Hybrid POMDP-BDI

An Agent Architecture with Online Stochastic Planning and

Desires with Changing Intensity Levels

Gavin Rens and Thomas Meyer

Centre for Artiﬁcial Intelligence Research, University of KwaZulu-Natal, and CSIR Meraka, Pretoria, South Africa

Keywords:

POMDP, BDI, Online Planning, Desire Intensity, Preference.

Abstract:

Partially observable Markov decision processes (POMDPs) and the belief-desire-intention (BDI) framework

have several complimentary strengths. We propose an agent architecture which combines these two powerful

approaches to capitalize on their strengths. Our architecture introduces the notion of intensity of the desire

for a goal’s achievement. We also deﬁne an update rule for goals’ desire levels. When to select a new goal to

focus on is also deﬁned. To verify that the proposed architecture works, experiments were run with an agent

based on the architecture, in a domain where multiple goals must continually be achieved. The results show

that (i) while the agent is pursuing goals, it can concurrently perform rewarding actions not directly related to

its goals, (ii) the trade-off between goals and preferences can be set effectively and (iii) goals and preferences

can be satisﬁed even while dealing with stochastic actions and perceptions. We believe that the proposed

architecture furthers the theory of high-level autonomous agent reasoning.

1 INTRODUCTION

Imagine a scenario where a planetary rover has four

main tasks and one task it can do when it does not

interfere with performing the main tasks. The main

tasks could be, for instance, collecting gas (for indus-

trial use) from a natural vent at the base of a hill, tak-

ing a temperature measurement at the top of the hill,

performing self-diagnostics and repairs, and reload-

ing its batteries at the solar charging station. The

less important task is to collect soil samples wherever

the rover is. The rover is programmed to know the

relative importance of collecting soil samples. The

rover also has a model of the probabilities with which

its various actuators fail and the probabilistic noise-

proﬁle of its various sensors. The rover must be able

to reason (plan) in real-time to pursue the right task

at the right time while considering its resources and

dealing with unforeseen events, all while considering

the uncertainties about its actions (actuators) and per-

ceptions (sensors).

We propose an architecture for the proper con-

trol of an agent in a complex environment such as

the scenario described above. The architecture com-

bines belief-desire-intention (BDI) theory (Bratman,

1987; Rao and Georgeff, 1995) and partially observ-

able Markov decision processes (POMDPs) (Mona-

han, 1982; Lovejoy, 1991). Traditional BDI architec-

tures (BDIAs) cannot deal with probabilistic uncer-

tainties and they do not generate plans in real-time. A

traditional POMDP cannot manage goals (major and

minor tasks) as well as BDIAs can. Next, we analyse

the POMDPs and BDIAs in a little more detail.

One of the beneﬁts of agents based on BDI theory,

is that they need not generate plans from scratch; their

plans are already (partially) compiled, and they can

act quickly once a goal is focused on. Furthermore,

the BDI framework can deal with multiple goals.

However, their plans are usually not optimal, and it

may be difﬁcult to ﬁnd a plan which is applicable to

the current situation. On the other hand, POMDPs

can generate optimal policies on the spot to be highly

applicable to the current situation. Moreover, poli-

cies account for stochastic actions and partially ob-

servable environments. Unfortunately, generating op-

timal POMDP policies is usually intractable. One so-

lution to the intractability of POMDP policy genera-

tion is to employ a continuous planning strategy, or

agent-centred search (Koenig, 2001). Aligned with

agent-centred search is the forward-search approach

or online planning approach in POMDPs (Ross et al.,

2008).

The traditional BDIA maintains goals as desires;

there is no reward for performing some action in some

Rens G. and Meyer T..

Hybrid POMDP-BDI - An Agent Architecture with Online Stochastic Planning and Desires with Changing Intensity Levels.

DOI: 10.5220/0005185000050014

In Proceedings of the International Conference on Agents and Artiﬁcial Intelligence (ICAART-2015), pages 5-14

ISBN: 978-989-758-073-4

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

state. The reward function provided by POMDP the-

ory is useful for modeling certain kinds of behavior

or preferences. For instance, an agent based on a

POMDP may want to avoid moist areas to prevent its

parts becoming rusty. Moreover, a POMDP agent can

generate plans which can optimally avoid moist areas.

But one would not say that avoiding moist areas is

the agent’s goal. A BDI agent cannot simultaneously

avoid moist areas and collect gold; it has to switch

between the two or combine the desire to avoid moist

areas with every other goal.

However, POMDP theory maintains a single re-

ward function; there is no possibility of weighing al-

ternative reward functions and pursuing one at a time

for a ﬁxed period—all objectives must be considered

simultaneously, in one reward function. Reasoning

about objectives in POMDP theory is not as sophisti-

cated as in BDI theory.

We argue that maintenance goals like avoiding

moist areas (or collecting soil samples) should rather

be viewed as a preference and modeled as a POMDP

reward function. And speciﬁc tasks to complete (like

collecting gas or keeping its battery charged) should

be modeled as BDI desires.

Given the advantages of POMDP theoretic reason-

ing and the potentially sophisticated means-ends rea-

soning of BDI theory, we propose to combine the best

features of these two theories in a coherent agent ar-

chitecture. We call it the Hybrid POMDP-BDI agent

architecture (or HPB architecture, for short).

