An Approach to the Context-oriented Use Case Analysis

Kalinka Kaloyanova

and Neli Maneva

Faculty of Mathematics and Informatics, Sofia University, 5 J. Bourchier Blvd., Sofia, Bulgaria

Institute of Mathematics and Informatics, BAS, Acad. G. Bonchev Str., Bl.8, Sofia, Bulgaria

kkaloyanova@fmi.uni-sofia.bg, neman@math.bas.bg

Keywords: Requirements Engineering, Use Case Analysis, Information Systems Development, Multiple-criteria

Decision Making, Comparative Analysis.

Abstract: The paper describes our efforts to propose a feasible solution of a significant problem in information

systems development – requirements engineering, based on use cases. The adjustable use case quality model

is constructed and used within the Comparative Analysis method to support the decision making during the

use case analysis process. Two real-life problems related to this process are described and their solutions

through the suggested approach are given.

1 INTRODUCTION

Nowadays the volumes of information are

continually increasing, the methods for storing and

searching information become more complex and

the software users - more demanding. One way to

meet their expectations is to assure an effective

engineering of the elucidated user-defined

requirements. Requirements Engineering (RE) as a

subfield of both Information Systems (IS) and

Software Engineering (SE) concerns the real-life

needs of the users and the constraints for the systems

to be built.

Recognizing the importance of the RE in any

software intensive system’s life cycle and

understanding the significant role of the

requirements elicitation activity, we address a

challenging issue – providing systematic approaches

to the construction and constantly improvement of

the requirements for information systems

development.

The goal of this paper is to present our approach

to IS requirements engineering, based on quality use

cases. The applicability of a formal method for the

proposed context-oriented use case analysis is

investigated in Section 2. The most difficult activity

– use case quality modelling in a specified context,

is described in Section 3. Two examples are given,

illustrating how the method can be successfully

applied. In the Conclusions section some directions

for future research and experimental work are

shared.

2 BASIC DEFINITIONS AND

RELATED APPROACHES

Requirements engineering is one of the initial and

very important activities in software development.

Lately its significance is realized and there are

plenty of methods, frameworks, tools, etc.,

supporting RE (Pressman, 2009), (Sommerville,

2011), (Denny, 2005). From practitioner’s point of

view the great variety of approaches and available

tools are more distractive than useful. This is

especially true for information systems

development, where the main requirements come

from end users and usually are ambiguous,

contradictory and incomplete (Pokorny, 2010). Due

to such reasons the iterative approaches usually are

more effective, because they support the

requirements refinement in a more constructive way

(Kaloyanova, 2012).

2.1 Use Case Modelling

A common form for describing functional

requirements for a system is the use case modelling

(Maciaszek, 2005). It captures user requirements of

a new system by detailing all scenarios that the users

will perform. Each use case describes a specific way

of using the designed system by actors – users with

specific roles, trying to achieve their goals (Sinnig,

2010). The set of all use cases defined by actors

describes the system functionality (Cockburn, 2000).

135

Kaloyanova K. and Maneva N.

An Approach to the Context-oriented Use Case Analysis.

DOI: 10.5220/0005425101350141

In Proceedings of the Fourth International Symposium on Business Modeling and Software Design (BMSD 2014), pages 135-141

ISBN: 978-989-758-032-1

Use case modelling usually is recognized as a

part of Requirement engineering discipline of the

Unified Process (UP) that is focused primarily on

the functional requirements of the system (Kruchten,

2004). The non-functional requirements are divided

by the UP approach into several categories. The

acronym FURPS+ presents the functional and

several important non-functional requirements,

which are quite relevant to IS development –

usability, reliability, performance, and supportability

of the system (Larman, 2004).

The use case model describes not only the

system behaviour, but it also defines the boundary of

the system and how this system communicates with

different actors.

Besides, as use case modelling is a part of the

UP, starting from the first phase of it - Inception, the

use cases capture functionality of the system in an

iterative process that is not only understandable for

the users, but could also be detailed in the next

phases of the UP – Elaboration and Construction.

Use cases are described in natural language. So

they can be easily understood by non-technical

people and can be further discussed by users, clients,

analysts, designers, developers and their managers.

