DRANKULA: A McEliece-like Rank Metric based Cryptosystem

Implementation

Ameera Salem Al Abdouli, Mohamed Al Ali, Emanuele Bellini, Florian Caullery,

Alexandros Hasikos, Marc Manzano and Victor Mateu

DarkMatter, U.A.E.

Keywords:

Code-based Cryptography, Public Key Cryptography, Cryptosystem, Software Implementation, Post-quantum

Cryptography.

Abstract:

We present and analyze the performance of DRANKULA, a McEliece-like cryptosystem implementation us-

ing rank metric instead of Hamming distance. Namely, we use the scheme proposed by Loidreau in PQCrypto

2017 using Gabidulin codes. We propose a set of carefully selected parameters and we address several non-

trivial issues when porting this scheme into real-world systems as, for example, the generation of errors of a

given rank. We provide the pseudo-code of the core algorithms of the cryptosystem. In addition, we also show

code optimization when special instructions like Carry-less multiplications are available. Moreover, we argue

how to have a practical and side-channel resistant version of the cryptosystem. We integrated the scheme in

Open Quantum Safe and benchmarked it against the other schemes implemented there. Our results show that

DRANKULA can be a practical alternative to other well-known quantum-safe schemes.

1 INTRODUCTION

Substantial advances in quantum computing in the

past decade have re-assured the scientiﬁc community

about the necessity to build quantum-resistant cryp-

tosystems (Devoret and Schoelkopf, 2013). Recently,

Google announced Bristlecone, a new 72 qubits quan-

tum processor (Google, 2018). Post-Quantum Cryp-

tography (PQC) has raised as the preferred solution

to face the threat that quantum computers pose to

traditional public-key cryptography based on number

theory (Shor, 1997). The recent announcement by

the National Institute of Standards and Technology

(NIST) to deﬁne new standards for public-key encryp-

tion, digital signatures and key-exchange schemes has

only augmented the attention towards PQC (Chen

et al., 2016).

There exist several alternative problems to classi-

cal public-key cryptography, which is based on inte-

ger factorization or discrete logarithms. Lattice-based

cryptography, multivariate cryptography, hash-based

cryptography schemes, isogeny-based cryptography

and code-based cryptography can be used to design

cryptosystems secure against both classical and quan-

tum computers (Bernstein et al., 2008), and are thus

regarded as PQC algorithms, being candidates for be-

coming the next standards deﬁned by NIST.

Code-based cryptography is the oldest PQC fam-

ily known and consequently is the most thoroughly

studied among the PQC candidates (Sendrier, 2017).

McEliece proposed the ﬁrst code-based public-key

cryptosystem (McEliece, 1978), which is based on bi-

nary Goppa codes, and so far has withstood all crypt-

analytic efforts. Another well known cryptosystem

was proposed by Niederreiter in (Niederreiter, 1986).

Recently, Bernstein, Chou and Schwabe presented

McBits, which improved decryption time with respect

to Niederreiter (Bernstein et al., 2015). An improved

version was presented in (Chou, 2017). However, the

usage of the aforementioned schemes in real world

applications has been prohibitive because of the sig-

niﬁcantly large key sizes (e.g., McBits requires 64KB

to achieve 2

classical security level). Therefore, the

most important challenge that code-based cryptogra-

phy faces is how to reduce key sizes in order to be

implemented on limited resource devices.

Two different lines have been investigated with the

purpose of reducing key sizes. On the one hand, sev-

eral works have tried to address this drawback by de-

signing McEliece variants with more compact keys

by using quasicyclic codes (Gaborit, 2005; Misoczki

et al., 2013; Chou, 2016). On the other hand, the us-

age of rank metric rather than Hamming distance has

been considered.

The rank metric was introduced by Gabidulin in

(Gabidulin, 1985) and he proposed a family of codes,

the Gabidulin codes, equivalent to Reed-Solomon

codes in Hamming distance, which can be decoded in

Abdouli, A., Ali, M., Bellini, E., Caullery, F., Hasikos, A., Manzano, M. and Mateu, V.

DRANKULA: A McEliece-like Rank Metric based Cryptosystem Implementation.

DOI: 10.5220/0006838100640075

In Proceedings of the 15th International Joint Conference on e-Business and Telecommunications (ICETE 2018) - Volume 2: SECRYPT, pages 64-75

ISBN: 978-989-758-319-3

polynomial time. Rank Syndrome Decoding (RSD)

is the equivalent in rank metric of the Syndrome

Decoding problem in Hamming distance. Later on,

Gabidulin et al. proposed the GPT cryptosystem,

a McEliece-like cryptosystem based on Rank metric

(Gabidulin et al., 1991). One of the advantages of us-

ing Gabidulin codes is that the complexity of the best

known attacks for solving the RSD problem have an

exponential complexity which is quadratic in the pa-

rameters of the system. As a consequence, key sizes

can be notably reduced to achieve the same security

level than a Hamming distance-based cryptosystem.

Then, Overbeck proposed a framework that dev-

astated all Gabidulin codes based encryption schemes

(Overbeck, 2005; Overbeck, 2008). Furthermore,

evolutions of the GPT cryptosystem have been shown

to be also breakable in polynomial-time (Otmani

et al., 2016). Nevertheless, Loidreau has proposed

a new McEliece-like rank metric based encryption

scheme from Gabidulin codes that is not affected by

the so-called Overbeck’s attacks (Loidreau, 2017).

In this work we carry out the ﬁrst implementation

of the scheme proposed in (Loidreau, 2017), which

we have called DRANKULA. We present a set of se-

lected parameters that allow the scheme to achieve

different levels of quantum security; namely 64, 96

and 128 bit. We motivate this parameter selection

by implementation constraints and optimization pos-

sibilities. Moreover, we go through all the caveats of

the implementation of a cryptosystem based on rank

metric codes, and we provide the pseudo-code for the

main algorithms. We also discuss several counter-

measures that would make the implementation side-

channel resistant.

