A Pipeline Supporting a Smart Access to Historical Documents based

on a Rich Semantic Representation of Their Content: A Case Study

on Time Expressions

Alessandro Baldo, Anna Goy and Diego Magro

Dipartimento di Informatica, Università di Torino, C. Svizzera 185, Torino, Italy

Keywords: Semantic Web, Web-based Intelligent Systems, Ontology, Web Services, Digital Humanities.

Abstract: This work is part of two ongoing projects whose main goal is to demonstrate how semantic technologies can

support an effective access to historical archives. In this paper we present a full pipeline, from rough texts

up to the final user interface, aimed at creating and exploiting such representations. The pipeline is

structured in three modules - handling information extraction, semantic representations, and queries - and

offers external applications the possibility of accessing, and thus re-using, the output of each module, by

providing a tagged text, a SPARQL endpoint, and a RESTful web service. In the paper, we describe the

details of a proof-of-concept implementation of the pipeline architecture that focuses on time expressions.

Moreover, we present an example application that exploits the pipeline to enable users to access historical

documents by searching and browsing events and time specifications, thus demonstrating the effectiveness

of an access to historical texts based on a rich semantic representation of their content.

1 INTRODUCTION

This work is part of two ongoing projects,

Harlock'900 (di.unito.it/harlock900) and PRiSMHA

(di.unito.it/prismha), based on a collaboration

between Università di Torino (Computer Science

and Historical Studies departments) and Fondazione

Istituto Piemontese A. Gramsci (part of the Polo del

'900 foundation: www.polodel900.it), and funded by

Università di Torino and Compagnia di San Paolo.

Both projects, from slightly different perspectives,

aim at the valorization of historical archives and

their content through semantic technologies. The

main goal is to demonstrate how a rich formal

semantic representation of the content of historical

documents can provide historians, researchers,

journalists, students, and simply interested users

with an effective access to the information contained

in historical archives. In particular, within

PRiSMHA, we are investigating crowdsourcing

approaches to overcome the bottleneck represented

by the production of rich formal semantic

representations of the content of historical

documents (Goy et al., 2017).

With respect to this focus, in this paper we

present a complementary perspective: a full pipeline,

from rough texts up to the final User Interface (UI),

aimed at creating and exploiting semantic

representations of the content of historical

documents. In line with the major trend in the

research field, such representations are centered on

the notion of event, together with its properties, i.e.,

place, time, and participants (people, organizations,

collectives) with their roles (see Section 2).

The pipeline is structured in three macro-steps,

corresponding to its three main modules, namely:

 Information Extraction module: Identification/

extraction of descriptions of events and related

expressions (referring to time, places, and

participants) in texts (see Section 3.2);

 Semantic module: Construction of a rich

semantic characterization of the identified

events (see Section 3.3);

 Query Support module: Definition and

implementation of an indexing data structure

supporting efficient queries (see Section 3.4).

Moreover, we implemented an example

application (see Section 4) that exploits the output of

the Query Support module) to enable users to access

historical documents by searching and browsing the

semantic representation of their content.

Baldo, A., Goy, A. and Magro, D.

A Pipeline Supporting a Smart Access to Historical Documents based on a Rich Semantic Representation of Their Content: A Case Study on Time Expressions.

DOI: 10.5220/0006929601990206

In Proceedings of the 14th International Conference on Web Information Systems and Technologies (WEBIST 2018), pages 199-206

ISBN: 978-989-758-324-7

199

The most notable aspect of the pipeline described

in this paper is the possibility of accessing, and thus

re-using, the output of its main modules: different

kinds of applications − e.g., digital libraries, tourist

guides, education tools, citizen services − could

exploit the knowledge offered by the different

mentioned modules, as we will describe in detail in

the rest of the paper: after a brief review of major

related works (Section 2), in Section 3 we will

introduce the pipeline architecture and its three main

modules. In Section 4 we will present a web-based

application exploiting the pipeline, while Section 5

will conclude the paper.