In BDI theory, one of the big challenges is to know

when the agent should switch its current goal and

what its new goal should be (Schut et al., 2004). To

address this challenge with an intuitive explanation,

we propose that an agent should maintain intensity

levels of desire for every goal. (This intensity of de-

sire could be interpreted as a kind of emotion.) The

goal most intensely desired should be the current goal

sought (the intention). We also deﬁne the notion of

how much an intention is satisﬁed in the agent’s cur-

rent belief-state.

Typically, BDI agents do not deal with stochastic

uncertainty. Integrating POMDP notions into a BDIA

addresses this. For instance, an HPB agent will main-

tain a (subjective) belief-state representing its proba-

bilistic (uncertain) belief about its current state. Plan-

ning with models of stochastic actions and percep-

tions is thus possible in the proposed architecture.

The tight integration of POMDPs and BDIAs is novel,

especially in combination with desires with changing

intensity levels.

Section 2 brieﬂy reviews the necessary theory.

The proposed agent architecture is presented in Sec-

tion 3 and formally deﬁned. Section 4 shows an im-

plementation of the architecture on an example do-

main and evaluates the performance on various di-

mensions, conﬁrming that the approach may be useful

in some domains. The last section discusses some re-

lated work and points out some future directions for

research in this area.

2 PRELIMINARIES

The basic components of a BDI architecture

(Wooldridge, 1999, 2002) are

• a set or knowledge-base B of beliefs;

• an option generation function wish, generating the

objectives the agent would ideally like to pursue

(its desires);

• a set of desires D (goals to be achieved);

• a ‘focus’ function which selects intentions from

the set of desires;

• a structure of intentions I of the most desirable

options/desires returned by the focus function;

• a library of plans and subplans;

• a ‘reconsideration’ function which decides

whether to call the focus function;

• an execution procedure, which affects the world

according to the plan associated with the inten-

tion;

• a sensing or perception procedure, which gathers

information about the state of the environment;

and

• a belief update function, which updates the

agent’s beliefs according to its latest observations

and actions.

Exactly how these components are implemented re-

sult in a particular BDI architecture.

Algorithm 1 (adapted from Wooldridge (2000,

Fig. 2.3)) it a basic BDI agent control loop. π is the

current plan to be executed. getPercept(·) senses the

environment and returns a percept (processed sensor

data) which is an input to update(·). plan(·) returns a

plan from the plan library to achieve the agent’s cur-

rent intentions. wish : B × I → D generates a set of

desires, given the agent’s beliefs, current intentions

and possibly its innate motives. It is usually imprac-

tical for an agent to pursue the achievement of all its

desires. It must thus ﬁlter out the most valuable de-

sires and desires that are believed possible to achieve.

This is the function of focus : B × D × I → I, taking

beliefs, desires and current intentions as parameters.

Together, the processes performed by wish and focus

ICAART2015-InternationalConferenceonAgentsandArtificialIntelligence

Algorithm 1: Basic BDI agent control loop.

Input: B

: initial beliefs

Input: I

: initial intentions

1 B ← B

;

2 I ← I

;

3 π ← null ;

4 while alive do

5 p ← getPercept();

6 B ← update(B, p);

7 D ← wish(B,I);

8 I ← focus(B,D,I);

9 π ← plan(B,I);

10 execute(π);

may be called deliberation, formally encapsulated by

the deliberate procedure.

Algorithm 2 (adapted fromSchut and Wooldridge

(2001b)) has some more sophisticated controls. It

controls when the agent would consider whether to

re-deliberate, with the reconsider function (line 7)

placed just before deliberation would take place.

reconsider(·) is a Boolean function which tells the

agent whether to reconsider its intentions (every time

line 7 is reached).

The agent tests at every iteration through the main

loop whether the currently pursued intention is still

possibly achievable, using impossible(·). In the algo-

rithm, serendipity is also taken advantage of by pe-

riodically testing—using succeeded(·)—whether the

intention has been achieved, without the plan being

Algorithm 2: Control loop for an agent with recon-

sideration.

Input: B

: initial beliefs

Input: I

: initial intentions

1 B ← B

;

2 I ← I

;

3 π ← null ;

4 while alive do

5 p ← getPercept() ;

6 B ← update(B, p) ;

7 if reconsider(B,I) then

8 D ← wish(B,I) ;

9 I ← focus(B,D,I) ;

10 if not sound(π,I,B) then

π ← plan(B,I)

11 if not empty(π) then

12 α ← head(π) ;

13 execute(α) ;

14 π ← tail(π) ;

15 I ← succeeded(I, B) ;

16 I ← impossible(I, B) ;

fully executed. This agent is considered ‘reactive’ be-

cause it executes one action per loop iteration; this al-

lows for deliberation between executions. The sound-

ness (or applicability) of the plan to achieve the cur-

rent intention is checked at every iteration of the loop.

There are various mechanisms that an agent might

use to decide when to reconsider its intentions. See,

for instance, Bratman (1987); Pollack and Ringuette

(1990); Kinny and Georgeff (1991, 1992); Schut and

Wooldridge (2000, 2001a); Schut et al. (2004).

In a partially observable Markov decision process

(POMDP), the actions the agent performs have non-

deterministic effects in the sense that the agent can

only predict with a likelihood in which state it will

end up after performing an action. Furthermore, its

perception is noisy. That is, when the agent uses its

sensors to determine in which state it is, it will have a

probability distribution over a set of possible states to

reﬂect its conviction for being in each state.

