A Hybrid Approach to Question-answering for a Banking Chatbot on

Turkish: Extending Keywords with Embedding Vectors

Enes Burak D

undar, Tolga C¸ ekic¸, Onur Deniz and Sec¸il Arslan

R&D and Special Projects Department, Yapi Kredi Technology, Istanbul, Turkey

Keywords:

Question-answering, Chat Bot, Word Embeddings.

Abstract:

In this paper, we have proposed a hybrid keyword-word embedding based question answering method for a

Turkish chatbot in banking domain. This hyrid model is supported with the keywords that we have determi-

ned by clustering customer messages of Facebook Messenger bot of the bank. Word embedding models are

utilized in order to represent words in a better way such that similarity between words can be meaningful.

Keyword based similarity calculation between two questions enhanced our chatbot system. In order to eva-

luate performance of the proposed system, we have created a test data which contains questions with their

corresponding answers. Questions in the test are paraphrased versions of ones in our dataset.

1 INTRODUCTION

Automated Q&A or troubleshooting systems have

been gaining increasing popularity in recent years.

These systems can be used as personal assistants or

domain based Q&A systems. This work proposes a

keyword-based Q&A system to complement our pre-

vious work in creating a banking domain chatbot for

Turkish language (So

gancıo

glu et al., 2017). Gene-

ral architecture of our chatbot is given in Figure 1.

Each day, thousands of customers contact the bank to

convey their demands, complaints or ask general que-

stions about products or services. Customers utilize

different channels such as customer support phone or

chat, social media, etc. and a high amount of hu-

man resource is required to answer all these questi-

ons. Thus, developing a Q&A system that can reply a

wide range of customer queries is vital for a bank to

have an efﬁcient customer support.

In order to create a banking Q&A system that can

help customers with their most common problems or

requests reliably, ﬁrstly most frequently asked questi-

ons are identiﬁed using two unlabeled datasets. Then

after answers for these most common questions are

determined by experts, a dataset consisting of ques-

tion and answer pairs is created. Then a retrieval ba-

sed question answer system is designed. The system

works by matching user queries with questions in the

dataset. The answer of the most similar question is

returned.

Initial experiments with sentence similarity mea-

sures such as Word Mover’s Distance (WMD), and

Q-gram similarity fell short of desired success rates.

In order to address this issue, question-answer pairs

are reviewed and it is seen that some words appear

frequently. Thus, a keyword based similarity scheme

is designed. Keywords are extracted from dataset via

clustering. However, since Turkish is an agglutinative

language every word can have arbitrary amount of va-

rious sufﬁxes that can inﬂuence the meaning of the

words. In order to handle various inﬂections of our

keywords with different sufﬁxes, word embeddings

are used to discern keywords with sufﬁxes.

Experiments have been performed on an annota-

ted dataset of 138 questions. These questions are

paraphrases and alternative forms of question ans-

wer pairs dataset and they have speciﬁc answers from

the dataset. Our ﬁrst set of experiments focused on

accurately ﬁnding correct answers for questions. Se-

condly, experiments were made to gauge the success

of system’s understanding of not being able to ﬁnd

the correct answer since in a Q&A system it would

be preferable to ask for a clariﬁcation rather than re-

turning an unrelated answer. In this second set of ex-

periments answers that admit not understanding the

question are counted as positives while answers unre-

lated to question are counted as negatives. In expe-

riments, our keyword based method have performed

better than other sentence similarity methods.

Our contribution in this paper is the keyword ba-

sed question answer system that can deal with sufﬁxes

intrinsically in mophologically rich languages such as

Dündar, E., Çekiç, T., Deniz, O. and Arslan, S.

A Hybrid Approach to Question-answering for a Banking Chatbot on Turkish: Extending Keywords with Embedding Vectors.

DOI: 10.5220/0006925701710177

In Proceedings of the 10th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2018) - Volume 1: KDIR, pages 171-177

ISBN: 978-989-758-330-8

171

User

Database

Vocabulary

Banking Web Services

Q&A

Module

IntentDetection

Module Dialog Manager

Credit card

application

Money transfer

Figure 1: Chatbot Architecture.

