Towards a Security-Aware Benchmarking Framework for

Function-as-a-Service

Roland Pellegrini, Igor Ivkic and Markus Tauber

University of Applied Sciences Burgenland, Eisenstadt, Austria

Keywords: Cloud Computing, Benchmarking, Cloud Security, Framework, Function-as-a-Service.

Abstract: In a world, where complexity increases on a daily basis the Function-as-a-Service (FaaS) cloud model

seams to take countermeasures. In comparison to other cloud models, the fast evolving FaaS increasingly

abstracts the underlying infrastructure and refocuses on the application logic. This trend brings huge

benefits in application and performance but comes with difficulties for benchmarking cloud applications. In

this position paper, we present an initial investigation of benchmarking FaaS in close to reality production

systems. Furthermore, we outline the architectural design including the necessary benchmarking metrics.

We also discuss the possibility of using the proposed framework for identifying security vulnerabilities.

1 INTRODUCTION

Cloud computing, as defined by Mell and Grance

(2011), is a model for enabling on-demand network

access to a shared pool of configurable resources.

Cloud vendors provide these resources in the service

models Infrastructure as a Service (IaaS), Platform-

as-a-Service (PaaS) and Software-as-a-Service

(SaaS). Through virtualization, the IaaS service

model provides computing resources (e.g.: servers,

storage, network) to consumers so they can deploy

and run software. In other words, the consumers do

not control the infrastructure, but are able to manage

the running operating systems and applications.

Quite contrary to IaaS, PaaS offers an integrated

runtime and development environment where

consumers only control their deployed and

developed applications. Finally, SaaS provides

software and applications, which can be used and

accessed by consumers via the web or application

programming interfaces (API).

These three service models are currently being

extended by a very new and rapidly evolving

technology called Function-as-a-Service (FaaS).

FaaS provides a runtime environment to develop,

deploy, run, and manage application functionality

without any knowledge about the underlying

application. All instances of these environments are

managed by the provider, who is responsible for the

code execution, resource provisioning and automatic

scaling for virtually any type of application. Figure 1

gives an overview of a generic FaaS architecture and

illustrates the technical workflow between the

components:

Figure 1: FaaS architecture, based on Pientka (2017).

However, Cloud Service Providers (CSP) often

limit the amount of execution time or resource

allocation a request may consume. Additionally,

FaaS code may suffer more from start-up latency

than code that is continuously running on a

dedicated server. The reason for that is that each

time a function is called the underlying environment

has to be provisioned. Depending on the providers

configuration, the function may wait an amount of

time before it is deprovisioned. If another request is

sent to the function while it is waiting it executes the

request again. But, in case the function has already

been deprovisioned and is reinvoked by an event, the

runtime environment has to start up again, which

leads to delays and latency.

As explained in Section II in more detail, the

existing publications either compare CSPs and/or

666

Pellegrini, R., Ivkic, I. and Tauber, M.

Towards a Security-Aware Benchmarking Framework for Function-as-a-Service.

DOI: 10.5220/0006817606660669

In Proceedings of the 8th International Conference on Cloud Computing and Services Science (CLOSER 2018), pages 666-669

ISBN: 978-989-758-295-0

technologies, or use approaches, which are

applicable for specific use cases. In order to make

FaaS benchmarking possible in close to reality

production systems and independent of a specific

use case a more general approach is required.

In this position paper we propose a framework

for benchmarking FaaS in production systems,

which is independent of a specific use case. In this

regard we present the architectual design, discuss

two different methods of measuring FaaS

performance, propose a set of benchmarking metrics

and explain, which components of the benchmarking

framework need to be implemented.

The rest of the position paper is structured as

follows: Section II provides a summary of the

related work, followed by the benchmark framework

archictechture in Section III. Finally, we present our

conclusions and future work including security

considerations in Section IV.

2 RELATED WORK

In the field of cloud performance evaluation most of

the existing research publications can be grouped in

the following three categories: (a) IaaS, PaaS, and

SaaS benchmarking at different abstraction levels,

(b) comparison of existing Cloud Benchmark

Frameworks, and (c) performance comparison of

cloud services among CSPs.

Since FaaS is a relatively new technology, more

detailed research is needed for benchmarking cloud

functions. An initial introduction and guideline has

been done by Bermbach et al. (2017) where they

compare the cloud service models, define terms

related to benchmarking, derive the quality

requirements of the users, and explain the

motivation for benchmarking these qualities.

Additionally, they cover the entire lifecycle of cloud

service benchmarking, from its motivations, over

benchmarking design and execution, to the use of

benchmarking results.

Sitaram and Manjunath (2011) provide another

introduction in cloud computing and examine some

popular cloud benchmarking tools. Whereas,

Mueller et al. (2014), Coarfa et al. (2006), and Juric

et al. (2006) evaluated security performance for

different use cases in experimental studies.

