Harvesting Organization Linked Data from the Web

Zhongguang Zheng, Yingju Xia, Lu Fang, Yao Meng and Jun Sun

Fujitsu R&D Center CO., LTD., Beijing, China

Keywords:

Linked Data, Web, Property Value Extraction.

Abstract:

In this paper, we describe our approach of automatically extracting property-value pairs from the Web for

organizations when only the name and address information are known. In order to explore the enormous

knowledge from the Web, we ﬁrst retrieve the Web pages containing organization properties by search engine,

and then automatically extract the property-value pairs regardless of heterogeneous Web page structures. Our

method does not require any training data or human-made template. We have constructed an organization

knowledge base containing 3 million entities extracted from the Web for 4.2 million organizations which only

have name and address information. The experiment shows that our approach makes it possible and effective

for people to construct their own knowledge base.

1 INTRODUCTION

Nowadays knowledge base (KB) plays an important

role in many applications such as question answering,

semantic disambiguation and information retrieval.

There are some well-known KBs such as DBpedia

and Yago which contain millions of entities describ-

ing different concepts, such as persons, places, orga-

nizations, etc. However, the quantity is still insufﬁ-

cient under certain contexts.

For instance, we have a task to build a KB for

all the Japanese organizations. According to the data

set published by the government

, there are about 4.2

million organizations registered in Japan. The re-

leased data set mainly contains four types of informa-

tion: the organization’s names, types, addresses and

corporate numbers. Figure 1 shows an example of the

ofﬁcial data.

It is known that DBpedia contains only 0.24 mil-

lion organizations in the English version

and much

less organizations in the Japanese version. Similarly,

other KBs fail to provide enough data to cover the 4.2

million Japanese organizations. As a result, it is im-

possible for us to meet the requirements with those

existing KBs. Similar problem could be posed when

people need to construct KBs for products, persons or

other things.

Considering that a huge amount of knowledge in

not tapped on the Web, it is sensible to extract the in-

http://www.houjin-bangou.nta.go.jp/download/zenken/

http://wiki.dbpedia.org/about

Figure 1: Example of the Japanese organization entity.

formation from the Web (WebIE). A lot of research

has been done to build effective methods for WebIE

in the past years. However, most of them focused on

learning wrappers from certain Web pages (training

set), and afterwards they use the well-tuned wrapper

to analyze other Web pages that have similar struc-

tures of the training set. Such methods generate re-

liable results when the target data is covered in only

several similar websites.

In our task, however, the detail information of one

organization is likely available in its homepage. Fur-

thermore, the structures of different homepages are in

a wide variety of forms. Thus it is difﬁcult to learn

wrappers when the Web pages have little in common.

In order to solve the above problems, we propose a

novel method that features two points signiﬁcantly

different from the previous work.

• We retrieve the information of the organizations

Zheng, Z., Xia, Y., Fang, L., Meng, Y. and Sun, J.

Harvesting Organization Linked Data from the Web.

DOI: 10.5220/0006888101590166

In Proceedings of the 10th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2018) - Volume 2: KEOD, pages 159-166

ISBN: 978-989-758-330-8

159

Figure 2: Overview of our method.

through the search engine. If one organization

has its own homepage, the search engine is about

to retrieve the homepage according to the proper

queries, and otherwise, the search engine would

retrieve other websites that probably contain the

information of that organization which ensures the

coverage of our method. In the experiment, we

extracted about 3 million organization entities and

2.2 million of them are matched with the ofﬁcial

data.

• Considering that the Web pages retrieved by the

search engine are heterogeneous, it is difﬁcult to

learn wrappers to ﬁnd common Web page struc-

tures. In order to solve this problem, we propose

an algorithm to analyze the Web page dynami-

cally without any training process or human-made

templates.

The rest of this paper is organized as follows. Sec-

tion 2 introduces the related work. In Section 3, we

describe our method. Experiment is shown in Section

4, followed by a discussion in Section 5. The conclu-

sion and future work are presented in Section 6.