Turkish. The rest of the paper is organized as follows.

In Section 2, related works have been introduced. In

Section 3, we have proposed our question-answering

system on the banking domain. In Section 4, expe-

rimental results have been denoted. In Section 5, we

summarize the proposed method, and denote possible

future works.

2 RELATED WORKS

This study is performed to enhance the Q&A aspect

of chatbot in our previous work in (So

gancıo

glu et al.,

2017). This banking chatbot can perform tasks that

require back-and-forth conversations between custo-

mer and the agent, such as taking a credit card appli-

cation or money transfer while understanding the in-

tent with the methodology explained in (So

gancıo

glu

et al., 2016) and shown in 1. Chatbot also targets

to offer Q&A troubleshooting for customer questions

that doesn’t require in depth conversations, which is

treated as a retrieval task in this study. For Q&A sys-

tems, the state of the art model developed for SQuAD

dataset is (Yu et al., 2018). The SQuAD is the Stan-

ford question answering dataset which is a benchmark

in which a lot of studies are ranked.

Turkish Q&A Systems. There have been previous

work in Turkish Q&A systems. In one study, a que-

stion answer system is designed to be used in online

courses for students to easily get their queries answe-

red from course material (Yurekli et al., ). This system

works like a search engine treating course material

as pages and returns the most relevant section to the

user. Another Turkish question answer system propo-

sed uses name entity recognition and pattern matching

to choose an appropriate reply (C¸ elebi et al., 2011).

Patterns are used to categorize questions into one of

nine question types and then with the help of name

entity recognition the most likely answer is retrieved.

Word Embeddings. Word embeddings are represen-

tations of words in a high dimensional space. While

one of the most popular models is word2vec (Miko-

lov et al., 2013) which showed that words can be re-

presented in high dimension by keeping semantic and

syntactic relationships, (Rumelhart et al., 1986) and

(Bengio et al., 2003) are considered as earlier studies.

In Section 3.3, a detailed information of word embed-

dings is given.

Sentence Similarity Measures. Q-gram similarity is

the ﬁrst text similarity measure reviewed for this work

(Ukkonen, 1992). Q-gram is a similarity metric based

on character-level string operations. At ﬁrst, n − 1

special characters are inserted at the beginning and

end of two words which we want to evaluate their si-

milarity. Then, they are divided into substrings with

length n. Then, the similarity between two strings is

denoted in Equation 1 in which A and B are set of

substrings. Experiments in a previous work also sho-

wed that this measure is good for morphologically

rich languages such as Turkish and noisy texts be-

cause of its character-level operations (So

gancıo

glu

et al., 2017).

Q − gram − similarity =

2 ∗ |A∩B|

|A∪B|

(1)

Another text similarity measure this work is based

on is Word Mover’s Distance (WMD) (Kusner et al.,

2015). WMD makes use of word embeddings. In or-

der to calculate a distance between two texts, each

KDIR 2018 - 10th International Conference on Knowledge Discovery and Information Retrieval

172

word is compared with each word from the other text.

Then the distance between most similar ones are ad-

ded to get the total distance.

3 METHODOLOGY

3.1 Datasets

Two datasets obtained from two channels has been

used in this study. First is from Webchat, which is

a system our company offers customers to solve their

problems via contacting a human agent. Hence, We-

bchat dataset is the collection of dialogues with mes-

sages written between customers and human agents.

The webchat dataset includes dialogues from 2014 to

2016. This dataset contains more than a million dia-

logues and total number of sentences in all dialogues

is over 13 million.

The second dataset is obtained from Facebook

Messenger. This dataset is similar to Webchat, but

here customers interact with a primitive troubleshoot-

ing chatbot that can reply to basic customer que-

ries. This basic chatbot is previously developed as

a quickwin solution - a decision tree based on ke-

ywords. Facebook messenger dataset only contains

messages written by customers. Moreover, it is obser-

ved that average length of messages is shorter com-

pared to messages in Webchat dataset. One possi-

ble reason might be due to the fact that customers,

being aware that responses are given by an automa-

tized system instead of a real human, shorten their

queries. Therefore, messages in Facebook messenger

dataset represent the summary of problem that custo-

mers want to ask.

