The Federated Ontology of the PAL Project

Interfacing Ontologies and Integrating Time-dependent Data

Hans-Ulrich Krieger

, Rifca Peters

, Bernd Kiefer

, Michael A. van Bekkum

, Frank Kaptein

and Mark A. Neerincx

DFKI, The German Research Center for AI, Campus D3 2, Stuhlsatzenhausweg 3, 66123 Saarbr

ucken, Germany

Interactive Intelligence Group, EEMCS, Delft University of Technology, Mekelweg 4, 2628 CD Delft, The Netherlands

TNO, Kampweg 5, 3769 DE, Soesterberg, The Netherlands

Keywords:

Knowledge Representation & Ontologies, Description Logics & OWL, Representation of & Reasoning

with Time-dependent Data, Transaction Time, Semantic Interoperability, Integration of Upper & Domain

Ontologies.

Abstract:

This paper describes ongoing work carried out in the European project PAL which will support children

in their diabetes self-management as well as assist health professionals and parents involved in the diabetes

regimen of the child. Here, we will focus on the construction of the PAL ontology which has been assembled

from several independently developed sub-ontologies and which are brought together by a set of hand-written

interface axioms, expressed in OWL. We will describe in detail how the triple model of RDF has been extended

towards transaction time in order to represent time-varying data. Examples of queries and rules involving

temporal information will be presented as well. The approach is currently been in use in diabetes camps.

1 INTRODUCTION

In this paper, we describe ongoing work carried out

in the European project PAL (Personal Assistant for

a healthy Lifestyle) which will improve child’s dia-

betes regimen by assisting the child, health profes-

sional and parent. The PAL system will be composed

of a social robot (NAO), its (mobile) avatar, and an ex-

tendable set of (mobile) health applications . . . which

all connect to a common knowledge-base and rea-

soning mechanism (citation taken from the project’s

homepage; see http://www.pal4u.eu).

The focus of this paper lies on the construction

of an integrated ontology, PALO, the PAL Ontology,

that has been assembled from several independently-

developed ontologies which are brought together

by an interface speciﬁcation, expressed in OWL

(McGuinness and van Harmelen, 2004).

Within

PAL, PALO serves as the common language which

helps to interlink data, delivered from both symbolic

and statistical components of the PAL system.

We will also detail how the triple data model of

The ontologies are publicly available for open re-

search and to other institutions upon request; see http://

www.dfki.de/lt/onto/pal/.

RDF is extended by two further arguments to incorpo-

rate temporal information in order to represent time-

varying data (transaction time). In order to record the

resulting quintuples, they can either be transformed

into a set of semantic-preserving triples when stored

in a triple repository, such as OWLIM (Kiryakov

et al., 2005), by applying, e.g., W3C’s N-ary relation

encoding scheme (Hayes and Welty, 2006), or can be

utilized immediately, when transferred to an n-tuple

repository, such as HFC (Krieger, 2013). In PAL, we

have opted for the latter case for various reasons. In

this paper, we will also sneak a peek on the temporal

entailment rules (Krieger, 2016) and queries that are

built into the semantic repository hosting the data and

which can be used to derive useful new information.

2 ONTOLOGIES

Overall, PALO consists of eight sub-ontologies,

seven of which are truly independent and do not have

knowledge of one another. One further ontology

brings them together through the use of hand-written

interface axioms, employing axiom constructors such

as rdfs:subClassOf and owl:equivalentProperty, or

Krieger, H-U., Peters, R., Kiefer, B., Bekkum, M., Kaptein, F. and Neerincx, M.

The Federated Ontology of the PA L Project - Interfacing Ontologies and Integrating Time-dependent Data.

DOI: 10.5220/0006015900670073

In Proceedings of the 8th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2016) - Volume 2: KEOD, pages 67-73

ISBN: 978-989-758-203-5

by posing domain and range restrictions on certain

underspeciﬁed properties. It is worth noting that

across the ontologies, each property has been cross-

classiﬁed as being either synchronic, i.e., property in-

stances staying constant over time, or diachronic, i.e.,

changing over time (Krieger, 2010). This property

characteristic can be used, amongst other things, to

check the consistency of a temporal ABox or as a dis-

tinguishing mark in an entailment rule.

