets and a deep analysis of the obtai-

ned results.

The remainder of the paper is organized as follows:

In Section 2, relevant state-of-the-art approaches are

summarized. Section 3 presents the proposed frame-

work and details the used skeleton-based descriptors.

The experimental evaluation is described in Section 4,

along with a thorough discussion of the results. Fi-

nally, Section 5 concludes this work and presents di-

rections for future works.

2 RELATED WORK

As mentioned in Section 1, invariance to viewpoint

represents a major challenge in action recognition.

Viewpoint invariant human action recognition can be

categorized into two main classes: RGB-D and RGB

based approaches as overviewed below.An extensive

review may be found in the recent survey by Trong et

al. (Trong et al., 2017).

2.1 RGB-D-based Methods

The emergence of RGB-D cameras has importantly

facilitated the task of viewpoint invariant action re-

cognition thanks to the availability of 3D informa-

tion (Hsu et al., 2016; Rahmani et al., 2014). Indeed,

RGB-D cameras provide depth images that may be

directly used for deﬁning view-invariant descriptors.

Depth images only provide partial 3D informa-

tion. In the context of action recognition, human 3D

skeletons estimated from depth images are considered

to be a more complete high level 3D representation,

which is view-invariant by nature. In addition, with

the rapid development of dedicated algorithms to es-

timate skeletons from depth maps such as (Shotton

et al., 2013), numerous view-invariant skeleton-based

approaches have been proposed. One of the pioneer-

ing works has been introduced in (Xia et al., 2012),

where a descriptor encoding a histogram of 3D joints

was proposed. Nevertheless, since the absolute posi-

tion of joints is used, these features are sensitive to

anthropometric variability. To resolve this issue and

preserve view-invariance, some approaches proposed

to describe actions using the distance between joints.

For instance, in (Yang and Tian, 2012), actions are de-

picted using a novel descriptor called eigenjoints. The

latter is computed by applying Principal Component

Analysis (PCA) on the spatial and temporal Euclidean

distances between joints.

To cope with viewpoint variability and increase accu-

racy, other approaches have modeled human actions

using more sophisticated geometric tools. In (Evan-

gelidis et al., 2014), authors proposed a novel view-

invariant representation by introducing a descriptor

based on the relative position of joint quadruples.

Also, Vemulapalli et al. suggested a new representa-

VISAPP 2019 - 14th International Conference on Computer Vision Theory and Applications

574

tion called Lie Algebra Representation of body-Parts

(LARP) by computing the geometric transformation

between each pair of skeleton body-parts (Vemula-

palli et al., 2014).

The presented descriptors are implicitly unaf-

fected by the viewpoint variability as they are deﬁned

using invariant features such as the distance between

joint, angles, transformation matrices, etc. Neverthe-

less, since the 3D skeleton contains the full 3D infor-

mation, an alignment pre-processing can be simply

applied before undertaking the descriptor computa-

tion. For example, we cite the work of (Ghorbel et al.,

2018), where the motion has been modeled by compu-

ting and interpolating kinematic features of joints. In

this case, the Kinematic Spline Curves (KSC) descrip-

tor is not view-invariant by nature; thus, the skeletons

are initially transferred to a canonical pose.

Although these representations have shown their

effectiveness in terms of computation time and accu-

racy, they are hardly applicable in various scenarios,

since the skeletons are estimated using RGB-D came-

ras. Indeed, the skeleton estimation accuracy decays

in the presence of a non-frontal view (Rahmani et al.,

2016) due to self-occlusions. Furthermore, as men-

tioned in Section 1, RGB-D cameras require speciﬁc

conditions to optimally work such as outdoor environ-

ment, closeness to the camera, moderate illumination,

etc. As a result, RGB-D based human action recogni-

tion has limited applications.

2.2 RGB-based Methods

Very recent efforts have been made to propose view-

invariant human action recognition methods using a

monocular RGB camera. However, the challenge is

that RGB images do not explicitly contain 3D infor-

mation and consequently traditional descriptors, such

as the Histogram of Oriented Gradients (HOG) (Dalal

and Triggs, 2005) and Motion Boundary Histograms

(MBH) (Dalal et al., 2006), are highly affected by the

introduction of additional views (Presti and Cascia,

2016). Thus, some RGB-based methods have been

speciﬁcally designed to overcome viewpoint varia-

tion (Gupta et al., 2014; Li et al., 2012; Zhang et al.,

2013; Wang et al., 2014; Li and Zickler, 2012; Rah-

mani and Mian, 2015; Weinland et al., 2006; Lv and

Nevatia, 2007).

One way of approaching the problem is to match

one viewpoint to another using geometric transforma-

tion as in (Weinland et al., 2007; Lv and Nevatia,

2007). However, this category of methods which are

usually based on 3D examplars require the use of la-

beled multi-view data. Another way consists in de-

signing spatio-temporal features which are insensitive

to viewpoint variation (Li et al., 2012; Parameswa-

ran and Chellappa, 2006; Rao et al., 2002). However,

their discriminative power has been shown to be limi-

ted (Rahmani and Mian, 2015).