Formally (Kaelbling et al., 1998), a POMDP is a

tuple hS, A, T, R, Z,P,b

i with

• S, a ﬁnite set of states of the world (that the agent

can be in),

• A a ﬁnite set of actions (that the agent can choose

to execute),

• a transition function T(s,a,s

′

), the probability of

being in s

′

after performing action a in state s,

• R(a,s), the immediate reward gained for execut-

ing action a while in state s,

• Z, a ﬁnite set of observations the agent can per-

ceive in its world,

• a perception function P(s

′

,a,z), the probability of

observing z in state s

′

resulting from performing

action a in some other state, and

• b

the initial probability distribution over all states

in S.

A belief-state b is a set of pairs hs, pi where each

state s in b is associated with a probability p. All

probabilities must sum up to one, hence, b forms a

probability distribution over the set S of all states. To

update the agent’s beliefs about the world, a special

function SE(z,a,b) = b

is deﬁned as

′

) =

P(s

′

,a,z)

∑

s∈S

T(s,a, s

′

)b(s)

Pr(z|a, b)

, (1)

where a is an action performed in ‘current’ belief-

state b, z is the resultant observation and b

′

) de-

notes the probability of the agent being in state s

′

‘new’ belief-state b

. Note that Pr(z|a,b) is a nor-

malizing constant.

Let the planning horizon h (also called the look-

ahead depth) be the number of future steps the

HybridPOMDP-BDI-AnAgentArchitecturewithOnlineStochasticPlanningandDesireswithChangingIntensityLevels

agent plans ahead each time it selects its next action.

∗

(b,h) is the optimal value of future courses of ac-

tions the agent can take with respect to a ﬁnite horizon

h starting in belief-state b. This function assumes that

at each step the action that will maximize the state’s

value will be selected.

Because the reward function R(a, s) providesfeed-

back about the utility of a particular state s (due to a

executed in it), an agent who does not know in which

state it is in cannot use this reward function directly.

The agent must consider, for each state s, the proba-

bility b(s) of being in s, according to its current belief-

state b. Hence, a belief reward function ρ(a,b) is

deﬁned, which takes a belief-state as argument. Let

ρ(a,b)

def

∑

s∈S

R(a,s)b(s).

The optimal state-value function is deﬁne by

∗

(b,h)

def

= max

a∈A

ρ(a,b)+

∑

z∈Z

Pr(z|a, b)V

∗

(SE(z,a,b), h− 1)

where 0 ≤ γ < 1 is a factor to discount the value of

future rewards and Pr(z|a,b) denotes the probability

of reaching belief-state b

= SE(z,a,b). While V

∗

de-

notes the optimal value of a belief-state, function Q

∗

denotes the optimal action-value:

∗

(a,b,h)

def

= ρ(a, b)+

∑

z∈Z

Pr(z|a, b)V

∗

(SE(z,a,b), h− 1)

is the value of executing a in the current belief-state,

plus the total expected value of belief-states reached

thereafter.

3 THE HPB ARCHITECTURE

A hybrid POMDP-BDI (HPB) agent maintains (i) a

belief-state which is periodically updated, (ii) a map-

ping from goals to numbers representing the level of

desire to achieve the goals, and (iii) the current in-

tention, the goal with the highest desire level. As the

agent acts, its desire levels are updated and it may

consider choosing a new intention based on new de-

sire levels.

The state of an HPB agent is deﬁned by the tuple

hB,D,Ii, where B is the agent’s current belief-state

(i.e., a probability distribution over the states S, de-

ﬁned below), D is the agent’s current desire function

and I is the agent’s current intention. We’ll have more

to say about D and I a little later.

An HPB agent could be deﬁned by the tuple

hAtrb,G,A,Z, T, P,Utili, where

• Atrb is a set of attribute-sort pairs (for short, the

attribute set). For every (atrb : sort) ∈ Atrb, atrb is

the name or identiﬁer of an attribute of interest in the

domain of interest, like BattryLevel or WeekDays, and

sort is the set from which atrb can take a value, for in-

stance, real numbersin the range [0,55] or a list of val-

ues like {Mon,Tue,Wed,Thu,Fri}. So {(BattryLevel :

[0,55]),(WeekDays : {Mon, Tue, Wed, Thu, Fri})}

could be an attribute set.

Let N = {atrb | (atrb : sort) ∈ Atrb} be the set

of all attribute names. We deﬁne a state s induced

from Atrb as one possible way of assigning values to

attributes: s = {(atrb : v) | atrb ∈ N ,(atrb : sort) ∈

Atrb,v ∈ sort} such that if (atrb : v),(atrb

′

: v

′

) ∈ s

and atrb = atrb

′

, then v = v

′

. The set of all possible

states is denoted S.

• G is a set of goals. A goal g ∈ G is a

set deﬁned as follows. Given a ﬁxed set N

⊆

N , g = {(atrb : v) | atrb ∈ N

,(atrb : sort) ∈

Atrb,v ∈ sort} such that if (atrb : v),(atrb

′

: v

′

) ∈

g and atrb = atrb

′

, then v = v

′

. For instance,

{(BattryLevel : 13),(WeekDay : Tue)} is a goal, and

so are {(BattryLevel : 33)} and {(WeekDay : Wed)}.

It is even possible to have one goal overlap or be a

subset of another goal. For instance, one is allowed to

have {(BattryLevel : 13),(WeekDay : Tue)} ∈ G and

simultaneously {(BattryLevel : 13)}, {(BattryLevel :

14),(WeekDay : Tue)} ∈ G. In this architecture, it is

assumed that the set of goals is given.

