On the Application of Fuzzy Set Theory for Access Control Enforcement

Diogo Domingues Regateiro,

Oscar Mort

agua Pereira and Rui L. Aguiar

Instituto de Telecomunicac¸

oes, DETI, Universidade de Aveiro, 3810-193, Aveiro, Portugal

Keywords:

Access Control, Fuzzy Set Theory, Database and Information Security.

Abstract:

Access control is a vital part of any computer system. When it comes to access to data, deterministic access

control models such as RBAC are still widely used today, but they lack the ﬂexibility needed to support some

recent scenarios. These include scenarios where users and data can be dynamically added to a system, which

emerged from IoT and big data contexts. Such scenarios include data from network operators, smart cities,

etc. Thus, models that are able to adapt to these dynamic environments are necessary. Non-deterministic

access control models fall into this approach, as they introduce new ways of mapping users to permissions and

resources, but lack the auditing capabilities of deterministic models. In this paper, the usage of these models

will be defended and argued for. In particular, a solution based on fuzzy set theory is proposed as it is thought

to be able to provide some ﬂexibility beneﬁts of non-deterministic models, while giving some assurance to

security experts that the resources are not accessed by unexpected users.

1 INTRODUCTION

Access control has always been an important fea-

ture on any system, be it physical or digital, as it re-

stricts the access to a location or resource in a con-

trolled and selective manner(Shirey, 2007). However,

these types of systems are usually deﬁned with bi-

nary permissions that either allows an entity (a hu-

man or some other system) to access that location/re-

source or not. The most successful access control

models are usually those that mimic real world ways

of managing permissions within the context of their

application, of which the Role-based Access Control

(RBAC)(Ferraiolo and Kuhn, 1992) model takes a

central position in many of them. RBAC maps en-

tities trying to access some resource to a role, a mean-

ingful category within the context of the system be-

ing protected and that determines to which resources

that entity may access to successfully complete their

tasks. This way, RBAC can be seen as a deterministic

model, since given a user its permissions are explic-

itly deﬁned.

However, with the advent of the Internet of Things

(IoT) and 5G, the quantity and complexity of data

available that needs to be stored and processed (big

data) has increased considerably. Classical storage

solutions that deployed these access control models,

such as relational databases, are ill-suited to handle

this issue because the deterministic nature of these

models require a tight mapping between users, per-

missions and objects(Fradique Duarte et al., 2017).

Furthermore, the real world is not always as un-

ambiguous as these models require it to be in their

policies. For example, some documentation from Eu-

ropean projects may not be publicly available, but ac-

cess to some portions of it could be disclosed to ex-

perts researching in some area related to a project.

There is no hard deﬁnition of what makes someone

an expert, so normally it would have to be checked

manually on a case-by-case basis. Fuzzy set theory

can handle vague notions such as expertise or envi-

ronmental risk, allowing it to be much more ﬂexi-

ble with its policies while retaining the auditing ca-

pabilities due to the fact that it still is deterministic in

nature. Non-deterministic models on the other hand

can be much more ﬂexible. They can use machine

learning techniques or probability approaches to han-

dle the vagueness associated with such notions and

classify users on it, allowing access control decisions

to be made. However, they lack auditing capabilities

as permissions can change over time.

Additionally, given a big data scenario, every re-

source must classiﬁed manually if they are to be made

publicly available or not. The application of ac-

cess control when there are potentially millions of re-

sources that are (semi-)structured and heterogeneous

is then problematic, as a user request would have to

be manually veriﬁed to each individual resource. Ma-

chine learning techniques can be used to classify doc-

uments based on their contents, and policies can be

540

Regateiro, D., Pereira, Ó. and Aguiar, R.

On the Application of Fuzzy Set Theory for Access Control Enforcement.

DOI: 10.5220/0006469305400547

In Proceedings of the 14th International Joint Conference on e-Business and Telecommunications (ICETE 2017) - Volume 4: SECRYPT, pages 540-547

ISBN: 978-989-758-259-2

written for each class the documents can be classi-

ﬁed into. There are non-deterministic models that

use machine-learning techniques to make access con-

trol decisions, which can be considered almost like

a black box that takes information about the user re-

questing access, the document to give access to and

outputs an access control decision. There are also

models that make probabilistic calculations if there

are missing attributes(Chen et al., 2016; McGraw,

2009) or models that calculate the risk associated with

a request(McGraw, 2009).