2 RELATED WORK

As already stated in Section 1, in this paper we will

present a pipeline, composed of different modules,

mainly handling Information Extraction (IE) from

historical texts and generation of formal semantic

representation of their content. It is clear, in this

perspective, that the related work is huge and spans

many research fields, preventing us from providing a

complete overview. In this section we therefore

survey only the most relevant approaches, without

any claim of exhaustiveness.

The core of the projects in which the pipeline is

grounded is represented by the ontology-based

semantic representation of events narrated within

historical documents. The exploitation of Semantic

Web technologies within historical research areas

has grown in the last decade (Meroño-Peñuela et al.,

2015), (Goy et al., 2015), as proven by large projects

such as Europeana (www.europeana.eu). Dealing

with the formal representation of knowledge about

cultural heritage, it is impossible not to mention

CIDOC Conceptual Reference Model (www.cidoc-

crm.org), an ISO standard that has been used in

many projects about cultural heritage − e.g.,

WarSampo (seco.cs.aalto.fi/projects/sotasampo/en),

a project aiming at publishing datasets about the

Second World War in Finland as Linked Open Data.

CIDOC-CRM, as well as other ontologies in the

same domain, like SEM (van Hage et al., 2011), are

centered on the notion of event, usually

characterized by a set of properties describing "who

does what when and where", i.e., time, place and

participants of the event itself. The concept of event

plays a major role also within other projects

focusing on the historical domain, such as Agora

(van den Akker et al., 2010) and DIVE (de Boer et

al., 2015), supporting professional and simply

interested users in event-centric browsing of cultural

heritage items belonging to different collections. The

centrality of the notion of event is also demonstrated

by the significant research effort that has been

devoted to the task of automatically extracting

information about events from texts; see, for

instance, (Hogenboom et al., 2011), (Cybulska and

Vossen, 2011), (Segers et al., 2011), (Sprugnoli and

Tonelli, 2016). Moreover, events and their temporal

dimension play a central role in many approaches

aimed at providing an access to cultural heritage

collections based on narratives, i.e., paths of related

events and entities playing relevant roles in them

(e.g., famous historical characters); see, for example,

Storyscope (Mulholland et al., 2015), among others.

In the pipeline presented in this paper, the input

to the Semantic module is provided by the

Information Extraction module, aimed at identifying

information items within textual documents. With

respect to this task, the reference research area is IE,

and in particular Named Entity Recognition (NER),

with a specific attention to historical texts and to the

Italian language. Historical texts represent a peculiar

domain, where IE/NER tools show quite low

performances compared to other domains (such as

news, for example); see, for example (Ehrmann et

al., 2016), (Boschetti et al., 2014), (Moretti et al.,

2016), (Rovera et al., 2017). In particular, in (Rovera

et al., 2017) the authors present the usage of NER

tools to extract relevant information from historical

texts written in Italian (namely, memories of the

Second World War in Italy) and discuss the poor

performances of such tools on this specific domain,

probably due to the high specificity of the entities to

identify: in fact, if state-of-the-art tools have usually

good performances on well-known entities (such as

"Benito Mussolini"), they often fail with entities that

are relevant only in specific historical contexts (e.g.,

"Nicola Barbato").

3 PIPELINE

PROOF-OF-CONCEPT

PROTOTYPE

Historical textual sources (biographies, narratives,

letters, etc.) abound with descriptions of events and

temporal expressions placing these events in time.

For this reason, the proof-of-concept implementation

of the architecture we are going to present focuses

on time expressions.

The most interesting aspect of such a prototype

is that it enables users and third-party applications to

access information about historical events narrated

WEBIST 2018 - 14th International Conference on Web Information Systems and Technologies

200

in textual sources by exploiting not only classical

calendar-based temporal references, but much more

flexible time interval specifications, that can be

described thanks to the expressive power of the

underlying semantic model (see Section 3.3). From

this perspective, the prototype represents a proof of

the feasibility and effectiveness of an access to

historical texts based on a rich semantic

representation of their content.

3.1 Overview of the Architecture

Figure 1 provides an overview of the pipeline

architecture.