2 RELATED WORK

Conventionally we call the programmatical data ex-

traction from the Web page “wrapper”. There has

been studies on developing various wrappers in the

past years.

Wrapper Induction. Wrapper induction is to learn

the structure of Web pages so that the wrapper is

used to analyze other Web pages and the informa-

tion is extracted accordingly. Some early studies fo-

cused on developing wrappers based on the priori

knowledge (e.g., labeled data set, templates or heuris-

tics). Kushmerick (1997) builds wrappers from a set

of labeled example Web pages. J. Hammer & Cre-

spo (1997) develops a tool for extracting semistruc-

tured data from Web pages which needs human con-

ﬁguration. In order to reduce human work, recent

studies learn wrappers automatically from Web pages

aiming to discover common structures. V. Crescenzi

& Merialdo (2001) develops wrappers by evaluating

the similarities and differences between Web pages

without any priori knowledge. Freitag & Kushm-

erick (2000) and Carlson & Schafer (2008) adopts

boost learning method to learn wrappers. Wong &

Lam (2010) presented a Bayesian learning framework

trained from source Web pages for new unseen Web

pages. N. Dalvi & Sha (2009) and Q. Hao & Zhang

(2011) adopt other statistical models for wrapper in-

duction. Those supervised methods still depend on

manually labeled data set to train the wrappers. More-

KEOD 2018 - 10th International Conference on Knowledge Engineering and Ontology Development

160

over, the inducted wrappers fail to produce satisfac-

tory results when dealing with very different struc-

tured Web pages. This makes the effectiveness of

the wrapper limited to a fraction of websites. Anna

Lisa Gentile & Ciravegna (2013) proposes a method

for learning wrappers without any training materials.

However, their method depends on existing Linked

Data knowledge bases (e.g., DBpeida) to match the

content in the Web page, and also induces wrappers

from homogeneous Web pages. In our task, there is

no such existing knowledge base that covers enough

organization entities and our goal is to analyze any

given Web pages.

Wrapper for Unstructured Web Pages. There has

been studies focused on unstructured information ex-

traction. Szekely & Craig A. Knoblock (2015) de-

scribes a system that constructs knowledge graph

by analyzing online advertisement to ﬁght the hu-

man trafﬁcking. They ﬁrst adopt Apache Nutch for

the data acquisition, and then use their DIG sys-

tem to extract the properties. The DIG system is

a semi-structured page extractor that identiﬁes ele-

ments based on several regular expressions. The sys-

tem needs a small size labeled data set for training

the property extractor. Michele Banko (2007) intro-

duces an open information extraction method that ex-

tracts relation tuples from the Web corpus. Aliak-

sandr Talaika & Suchanek (2015) proposes an extrac-

tion method of the unique identiﬁers and names for

products from the Web pages. Their method is inde-

pendent of the Web page structure. Although those

methods are workable to handle any given Web page

and are free of training set (or need a small set) since

they are insensitive to the Web page structure, their

methods are conﬁned to either extraction scope in

the Web page or the property numbers of the target

data. Szekely & Craig A. Knoblock (2015) focuses on

the sentences containing suspicious information while

Aliaksandr Talaika & Suchanek (2015) is only inter-

ested in the identiﬁer and the product name. A lot of

information on the Web is organized in the tabular or

list layout. Their methods fail to handle such com-

plex Web structures. As a result they can not extract

multiple property-value pairs from the Web page.

In this paper, we propose a novel approach that

efﬁciently extracts property-value pairs for organiza-

tions from the Web pages. Our method differs from

the previous studies in that we automatically detect

the area that containing useful information in the Web

page without any training process. Moreover, the

goalof our method is to extract all the property-value

pairs describing the same organization entity from

one Web page. Our method is scalable for extracting

information for other kinds of entities.

Figure 3: Example of retrieved results.