Finally, there are those that use methods based

on fuzzy set theory, classifying users in terms

of fuzzy relations and fuzzy permissions over the

data(Mart

ınez-Garc

ıa et al., 2011). This paper will

explore the usage of fuzzy set theory in more de-

tail and contrast deterministic and non-deterministic

models on their beneﬁts and issues. Furthermore,

the possibility of pairing a fuzzy model with machine

learning techniques as a solution for access control in

highly dynamic scenarios will be proposed as an ap-

plication scenario.

This paper is divided as follows. Section 2 will

provide a short background introduction into some

non-deterministic access control models and tech-

niques. Section 3 will present current state of the

art related these access control models. Section 4

will present arguments in favor of such models and

in particular to fuzzy sets. Section 5 will present the

counter arguments to use such models. Section 6 will

present solution which aims to address some of the is-

sues found, and ﬁnally section 7 will present a brief

discussion.

2 BACKGROUND

As stated, there are scenarios where the manual clas-

siﬁcation of users and data is not practical due to their

dynamic nature. Systems where new users can re-

quest access at any time and/or new kinds of data,

with different structure and information, can be added

at runtime. It has been explained how deterministic

models such as RBAC cannot handle these situations

in a satisfying manner, leaving access to be deﬁned

manually from one user to some data. This section

will introduce three techniques to tackle this problem:

through probabilistic methods; cognitive systems; and

fuzzy set theory.

Probabilistic models(Chen et al., 2016; McGraw,

2009), on the one hand, attempt to some measure

of probability related to the access control decision.

RAdAC attempts to take into account the proﬁle of

the user attempting to access some resource and the

context of the request, such as current thread levels.

From this information, a risk measurement can be cal-

culated for a given request using probabilistic meth-

ods. A policy in this context should state the accept-

able level of risk to grant access, so the calculated

risk measure can be used to reach an access control

decision. These models can also add additional con-

straints to override a high risk request, such as the

operational need. Hence, if a request is allowed to

be executed due to operational need, it can be granted

access regardless of the risk involved.

Cognitive systems, on the other hand, are simi-

lar to a black box that takes user proﬁles and other

inputs to provide an access control decision. This

can be achieved through the usage of machine learn-

ing techniques and other methods such as reasoning,

natural language processing, human-computer inter-

action, etc. This is the simplest method as the model

only needs to be conﬁgured with the appropriate al-

gorithms and then given a sample dataset of access

control decision for training. While this allows for

a request from a new user to be easily processed, it

has some problems since security experts cannot eas-

ily determine what the outcome of an access control

decision will be. More so if the cognitive system is

allowed to learn from the access control decision it

makes, allowing it to evolve over time.

Finally, fuzzy set theory involves sets where its

members might only have partial membership to it.

As an example, consider a liquid in a bottle labelled

as 90% water. The liquid does not have a 90% chance

of being water, but instead it IS 90% water and 10%

something else. Thus, fuzzy set theory is not related

to probabilistic models, as the membership values do

not convey a notion of chance. It allows for more

vague conditions to be used. For example, a fuzzy set

could contain all the temperature values that a room

feel ”hot”. A room being hot is a vague notion, but

nevertheless it is possible to create a function that

more or less models it. This function can take the ex-

act temperature value, also known as the crisp value,

and turn it into a membership degree to the fuzzy set

just described. Hence, a temperature input of 5

could be considered to have 0% membership, at 15

it would start to rise linearly from 0% and when the

input becomes 30

C the membership degree is 100%.

An access control model based on fuzzy set theory is

still deterministic in nature, but it would be able to

model vague conditions that are usually found in the

real world and that are more intuitive to use by hu-

mans.

To ﬁnalize this section, all of these approaches

are valid and can be used to address the problem dis-

cussed, depending on the situation at hand. Proba-

On the Application of Fuzzy Set Theory for Access Control Enforcement

541

bilistic models can be used to handle unexpected situ-

ations, such as missing attributes, or situations where

the access decision must take into account risk related

situations. Fuzzy set theory based models allow poli-

cies to be deﬁned based on the vague conditions that

exist in the world, enabling a more natural way of ex-

pressing said policies. It also has the beneﬁt of clas-

sifying users and data into each deﬁned fuzzy set as

they come into the system in a predictable and reli-

able way. Cognitive systems employ a great variety

of tools, from machine learning to reasoning, to be

able to generate an access control decision based on

the user and the data requested, however the decision

may change over time.