The most popular RGB-based approaches are kno-

wledge transfer-based methods. The idea of know-

ledge transfer for view-invariant action recognition is

to map features from any view to a canonical one

by modeling the statistical properties between them.

For instance, Gupta et al.introduced a novel know-

ledge transfer approach using a collection of data

containing unlabeled MoCap sequences (Gupta et al.,

2014). Dense motion trajectories from RGB sequen-

ces are matched to projections of 3D trajectories ge-

nerated from synthetic data (cylinders ﬁtted to Mo-

Cap data). However, the number of these projections

is ﬁnite, which means that not every viewing angle is

represented. In addition, it is highly possible that dif-

ferent but similar-looking (from a speciﬁc angle) 2D

motion patterns are incorrectly matched, since the 2D

descriptors used in this context are view-dependent.

In (Rahmani and Mian, 2015), dense motion tra-

jectories (Gupta et al., 2014) are computed using synt-

hetic data similar to (Gupta et al., 2014), and repre-

sented using a codebook. A histogram is then built

in order to be used as a ﬁnal descriptor. This parti-

cular method is robust even when the testing view is

completely different from the training views. This is

due to the fact that the introduced Non-Linear Trans-

fer Model (NKTM) allows the approximation of non-

linear transformations. Despite their efﬁciency, the

two methods proposed in (Rahmani and Mian, 2015)

and in (Gupta et al., 2014) rely on 2D-based descrip-

tors that are not invariant to viewpoint changes.

3 PROPOSED FRAMEWORK

FOR RGB-BASED

VIEW-INVARIANT ACTION

RECOGNITION

In this section, we present the proposed framework

to perform a fast view-invariant human recognition

from a single RGB camera. Inspired by the advan-

ces in human pose estimation and the performance

of skeleton-based approaches, we propose to ﬁrst ge-

nerate 3D human skeletons from a monocular RGB

camera based on the recently introduced CNN-based

approaches. Then, the extracted skeletons are used to

compute skeleton-based features. Figure 1 illustrates

the proposed pipeline. In what follows, we detail the

different steps of this pipeline.

A View-invariant Framework for Fast Skeleton-based Action Recognition using a Single RGB Camera

575

TrainingPhase TestingPhase

Skeleton sequences

per frame

Heatmaps and location maps

generation

Input RGB

Sequences

Training SVM classifier

Kinematic

Spline Curves

Lie Algebra representation

of Body-Parts

Skeleton Feature Extraction

Kinematic

Spline Curves

Lie Algebra representation

of Body-Parts

Skeleton Feature Extraction

Skeleton sequences

per frame

Heatmaps and location maps

generation

Input RGB

Sequences

Trained SVM model

ActionLabel

Figure 1: Overview of the proposed pipeline for fast and view-invariant human action recognition from a monocular RGB

image: in both the training phase and the testing phase, skeletons are extracted from RGB images using the heatmaps and

locations maps generated by the VNect algorithm (Mehta et al., 2017). Then, based on the estimated skeleton, skeleton

features are computed e.g., LARP and KSC. Finally, in order to train a model of classiﬁcation and use it to recognize actions,

linear SVM is used.

3.1 Pose Estimation from a Monocular

RGB Image

Given a sequence of RGB images

R = {R

, ··· , R

}, where N is the total

number of frames, the goal of a pose estimation

algorithm f (·) is to extract a 3D skeleton composed

of n joints. We denote the sequence of extracted

skeletons by P(t) = [P

(t), P

(t), ..., P

(t)] such that

P(t) = f (R

), (1)

where f (·) is a function that maps a single RGB

image to an estimated representation of the human

pose in three dimensions and where t ∈ [1, ··· , N] de-

notes the frame index. Lately, with the recent success

of Deep Neural Networks, numerous methods have

been proposed to estimate 3D skeletons from a single

RGB image (Bogo et al., 2016; Tekin et al., 2016).

However, the resulting 3D estimated skeletons are

neither temporally stable nor computed online (Mehta

et al., 2017). Meanwhile, VNect proposed in (Mehta

et al., 2017) addresses both of these issues effectively.

As in (Mehta et al., 2016; Pavlakos et al., 2017),

VNect makes use of CNN models. However, authors

select a smaller architecture, Residual Netoworks

(ResNet) to achieve real-time performance. More im-

portantly, it is based on a network architecture with

fewer parameters, hence inference can be done in a

computationally efﬁcient manner. This CNN pose re-

gression allows the estimation of 2D and 3D skeletons

using a monocular RGB camera. To that aim, for each

joint j, the network is trained to estimate a 2D heat-

map H

of body parts along with joint location maps

in each of the three dimensions, which we denote as

, Y

, Z

. The position of each joint j is therefore

estimated by extracting the maximum values from the

location maps of the associated heatmap H

The network is trained by considering the weigh-

ted L

norm difference between estimated joint loca-

tion and the ground truth– the cost is summed over

each dimension. For instance, the loss of predicting

location x

, is given as

Loss = kH

 (X

− X

, (2)

where GT refers to the Ground Truth and  indicates

the Hadmord product.

