Archiving Programs for the Future

Alexander Binun, Shlomi Dolev and Yin Li

Department of Computer Science, Ben-Gurion University of the Negev, Beer Sheva, Israel

Keywords: Data Archiving, Long-term Bit Preservation, OISC, Subleq.

Abstract: This paper presents a novel approach for long-term software archiving which is based on preserving

programs as bit blocks. A simple machine that is able to execute a single command is used to interpret these

bit blocks. We suggest to compile the existing programs into the bit representation of the One-Instruction-

Set computer (OISC) command “SUBtract and Branch if Less than or EQual to zero”, shortly Subleq. This

is in order to keep the resulting bit stream using error correcting code in a reliable storage unit. At any

moment, this bit stream can be executed by a simple interpreter that possesses the functionality of a basic

Random Access Machine. Furthermore, a compiler prototype based on an existing compiler and interpreter

is also proposed to convert a program written by a procedural language (e.g., C) into the Subleq assembly

language, and then translates it into a binary executable format. Error correcting is achieved by

supplementing bit streams with Hamming codes. Our scheme nullifies the need to preserve legacy hardware

in order to support/operate preserved software systems thus serving as a program “time capsule” for the

future.

1 INTRODUCTION

Information preservation is one of the most crucial

challenges facing scholarly communities today. We

have large amounts of digital data, such as e-

journals, e-books, emails and blogs that will be

preserved for generations to come. Nowadays, there

are certain programs (National Digital Information

Infrastructure, 2015) and organizations (Research

Information Info, 2015) that are dealing with digital

asset preservation, before technological

obsolescence, or data loss creep in.

Attempts to preserve information for future

generations have been known since the ancient

times, for example ancient Egyptian or Cretan

hieroglyphs and Babylonian cuneiform scripts.

Organized efforts to conserve information for future

generations are observed during the recent centuries.

These efforts manifest in placing and tracking time

capsules (Time Capsule, 2015), i.e. containers of

such information. However, languages do not

become dead and time capsules do not disintegrate

during a short period. Modern works on

computerized long-term data preservation such as

(Campisi et al., 2009) focus mainly on

supplementing data with auxiliary information

needed for proper interpretation (metadata) and

synchronizing metadata.

In this paper, our work is devoted to finding a

uniform solution for the preservation of code, in an

architectural and compiler independent form, in the

extreme, to ensure preservation of codes for a long

time – for decades, centuries, or even for thousands

of years. To put it another way, we suggest to store

program code in a time capsule that should be

opened in the future for technology preservation and

can still be executed in the future. For example,

imagine that we need to run an important program

written in PL/I with DOS on PDP-11, with

procedure written in Pascal for MAC. Obviously,

backward compatibility issues become impassable

barriers for executing legacy programs as time goes

by. Thus, a new paradigm for software repository is

extremely important.

Our approach focuses on different aspects:

 We suggest using a minimalistic and simple

command, namely, OISC machine commands

that can be easily interpreted by any future

machine, or even manually.

 In the longer range future (thousands of years),

people may cease to understand the rationale

behind code, its effects and even the language

used to express the code ideas. We emphasize

the need to develop a universal writing system in

Binun, A., Dolev, S. and Li, Y..

Archiving Programs for the Future.

In Proceedings of the 6th International Workshop on Software Knowledge (SKY 2015), pages 53-57

ISBN: 978-989-758-162-5

order to keep our code today understandable for

future generations.

We assume that the design concepts behind the code

will become less relevant in a certain amount of

years. Our assumption is based on the fast pace of

software evolution. In the 1970s efficiency was

amongst the major requirements for C programs

which were often enriched by assembly fragments.

Nowadays, thanks to modern and powerful

computers, (that can endure huge libraries)

readability and maintainability have become

“affordable” and actual issues. The design rationale

behind modern OO libraries (such as Java Beans)

may become less relevant in the upcoming 30-40

years but sometimes we might be willing to run

programs based on these libraries. We need to be

able to understand the execution effects rather than

the design details of old programs.