3 APPROACH

3.1 Overview

Our goal is to ﬁnd the Web page which contains the

information of the given organization, and then ex-

tract all the property-values pairs from the page. In

order to ﬁnd the Web page related to the given organi-

zation, we adopt the search engine as a helper. After

retrieving the Web pages, our wrapper will automati-

cally analyze the pages and extract all the property-

value pairs by some rule-based parsers, and after-

wards we will discover new properties so as to com-

plement the extraction results. The whole process is

depicted in Figure 2.

3.2 Related Web Pages Retrieval

Since there is no available knowledge base which con-

tains enough information for our task, we turn to the

search engine to locate the Web pages containing the

organization information, e.g., the homepage. In or-

der to make the retrieval result as precise as possi-

ble, we construct each query with the organization

names, cities and other keywords such like “

(proﬁle)”. In this paper, Yahoo! Japan

is selected

as our ﬁnal search engine.

Figure 3 shows an example of the query “

InnoBeta (InnoBeta Corporation),

(proﬁle)”. The retrieval result contains about 10

records per page and the top 2 records are listed in

Figure 3. Conventionally the topmost record should

be considered as the closest result to the query. How-

ever, when examining the related Web pages, we ﬁnd

that sometimes the search engine fails to return sat-

isfactory results by using the same set of keywords

yahoo.jp

Harvesting Organization Linked Data from the Web

161

Figure 4: Example of property-value pairs.

since different Web pages may contain different key-

words.

Thus we create a keyword list by hand denoted

as l = [(k

, p

), (k

, p

), ..., (k

, p

)], where k

de-

notes a keyword, such as “ (prﬁle)”, “

(proﬁle)”, “ (name)” and “

(address)”, and p

denotes the priority of the key-

word which is assigned manually. We use an iterative

mechanism to retrieve the related Web pages depicted

as follows.

sort l by priority

i = 0

while iter < max_iter_num:

select l[i,i+n] as keywords

construct query with the keywords

call the search engine

extract information from retrieved results

if success

go to the next query

else

iter += 1

i += n

Where l denotes the keyword list. For each orga-

nization name, we deﬁne max iter num as the maxi-

mum iteration number when the search engine fails to

retrieve satisfactory pages.

3.3 Web Page Analysis

3.3.1 Anchor Nodes Detection

Figure 4 shows an example of the tabular structure

in the Web page containing property-value pairs of

the organization “ InnoBeta (InnoBeta Cor-

poration)” together with its corresponding DOM tree

structure. First, we identify all the leaf nodes which

contain property names. Thus we create a property

name dictionary manually beforehand. Note that the

expressions of the same property name are unpre-

dictable and vary a lot in different Web pages. For

instance, the property “organization name” may be in

terms of “ ”, “ ” or “ ”. Besides, it is

impossible to cover all types of properties in advance.

As a result, it is difﬁcult to create a dictionary which

covers all the expressions or properties. Therefore

we propose a mechanism introduced in Section 3.4 to

enlarge the dictionary when extracting property-value

pairs simultaneously.

For each leaf node in the DOM tree, if the text of a

node n

is matched in the dictionary, we consider n

an anchor node. Those anchor nodes roughly locate

the positions of the property-value pairs.

3.3.2 Property-value Pair Extraction

After the observation of many Web pages, we ﬁnd that

despite Web pages have heterogeneous HTML struc-

tures, the useful information is always displayed in

well-organized layouts such as table or list. As shown

in Figure 4, the property-value pairs are located in

the node “table”. Furthermore, each property-value

pair is under the node “tr”. In this paper, we call

nodessuch as “table” root nodes, and its descendant

nodes such as “tr” pattern nodes. Note that the “table

or list” layouts may be composed of any HTML ele-

ments, such as “table”, “div”, “span”, “ul”, etc. Thus

it is impossible to use templates to predict the location

of property-value pairs.

The pattern nodes have two characteristics.