The network is pre-trained using the annotated 3D and

2D human datasets (Ionescu et al., 2014; Mehta et al.,

2016; Andriluka et al., 2014).

In order to ensure temporal coherence, the estima-

ted joint positions are later smoothed. This is of great

importance in our case since our goal is to recognize

actions.

3.2 Feature Extraction

Using the estimated skeletons, we propose to in-

dependently integrate two different view-invariant

skeleton-based methods: LARP (Vemulapalli et al.,

2014) and KSC (Ghorbel et al., 2018). In (Vemula-

palli et al., 2014), the used features are view-invariant

by nature, while in (Ghorbel et al., 2018), a skeleton

alignment pre-processing is realized. In the following

two subsections, we describe both LARP and KSC.

VISAPP 2019 - 14th International Conference on Computer Vision Theory and Applications

576

3.2.1 Lie Algebra Representation of Body-Parts

(LARP)

In (Vemulapalli et al., 2014), an efﬁcient skeleton-

based action recognition approach is introduced. The

approach is based on describing the geometric rela-

tionship between different coupled body segments.

Let S(t) = (P(t), E(t)) be a set of skeleton sequen-

ces P(t) with n joints, and m rigid-oriented body

parts E(t). The skeleton sequence are described

in (1), while the rigid-body parts are deﬁned as E(t) =

(t), e

(t), ··· , e

(t)}. Each body part e

(t) is as-

signed a 3D local coordinate system. Then, between

each couple of local coordinate systems attached to

the body-parts e

(t) and e

(t), a 3D rigid transforma-

tion matrix T

i, j

(t) is deﬁned as:

i, j

(t) =



i, j

(t) t

i, j

(t)

0 1



, (3)

where Q

m,n

is a 3 × 3 rotation matrix and t

i, j

(t) a

three-dimensional translation vector.

To completely encode the geometric relation be-

tween e

and e

, both T

m,n

and T

n,m

are es-

timated. Subsequently, a sequence of skele-

tons varying over time is represented as C(t) =

1,2

(t), T

2,1

(t), ..., T

n,m

(t), T

m,n

(t)].The set of rigid

transformation matrices deﬁne a direct product of

non-Euclidean observation space called the Special

Euclidean group SE(3). As a result, each represen-

tation of a skeleton is a point and skeleton sequence

is a curve in SE(3)

, with C

denoting the combi-

nation operation. Classiﬁcation of the observed cur-

ves is done on the tangent space of the identity ma-

trix, using Support Vector Machine (SVM) algorithm.

Note that, a preliminary point matching is necessary

to achieve temporal alignment which, in (Vemulapalli

et al., 2014), is achieved via dynamic time warping

and Fourier temporal pyramid representation. The use

of 3D rigid transformation matrices between body-

parts as features ensures the view-invariance, since

they are independent from the view of acquisition.

3.2.2 Kinematic Spline Curves (KSC)

This second skeleton-based representation has been

introduced in (Ghorbel et al., 2018) and is mainly

characterized by its compromise between computa-

tional latency and accuracy. To do that, the chosen

components are carefully selected to ensure accuracy

and computational efﬁciency. The descriptor is based

on the computation of kinematic values, more speciﬁ-

cally joint position P(t), joint velocity V(t) and joint

acceleration A(t).

Figure 2: Frame samples from the Northwestern-UCLA da-

taset: an example is given for each viewpoint V

, V

and V

The key idea of this approach is to deﬁne a kine-

matic curve of a skeleton sequence as

KF(t) = [P(t), V(t), A(t)]. (4)

Subsequently, a kinematic curve can be reparamete-

rized such that it is invariant to execution rate using

a novel method called Time Variable Replacement

(TVR) (Ghorbel et al., 2018). As its name indicates,

this method consists in changing the variable time by

another variable that is less inﬂuenced by the variabi-

lity in execution rate. It be written as

KF(φ(t)) = [P(Φ(t)), V(Φ(t)), A(Φ(t))]. (5)

The new parameter φ is constrained to be bijective,

increasing with respect to t, and have a physical rate-

invariant meaning. In our case, we use the Pose

Motion Signal Energy function proposed in (Ghor-

bel et al., 2018) to deﬁne φ. Subsequently, in order

to obtain a meaningful descriptor, the discrete data

point samples KF(φ(t)) are interpolated using a cu-

bic spline interpolation, then, uniformly sampled. Fi-

nally, the classiﬁcation is carried out using a linear

SVM. It is important to note that the computation of

this descriptor includes also skeleton normalization

and skeleton alignment steps making it respectively

invariant to anthropometric and viewpoint changes.

The alignment is carried out by estimating a transfor-

mation matrix between each skeleton and a canonical

pose.

4 EXPERIMENTS

The proposed pipeline is tested on two different

cross-view human action recognition benchmarks:

the Northwestern-UCLA Multiview Action3D (Wang

et al., 2014) denoted by N-UCLA and the INRIA

Xmas Motion Acquisition Sequences dataset (Rah-

mani and Mian, 2015) denoted by IXMAS.

