On the Need for Federated Authorization

in Cross-organizational e-Health Platforms

Maarten Decat, Dimitri Van Landuyt, Bert Lagaisse and Wouter Joosen

iMinds-DistriNet, KU Leuven, 3001 Leuven, Belgium

Keywords:

e-Health, Security, Access Control, Federated Access Control, Authorization.

Abstract:

Health care is currently witnessing increased specialization as well as a need for integrated care delivery. As a

result, care organizations should collaborate and in order to facilitate this, e-health collaboration platforms are

being created. Access control is a primary concern for such cross-organizational platforms and efﬁcient access

control management is crucial to their adoption. Federated access control is a potential technique to achieve

this and our experience in multiple research projects shows that federated authorization is an essential building

block for future collaboration platforms. However, this technology still faces open research challenges. This

paper wants to spark research on these challenges by motivating the need for federated authorization in the

context of a real-world collaborative care platform. Based on this case study, we also discuss the state of the

art and present a set of key requirements to realize wide-scale adoption of federated authorization in practice.

1 INTRODUCTION

Health care is increasingly being delivered as a col-

laborative effort between multiple specialized care or-

ganizations and in order to facilitate this, collabora-

tive e-health platforms are being created. For exam-

ple, Vitalink (Vitalink, 2013) facilitates the sharing

of medication and vaccinations of patients between

medical professionals. Another example is OCare-

CloudS (OCareCloudS, 2014), a research project that

aims to facilitate information sharing between the

multiple organizations that provide home care to a

certain care receiver.

A primary concern in these collaboration plat-

forms is security. The data that are shared amongst

the care organizations concern patients and as a result,

data protection legislation applies. Cryptographic

techniques can provide storage and transmission se-

curity, but in order to share data in a controlled way,

application-level access control is required as well.

The goal of access control is to limit the access

of users to the resources in the application by enforc-

ing the access control policies of the organization that

controls these resources (Samarati and de Vimercati,

2001). Access control is therefore highly interrelated

with the user management of that organization: user

accounts have to be created, access control policies

have to be deployed and the access control data of

users have to be managed. Examples of these data

are the names of users, their roles in the organization,

their birth date, their location, their department, their

shifts, their assigned patients etc.

However, realizing access control for a collabo-

ration platform is challenging because of the multi-

ple organizations involved. These organizations often

share the ownership of the data and should all be able

to express their access constraints. However, these or-

ganizations remain separate domains in terms of ad-

ministration and security, and do not necessarily trust

each other completely. Amongst others, this leads to

challenges such as sharing the identities of users be-

tween these organizations, integrating the multiple ac-

cess control infrastructures, and evaluating the access

control policies in a way that performs well and keeps

the sensitive access control data of all organizations

conﬁdential. This paper is not the ﬁrst to identify

these challenges, e.g., (Poortinga-van Wijnen et al.,

2010), but as we will show, not many of them have

been addressed properly.

Federated access control is a potential answer

to these challenges. While federated authentication

is an established technology (e.g., (OpenId, 2013)

and (SAML, 2005)), our experience with the OCare-

CloudS research project shows that federated autho-

rization is necessary to address these challenges com-

pletely. Similar to federated authentication, federated

authorization externalizes policy evaluation from an

application. In the short term, this technique is re-

540

Decat M., Van Landuyt D., Lagaisse B. and Joosen W..

On the Need for Federated Authorization in Cross-organizational e-Health Platforms.

DOI: 10.5220/0005264905400545

In Proceedings of the International Conference on Health Informatics (HEALTHINF-2015), pages 540-545

ISBN: 978-989-758-068-0

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

quired for the adoption of collaborative platforms by

large organizations that require centralized user man-

agement. In the long term, it enables efﬁciently eval-

uation of cross-organizational policies while keeping

sensitive access control data conﬁdential.

However, while the concept of federated autho-

rization is fairly intuitive, its realization still poses

many challenges by itself, especially in realistic fed-

erations. Therefore, we want to spark research on

federated authorization by motivating the need for it

using the case study of the OCareCloudS collabora-

tion platform. Although this paper focuses on a sin-

gle case study, our research on federated authorization

is based on and validated in multiple application do-

mains (PUMA, 2014; SPARC, 2014).