Figure 1: Pipeline architecture.

In the proof-of-concept implementation of the

Information Extraction Module, to identify temporal

expressions from historical texts, we relied on

HeidelTime (Strötgen and Gertz, 2013) − probably

the most used multilingual, cross-domain, rule-based

temporal tagger − that annotates the input text using

TimeML (www.timeml.org) (Pustejovsky, 2017).

HeidelTime supports the Italian language (Strötgen

et al., 2014) (Caselli and Sprugnoli, 2015), and its

performance in Italian processing was improved for

the participation in the evaluation contest EVENTI-

14 (Manfredi et al., 2014), where it achieved good

results compared to other systems (Caselli et al.,

2014). The identification of events, instead, was

based on a manual extraction performed in a

previous work (Caserio et al., 2017).

In line with the Semantic Web and Linked Data

principles (Heath and Bizer, 2011), the semantic

characterization of events and temporal intervals,

produced by the Semantic module, is stored in an

RDF triplestore (based on Apache Jena TDB:

jena.apache.org/documentation/tdb); it relies on the

HERO ontology (Caserio et al., 2017) and on a

declarative (configurable) mapping between

TimeML and HERO (see Section 3.3).

As discussed in Section 3.4, since the temporal

characterizations contained in the triplestore does

not support, at runtime, an efficient retrieval needed

to answer flexible temporal queries, the Query

Support module provides an efficient indexing data

structure, enabling temporal range queries.

The proposed pipeline offers third-party

applications a set of programming interfaces to

access the output of its main modules:

 The output of the Information Extraction

Module is a text containing tagged temporal

expressions in TimeML format, provided as

an XML object;

 The semantic representations produced by the

Semantic module and stored in the RDF

triplestore are accessible through a SPARQL

endpoint (based on Apache Jena Fuseki:

jena.apache.org/documentation/fuseki2);

 The data structure managed by the Query

Support module is accessible through a

RESTful web service that returns a JSON

object (a serialized tree of time intervals IRIs:

see Section 3.4).

To test the proof-of-concept prototype we used a

selection of texts extracted from two books (in

Italian) containing an autobiographical

chronological account of events of the "Resistenza"

(the Italian struggle against the Fascist regime and

the Nazi occupation) in Piemonte (North-West of

Italy) during the Second World War: Diena Marisa,

Guerriglia e autogoverno, Guanda, 1970; Diena

Marisa, Un intenso impegno civile, Lupieri, 2006.

3.2 Information Extraction Module

The task of temporal tagging can be viewed as a

particular Named Entity Recognition task, including

three main phases: extraction (i.e., identification of

temporal expressions), classification (i.e.,

association of the temporal expression with a class

of an ontology), and normalization (assignment of

the same value to all the time expressions referring

to the same temporal entity).

As already stated, the Information Extraction

module is based on HeidelTime, that annotates the

input text using TimeML. For the scope of this

work, the relevant TimeML tag is TIMEX3 with its

four main attributes: tid (a per-document identifier);

type (one out of DATE, TIME, DURATION, or

SET); value (the normalized value for the marked

temporal expression); mod (the normalized value for

the semantics of modifiers expressions, like − for

instance − the value APPROX for the modifier

around in the expression "around five o'clock").

After annotating the selected texts, we found out

some recurring errors that can be classified in two

A Pipeline Supporting a Smart Access to Historical Documents based on a Rich Semantic Representation of Their Content: A Case Study

on Time Expressions

201

categories: (a) errors due to the HeidelTime

heuristics; (b) errors due to incomplete and/or

erroneous rules.

Errors of type a are produced by the wrong

normalization of relative (under-specified) temporal

expressions (Strötgen and Gertz, 2013), such as

"July" ("luglio"), which require additional contextual

information to be correctly normalized. HeidelTime

anchors these expressions to the closest temporal

expression occurring before the under-specified one.