The use cases can be written with different level

of details (Larman, 2004):

 Brief – one-paragraph summary, focused on the

main success scenario;

 Casual – multiple paragraphs, covered various

scenarios of user-system interaction;

 Fully dressed – all scenarios are written in detail,

comprising some supporting sections, such as

preconditions, post-conditions, special

requirements, etc.

The different forms of use cases description can be

created during successive iterations, following the

UP. In this way, at every step some new information

is added to the use case description. The analysis

usually starts with a set of use cases in brief format

and detail them through the next iterations. In order

to do this systematically, the use cases have to be

ranked, taking into account their significance, risk,

complexity or other criterion of prioritization.

Several questions arise here - how to implement

the use case definition method in practice and how

to evaluate the quality of use case description in

different iterations. The analysts need a technique

that supports a stable evolution of the specifications

of every element of software functionality, described

by the corresponding use case.

A number of works discuss different sides of the

use case development – formalization (Sinning,

2009), content (Cockburn, 2000), inspection

techniques (Anda, 2002), etc. Most of the research

publications about the use case modelling are

summarized in (Torner, 2006). Although the

intensive research in the area it is hard to find a

method that represents a holistic view on all aspects

of the use case transformation.

In this paper we introduce a use case quality

model for the description of the functionality,

presented at different consecutive iterations of the

same use case. Further this quality model can be

built into a method allowing not only to assess the

achieved use case quality, but to facilitate some

decisions, made during the process of quality

improvement. We base our approach on the formal

Comparative Analysis method (Maneva, 2007). This

method was chosen primarily because it shares the

main objectives and methods of the broad theory of

the Multiple Criteria Decision Making, trying to

specify and apply them systematically.

2.2 Comparative Analysis

We will present the essence of the Comparative

Analysis (CA) in order to explain how it can be

used for the activity under consideration – use case

analysis.

Comparative Analysis is a study of the quality

content of a set of homogeneous objects and their

mutual comparison in order to select the best, to

rank them (establishing a preference order) or to

classify each object to one of the predefined quality

categories.

For CA use we distinguish two main roles: the

CA Analyst, responsible for all aspects of CA

implementation, and a CA customer – a single

person or a group of individuals, tasked with making

a decision in a given situation. Depending on the

identified problem to be solved at a given moment, a

case should be opened to determine the context of

the desired Comparative Analysis.

Each case is specified by the following elements:

case={View, Goal, Object, Competitors, Task, Level }

The View describes the CA customer’s role and the

perspective from which the CA will be performed.

The Goal expresses the main customer’s

intentions in CA accomplishment such as to

describe, analyse, estimate, improve, predict or any

other, formulated by the Customer, defining the

case.

The Object represents the item under

consideration. In the field of software engineering

any studied object belongs to one of the following

groups: products, processes or resources. For each

Fourth International Symposium on Business Modeling and Software Design

136

object for CA application, a quality model should be

created – a set of characteristics, selected to

represent the quality content in this context, and the

relationships among them.

According to the goal, the set C of Competitors,

C = {C

, C

2, … ,

} – the instances of the objects to

be compared – should be chosen.

The element Task of a case can be Selection

(finding the best), Ranking (producing an ordered

list), Classification (splitting the competitors to a

few preliminary defined quality groups) or any

combination of them.

The parameter Level defines the overall

complexity of the CA and depends on the

importance of the problem under consideration and

on the resources needed for CA implementation.

Usually the object quality model is presented as a

hierarchy. At the top of the hierarchy is the total

object quality. The first level comprises some user-

oriented attributes, called factors. The next level

describes a number of object-dependent attributes,

providing quality. These criteria can be further

decomposed to more simple and measurable

characteristics. To each node at the hierarchy

structure a weight (a coefficient of importance) is

assigned, and for the leaves of the hierarchy some

appropriate metrics are defined. Starting a bottom-

up evaluation of characteristics at each level in the

hierarchy and applying a modification of the

MECCA (Multi-Element Component Comparison

and Analysis) method, described in (Bowen, 1985),

we can obtain the quantitative measures of all

factors and fill the competitors-factors matrix

E(nxm), where n is the number of the competitors,

defined in the set C, and m is the number of the

quality factors. Each element Ei,j is the measure of

the i-th competitor with respect to the j-th quality

factor. The obtained matrix E is further used as input

to the software tools, implementing the required

selection, ranking or classification methods.