When we talk about an ontology here, we have

to make a distinction between information from the

TBox (terminological knowledge), RBox (general in-

formation about properties), and ABox (assertional

knowledge). The TBox and RBox of the PAL do-

main stays constant, i.e., will not change over time.

Only relation instances from the ABox might undergo

a temporal change, e.g., the weight of a child at cer-

tain times, but not the birthdate.

2.1 HFC

HFC is a bottom-up forward chainer and semantic

repository implemented in Java, comparable to popu-

lar systems such as Jena and OWLIM. HFC supports

RDFS and OWL reasoning

a la (Hayes, 2004) and (ter

Horst, 2005), but at the same time provides an ex-

pressive language for deﬁning custom rules, involving

functional and relational variables, complex tests and

actions, and the replacement of triples in favour of tu-

ples of arbitrary length. The query language of HFC

implements a subset of SPARQL, but at the same time

provides powerful custom M:N aggregates, not avail-

able elsewhere. In PAL, we are using HFC to store

universal knowledge (TBox, RBox), to query time-

varying data (ABox), and to reason about temporal

change. This is explicated in detail in Section 3.

2.2 Upper

PAL makes use of a minimal and stripped-down up-

per ontology that we have originally developed for

the EU projects MUSING, MONNET, and TREND-

MINER (Krieger and Declerck, 2014), showing a

tri-partite division of the most general class Entity,

viz., upp:Abstract, upp:Happening, and upp:Physical.

Most notable for PAL is the upp:Happening rep-

resentation which distinguishes between atomic

upp:Situations and decomposable upp:Events, using

properties such as upp:startsWith, upp:continuesWith,

and upp:endsWith. This allows us to encode

PDL-like processes and makes it also possible to

deﬁne pre- and post-conditions. upp:Happenings

are upp:basedOn upp:Entitys, upp:leadsTo other

upp:Entitys, and upp:involves other upp:Agents.

2.3 DIT++

The DIT++ ontology is based on the taxonomy

of dialogue acts, deﬁned by Harry Bunt and col-

leagues (Bunt et al., 2012). The DIT++ taxon-

omy is translated into a subclass hierarchy, led by

the most general class dial:DialogueAct. We have

taken over the general-purpose communicative func-

tions and parts of the dimension-speciﬁc communica-

tive functions. The former dimension involves di-

alogue acts, such as dial:Request, dial:Instruct, or

dial:AcceptSuggestion. The latter contains commu-

nicative acts which help to maintain a dialogue, by

indicating, e.g., dial:AlloFeedback or dial:Pausing.

dial:DialogueActs are equipped with several important

properties, such as dial:sender and dial:addressee. A

dialogue act furthermore incorporates the (shallow)

semantics of a natural language utterance through

property dial:frame. Property dial:follows records

the temporal succession of dialogue acts, whereas

dial:refersTo allows to refer back to previously intro-

duced dialogue acts (e.g., as used in indirect speech).

2.4 Time

The time ontology basically deﬁnes the classes

time:DiachronicProperty and time:SynchronicProper-

ty, making it possible to characterize OWL proper-

ties (via rdf:type) as being able to undergo a temporal

change or not (see Section 2), for instance

dom:birthdate rdf:type time:SynchronicProperty

dom:weight rdf:type time:DiachronicProperty

We have furthermore deﬁned the property

time:assign to implement the concept of an impera-

tive, programming language variable that can change

over time and whose time series needs to be recorded.

Such functionality is used in PAL in the dialogue pro-

cessing module (see Section 4.1).

2.5 Logic

The representation of transaction time in Section 3

needs to talk about the truth (= >) and falsity (⊥) of

statements. For this, we make use of a logic ontol-

ogy which includes even more general polarity val-

ues, such as don’t know (?) and error (!), arranged in

a class subsumption hierarchy: ! v {>, ⊥} v ?.