Malawski et al. (2017) focus on performance

evaluation of cloud functions by taking

heterogeneity aspects into account. For this purpose,

they developed a framework with two types of CPU-

intensive benchmarks for performance evaluation of

cloud functions. Then they applied it to all the major

Cloud Function Providers (CFP) such as Amazon,

Microsoft, Google, and IBM. Their results show the

heterogeneity of CFPs, the relation between function

size and performance and how CFPs interpret the

resource allocation policies differently.

Hwang et al. (2016) provided a summary of

useful Cloud Performance Metrics (CPM) and

introduced an extended CPM-concept on three

levels: (a) basic performance metrics including

traditional metrics (e.g. execution time, speed and

efficiency), (b) cloud capabilities for describing

network latency, bandwidth, and data throughput,

and finally, (c) cloud productivity, which deals with

productivity metrics (e.g. Quality of Service (QoS),

Service Level Agreement (SLA) and security).

Additionally, Luo et al. (2012) proposes a

benchmark suite for evaluating cloud systems

running data processing applications. Furthermore,

they discussed and analysed, why traditional metrics

(e.g. floating-point operations and I/O operations)

are not appropriate for system cloud benchmarking.

Instead, they propose data processed per second and

data processed per Joule as two complementary

metrics for evaluating cloud computing systems.

The architecture of cloud benchmarking tools has

been subject of previous research. An overview of a

generic architecture, elements of a benchmarking

tool and performance metrics for IaaS cloud

benchmarking has been discussed by Iosup et al.

(2014). Furthermore, Sangroya and Bouchenaket

(2015) proposed a generic software architecture for

dependability and performance benchmarking for

cloud computing services. They also describe

various components and modules responsible for

injecting faults in cloud services in addition to the

components responsible for measuring the

performance and dependability.

Finally, the Yahoo! Cloud Serving Benchmark

(YCSB) is a benchmark suite that measures the

performance of a cloud storage system against

standard workloads. The architecture, as described

by Cooper et al. (2010), consists of a YCSB client,

which is a Java-based multi-threaded workload

generator and can be extended to support

benchmarking different databases.

3 PROPOSED ARCHITECTURE

FRAMEWORK

The approach taken in this position paper differs

from the existing publications as mentioned above.

The main focus is to evaluate the FaaS performance

for data processing (e.g. the maximum number of

Towards a Security-Aware Benchmarking Framework for Function-as-a-Service

667

Figure 2: Prototype architecture, based on Pientka (2017).

function calls per seconds) instead of identifying the

hardware specification of the underlying IT

infrastructure of the CFP. In order to evaluate FaaS

performance the following influencing parameters

need to be considered: (a) FaaS caller with varying

parameters such as data size, run length, batch size,

and pause interval, (b) cloud function latency and

throughput, and (c) network latency and bandwidth.

In this position paper we propose an approach for

benchmarking FaaS performance on a close to

reality system without the need of implementing a

complex testbed. To achieve this goal, the

architecture of the benchmarking framework needs

to be designed in a way, so that the production

system needs a minimum amount of adaptation. The

reason for that is that a benchmarking executed on a

production system delivers more significant results

in comparison to a test environment. In more detail,

the benchmarking framework has to be designed as a

two-tier architecture. In this way the FaaS calls will

be executed on a sender and the cloud function

processing will run on the CSP platform. We

consider two FaaS sender variants: A Faas

Performance Caller (FaaS-PC) and a FaaS Latency

Caller (FaaS-LC).

The FaaS-PC measures the potential

performance of a cloud function by sending runs of

messages, and compiling statistics. Instead of

sending a continuous stream of messages, the FaaS-

PC groups them into batches. Between two batches

the FaaS-PC pauses for a freely configurable interval

of seconds. Furthermore, the FaaS-PC supports a

single mode and an automatic mode. In the single

mode, the FaaS-PC sends a single run of messages.

This mode is useful to answer questions about cloud

function behavior under sustained load conditions.

In the automatic mode the FaaS-PC starts sending

several runs of messages and function calls,

modifying the parameters for each run. It does so,

until the ideal batch size and interval parameters that

yield maximum sustainable cloud function

throughput are found. This mode allows FaaS-PC to

tune its send rate to match the maximum receive rate

of the slowest cloud function call-back. Both, the

single mode and the automatic mode provide a

summary-report at the end of the run.

In contrast to FaaS-PC, the FaaS-LC helps to

identify latency bottlenecks in networks where the

transit time between FaaS caller and cloud function

needs to be kept to a minimum. However, clock

synchronization between FaaS-LC and cloud

function is not precise enough to accurately measure

one-way travel time. Therefore, FaaS-LC measures

round-trip time for a request-reply message pair by

using a single clock. For this scenario an additional

function needs to be developed.

The following metrics are potential candidates to

measure the performance for both types of FaaS

callers: elapsed time, number of cloud function calls,

number of messages, size of payloads, total payload

size, batch interval, batch size, messages per second,

payload per second (in bytes), maximum latency (in

milliseconds), minimum latency (in milliseconds),

number of messages or function calls with latency

exceeds a threshold.