Additional details about the CA method can be

found in a number of recent publications. In this

paper we provide only the information, absolutely

necessary for understanding the CA application as a

method, supporting decision making.

3 A CONTEXT-ORIENTED USE

CASE ANALYSIS

The CA method can be used in any decision making

situation within the use case analysis, after

specifying its context.

According to the definition already given in

Section 2.2, the concrete situation for a particular

decision making can be stated by a case, comprising

six elements:

case={View, Goal, Object, Competitors, Task, Level}

The View describes the CA customer’s role and

focuses on the perspective of the Comparative

Analysis. Taking into account the responsibilities

and typical tasks of the main participants in the use

case analysis, the following Customer’s roles have

been identified till now: Business Analyst, User, IS

developer. Thus a lot of situations can be further

specified, reflecting the specific participant’s point

of view to the analysed context.

As the Goal expresses the main Customer’s

intentions in CA accomplishment and bearing in

mind the goal-oriented use case definition and its

further improvement, the Analyst should decompose

the goal stated for use case analysis to a number of

CA-related goals, e.g. to describe, assess, estimate,

improve, predict, etc.

The element Object, as it was mentioned above,

represents the item under consideration. Particularly

for the use case analysis, the following objects,

classified in three groups, can be studied:

Products – use case, collection of use cases, use

cases source (discussion memos, documentation,

specifications, user’s and developer’s stories),

prototypes for checking selected use case

characteristics, like completeness, usefulness, etc.

Processes, related to use case analysis:

elicitation, quality assessment, prioritization,

documenting, maintenance, tracking, etc.

Resources, related to use case analysis:

technological (e.g. method, technique, tool), or

project-oriented (people, team, performance).

For each studied object a quality model should

be created – a set of characteristics, selected to

represent the quality content, and the relationships

among them.

According to the goal, the set C of Competitors

– the instances of the objects to be mutually studied

and compared – should be chosen. If the Goal is

only to create the quality model of the object under

consideration, the set C is empty.

There are no special considerations, when we

define the element Task of a situation for use case

analysis. As usual, the task can be Selection,

Ranking, Classification or any combination of them.

It is not difficult to define the degree of

complexity (simple, medium or high) presented by

the element Level.

One of the challenges in the implementation of

the CA is the construction of a model, adequate to

the quality content of the object, pointed in a given

An Approach to the Context-oriented Use Case Analysis

137

case. According to the prescriptions, the Analyst is

responsible for accomplishment of this task, which

is with very high cognitive complexity and usually

requires unified efforts of the Analyst and the

Customer, ordered the CA.

3.1 A Quality Model for Object “Use

Case”

As an example, we will describe the basic

hierarchical model, constructed for the quality of

object “use case”. In this model we propose three

user-oriented characteristics (factors) –

Applicability, Validity and Utility.

The factor Applicability concerns the relation

between the use case and the real system

functionality and addresses the question of the use

case legality. Next follows a brief definition of the

quality characteristics selected for this factor and the

corresponding metrics for the leaves of the tree

structure.

The hierarchy obtained after the decomposition

of the Applicability factor is shown in Table 1.

The first level of the hierarchy comprises three

criteria affecting the factor Applicability -

Accuracy, Trackability, and Adequacy.

Table 1: Decomposition of the factor Applicability.

Factor Applicability

Criteria Item-Oriented Characteristics

Accuracy

Trackability

Adequacy Robustness

Completeness

Correctness

Accuracy defines how the use case corresponds

to the reality. It shows whether the goal of this use

case could be reached by the presented use case

description. Accuracy can be measured by the ratio

of correct features to the total number of features,

described in the use case.

Trackability reflects whether the changes in

reality can be accompanied by changes in the use

case.

The Adequacy criterion is more complex. It

should be evaluated by answering several important

questions like:

 Is the use case robust?

 Is the use case complete? Are all possible

scenarios defined?

 Is the use case correct? Is the right sequence of

steps described in the scenarios?