2.6 Domain

The domain ontology deﬁnes concepts and rela-

tion which are relevant to the PAL domain, e.g.,

dom:Activity (playing a game, cooking, making a di-

ary entry), dom:Actor (child, family members, health

KEOD 2016 - 8th International Conference on Knowledge Engineering and Ontology Development

professionals), emotional dom:Mood, or (learning)

dom:Goals which progress over time (see Section

2.8). As the child (and its diabetes’ history) is at the

heart of the PAL project, dom:Child is consequently

equipped with a large number of properties, deal-

ing with family relationships, serious issues (hypo-

glycemia symptoms), hobbies, activities, or lab val-

ues. dom:LabValue bundles datatype properties rel-

evant for the initial anamnesis and the diabetes use

case, such as dom:bmi (body mass index), dom:height,

or dom:bsl (blood sugar level). It is worth noting that

such datatype properties usually map to custom XSD

datatypes, designed for PAL (see Section 2.10).

2.7 Semantics

The shallow semantic representation in PAL is

loosely build on thematic relations or roles (Fillmore,

1977), leading to general verb frames and includ-

ing named arguments such as sem:agent, sem:patient,

sem:theme, or sem:manner which can be found

in frameworks, such as VerbNet, VerbOcean, or

FrameNet (Ruppenhofer et al., 2006). These proper-

ties are deﬁned on the very general class sem:Frame

and are domain-restricted by very general classes; for

instance, sem:agent and sem:patient map to the un-

derspeciﬁed class sem:Actor. These general dock-

ing classes will later be interfaced with more speciﬁc

classes from other sub-ontologies by means of inter-

face axioms (Section 2.9). Even though the semantic

representation is almost ﬂat, additional roles such as

sem:purpose (typed to sem:Frame) allow us to build

up nested structures, say for a sentence like OK, you

will be asking (frame: sem:AssigningRole) in a natu-

ral language quiz scenario between robot and child.

2.8 Goal

The goal ontology formalizes diabetes self-

management progression and is based on the Dutch

Diabetes “weet & doe” doelen (know & do goals) as

formulated by the EADV (http://www.eadv.nl/).

These recommendations structure knowledge and

skills supposed to be obtained by the child from

onset to adolescence in order to gradually increase

autonomy. Thus, goals are attuned to age ranges and

are divided into important topics, such as nutrition

and insulin. These goals are translated into sub-

classes of goal:KnowledgeGoal and goal:SkillGoal,

led by the superclass goal:T1DMGoal. One aim

of the PAL system is to support self-management

progression, by offering educational content and

activities. The PAL system objectives that contribute

to diabetes learning goals are deﬁned as subclasses

of goal:SupportingObjectives. Multilingual labels

for Dutch, Italian, and English have been added to

the goal classes as they were used in the dialogue.

Properties, such as goal:hasLevel (the suggested age

range) and goal:hasProgress (capturing percentage

of completion) are deﬁned on the general goal class

goal:Goal. Dependencies between goals are captured

via property goal:requiresAsClass which directly

operates on class objects (see Section 4.2).

2.9 Pal

The PAL ontology ﬁrst of all imports the previously

introduced sub-ontologies, but also deﬁnes interface

axioms in order to properly integrate the distributed

information. This includes, e.g., restricting the do-

main and range of (possibly underspeciﬁed) proper-

ties or identifying (subsuming) classes and properties

across ontologies. For example:

dom:Actor ≡ upp:Agent ≡ dial:Agent ≡

sem:Actor

dom:Goal ≡ goal:Goal v upp:Event

goal:contributesTo v upp:leadsTo

∀ dial:frame . sem:Frame

The ﬁrst axiom identiﬁes the important ac-

tor/agent classes that can be found in the various

ontologies. The second statement makes goal:Goal

(and dom:Goal) a subclass of the very general class

upp:Event from the upper ontology (see Section 2.2).

As a consequence, properties, such as upp:startsWith

or upp:continuesWith, deﬁned on upp:Event become

available in instances of goal:Goal (goals behave

like events, occupying time). The third declaration

deﬁnes goal:contributesTo as a subproperty of the

general property upp:leadsTo and constraints the re-

lation signature from hupp:Happening, upp:Entityi to

hgoal:SupportingObjective, goal:T1DMLearningGoali.

The fourth restriction links the underspeciﬁed dia-

logue act property dial:frame to shallow semantic

frames (see Sections 2.7 and 4 for an example).

