Comparison of Decision Tree, Neural Network, Statistic Learning,

and k-NN Algorithms in Data Mining of Thyroid Disease Datasets

Wafaa Al Somali and Riyad Al Shammari

Department of Health Informatics, King Saud Bin Abdul-Aziz University for Health Sciences, Riyadh, Saudi Arabia

Keywords: Data Mining, Knowledge Discovery, Thyroid Dataset.

Abstract: Massive information contained in medical datasets presents challenge to the practitioners in diagnosing

diseases or determining health status of patients. Data mining is therefore required to help users obtaining

valuable information from a very complex data collection. In this study, we explored several methods of data

mining in order to improve the quality of a dataset which is related to diagnosis of thyroid disease. Several

classifiers were trained on the dataset and compared to previous study by Akbas

et al (2013). The performance

improvement was examined in order to determine the best classifier that can be executed. Findings revealed

that decision tree (J48) algorithm outperformed all other algorithms in terms of accuracy, Kappa, Matthew’s

correlation coefficient (MCC), and receiver operating characteristics (ROC) with respective values of 0.994,

0.951, 0.953, and 0.987. Classification using J48 was found to be better than those conducted by Akbas

et al.

In contrast, IBK algorithm showed the poorest performance, particularly Kappa and MCC. The size of tree

generated from J48 and Logistic Model Tree (LMT) varied greatly. Integration of single classifier with

AdaBoost classifier mostly resulted in higher accuracy. However, AdaBoost did not improve the performance

of NaïveBayes, IBK and RandomForest algorithms. These results were consistent with the previous study

using AdaBoost-based ensemble classifier.

1 INTRODUCTION

Medical datasets are growing rapidly in size.

Therefore, data mining (DM) is inseparable from the

process of establishing knowledge-based decision

(Yeh et al., 2008).

Over the last decades, studies have

been exploring the DM technique with optimum

results. The main task in DM of medical dataset is

classification (Olafsson et al., 2008).

The labelled

subjects are partitioned into predefined groups or

classes by using a suitable DM model, resulting in

new instances. Knowledge discovery in DM might be

achieved through an ‘if – then’ rules, knowledge

representation, and many more (Mohamadi et al.,

2008).

2 BACKGROUND

Health care related datasets are usually huge and

complex. Thyroid disease dataset has taken from UCI

Machine Learning repository). Thyroid disease

dataset has 7200 instances, with both continuous and

discrete inputs. The purpose of this dataset is to

determine whether the patient has hypothyroid,

hyperthyroid, or normal thyroid function.

Hypothyroid is a condition where insufficient level of

thyroid hormones are produced. Hyperthyroid, on the

contrary, is an abnormality where thyroid hormones

are produced in exceeding level. The attributes in the

datasets are based on clinical observation which

measures the percentage of T3-resin uptake, serum

thyroxin level, serum triiodothyronine level, basal

thyroid-stimulating hormone, and maximal absolute

difference of thyroid stimulating hormone level

(Chang et al.. 2010, Ozyilmaz and Yildirim. 2002).

It is an exhaustive task to diagnose thyroid disease

by only interpreting clinical observations and

examining medical history of the patient. Moreover,

thyroid disease is not only related to the production of

thyroid hormones. Other abnormalities such as

thyroid cancer might be confused with

hyperthyroidism (Ozyilmaz and Yildirim. 2002).

appropriate DM model will solve this problem and

help users to diagnose a disease more accurately.

Somali, W. and Shammari, R.

Comparison of Decision Tree, Neural Network, Statistic Learning, and k-NN Algorithms in Data Mining of Thyroid Disease Datasets.

DOI: 10.5220/0006479602410246

In Proceedings of the 11th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2018) - Volume 5: HEALTHINF, pages 241-246

ISBN: 978-989-758-281-3

241

2.1 Data Mining

Data mining (DM) is a process of obtaining valuable

data from a huge-sized data collection

(Giannopoulou, 2008).