Firstly, they cover anchor nodes. Secondly, they

repetitively appear under one root nodes. These two

characteristics ensure that each property-value pair is

covered in just one pattern node, e.g., each “tr” node

covers only one property-value pair in Figure 4. This

KEOD 2018 - 10th International Conference on Knowledge Engineering and Ontology Development

162

Figure 5: New property name detection.

is an import clue that helps us to conﬁne the boundary

of the property value. As the example in Figure 4,

the value of property “ (name)” can be only

extracted from node “td” which is the child node of

the ﬁrst pattern node “tr”. Hence our problem is to

ﬁnd those pattern nodes. As mentioned above, the

pattern nodes may be composed of multiple nodes

which could be any HTML element, we propose a

novel method to detect pattern nodes automatically.

Root Node Detection. In order to ﬁnd the pattern

nodes, we ﬁrst ﬁnd the root node. If the root is de-

tected, we could extract pattern nodes from its descen-

dant nodes.

Given a Web page, we ﬁrst resolve the Web page

into its DOM tree structure. Then we preserve all the

anchor nodes from the leaf nodes. For each anchor

node, we deﬁne its pattern as pat

{

tag,class

}

, where

tag is the DOM node type such as “div” or “table”,

while class is the class attribute of that node. For ex-

ample, the node “<table class=‘mt20’>...</table>”

in Figure 4 has the pattern pat

{

‘table’, ‘mt20’

}

. For

each non-leaf node, we select a root node node

root

when

• The node covers all the anchor nodes which have

the same pat.

• There is no other root nodes in its descendants.

Pattern Node Detection. For each node

root

if it has more than n children, we will ex-

tract pattern nodes from its children de-

noted as patset[subpat

1,l

, ..., subpat

n,1

], where

subpat

i,l

{

pat

, nodeset

}

presents node sets

that have the same pat

and l is the length

of pat

, while nodeset[nodes

, ..., nodes

]

(m>minmum repeat count) presents the node

sets. minmum repeat count is a constraint that depicts

the minimum occurrence of pat

. Each nodes

contains DOM tree nodes [child

, ..., child

], where

child

is a descendant node of node

root

. For one

subpat

i,l

{

pat

, nodeset

}

, if l ≥valid pattern length,

we will consider pat

i,l

as a valid pattern and then

extract property-value pairs from nodeset.

As the example in Figure 4, the node “table” is

not a root node since it has only one child “tbody”.

The node “tbody” is a root node since we can extract

patset from its eight children nodes “tr”, that is

patset[subpat

{

tr, nodeset[0, 1, ..., 7]

}

], and then we

can extract property-value pairs from each “tr” node.

Rule based Value Parser. Parsing values from the

free text is task speciﬁc. In our task, we developed

several rule-based parsers (shown in Figure 2) for dif-

ferent types of organization properties such as date,

number, address and organization name, etc. Note

that the previous procedure depicted in this section

is independent of subjects or languages (except the

handcrafted dictionary).

There is a problem that the extracted property-

value pairs may describe multiple organizations. In

this paper, we simply split the property-value pairs

into different groups ensuring that each group has

only one property representing the organization’s

name.

Entity Linkage. After extracting the property-value

pairs, we will link the pairs with the ofﬁcial data set.

Since the organization name and address are already

known (see Figure 3), we can link extracted property-

value pairs with an organization entity by matching

their name and address properties. Those property-

value pairs failed to match the source organizations

will be grouped by matching their name and address

properties with each other, and the grouped pairs will

form new organization entities.

3.4 New Property Name Detection

As mentioned in Section 3.3.1, the handcraft dictio-

nary fails to cover all the properties on the Web. Some

unknown properties may occur when handling differ-

ent Web pages. Moreover, even a known property

may have various expressions in different Web pages,

for example, property “ (organization name)”

has other synonymous expressions like “ ”,“

”, “ ”, etc. It is an important work to discover

more properties and expressions to enlarge the dictio-

nary.

Initially we craft the dictionary with some basic

properties, such as “ (organization name)”, “

(address)”, “ (manager)”, etc. Then dur-

ing the step described in Section 3.3.2, for nodes

[child

, ..., child

], if child

is in the property dic-

tionary, we will record its pattern pat

. If there is

Harvesting Organization Linked Data from the Web

163

Table 1: Overall experimental result.