3 RELATED WORK

In the area of non-deterministic access control mod-

els, the techniques and approaches used to achieve

non-determinism can vary signiﬁcantly. (Crampton

et al., 2015) argues that in cases where user attributes

may be missing, the access decision may be incon-

clusive and a probabilistic model is used. This would

lead to more than one decision generated by the ac-

cess control system, a possibility also introduced by

the ABAC access control model. When facing this

scenario, the access control decision process can be

quite complex. Instead of building an entire new eval-

uation mechanism based on probabilities, fuzzy set

theory could assume a membership degree of 0% to

the associated conditions. Depending on the condi-

tions used and the importance of the missing attribute,

the user could still be granted access.

Other non-deterministic models exist in the

literature, such as DRAC (Chen et al., 2016),

RAdAC(McGraw, 2009) and other frameworks(dos

Santos et al., 2016). DRAC proposes a model based

on risk evaluation for the cloud which uses a dynamic

threshold for the risk associated with the request. The

associated risk is calculated based on a sliding win-

dow of the subject’s history. However, it does not

differ much the ABAC model, integrating only the

measured risk into the access control decision mak-

ing. When it comes to handling dynamic users and

data, it suffers from the same problem that determinis-

tic models suffer. RAdAC is similar to DRAC, adding

operational need to the decision making process that

can override a too high risk request. In the end, it also

fails to solve the issues presented in this paper.

In regard to existing deterministic models, ex-

tensions can be made to give them more function-

ality or make the applications built for them more

secure(Pereira et al., 2014; Regateiro et al., 2014).

However, the intent of applying fuzzy set theory to

access control is to create a more ﬂexible determinis-

tic model that is not held back by previous models.

In addition, IBM(IBM, 2016) has also argued that

most information regarding security is written in nat-

ural language, i.e. humans can easily understand it but

machines cannot. This also means that a human can-

not know every bit of information about threats and

other security related information that exists. How-

ever, by using cognitive systems it is possible to an-

alyze this type of information and include it so that,

for example, new threats are accounted for when in-

vestigating some issue. This helps an analyst to have

greater knowledge about the latest security threats,

freeing his time to focus on other issues.

Current solutions such as IBM Watson, Microsoft

Cognitive Services, Google Prediction API and Ama-

zon Machine Learning show how important cognitive

systems are becoming. However, most of these ser-

vices are just APIs that allow to build cognitive ser-

vices. One problem with the cognitive systems is that

the algorithms used are a lot of the times opaque to the

people that use them. This means that it is not pos-

sible to know what the behaviour of the system will

be in every situation, specially when the system can

evolve over time, which can result in the lack of trust

in its correctness. Fuzzy set theory, however, follows

membership functions that can be understood and vi-

sualized, allowing more easily to verify its correct-

ness.

Finally, fuzzy set theory is an idea that has been

researched in recent years to tackle use cases where

authorization-related information is vague. It can be

applied in two different levels(Kacprzyk et al., 2015)

when it comes to its application to access to data:

on the databases(Mart

ınez-Garc

ıa et al., 2011; Prade,

1984; Buckles and Petry, 1982; Ma, 2006) or on the

querying language(Bosc and Pivert, 1995; Bosc and

Pivert, 1992b; Bosc and Pivert, 1992a).

In (Mart

ınez-Garc

ıa et al., 2011) the authors

present an access control model based on RBAC that

is applied on the database level. The model uses fuzzy

sets to model the relations between subjects, roles and

the permissions. Such a model can handle some un-

certainty when it comes to the degree a subject ac-

tually plays a certain role and what permissions are

actually granted. However, this model is restricted to

using the role associated with each user and does not

handle other attributes directly into the access control

process.