• A is a ﬁnite set of actions.

• Z is a ﬁnite set of observations.

• T is the transition function of POMDPs.

• P is the perception function of POMDPs.

• Util consists of two functions Pref and Satf

which allow an agent to determine the utilities of al-

ternative sequences of actions. Util = hPref,Satfi.

Pref is the preference function with a range in

R ∩ [0, 1]. It takes an action a and a state s, and re-

turns the preference (any real number) for performing

a in s. That is, Pref(a,s) ∈ [0,1]. Numbers closer

to 1 imply greater preference and numbers closer to

0 imply less preference. Except for the range restric-

tion of [0,1], it has the same deﬁnition as a POMDP

reward function, but its name indicates that it mod-

els the agent’s preferences and not what is typically

thought of as rewards. An HPB agent gets ‘rewarded’

by achieving its goals. The preference function is es-

pecially important to model action costs; the agent

should prefer ‘inexpensive’ actions. Pref has a lo-

cal ﬂavor. Designing the preference function to have

a value lying in [0,1] may sometimes be challenging,

but we believe it is always possible.

Satf is the satisfaction function with a range in

R ∩ [0,1]. It takes a state s and an intention I, and

ICAART2015-InternationalConferenceonAgentsandArtificialIntelligence

returns a value representing the degree to which the

state satisﬁes the intention. That is, Satf(I,s) ∈ [0, 1].

It is completely up to the agent designer to decide how

the satisfaction function is deﬁned, as long as num-

bers closer to 1 mean more satisfaction and numbers

closer to 0 mean less satisfaction. Satf has a global

ﬂavor.

The desire function D is a total function from

goals in G into the positive real numbers R

. The

real number represents the intensity or level of de-

sire of the goal. For instance, ({(BattryLevel :

13),(WeekDay : Tue)},2.2) could be in D, mean-

ing that the goal of having the battery level at 13

and the week-day Tuesday is desired with a level

of 2.2. ({(BattryLevel : 33)},56) and ({(WeekDay :

Wed)},444) are also examples of desires in D.

I is the agent’s current intention; an element of G;

the goal with the highest desire level. This goal will

be actively pursued by the agent, shifting the impor-

tance of the other goals to the background. The fact

that only one intention is maintained makes the HPB

agent architecture quite different to standard BDIAs.

Figure 1 shows a ﬂow diagram representing the

operational semantics of the HPB architecture.

The satisfaction an agent gets for an intention in

its current belief-state is deﬁned as

Satf

(I, B)

def

∑

s∈S

Satf(I,s)B(s),

where Satf(I,s) is deﬁned above and B(s) is the prob-

ability of being in state s. The deﬁnition of Pref

has

the same form as the reward function ρ over belief-

states in POMDP theory:

Pref

(a,B)

def

∑

s∈S

Pref (a,s)B(s),

where Pref(a,s) was discussed above.

We propose the following desire update rule.

D(g) ← D(g) + 1− Satf

(B,g) (2)

Rule 2 is deﬁned so that as Satf

(B,g) tends to one

(total satisfaction), the intensity with which the in-

cumbent goal is desired does not increase. On the

other hand, as Satf

(B,g) becomes smaller (more dis-

satisfaction), the goal’s intensity is incremented. The

rule transforms D with respect to B and g. A goal’s

intensity should drop the more it is being satisﬁed.

The update rule thus deﬁnes how a goal’s intensity

changes over time with respect to satisfaction.

Note that desire levels never decrease. This does

not reﬂect reality. It is however convenient to rep-

resent the intensity of desires like this: only relative

differences in desire levels matter in our approach and

we want to avoid unnecessarily complicating the ar-

chitecture.

An HPB agent controls its behaviour according to

the policies it generates. Plan is a procedure which

generates a POMDP policy π of depth h. Essentially,

we want to consider all action sequences of length h

and the belief-states in which the agent would ﬁnd it-

self if it followed the sequences. Then we want to

choose the sequence (or at least its ﬁrst action) which

yields the highest preference and which ends in the

belief-state most satisfying with respect to the inten-

tion.

During planning, preferences and intention satis-

faction must be maximized. The main function used

in the Plan procedure is the HPB action-value func-

tion Q

∗

HPB

, giving the value of some action a, con-

ditioned on the current belief-state B, intention I and

look-ahead depth h:

∗

HPB

(a,B,I,h)

def

= αSatf

(B,I) + (1− α)Pref

(a,B) +

∑

z∈Z

Pr(z | a, B) max

′

∈A

∗

′

,I, h − 1),

∗

HPB

(a,B,I,1)

def

= αSatf

(B,I) + (1− α)Pref

(a,B),

where B

′

= SE(a,z,B), 0 ≤ α ≤ 1 is the

goal/preference ‘trade-off’ factor, γ is the nor-

mal POMDP discount factor and SE is the normal

POMDP state estimation function.

To keep things simple for this introductory paper,

we deﬁne Plan to return argmax

a∈A

∗

HPB

(a,B,I,h),

the trivial policy of a single action. In general, Plan

could return a policy of depth h, that is, a sequence of

h actions, where the choice of exactly which action to

take at each step depends on the observation received

just prior.