Source entity Extracted entity Linked entity

4.27M 2.99M 2.33M (77.9%)

a node child

in nodes

[child

, ..., child

] (nodes

∈

nodeset

, nodes

∈ nodeset

) has the same pattern

with pat

but text(child

) is not in the dictionary,

we will count the occurrence of text(child

). A new

property will be discovered if its occurrence reaches

a threshold.

This process is shown in Figure 5, where the cir-

cle nodes are the known properties. We consider the

rectangle node as the new property when it co-occurs

with the known properties and they have the same pat-

tern. We have discovered more than 240 new property

entries comparing with the initial dictionary that only

contains about 120 property entries. Finally we can

construct our organization knowledge base with those

extracted property-value pairs.

Table 2: Information of our organization KB.

Entity Triple Property

2.99M 31.22M 42

Table 3: Result of listed organizations.

Source entity Extracted entity Linked entity

2642 2431 2431 (92%)

4 EXPERIMENT

In this paper, our task is to construct a knowledge

base for the Japanese organizations. The source data

released by the government contains about 4.2 mil-

lion organizations (see Figure 1). We ﬁrst develop a

crawler to collect the related Web pages as described

in Section 3.2, and then extract property-value pairs

for the knowledge base construction by our proposed

method.

Table 1 displays the overall result. We extract

2.99 million entities from all the Web pages, and 2.33

million (78%) of them are successfully linked to the

source entities. Table 2 depicts the main information

of our knowledge base which contains 31.22 million

triples and 42 kinds of properties. The discussion of

our result is shown in Section 5.

In order to further prove the effectiveness of our

approach, we select a subset containing 2.6 thousand

organizations listed in the Japanese stock market from

the ofﬁcial data set. Considering that it is much easier

to obtain the Web pages for the listed organizations,

the inﬂuence of the search engine will be lowered.

Figure 6: Information from the third-party website.

This makes it a better test set for our wrapper. Table

3 demonstrates the result on the listed organizations.

We can see that 92% of the source entities are cov-

ered by our extracted entities. This convincing result

reveals the effectiveness of our method.

We list a portion of properties with coverage

greater than 5% and their corresponding entries in Ta-

ble 4. “Coverage” presents the percentage of the ex-

tracted entities with the property. The discussion of

this result is shown in the following section. More-

over, we randomly selected about 100 entities from

the listed organizations as a sample which is available

here

. People could trace the hyperlink of property

“dct:source” to the original Web page

5 DISCUSSION

Long Tail Data. In our experiment, there are still a

large portion of source entities left without any ex-

tracted information. After studying some bad cases,

we ﬁnd that the search engine is set to retrieve un-

related Web pages for some unknown organizations.

For example, the retrieval results of the organization

“ ” are all irrelevant Web pages.

It is even difﬁcult for human to ﬁnd the related Web

pages through search engine for those long tail data.

This is contradictory against our initial thoughts that

there would be enough data on the Web. It seems that

many organizations do not have homepage or do not

put their information available on the Web.

Property Coverage. As shown in Table 4, addresses,

postal codes and telephone umbers are the most

common properties. The coverage of other properties

http://36.110.45.44:8081/sample.html

Since the most Web pages were crawled in 2016 and

2017, the access to the original Web page may fail due to

the possible change of the website.

KEOD 2018 - 10th International Conference on Knowledge Engineering and Ontology Development

164

Table 4: Properties with coverage greater than 5%.

Property Dictionary entry Coverage Property Dictionary entry Coverage

Name 100%

Foundation

date

17.9%

Address 95.1% Scale 11.5%

Postcode

Telephone 83% Classiﬁcation 8.9%

Key

person

CEO

27.5% Homepage

homepage url

Corporation

number

25.2%

bank

6.6%

Fax fax FAX 21.7%

Business

hour

Industry 18.8% Email

e-mail email

5.7%

drops drastically. That is because many entities are

extracted from the third-party websites rather than the

organization homepages, and the third-party websites

are set to provide less information. Figure 6 shows

an example from the third-party website. Ideally, the

homepage would provide diverse information, how-

ever, as discussed above, many long tail organizations

do not have homepages. As a result, the third-party

websites become the only information resources.