Therefore, DM is an

important task in generating knowledge-based

decisions. A high number of DM programs has been

developed using various algorithms and approaches,

commonly known as classifiers. A classifier

determines a model for a collection of instances or

target values by predicting general rules.

In clinical

DM process, classification is often performed on

previous data stored in medical records and databases

in order to improve the quality of the data (Ressom et

al.. 2008, Iavindrasana et al.. 2010, Fernandez et al..

2010).

2.2 Thyroid Disease Data Mining

Various algorithm has been used in classification of

thyroid disease dataset, including decision tree, ANN,

RBF, MLP with BP and CSFNN (Ozyilmaz and

Yildirim. 2002, Fernandez et al., 2010).

In another

study, a high number of algorithms was applied,

including C4.5, Random Tree, Logistic Regression,

k-NN, Naïve Bayes, and SVM. Performance

evaluation was conducted by determining accuracy,

rate of error, and tree size (Jacob and Ramani, 2012).

We compared our data mining to a study by Akbas

et al. (2013). The study describes the performance

improvement in diagnosis of thyroid cancer by

training and testing datasets using several classifiers

(Akbas

et al., 2013).

Five individual classifiers were

used and compared for their accuracy, kappa,MCC

and ROC values: BayesNet, NaÏveBayes, SMO, IBk

and Random Forest. Ensemble classifiers were also

used in addition to individual classifiers, by

combining them with AdaboostMI. Algorithm

process comprised of three stages: dataset training,

dataset testing, and reclassification. All data mining

was performed on WEKA developer version 3.7.13.

Improvement in the diagnosis of thyroid cancer was

indicated by ROC graphs. Random Forest was found

to be the most accurate classifier (Akbas

et al., 2013).

The value for accuracy, kappa, MCC, and ROC in

Random Forest were 0.99, 0.937, 0.941, and 0.998,

respectively (Akbas

et al., 2013). In combination with

AdaboostMI, the value for accuracy, kappa, MCC,

and ROC in Random Forest remained the highest,

being 0.991, 0.939, 0.940, and 0.998, respectively

(Akbas

et al., 2013).

In this study, we proposed several methods of data

mining of Thyroid dataset. The objectives of this

study were to obtain a classification algorithm that

can improve the quality of Thyroid dataset, to apply

several classifiers by training and testing on the

dataset and compare the results with previous study,

and to measure the performance improvement by

each algorithm in order to determine the best

classifier that can be executed.

3 METHODOLOGY

3.1 Individual Classifier

Classification of Thyroid disease dataset (retrieved

https://archive.ics.uci.edu/ml/datasets/Thyroid+Dise

ase), consisted of 21 attributes and 7200 instances,

were performed. The thyroid dataset was divided into

two groups: training group (3772 instances) and

testing group (3428 instances). In the pre-processing

the obtained dataset converted it to CSV (comma

separated values) format, the class column values

have been changed it from numeric to nominal.

Classifier algorithms used in this study were neural

network (Multiple Layer Perceptron/MLP) and

decision tree classifiers (J48 and Logistic Model

Tree/LMT). These classifiers were chosen because

thyroid disease dataset comprises of continuous and

discrete values. Thyroid dataset was also classified

using several algorithms used by Akbas

et al (2013),

including BayesNet, NaiveBayes, sequential minimal

optimization (SMO), IBk, and RandomForest.

3.2 Ensemble Classifier

Individual classifiers were integrated into an

ensemble classifier, together with AdaBoost, to

evaluate whether ensemble classifier can improve the

performance of individual classifier. All DM

procedures was performed on WEKA developer

version 3.7.13.

3.3 Performance Evaluation

Performance improvement evaluation was conducted

by determining classification accuracy, Kappa

statistics, Matthews correlation coefficient (MCC),

receiver operating characteristics (ROC) value,

decision tree size (only for decision tree classifier.

3.4 Experiment

In this study, training and testing datasets were

separated for each classification method. This

technique was chosen to remove unnecessary data.