Focus is a function which returns one member of

G called the (current) intention I. Presently, we de-

ﬁne it simply as selecting the goal with the highest

desire level. After every execution of an action in the

real-world, Refocus is called to decide whether to call

Focus to select a new intention. Refocus is a meta-

reasoning function analogous to the reconsider func-

tion discussed in Section 2. It is important to keep the

agent focused on one goal long enough to give it a rea-

sonable chance of achieving it. It is the job of Refocus

to recognize when the current intention seems impos-

sible or too expensive to achieve.

Let Satf

levels be the sequence of satisfaction lev-

els of the current intention since it became active and

let MEMORY be a designer-speciﬁed number repre-

senting the length of a sub-sequence of Satf

levels—

the MEMORY last satisfaction levels. One possible

HybridPOMDP-BDI-AnAgentArchitecturewithOnlineStochasticPlanningandDesireswithChangingIntensityLevels

Focus

Plan

Replan

Execute

Sense

Refocus

Belief Update

action

observation

yes

information flow

control flow

Desire Update

Figure 1: Operational semantics of the HPB architecture. SL stands for Satf levels. Note that Satf levels depends on the

current belief-state and intention, but not on desire levels. Planning is also independent of desire levels. The focus function

depends on desire levels, but not on satisfaction. Whether to refocus depends on satisfaction levels, but not on desire levels.

ICAART2015-InternationalConferenceonAgentsandArtificialIntelligence

deﬁnition of Refocus is

Refocus(c,θ)

def







‘no’ if |Satf levels| < MEMORY

‘yes’ if c < θ

‘no’ otherwise,

where c is the average change from one satisfaction

level to the next in the agent’s ‘MEMORY’, and θ

is some threshold chosen by the agent designer. If

the agent is expected to increase its satisfaction by

at least, say, 0.1 on average for the current intention,

then θ should be set to 0.1. With this approach, if the

agent ‘gets stuck’ trying to achieve its current inten-

tion, it will not blindly keep on trying to achieve it,

but will start pursuing another goal (with the highest

desire level). Note that if an intention was not well

satisﬁed, its desire level still increases at a relatively

high rate. So whenever the agent focuses again, a goal

not well satisﬁed in the past will be a top contender to

become the intention (again).

4 EVALUATION

We performed some tests on an HPB agent in a six-

by-six grid-world. In this world, the agent’s task is to

visit each of the four corners, while collecting items

on the way. That is, the agent’s goals are the states

representing the four corners, but the collecting of

items is regarded as a preferred behavior, not a goal

to be pursued.

States are quadruples hx,y, d,ti, with x,y ∈

{1,··· ,6} being the coordinates of the agent’s po-

sition in the world, d ∈ {North,East,West, South}

the direction it is facing, and t ∈ {0,1}, t = 1

if an item is present in the cell with the agent,

else t = 0. The agent can perform ﬁve actions

{left, right,forward,see,collect}, meaning, turn left,

turn right, move one cell forward, see whether an item

is present and collect an item. The only observation

possible when executing one of the physical actions

is obsNil, the null observation, and see has possible

observations from the set {0,1} for whether the agent

sees the presence of an item (1) or not (0).

Next, we deﬁne the possible outcomes for each

action: When the agent turns left or right, it can get

stuck in the same direction, turn 90

◦

or overshoots by

◦

. When the agent moves forward, it moves one cell

in the direction it is facing or it gets stuck and does

not move. The agent can see an item or see nothing

(no item in the cell), and collecting is deterministic (if

there is an item present, it will be collected with cer-

tainty, if the agent executes collect). All actions ex-

cept collect are designed so that the correct outcome

is achieved 95% of the time and incorrect outcomes

are achieved 5% of the time.

So that the agent does not get lost too quickly,

we have included an automatic localization action,

that is, a sensing action returns information about the

agent’s approximate location. The action is automatic

because the agent cannot choose whether to perform

it; the agent localizes itself after every regular/chosen

action is executed. However, just as with regular ac-

tions, the localization sensor is noisy, and it correctly

reports the agent’s location with probability 0.95, else

the sensor reports a location adjacent to the agent with

probability uniformly distributed over 0.05.

Errors in the agent’s actions and perceptions are

thus modeled, not ignored.

In the experiments which follow, the threshold θ

is set to 0.05, MEMORY is set to 5 and h = 4. De-

sire levels are initially set to zero for all goals. Three

experiments were performed. First, visiting corners

but not collecting items, second, collecting items but

not intentionally visiting corners and third, visiting

corners while collecting items. For each experiment,

10 trials were run with the agent starting in random

locations and performing 100 actions per trial. We

let Satf(I, s) = 1− dist/10 where 10 is the maximum

Manhattan distance between two cells in the world

and dist is the Manhattan distance between the cells

represented by I and s, and we let

Pref (a,s) = (1− dist/10+ collUtil+ sensUtil)/100,

where dist is the Manhattan distance between the cell

representing s and the closest cell containing an item,

collUtil is 98 if a is collect and there is actually an

item in the cell represented by s, else 0, and sensUtil

is 1 if the agent tries to see, else 0.

The division by

100 is to bring the value of Pref (·) within the limits

of 0 and 1.

First, we see how an HPB agent behaves when

it has no goal state (α = 0), but continually only

‘prefers’ to collect items. That is, we let

∗

HPB

(a,B,I,h)

def

= Pref

(a,B)+

∑

z∈Z

Pr(z | a, B) max

′

∈A

∗

′

,I, h − 1).

On average, it collects 7.4 of 12 possible items. The

left-most results column of Table 1 shows how often

corners are (unintentionally) visited.