1.1 Organization of the Paper

The rest of the paper is structured as follows. First, in

Section 2 we outline all the code-based Key Encapsu-

lation Mechanism (KEM) and Public Key Encryption

(PKE) submissions to the NIST competition and then

in Section 3 we introduce the cryptosystem we are

implementing on this paper, and the selected parame-

ters. Section 4 is devoted to the base ﬁeld arithmetic

and matrix operations that are required to implement

for running the cryptosystem. In Section 5 we present

the necessary code-blocks used to build the cryptosys-

tem, namely, (a) the key generation, (b) the encryp-

tion which includes the error generation, and (c) the

decryption. Section 6 gives an overview of the per-

formance of the scheme compared with other post-

quantum cryptography schemes. Section 7 presents

some directions to have a side-channel resistant im-

plementation. Finally, we provide the conclusions of

our proposal in Section 8.

2 RANK-METRIC NIST

SUBMISSIONS

There were four code-based KEM and PKE schemes

based on the rank metric submitted to the ﬁrst round

of the NIST post-quantum cryptography standardiza-

tion competition (NIST, 2018). First, Ouroboros-R

(Deneuville et al., 2017), is a cryptosystem that inher-

its features from MDPC-McEliece (Misoczki et al.,

2013) and the rank metric quasi-cyclic family. The

security relies on decoding small weight vectors of

random quasi-cyclic codes. The advantages are the

security reduction with small public key sizes result-

ing from cyclicity, the easy evaluation of the low

decryption failure probabilities and the efﬁciency of

the decoding compared to MDP. Second, LAKE (Ga-

borit et al., 2013), which stands for Low rAnk parity

check codes Key Exchange, is a rank-metric scheme

for which the authors provide an efﬁcient probabilis-

tic decoding algorithm. The quasi-cyclic family of

codes that is being used produces a public key which

is signiﬁcantly smaller than MDPC codes. Similar to

LAKE, LOCKER (Aragon et al., 2017) is built on a

small variation of low rank parity check codes and

has been adapted to support low decryption proba-

bility failures with a versatile choice of parameters.

Considering the low decryption failure probabilities

the scheme is efﬁcient in terms of key sizes and com-

putational complexity. These three schemes share the

property of a probabilistic decryption algorithms. In

contrast, DRANKULA offers a deterministic decryp-

tion procedure which makes it more suitable in sce-

narios where we cannot tolerate decryption failures.

Last, RQC (Melchor et al., 2016), is another rank-

metric scheme that is also based on the difﬁculty of

decoding random quasi-cyclic codes. The key-size of

the scheme is restricted to a few thousands of bytes

and has a deterministic decoding algorithm. It is also

resistant to code hidden structure recovery attacks.

Although having a bigger key size, DRANKULA re-

duces the ciphertext expansion by a factor of 2 in

comparison to RQC.

3 CRYPTOSYSTEM

DESCRIPTION

The scheme we have chosen to implement is the one

proposed in (Loidreau, 2017). It is a scheme based

on Gabidulin codes using a special sub-space for the

entries of the scrambling matrix which transforms the

private key into the public key.

The essential difference between the presented

DRANKULA: A McEliece-like Rank Metric based Cryptosystem Implementation

cryptosystem and traditional McEliece instantiations

is that, instead of XORing the encoded plaintext with

errors of a given Hamming weight, we do it with an

error of a speciﬁc rank weight.

Deﬁnition 1. Let e = {e

,...,e

} ∈ F

. The rank

weight of e is deﬁned by

rk(







1,1

··· e

n,1

1,2

··· e

n,2

1,m

··· e

n,m







)

where e

i, j

is the jth component of e

seen as a vector

over F

Deﬁnition 2 (Gabidulin codes). Let k < n ≤ m be

non-negative integers and let {g

,...,g

} ∈ F

, be

linearly independent over F

. Let [i] = 2

such that

x → x

[i]

is the ith power of the Frobenius automor-

phism x → x

. The code Gab

k,n

(g), is the linear code

with generator matrix

G =







··· g

[1]

··· g

[1]

[k−1]

··· g

[k−1]







that is:

Gab

k,n

(g) = {xG|x ∈ F

These codes can be decoded in polynomial-time

for errors of rank weight up to b(n−k)/2c (Gabidulin,

1985).

Gabidulin Codes are the rank-metric equivalent of

Reed Solomon Codes. The scheme’s approach is to

choose a randomly selected vector space of F

ﬁxed dimension which is used to scramble the codes.

The proof of correctness of the cryptosystem is based

on the rank multiplication property, the same one used

to show that the Low Rank Parity Check (LRPC)

codes decoding procedure works.

The scheme has four parameters:

• m:= the degree of the extension of F

in which our

code will be deﬁned

• n:= the length of the code

• k:= the dimension of the code

• λ:= the dimension of a randomly selected sub-

space of F

The security bounds of the scheme given in

(Loidreau, 2017) are the following:

• Decoding of the ciphertext in the public code cor-

responds to the complexity of solving Bounded

Distance binary Rank decoding BDR problem

which is NP-hard. In that setting, the decoding

complexity is equal to m

(λRk(e)−1)b(k min(m,n))/nc

binary operations for a classical computer and

to m

(λRk(e)−1)b(k min(m,n))/nc

operations for a

quantum computer.

• The lower bound on the complexity of distin-

guishability of the public code from a random

code is 2

(λ−1)m−(λ−1)

Finally, the scheme is separated into the three fol-

lowing parts:

• Key Generation:

– Private Key:

1. Select a Gabidulin code of length n and di-

mension k over F

with generator matrix

priv

2. Randomly generate a non-singular k × k ma-

trix S ∈ M

)

3. Randomly select a vectorial subspace V ⊂ F

of dimension λ

4. Randomly generate a non-singular P ∈ M

(V )

– Public Key: The public code C

pub

has G

pub

priv

−1

as a generator matrix.