Both datasets includes free written text messa-

ges from users and they contain high amount of ty-

pos, misspellings and grammatically wrong senten-

ces. Therefore, since datasets consist of noisy texts,

preprocessing and using word vectors for calculating

similarity between words is very important.

3.2 Preprocessing

Messages in both datasets introduced in Section 3.1,

contain Turkish and English letters. Therefore, Tur-

kish letters are converted to their closest English

counterparts for consistency since most of the letters

belong to English.

g, c¸, s¸,

o, and ı are converted

to g, c, s, u, o, and i respectively. What is more,

spell checker is also utilized to ﬁnd correct forms of

words. For this approach, Zemberek (Akın and Akın,

2007), a natural language processing tool for Turkish

language, has been utilized.

Before calculating similarity between two ques-

tions, they are preprocessed in following ways. At

ﬁrst, all punctuation marks are removed. Then, each

letter is converted to lowercase. Finally, Turkish cha-

racters are converted to corresponding English words.

Latter process is mainly done to ensure consistency

because inspection of datasets show people can write

with either a Turkish keyboard or an English keyboard

and often Turkish characters are replaced with their

English counterparts.

3.3 Word Embeddings

In order to calculate semantic similarities among

words word embeddings are used. Word embeddings

are dense vector representations of words. Word em-

beddings are used to get semantic similarities between

synonymous words or same words with different suf-

ﬁxes. While a bag-of-words approach would treat

inﬂectional forms and synonyms of words as enti-

rely irrelevant, a well trained word embedding should

capture similarity between such words. Furthermore,

word embeddings can calculate vectors for frequent

misspelling of words that are very similar to vector for

original words. Such the closest vector for the word

’kredi’ (credit in English) is ’kreid’ which is a com-

mon typo of that word in datasets. We used two algo-

rithms to train word vectors mainly due to their pro-

ven success in capturing semantic relations between

words: Word2Vec and Fasttext.

Word embeddings with both methods have been

trained on webchat dataset with all messages conca-

tenated as a whole document. Since webchat dataset

is domain speciﬁc, training word vectors on it provi-

ded meaningful semantic representations of banking

related terms. Dimensions of the trained vectors are

set as 300 since it is shown that 300 dimensional word

vectors performs better in (Sen and Erdogan, 2014).

3.3.1 Word2vec

Word2Vec is a method for training word em-

beddings using neural networks (Mikolov et al.,

2013). Word2Vec actually has two different ways

to train embeddings: skip-gram and continous-bag-

of-words(CBOW). Both versions of the method has

a sliding window through words. In CBOW model,

the words are projected by their previous and future

words along the window size. This model is called

bag-of-words because order of the words inside the

window are not taken into consideration and the con-

text is trained by neighboring information. Skip-gram

model works similar to CBOW model with a few key

differences. In skip-gram model words are used to

project their neighboring words within the window

A Hybrid Approach to Question-answering for a Banking Chatbot on Turkish: Extending Keywords with Embedding Vectors

173

Figure 2: Procedure to calculate similarity between Q

and Q

instead of the other way around. And not all words

within window are used but they are chosen randomly

and they are weighted according to their proximity to

the current word within the window.

Reviewing Word2Vec vectors trained with we-

bchat dataset we have found some semantic relations

between words, such as:

vec(yillik)+vec(ucret) = vec(aidat)

yillik means annual, ucret means fee in Turkish and

aidat is another word in Turkish meaning periodic fee.