4.1 Datasets

4.1.1 Northwestern-UCLA Dataset

The Northwestern-UCLA dataset consists of videos

captured by using 3 different Kinect sensors from dif-

A View-invariant Framework for Fast Skeleton-based Action Recognition using a Single RGB Camera

577

ferent viewpoints. Thus, this dataset contains in total

3 modalities: RGB images, depth maps and skeleton

sequences and includes 10 action classes: pick with

one hand, pick up with two hands, drop trash, walk

around, sit down, stand up, donning, dofﬁng, throw

and carry. Each action class is repeated by 10 sub-

jects from 1 to 6 times. The main challenge of this

dataset is that it contains very similar actions such as

pick with one hand and pick up with two hands. Fi-

gure 2 illustrates examples from this benchmark.

4.1.2 IXMAS Dataset

This dataset is captured using 5 synchronized RGB-

cameras placed in 5 different viewpoints: four from

the side and one from the top of the subject. IXMAS

dataset is constituted from 11 different action catego-

ries: check watch, cross arms, scratch head, sit down,

get up, turn around, walk, wave, punch, kick and pick

up. This dataset is challenging since it contains com-

plex viewpoints leading to self-occlusions. Such vie-

wpoints are illustrated in Figure 4 (top row).

4.2 Experimental Settings and

Implementation Details

All the experiments were run on an i7 Dell Latitude

laptop with 16GB RAM and implemented in Matlab.

For both datasets, we follow the same experimental

protocol used in (Rahmani and Mian, 2015). For the

case of the Northwestern dataset, two viewpoints are

used for the training and the third for the testing. In

total, 3 experiments are performed. Moreover, each

test on IXMAS dataset involves every combination of

viewpoint pairs for training and testing, resulting in

20 experiments in total.

In this work, we consider two types of experi-

ments: VNect+KSC and VNect+LARP. VNect+KSC

refers to our framework combined with the KSC des-

criptor, while VNect+LARP denotes our framework

merged with the LARP descriptor. We compare our

framework with the recent RGB-based methods de-

noted in the rest of the paper by Hanklets (Li et al.,

2012), Dis- criminative Virtual Views (DVV) (Li

and Zickler, 2012), AND-OR Graph (AOG) (Wang

et al., 2014), Continuous Virtual Pat (CVP) (Zhang

et al., 2013), Non-linear Circulant Temporal Enco-

ding (nCTE) (Gupta et al., 2014) and Non-linear

Knowledge Transfer Model (NKTM) (Rahmani and

Mian, 2015).

Table 1: Accuracy of recognition (%) on the Northwestern-

UCLA dataset: We report the accuracy obtained for each

test (when two viewpoints are used for training (Source) and

one viewpoint for testing (Target)) and the average accuracy

for the three tests (Mean).

{Source} | {Target} {1,2}| 3 {1,3}| 2 {2,3}| 1 Mean

Hankelets (Li et al., 2012) 45.2 - - -

dvv1 (Li and Zickler, 2012) 58.5 55.2 39.3 51.0

CVP (Zhang et al., 2013) 60.6 55.8 39.5 52.0

AOG (Wang et al., 2014) 73.3 - - -

nCTE (Gupta et al., 2014) 68.8 68.3 52.1 63.0

NKTM (Rahmani and Mian, 2015) 75.8 73.3 59.1 69.4

VNect+LARP (ours) 70.0 70.5 52.9 64.47

VNect+KSC (ours) 86.29 79.72 66.53 77.51

4.3 Results and Discussion

The results on the Northwestern-UCLA dataset

are reported in Table 1 and prove that our met-

hod (VNect+KSC) outperforms state-of-the-art met-

hods. Indeed, an increase of around 8% compa-

red to the most competitive approach can be no-

ted (NKTM (Rahmani and Mian, 2015)). Moreo-

ver, Figure 3 shows that for almost all action classes,

VNect+KSC outperforms nCTE(Gupta et al., 2014)

and NKTM(Rahmani and Mian, 2015). On the other

hand, despite the fact that VNect+LARP shows a lo-

wer accuracy by 5% compared to NKTM, this appro-

ach stands among the best performing ones, showing

promising results.

The results for the IXMAS dataset are presen-

ted in Tables 2 and 3. Our proposed approach

(VNect+KSC) achieves the third best mean recogni-

tion accuracy, achieving 58.12% (against 72.5% for

NKTM (Rahmani and Mian, 2015) and 67.4% for

NCTE(Gupta et al., 2014)). However, as depicted in

Table 2, for every viewpoint pair, our approach shows

a competitive performance, except for the ones which

include viewpoint V

. For example, tests 2 | 0 and

2 | 3 outperform earlier works and respectively reach

an accuracy of 85.2% and 88.5%, while tests 0 | 4 and

2 | 4 present very low results (respectively 15.5% and

16.4%). This poor performance is the result of er-

roneous and noisy skeleton estimation coming from

the pose estimator. Figure 4 illustrates an example of

the extraction of skeletons from different viewpoints

using VNect. This ﬁgure highlights the fact that all

skeletons are visually coherent except for the one ex-

tracted from V

which represents the top viewpoint.