• Encryption:

1. Choose a random vector e ∈ F

of rank weight

t := b(n − k)/(2λ)c

2. Compute y = xG

pub

+ e

3. Send y

• Decryption:

1. Compute yP = xSG + eP

2. Recover xS and eP by decoding and recover x

by multiplying xS by S

−1

We refer to (Loidreau, 2017) for the proof of work.

3.1 Parameters Selection

The parameters proposed in (Loidreau, 2017) were

not optimal for its implementation because they were

focused on reducing the size of both private and pub-

lic keys instead. For our implementation, we have

chosen a base ﬁeld which is either F

or F

ﬁt nicely into the words structure available on mod-

ern machines and carry out optimizations based on

special sets of instructions (e.g. carry-less multipli-

cation). We targeted 3 levels of post-quantum secu-

rity, namely 64 bit, 96 bit and 128 bit and we have

determined the following parameters. Table 1 shows

our parameter sets and their respective security lev-

els. Such values are computed following the formulas

given in (Loidreau, 2017) and are consistent with the

ones presented in that paper.

SECRYPT 2018 - International Conference on Security and Cryptography

Table 1: DRANKULA security parameters.

m n k λ t dec. cplx quantum dec. cplx. key recovery cplx. public key size

64 63 31 3 5 142 78 124 7.75KB

96 71 35 3 6 194.76 104.76 188 14.77KB

96 96 48 4 6 259.75 139.75 279 27KB

4 IMPLEMENTATION OF CORE

COMPONENTS

Given the nature of the cryptosystem, the core com-

ponents are the ﬁeld arithmetic and the matrix oper-

ations. Therefore, the performance of the resulting

algorithms will heavily rely on how efﬁcient such op-

erations are.

4.1 Field Arithmetic

We implemented ﬁnite ﬁeld arithmetic for the two bi-

nary ﬁelds F

, with m = 64 and m = 96, represent-

ing elements as polynomials of degree m − 1. As it

was proven in Swan’s Theorem (Swan, 1962) on fac-

torization of polynomials over ﬁnite ﬁelds, given that

64 and 96 are multiples of 8 there is no irreducible

trinomial. Therefore, we used the two following ir-

reducible pentanomial f

(x) = x

+ x

+ x + 1

and f

(x) = x

+1, respectively, both

provided by the Allan Steel database incorporated

in Magma software (Bosma et al., 1997). Notice

that in the case of f

the pentanomial has also low-

est possible intermediate degree, allowing the short-

est shift during the reduction operations. Such irre-

ducible polynomial for the case of F

has 7 terms,

i.e. x

+ x

+ x + 1, which is not con-

venient to use compared with the pentanomial.

We stored elements in both ﬁelds using 128 unsigned

integers, with unused bits set to zero.

Addition and subtraction of two elements are a simple

XOR operation.

The multiplication of two polynomials has been per-

formed using PCLMULQDQ instruction (Gueron and

Kounavis, 2010). In the case of F

, three calls to such

instruction are needed, since the instruction operates

on 64 bit inputs. For this reason we split one ele-

ment of 96 bits in two elements of 32 and 64 bits re-

spectively, and then apply Karatsuba-Ofman method

(Karatsuba and Ofman, 1962). In the case of F

, only

one call to the instruction is needed, and there is no

need to split the element.

Since the multiplication provides polynomials of de-

gree at most 2m−2, we need to perform the reduction

of such result. The two algorithms for reduction are

presented in Algorithm 1 and Algorithm 2, where the

symbols ,  denote ﬁeld multiplication and divi-

sion by x respectively (left and right shift operators),

⊕ is the ﬁeld addition (XOR operator), and || is the

concatenation operator.

Algorithm 1: Reduction in F

input : A = (a

126

,...,a

) ∈ F

127

output : C = A mod f

∈ F

1 A

= (a

,...,a

) ∈ F

2 A

= (0,a

126

,...,a

) ∈ F

3 A

= A

⊕ (A

 4) ⊕ (A

 3) ⊕ (A



1) ⊕ A

4 A

= (A

 60) ⊕ (A

 61) ⊕ (A

 63)

5 T = (0,...,0,a

) ∈ F

6 A

= A

⊕(T  4)⊕(T  3)⊕(T  1)⊕T

7 return A

Algorithm 2: Reduction in F

input : A = (a

190

,...,a

) ∈ F

191

output : C = A mod f

∈ F

1 A

= (a

,...,a

) ∈ F

2 A

= (a

127

,...,a

) ∈ F

3 A

= (0,...,0,a

190

,...,a

128

) ∈ F

4 A

= A

⊕ (A

 42) ⊕ (A

 41) ⊕ (A



38) ⊕ (A

 32)

5 A

= A

⊕ (A

 22) ⊕ (A

 23) ⊕ (A



26) ⊕ (A

 32)

6 T = (0,...,0,a

127

,...,a

) ∈ F

7 A

= A

⊕ (T  10) ⊕ (T  9) ⊕ (T 

6) ⊕ T

8 return A

||A

∈ F

To limit memory usage, the inversion on the ﬁeld

relies on the Extended Euclidean Algorithm (Hanker-

son et al., 2006). An alternative requiring more mem-

ory, which we did not consider, would be Itoh-Tsujii

algorithm with precomputed powers (Itoh and Tsujii,

1988).