The remainder of this paper is structured as fol-

lows: Section 2 describes the case study of the collab-

orative care platform. Section 3 illustrates the need

for federated authorization in this case study. Sec-

tion 4 extrapolates a set of key requirements for fed-

erated authorization. Section 5 concludes this paper.

2 CASE STUDY: A

COLLABORATIVE CARE

PLATFORM

The case study focuses on a software platform that

aims to streamline home care by improving the com-

munication between the multiple involved organiza-

tions. The platform therefore digitizes the informa-

tion that these organizations share, such as prescrip-

tions of and notes about the care receiver.

Together, the various organizations involved in the

collaboration platform behave as a federation. This

means that these organizations have set up collabora-

tion agreements, but still remain separate domains in

terms of security and administration, and do not nec-

essarily trust each other completely.

Figure 1 illustrates the federation of organizations

involved in the care platform. While this ﬁgure only

illustrates a part of the complete federation, it al-

ready shows that a large amount of organizations is

involved, such as general practitioner practices, elder

homes, daily care organizations, physiotherapist prac-

tices, home nursing organizations, hospitals and cater-

ing services. Some of these are directly involved (e.g.,

the meal delivery service), but others get involved be-

cause of business relationships with directly involved

organizations (e.g., the caterers) or because of the in-

tegration of the platform with the Electronic Health

Record (EHR) for sharing patient data on a wider

scale (e.g., other hospitals). Figure 1 also illustrates

Family, friends,

neighbours, ...

General

pracitioners

Caterer 1

Caterer 2

Meal

delivery

Physio-

therapist

Care

Platform

Hospital 1

Service

flats

Facebook

EHR

Hospital 2 Hospital 3

Pharmacists

Medical

imaging

...

Figure 1: Part of the federation of organizations involved in

the collaborative care platform. As shown, such a platform

quickly leads to a federation of a large amount of organiza-

tions and individuals of different nature.

that the organizations in the federation are of very dif-

ferent nature, ranging from core-medical (e.g., gen-

eral practitioners and hospitals) to supporting (e.g.,

caterers), and from large organizations (e.g., hospi-

tals) to small organizations (e.g., a medical imaging

practice) and even individuals (e.g., family, friends,

general practitioners). Moreover, this federation is

dynamic in the sense that new organizations can join

the federation over time or others can leave.

The remainder of this section outlines the speciﬁc

access control challenges that arise in the context of

such large and complex federations.

2.1 Access Control Challenges

While the collaboration platform enables easier cross-

organizational information sharing, the data in this

platform are sensitive, personal and medical. There-

fore, the platform should also enable more controlled

information sharing. To achieve this, the collabora-

tion platform performs access control, which limits

the actions (e.g., read, write) that a user can take on a

resource in the system (e.g., notes about the status of

a patient) by enforcing access rules that are speciﬁed

in access control policies (e.g., (OASIS, 2013)).

In the federation of the platform (see Figure 1),

there are three types of access control policies:

1. Intra-organizational: Firstly, the care organiza-

tions want to constrain their own employees. For

example, the hospital imposes that each of its

nurses can only view data of care receivers ex-

plicitly assigned to him or her, which depends on

internal task assignment.

OntheNeedforFederatedAuthorizationinCross-organizationale-HealthPlatforms

541

2. Inter-organizational: Secondly, the care organi-

zations want to control which other organizations

are allowed to access their data. For example, the

hospital trusts the meal delivery service, but not a

private hospital that also uses the platform.

3. Cross-organizational: Thirdly, the platform itself

imposes access control polices that apply to all or-

ganizations and individuals using it. For example,

these policies can impose that medical data can

only be read by medical professionals that are not

family members of the related patient, unless ex-

plicitly allowed by that patient.