However, this heuristic is not very accurate, as

acknowledged also by HeidelTime authors

themselves in (Strötgen and Gertz, 2013): for

example, if the expression "born in Torino on

13/6/1918" ("nato a Torino il 13/6/1918") precedes

the expression "July" ("luglio"), the latter is

normalized as "July 1918", even though it is clear

from the overall context that it refers to "July 1943".

This kind of errors is not influenced by the language

of the input document and is deeply rooted in

HeidelTime internal heuristics: no modification to

the rules could, alone, solve this problem. Therefore,

we decided to manually correct these mis-

normalizations (which, in our case, occurred in

about 50% of the correctly identified temporal

expressions of that kind).

Errors of type b are related to the identification

phase: Temporal expressions like "the morning of

June 20th" ("la mattina del 20 giugno") were

recognized as two separate expressions instead of a

single one (the equivalent English expressions were

correctly extracted and normalized). The correct

behavior in this case is reported in the Italian

TimeML annotation guidelines (Caselli and

Sprugnoli 2015). This means that HeidelTime

resources for the Italian language were missing the

correct rules to handle these expressions: we thus

added them to the Italian rules file.

The output of the Information Extraction Module

is an XML object containing the original text with

TimeML tags identifying temporal expressions.

3.3 Semantic Module

To map temporal expressions identified by the

Information Extraction module to RDF triples

expressed using the vocabulary provided by the

selected ontology, we developed a Java-based

software, TimeML2RDF, that maps a temporal

expression tagged with (a subset of) TimeML to a

customizable set of RDF triples. In particular, the

target vocabulary used by TimeML2RDF is

completely configurable by defining mapping rules,

declaratively stated in a separate file.

Before presenting the mapping rules, we briefly

introduce HERO (Historical Event Representation

Ontology), a computational ontology written in

OWL2, developed within the Harlock'900 project. It

includes the following modules:

 HERO-TOP is the top-layer of the ontology,

linking it to the DOLCE foundational

ontology (Masolo et al., 2003).

 HERO-EVENT provides a class hierarchy for

events classification and properties for linking

an event to its participants, to the geographical

place where it occurred, and to the time

interval in which it occurred.

 HERO-PLACE provides a characterization of

geo-referenceable entities.

 HERO-TIME models time intervals, following

Allen's algebra (Allen, 1983).

 HERO-ROCS defines the semantics of roles,

organizations, collections and sets.

A complete description of HERO is out of the

scope of this paper: we just sketch the main features

of HERO-TIME, and quickly mention the classes

and properties of HERO-EVENT used in the

prototype. Figure 2 provides a (simplified) overview

of the main classes and properties in HERO-TIME

and their relations with elements in HERO-EVENT.

Figure 2: Events and time intervals in HERO.

Following Allen's interval algebra (Allen, 1983)

HERO-TIME adopts a representation of time based

on time intervals (or time spans), enabling reasoning

about time at various levels of granularity and taking

into account the inherently under-specification of

temporal expressions typically found in historical

sources (e.g., "at the beginning of 1945").

WEBIST 2018 - 14th International Conference on Web Information Systems and Technologies

202

A time interval in HERO is characterized as an

instance of the TimeInterval class − or, more often,

of its sub-class ProperTimeInterval, representing

time intervals with non-zero duration;

CalendarClockInterval, sub-class of

ProperTimeInterval, represents intervals referring to

some calendar or time convention (e.g., years,

months, days). Moreover, HERO-TIME models the

distinction between a time interval (e.g., an instance

of the CalendarClockInterval class) and the

expression denoting it (e.g., an instance of the

CalendarClockIntervalExpression class).

The main properties defined in HERO-TIME are

based on the 13 basic relations described by Allen

and representing all the possible relations between

two time intervals. The most relevant properties in

HERO-TIME are the following (in brackets the

corresponding relation in Allen's algebra): intStarts

(starts); intEnds (finishes); intIn (starts ∨ finishes ∨

during ∨ equals); intBeginsIn and intEndsIn (the

relation between a time interval t and other two time

intervals, t

and t

, that contain, respectively, the

beginning and ending "instants" of t).