We therefore focus on bit preservation, i.e., the

ability to restore the bits of a program stored for a

long period of time and obtain their effect, namely,

run the bytecode of the restored program. The bit-

level interpreter should thus embody some

fundamental computing ideas based on bit

manipulation (e.g., Random Access Machine,

Goldstine et al., 1947)). This concept is powerful,

simple to simulate, efficient (with relation to Turing

machine) and has not be changed (and will probably

not change) since the beginning of the computer

science era.

However, there are several challenges for long-

term code preservation as in (Factor et al., 2009).

These are storage media degradation, hardware

obsolescence and hardware failures. These

drawbacks are aggravated by targeted attacks against

media systems staged by malicious parties. As a

result, corrupted data may be fetched from the

storage. To address this challenge, we use the

Subleq machine as in (Mazonka et al., 2011) as an

appropriate format for keeping and running code.

Redundancy is also employed when storing the data,

augmenting data with error correcting information.

The use of error correcting codes enables integrity

checks and correction during data access. One

possible error correcting code is Hamming code that

can be utilized for the preservation of every bit of a

command.

RAM based Subleq is proven to be Turing-

equivalent and therefore capable of expressing code

for any feasible computation. In our scheme any

code is converted into the Subleq assembly format

and then into a bit stream. Such bit streams enriched

with the Hamming error-correcting codes (Arazi,

1988) are placed into media storage units (e.g., CD-

ROMS, or even into a plate with Braille style marks

on a surface).

The second challenge is to ensure that our

descendants in future will want to learn more about

our lives and will be able to do so. Even if we focus

solely on execution effects, what is the input/output

format? Textual input/output is usually expressed in

some modern language (today mostly in English).

Images and sound might be based on modern

cultural references (like modern computers, cars).

With that being said, modern languages and other

cultural references may be forgotten in the future,

sharing the destiny of undeciphered ancient scripts.

A possible solution would be to propose a set of

visual or tactile signs allowing any language group

to express their own utterances; that is, using a

universal writing system (Universal Writing System,

2015). Possible inputs/outputs can be translated into

this system and deciphered in the future. There is a

clear need to bring together computer scientists,

linguists, psychologists etc. into the joint

interdisciplinary project aimed at developing a

universal writing system.

Paper Organization. Section 2 outlines the

principles behind preserving code excerpts as bit

streams. It includes compiling any procedural

language into the Subleq assembly language and

further into bytecode as well as integrating error-

correcting capabilities. Section 3 outlines the main

idea behind the usage of a universal writing system

in our context and provides an example of a simple

C program converted into the bit stream format.

Finally, some conclusions are drawn in Section 4.

2 PRESERVATION OF CODE

EXCERPTS

2.1 Keeping Code as Bit Stream

A Subleq program represents an infinite array of

memory cells, where each cell holds an integer

number. This number can be an address of another

memory cell. The Subleq interpreter considers this

array as a sequence of instructions; each instruction

has 3 operands: A,B,C. An operand may be either

an integer number or a symbolic label describing a

memory address. Execution of a Subleq instruction

subtracts the value in the memory cell at the address

stored in A from the content of a memory cell at the

address stored in B and then writes the result back

into the cell with the address in B. If the value after

subtraction in B is less than or equal to zero, the

SKY 2015 - 6th International Workshop on Software Knowledge

execution jumps to the address specified in C.

Otherwise, the execution continues to the next

instruction, which is the address of the memory cell

next to the current cell.

We use the compiler that accepts a simplified

version of C language (mentioned as Higher Subleq

in (Mazonka et al., 2011)) that is referenced

throughout the article as the compiler. Higher

Subleq does not have a preprocessor, does not

support structures, bit fields, abstract declarations

and bit operations. It has only one underlying type

int. Depending on the configuration the compiler

can produce:

 A Subleq assembly language module.

 An executable Subleq module. It is assumed that

the address of the first instruction in a Subleq

assembly program is zero so every Subleq

instruction is converted into a triple of integer

numbers.