An example of the application of fuzzy set the-

ory on the querying language level is SQLf(Bosc and

Pivert, 1995), an extension made from the SQL lan-

guage, where vague querying is achieved on regu-

SECRYPT 2017 - 14th International Conference on Security and Cryptography

542

lar databases. Instead of applying ﬁxed predicates in

queries, such as querying accounts with balances over

some particular number, they can be created that use

fuzzy conditions in the predicates. For example, given

a table with account balances, it would allow to query

for entries where the account balance is high. This

allows for more intuitive queries to be written when

exactness is not needed for the results returned. How-

ever, this approach also does not solve the issue men-

tioned in this paper, as it only applies to the querying

procedure and not the decision-making.

4 GROUNDS FOR FUZZY

ACCESS CONTROL MODELS

One of the arguments used to justify the inclusion of

fuzzy access control models in computer systems is

the fact that the real world is not always unambiguous

by nature, specially when it comes to human inter-

action. This includes human decisions which can be

inﬂuenced by many external factors such as human

language which can convey the same information in a

multitude of ways and is oftentimes vague and depen-

dent on context, emotions, etc.

Access to resources can also be seen as another

form of human interaction. Person A possesses data

that other people want to access, and so person A sets

conditions that must be met for access to be granted

in their policies. When humans enforce the access

control policies, it is possible to process the subjectiv-

ity inherent in some of the access requests. However,

when it comes to computer systems, it is not generally

the case due to their unambiguous nature.

Non-deterministic models allows computer sys-

tems to capture the subjectivity and vagueness of the

human world. These can include the conditions that

do not have a concrete deﬁnition but that are used by

humans constantly in speech, such as the example of

someone being an expert in some area, through train-

ing. While deterministic, fuzzy set theory is particu-

larly good in capturing these vague notions but taking

inputs that can be used to deﬁne them - in the case

of being an expert it would mean values like number

of publications, number of citations, etc - and use a

function to map those inputs into a membership de-

gree. In this sense, a person does not have to either be

an expert or not at all. Instead, someone can be par-

tially an expert, like 40%, working their way higher

but still not considered to be like a person who does

not know anything of said area.

In fact, a policy based on fuzzy set theory can

grant access to someone provided they have some

minimum degree of membership to a fuzzy set. To re-

iterate, fuzzy sets are deﬁned by a domain of elements

and a function that takes values from that domain and

maps them to a membership degree between 0 and

1. Furthermore, fuzzy logic uses a generalization of

two-valued logic to support values any between 0 and

1, meaning that vague conditions can be used together

in logical expressions. Since the logic used is a gener-

alization, a condition that is precise is allowed in such

a model, with membership functions that either out-

put a membership degree of 0 or 1 for a given input.

Thus, it becomes simple to categorize users based on

their attributes and policy deﬁned fuzzy sets automat-

ically. These fuzzy sets can represent the users that

can access a certain resource, with a different fuzzy

set for each permission if required. A defuzziﬁcation

process can then be carried out to map the member-

ship degrees to access control decisions.

Fuzzy-based models also have the beneﬁt of being

easier to audit and analyze when compared to cog-

nitive based solutions. Fuzzy set theory is based on

membership functions to sets, which are well deﬁned.

On the other hand, cognitive systems use a collec-

tion of technologies and methods to learn from infor-

mation and to be able to perform reasoning over it.

For example, a cognitive system, given enough infor-

mation about access attempts and the corresponding

access decision, is able to categorize access requests

and answer with a decision. However, auditing such a

system is hard, as the model used to reach a decision

is based on training data, complex machine learning

techniques and reasoning. As such, a cognitive sys-

tem is many times considered to be a black box in

a system that takes certain inputs and outputs an an-

swer.

Fuzzy set theory is also beneﬁcial for IoT and big

data contexts where a big amount of data is generated

and/or new data-sources can dynamically appear. A

model based on fuzzy set theory can categorize re-

sources based on several attributes, such as its origin,

contents, and other (meta-)information. The classes

that a given classiﬁer classiﬁes resources into can be

deﬁned in the policy. Alternatively, resources can be

classiﬁed beforehand. These classes can then be as-

sociated with the fuzzy sets that denote permissions

within that class, to which a subject must have some

degree of membership to be granted the associated

permissions.

Regarding probabilistic models, they usually out-

put more than one access decision, depending on the

probability values. In the case of the model presented

in (Crampton et al., 2015), missing attributes are mod-

elled as a non-deterministic attribute retrieval process.