In the end, both FaaS callers generate a report,

which can easily be transferred to spreadsheet

applications or command-line programs. Another

benefit is that two- and three-dimensional plots of

functions, data and statistical reports can be

produced. In Figure 2 the prototype architecture for

FaaS benchmarking, the planned measuring-points,

and metrics candidates are shown. As shown in the

dotted line, the elapsed time has to be measured

indirectly between the gateway and the function if

the access to the API gateway is not possible.

CLOSER 2018 - 8th International Conference on Cloud Computing and Services Science

668

4 CONCLUSION AND FUTURE

WORK

In this position paper, we introduced a FaaS

benchmarking framework for measuring the cloud

function performance in a production environment

for a front-to-back processing. First, we compared

the functionality of FaaS to the traditional cloud

service models. Next, we explained the technical

architecture of FaaS and pointed out some related

performance issues. In this regard, we discussed

several aspects of cloud benchmarking and cloud

security. Finally, in Section III we proposed a

prototype including the architectural design and the

functional requirements. In this regard, we outlined

the necessity of the FaaS-PC and FaaS-LC from the

benchmarking perspective. In addition to that we

identified a set of metrics for measuring the

performance of these FaaS callers.

In summary, we explored the possibility of

measuring the performance of FaaS to make CSPs

more comparable. By doing so, we provided a

method for decision-makers, IT architects and cloud

service consumers to assist them in finding the best

FaaS solution for their businesses. The main

contribution of this paper is the initial investigation

on an approach for benchmarking FaaS, which can

also be used to identify FaaS security vulnerabilities.

While FaaS dramatically reduces some top-level

threats, there are still some risks regarding DoS

attacks and exploitation of the long-lived FaaS

container functionality. Even though the proposed

framework is used to measure the performance, it

could also be applied to stress indirectly the

underlying IaaS, PaaS and/or SaaS to emulate e. g.

DoS attacks. This would make the Cloud return error

codes, which could be exploited as security

vulnerabilities. In future work, we will consider

using the proposed benchmarking framework to

identify possible FaaS vulnerabilities, threats and

attacks to verify a broader application of our work.

ACKNOWLEDGEMENTS

The research has been carried out in the context of

the project MIT 4.0 (FE02), funded by IWB-EFRE

2014 - 2010.

REFERENCES

Bermbach, D., Wittern, E. and Tai, S., 2017. Cloud

Service Benchmarking: Measuring Quality of Cloud

Services from a Client Perspective. Springer.

Coarfa, C., Druschel, P. and Wallach, D.S., 2006.

Performance analysis of TLS Web servers. ACM

Transactions on Computer Systems (TOCS), 24(1), pp.

39-69.

Cooper, B.F., Silberstein, A., Tam, E., Ramakrishnan, R.

and SEARS, R., 2010. Benchmarking cloud serving

systems with YCSB, Proceedings of the 1st ACM

symposium on Cloud computing 2010, ACM, pp. 143-

154.

Hwang, K., Bai, X., Shi, Y., Li, M., Chen, W. and Wu, Y.,

2016. Cloud performance modeling with benchmark

evaluation of elastic scaling strategies. IEEE

Transactions on Parallel and Distributed Systems,

27(1), pp. 130-143.

Iosup, A., Prodan, R. and Epema, D., 2014. IaaS cloud

benchmarking: approaches, challenges, and

experience. Cloud Computing for Data-Intensive

Applications. Springer, pp. 83-104.

Juric, M.B., Rozman, I., Brumen, B., Colnaric, M. and

Hericko, M., 2006. Comparison of performance of

Web services, WS-Security, RMI, and RMI–SSL.

Journal of Systems and Software, 79(5), pp. 689-700.

Luo, C., Zhan, J., Jia, Z., Wang, L., Lu, G., Zhang, L., Xu,

C. and Sun, N., 2012. Cloudrank-d: benchmarking and

ranking cloud computing systems for data processing

applications. Frontiers of Computer Science, 6(4), pp.

347-362.

Müller, S., Bermbach, D., Tai, S. and Pallas, F., 2014.

Benchmarking the performance impact of transport

layer security in cloud database systems, Cloud

Engineering (IC2E), 2014 IEEE International

Conference on 2014, IEEE, pp. 27-36.

Malawski, M., Figiela, K., Gajek, A. and Zima, A., 2017.

Benchmarking Heterogeneous Cloud Functions,

European Conference on Parallel Processing 2017,

Springer, pp. 415-426.

Mell, P. and Grance, T., 2011. The NIST definition of

cloud computing.

Pientka, F., 2017, Function as a Service: Was ist

Serverless Computing? [online] Informatik Aktuell.

Available at: https://www.informatik-

aktuell.de/betrieb/server/function-as-a-service-was-ist-

serverless-computing.html [Accessed 10 Jan. 2018].

Sangroya, A. and Bouchenak, S., 2015. A Reusable

Architecture for Dependability and Performance

Benchmarking of Cloud Services, International

Conference on Service-Oriented Computing 2015,

Springer, pp. 207-218.

Sitaram, D. and Manjunath, G., 2011. Moving to the

cloud: Developing apps in the new world of cloud

computing. Elsevier.

Towards a Security-Aware Benchmarking Framework for Function-as-a-Service

669