Enforcing these policies in the federation requires

collaboration because each of the involved organi-

zations remains a separate domain of administration,

i.e., each organization manages its own users and has

its own access policies. As a result, the access con-

trol policies and the data required to evaluate them

are spread over the multiple organizations. Conse-

quently, multiple organizations are involved in eval-

uating these policies. Moreover, these organizations

do not necessarily trust each other with their access

control policies or data.

This collaborative decision making causes many

challenges. Semantically, it leads to challenges such

as how a single user can be identiﬁed as the same user

by these multiple organizations, and how the policies

of one organization can reason about the users of an-

other organization while for example the meaning of

the role “nurse” can differ substantially in different

organizational contexts. Technically, it leads to chal-

lenges such as how the different user management and

authorization infrastructures employed by the organi-

zations can interact, and how this federated decision

making can provide suitable performance if commu-

nication is required between multiple separate organi-

zations. And in terms of trust, it leads to challenges

such as expressing trust in the other organizations

in the federation, allowing each organization to keep

sensitive access control data conﬁdential from orga-

nizations it does not trust, and achieving correct deci-

sion making while the trustworthiness of the data re-

ceived from another organization can vary, e.g., Face-

book versus a university hospital.

Prior to this work, other authors have also dis-

cussed challenges for access control in a federated

context (e.g., (Colombo et al., 2010; Freudenthal

et al., 2002; Poortinga-van Wijnen et al., 2010;

Chakraborty and Ray, 2006)). However, a large part

of these challenges still remains and our experience

shows that the technique of federated authorization is

a necessary building block to address these. However,

this technique still poses challenges by itself. There-

fore, this paper focuses on the need for federated au-

thorization in order to spark research on this topic.

3 THE NEED FOR FEDERATED

AUTHORIZATION

As mentioned, we believe that federated authoriza-

tion is an important enabler for access control for fu-

ture collaborative applications. In the short term, fed-

erated authorization is necessary to enable organiza-

tions to effectively enforce their intra-organizational

policies on remote applications such as the care plat-

form. In the long term, federated authorization is

necessary to address the challenges related to perfor-

mance and conﬁdentiality of policy evaluation across

the federation.

Let us start by illustrating the need for federated

authorization in the short term. To do this, we fo-

cus on a simpliﬁed version of the complete federa-

tion consisting of three organizations (see Figure 2):

(i) a small physiotherapist practice that helps care re-

ceivers with physical exercises, (ii) a mid-size meal

delivery service that delivers hot meals on a daily ba-

sis and (iii) a large hospital that is responsible for

medical examinations and treatments. As said, these

three organizations collaborate via the care platform.

For example, the meal delivery service visits care re-

ceivers most often and can notice that they are not eat-

ing well or are complaining about the effects of their

medication. This is important information that should

be shared with the other organizations.

For the point of all three care organizations the

care platform behaves as a remote web application:

the data in the application are located outside of the

premises of the organizations and the platform is ac-

cessed using a web-based interface. However, the

three organizations involved in this example are very

different in terms of how they typically manage their

own users for this remote application: (i) The physio-

therapist practice is a small organization of only three

physiotherapists and does not have IT infrastructure

yet. Therefore, it chooses to deﬁne and manage their

user accounts on the platform itself. As a result, the

Care Platform

Application

data

Physiotherapist

practice

User

data

Hospital

User

data

Meal delivery

service

User

data

AuthZ

service

Figure 2: A simpliﬁed version of the federation of organiza-

tions involved in the collaborative care platform consisting

of three organizations of different size.

HEALTHINF2015-InternationalConferenceonHealthInformatics

542

platform also hosts the user data of the physiothera-

pist practice. While this approach duplicates user data

for every application that the physiotherapist practice

employs, the resulting management overhead is lim-

ited because of the small size of the practice. (ii) The

meal delivery service on the other hand is larger than

the physiotherapist practice. It employs around thirty

caregivers and utilizes its own centralized user man-

agement infrastructure for assigning care receivers to

care givers and managing paychecks and holidays.