The HERO-EVENT module defines the class

Event (sub-class of Perdurant, corresponding to the

same class in DOLCE) to represent entities that

happen in time. As depicted in Figure 2, the property

hasTimeSpan associates a perdurant to a time

interval, with the following meaning: given an event

(perdurant) e occurring exactly in the time interval

, hasTimeSpan(e,t) implies that intIn(t

,t); in this

way we account for the intrinsic "fuzziness" (under-

specification) of time expressions used in natural

languages (e.g., when we say that "Archduke Franz

Ferdinand of Austria was killed on 28 June 1914" it

is clear that we do not mean that the event lasted the

whole day, but that it occurred in a shorter time

interval contained in that day).

In order to translate TimeML tags produced by

the Information Extraction module into RDF

statements, different vocabularies (ontologies) can

be used, by defining different mapping rules. Each

rule is composed of two parts:

 a matching section, that defines a pattern of

features of a TimeML tag;

 a mapping section, that contains all the

information needed to produce the

corresponding set of RDF triples.

For example, the following TimeML tag:

<TIMEX3 tid="t01" value="1943-09-10"

type="DATE">il 10</TIMEX3>

matches the rule labeled YYYY-MM-DD date

(day), that − thanks to its mapping section −

produces the following RDF triples (ids have been

simplified for the sake of readability):

<https://w3id.org/dataset_900/

resource/time/id1>

a hero-time:Day ;

rdfs:label "1943-09-10" .

<https://w3id.org/dataset_900/

resource/time/id2>

a hero-time:DoMMYDate ;

hero-time:accordingToCalendarType

hero-time:gregorianCalendar ;

hero-time:

calCIExprDescrCalCI

<https://w3id.org/dataset_900/

resource/time/id1> ;

hero-time:hasXMLSchemaGDateLex

"1943-09-10"^^xsd:date .

The produced triples say that the identified time

interval (id1) is a day (hero-time:Day) and the

expression denoting it (id2) is a date consisting of

three parts: day, month and year (hero-

time:DoMMYDate), according to the Gregorian

calendar (the hero-time: calCIExprDescrCalCI

property associates the expression, id2, to the

described time interval, id1; the

hasXMLSchemaGDateLex property connects the

date id2 to its lexicalization as an XML Schema

xsd:date, i.e., "1943-09-10").

As far as the proof-of-concept prototype is

concerned, the relevant events had been manually

extracted, and the corresponding RDF triples

manually generated, in a previous work (Caserio et

al., 2017): therefore, we simply linked (through the

HERO hasTimeSpan property) the already available

semantic representation of such events to the RDF

triples describing time intervals produced by

TimeML2RDF. In this way, the final triplestore

contains the information about the (relevant) events

mentioned in the input texts, together with a fine-

grained representation of the time interval in which

they occurred, and the references to the documents

in which the events are mentioned. This knowledge

is available for third-party applications through a

SPARQL endpoint.

3.4 Query Support Module

The temporal description of the events in the

triplestore, while completely characterizing them,

does not allow an efficient retrieval based on

temporal range queries, due to different factors:

 Accessing the triplestore using SPARQL does

not specifically support temporal queries;

A Pipeline Supporting a Smart Access to Historical Documents based on a Rich Semantic Representation of Their Content: A Case Study

on Time Expressions

203

 The time intervals contained in the triplestore

have non-homogeneous granularities

(spanning from hours to several years);

 We cannot practically use, at run-time, an

OWL reasoner to infer additional temporal

information from the triples, due to the well-

known huge computational effort needed.

However, temporal relations defined in HERO

enable us to order intervals that cannot be placed on

a calendar reference system (e.g., "between

December 1943 and February 1944") by stating their

relation with calendar intervals.

Figure 3: Data structure for temporal range queries.

Figure 3 depicts, with some abstraction, the

indexing data structure that encodes the mentioned

relations, i.e., essentially a tree representation of a

calendar system where nodes represent either:

 Intervals with a 1:1 mapping to a calendar/

clock system (labeled boxes in Figure 3),

corresponding to CalendarClockInterval

instances, directly added to the data structure.