We configure the compiler to transform a program

written in a high-level language into an executable

Subleq module. Then we convert the integer

numbers of this module into the binary format. Thus,

eventually a program written in a high-level

language is converted and stored as an array of bits.

There are a number of high-level languages that

possess similar syntax and semantics for basic

operations. Based on the similarities and the

modularity of the compiler, it can seamlessly adapt

to many procedural languages.

2.2 Using Error-correcting Codes

Long-term preservation of bit streams may be

challenged by storage media degradation, hardware

obsolescence and hardware failures (Factor et al.,

2009). Media systems may be also attacked by

malicious users. As a result, the stored bits that need

to be interpreted may be corrupted.

To preserve the integrity of bit streams we stored

those streams using Hamming error-correcting codes

as in (Arazi, 1988). We omit the details of Hamming

codes as it is a classical basic error-correcting code;

in fact we can use any other code. The storage

system recognizes code excerpts by their IDs.

Periodic storage scans of stored bit streams can

exploit its redundancy, preserving the data integrity.

When a user wants to retrieve a code excerpt, the

corresponding excerpt ID is sent to the storage

system. The required excerpt with error correction

codes is fetched. When a bit stream arrives at the

interpreter site, Hamming codes are stripped off,

necessary correction is performed and the “clean” bit

stream is executed.

3 A UNIVERSAL WRITING

SYSTEM

All natural languages carry a lot of irregularities in

grammar which make them more difficult to learn.

They are also associated with the national and

cultural dominance of the nation that speaks it as its

mother tongue. Therefore creating an artificial or

constructing language lies at the core of an approach

of universal language where people from different

nations can communicate, just like numbers and

calculations became universal.

The notion of “phoneme“, that is a single “unit”

of sound that has meaning in any language is at the

heart of the ongoing efforts to devise a universal

writing system. This is because pronouncing of

individual letters may differ in various languages

and depend on their context; English is known for

many irregularities and exceptional cases.

It should be noted that writers of ancient

manuscripts did not invest decent efforts in making

their writing understandable for future generations.

As a result, some dead languages (e.g., Cretan

hieroglyphs) still remain undeciphered. The ancient

Egyptian hieroglyphs were not deciphered until

several stones with bilingual writings in two

languages (Egyptian and ancient Greek) were found

(the so-called Rosetta Stones). Ancient Greek was

known to archaeologists and served as a universal

writing system when deciphering Egyptian.

As a first attempt to instruct our descendants how

to use our storage system, we suggest to use the

pictogram approach, to draw several pictures

describing an operator executing a program. We thus

will be following ancient Egyptians whose

hieroglyphs carried intuitive sense (e.g., the

hieroglyph “king” resembles a king, one can even

recognize the crown, see Figure 1).

Figure 1: The picture of crown represents ‘the King”.

3.1 A Simple Program Written as a Bit

Stream

In this subsection, we give a very simple example to

show the whole procedure of our scheme. Consider

the following simple program written in Higher

Subleq:

Archiving Programs for the Future

int main(void){

int x=0;

x=x-2;

}

The Subleq assembly code for this fragment is.

main:

c1 x ?

x=x-2;

. x:0 c1:2

 The semantics behind the Subleq code is: The

row starting from “.” denotes the data section

where variables are initialized. Thus x gets the

value 0, the constant 2 is placed into the variable

“c1”.

 The instruction “c1 x ?“ performs subtraction

of the value stored at the address denoted by

“c1” from the value stored at the address

denoted by “x”. Afterwards the execution

proceeds to the next instruction (whose address

is denoted by “?”).

The bytecode (and the bit stream resulting from it)

are obtained by setting the address of the first

instruction to 0. We assume that 2-byte integer

numbers hold actual addresses.