Thyroid dataset is a very large dataset and removal of

HEALTHINF 2018 - 11th International Conference on Health Informatics

242

unnecessary data was required. Accuracy was

determined by using equation 1, where 1 was

considered as the highest accuracy. Kappa statistics

was used to assess the reliability of cohesion between

two data, as shown in equation 2. Higher Kappa

means higher reliability and zero is considered the

worst result. Matthew’s correlation coefficient was

calculated by using equation 3, while ROC was

calculated by using equation 4.

4 RESULTS AND DISCUSSION

4.1 Individual Classifiers

In our proposed study, Thyroid dataset was classified

by using J48 tree, LMT tree, and multiple layer

perceptron (MLP) algorithms. The results of

performance evaluation are shown in Table 1. It was

found that J48 resulted in highest accuracy, Kappa,

and MCC. The highest ROC values was obtained

using LMT tree. The tree size in J48 was 23,

significantly higher than the tree size in LMT tree

(only 5). There were 12 leaves in J48 and only 3

leaves in LMT. In comparison with decision tree

models (J48 and LMT), MLP as a neural network

resulted in lower accuracy, Kappa, MCC, and ROC.

This finding is contrary to our expectation, where

decision tree algorithm was more likely to have lower

classification accuracy because the high variance in

decision tree that potentially lead to overfitting. We

also expected that neural network would perform

better on a large dataset. Kotsiantis (2007) has

reported that neural network would take longer time

to execute in comparison with decision trees

(Kotsiantis, 2007).

However, neural network are

usually able to provide learning more easily in

comparison to decision trees (Bostanci and Bostanci,

2012).

In this study, classification using other algorithms

were also performed in order to compare our findings

to the study conducted by Akbas

et al (2013). The

results, summarized in Table 2, were consistent.

RandomForest was the most accurate classifier for the

Thyroid dataset. It also produced the highest Kappa,

MCC, and ROC. IBK algorithm was found to be the

poorest model in terms of all performance indicators.

Among all classification models, J48 showed the

best performance. Decision tree model is expected to

have a great performance on discrete or categorical

datasets, including Thyroid disease (Kotsiantis,

2007).

However, it might be not suitable for a very

large datasets or when the splitting of nodes are based

on more than one feature (Ozyilmaz and Yildirim.

2002),(Kotsiantis, 2007).

IBK showed poor accuracy,

reliability of cohesion, and ROC because IBK is a K-

Nearest Neighbor (KNN) classifier that is more

suitable for nominal and numerical data (Bostanci and

Bostanci, 2012).

4.2 Ensemble Classifiers

In this study, combination of classifier with Adaptive

Boosting algorithm (AdaBoost) resulted in higher

accuracy in all classifiers except NaïveBayes, IBK

and RandomForest models, as shown in Table 3 and

4. Moreover, Kappa, MCC and ROC values were

successfully improved in LMT model. Increased

accuracy in BayesNet and SMO was in accordance

with previous study by Akbas

et al (2013).

Improvement of ROC value was obtained only for

SMO model, as shown in Figure 1. None of

performance indicators were improved in

NaïveBayes, IBK and RandomForest models, which

has been similarly found by Akbas

et al (2013).

Merging two algorithms into a combinatorial

classifier can overcome the shortages of individual

classifier. For instance, ensemble classifier generally

has higher accuracy. However, combinatorial

classifier is expected to take a long time in dataset

training (Zaïane and Zilles, 2013).

This is because the

increased data to be stored and the storage must be

conducted after dataset training (Kotsiantis, 2007).

Moreover, two classifiers or more should be run upon

input query. Lastly, although combinatorial classifier

can provide higher accuracy, the relationships

become less comprehensible (the rule learning is not

clear) (Kotsiantis, 2007).

Therefore, ensemble

classifier is recommended only for a purpose of

seeking the highest possible accuracy (Kotsiantis,

2007).

AdaBoost classifies dataset by using a number of

weak classifiers that concentrate on misclassification

of instances obtained from training using various

weight distribution (Elhenawy et al., 2015).