 Intervals related to a calendar interval via

HERO relations (black circles in Figure 3),

i.e., generic ProperTimeInterval instances,

added to the data structure by linking them to

a calendar interval through a HERO property.

Thanks to the described data structure, a

temporal range query generates a tree visit between

the two nodes delimiting the range, and the result

will contain both calendar intervals and intervals

specified using HERO relations.

Moreover, in many cases, it can be useful to

include in the result not only intervals completely

falling within the range, but also intervals partially

overlapping with it. For example, given the range

(selected by the user) spanning from 1942-12-04 to

1944-03-21, the time interval December 1942 has a

partial overlap with the query range, so an event

occurred in December 1942 ("fuzzy" specification)

may have occurred during the time-span selected by

the user. Events occurred in such time intervals can

be useful for a user querying the knowledge base

and can be retrieved by the Query Support module,

thanks to the indexing data structure just described.

This is particularly relevant in the historical domain

because, frequently, events described in historical

sources are placed in time in a rather "fuzzy" way

and at different granularities, depending on their

relative importance, the required precision, the

author’s preference, etc.

The knowledge encoded in such a data structure

is made available via a RESTful web service that

returns a serialized tree of the relevant time intervals

IRIs (linked to events, in turn linked to historical

documents) encoded in JSON.

4 EXAMPLE APPLICATION

As an example of application exploiting the rich

semantic characterization of historical events and

their temporal information, we developed a web-

based UI enabling the visualization and exploration

of historical events using temporal range queries.

The application exploits the RESTful web service

provided by the Query Support module to access the

knowledge about historical events and their temporal

properties and its ultimate goal is to provide users

with a smart access to the historical documents

where the events presented in the UI are narrated.

The UI enables the user to query the application

for events occurred in a given time period specified

by start and end time intervals. To support both fine

and coarse-grained searches, we allow the user to

express the query with different granularities. Figure

4 shows the input control and the interaction

sequence required to specify one extreme of the

query range. In order to keep the UI as intuitive as

possible, the control allows to specify only start and

end dates having the same temporal granularity.

Figure 4: UI for the specification of the query range.

The control starts in an empty state (1),

prompting the user to input a year; when the user has

inserted a valid year (2) the control shows a "+"

button that allows her to add the month granularity;

WEBIST 2018 - 14th International Conference on Web Information Systems and Technologies

204

she can proceed to specify a month (3) using the

date-picker appearing below the control. The same

steps can be repeated (5, 6) if the user wants to

specify the granularity of a day.

Historical time is often represented in graphical

form using timelines, i.e., geometrical mappings

from time to space. Timelines can offer an effective

overview of events in time and, when employed with

uniform timescales, they can provide an insight on

the relative duration of different events. However,

we decided to discard a timeline-based visualization

in our UI, mainly because the temporal data in our

prototype have very different granularities and the

described events are usually not related to a precise

time duration; for example, an event linked to

December 1943 and one linked to 1943-12-21 do not

have comparable relative durations. For this reason,

a simple geometrical mapping can be misleading,

since it can transmit the wrong mental model to the

user. Therefore, we opted for a representation based

on a chronological list of events, where events do

not possess any geometric dimension, but they are

simply chronologically ordered. This ordering plays

well with the vertical scrolling direction of a web

application UI compared to the horizontal

orientation typical of timelines. The resulting UI is

shown in Figure 5, that displays a portion of the

results obtained querying the system for events

occurred in the period 1943-1945.

Figure 5: Result page for the query 1943-1945.

On the top of the page there is a menu showing

the query made by the user. From these controls the

user can edit the temporal range and start a new

search. Just below there is a dynamic timeline that

allows the user to have a better overall grasp of the

time interval absolute position in the calendar and of

the relative distance with other intervals.

In the central part of the page there is the

chronological list of events occurred in time

intervals that can be positioned on a calendar.