(iii) Finally, the hospital is the largest organization of

the three. It employs over three hundred nurses and

physicians. The hospital utilizes a similar infrastruc-

ture for user management as the meal delivery service,

plus a central authorization service for all its applica-

tions. Both the meal delivery service and the hospital

would like to integrate their existing infrastructures

with the platform in order to conserve their efﬁcient

management. For example, adding a new user or ac-

cess rule should only require changes to be made in

exactly one place.

Integrating the collaboration platform with the

user management infrastructures of the meal deliv-

ery service and the hospital can be achieved using

federated authentication techniques (SAML, 2005;

OpenId, 2013). Authentication is the part of access

control that conﬁrms the stated identity of a user, for

example by checking the combination of a username

and password. Federated authentication externalizes

authentication from the platform as shown in Fig-

ure 3. As a result, the user data of the meal delivery

service and the hospital are also externalized from the

platform and can be centralized for all the applica-

tions they employ. Moreover, sensitive data such as

user passwords are not shared with the platform.

However, user management is only part of the

complete access control management. After users

have been deﬁned, the organizations have to specify

the access policies that constrain them. Traditionally,

these policies are deployed on and evaluated by the

Organization

User

data

Care Platform

Appl.

data

Figure 3: High-level overview of federated authentication:

when the user make a request to the platform (step 1), the

platform asks the organization of the user for an authentica-

tion statement (step 2). This organization authenticates the

user locally (e.g., by asking for his password, steps 3 and

4) and returns the identity of the authenticated user to the

platform afterward (step 5).

platform. This approach has the following disadvan-

tages:

• It requires the platform to provide an access con-

trol infrastructure sufﬁciently expressive to sup-

port all rules of all organizations potentially in-

volved in the federation.

• It requires an organization to specify its policies

for every application it employs. This hinders a

new organization to join the federation because

of the larger initial management overhead and in-

creased authorization management afterwards.

• It forces the organization to disclose its policies

and the data required to evaluate them. These

policies may be sensitive because they reason

about competitors, and these data may include in-

ternal information of the organization, which is

sensitive for competitive reasons, or even patient

data, which are sensitive for privacy reasons.

Similar to user management, the increased authoriza-

tion management required for this approach is not

practically feasible for an organization of the size

of the hospital, which requires to reuse or at least

integrate its centralized authorization infrastructure.

Moreover, independent of the size of the organization,

the necessary disclosure of sensitive policies and user

data either limits the expressiveness of these policies

or hinders the adoption of the platform itself.

Federated authorization can address these disad-

vantages, as it externalizes policy evaluation from the

application similarly to federated authentication (see

Figure 4). As a result, federated authorization relieves

the platform of the burden to provide a generic and

complex access control infrastructure. Federated au-

thorization also lowers the initial administration over-

head when a new organization joins the platform since

existing policies and user accounts can be reused.

Moreover, federated authorization conserves the cen-

tralized administration of the hospital, even when us-

ing remote applications. Finally, federated authoriza-

tion enables the hospital to enforce access control on

Organization

User

data

Pol

Care Platform

Appl.

data

Figure 4: High-level overview of federated authorization:

When a user makes a request to the platform (step 1), the

platform asks the organization of the user for an access con-

trol decision (step 2). This organization evaluates its poli-

cies locally (step 3) and returns its decision (step 4), which

the platform enforces afterward.

OntheNeedforFederatedAuthorizationinCross-organizationale-HealthPlatforms

543

the platform without having to disclose its policies or

the data required by them. The main disadvantage of

federated authorization is its complexity. However,

the value of the four beneﬁts listed above grows with

the size of the organization. Federated authorization

therefore is an important enabler for the adoption of

collaborative e-health platforms (and more generally,

remote applications) by large organizations.

As such, this scenario illustrates the need for

federated authorization for enforcing the intra-

organizational policies of an organization on remote

applications. This technique can also be applied to

more complex policies and usage scenarios in the fed-

eration. For example, the cross-organizational poli-

cies imposed by the platform itself require access con-

trol data spread over multiple organizations. For these

policies, federated authorization enables an organiza-

tion to evaluate their part of the complete policy with-

out having to share the data required for this. This

approach can also improve performance of cross-

organizational policy evaluation by evaluating parts of

a policy close to the data they require instead of trans-

porting the data itself, which is especially relevant if

the organizations in the federation have separate IT

infrastructures. As such, federated authorization is a

necessary building block for federated access control

in both short and long term.