Next, if the HPB agent prefers to collect items

while equally trying to reach corners (α = 0.5), it col-

lects 4.3 of 12 possible items and the corners it visits

is summarized in the second-from-left results column

of Table 1.

Pref(·) is designed such that the agent collects a maxi-

mum number of items (ignoring goals). The agent collects

more when it is encouraged to sense where items are, hence

sensUtil is 1 if the agent tries to see.

HybridPOMDP-BDI-AnAgentArchitecturewithOnlineStochasticPlanningandDesireswithChangingIntensityLevels

Table 1: The average number of times each corner was vis-

ited (on separate occasions), percentage of times all corners

were visited, and percentage of items (out of 12) collected.

Corner

Times visited

α = 0 α = 0.5 α = 0.75 α = 1

(1,1) 2.2 2.8 2.7 2.9

(1,6) 2.1 2.6 2.7 3.2

(6,1) 2.0 2.7 2.6 3.0

(6,6) 1.7 2.6 2.9 3.0

All 8.0% 10.7% 10.9% 12.1%

Items

coll’ed

62% 36% 29% 0%

Then, we observe the agent’s behavior if we set

α = 0.75. In this case, the agent collects 3.5 items on

average, and its corner-visiting behavior—as given in

the second-from-right column of Table 1—is propor-

tional to the value of α, as expected.

Finally, we ignore the collection of items by set-

ting α = 1. That is, we let

∗

HPB

(a,B,I,h)

def

= Satf

(B,I)+

∑

z∈Z

Pr(z | a, B) max

′

∈A

∗

′

,I, h − 1).

The right-most results column of Table 1 shows the

average number of times each corner was visited

when collecting items is not a preference. No items

were collected.

These experiments highlight four important fea-

tures of an HPB agent: (1) While the agent is pursuing

goals, it can concurrently perform rewarding actions

not directly related to its goals. (2) Each of several

goals can be pursued individually until satisfactorily

achieved. (3) Goals must periodically be re-achieved.

(4) The trade-off between goals and preferences can

be set effectively. (5) Goals and preferences can be

satisﬁed even while dealing with stochastic actions

and perceptions.

5 RELATED WORK AND

CONCLUSION

Our work focuses on providing high-level decision-

making capabilities for robots and agents who live

in dynamic stochastic environments, where multiple

goals and goal types must be pursued. We introduced

a hybrid POMDP-BDI agent architecture, which may

display emergentbehavior, driven by the intensities of

their desires. In the past decade, several BDIAs have

been augmented with capabilities to deal with uncer-

tainty. The HPB architecture is novelin that, while the

agent is pursuing goals, it can concurrently perform

rewarding actions not directly related to its goals, and

goals must periodically be re-achieved, depending on

the goals’ desire levels, which change over time and

in proportion to how close the goals are to being sat-

isﬁed.

Walczak et al. (2007) and Meneguzzi et al. (2007)

have incorporated online plan generation into BDI

systems, however the planners deal only with deter-

ministic actions and observations.

Nair and Tambe (2005) use POMDP theory to

coordinate teams of agents. However, their frame-

work is very different to our architecture. They use

POMDP theory to determine good role assignments

of team members, not for generating policies online.

Lim et al. (2008) provide a rather sophisticated

architecture for controlling the behavior of an emo-

tional agent. Their agents reason with several classes

of emotion and their agents are supposed to portray

emotional behavior, not simply to solve problems, but

to look believable to humans. Their architecture has

a “continuous planner [...] that is capable of partial

order planning and includes emotion-focused coping

[...]” Their work has a different application to ours,

however, we could take inspiration from them to im-

prove the HPB architecture.

Pereira et al. (2008) take a different approach to

use POMDPs to improve BDI agents. By leveraging

the relationship between POMDP and BDI models,

as discussed by Simari and Parsons (2006), they de-

vised an algorithm to extract BDI plans from optimal

POMDP policies. The main difference to our work

is that their policies are pre-generated and BDI-style

rules are extracted for all contingencies. The advan-

tage is that no (time-consuming) online plan/policy

generation is necessary. The disadvantage of their ap-

proach is that all the BDI plans must be stores and ev-

ery time the domain model changes, a new POMDP

must be solved and the policy-to-BDI-plan algorithm

must be run. It is not exactly clear from their paper

(Pereira et al., 2008) how or when intentions are cho-

sen. Although it is interesting to know the relation-

ship between POMDPs and BDI models (Simari and

Parsons, 2006, 2011), we did not use any of these in-

sights in developing our architecture. However, the

fact that the HPB architecture does integrate the two

frameworks, is probably due to the existence of the

relationship.

Rens et al. (2009) also introduced a hybrid

POMDP-BDI architecture, but without a notion of de-

sire levels or satisfaction levels. Although their basic

approaches to combine the POMDP and BDI frame-

works is the same as ours, there are at least two major

differences: Firstly, they deﬁne their architecture in

terms of the GOLOG agent language (Boutilier et al.,

ICAART2015-InternationalConferenceonAgentsandArtificialIntelligence

2000). Secondly, their approach uses a computation-

ally intensive method for deciding whether to refocus;

performing short policy look-aheads to ascertain the

most valuable goal to pursue.

Our approach seems

much more efﬁcient.