Besides being chronologically ordered from top to

bottom, the events are horizontally aligned with a

calendar date (in year, month, or day granularity)

rendered on the left and allowing the anchoring of

the events in time. The hierarchical relation between

time granularities of the calendar is rendered using

spatial nesting from the left to the right.

The user can navigate through the list of events

by vertically scrolling the page: the calendar and the

list of events move outside the viewport to reveal

new portions of the results. When a calendar element

crosses the middle of the viewport, it is highlighted.

On the right-hand side of the central portion of

the page there is a graphical representation of time

intervals not expressed as CalendarClockInterval

instances and defined as time spans between two

calendar intervals (characterized using the

intBeginsIn and intEndsIn HERO properties). Each

interval is displayed as a rectangular bar, in which

the top and the bottom sides are horizontally aligned

with the start and end calendar dates delimiting the

interval. This section scrolls together with the

calendar and the events list. When an interval bar

intersects the middle of the viewport, the events

occurred in that time interval are listed on the right.

When the user pointer hovers over an event

description, the bar denoting the corresponding time

interval is highlighted, isolating it from other

possible overlapping bars.

Finally, the application exploits the possibility

that some events are characterized as occurring in a

time interval that only partially overlaps with the

query interval. In these cases we cannot be sure

whether or not to include these events in the result

set, so they are displayed with an appropriate

graphical distinction (italic font-face).

The application presented in this section

demonstrates:

 The possibility, for external applications, of

exploiting the knowledge provided by our

pipeline (namely, the RESTful web service

offered by the Query Support module).

 The advantages of having a rich semantic

representation of the content of historical

resources (namely, in the current prototype,

events with a fine-grained representation of

temporal information).

5 CONCLUSIONS

The proof-of-concept prototype presented in this

paper shows the feasibility and the effectiveness of

our approach. However, in order to fully assess it,

we plan to integrate both the back-end and the UI

within a wider application, enabling users to

navigate − by querying and browsing − historical

A Pipeline Supporting a Smart Access to Historical Documents based on a Rich Semantic Representation of Their Content: A Case Study

on Time Expressions

205

events narrated within archival documents. Such an

application, besides time information, will take into

account places where events occurred (i.e.,

geographical information) and event participants,

together with their roles in the events. The back-end

integration will be supported by the HERO ontology

and the usage of Semantic Web standards, while the

integration of the UI represents an interesting

challenge, which is under study.

ACKNOWLEDGEMENTS

This work has been partially supported by Università

di Torino and Compagnia di San Paolo within the

PRiSMHA project. We are grateful to M. Rovera for

the valuable suggestions on IE from historical texts.

REFERENCES

van den Akker, C., Aroyo, L., Cybulska, A., van Erp, M.,

Gorgels, P., Hollink, L., Jager, C., Legêne, S., van der

Meij, L., Oomen, J., van Ossenbruggen, J., Schreiber,

G., Segers, R., Vossen, P., Wielinga, B., 2010.

Historical Event-based Access to Museum

Collections. Applied Artificial Intelligence, 25.

Allen, J. F., 1983. Maintaining Knowledge about

Temporal Intervals. Communications of the ACM,

26(11), 832-843.

de Boer, V. Oomen, J., Inel, O., Aroyo, L., van Staveren,

E., Helmich, W., de Beurs, D. 2015. DIVE into the

Event-Based Browsing of Linked Historical Media.

Journal of Web Semantics, 35(3), 152-158.

Boschetti, F., Cimino, A., Dell'Orletta, F., Lebani, G. E.,

Passaro, L., Picchi, P., Venturi, G., Montemagni, S.,

Lenci, A. 2014. Computational Analysis of Historical

Documents: An Application to Italian War Bulletins in

World War I and II. In LREC 2014 Workshop.

Caselli, T., Sprugnoli, R., 2015. It-TimeML - TimeML

Annotation Guidelines for Italian, v. 1.4. Technical

Report. VU Amsterdam and FBK.

Caselli, T., Sprugnoli, R., Speranza, M., Monachini, M.,

2014. Eventi evaluation of events and temporal

information at EVALITA 2014. 4th EVALITA, 27-34.