The presence of self-occlusions in V

is crucial for

the performance of VNect, since it makes the skeleton

estimation by nature more challenging. Nevertheless,

this constraint can be generalized to other approaches,

affecting their performance, as well. By investigating

more on this question, we discovered that VNect is

not trained on extreme viewpoints such as V

. Thus,

we underline a very interesting research issue to study

in the future.

VISAPP 2019 - 14th International Conference on Computer Vision Theory and Applications

578

Table 2: Accuracy of recognition (%) on the IXMAS dataset: the different tests are detailed. Each time, one viewpoint is used

for training (Source) and another one for testing (Target).

{Source} | {Target} 0| 1 0| 2 0| 3 0| 4 1| 0 1| 2 1| 3 1| 4 2| 0 2| 1 2| 3 2| 4 3| 0 3| 1 3| 2 3| 4 4| 0 4| 1 4| 2 4| 3

Hankelets (Li et al., 2012) 83.7 59.2 57.4 33.6 84.3 61.6 62.8 26.9 62.5 65.2 72.0 60.1 57.1 61.5 71.0 31.2 39.6 32.8 68.1 37.4

DVV (Li and Zickler, 2012) 72.4 13.3 53.0 28.8 64.9 27.9 53.6 21.8 36.4 40.6 41.8 37.3 58.2 58.5 24.2 22.4 30.6 24.9 27.9 24.6

CVP (Zhang et al., 2013) 78.5 19.5 60.4 33.4 67.9 29.8 55.5 27.0 41.0 44.9 47.0 41.0 64.3 62.2 24.3 26.1 34.9 28.2 29.8 27.6

nCTE (Gupta et al., 2014) 94.8 69.1 83.9 39.1 90.6 79.7 79.1 30.6 72.1 86.1 77.3 62.7 82.4 79.7 70.9 37.9 48.8 40.9 70.3 49.4

NKTM (Rahmani and Mian, 2015) 92.7 84.2 83.9 44.2 95.5 77.6 86.1 40.9 82.4 79.4 85.8 71.5 82.4 80.9 82.7 44.2 57.1 48.5 78.8 51.2

VNect+LARP (ours) 46.6 42.1 53.9 9.7 50.6 37.5 47.3 10.0 43.4 33.0 53.6 11.8 51.2 37.8 53.6 9.1 10.9 8.7 10.9 7.9

VNect+KSC (ours) 86.7 80.6 82.4 15.5 91.5 79.4 81.8 15.8 85.2 77.0 88.5 16.4 83.0 77.9 82.4 12.1 28.1 24.8 29.1 24.2

Figure 3: Action recognition accuracy for each action on the

Northwestern-UCLA dataset: comparison of our method

with NKTM(Rahmani and Mian, 2015) and nCTE(Gupta

et al., 2014).

Table 3: Average accuracy of recognition (%) on the IX-

MAS dataset: the ﬁrst value (Mean with V

) reports the

average of all the tests done, while the second value (Mean

without V

) computes the average of all texts excepting the

ones involving V

{Source} | {Target} Mean with V

Mean without V

Hankelets (Li et al., 2012) 56.4 61.41

DVV (Li and Zickler, 2012) 38.2 36.2

CVP (Zhang et al., 2013) 42.2 49.60

NCTE (Gupta et al., 2014) 67.4 80.45

NKTM (Rahmani and Mian, 2015) 72.5 84.46

LARP-VNect (ours) 31.50 45.91

KSC-VNect (ours) 58.12 83.03

For this reason, we propose to evaluate the pro-

posed concept by keeping in mind that the current

version of VNect is not adapted yet to the estima-

tion of skeletons from top views. Thus, we compute

the average accuracy by ignoring the tests where V

has been considered. The results reported in Table 3

show that our approach competes with state-of-the-

art by achieving 83.03% of recognition. It shows the

second highest accuracy after NKTM (Rahmani and

Mian, 2015) approach (reaching 84.46%) with only

1% of difference.

4.3.1 RGB-based Skeletons vs. RGB-D-based

Skeletons

In order to compare the quality of skeletons extracted

from VNect compared to the ones provided by RGB-

Table 4: Accuracy of recognition (%) on the Northwestern

dataset using the KSC descriptor: the performances obtai-

ned when using the skeletons provided by RGB-cameras

and the ones extracted using VNect algorithm are compa-

red. We report the accuracy obtained for each test (when

two viewpoints are used for training and one viewpoint for

testing) and the average accuracy (Mean).

{Source} | {Target} {1,2}| 3 {1,3}| 2 {2,3}| 1 Mean

skeleton-RGB-D 80.5 72.6 61.0 71.1

skeleton-VNect 86.3 79.7 66.5 77.5

D cameras for the task of action recognition, we pro-

pose to compute the KSC descriptor using both the

VNect-generated skeletons and the RGB-D skeletons.