Chen et al. (2013) incorporate probabilistic graph-

ical models into the BDI framework for plan selection

in stochastic environments. An agent maintains epis-

temic states (with random variables) to model the un-

certainty about the stochastic environment, and cor-

responding belief sets of the epistemic state are de-

ﬁned. The possible states of the environment, ac-

cording to sensory observations, and their relation-

ships are modeled using probabilistic graphical mod-

els: The uncertainty propagation is carried out by

Bayesian Networks and belief sets derived from the

epistemic states trigger the selection of relevant plans

from a plan library. For cases when more than one

plan is applicable due to uncertainty in an agent’s be-

liefs, they propose a utility-driven approach for plan

selection, where utilities of actions are modeled in in-

ﬂuence diagrams. Our architecture is different in that

it does not have a library of pre-supplied plans; in our

architecture, policies (plans) are generated online.

None of the approaches mentioned maintain de-

sire levels for selecting intentions. The beneﬁt of

maintaining desire levels is that intentions are not se-

lected only according what they offer with respect to

their current expected reward, but also according to

when last they were achieved.

Although Nair and Tambe (2005) and Chen et al.

(2013) call their approaches hybrid, our architecture

can arguably more conﬁdently be called hybrid be-

cause of its more intimate integration of POMDP and

BDI concepts.

We could take some advice from Antos and Pf-

effer (2011). They provide a systematic methodol-

ogy to incorporate emotion into a decision-theoretic

framework, and also provide “a principled, domain-

independent methodology for generating heuristics in

novel situations”.

Policies returned by Plan as deﬁned in this paper

are optimal. A major beneﬁt of a POMDP-based ar-

chitecture is that the literature on POMDP planning

optimization (Murphy, 2000; Roy et al., 2005; Paquet

et al., 2005; Li et al., 2005; Shani et al., 2007; Ross

et al., 2008; Cai et al., 2009; Shani et al., 2013) (for in-

stance) can be drawn upon to improve the speed with

which policies can be generated.

Our architecture cannot yet control how often one

Essentially, the goals in G are stacked in descending

order of the value of V

∗

HPB

(B,g,h

−

), where h

−

< h and B

is the current belief-state. The goal on top of the stack be-

comes the intention.

goal is sought relative to other goals. It would be ad-

vantageous to be able to do this.

Evaluating the proposed architecture in richer do-

mains would highlight problems in the architecture

and indicate new directions for research and develop-

ment in the area of hybrid POMDP-BDI architectures.

REFERENCES

Antos, D. and Pfeffer, A. (2011). Using emotions to en-

hance decision-making. In Walsh, T., editor, Pro-

ceedings of the 22nd Intl. Joint Conf. on Artif. In-

tell. (IJCAI-11), pages 24–30, Menlo Park, CA. AAAI

Press.

Boutilier, C., Reiter, R., Soutchanski, M., and Thrun, S.

(2000). Decision-theoretic, high-level agent program-

ming in the situation calculus. In Proceedings of the

Seventeenth National Conference on Artiﬁcial Intelli-

gence (AAAI-00) and of the Twelfth Conference on In-

novative Applications of Artiﬁcial Intelligence (IAAI-

00), pages 355–362. AAAI Press, Menlo Park, CA.

Bratman, M. (1987). Intention, Plans, and Prac-

tical Reason. Harvard University Press, Mas-

sachusetts/England.

Cai, C., Liao, X., and Carin, L. (2009). Learning to explore

and exploit in pomdps. In NIPS, pages 198–206.

Chen, Y., Hong, J., Liu, W., Godo, L., Sierra, C., and

Loughlin, M. (2013). Incorporating PGMs into a BDI

architecture. In Boella, G., Elkind, E., Savarimuthu,

B., Dignum, F., and Purvis, M., editors, PRIMA 2013:

Principles and Practice of Multi-Agent Systems, vol-

ume 8291 of Lecture Notes in Computer Science,

pages 54–69. Springer, Berlin/Heidelberg.

Kaelbling, L., Littman, M., and Cassandra, A. (1998). Plan-

ning and acting in partially observable stochastic do-

mains. Artiﬁcial Intelligence, 101(1–2):99–134.

Kinny, D. and Georgeff, M. (1991). Commitment and effec-

tiveness of situated agents. In Proceedings of the 12th

Intl. Joint Conf. on Artiﬁcial Intelligence (IJCAI-91),

pages 82–88.

Kinny, D. and Georgeff, M. (1992). Experiments in optimal

sensing for situated agents. In Proceedings of the the

2nd Paciﬁc Rim Intl. Conf. on Artiﬁcial Intelligence

(PRICAI-92).

Koenig, S. (2001). Agent-centered search. Artiﬁcial Intelli-

gence Magazine, 22:109–131.

Li, X., Cheung, W., and Liu, J. (2005). Towards solv-

ing large-scale POMDP problems via spatio-temporal

belief state clustering. In Proceedings of IJCAI-05

Workshop on Reasoning with Uncertainty in Robotics

(RUR-05).

Lim, M., Dias, J., Aylett, R., and Paiva, A. (2008). Im-

proving adaptiveness in autonomous characters. In

Prendinger, H., Lester, J., and Ishizuka, M., editors,

Intelligent Virtual Agents, volume 5208 of Lecture

Notes in Computer Science, pages 348–355. Springer,

Berlin/Heidelberg.

HybridPOMDP-BDI-AnAgentArchitecturewithOnlineStochasticPlanningandDesireswithChangingIntensityLevels

Lovejoy, W. (1991). A survey of algorithmic methods for

partially observed Markov decision processes. Annals

of Operations Research, 28:47–66.