Misclassified instances from a classifier were passed

in the next iteration/training using another classifier,

generating a ‘cascading’ hypothesis (Zaïane and

Zilles, 2013).

These multiple training steps causes

long execution time in AdaBoost classification.

Ensemble classification with AdaBoost would be

even longer. This is the main challenge in using

combination of classifier with AdaBoost (Zaïane and

Zilles, 2013).

Comparison of Decision Tree, Neural Network, Statistic Learning, and k-NN Algorithms in Data Mining of Thyroid Disease Datasets

243

5 TABLES

Table 1: Performance Indicators for Decision Trees (J48

and LMT) in comparison with Neural Network Model

(MLP).

Classifier

Accuracy

Kappa

MCC

ROC

J48 trees

0.994

0.951

0.953

0.987

LMT trees

0.992

0.924

0.927

0.996

MLP

0.973

0.715

0.718

0.971

Table 2: Performance Indicators for Statistic Learning

Method (BayesNet and NaiveBayes), Instance-Based

Learning Method (IBK), Sequential Minimal Optimization

(SMO) and Decision Tree (RandomForest).

Classifier

Accuracy

Kappa

MCC

ROC

BayesNet

0.975

0.761

0.765

0.994

NaiveBayes

0.952

0.401

0.421

0.916

SMO

0.935

0.210

0.318

0.566

IBK

0.922

0.138

0.144

0.640

Random

Forest

0.992

0.932

0.936

0.999

Table 3: Performance Indicators for Ensemble Classifiers

using AdaBoost in combination with Decision Trees (J48

and LMT) in comparison with Neural Network Model

(MLP).

Ada Boost

Classifier

Accuracy

Kappa

MCC

ROC

J48

0.994

0.948*

0.951

0.999

LMT

0.992*

0.932*

0.934*

0.993*

MLP

0.973

0.715

0.718

0.971

* higher values compared to single classifier

Table 4: Performance Indicators for Ensemble Classifiers

using AdaBoost in combination with Statistic Learning

Method (BayesNet and NaiveBayes), Instance-Based

Learning Method (IBK), Sequential Minimal Optimization

(SMO) and Decision Tree (RandomForest).

Ada Boost

Classifier

Accuracy

Kappa

MCC

ROC

BayesNet

0.988*

0.884*

0.886*

0.995*

Naïve

Bayes

0.952

0.401

0.421

0.862

SMO

0.940*

0.375*

0.425*

0.890*

IBK

0.922

0.138

0.144

0.640

Random

Forest

0.993

0.930

0.934

0.999

* higher values compared to single classifier

6 FIGURES

Figure 1: ROC graphics obtained from individual classifier

(blue line) and combined classifier (green line).

Improvement of ROC value was obtained only for SMO

model.

7 EQUATIONS





  

      

(1)

 





 



  



(2)

HEALTHINF 2018 - 11th International Conference on Health Informatics

244

where p

is ratio of cohesions and p

is probability of

cohesion by coincidence







  







  







  



  



  



  



(3)

where TP is the number of true positives, TN is the

number of true negatives, FP is the number of false

positives, and FN is the number of false negatives

 



  

(4)

8 LIMITATION

The limitation of this paper is the pre-processing of

dataset that was not mentioned in details. However,

during running some algorithms compatibility issue

occurred with train and test dataset. WEKA developer

version 3.7.13 addresses this by using class input

mapped classifier. Secondly, this study did not

include statistical comparison of classification

performance and thus, how significant the difference

in performance among all classifiers is unknown.

9 CONCLUSIONS

In this study, Thyroid dataset has been classified

using various decision trees, neural network, Statistic

Learning, and k-NN algorithms. Decision tree J48

model was found to be the best classifier based on

accuracy, Kappa, MCC, and ROC. This model also

outperformed other classifiers used in previous study,

either as single classifier or in combination with

Adaptive Boosting algorithm. Deciding the best

algorithm that can be used in data mining of thyroid

dataset can simply be based on the classification

accuracy, which is the closeness of measured value to

the actual value. The vast majority of studies claimed

that the most common predictor of the optimum

classification algorithm is classification accuracy.