4 KEY REQUIREMENTS FOR

FEDERATED AUTHORIZATION

The previous section has motivated the need for fed-

erated authorization in the context of a collaborative

care platform. Federated authorization has been dis-

cussed by other authors, e.g., (Poortinga-van Wijnen

et al., 2010), and initial attempts have been made to

create supporting run-time environments, e.g., (Decat

et al., 2013; Lischka et al., 2009). Moreover, simple

domain-speciﬁc instances of federated authorization

are already used in practice, e.g., for credit card pay-

ments where the bank of the customer is contacted

to authorize the payment. However, while the basic

concept of federated authorization is fairly intuitive,

many open research challenges still remain before it

can be realized in a practical setting, amongst others

because of the complexity of real-life federations as

described in Section 2.1. In the remainder of this

section, we discuss our key requirements for feder-

ated authorization in terms of policy language sup-

port, run-time support and standardization.

Policy Language Support. Existing policy lan-

guages such as XACML (OASIS, 2013) already pro-

vide extensive constructs for specifying access rules

within a single organization. However, these lan-

guages and their underlying models should be ex-

tended to support federated authorization. Firstly,

policies should be able to refer to other organizations

in the federation and incorporate the result of their

policy evaluation. This basic requirement has been

addressed by previous research (Lischka et al., 2009;

Decat et al., 2013). Secondly, these policy languages

should also be extended to support reasoning about

other organizations as a whole. For example, organi-

zations should be able to express their trust in other

organizations in the federation and incorporate this

trust in their access decisions. Thirdly, since real-

istic federations can be large and members can join

and leave frequently, these policies require language

mechanisms that make abstraction of speciﬁc mem-

bers of the federation, e.g., higher-level federation

roles such as “home care provider”, “caterer” or “hos-

pital”. As such, existing paradigms such as role-based

access control (Ferraiolo et al., 2001) and attribute-

based access control (Jin et al., 2012) can serve as a

ﬁrst step to address these challenges.

Run-time Support. Next to specifying policies for

federated authorization, a supporting run-time execu-

tion environment is required, with at its core the pol-

icy engine. In terms of policy evaluation, federated

authorization requires these engines to be able to con-

tact the engines of other organizations. Again, this

basic requirement has already been addressed in liter-

ature (Lischka et al., 2009; Decat et al., 2013). How-

ever, employing federated authorization in practice

requires additional features of policy engines. For ex-

ample, by employing federated authorization, policies

are also evaluated in a distributed fashion. If these

policies have side-effects (e.g., obligations (OASIS,

2013)), some form of concurrency control is required

to ensure correctness. Moreover, while federated au-

thorization can be employed as a performance tactic,

it still entails communication with a remote organiza-

tion. Therefore, it requires performance tactics itself

to keep its latency low, e.g., decision caching, caching

of access data or policy splitting. Since access control

is a security feature, the proven correctness of each of

these tactics is essential.

Interoperability Through Standardization.

Cross-cutting to the above, standardization is key

to the successful adoption of federated authoriza-

tion, especially to achieve dynamic and large-scale

federations. More precisely, federated authorization

requires standardized policy languages, data sharing

formats and access control orchestration mecha-

HEALTHINF2015-InternationalConferenceonHealthInformatics

544

nisms. Initial steps in this direction are currently

being made, e.g., by the OASIS working group on

cloud authorization (CloudAuthZ, 2013).

5 CONCLUSION

In this paper, we motivated the need for federated au-

thorization in the context of a collaborative care plat-

form. Federated authorization is a technique to ex-

ternalize policy evaluation from an application. Fed-

erated authorization is a necessary building block for

access control in the federations of organizations that

arise from current and future inter-organizational col-

laboration platforms. In the short term, this technique

can facilitate the adoption of collaborative platforms

by large organizations which require centralized user

management. In the long term, this technique can

be employed to evaluate cross-organizational policies

efﬁciently while keeping sensitive data conﬁdential.