2.10 XSD Datatypes

Some of the datatype properties from the domain on-

tology utilize custom XSD types. For instance:

• body mass index dom:bmi, measured in xsd:kg m2

• blood sugar level dom:bsl, either measured in

xsd:mmol L or xsd:mg dL

• diastolic blood pressure dom:dbp, measured in

xsd:mmHg

The Federated Ontology of the PAL Project - Interfacing Ontologies and Integrating Time-dependent Data

3 HANDLING TIME

This section shed some light on the representation of

time-varying data in PAL and the underlying model,

viz., transaction time. We will also look into how

temporal information is utilized in queries and rules.

3.1 Metric Linear Time

In the following, we assume that the temporal measur-

ing system is based on a metric linear time, so that we

can compare starting/ending points, using operators,

such as < or ≤, or pick out input arguments in aggre-

gates, using min or max. We furthermore require that

time is discrete and represented by natural numbers.

The implementation of HFC employs 8-byte long in-

tegers (XSD datatype long) to encode milli or even

nano seconds w.r.t. a ﬁxed starting point (Unix Epoch

time, starting from 1 January 1970, 00:00:00). As a

consequence, given a time point t, the next smallest

or successor time point would then be t + 1.

3.2 Transaction Time

Transaction time (Snodgrass, 2000) makes use of

temporal intervals in order to represent the time dur-

ing which a fact is stored in the database, even though

the ending time must not be known in advance. This

is indicated by the wildcard ? in the database table

below which will later be overwritten by the concrete

ending time.

We deviate here from the interval view by speci-

fying both the starting time when an ABox statement

is entered to the ontology, and, via a separate state-

ment, the ending time when the statement is invali-

dated. For this, we exploit the polarity values > and

⊥ from the logic ontology that we have already intro-

duced in Section 2.5. This idea is shown below for

a binary relation P. We write P(c,d,b,e) to denote

row <c,d,b,e> in the database table P for relation P.

TIME DATABASE VIEW ONTOLOGY VIEW

add: P(c,d,t

,?) add: >P(c,d)@t

overwrite: P(c,d,t

) ——

+ 1 —— add: ⊥P(c,d)@t

As we see from this picture, the invalidation in the

ontology happens at t

+ 1, whereas [t

] speciﬁes

the transaction time in the database. Clearly, the same

transaction time interval for P(c,d) in the ontology can

be derived from the two statements >P(c,d)@t

and

⊥P(c,d)@t

+1, assuming that there does not exist a

⊥P(c,d)@t, such that t

< t ≤ t

(we can effectively

query for this by employing the ValidInBetween test;

see Section 3.4 for its use in a rule).

Extending ontologies by transaction time the way

we proceed here gives us a means to easily encode

time series data, i.e., allows us to record the history of

data that changes over time, e.g., the blood sugar level

of a child (see Section 2.4). The formal foundations

for extending the triple model with transaction time

can be found in (Krieger, 2016).

Given polarity value π = {>, ⊥}, the above state-

ments

π P(c, d)@t

are written in HFC as quintuples, i.e.,

π c P d t

As we opt for a uniform representation, axiomatic

triples from the TBox and RBox of an ontology need

to be extended by two further arguments; for instance,

owl:sameAs rdf:type owl:TransitiveProperty

becomes quintuple

true sameAs type TransitiveProperty ”0”ˆˆlong

We read the above statement as being true (> =

logic:true) from the beginning of time (long int 0 =

”0”ˆˆxsd:long).

Information uploaded into HFC is also backed

up by an external ﬁle. However, entailed informa-

tion, obtained through successive rule applications

(see Section 3.4) is not stored at all, as it can be re-

stored through the same rules again. As a conse-

quence, wrongly-entered information at time t can ei-

ther be deleted directly in case no rule application has

taken place since, or is deleted together with derived

information from a later time t

> t (like a DB roll-

back), followed by an application of the rules.