The actual address of “x” is resolved to 402,

the actual address of “c1” is 404, the instruction

following “c1 x ?” has the address 350. The

instruction bytecode has the form “404

402 350”. The corresponding bit stream is:

0000000110010100

0000000110010010

0000000101011110

If we use the Hamming (7,4)-code principle to add

redundant bit for error correcting, the above bit

stream is extended as follows:

0000000 1101001 0011001

0101010

0000000 1101001 0011001

1001100

0000000 1101001 0100101 0010110

In above codes, every 4 bits are extended into 7 bits,

the bits underlined are additional parity bits that we

added.

3.2 Visual Puzzle Styled Manual Guide

As mentioned previously, we use a pictogram to

explain our operations and ideas. More explicitly, a

“user manual” is needed to explain the process and

should be stored as a part of the record.

Here, we can follow the rule of visual puzzles to

write such a manual. For example, the following

figure gives a manual for Subleq

Figure 2: The visual manual guide for Subleq.

In the above figure, we use different types of

arrows to show one Subleq command step by step,

and describe the way it is manipulated. For the sake

of simplicity, Figure 2 does not include a visual

puzzle for explaining the subtractions operation and

comparison. One can easily add related con- tents to

make these operations comprehensible. The manual

for Hamming error correcting code could be made in

a similar fashion.

In the future, when people want to recover the

program, they first check the integrity of the bit

stream using these parity bits. Then, they delete

these parity bits and recover the original bits

stream. Intelligent people should be able to follow

the visual puzzle manual and recover the whole

program, with the input and output.

4 CONCLUSIONS

This paper proposed a new prototype for program

archiving for the future. The OISC command Subleq

is used to simplify the classic complex program

codes and Hamming error-correcting code to protect

the program itself. Meanwhile, visual puzzles are

utilized to design instruction manual. All these tricks

form an alternative universal writing system. This

scheme allows us to archive various programs

without preserving different hardware and software

platforms, allowing for future execution by future

generations of computers. At last our scheme can be

used as an Arecibo message as in (Arecibo Message,

2015).

SKY 2015 - 6th International Workshop on Software Knowledge

ACKNOWLEDGEMENTS

We thank Oleg Mazonka for providing us with the

Subleq compiler prototype and for giving thorough

explanations regarding its usage. We thank the

support of the Rita Altura Trust Chair in Computer

Science. We also indebted to the Lynne and

William Frankel center for its generous support.

REFERENCES

B. Arazi, 1998. A Commonsense Approach to the Theory

of Error- Correcting Codes. Computer System Series,

The MIT Press, ISBN-10:0262010984.

P. Campisi, E. Maiorana, E. Ducci Teri, A. Neri, 2009.

Challenges to long-term data preservation: a glimpse of

the Italian experience. In DSP’09: Proceedings of the

16th international conference on Digital Signal

Processing. Pages 120-127, IEEE Press, Piscataway,

NJ.

M. Factor, E. Henis, D. Naor, S. Rabinovici-Cohen, P.

Reshef, S. Ronen, G. Michetti and M. Guercio, 2009.

Authenticity and Provenance in Long Term Digital

Preservation: Modeling and Implementation in

Preservation Aware Storage. In TAPP09: First

Workshop on on Theory and Practice of Provenance,

Pages 6:1-6:10, San Francisco, USA.

H. H. Goldstine and J. von Neumann,1947. Planning and

Coding of the Problems for an Electronic Computing

Instrument. Institute for Advanced Study, Princeton.

McGraw-Hill Book Company, New York.

O. Mazonka and A. Kolodin,2011. A Simple Multi-

Processor Computer Based on Subleq. In CoRR,

Volume 1106.2593.

Time Capsule, 2015. http://en.wikipedia.org/

wiki/Time_capsule

A Universal Writing System, 2015.

http://www.omniglot.com/pdfs/phonbook.pdf

National Digital Information Infrastructure, 2015.

http://en.wikipedia.org/wiki/National_Digital_Informa

tion_Infrastructure

Research Information Info, 2015. http://

www.researchinformation.info/features/feature.php?

feature_id=506

Arecibo Message, 2015. http://en.wikipedia.org/

wiki/Arecibo_message

Archiving Programs for the Future