Although this paper mainly focused on a single col-

laborative e-health platform, our interactions with in-

dustry partners have conﬁrmed the need for feder-

ated authorization in other domains that rely on inter-

organizational collaboration, such as electronic doc-

ument processing (PUMA, 2014) and payment ser-

vices (SPARC, 2014). However, while the concept

of federated authorization is fairly intuitive, there are

still research challenges that should be addressed to

achieve wide-spread adoption. We will continue our

work on these challenges and hope that this position

paper has sparked the interest of other researchers.

ACKNOWLEDGEMENTS

This research is partially funded by the Research

Fund KU Leuven, by the EU FP7 project NES-

SoS and by the Agency for Innovation by Science

and Technology in Flanders (IWT). With the ﬁ-

nancial support from the Prevention of and Fight

against Crime Programme of the European Union (B-

CCENTRE).

REFERENCES

Chakraborty, S. and Ray, I. (2006). TrustBAC: integrat-

ing trust relationships into the RBAC model for access

control in open systems. In SACMAT, pages 49–58.

ACM.

CloudAuthZ (2013). OASIS Cloud Authorization

(CloudAuthZ) TC | OASIS. https://www.oasis-

open.org/committees/cloudauthz/.

Colombo, M., Lazouski, A., Martinelli, F., and Mori, P.

(2010). Access and usage control in grid systems. In

Handbook of Information and Communication Secu-

rity.

Decat, M., Van Landuyt, D., Lagaisse, B., Crispo, B.,

and Joosen, W. (2013). Federated authorization for

software-as-a-service applications. In To be published

in the proceedings of DOA-Trusted Cloud’13.

Ferraiolo, D., Sandhu, R., Gavrila, S., Kuhn, D., and Chan-

dramouli, R. (2001). Proposed NIST standard for role-

based access control. TISSEC, 4(3):224–274.

Freudenthal, E., Pesin, T., Port, L., Keenan, E., and Karam-

cheti, V. (2002). dRBAC: distributed role-based ac-

cess control for dynamic coalition environments. In

DSS, pages 411–420.

Jin, X., Krishnan, R., and Sandhu, R. (2012). A Uni-

ﬁed Attribute-Based Access Control Model Covering

DAC, MAC and RBAC. In Data and Applications

Security and Privacy XXVI, pages 41–55. Springer

Berlin Heidelberg.

Lischka, M., Endo, Y., and Sánchez Cuenca, M. (2009).

Deductive policies with xacml. In Proceedings of the

2009 ACM workshop on Secure web services, pages

37–44. ACM.

OASIS (2013). eXtensible Access Control Markup Lan-

guage (XACML) Version 3.0.

OCareCloudS (2014). OCareCloudS - Overview projects -

iMinds. http://www.iminds.be/en/research/overview-

projects/p/detail/ocareclouds-2.

OpenId (2013). OpenID Authentication 2.0 - Final. http://

openid.net/specs/openid-authentication-2_0.html.

Poortinga-van Wijnen, R., Hulsebosch, B., Reitsma, J., and

Wegdam, M. (2010). Federated authorisation and

group management in e-science.

PUMA (2014). Permission, User Management and Avail-

ability for multi-tenant SaaS applications (PUMA).

http://distrinet.cs.kuleuven.be/research/projects/

PUMA.

Samarati, P. and de Vimercati, S. C. (2001). Access con-

trol: Policies, models, and mechanisms. In Founda-

tions of Security Analysis and Design, pages 137–196.

Springer.

SAML (2005). Security Assertion Markup Lan-

guage (SAML) v2.0. http://www.oasis-open.org/

standards#samlv2.0.

SPARC (2014). Smart Plug-in Automobile Renewable

Charging Services (SPARC). https://distrinet.cs.

kuleuven.be/research/projects/SPARC.

Vitalink (2013). Home | Vitalink. http://www.vitalink.be/.

OntheNeedforFederatedAuthorizationinCross-organizationale-HealthPlatforms

545