3.3.2 FastText

FastText method is a derivation of Word2Vec method

but instead of focusing words as a whole it takes into

account character n-grams within words (Bojanowski

et al., 2016). Vectors are calculated for each character

n-gram that appear in corpus and words are represen-

ted as the sum of vectors of character n-grams within

the word. Authors argue that focusing on character

n-grams instead of words yield better results for mor-

phologically rich languages such as Turkish. Because

some rare inﬂections of words may not appear in trai-

ning corpus. However, since character n-grams are

used to calculate a word vector, embeddings for those

words can be used when they appear in other docu-

ments.

3.4 Extracting Keywords

Keywords play an important role for our question ans-

wering system since similarity between sentences is

calculated by sole keywords. In order to extract ke-

ywords, we have clustered messages from Facebook

messenger and Webchat datasets by using k-means

algorithm with k=100. Before clustering process,

messages are represented with 300 dimensional vec-

tors, then dimensionality reduction(Maaten and Hin-

ton, 2008) is applied into them. Each message is to-

kenized, then word vectors of tokens are averaged in

order to obtain a representation of the message. In

Equation 2, vector representation of j-th document is

denoted in which n is the number of words in the do-

cument, w is a list of words.

Clustering results obtained from Facebook mes-

senger have shown better performance since average

length of messages in the dataset is less than the mes-

sages in Webchat dataset. Length of messages plays

an important role in our clustering process, since

clustered instances are vectors representing messa-

ges. Thefore, keywords in a message are not domi-

nant for representing a vector of the message when the

message becomes longer.We have selected 30 clusters

with messages that are close to each cluster centroid.

We have chosen topics of these 30 clusters as the

scope of Q&A system. Then, for each of these impor-

tant tokens are extracted according to their proximity

to cluster centroid to be used as keywords. Moreo-

ver, keyword set is augmented by adding words with

similar word vectors to these keywords. This process

plays an important role since Turkish is a morpholo-

gically rich language. So, it becomes possible to co-

ver same word with different sufﬁxes without parsing

words morphologically.

Doc

∑

i=1

(2)

In Table 1, some sample questions from different

topics that are found by clustering are shown with

their English translations.

3.5 Question Answering

Given that Q

and Q

are two questions such that we

want to calculate how much Q

is similar to Q

. Thus,

we have developed a keyword based similarity metric

that is a combination of cosine and q-gram simila-

rity metrics. There are other studies that our appro-

ach shares some similarities, namely using keywords

in an information retrieval based question answer sy-

stem (Tirpude and Alvi, 2015; Kamdi and Agrawal,

KDIR 2018 - 10th International Conference on Knowledge Discovery and Information Retrieval

174

2015). Our method mainly differs from these appro-

aches by using word embeddings to extend keywords

to include inlections and synonyms of keywords.

In Figure 2, the procedure utilized in our question

answering system has been shown where Q

and Q

are two questions which are tokenized. Also, tokens

which are keyword and non-keyword have been deno-

ted. Similarity between two keywords are calculated.

Each keyword in Q

is matched with only one in Q

such that both have the best similarity. The similarity

between two keywords are calculated by multiplying

their cosine and q-gram similarity values. Calculation

of the cosine similarity is denoted in Equation 3 in

which A and B are two n-dimensional vectors. Word

embeddings trained with FastText and Word2Vec are

used represantations of word for cosine similarity cal-

culations.

Cosine − similarity =

A · B

||A|| ||B||

(3)

In order to ﬁnd the similarity between Q

and Q

, si-

milarity values calculated for each token in Q

is ad-

ded up. Then, total similarity is multiplied by q-gram

value of two questions.

function GetSimilarity(Tokens1, Tokens2)

totalSimilarity = 0

for( token1 in Tokens1)

maxi = 0

for( token2 in Tokens2)

if(token1 in Model and token2 in Model)

similarity = Cosine(token1,token2)

similarity *= Qgram(token1,token2)

if(maxi < similarity)

maxi = similarity

totalSimilarity += maxi

return totalSimilarity

Question-answering in a banking domain is a dif-

ferent task when it is compared to a general domain.

Banking domain has its own vocabulary. Therefore,

a keyword based similarity metric shows a promising

result.