The process is extended to be a probabilistic attribute

retrieval and probabilistic tools are used for imple-

On the Application of Fuzzy Set Theory for Access Control Enforcement

543

mentation. While these can possibly be used to imple-

ment a model with similar goals as a fuzzy set theory

based model, it does not exactly support vagueness

in the same way. For example, using a probabilistic

model, a subject can have some chance of being an

expert, but in the end it means that it either is, or it is

not an expert. Fuzzy set theory allows for users to be

partial experts, a notion that is closer to reality.

To summarize, when it comes to scenarios where

the conditions for granting access to data are vague or

there is a high dynamism of users and resources, such

as in IoT and big data scenarios, non-deterministic

access control models pose an interesting solution.

However, models based on fuzzy set theory are able

to handle a large number of new users without the

need for manual permission granting. Furthermore,

resources that are added to the system can be catego-

rized into security classes that, based on the member-

ship degree of a user to one or more fuzzy sets, can

allow those resources to be made available instantly.

Finally, fuzzy set theory allows security experts to au-

dit the correctness of the access control system more

easily when compared to other solutions such as cog-

nitive systems, since membership functions are deter-

ministic and can be analyzed.

5 CHALLENGES AND ISSUES

There are several claims that can be made against non-

deterministic and fuzzy access control models being

used in computer systems. These range from model

speciﬁc issues to the ethics surrounding the fact that

computer systems are being allowed to grant or deny

access to a resource without human intervention.

The ﬁrst issue that can be raised with the usage of

non-deterministic access control models is detailed in

(Matzner, 2016), where the notion of a gap between

the perceived situation between a human and a cogni-

tive system differs. This difference is branded as ”the

model gap”. The model gap itself is not a problem,

but instead it is the main feature of a cognitive system.

Deploying human operators to analyze the output of

a cognitive system is often thought to be enough to

address the ethical problems related with the automa-

tion. Hence, it is important to reﬂect on this model

gap when deploying a non-deterministic model, in

which the presentation and description of the system

are necessary so ethically problematic judgments do

not occur by recognizing the difﬁculty of independent

judgment.

Note that this issue is not conﬁned to non-

deterministic models, but since deterministic models

follow a set of static rules imposed by a human, the

issue is not as great and problems can be resolved

rather easily by a human operator by adding another

rule. Non-deterministic models require an easy way

for a human to control it and grant or deny access

to a user. RAdAC(McGraw, 2009) achieves this by

taking into account the notion of ”operational need”

with a request. If the operational need is allowed by

the policy, then it can override the risk measurement.

Models based on fuzzy set theory can, for example,

do something similar, such as using a fail-safe fuzzy

set that acts like a regular set. Members of this set

are granted membership by a human operator and it

grants the user the associated permission. Another

solution is to add explicit rules just to handle these sit-

uations. Cognitive systems require a human operator

to keep teaching it whether an access control decision

is correct or not, so that wrong access decisions get

corrected.

Auditing can also play a part in the issues these

models face. By becoming more complex, using tech-

niques ranging from algorithms to artiﬁcial intelli-

gence to arrive at access control decisions, it becomes

harder for the policies of these models to be veri-

ﬁed that they behave exactly as intended. Risk-based

models can change their access control decision out-

puts based on the risk levels and cognitive systems

can be setup to learn over time. Fuzzy set based mod-

els can have their membership functions mathemati-

cally checked to determine the inputs where the deci-

sion is grant or deny. However, the formulas involved

can depend on various input variables, so the analysis

may be quite complex as well.

Another fair concern is misconﬁguration of the

models themselves. While deterministic models

tend to be very straightforward in what conditions

can a user access some resource or not, the non-

deterministic are not. Risk measurements procedures

and training datasets all need to be considered for the

access control policies creation. In more complex sce-

narios that involve many variables to grant access to

a resource, slight misjudgments may go unnoticed.

This is why it is important to have a close monitor-

ing of the decisions such a security system makes

so these misconﬁgurations of the policies can be de-

tected. While fuzzy models are deterministic, the

membership functions also need to be carefully de-

signed to represent the vague notions associated with

them.