In the frame of Adequacy the characteristic

Correctness can be measured by the ratio of correct

steps to the total number of steps, described in the

use case. More sophisticated evaluation of the

correctness can be done by splitting this

characteristic into two more – Compliance and

Homogeneity, defined as follows:

– Compliance: Does the use case description

follow the proper separation between the positive

scenario and other alternative scenarios?

– Homogeneity: Are the descriptions of all

scenarios with the same level of details?

The second suggested factor Validity concerns the

inner capacity of the use case to produce results

corresponding to the expected ones.

Table 2: Decomposition of the factor Validity.

Factor Validity

Criteria Item-Oriented Characteristics

Reliability

Modifiability Complexity

Modularity

Understandability Self-descriptive

Concise

Structured

Measurability

Table 2 illustrates the proposed hierarchy for this

factor based on the selected quality criteria:

Reliability, Modifiability, Understandability and

Measurability.

The quality criterion Reliability is evaluated

through the answers of two questions:

 Is the use case adequate?

 Is the use case robust?

The next criterion Modifiability shows how easily

the use case can be modified. It is decomposed

further in two measurable characteristics:

- Complexity – can be considered as textual or

algorithmic, measured by the appropriately

constructed metrics;

- Modularity – usually measured by the number of

all alternative scenarios.

Nevertheless the quality criterion Understandability

is well known concept, for the use case analysis it

concerns variety of details, which can be taken into

account:

 Is the use case self-descriptive? Are all steps

clear to follow?

 Is the use case concise? Is the description of the

steps brief and clear?

 Is the use case well structured? Do all scenarios

fit each other? Is the main positive scenario

properly defined and all alternative scenarios are

adequate to it?

Fourth International Symposium on Business Modeling and Software Design

138

The used metrics here reflect the structure – linear

(usually for the brief form of the use case) or

hierarchical (for the description of the alternative

scenarios and their connections to the steps of the

main positive scenario).

When we consider the criterion Measurability, it

is obligatory to select some concrete metrics for use

case assessment like:

 The number of steps of the successfull scenario;

 The number of steps, performed by each actor,

involved into the success scenario;

 The number of system steps, described by the

success scenario;

 The number of all alternative scenarios;

 The number of steps of alternative scenarios;

 The number of steps of the negative alternative

scenarios;

 The number of all steps, described in the studied

use case;

 The number of preconditions in the studied use

case.

The third factor Utility deals with the relation

between use case and users and addresses the

question of the possibility to derive conclusions

from the created use case. The proposed hierarchy

for this factor is shown in Table 3, presenting a

number of quality characteristics.

Table 3: Decomposition of the factor Utility.

Factor Utility

Criteria Item-Oriented Characteristics

Content

Fidelity

Constructiveness

Stability

Usability

Effectiveness

Efficiency

User satisfaction

The Content criterion focuses on the text

description. Several questions arise here:

What does the use case represent?

Is use case detailed enough? Are all steps clear

and described with appropriate level of detail?

The criterion Fidelity answers the question if

different users will get similar results using the same

use case.

The next criterion - Constructiveness explains

how the use case facilitates some future IS-related

activities like design, coding, testing, etc.

The criterion Stability explains if the use case

can be manipulated to obtain false results or if the

new version of the use case corrupts any of the

previous versions.

The last considered criterion Usability can be

evaluated from three different perspectives:

- Effectiveness: Does the use case match the

purpose? Are all steps of the main positive scenarios

leading to the goal?

- Efficiency: Does the use case fulfil the stated

goal with minimal resources? Is the sequence of the

steps is the shortest way to the goal?

- User satisfaction: Can be measured by the

percentage of unsatisfied users and the average

rating, given by users.

3.2 A Quality Model for Object “A Set

of Use Cases”

This object can appear in a situation involving a set

U of interconnected use cases, which can be studied

as a whole due to some customer’s considerations.

For this object a simple linear model can be created,

comprising four quality characteristics -

Completeness, Consistency, Relevance, and

Correctness.

For the purposes of the use case analysis we

define their meaning as follows:

Completeness – the set U comprises all developed

use cases, necessary to described the functionality of

a system or a system’s compound element –

component, subsystem, etc.;

Consistency – all involved in U use cases are in

reasonable and logical harmony, without any

contradictions in their content;

Relevance – all involved in U use cases should

possess a direct and clearly identified connection to

the studied system’s functionality. For this factor

two measures have been applied – Recall and

Precision:

Recall measures how exhaustive a description of

the scenarios is. It can be calculated by the following

formula:

Recall = x / (x+y) * 100%, where

- x is the number of described in U relevant

scenarios,

- y is the number of the relevant, but not

described yet in U scenarios.