DRANKULA: A McEliece-like Rank Metric based Cryptosystem Implementation

4.2 Matrix Operations

The operations needed in our implementation are the

following:

• Matrix multiplications

• Gaussian elimination in order to perform:

– Matrix inversion for square matrices

– Assertion of linear independence

– Reduction of the generator matrix of the public

code to the systematic form (i.e. rewrite G

pub

as [Id

||G

pub

])

It has to be noted that those operations were im-

plemented with two variants. That is, one for the ma-

trices with coefﬁcients in F

and one for the matrices

with coefﬁcients in F

. As the sizes of the matrices

are quite small (96 × 96 at maximum), the naive al-

gorithms were actually faster than any optimized ver-

sion. For example, the matrix multiplication is not us-

ing Strassen’s algorithm and matrix inversion is car-

ried out using Gaussian elimination.

5 ALGORITHMS

IMPLEMENTATION

Loidreau’s proposed scheme consists of the three al-

gorithms sumarized in Section 3. Here we present our

implementation for each of them.

5.1 Key Generation

The key generation is pretty simple. It just requires to

generate random matrices with coefﬁcients in F

of the right dimension and to ensure that they re-

spect the conditions given in the scheme speciﬁcation.

If the randomly generated matrix does not fulﬁll the

conditions, then repeat the process until one suitable

candidate is found.

More precisely, the conditions are the following:

• The generators g

,...,g

of the Gabidulin code

with generator matrix G

priv

are all linearly inde-

pendent over F

. That is, the binary matrix







1,1

... g

n,1

1,m

... g

n,m







where g

i, j

is the j-th bit of g

, has a rank equal to

• The λ random elements of F

which shall be seen

as the basis of V have to be linearly independent

over F

• Matrices P ∈ M

(V ) and S ∈ M

) should be

non-singular.

Luckily, the density of non-singular matrices with

coefﬁcients in ﬁnite ﬁeld is high (see (Maples, 2013))

and the sample-rejection strategy is guaranteed to be

fast for the generation of P and S or even of g

,...,g

in the case where m = n.

5.2 Encryption

The encryption operation uses a matrix multiplication

and a vector addition. Nevertheless, the generation of

an error vector of a given rank is a tricky process. In-

deed, the probability that a randomly generated n × m

matrix with coefﬁcients in F

has a rank equal to the

value speciﬁed in the scheme is low (see (Maples,

2013)). There is a need for a more optimized strategy.

The idea is to generate t random linearly independent

vectors of F

and then generate n random linear com-

binations of those vectors. This is the method which

is also used in (Deneuville et al., 2017). The pseudo-

code of the error generation is given in Algorithm 3.

Algorithm 3: Random error generation.

input : The binary ﬁeld size m, the

length of the error n and the error

rank t

output : A random element

e := {e

,...,e

} ∈ F

such that

rk(e) = t

1 while not linearly independent(b

,...,b

)

2 b

,...,b

←generate random vectors(t,F

)

3 while rk(e) 6= t do

4 for i from 1 to n do

5 rand

←− {0,1}

6 e

∑

k=1

rand

× b

7 return e

Even if highly unlikely, it could happen that the

coefﬁcient associated to one (or more) of the gener-

ating vectors is always zero. In that case, the error

vector would have a rank lower than t. This is why

the rank of the output error vector must be checked

and, in case it does not fulﬁll the requirements of the

scheme, another error vector must be generated.

5.3 Decryption

Given an encrypted message y = xSG

priv

−1

+ e, the

ﬁrst step to decrypt it is to multiply y by P to ob-

tain yP = xSG

priv

+ eP. After that, the Algorithm 11

SECRYPT 2018 - International Conference on Security and Cryptography

might be used to obtain the corrected message which

is equal to xS. Finally, the cleartext x is computed by

multiplying xS and S

−1

. Notice that S is only needed

during the public key generation but, for decryption,

it is S

−1

the required matrix. Therefore, in our im-

plementation we store S

−1

as part of the private key

instead of S in order to avoid the computations and

memory consumption from the inversion in each de-

cryption operation.

The core component of the decryption algorithm

is the error detection and correction. In order to op-

timize this step, we use the algorithms provided in

(Puchinger and Wachter-Zeh, 2015) and (Wachter-

Zeh, 2013). Here we provide the pseudo-code of the

algorithms. We refer to the aforementioned papers

for the proof that these algorithms correctly decode

any error with rank less or equal to b(n − k)/2λc, and

an in-depth explanation of the main idea. Essentially,

this decoding procedure can be seen as the equiv-

alent of Gao’s algorithm (Gao, 2003) for decoding

Gabidulin codes. It outputs an evaluation polynomial

of the estimated message thus avoiding to solve large

linear equations systems depending on the syndrome.

To the best of our knowledge, this is the fastest de-

coding procedure for Gabidulin codes. The algorithm

takes advantage of the properties of linearized poly-

nomials to achieve a sub-quadratic complexity. Since

linearized polynomials are used in all the algorithms

for decryption, we brieﬂy recall their deﬁnition.

Deﬁnition 3 (Linearized polynomials). A linearized

polynomial a(x) ∈ F

[x] is a polynomial of the form

∑

i=0

[i]

where x

[i]

= x

and d is the 2-degree of a, denoted as

deg

(a) in this paper.

We will denote by L

[x] the space of all lin-

earized polynomials of F

[x] and by L

[x]

≤s

the

space of all linearized polynomials of F

[x] with

maximum degree s. When embedded with the stan-

dard addition + and composition ◦, L

[x] is a left

(right) euclidean ring. Meaning that we can deﬁne a

left (right) division.

5.3.1 Algorithms Notation

Given that the algorithms required to compute the de-

coding of a message are presented next, here we in-

troduce the notation rules we have used:

• We denote as c

the coefﬁcient at position i from

polynomial c.

• We denote as Frobenius(x,n) the computation of

the n-th iteration of Frobenius automorphism over

• Given a linearized polynomial p, we denote as

p = 0 the assignment to p of a polynomial with

all its coefﬁcients being 0.