Caserio, M., Goy, A., Magro, D., 2017. Smart access to

historical archives based on rich semantic metadata. In

IC3K

−

KMIS'17. INSTICC SciTePress, 93-100.

Cybulska, A., Vossen, P., 2011. Historical Event

Extraction from Text. In LaTeCH'11, 39-43.

Ehrmann, M., Colavizza, G., Rochat, Y., Kaplan, F., 2016.

Diachronic evaluation of NER systems on old

newspapers. In KONVENS'16, 97-107.

Goy, A., Magro, D., Rovera, M., 2015. Ontologies and

historical archives: A way to tell new stories. Applied

Ontology, 10(3-4), 331-338.

Goy, A., Damiano, R., Loreto, F., Magro, D., Musso, S.,

Radicioni, D., Accornero, C., Colla, D., Lieto, A.,

Mensa, E., Rovera, M., Astrologo, D., Boniolo, B.,

D’Ambrosio, M., 2017. PRiSMHA (Providing Rich

Semantic Metadata for Historical Archives). In

CREOL 2017.

van Hage, W.R., Malaisé, V., Segers, R., Hollink, L.,

Schreiber, G., 2011. Desing and use of the Simple

Event Model (SEM). Journal of Web Semantics, 9(2),

128-136.

Heath, T., Bizer, C., 2011. Linked Data: Evolving the Web

into a Global Data Space, Morgan & Claypool.

Hogenboom F., Frasincar F., Kaymak U., de Jong F.,

2011. An Overview of Event Extraction from Text. In

DeRiVE'11 at ISWC 2011, Vol. 779.

Manfredi, G., Strötgen, J., Zell, J., Gertz, M., 2014.

HeidelTime at EVENTI: Tuning Italian resources and

addressing TimeML's empty tags. In 4th EVALITA,

39-43.

Masolo, C., Borgo, S., Gangemi, A., Guarino, N.,

Oltramari, A., 2003. WonderWeb Deliverable D18.

Technical Report, CNR.

Meroño-Peñuela, A. Ashkpour, A., van Erp, M.,

Mandemakers, K., Breure, L., Scharnhorst, A.,

Schlobach, S., van Harmelen, F., 2015. Semantic

Technologies for Historical Research: A Survey.

Semantic Web Journal, 6(6), 539-564.

Moretti, G., Sprugnoli, R., Menini, S., Tonelli, S., 2016.

ALCIDE: Extracting and visualising content from

large document collections to support humanities

studies. Knowledge-Based Systems, 111, 100-112.

Mulholland P., Wolff A., Kilfeather E., 2015. Storyscope:

Supporting the authoring and reading of museum

stories using online data sources. In WebSci 2015,

ACM Press.

Pustejovsky, J., 2017. ISO-TimeML and the Annotation of

Temporal Information. In Ide, N., Pustejovsky, J.

(Eds.), Handbook of Linguistic Annotation, Springer,

941-968.

Rovera, M., Nanni, F., Ponzetto, S. P., Goy, A., 2017.

Domain-specific Named Entity Disambiguation in

Historical Memoirs, In CLiC-it'17, vol. 2006. CEUR.

Segers, R., van Erp, M., van der Meij, L. 2011. Hacking

History via Event Extraction. In K-CAP'11, 161-162.

Sprugnoli, R., Tonelli, S. 2016. One, no one and one

hundred thusand events: Defining and processing

events in an inter-disciplinary perspective.

Natural

Language Engineering, 23(4), 485-506.

Strötgen, J., Gertz, M., 2013. Multilingual and cross-

domain temporal tagging. Language Resources and

Evaluation, 47(2), 269-298.

Strötgen, J., Armiti, A., Van Canh, T., Zell, J., Gertz, M.,

2014. Time for more languages: Temporal tagging of

Arabic, Italian, Spanish, and Vietnamese. ACM

Transactions on Asian Language Information

Processing, 13(1), 1-21.

WEBIST 2018 - 14th International Conference on Web Information Systems and Technologies

206