Precision measures the amount of noise in

scenarios description, based on the formula:

Precision = x / (x+z) * 100%, where

- x is the number of described in U relevant

scenarios;

- z is the number of described in U, but non-

relevant scenarios.

The last quality characteristic – Correctness, is

related to some scenarios errors in U, which have

An Approach to the Context-oriented Use Case Analysis

139

been found and fixed during the use case analysis. It

can be measured by the ratio of corrected scenarios

to the number of all scenarios described in the set U.

4 EXAMPLES

The usefulness and feasibility of our idea to apply

the CA method to use case analysis have been

examined for solving two real-life problems,

described below.

Case Study 1: How the CA can Support the

Iterative Use Case Development. The iterative use

case development is based on defining the initial

version of the use case and then - a repetitive

process of use case quality assessment and further

refinement. According to the results of assessment,

next iteration of the use case should be created

through some changes that improve the recent

quality content and functionality of the use case.

The CA with properly defined context can be used

as a form of research for communicating and

evolving a use case, as consecutive versions of the

use case are implemented within the following step-

wise procedure:

Step 1. Pre-analysis – description of a number of

real-life problems encountered during the activity

under consideration, for which the CA method

seems to be useful. During the iterative use case

development some additional information about the

current state should be gathered to decide how to

continue. From CA perspective this can be done as

follows:

 Creating a derivative quality model of the use

case, including only those quality characteristics

from the generic model, which are relevant to the

considered context;

 Evaluating the current version of a use case from

the point of view of different actors;

 Comparing two consecutive iterations of the

same use case to observe the effect of the

performed changes on the quality;

 Evaluating the last iteration of a use case to

decide how to proceed. In this situation the use

case estimates are compared with those of a

virtual “perfect” use case, whose current state is

described by the same quality characteristics, but

with preliminary assigned threshold values.

Step 2. Preparation – defining the CA context and

planning the CA implementation. The elements

(View, Goal, Object, Competitors, Task and Level)

of each case must be specified. The relevant sources

of information, needed for the CA performance, are

identified and made available. A CA plan is created,

describing some parameters of the work – duration,

cost, personnel involved, tasks and responsibilities

allocation and schedule.

For the above mentioned activities the possible

elements of a case can be:

View – that of any already identified participant in

use case analysis - user, IS developer or business

analyst;

Goal – to assess, to compare or any other, defined

by the CA Customer;

Object – a use case;

Competitors – an instance of a use case (and a

“perfect” use case for the last action for comparison

of the current use case with the “perfect” one);

Task – usually it is ranking;

Level – simple, middle or high.

Step 3. Construction – building a quality model,

corresponding to use cases quality content for a

defined case.

Step 4. Execution – evaluating the quality factors

and accomplishment of the CA Task.

As an example, let us describe this step in CA for

the case, designed for comparison of the last use

case version and the “perfect” use case. The final

results of the bottom up evaluation are presented in

an objects-factors matrix. In it the first row

comprises the threshold values, assigned to the

perfect use case, and the second row comprises the

results of use case evaluation (see Table 4).

Table 4: A filled objects-factors matrix.

Use case/

Factors

F1 Applicability

weight - 0.3

F2 Validity

w e i g h t - 0.2

Utility

w e i g h t - 0.5

Perfect

use case

1 1 1

Investigated

use case

0.8 0.7 1

Step 5. Completion - analysis, interpretation and

drawing conclusions from the results.

In the discussed case the deviation of the

estimated measures from the desired values for each

factor are calculated and described, in order to make

decision what to do further. The first possibility is to

continue with new iterations, trying to improve the

values for the second and the third factor. In this

case we have to define the scope and contents of

some additional use case refining activities. The

second possibility is to accept the achieved quality

level as appropriate and to stop analysing this use

case.