• Given a linearized polynomial p, we denote as

p = x to represent that p is the linearized poly-

nomial with coefﬁcient 1 in the lowest degree po-

sition (i.e. the coefﬁcient of the term x) and 0s in

all others.

• We use the notation U[i] to denote that U is a vec-

tor of elements in F

where we access its ith po-

sition.

• We use —— as the concatenation operation.

• We use #U to denote the amount of elements of a

vector U.

5.3.2 Linearized Polynomial Multiplication

The ﬁrst needed subroutine is the fast multiplication

of two linearized polynomials. Recall that the mul-

tiplication in the ring L

[x] is actually the standard

composition. The details of its implementation are in

Algorithm 4.

Algorithm 4: Multiplication.

input : a,b ∈ L

[x]

≤s

output: c = a ◦ b ∈ L

[x]

≤s

1 for i from 0 to deg

(a) + deg

(b) do

2 y = 0

3 for j from 0 to i do

4 if j ≤ deg

(a) and i − j ≤ deg

(b)

then

5 z = Frobenius(b

i− j

, j)

6 z = z · a

7 y = y + z

8 c

= y

9 return c

5.3.3 Linearized Polynomial Divisions

As L

[x] is a Euclidean ring, we can deﬁne a divi-

sion. As the multiplication in that ring is not com-

mutative, there exist a well-deﬁned left and right divi-

sion. The fast algorithms for the left and right division

are given by Algorithms 5 and 6, respectively.

5.3.4 Right Linearized Extendend Euclidean

Algorithm

We can use a Linearized version of the Euclidean

Algorithm (LEEA) based on the divisions deﬁned

DRANKULA: A McEliece-like Rank Metric based Cryptosystem Implementation

Algorithm 5: LeftDivision.

input : a, b ∈ L

[x] − {0}

output : q,r ∈ L

[x] such that

b ◦ q + r = a

initialize: r = a, db = deg

(b),

q = 0, di = deg

(r),

1 if di < db then

2 return q, r

3 while di ≥ db do

4 q

= 0

5 q

di−db

= Frobenius(r

,m − db)

6 q = q + q

7 r = r + b ◦ q

8 di = deg

(r)

9 return q, r

Algorithm 6: RightDivision.

input : a,b ∈ L

[x] − {0}

output : q,r ∈ L

[x] such that

q ◦ b + r = a

initialize: r = a, db = deg

(b),

q = 0, di = deg

(r),

1 if di < db then

2 return q, r

3 while di ≥ db do

4 q

= 0

5 q

di−db

= r

/ Frobenius(b

,di − db)

6 q = q + q

7 r = r + q

◦ b

8 di = deg

(r)

9 return q, r

above. Given that only the version using right division

is required, in Algorithm 7 we show the implementa-

tion of the right LEEA algorithm.

5.3.5 Minimal Subspace Polynomial (MSP) and

Multi-Point Evaluation (MPE)

The next needed notion is the so-called Minimal Sub-

space Polynomial which is the linearized polynomial

of minimal degree which vanishes over a subspace of

. Its existence and uniqueness is ensured by the

following lemma.

Lemma 1 (Minimal Subspace Polynomial (MSP),

(Lidl and Niederreiter, 1997)). Let U be a linear

subspace of F

. Then there exists a unique nonzero

monic polynomial M

∈ L

of minimal degree such

that kerM

= U. Its degree is dimU.

Algorithm 7: RightLEEA.

input : a,b ∈ L

[x] with

deg

(a) ≥ deg

(b), stopping

degree d

stop

output : τ,z,y ∈ L

[x] such that

τ = z ◦ a + y ◦ b and

deg

(τ) < d

stop

initialize: z = 0, y = x,

v = 0, u = x,

= a, b

= b

1 while deg

(b) ≥ d

stop

and a 6= 0 do

2 q,r = RightDivision(b

)

3 l = z + q ◦ u

4 i = y + q ◦ v

5 b

= a

, a

= r

6 z = u, y = v

7 u = l, v = i

8 τ = b

9 return τ, z, y

Algorithm 8 is used to ﬁnd the MSP of a subspace

of F

and requires another operation called Multi-

Point Evaluation (MPE) which outputs the evaluation

of a linearized polynomial over a set of points in F

The algorithm to compute MPE is presented in Algo-

rithm 9. Both algorithms apply the divide and con-

quer strategy and call each other recursively.

Algorithm 8: MSP.

input : Generating set U = u

,...,u

of a

subspace U ∈ F

output: p ∈ L

[x]

≤s

such that p(u

) = 0

for each i ∈ {1, . . . , s}

1 if s = 1 then

2 if U[1] = 0 then

44 return p = x

5 else

6 return p = x −U[1]

7 else

8 for i from 1 to bs/2c do

9 A[i] := U[i]

10 for i from bs/2c + 1 to s do

11 B[i − bs/2c] = U[i]

12 a = MSP(A)

13 P

= MPE(a,B)

14 b = MSP(P

)

15 return p = b ◦ a

SECRYPT 2018 - International Conference on Security and Cryptography

Algorithm 9: MPE.

input : a ∈ L

[x]

≤s

,{u

,...,u

} ∈ F

output: Vector A = [a(u

),...,a(u

)] ∈ F

1 if a = 0 then

2 return A = [0

,...,0

];

3 if s = 1 then

4 σ = 0

5 for i from 0 to deg

(a) do

6 σ = σ + a

i+1

· Frobenius(U[1],i)

7 return A = [σ]

8 else

9 for i from 1 to bs/2c do

10 A[i] = U[i]

11 for i from bs/2c+ 1 to s do

12 B[i − bs/2c] = U[i]

13 w = MSP(A)

14 w

= MSP(B)

15 q, r = RightDivision(a,w)

16 q

= RightDivision(a,w

)

17 return A = MPE(r

,A)kMPE(r

,B)

5.3.6 Interpolation

The last subroutine is shown in Algorithm 10, and

depicts an instantiation of the interpolation algorithm

optimized for linearized polynomials which also uses

the MSP and MPE Algorithms 8, 9.