4 EXPERIMENTAL RESULTS

In this section, we explain the experiments performed

to show success of our keyword-based similarity me-

asure. In order to perform tests, a set of 138 questions

created that are various rephrases of questions from

Q&A pair set. Experiments have been performed in

two ways. Firstly, accuracy of ﬁnding different ans-

wers have been evaluated. In second part of expe-

riments, accuracy for reliable answers is calculated.

A reliable answer is the Q&A system admitting not

being able to reply to the query instead of returning

an unrelated answer.

The similarity metrics that are being compa-

red are: Q-gram similarity, Word Mover’s Distance

(WMD), QA-wo-keyword is the proposed method

without utilizing keywords, QA is the proposed met-

hod with keywords used for both user queries data-

set questions, QA-q-keyword is a variant of QA algo-

rithm where it utilizes the keyword set for questions

obtained from Q&A pairs dataset. Also Word2Vec

and FastText word embeddings are evaluated for

each method separately except for Q-gram similarity

which doesn’t utilize word embeddings.

In the table, the best performing approach is QA-

q-keyword which is based on word2vec model. It is a

variant of the QA algorithm mentioned in Section 3.5.

It only considers keywords in questions since a que-

stion asked by a customer may contain some words

which are not in the keyword set. Yet, these words

can show similarity with keywords. Because of the

reason of that non-keywords are not ignored, more

questions can be covered. On the other hand, Word

Mover’s Distance method degrades the performance.

When word embedding models are compared with

each other, methods using FastText demonstrate slig-

htly better performances except the QA-q-keyword

method. Furthermore, we have also tested our ap-

proach for reliable answers since we do not want our

system to return wrong answers. Thus, if it does not

ﬁnd a similar question, then it could not answer. In

Table 3, responses which QA algorithm does not fail

are considered as correct.

5 CONCLUSIONS

In this study, we have proposed a new way to com-

pute similarity between two sentences by considering

a set of keywords. This method has been mainly de-

signed to be used in a retrieval based Turkish Q&A

system. By utilizing keywords, the important words

of queries and dataset are matched and performance

has been increased signiﬁcantly compared to methods

that doesn’t utilize keywords as our experiments have

shown. In order to deal with challenges of a morpho-

logically rich language such as Turkish word embed-

dings are used to expand keywords to include various

inﬂections of words and calculate semantic similarity

between words.

Experiments show that our hybrid keyword-

based performed better than other similarity metrics.

Mainly because this approach extends keywords by

using word embeddings so different word inﬂections

and misspelled words can be calculated as similar to

keywords. Also, Q-gram similarity, a character based

similarity is used to also increase scores even when

A Hybrid Approach to Question-answering for a Banking Chatbot on Turkish: Extending Keywords with Embedding Vectors

175

Table 1: Sample questions of selected topics.

Topic Questions

IBAN

TR: IBAN numaram nedir?

EN: What is my IBAN number?

TR: IBAN numaramı

grenmek istiyorum.

EN: I want to learn my IBAN number.

Account

Balance

TR: Hesabımda kac¸ tl var?

EN: How much TL are there in my account?

TR: Bakiyemi s

oyler misiniz?

EN: Would you tell my balance?

Mobile

App

Problems

TR: Mobil uygulamaya giris¸ yapamıyorum.

EN: I cannot login to mobile application.

TR: Mobil cihazımdan bankacılık is¸lemlerini yapamıyorum.

EN: I cannot perform banking operations via my mobile device.

Table 2: Accuracy results for correct replies.

Method Word Embedding Accuracy(%)

Q-gram N/A 72.46

WMD word2vec 44.20

QA-wo-keyword word2vec 69.56

QA word2vec 86.23

QA-q-keyword word2vec 90.57

WMD fastText 62.31

QA-wo-keyword fastText 69.56

QA fastText 86.95

QA-q-keyword fastText 89.13

Table 3: Accuracy results for reliable replies.