As mentioned, models based on fuzzy set theory

require membership functions, which are used to de-

ﬁne the fuzzy sets by mapping a membership degree

of an element to the set. These membership func-

tions, in an access control system, can take attributes

of the users as inputs to map them into various fuzzy

SECRYPT 2017 - 14th International Conference on Security and Cryptography

544

sets, which can represent roles, relations, or some-

thing else. Where risk-based models can use thresh-

olds to make the access control decisions (even if the

risk measurement can be quite complex) and cog-

nitive systems automatically create the needed inner

conﬁguration from the training set, models based on

fuzzy set theory do not. Membership functions need

to be deﬁned manually or using some machine learn-

ing method like cognitive systems. While fuzzy set

theory is great at capturing vagueness and vagueness,

it requires some work to create the policies, even if

the membership functions are not usually too complex

and are usually simple truncated triangles in shape.

Since models based on fuzzy set theory require

membership functions, it is important that the at-

tributes a user has can be validated as they are used

to map the users to fuzzy sets. This can be a problem,

since to be sure that the attributes a user has are cor-

rect and have not been modiﬁed, an Identity Provider

(IdP) must exist that can validate and sign them. In

the case of the access to the European project docu-

mentation, trusted Universities could be accepted at

IdPs for their users, as well as citation databases and

other similar entities so that the expertness of a user

can be determined. So, a use case where these kind of

access control model is deployed must consider the

IdP to use for the users.

Finally, computer resource concerns can also be

raised. While models that function by using and fol-

lowing a set of access control rules are usually fast

and not very heavy computationally, cognitive sys-

tems require a big base of information to perform ad-

equately, and since they have to process said informa-

tion base they can be quite computationally intensive

as well. Nevertheless, models based on fuzzy set the-

ory can be less computationally intensive than cogni-

tive systems, since they do not require a large training

dataset to operate. To summarize, when using these

models it is important to keep in mind the ethical is-

sues since machines and humans perceive contexts

differently. Furthermore, the potential for a model

policy to be veriﬁed as being correct should be con-

sidered, as well as the model conﬁguration complex-

ity and how computationally intensive it can become.

6 PROPOSED SOLUTION

A solution, consisting of a possible model and archi-

tecture, will be proposed here that aims to handle the

use cases mentioned thus far. The idea will be for the

system running this solution to take in large amounts

of data while allowing new users to be able to access

them based on vague linguistic notions. Fuzzy set the-

Figure 1: Partial fuzzy inference system diagram example.

ory is able to deﬁne these notions while retaining its

vagueness by allowing users to be partially matched

to them.

6.1 Model

Figure 1 provides a simple diagram of how such a sys-

tem could work. The lower section indicates the in-

put distributions used by the system, which are the

user attributes. These distributions are mapped by

the membership functions into fuzzy sets that model

vague notions, matching a user partially or fully to

them via a membership degree. Then, the member-

ship degree for each notion is used to calculate a rule

strength. This rule strength can then be used to qual-

ify the user in terms of an output notion, such as how

much of an expert the user is. Several of these output

notions can be used, each derived in the same manner,

to arrive at an access control decision.

In the European project documentation example

provided, a user has two attributes, which could be

signed by an University IdP: number of publications

and time since last publication. These are discreet

values, shown as vertical bars on the real number line.

Then, the system would recognize that the re-

source that is being requested has some security la-

bel (not shown in the ﬁgure) that requires the user to

be an expert in an area to be able to access it. A se-

curity label is placed on a resource to indicate which

characteristics the user must possess to be granted a

permission, such as reading access. For this example

system, a user is recognized as being an expert if they

have many publications AND are active researchers

in the area. This would be deﬁned in the policy as a

rule using the fuzzy controller language, for example.

Number of publications and time since last pub-

lication are vague notions. For the system to handle

these, each is mapped to a fuzzy set. In the Figure 1

it is possible to see the membership functions associ-

ated with them in the IF section, and how the num-

ber of publications and time since last publication

of the user are not enough to grant him total member-

ship. In fact, it is possible to say that the user is close

On the Application of Fuzzy Set Theory for Access Control Enforcement

545

Figure 2: Fuzzy set based model architecture.

to having many publications according to this policy,

around 80%, but is only around 50% active. Never-

theless, the policy still recognizes the user as being

partially an expert - around 50% - given the provided

rule strength, which was calculated by applying the

AND operator on both membership degrees, which

takes the smallest of the two.