3.3 Queries and a Use Case

The query language of HFC can be seen as an ex-

tension of a subset of SPARQL towards general n-

tuples. Consider the following quintuple excerpt from

the ABox for Lisa who has undergone anamnesis at

time 5544 and further lab values taken at 5577:

logic:true lisa rdf:type dom:Child ”5544”ˆˆxsd:long

true lisa dom:hasLabValue lv22 ”5544”ˆˆxsd:long

true lv22 dom:height ”133”ˆˆxsd:cm ”5544”ˆˆxsd:long

true lv22 dom:weight ”28.2”ˆˆxsd:kg ”5544”ˆˆxsd:long

true lv22 dom:bsl ”9.0”ˆˆxsd:mmol L ”5544”ˆˆxsd:long

. . . . . .

true lisa dom:hasLabValue lv33 ”5577”ˆˆxsd:long

true lv33 dom:weight ”28.6”ˆˆxsd:kg ”5577”ˆˆxsd:long

We sometimes omit namespaces here in order to make

sure that a quintuple ﬁts into a single paper line.

KEOD 2016 - 8th International Conference on Knowledge Engineering and Ontology Development

true lv33 dom:bsl ”165.6”ˆˆxsd:mg dL ”5577”ˆˆxsd:long

. . . . . .

What this example shows is that the blood sugar

level dom:bsl for Lisa was measured using different

units at different times (cf. Section 2.10). Given that

all possible lab values will not be taken every time a

medical examination takes place, we would neverthe-

less like to know the latest value for each individual

property; for instance in our case, that Lisa is 133 cm

tall (time: 5544), weights 28.6 kg (time: 5577), and

has been measured with a blood sugar level of 165.6

mg/dL also at 5577. This information can be obtained

through the following quintuple-based query which

utilizes the complex aggregate GetLatestValues:

SELECT ?prop ?val ?t

WHERE logic:true lisa dom:hasLabValue ?labvalue ?t &

logic:true ?labvalue ?prop ?val ?t

AGGREGATE ?measurement ?result ?time =

GetLatestValues ?prop ?val ?t ?t

The meaning of SELECT and WHERE does not

differ from SPARQL, except that quintuples are in-

volved instead of triples. AGGREGATE speciﬁes an

aggregate with four input and three output arguments

which sorts the result table obtained from SELECT-

WHERE and headed by h?prop,?val,?ti according to

the last fourth element ?t. It then takes the newest

values h?val,?ti (argument 2 and 3) for each property

?prop (argument 1) and ﬁnally returns the following

table:

?measurement ?result ?time

dom:height ”133”ˆˆxsd:cm ”5544”ˆˆxsd:long

dom:weight ”28.6”ˆˆxsd:kg ”5577”ˆˆxsd:long

dom:bsl ”165.6”ˆˆxsd:mg dL ”5577”ˆˆxsd:long

3.4 Rules

As we have shown in (Krieger, 2016), the entailment

rules for RDFS (Hayes, 2004) and OWL (ter Horst,

2005) can be extended naturally towards a treatment

of time-varying data which mimics transaction time

(Snodgrass, 2000). Here, we will present two such

entailment rules which will derive new information

for the PAL domain. The ﬁrst one deal with proper-

ties and subproperties (see Section 2.9 for two such

properties). The original rule rdfs7x from (ter Horst,

2005) is (we separate the if-then parts by writing ->):

?p rdfs:subPropertyOf ?q

?v ?p ?w

?w ?q ?w

This is exactly the syntax used in HFC for writing

rules. The transaction time extension using quintuples

is quite natural:

logic:true ?p rdfs:subPropertyOf ?q

”0”ˆˆxsd:long

logic:true ?v ?p ?w ?t

logic:true ?w ?q ?w ?t

As we see, the underlined parts of the three clauses

correspond one-to-one to the original rule and all

statements are valid (ﬁrst argument: logic:true). In-

stantiations of the ﬁrst clause will be RBox axioms

which will not change over time, thus we assign

time 0 here, whereas changing time in the other two

clauses is addressed by a coinciding logic variable ?t.

The next rule does not have a counterpart in nei-

ther (Hayes, 2004) nor (ter Horst, 2005). It addresses

a functional property P deﬁned on x whose value y at

time t

is speciﬁed differently at a later time t

by z,

without invalidating y before:

true ?p rdf:type owl:FunctionalProperty

”0”ˆˆlong

true ?x ?p ?y ?t1

true ?x ?p ?z ?t2

error ?x ?p ?y ?t2

error ?x ?p ?z ?t2

@test

?y != ?z

?t1 < ?t2

ValidInBetween ?x ?p ?y ?t1 ?t2

This rule derives that P(x,y)@t

as well as

P(x,z)@t

is an inconsistent (but not a false) state-

ment in case P(x,y) does not get invalidated at t < t

⊥P(x, y)@t. Whether this is the case is checked by

ValidInBetween as explained before in Section 3.2. If

the test succeeds, we mark the inconsistency through

the use of the error modality ! (see Section 2.5) on the

RHS.