Improved accuracy can be achieved by combining

two classifiers. In this study, integration of different

algorithms into a combinatorial classifier has

successfully overcome the shortages of some

classifiers (SMO and BayesNet). However, there are

considerations to weigh in, particularly the type of

dataset. Moreover, classification using combinatorial

algorithm for large dataset would be a time-

consuming procedure. Therefore, it is suggested that

further study on optimization of combinatorial

classification for numerical, nominal, and discrete

datasets would be very beneficial.

REFERENCES

Akbas

, A., Turhal, U., Babur, S., & Avci, C. (2013).

Performance Improvement with Combining Multiple

Approaches to Diagnosis of Thyroid Cancer.

Engineering, 05(10), 264-267.

Yeh, W.C., Chang, W.W., & Chung, Y.-Y. (2008). A new

hybrid approach for mining breast cancer pattern using

discrete particle swarm optimization and statistical

method. Expert Systems with Applications. Available

online 21 October 2008. 

Olafsson, S., Li, X., & Wu, S. (2008). Operations research

and data mining. European Journal of Operational

Research, 187(3), 1429–1448. 

Mohamadi, H., Habibi, J., Abadeh, M. S., & Saadi, H.

(2008). Data mining with a simulated annealing based

fuzzy classification system. Pattern Recognition, 41(5),

1824–1833. 

Chang, W., Yeh, W., & Huang, P. (2010). A hybrid

immune-estimation distribution of algorithm for mining

thyroid gland data. Expert Systems With Applications,

37(3), 2066-2071. 

Ozyilmaz, L., Yildirim. (2002) T. Diagnosis of Thyroid

Disease Using Artificial Neural Network Methods.

Proceedings of the 9

International Conference on

Neural Information Processing (ICONIP’02), 4, 2033-

2037. 

Giannopoulou, E.G. (2008). Data Mining in Medical and

Biological Research, InTech, November, ISBN 978-

953-7619-30-5. 

Ressom, W., Varghese, R.S., Zhang, Z., Xuan, J., and

Clarke, R. (2008) Classification Algorithms for

phenotype prediction in genomic and Proteomics Front

BioScience. 

Iavindrasana, J., Hidki, A., Cohen, G., Geissbuhler, A.,

Platon, A., Poletti, P.A., Müller, H.J. (2010). Journal of

Digit Imaging, Comparative performance analysis of

state-of-the-art classification algorithms applied to lung

tissue categorization. Depeursinge. 23(1), 18-30. 

Fernandez, A., Duarte, A., Hernandez, R., Sanchez, A.

(2010). GRASP for Instance Selection in Medical Data

Sets. AISC, 74, 53-60. 

Jacob, S.B., Ramani, R.G. (2012). Mining of Classification

Patterns in Clinical Data through Data Mining

Algorithms. International Conference on Advances in

Computing Communiations and Informatics, 997-1003.



Kotsiantis, S.B. (2007). Supervised Machine Learning: A

Review of Classification Techniques. Informatica, 31,

249-268. 

Bostanci, B. and Bostanci, E. (2012). An Evaluation of

Classification Algorithms Using Mc Nemar’s Test.

Advances in Intelligent Systems and Computing,

pp.15-26. 

Comparison of Decision Tree, Neural Network, Statistic Learning, and k-NN Algorithms in Data Mining of Thyroid Disease Datasets

245

Zaïane, O. and Zilles, S. (2013). Advances in artificial

intelligence. Berlin: Springer. 

Elhenawy, M., Jahangiri, A., Rakha, H. and El-Shawarby,

I. (2015). Classification of Driver Stop/Run Behavior at

the Onset of a Yellow Indication for Different Vehicles

and Roadway Surface Conditions Using Historical 

Behavior. Procedia Manufacturing, 3, pp.858-865. 

HEALTHINF 2018 - 11th International Conference on Health Informatics

246