Results obtained on the Northwestern-UCLA da-

taset are reported in Table 4. Skeleton-RGB-D and

skeleton-VNect refer to the results obtained by ap-

plying respectively the KSC descriptor to the skele-

tons provided by the Kinect and the skeletons pro-

vided by the VNect. The reported results show that

action recognition can be more robust using VNect-

generated skeleton sequences. In fact, using VNect

skeletons, the mean accuracy increased by 7.4% com-

pared to the utilization of the provided RGB-D skele-

ton sequences. The reason for that is the fact that the

extraction of skeletons from RGB-D cameras is less

accurate when the human body is not totally visible.

With the variation of human body orientation with re-

spect to the camera, self-occlusions occur, impacting

negatively the skeleton estimation.

4.3.2 LARP vs. KSC

The results performed on the Northwestren dataset

as well as on the IXMAS dataset show the superio-

rity of KSC descriptor for viewpoint action recogni-

tion when combined with VNect skeletons. Indeed,

KSC+VNect presents an average accuracy of 77.51%

against 64.47% for VNect+LARP on the Northwes-

tern UCLA dataset. On IXMAS dataset, KSC out-

performs LARP, as well, by achieving an average

accuracy of 83.03% against 58.12% when ignoring

and of 45.91% against 31.5% when considering it.

The interpretation of this result lies on the fact that

KSC+VNect is less sensitive to noise than LARP.

A View-invariant Framework for Fast Skeleton-based Action Recognition using a Single RGB Camera

579

Figure 4: Illustration of skeleton extraction from the IXMAS dataset using VNect system: it can be noted that for the four ﬁrst

views (V

, V

), the quality of the estimated is visually acceptable. However, the quality of the last view V

is completely

biased. This fact is conﬁrmed by our experiments.

Table 5: Computation time in minutes on the Northwe-

stren dataset by using V

and V

for training and V

for tes-

ting. All the reported computation time includes descriptor

calculation. *The reported values for AOG (Wang et al.,

2014), NCTE (Gupta et al., 2014), NKTM (Rahmani and

Mian, 2015) have been reported from the paper (Rahmani

and Mian, 2015) and therefore the computation time has not

been computed on the same computer.

Method Training + Testing

AOG* (Wang et al., 2014) 1020

NCTE* (Gupta et al., 2014) 612

NKTM* (Rahmani and Mian, 2015) 38

VNect+KSC 6

4.3.3 Computation Time and Memory

The main advantage of our framework is its low com-

putation time. The training plus testing process takes

only 6 minutes, as presented in Table 5. This shows

that our framework can be considered as a real-time

system.

On the other hand, the proposed framework, when

using VNect for the skeleton estimation step, requires

to consume only 58.5MB of further memory which is

comparable to the memory needed to store the lear-

ned R-NKTM and the general codebook (57MB) in

(Rahmani and Mian, 2015) and which is signiﬁcantly

lower than the memory needed to store the samples

(30 GB) in (Gupta et al., 2014).

5 CONCLUSION AND FUTURE

WORK

In this work, a simple but original framework has

been proposed to resolve the issue of cross-view

action recognition based on a single monocular RGB

camera. For this purpose, a novel concept aiming

at augmenting 2D images by a third dimension is

proposed taking advantage of the recent advances in

3D pose estimation from a monocular RGB camera

and the effectiveness of skeleton-based descriptors.

A 3D skeleton is ﬁrst estimated from a single 2D

image using a CNN-based approach. Then, a view-

invariant skeleton-based method is applied to the es-

timated skeletons. To prove the validity of our frame-

work, the recently introduced VNect system has been

chosen to extract 3D skeletons from RGB images. Af-

ter that, two different view-invariant skeleton-based

approaches have been tested: KSC (Ghorbel et al.,

2018) and LARP (Vemulapalli et al., 2014). The ex-

periments on two datasets have shown the superiority

of KSC when integrated into that framework. The

obtained results are competitive with respect to re-

cent state-of-the-art approaches on both datasets, ex-

cept for the cases where an extreme viewpoint (the top

viewpoint) is considered. This suggests that it would

be important to extend 3D pose estimator to extreme

viewpoints.

ACKNOWLEDGEMENTS

This work was funded by the European Unions Ho-

rizon 2020 research and innovation project STARR

under grant agreement No.689947, and by the Nati-

onal Research Fund (FNR), Luxembourg, under the

project C15/IS/10415355/3D-ACT/Bj

orn Ottersten.

REFERENCES

Aggarwal, J. K. and Xia, L. (2014). Human activity recog-

nition from 3d data: A review. Pattern Recognition

Letters, 48:70–80.

VISAPP 2019 - 14th International Conference on Computer Vision Theory and Applications

580

Andriluka, M., Pishchulin, L., Gehler, P., and Schiele, B.

(2014). 2d human pose estimation: New benchmark

and state of the art analysis. In 2014 IEEE Conference

on Computer Vision and Pattern Recognition. IEEE.

Baptista, R., Antunes, M., Aouada, D., and Ottersten, B.

(2018). Anticipating suspicious actions using a small

dataset of action templates. In 13th International Joint

Conference on Computer Vision, Imaging and Com-

puter Graphics Theory and Applications (VISAPP).