4 ONTOLOGY IN USE

We have already presented an use case involving the

ontology in Section 3.3, where a health professional is

interested in obtaining the most recent lab values for

a speciﬁc child. Here, we will look into two further

examples.

4.1 Use Case 2: Dialogue Processing

The natural language dialogue engine in PAL utilizes

sets of reactive if-then-like rules for the various health

applications (e.g., diabetes diary, educational quizzes,

The Federated Ontology of the PAL Project - Interfacing Ontologies and Integrating Time-dependent Data

sorting games). Simpliﬁed, the rules match against

general as well as speciﬁc dialogue situations (= dia-

logue acts enriched by semantics and other informa-

tion; see Sections 2.3 and 2.7) and generate continu-

ations, describing how the dialogue proceeds. Both

the matching information as well as the derived new

information is grounded in time, represented by the

transaction time model presented above, and stored in

HFC . Even though the transaction time model and the

ontology schema lead to a high abstraction level, HFC

queries (Section 3.3) and rules (Section 3.4) would

still be too talkative to be of easy use. Thus the re-

active dialogue rules abstract away from things that

need to be repeated over and over again (e.g., prop-

erties, such as dial:sender or dial:addressee; property

chains; time). Here is an example of such a rule, a

specialization of a general answer:

if (myLastDA <= @Request(Top)

&& lastDA < @Answer(Top)) {

if (lastDA <= @Conﬁrm(Top))

lastDA.dialogueAct = AcceptRequest;

else

lastDA.dialogueAct = RejectRequest;

}

If the sender’s last dialogue act myLastDA is at

least as speciﬁc as dial:Request (see Section 2.3) and

we are given a conﬁrmation by the addressee (stored

in lastDA), the rule will assign a more speciﬁc dia-

logue act, viz., AcceptRequest to the ﬁeld dialogueAct

of variable lastDA; otherwise, RejectRequest is as-

signed. Even though lastDA and myLastDA look like

imperative variables, they are implemented with the

help of time:assign to record time series data (see Sec-

tion 2.4). Furthermore, complex conditions, such as

the subsumption tests above are compiled into com-

plex SPARQL-like ASK queries.

4.2 Use Case 3: Goal Progression

The goal ontology is used to inform the child, its

parents, and the healthcare professionals on the cur-

rent status of self-management, but also to direct

the PAL system to provide suitable content and ac-

tivities. Imagine a child Henk, recently diagnosed

with diabetes and started treatment, including self-

management educational goals. Henk already learned

that insulin intake is needed, thus goal:InsulinIntake is

achieved and is given progress value 1.0. Note how

the domain and goal sub-ontologies interacts (below,

we omit the ﬁrst argument logic:true and the transac-

tion time argument of the quintuple in lack of space):

henk dom:hasTreatment henks

treatment

henks treatment dom:hasGoal insulinIntake henk

insulinIntake henk goal:hasProgress ”1.0”ˆˆxsd:ﬂoat

Henk’s ﬁrst selected objective is to learn to inject

insulin. This requires knowledge on the location for

injection and skills to prepare the insulin pen. Upon

selection of goal:InsulinInjection, the progress value of

this goal and its pre-conditions goal:PreparePen and

goal:InsulinLocation is set to 0.0, as for related sub-

classes of goal:SupportingObjectives:

InsulinInjection goal:requiresAsClass PreparePen

InsulinInjection goal:requiresAsClass InsulinLocation

InsulinLocation goal:requiresAsClass AnswerI1

insulinLocation

henk goal:hasProgress ”0.0”ˆˆxsd:ﬂoat

answerI1 henk goal:hasProgress ”0.0”ˆˆxsd:ﬂoat

preparePen henk goal:hasProgress ”0.0”ˆˆxsd:ﬂoat

While playing a quiz, the PAL system keeps track

of the scores and for each correct answer, the corre-

sponding progress value is updated at a later time:

answerI1 henk goal:hasProgress ”0.2”ˆˆxsd:ﬂoat

After correctly answering all related quiz ques-

tion, the goal is achieved and all connected learning

goals advance progression. Since goal:InsulinLocation

has no other pre-condition, progress is updated

to 1.0. As goal:InsulinInjection also speciﬁes

goal:PreparePen as a further pre-condition via prop-

erty goal:requiresAsClass (see above), it is therefore

progressing to 0.5 (both pre-conditions are equally

important):

answerI1 henk goal:hasProgress ”1.0”ˆˆxsd:ﬂoat

insulinLocation henk hasProgress ”1.0”ˆˆxsd:ﬂoat

preparePen henk goal:hasProgress ”0.0”ˆˆxsd:ﬂoat

insulinInjection henk goal:hasProgress ”0.5”ˆˆxsd:ﬂoat

ACKNOWLEDGEMENTS

The research described in this paper has been partially

ﬁnanced by the European project PAL (Personal As-

sistant for healthy Lifestyle) under Grant agreement

no. 643783-RIA Horizon 2020.

Thanks to Antoine Cully and Maxime Petit (Impe-

rial College London) for the preparation of the PAL

Data Deﬁnition. We would like to thank the reviewers

for their suggestions.

REFERENCES

Bunt, H., Alexandersson, J., Choe, J.-W., Fang, A. C.,

Hasida, K., Petukhova, V., Popescu-Belis, A., and

Traum, D. (2012). Iso 24617-2: A semantically-based

standard for dialogue annotation. In Proceedings of

the Eight International Conference on Language Re-

sources and Evaluation (LREC’12), pages 430–437.

KEOD 2016 - 8th International Conference on Knowledge Engineering and Ontology Development

Fillmore, C. J. (1977). The case for case reopened. In Cole,

P. and Saddock, J. M., editors, Grammatical Rela-

tions. Syntax & Semantics 8, pages 59–81. Academic

Press.

Hayes, P. (2004). RDF semantics. Technical report, W3C.

Hayes, P. and Welty, C. (2006). Deﬁning N-ary relations on

the Semantic Web. Technical report, W3C.

Kiryakov, A., Ognyanov, D., and Manov, D. (2005).

OWLIM – a pragmatic semantic repository for OWL.

In Proceedings of the International Workshop on Scal-

able Semantic Web Knowledge Base Systems, pages

182–192.

Krieger, H.-U. (2010). A general methodology for equip-

ping ontologies with time. In Proceedings LREC

2010.

Krieger, H.-U. (2013). An efﬁcient implementation of

equivalence relations in OWL via rule and query

rewriting. In Proceedings of the 7th IEEE Interna-

tional Conference on Semantic Computing (ICSC),

pages 260–263.

Krieger, H.-U. (2016). Integrating graded knowledge and

temporal change in a modal fragment of OWL. In van

den Herik, J. and Filipe, J., editors, Agents and Artiﬁ-

cial Intelligence, Lecture Notes in Computer Science.

Springer, Berlin. Revised selected papers from the 8th

International Conference, ICAART 2016.

Krieger, H.-U. and Declerck, T. (2014). TMO—the feder-

ated ontology of the TrendMiner project. In Proceed-

ings of the 9th edition of the Language Resources and

Evaluation Conference (LREC).

McGuinness, D. L. and van Harmelen, F. (2004). OWL

Web Ontology Language Overview. Technical report,

W3C.

Ruppenhofer, J., Ellsworth, M., Petruck, M. R., Johnson,

C. R., and Scheffczyk, J. (2006). FrameNet II: Ex-

tended theory and practice. Technical report, Interna-

tional Computer Science Institute (ICSI), University

of California, Berkley.

Snodgrass, R. T. (2000). Developing Time-Oriented

Database Applications in SQL. Morgan Kaufmann,

San Francisco, CA.

ter Horst, H. J. (2005). Combining RDF and part of OWL

with rules: Semantics, decidability, complexity. In

Proceedings of the International Semantic Web Con-

ference, pages 668–684.

The Federated Ontology of the PAL Project - Interfacing Ontologies and Integrating Time-dependent Data