What is left is to arrive at the access control de-

cision. This is a simple case where only one rule

is used, but note how there is a function under ”ex-

pert”. This function is known as an output member-

ship function and it is truncated at the rule strength.

From it, a value z∗ from the z domain is chosen as

an output value using a process known as defuzziﬁ-

cation. There are many methods to achieve this de-

pending on the use case, but as an initial approach, a

threshold z

value could be used. Then, z∗ could be

obtained by selecting the smallest z value that maxi-

mizes the truncated function. If z∗ < z

, then the user

is denied the permission, else the user would have it

granted. If more than one rule is used, such as the user

having to be an expert and not young, then the func-

tion obtained from the union or the intersection of the

output membership functions of each rule is used.

6.2 Architecture

A possible architecture to implement this model is

shown in Figure 2. This architecture is based on the

XACML architecture, mostly due to its modular ap-

proach, and encompasses several modules and other

components. This is only one architecture amongst

many that could be used. The various modules that

are proposed in this architecture are:

• Subject: A human or service that uses the system.

• Datasource: A source of resources to be pro-

tected by the system.

• Enforcement: The module that enforces access

control decisions.

• Administration: The module that handles ad-

ministration requests, such as the creation and al-

teration of policies.

• RIaC: The Resource Ingestion and Classiﬁcation

module. It handles the resources sent by data-

sources and classiﬁes them to associate security

labels so the system knows which fuzzy sets to

apply to them when access is requested.

• Decision: The module that runs the fuzzy infer-

ence system to arrive at an access control deci-

sion.

• Information: Handles information requests made

by the decision module in its operation, be it from

the deﬁned policies, user attributes or some other

environmental attributes.

• Policy Retrieval: Retrieves policies as needed by

other modules.

• DBI: The DataBase Interface module to access

the datastores. Handles requests for data and poli-

cies.

• Message Bus: A tool used to interconnect all

modules of the system.

A subject, when they need access to some re-

source in some way, sends a request to the enforce-

ment module through some public API along with an

identiﬁer, such as a token. The enforcement module

will then dispatch the request to the decision module

for evaluation. The decision module then requests the

access conditions and associated fuzzy sets to match

the user attributes to the information module, which

will request the required policy to the policy retrieval

module if needed. Finally, the policy retrieval mod-

ule may request the policy from the policy datastore

to the DBI module.

Once the required information propagates back to

the decision module, membership degrees of the user

to the various fuzzy sets are calculated and a ﬁnal ac-

cess decision is made as detailed in section 6.1. The

decision is then sent back to the enforcement module

that enforces the decision made. Administration re-

lated requests are made to the Administration module

instead, which can have an authentication layer. Mul-

tiple instances of each module can be used as well,

allowing the architecture to scale as needed.

Finally, testing such a model and architecture for

correctness can be more challenging since to allow

large amounts of data to be ingested by the system, it

needs to classify each document automatically using

some method. However, assuming that the documents

are well classiﬁed, the correctness of the system can

be assured by analyzing the membership functions

and how the z∗ value depends on the input values pro-

vided.

SECRYPT 2017 - 14th International Conference on Security and Cryptography

546

7 DISCUSSION

In this position paper, a position to use non-traditional

access control models, and in particular fuzzy set the-

ory, was defended and argued for. What makes fuzzy

set theory so interesting is its capability to handle

vagueness and conditions that are vaguely worded.

These types of models were found to have sev-

eral issues, which included the ethical questions of

computer systems and humans perceiving a context

in different ways, their more complex inner workings

which makes auditing the correctness of the policies

harder and the difﬁculty of creating the policies them-

selves. However, these models are capable of han-

dling scenarios with a big amount of users and re-

sources automatically, being an interesting choice for

IoT and big data scenarios. Furthermore, situations

where access conditions are ambiguous or there are

many variables to consider can also be handled.

A solution, comprised of an idea for a model based

on fuzzy set theory and an architecture, was also pro-

posed which aimed to be able to take advantage of

the points raised in this paper while trying to address

some of the issues that were found as well. This solu-

tion will be studied further, especially in terms of cor-

rectness validation, and a working proof of concept is

expected to be implemented in the near future.