Algorithm 10: Interpolation.

input : (w

),...,(w

) ∈ F

, x

linearly independent over F

output: Interpolation polynomial p such

that p(w

) = y

for all i ∈ {1, . . . , s}

1 if s = 1 then

2 return [y[1]/w[1]]

3 else

4 for i from 1 to bs/2c do

5 A[i] = w[i]

6 for i from bs/2c+ 1 to s do

7 B[i − bs/2c] = w[i]

8 p = MSP(A)

9 p

= MSP(B)

10 Z = MPE(p

,A)

11 Z

= MPE(p, B)

12 I = Interpolation(Z, [y[1], . . . , y[#Z]])

13 I

= Interpolation(Z

,[y[#Z],...,y[#Z +

]])

14 return I ◦ M

+ I

◦ M

5.3.7 Gabidulin Decoding

Finally, we present the main decoding procedure in

Algorithm 11. One can immediately spot that the

second step of this procedure is only depending on

the generators of the chosen Gabidulin code which

is part of the private key. Hence, one can store

the MSP(

,...,g

) into the private key to opti-

mize the decoding speed at the price of memory con-

sumption. Notice that, the value v computed in the

RightLEEA step is the error span polynomial as de-

ﬁned in (Wachter-Zeh, 2013).

Algorithm 11: Gabidulin Decoding.

input : Received word r ∈ F

and the

Gab

k,n

code generators

,...,g

}

output: Corrected codeword z, or a

decoding failure message

1 ˜r = Interpolation(g,r)

2 M = MSP(g)

3 r, u, v = RightLEEA(M, ˜r, b(n + k)/2c)

4 z, p = LeftDivision(r,v)

5 if p = 0 then

6 return z

7 else

8 return ”Decoding Failure”

6 PERFORMANCE RESULTS

Our software implementation has been designed as an

extension of the Open Quantum Safe (OQS) project

(Mosca et al., 2017). The main motivation was to be

able to compare our scheme with the other available

cryptosystems under the same conditions. We have

integrated DRANKULA in the OQS library and have

performed the automated benchmarks. The bench-

marks have been run on a MacBook Pro 2017, 2.9

GHz Intel Core i7, 16 GB 2133 MHz LPDDR3.

Table 2 presents the OQS benchmark results. As

can be observed, DRANKULA has a faster key gen-

eration than McBits as well as a signiﬁcantly lower

public key size. Moreover, our scheme is faster than

SIDH for encryption and decryption, but that comes

at the price of a larger ciphertext. Same results ap-

ply to SIKE. Although RLWE BCNS15 has the best

key generation performance, its encryption is substan-

tially worse than DRANKULA with respect to both

performance and ciphertext size.

Tables 3 and Table 4 show DRANKULA’s per-

formance for the three levels of security considered

DRANKULA: A McEliece-like Rank Metric based Cryptosystem Implementation

Table 2: Performance comparison between different post-quantum cryptography schemes using OQS.

Scheme Class. sec. PQ sec. operation mean CPU cycles Bytes comm.

McBits 128 - Key gen. 196,718,429 311,736

Encryption 72,952 141

Decryption 331,282

DRANKULA 128 78 Key gen. 159,808,905 7,936

Encryption 115,975 504

Decryption 7,761,451

SIDH 126 84 Key gen. 70,672,623 378

Encryption 143,629,801 378

Decryption 56,956,858

SIKE 126 84 Key gen. 77,602,053 378

Encryption 126,294,194 402

Decryption 134,851,945

RLWE BCNS15 163 76 Key gen. 1,807,319 4,096

Encryption 2,895,648 4,224

Decryption 297,673

in this work, and for an implementation without and

with carry-less multiplication optimization, respec-

tively. As observed, a simple software optimization

as is the carry-less multiplication provides a signiﬁ-

cant performance improvement.

7 A NOTE ON A SIDE-CHANNEL

RESISTANT

IMPLEMENTATION

When implementing a new cryptosystem there is al-

ways the challenge of ﬁnding the fastest way to com-

pute each algorithm. As we detailed in the previous

sections, the approach to implement the operations re-

quired in each algorithm could be done in different

manners. A typical technique to speed up an imple-

mentation is to remove operations under certain con-

ditions or to compute the same in a different way

depending on the inputs (i.e., by means of branch-

ing). This conditional execution is usually exploited

by side-channel attackers who try to gather informa-

tion about the inputs of operations by studying the

time difference or any other physical measurement

that may lead to some information leakage.

The fact that an implementation is weak against

some side-channel attack does not mean that the cryp-

tosystem itself is not secure. It usually means that

some performance improvements must be modiﬁed

from the implementation so that secret information

remains secure. Nevertheless, nowadays performance

is such an important property for cryptosystems that

the lack of an efﬁcient implementation may end up

with the cryptosystem becoming not used at all and

eventually obsolete.

One alternative to protect an implementation from

side-channel attacks is by means of constant-time op-

erations. This way, the operations required by each

algorithm take the same time no matter the input and,

therefore, an attacker can only extract information

about the operations, which might be public, but not

about the inputs and outputs. The main drawback of

this approach is that the cost of the algorithms is heav-

ily increased. For this reason, we propose to modify

only a subset of operations to be constant-time, and

we analyze the information leaked to check the feasi-

bility of obtaining any knowledge of the secret key, or

the error generated during encryption, from the leaked

data.