Meneguzzi, F., Zorzo, A., M´ora, M., and M., L. (2007).

Incorporating planning into BDI systems. Scalable

Computing: Practice and Experience, 8(1):15–28.

Monahan, G. (1982). A survey of partially observable

Markov decision processes: Theory, models, and al-

gorithms. Management Science, 28(1):1–16.

Murphy, R. (2000). Introduction to AI Robotics. MIT Press,

Massachusetts/England.

Nair, R. and Tambe, M. (2005). Hybrid bdi-pomdp

framework for multiagent teaming. J. Artif. Intell.

Res.(JAIR), 23:367–420.

Paquet, S., Tobin, L., and Chaib-draa, B. (2005). Real-time

decision making for large POMDPs. In Advances in

Artiﬁcial Intelligence: Proceedings of the Eighteenth

Conference of the Canadian Society for Computa-

tional Studies of Intelligence, volume 3501 of Lecture

Notes in Computer Science, pages 450–455. Springer

Verlag.

Pereira, D., Gonc¸alves, L., Dimuro, G., and Costa, A.

(2008). Constructing bdi plans from optimal pomdp

policies, with an application to agentspeak program-

ming. In G. Henning, M. G. and Goneet, S., editors,

XXXIV Conferˆencia Latinoamericano de Inform´atica,

Santa Fe. Anales CLEI 2008, pages 240–249.

Pollack, M. and Ringuette, M. (1990). Introducing the Tile-

world: Experimentally evaluating agent architectures.

In Proceedings of the AAAI-90, pages 183–189. AAAI

Press.

Rao, A. and Georgeff, M. (1995). BDI agents: From theory

to practice. In Proceedings of the ICMAS-95, pages

312–319. AAAI Press.

Rens, G., Ferrein, A., and Van der Poel, E. (2009). A

BDI agent architecture for a POMDP planner. In

Lakemeyer, G., Morgenstern, L., and Williams, M.-

A., editors, Proceedings of the 9th Intl. Symposium

on Logical Formalizations of Commonsense Reason-

ing (Commonsense 2009), pages 109–114, University

of Technology, Sydney. UTSe Press.

Ross, S., Pineau, J., Paquet, S., and Chaib-draa, B. (2008).

Online planning algorithms for POMDPs. Journal of

Artiﬁcial Intelligence Research (JAIR), 32:663–704.

Roy, N., Gordon, G., and Thrun, S. (2005). Finding

approximate POMDP solutions through belief com-

pressions. Journal of Artiﬁcial Intelligence Research

(JAIR), 23:1–40.

Schut, M. and Wooldridge, M. (2000). Intention reconsider-

ation in complex environments. In Proceedings of the

the 4th Intl. Conf. on Autonomous Agents (AGENTS-

00), pages 209–216, New York, NY, USA. ACM.

Schut, M. and Wooldridge, M. (2001a). The control of rea-

soning in resource-bounded agents. The Knowledge

Engineering Review, 16(3):215–240.

Schut, M. and Wooldridge, M. (2001b). Principles of inten-

tion reconsideration. In Agents 2001: Proceedings of

the 5th Intl. Conf. on Autonomous Agents, pages 340–

347, New York, NY. ACM Press.

Schut, M., Wooldridge, M., and Parsons, S. (2004).

The theory and practice of intention reconsideration.

Experimental and Theoretical Artiﬁcial Intelligence,

16(4):261–293.

Shani, G., Brafman, R., and Shimony, S. (2007). Forward

search value iteration for POMDPs. In de Mantaras,

R. L., editor, Proceedings of the 20th Intl. Joint Conf.

on Artif. Intell. (IJCAI-07), pages 2619–2624, Menlo

Park, CA. AAAI Press.

Shani, G., Pineau, J., and Kaplow, R. (2013). A survey of

point-based pomdp solvers. Autonomous Agents and

Multi-Agent Systems, 27(1):1–51.

Simari, G. and Parsons, S. (2006). On the relationship

between mdps and the bdi architecture. In Proceed-

ings of the ﬁfth international joint conference on Au-

tonomous agents and multiagent systems, AAMAS

’06, pages 1041–1048, New York, NY, USA. ACM.

Simari, G. and Parsons, S. (2011). Markov Deci-

sion Processes and the Belief-Desire-Intention Model.

Springer Briefs in Computer Science. Springer, New

York, Dordrecht, Heidelberg, London.

Walczak, A., Braubach, L., Pokahr, A., and Lamersdorf,

W. (2007). Augmenting BDI agents with delibera-

tive planning techniques. In Bordini, R., Dastani,

M., Dix, J., and Seghrouchni, A., editors, Proceed-

ings of the 4th Intl. Workshop of Programming Multi-

Agent Systems (ProMAS-06), pages 113–127, Heidel-

berg/Berlin. Springer Verlag.

Wooldridge, M. (1999). Intelligent agents. In Weiss, G., ed-

itor, Multiagent Systems: A Modern Approach to Dis-

tributed Artiﬁcial Intelligence, chapter 1. MIT Press,

Massachusetts/England.

Wooldridge, M. (2000). Reasoning about Rational Agents.

MIT Press, Massachusetts/England.

Wooldridge, M. (2002). An introduction to multiagent sys-

tems. John Wiley & Sons, Chichester, England.

ICAART2015-InternationalConferenceonAgentsandArtificialIntelligence