Data Cleansing and Formalizing. It is known that

the data on the Web is mostly noisy and informal. It

will take a lot of effort to improve the data quality.

Meanwhile, some sophisticated technologies should

be involved, e.g., named entity recognition (NER).

Though we have developed several basic parsers

for formalizing certain properties, more parsers are

needed to improve the data quality, such as person

name or other newly detected properties.

Evaluation. Currently we are still improving our

method according to the feedbacks of human check.

In our experiment, the linkage rate between the ex-

tracted results and the ofﬁcial data set can be seen as

the recall value. However, in order to thoroughly eval-

uate the precision of our method, a test set is needed,

although it is not easy to set up.

6 CONCLUSION AND FUTURE

WORK

In this paper, we introduced our approach to extract

entity property-value pairs through the Web. We

ﬁrst utilize search engine to retrieve the related Web

pages, and then we automatically analyze the Web

page structure and extract property-value pairs. Fur-

thermore, we studied the technology to discover un-

known properties.

Our proposed approach makes it possible for peo-

ple to build their own knowledge base from a fraction

of data. In the future, we will improve our approach to

make it robust for more complicated structured Web

pages. Moreover, evaluation by precision is another

important subject to explore in the future.

Harvesting Organization Linked Data from the Web

165

REFERENCES

Aliaksandr Talaika, Joanna Biega, A. A. & Suchanek, F. M.

(2015), Ibex: Harvesting entities from the web using

unique identiﬁers, in ‘Proceedings of the 18th Interna-

tional Workshop on Web and Databases’, pp. 13–19.

Anna Lisa Gentile, Ziqi Zhang, I. A. & Ciravegna, F.

(2013), Unsupervised wrapper induction using linked

data, in ‘Proceedings of the seventh international con-

ference on Knowledge capture’, pp. 41–48.

Carlson, A. & Schafer, C. (2008), Bootstrapping infor-

mation extraction from semi-structured web pages,

in ‘European Conference on Machine Learning and

Principles and Practice of Knowledge Discovery in

Databases’.

Freitag, D. & Kushmerick, N. (2000), Boosted wrapper in-

duction, in ‘NCAI’.

J. Hammer, H. Garcia-Molina, J. C. R. A. & Crespo, A.

(1997), Extracting semistructured information from

the web, in ‘Proceedings of the Workshop on the Man-

agement of Semistructured Data’.

Kushmerick, N. (1997), Wrapper induction for information

extraction, in ‘IJCAI97’, pp. 729–735.

Michele Banko, Michael J Cafarella, e. a. (2007), Open in-

formation extraction from the web, in ‘Proceedings of

the 20th international joint conference on Artiﬁcal in-

telligence’, pp. 2670–2676.

N. Dalvi, P. B. & Sha, F. (2009), Robust web extraction: an

approach based on a probabilistic tree-edit model, in

‘Proceedings of the 35th SIGMOD international con-

ference on Management of data’.

Q. Hao, R. Cai, Y. P. & Zhang, L. (2011), A uniﬁed so-

lution for structured web data extraction, in ‘SIGIR’,

pp. 775–784.

Szekely, P. & Craig A. Knoblock, e. a. (2015), Building and

using a knowledge graph to combat human trafﬁck-

ing, in ‘Proceedings of the 14th International Seman-

tic Web Conference’, Vol. 9367, pp. 205–221.

V. Crescenzi, G. M. & Merialdo, P. (2001), Roadrunner: To-

wards automatic data extraction from large web sites,

in ‘VLDB’.

Wong, T. & Lam, W. (2010), Learning to adapt web in-

formation extraction knowledge and discovering new

attributes via a bayesian approach, in ‘Knowledge and

Data Engineering’, Vol. 22, pp. 523–536.

KEOD 2018 - 10th International Conference on Knowledge Engineering and Ontology Development

166