We propose to only modify some algorithms used

for the decryption procedure in order to make them

constant time, namely: the linearized polynomial ad-

dition, the linearized polynomial multiplication and

part of the Minimal Subspace Polynomial. The ﬁrst

modiﬁcation is simple, we just computed the addition

for all the elements and checked the degree by iter-

ating over all the positions. For the multiplication,

in Algorithm 12 we modiﬁed a little bit the previous

Algorithm 4 to avoid conditional instructions in the

loop,. We also computed the multiplication up to the

maximum degree, not only up to the degree of the

polynomials.

Finally, the changes in MSP only affected the ini-

tial conditions to return values. In Algorithm 8 we

returned either 1 or 2 values depending if the input

subspace is 0 or not. This would leak information of

the 0s in the input subspace. To prevent that from

happening we generated the same result but we ﬁll

the polynomial with a 0 in the second position. More

precisely, we change the return value so instead of

the return statement in Algorithm 8 line 4, we return

p = x − 0.

SECRYPT 2018 - International Conference on Security and Cryptography

Table 3: Performance comparison for different security levels without carry-less multiplication.

Scheme Class. sec. PQ sec. operation mean CPU cycles Bytes comm.

DRANKULA 128 78 Key gen. 717,478,286 7,936

Encryption 1,167,473 504

Decryption 64,645,692

DRANKULA 192 104 Key gen. 1,405,999,903 15,120

Encryption 2,154,776 852

Decryption 131,834,096

DRANKULA 256 139 Key gen. 3,537,521,289 27,648

Encryption 3,887,225 1,152

Decryption 276,356,299

Table 4: Performance comparison for different security levels with carry-less multiplication.

Scheme Class. sec. PQ sec. operation mean CPU cycles Bytes

DRANKULA 128 78 Key gen. 159,808,905 7,936

Encryption 115,975 504

Decryption 7,761,451

DRANKULA 192 104 Key gen. 281,555,550 15,120

Encryption 209,117 852

Decryption 127,45,290

DRANKULA 256 139 Key gen. 544,649,920 27,648

Encryption 320,951 1,152

Decryption 23,559,649

Algorithm 12: Constant-Time Multiplication.

input : a,b ∈ L

[x]

≤n+1

output: c = a ◦ b ∈ L

[x]

≤n+1

1 for i from 0 to n + 1 do

2 y = 0

3 for j from 0 to i do

4 z = Frobenius(b

i− j

, j)

5 z = z · a

6 if j ≤ deg

(a) and i − j ≤ deg

(b)

then

7 y = y + z

8 else

9 y = y + 0

10 c

= y

11 return c

We have chosen only these three operations be-

cause our analysis showed that with these changes,

the decryption would not leak not enough informa-

tion to threaten the security of the cryptosystem. In-

deed, the unmodiﬁed operations are: interpolation,

rightLEEA and left / right division, which usually

take polynomials of the same degree as inputs at a

given recursion degree.

Table 5 shows the performance of our constant-

time implementation of DRANKULA for the same

three security levels that we have considered in our

work. It must be noted that our solution uses the

carry-less multiplication and, as the constant-time im-

plementation only affects the decryption, we skip the

other two operations. Results show that decryption is

heavily impacted when the countermeasures are put

in place.

The only identiﬁed cases where an attacker would

observe a timing difference are the following:

1. The interpolation polynomial ˜r is of 2-degree less

than n − 1: the attacker would be able to learn

that the point (g

) is already part of the graph

of the interpolation polynomial of {(g

)}

1≤i<n

As the attacker does not have any control on the

and neither on the r

s (as they are actually the

coefﬁcients of cP where P is unknown to him), he

will not be able to extract any meaningful infor-

mation.

2. The degree controlling the number of iterations

in the loop of RightLEEA or the right division is

decreasing more than 1: the attacker would ob-

serve in the best case that the Interpolation poly-

nomial ˜r divides the MSP of the generators of the

Gabidulin code. Again, as the coefﬁcients of ˜r are

actually depending on the coefﬁcients of cP, then

the attacker will not gain any valuable knowledge

on the private key.

Nevertheless, a deeper analysis of the possible

leakages through timing analysis constitutes a path for

future works.

DRANKULA: A McEliece-like Rank Metric based Cryptosystem Implementation

Table 5: Performance comparison for different security levels of the constant-time implementation with carry-less multiplica-

tion.

Scheme Class. sec. PQ sec. operation mean CPU cycles

DRANKULA 128 78 Decryption 314,116,991

DRANKULA 192 104 Decryption 878,204,550

DRANKULA 256 139 Decryption 2,662,744,720

8 CONCLUSIONS AND FUTURE

WORK

This work is presenting a software implementation

of DRANKULA, a rank based McEliece-like cryp-

tosystem with deterministic decryption presented in

(Loidreau, 2017), and its performance results. We

address several caveats of the scheme when carry-

ing out a practical implementation, and we provide

three sets parameters targeting 64, 96 and 128 bits

of post-quantum security. In addition we provide

the pseudocode for the main subroutines of our al-

gorithms, which might be helpful to the community

to continue investigating this scheme. Results show

that DRANKULA is a viable alternative to other post-

quantum cryptography schemes and efﬁcient in terms

of key sizes and computational complexity. We end

up providing a note on a side-channel resistant imple-

mentation of our proposal. As future work it would be

interesting to formally investigate the IND-CCA and

IND-CPA properties of DRANKULA.

REFERENCES

Aragon, N., Blazy, O., Deneuville, J.-C., Gaborit, P.,

Hauteville, A., Ruatta, O., Tillich, J.-P., and Zemor,

G. (2017). Locker - low rank parity check codes en-

cryption.

Bernstein, D. J., Buchmann, J., and Dahmen, E. (2008).

Post Quantum Cryptography. Springer Publishing

Company, Incorporated, 1st edition.

Bernstein, D. J., Chou, T., and Schwabe, P. (2015). Mcbits:

fast constant-time code-based cryptography. IACR

Cryptology ePrint Archive, 2015:610.