Method Word Embedding Accuracy(%)

Q-gram N/A 81.88

WMD word2vec 87.68

QA-wo-keyword word2vec 69.56

QA word2vec 92.75

QA-q-keyword word2vec 92.75

WMD fastText 84.78

QA-wo-keyword fastText 69.56

QA fastText 92.75

QA-q-keyword fastText 89.85

words are not exact matches.

For a future work, the process of extracting ke-

ywords from a set of messages can be automatized

such that it becomes possible to import a new type

of questions which contain a new possible list of ke-

ywords. Furthermore, we have manually determined

the top 30 categories in question-answering system.

This can also be automatized for adding new catego-

ries without human interaction.

ACKNOWLEDGEMENTS

The authors would like to thank Nihan Karslıo

glu for

her invaluable contributions to the system and Ers¸ah

git Karademir for annotations. This work is sup-

ported by TUBITAK 3160116.

REFERENCES

Akın, A. A. and Akın, M. D. (2007). Zemberek, an open

source nlp framework for turkic languages. Structure,

10:1–5.

Bengio, Y., Ducharme, R., Vincent, P., and Jauvin, C.

(2003). A neural probabilistic language model. Jour-

nal of machine learning research, 3(Feb):1137–1155.

Bojanowski, P., Grave, E., Joulin, A., and Mikolov, T.

(2016). Enriching word vectors with subword infor-

mation. arXiv preprint arXiv:1607.04606.

C¸ elebi, E., G

unel, B., and S¸en, B. (2011). Automatic que-

stion answering for turkish with pattern parsing. In

Innovations in Intelligent Systems and Applications

(INISTA), 2011 International Symposium on, pages

389–393. IEEE.

Kamdi, R. P. and Agrawal, A. J. (2015). Keywords based

closed domain question answering system for indian

penal code sections and indian amendment laws. In-

ternational Journal of Intelligent Systems and Appli-

cations, 7(12):54.

Kusner, M., Sun, Y., Kolkin, N., and Weinberger, K. (2015).

From word embeddings to document distances. In In-

ternational Conference on Machine Learning, pages

957–966.

Maaten, L. v. d. and Hinton, G. (2008). Visualizing data

using t-sne. Journal of machine learning research,

9(Nov):2579–2605.

Mikolov, T., Chen, K., Corrado, G., and Dean, J. (2013).

Efﬁcient estimation of word representations in vector

space. arXiv preprint arXiv:1301.3781.

Rumelhart, D. E., Hinton, G. E., and Williams, R. J. (1986).

Learning representations by back-propagating errors.

nature, 323(6088):533.

Sen, M. U. and Erdogan, H. (2014). T

urkc¸e ic¸in kelime

temsillerinin

ogrenimi learning word representations

for turkish.

KDIR 2018 - 10th International Conference on Knowledge Discovery and Information Retrieval

176

gancıo

glu, G., C¸ ekic¸, T., K

oro

glu, B., Basmacı, M., and

gın, O. (2017). Dialog management for credit card

selling via ﬁnite state machine using sentiment classi-

ﬁcation in turkish language.

gancıo

glu, G., K

oro

glu, B., and A

gın, O. (2016). Multi-

label topic classiﬁcation of turkish sentences using

cascaded approach for dialog management system.

Tirpude, S. C. and Alvi, A. (2015). Closed domain

keyword-based question answering system for legal

documents of ipc sections and indian laws. Internati-

onal Journal of Innovative Research in Computer and

Communication Engineering, 3(6):5299–5311.

Ukkonen, E. (1992). Approximate string-matching with q-

grams and maximal matches. Theoretical computer

science, 92(1):191–211.

Yu, A. W., Dohan, D., Luong, M.-T., Zhao, R., Chen,

K., Norouzi, M., and Le, Q. V. (2018). Qa-

net: Combining local convolution with global self-

attention for reading comprehension. arXiv preprint

arXiv:1804.09541.

Yurekli, B., Arslan, A., Senel, H. G., and Yilmazel, O. Tur-

kish question answering.

A Hybrid Approach to Question-answering for a Banking Chatbot on Turkish: Extending Keywords with Embedding Vectors

177