Bogo, F., Kanazawa, A., Lassner, C., Gehler, P., Romero,

J., and Black, M. J. (2016). Keep it SMPL: Auto-

matic estimation of 3D human pose and shape from

a single image. In Computer Vision – ECCV 2016,

Lecture Notes in Computer Science. Springer Interna-

tional Publishing.

Dalal, N. and Triggs, B. (2005). Histograms of oriented gra-

dients for human detection. In 2005 IEEE Computer

Society Conference on Computer Vision and Pattern

Recognition (CVPR05). IEEE.

Dalal, N., Triggs, B., and Schmid, C. (2006). Human de-

tection using oriented histograms of ﬂow and appea-

rance. In Proceedings of the 9th European Conference

on Computer Vision - Volume Part II, ECCV’06, pages

428–441, Berlin, Heidelberg. Springer-Verlag.

Evangelidis, G., Singh, G., and Horaud, R. (2014). Skeletal

quads: Human action recognition using joint quadru-

ples. In Pattern Recognition (ICPR), 2014 22nd Inter-

national Conference on, pages 4513–4518. IEEE.

Fernando, B., Gavves, E., Oramas, J. M., Ghodrati, A., and

Tuytelaars, T. (2015). Modeling video evolution for

action recognition. In Proceedings of the IEEE Con-

ference on Computer Vision and Pattern Recognition,

pages 5378–5387.

Ghorbel, E., Boutteau, R., Bonnaert, J., Savatier, X., and

Lecoeuche, S. (2016). A fast and accurate motion des-

criptor for human action recognition applications. In

Pattern Recognition (ICPR), 2016 23rd International

Conference on, pages 919–924. IEEE.

Ghorbel, E., Boutteau, R., Boonaert, J., Savatier, X., and

Lecoeuche, S. (2018). Kinematic spline curves: A

temporal invariant descriptor for fast action recogni-

tion. Image and Vision Computing, 77:60–71.

Gupta, A., Martinez, J., Little, J. J., and Woodham, R. J.

(2014). 3d pose from motion for cross-view action re-

cognition via non-linear circulant temporal encoding.

In 2014 IEEE Conference on Computer Vision and

Pattern Recognition. IEEE.

Haque, A., Peng, B., Luo, Z., Alahi, A., Yeung, S., and

Fei-Fei, L. (2016). Towards viewpoint invariant 3d

human pose estimation. In European Conference on

Computer Vision, pages 160–177. Springer.

Hsu, Y.-P., Liu, C., Chen, T.-Y., and Fu, L.-C. (2016). On-

line view-invariant human action recognition using

rgb-d spatio-temporal matrix. Pattern recognition,

60:215–226.

Ionescu, C., Papava, D., Olaru, V., and Sminchisescu, C.

(2014). Human3.6m: Large scale datasets and pre-

dictive methods for 3d human sensing in natural envi-

ronments. IEEE Transactions on Pattern Analysis and

Machine Intelligence, 36(7):1325–1339.

Lea, C., Hager, G. D., and Vidal, R. (2015). An impro-

ved model for segmentation and recognition of ﬁne-

grained activities with application to surgical training

tasks. In Applications of computer vision (WACV),

2015 IEEE winter conference on, pages 1123–1129.

IEEE.

Li, B., Camps, O. I., and Sznaier, M. (2012). Cross-view

activity recognition using hankelets. In Computer

Vision and Pattern Recognition (CVPR), 2012 IEEE

Conference on, pages 1362–1369. IEEE.

Li, R. and Zickler, T. (2012). Discriminative virtual views

for cross-view action recognition. In Computer Vision

and Pattern Recognition (CVPR), 2012 IEEE Confe-

rence on, pages 2855–2862. IEEE.

Lv, F. and Nevatia, R. (2007). Single view human action

recognition using key pose matching and viterbi path

searching. In Computer Vision and Pattern Recogni-

tion, 2007. CVPR’07. IEEE Conference on, pages 1–

8. IEEE.

Mehta, D., Rhodin, H., Casas, D., Sotnychenko, O., Xu, W.,

and Theobalt, C. (2016). Monocular 3d human pose

estimation using transfer learning and improved CNN

supervision. CoRR, abs/1611.09813.

Mehta, D., Sridhar, S., Sotnychenko, O., Rhodin, H.,

Shaﬁei, M., Seidel, H.-P., Xu, W., Casas, D., and The-

obalt, C. (2017). Vnect: Real-time 3d human pose

estimation with a single rgb camera. volume 36.

Papadopoulos, K., Antunes, M., Aouada, D., and Ottersten,

B. (2017). Enhanced trajectory-based action recogni-

tion using human pose. In Image Processing (ICIP),

2017 IEEE International Conference on, pages 1807–

1811. IEEE.

Parameswaran, V. and Chellappa, R. (2006). View inva-

riance for human action recognition. International

Journal of Computer Vision, 66(1):83–101.