Bosma, W., Cannon, J., and Playoust, C. (1997). The

Magma algebra system. I. The user language. J. Sym-

bolic Comput., 24(3-4):235–265. Computational al-

gebra and number theory (London, 1993).

Chen, L., Jordan, S., Liu, Y.-K., Moody, D., Peralta, R.,

Perlner, R., and Smith-Tone, D. (2016). Report on

post-quantum cryptography.

Chou, T. (2016). Qcbits: Constant-time small-key code-

based cryptography. In Cryptographic Hardware and

Embedded Systems - CHES 2016 - 18th International

Conference, Santa Barbara, CA, USA, August 17-19,

2016, Proceedings, pages 280–300.

Chou, T. (2017). Mcbits revisited. In International Con-

ference on Cryptographic Hardware and Embedded

Systems, pages 213–231. Springer.

Deneuville, J.-C., Gaborit, P., and Z

emor, G. (2017).

Ouroboros: A simple, secure and efﬁcient key ex-

change protocol based on coding theory. In Inter-

national Workshop on Post-Quantum Cryptography,

pages 18–34. Springer.

Devoret, M. H. and Schoelkopf, R. J. (2013). Supercon-

ducting circuits for quantum information: An outlook.

Science, 339(6124):1169–1174.

Gabidulin, E. M. (1985). Theory of codes with maximum

rank distance. Problems of Information Transmission

(English translation of Problemy Peredachi Informat-

sii), 21(1).

Gabidulin, E. M., Paramonov, A. V., and Tretjakov, O. V.

(1991). Ideals over a Non-Commutative Ring and

their Application in Cryptology, pages 482–489.

Gaborit, P. (2005). Shorter keys for code based cryptogra-

phy, pages 81–90.

Gaborit, P., Murat, G., Ruatta, O., and Zmor, G. (2013).

Low rank parity check codes and their application to

cryptography.

Gao, S. (2003). A New Algorithm for Decoding Reed-

Solomon Codes, pages 55–68.

Google (2018). A preview of bristlecone, googles

new quantum processor. Available at

https://research.googleblog.com/2018/03/a-preview-

of-bristlecone-googles-new.html.

Gueron, S. and Kounavis, M. E. (2010). Intel

 carry-less

multiplication instruction and its usage for computing

the gcm mode. White Paper.

Hankerson, D., Menezes, A. J., and Vanstone, S. (2006).

Guide to elliptic curve cryptography. Springer Sci-

ence & Business Media.

Itoh, T. and Tsujii, S. (1988). A fast algorithm for com-

puting multiplicative inverses in gf (2m) using normal

bases. Information and computation, 78(3):171–177.

Karatsuba, A. and Ofman, Y. (1962). Multiplication of

many-digital numbers by automatic computers. Dok-

lady Akademii Nauk SSSR, Translation in Physics-

Doklady 7, 595-596, 1963, 145(2):293–294.

Lidl, R. and Niederreiter, H. (1997). Finite ﬁelds, volume 20

of Encyclopedia of Mathematics and its Applications.

Cambridge University Press, Cambridge, second edi-

tion.

Loidreau, P. (2017). A New Rank Metric Codes Based En-

cryption Scheme, pages 3–17.

Maples, K. (2013). Singularity of random matrices over

ﬁnite ﬁelds.

SECRYPT 2018 - International Conference on Security and Cryptography

McEliece, R. J. (1978). A Public-Key Cryptosystem Based

On Algebraic Coding Theory. Deep Space Network

Progress Report, 44:114–116.

Melchor, C. A., Aragon, N., Bettaieb, S., Bidoux, L.,

Blazy, O., Deneuville, J.-C., Gaborit, P., and Zmor,

G. (2016). Rank quasi-cyclic (rqc).

Misoczki, R., Tillich, J., Sendrier, N., and Barreto, P. S.

L. M. (2013). Mdpc-mceliece: New mceliece variants

from moderate density parity-check codes. In Pro-

ceedings of the 2013 IEEE International Symposium

on Information Theory, Istanbul, Turkey, July 7-12,

2013, pages 2069–2073.

Mosca, M., Stebila, D., and Contributors (2017). Open

quantum safe.

Niederreiter, H. (1986). Knapsack-type cryptosystems and

algebraic coding theory. Problems of Control and In-

formation Theory, 15:159–166.

NIST (2018). Round 1 submissions. Available

at https://csrc.nist.gov/Projects/Post-Quantum-

Cryptography/Round-1-Submissions.

Otmani, A., Kalachi, H. T., and Ndjeya, S. (2016). Im-

proved cryptanalysis of rank metric schemes based on

gabidulin codes. CoRR, abs/1602.08549.

Overbeck, R. (2005). A New Structural Attack for GPT and

Variants, pages 50–63.

Overbeck, R. (2008). Structural attacks for public-key cryp-

tosystems based on gabidulin codes. Journal of Cryp-

tology, 21(2):280–301.

Puchinger, S. and Wachter-Zeh, A. (2015). Fast opera-

tions on linearized polynomials and their applications

in coding theory. CoRR, abs/1512.06520.

Sendrier, N. (2017). Code-based cryptography: State of

the art and perspectives. IEEE Security & Privacy,

15(4):44–50.

Shor, P. W. (1997). Polynomial-time algorithms for prime

factorization and discrete logarithms on a quantum

computer. SIAM Journal on Computing, 26(5):1484–

1509.

Swan, R. G. (1962). Vector bundles and projective modules.

Transactions of the American Mathematical Society,

105(2):264–277.

Wachter-Zeh, A. (2013). Decoding of block and convolu-

tional codes in rank metric, PhD thesis.

DRANKULA: A McEliece-like Rank Metric based Cryptosystem Implementation