Fourth International Symposium on Business Modeling and Software Design

140

Case Study 2: How the CA Can Support the Use

Case Prioritization. One of the most difficult

problems in use case analysis is to create an ordered

list of all identified as important use cases. Such

prioritization will make possible to perform the use

case analysis in a more systematic and efficient way,

facilitating the proper distribution of the planned and

usually insufficient resources.

A Real-life Problem: After the use case quality

content assessment is done, it is necessary to assign

a priority to each use case in a given set of already

developed use cases.

Some cases for this problem can be defined as a

combination of the following elements:

View – can be that of the User, Business Analyst,

Project manager or IS Developer;

Goal – to compare the use cases, selected for

prioritization;

Object – use case;

Competitors – all developed use cases, chosen to be

prioritized;

Task – ranking to produce an ordered list of the

compared use cases;

Level – simple, middle or high.

5 CONCLUSIONS

The main purpose of this paper is to propose a

systematic approach to the creation and continuous

improvement of use cases, based on the

Comparative Analysis method. It supports the

decision making in some significant situations for

the use case analysis.

The basic advantage of the CA is the possibility

for adjustment to the context, specified by the

elements of the investigated case. The most difficult

activity – object quality modelling – has been

described and illustrated with models for two basic

objects – use case and a set of use cases. As

example, three CA successful implementations in

the field of use case analysis have been given.

Some possible directions for future work can be:

 To identify and describe entirely some other CA

situations within the use case analysis, so as to

enrich the collection of the re-used items –

situations, models, metrics, etc.;

 To examine the possibility to apply the CA to

other use case related activities as validating,

tracking, change management, design and

implementation of already defined use cases.

ACKNOWLEDGEMENTS

This work is partly supported by the National

Scientific Research Fund under the Contract ДТК

02-69/2009 and partially supported by Sofia

University “St. Kl. Ohridski” SRF/2014 under the

Contract “Successful Practices for Information

Systems Analysis and Design”.

REFERENCES

Anda, B., D. Sjøberg, 2002. Towards an Inspection

Technique for Use Case Models, In Proceedings of the

14th Int. Conf. on Software Engineering and

Knowledge Engineering, pp. 127-134.

Bowen, T., G.B. Wigle, J. Tsai, 1985. Specification of

software quality attributes, Software quality evaluation

guidebook, RADC-TR-85-37, vol.III.

Cockburn, A., 2000. Writing Effective Use Cases,

Addison-Wesley.

Denny, R., 2005. Succeeding with Use Cases: Working

Smart to Deliver Quality, Addison Wesley.

Kaloyanova, K., 2012. Design from Data: How To Use

Requirements for Better IS Analysis and Design,

Proceedings of the Int. Conference Informatics in

Scientific Knowledge, pp. 189-197.

Kruchten, P., 2004. The Rational Unified Process: An

Introduction, Pearson Education.

Larman, G., 2004. Applying UML and Patterns: An

Introduction to Object-Oriented analysis and Design

and Iterative Development, 3rd Edition, Prentice Hall.

Maciaszek, L., 2005. Requirements Analysis and System

Design, Addison-Wesley Longman, Inc.

Maneva, N., 2007. Comparative Analysis: A Feasible

Software Engineering Method, Serdica J. of

Computing, 1(1), pp. 1-12.

Pokorny, J. at all, 2010. Information Systems

Development: Business Systems and Services:

Modelling and Development, Springer.

Pressman, R., 2009. Software Engineering: A

Practitioner's Approach, 7th Edition, McGraw-Hill.

Sinnig, D., P. Chalin., F Khendek, 2009, LTS Semantics

for Use Case Models, In Proceedings of the 2009

ACM symposium on Applied Computing, pp. 365-370.

Sinnig, D., H. Javahery, 2010. Mastering Use Cases:

Capturing Functional Requirements for Interactive

Applications, In Proceedings of the 2nd ACM SIGCHI

symposium on Engineering interactive computing

systems, pp. 373-374.

Sommerville, I., 2011. Software Engineering, 9th Edition,

Addison Wesley.

Tornew, F., M. Ivarsson, F. Pettersson, P. Ohman, 2006.

Defect in automotive use cases, In Proc. of 2006

ACM/IEEE international symposium on Empirical

software engineering, pp.115-123.

An Approach to the Context-oriented Use Case Analysis

141