Pavlakos, G., Zhou, X., Derpanis, K. G., and Daniilidis,

K. (2017). Coarse-to-ﬁne volumetric prediction for

single-image 3d human pose. In Computer Vision and

Pattern Recognition (CVPR), 2017 IEEE Conference

on, pages 1263–1272. IEEE.

Poppe, R. (2010). A survey on vision-based human action

recognition. Image and vision computing, 28(6):976–

990.

Presti, L. L. and Cascia, M. L. (2016). 3d skeleton-based

human action classiﬁcation: A survey. Pattern Recog-

nition, 53:130–147.

Rahmani, H., Mahmood, A., Huynh, D., and Mian, A.

(2016). Histogram of oriented principal components

for cross-view action recognition. IEEE transacti-

ons on pattern analysis and machine intelligence,

38(12):2430–2443.

Rahmani, H., Mahmood, A., Huynh, D. Q., and Mian, A.

(2014). Hopc: Histogram of oriented principal com-

ponents of 3d pointclouds for action recognition. In

European conference on computer vision, pages 742–

757. Springer.

Rahmani, H. and Mian, A. (2015). Learning a non-linear

knowledge transfer model for cross-view action re-

cognition. In 2015 IEEE Conference on Computer

Vision and Pattern Recognition (CVPR). IEEE.

A View-invariant Framework for Fast Skeleton-based Action Recognition using a Single RGB Camera

581

Rao, C., Yilmaz, A., and Shah, M. (2002). View-invariant

representation and recognition of actions. Internatio-

nal Journal of Computer Vision, 50(2):203–226.

Shotton, J., Sharp, T., Kipman, A., Fitzgibbon, A., Fi-

nocchio, M., Blake, A., Cook, M., and Moore, R.

(2013). Real-time human pose recognition in parts

from single depth images. Communications of the

ACM, 56(1):116.

Song, Y., Demirdjian, D., and Davis, R. (2012). Conti-

nuous body and hand gesture recognition for natural

human-computer interaction. ACM Transactions on

Interactive Intelligent Systems (TiiS), 2(1):5.

Tekin, B., Rozantsev, A., Lepetit, V., and Fua, P. (2016).

Direct prediction of 3d body poses from motion com-

pensated sequences. In Proceedings of the IEEE Con-

ference on Computer Vision and Pattern Recognition,

pages 991–1000.

Trong, N. P., Minh, A. T., Nguyen, H., Kazunori, K., and

Hoai, B. L. (2017). A survey about view-invariant hu-

man action recognition. In 2017 56th Annual Confe-

rence of the Society of Instrument and Control Engi-

neers of Japan (SICE). IEEE.

Vemulapalli, R., Arrate, F., and Chellappa, R. (2014). Hu-

man action recognition by representing 3d skeletons

as points in a lie group. In 2014 IEEE Conference on

Computer Vision and Pattern Recognition. IEEE.

Wang, H., Kl

aser, A., Schmid, C., and Liu, C.-L. (2011).

Action recognition by dense trajectories. In Computer

Vision and Pattern Recognition (CVPR), 2011 IEEE

Conference on, pages 3169–3176. IEEE.

Wang, H. and Schmid, C. (2013). Action recognition with

improved trajectories. In Proceedings of the IEEE

international conference on computer vision, pages

3551–3558.

Wang, J., Nie, X., Xia, Y., Wu, Y., and Zhu, S.-C. (2014).

Cross-view action modeling, learning and recognition.

In Proceedings of the IEEE Conference on Computer

Vision and Pattern Recognition, pages 2649–2656.

Weinland, D., Boyer, E., and Ronfard, R. (2007). Action

recognition from arbitrary views using 3d exemplars.

In Computer Vision, 2007. ICCV 2007. IEEE 11th In-

ternational Conference on, pages 1–7. IEEE.

Weinland, D., Ronfard, R., and Boyer, E. (2006). Free

viewpoint action recognition using motion history vo-

lumes. Computer Vision and Image Understanding,

104(2-3):249–257.

Xia, L., Chen, C.-C., and Aggarwal, J. K. (2012). View

invariant human action recognition using histograms

of 3d joints. In Computer vision and pattern recog-

nition workshops (CVPRW), 2012 IEEE computer so-

ciety conference on, pages 20–27. IEEE.

Yang, W., Ouyang, W., Wang, X., Ren, J., Li, H., and Wang,

X. (2018). 3d human pose estimation in the wild by

adversarial learning. In Proceedings of the IEEE Con-

ference on Computer Vision and Pattern Recognition,

volume 1.

Yang, X. and Tian, Y. L. (2012). Eigenjoints-based action

recognition using naive-bayes-nearest-neighbor. In

Computer vision and pattern recognition workshops

(CVPRW), 2012 IEEE computer society conference

on, pages 14–19. IEEE.

Zhang, Z., Wang, C., Xiao, B., Zhou, W., Liu, S., and Shi,

C. (2013). Cross-view action recognition via a conti-

nuous virtual path. In Proceedings of the IEEE Con-

ference on Computer Vision and Pattern Recognition,

pages 2690–2697.

VISAPP 2019 - 14th International Conference on Computer Vision Theory and Applications

582