ACKNOWLEDGEMENTS

This work is funded by National Funds through

FCT - Fundac¸

ao para a Ci

encia e a Tecnolo-

gia under the project UID/EEA/50008/2013 and

SFRH/BD/109911/2015.

REFERENCES

Bosc, P. and Pivert, O. (1992a). Fuzzy logic for the man-

agement of uncertainty. chapter Fuzzy Querying in

Conventional Databases, pages 645–671. NY, USA.

Bosc, P. and Pivert, O. (1992b). Some approaches for rela-

tional databases ﬂexible querying. Journal of Intelli-

gent Information Systems, 1(3-4):323–354.

Bosc, P. and Pivert, O. (1995). SQLf: a relational database

language for fuzzy querying. IEEE Transactions on

Fuzzy Systems, 3(1):1–17.

Buckles, B. P. and Petry, F. E. (1982). A fuzzy representa-

tion of data for relational databases. Fuzzy Sets and

Systems, 7(3):213–226.

Chen, A., Xing, H., She, K., and Duan, G. (2016). A Dy-

namic Risk-Based Access Control Model for Cloud

Computing. In 2016 IEEE Int. Conf.s on Big Data and

Cloud Comp., Social Comp. and Networking, Sustain-

able Comp., number 2014, pages 579–584.

Crampton, J., Morisset, C., and Zannone, N. (2015). On

Missing Attributes in Access Control. In Proc. of the

20th ACM Symposium on Access Control Models and

Technologies, pages 99–109, NY, USA.

dos Santos, D. R., Marinho, R., Schmitt, G. R., Westphall,

C. M., and Westphall, C. B. (2016). A framework and

risk assessment approaches for risk-based access con-

trol in the cloud. Journal of Network and Computer

Applications, 74:86–97.

Ferraiolo, D. and Kuhn, D. (1992). Role-based access con-

trols. 15th National Computer Security Conf., pages

554–563.

Fradique Duarte, F., Domingues Regateiro, D., Mort

agua

Pereira,

O., and Aguiar, R. L. (2017). On the Prospect

of using Cognitive Systems to Enforce Data Access

Control. In Proc. of the 2nd Int. Conf. on Internet of

Things, Big Data and Security, pages 412–418.

IBM (2016). Cognitive Security White Paper. Technical

report.

Kacprzyk, J., Zadro

zny, S., and De Tr

e, G. (2015). Fuzzi-

ness in database management systems: Half a century

of developments and future prospects. Fuzzy Sets and

Systems, 281:300–307.

Ma, Z. (2006). Fuzzy Database Modeling of Imprecise and

Uncertain Engineering Information (Studies in Fuzzi-

ness and Soft Computing). Secaucus, NJ, USA.

Mart

ınez-Garc

ıa, C., Navarro-Arribas, G., and Borrell, J.

(2011). Fuzzy Role-Based Access Control. Informa-

tion Processing Letters, 111(10):483–487.

Matzner, T. (2016). The model gap: cognitive systems in

security applications and their ethical implications. AI

& SOCIETY, 31(1):95–102.

McGraw, R. (2009). Risk-Adaptable Access Control (

RAdAC ). in:Privilege (Access) Management Work-

shop. NIST–National Institute of Standards and Tech-

nology–Information Technology Laboratory.

Pereira,

O. M., Regateiro, D. D., and Aguiar, R. L. (2014).

Extending RBAC Model to Control Sequences of

CRUD Expressions. Intl. Conf. on Software Engineer-

ing and Knowledge Engineering, (January):463–469.

Prade, H. (1984). Generalizing database relational alge-

bra for the treatment of incomplete or uncertain in-

formation and vague queries. Information Sciences,

34(2):115–143.

Regateiro, D. D., Pereira,

O. M., and Aguiar, R. L. (2014).

Distributed And Typed Role-Based Access Control

Mechanisms Driven By CRUD Expressions. Int. Jour-

nal of Computer Science: Theory and Application,

2(1):1–11.

Shirey, R. (2007). Internet Security Glossary, Version 2.

Technical Report 9.

On the Application of Fuzzy Set Theory for Access Control Enforcement

547
