Agent-based Simulations of Patterns for Self-adaptive Systems

Mariachiara Puviani

, Giacomo Cabri

and Franco Zambonelli

DIEF, Universit

a di Modena e Reggio Emilia, Via Vignolese 905/b, Modena, Italy

FIM, Universit

a di Modena e Reggio Emilia, Via Campi 213/b, Modena, Italy

DISMI, Universit

a di Modena e Reggio Emilia, Via Amendola 2, Reggio Emilia, Italy

Keywords:

Adaptation Pattern, Taxonomy, MAS.

Abstract:

Self-adaptive systems are distributed computing systems composed of different components that can adapt

their behavior to different kinds of conditions. This adaptation does not concern the single components only,

but the entire system. In a previous work we have identiﬁed several patterns for self-adaptation, classifying

them by means of a taxonomy, which aims at being a support for developers of self-adaptive systems. Start-

ing from that theoretical work, we have simulated the described self-adaptation patterns, in order to better

understand the concrete and real features of each pattern. The contribution of this paper is to report about the

simulation work, detailing how it was carried out, and to present a “table of applicability” that completes the

initial taxonomy of patterns and provides a further support for the developers.

1 INTRODUCTION

A complex distributed self-adaptive system consists

of multiple components that are deployed on multi-

ple nodes connected via some network (Weyns et al.,

2013), whose administration must be automated, to

avoid human manual management that would intro-

duce cost, duration, slowness, and error-proneness.

Self-adaptive systems can also optimize their perfor-

mance under changing operating conditions.

In order to build self-adaptive systems, develop-

ers can choose a speciﬁc adaptation pattern among

available ones. In a previous work we have cata-

loged them (Puviani, 2012b), and such a catalogue

turns out to be useful, because a pattern describes a

generic solution for a recurring design problem and

the application of these adaptation patterns helps to

develop a system that exhibits speciﬁc adaptation fea-

tures and that is able to self-adapt during all its life.

Often the same problem can be solved with differ-

ent approaches, which means that different adaptation

patterns can be used.

Starting from the catalogue of adaptation patterns,

we wrote a taxonomy table (Puviani et al., 2013) that

will help developer to choose the most suitable pattern

for their systems. Moreover, to better understand (and

take advantages from) the speciﬁc features of each

adaptation pattern and its applicability, we have simu-

lated the behaviour of different patterns. The simula-

tions allow us to deﬁne a “table of applicability” that

will complete the initial taxonomy of patterns.

In simulating self-adaptive systems we take ad-

vantages of agents. Software agents represent an

interesting paradigm to develop intelligent and dis-

tributed systems, because of their autonomy, proac-

tiveness and reactivity. In addition to that, their so-

ciality enables the distribution of the application logic

in different agents that can interact with each other

and with the host environment. In our work we use

Multi Agent Systems (Ferber, 1999) in order to sim-

ulate complex self-adaptive systems. This is because,

as said before, agents exhibit features very relevant

for self-adaptation.

Moreover, the chosen mechanism used to im-

plement adaptation patterns is the “role based ap-

proach” (Cabri and Capodieci, 2013). Roles are a set

of behaviours common to different entities, that can

be applied to the context in which a component is be-

having. An adaptive pattern can be described in terms

of the roles the different components play. This will

allow us to apply different roles to agents, in order to

simulate different adaptation patterns.

The remainder of this paper is organized as fol-

lows. Section 2 discusses related work in the area. In

Section 3 we present the taxonomy of adaptation pat-

terns and show some examples; while in Section 4 we

present the “role based approach” and how agents are

used o develop patterns. Section 5 presents a case

190

Puviani M., Cabri G. and Zambonelli F..

Agent-based Simulations of Patterns for Self-adaptive Systems.

DOI: 10.5220/0004925001900200

In Proceedings of the 6th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2014), pages 190-200

ISBN: 978-989-758-015-4

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

study and simulations implemented using RoleSys-

tem. Section 6 shows how these simulations help us

to enrich the initial taxonomy and validate the use of

adaptation patterns in developing self-adaptive sys-

tems. Section 6 discusses the results of the work and

concludes the paper.

2 RELATED WORK

The interest in engineering complex distributed self-

adaptive systems is growing more and more in the

last years, as shown by the number of surveys and

overviews on the topic (Cheng et al., 2009; Salehie

and Tahvildari, 2009; Weyns et al., 2012a). How-

ever, a comprehensive and rationally-organized anal-

ysis of architectural patterns for self-adaptation, and

their use, is still missing, despite the potential advan-

tages of such a contribution.

Going into details, some works are very relevant

considering patterns for adaptive systems. For exam-

ple, Gomaa et al. (Gomaa and Hashimoto, 2012) in-

troduce the concept of “software adaptation patterns”

and speciﬁes how they can be used in software adapta-

tion of service-oriented architectures. However, they

do not give a complete overview of their use.

Grounded on earlier works on architectural self-

adaptation approaches, the FORMS model (FOrmal

Reference Model for Self-adaptation) (Weyns et al.,

2012b) enables engineers to describe, study and eval-

uate alternative design choices for self-adaptive sys-

tems. FORMS deﬁnes a shared vocabulary of adap-

tive primitives that – while simple and concise – can

be used to precisely deﬁne arbitrary complex self-

adaptive systems, and can support engineers in ex-

pressing their design choices, there included those re-

lated to the architectural patterns for feedback loops.

Closest to our approach, Weyns et al. (Weyns et al.,

2012c) introduce the concept of patterns for self-

adaptive systems based on control loops. The authors

describe how control loops are able to enforce adap-

tivity in a system, and present a set of patterns, but it

is not clear how to chose between them.

In summary, the analysis of the related work in

the area shows that literature on adaptive systems is

very rich: patterns are a good mechanism that can be

adopted to promote and support self-adaptation, but

are not too much investigated, especially there is not a

clear idea on how to help developers to choose among

patterns for their systems. After our taxonomy pro-

posed in (Puviani et al., 2013), experiments that sup-

port the use of patterns to build self-adaptive systems

are still missing, and that is why we proceed with our

work. From our knowledge, there is no work that uses

agents to simulate self-adaptive systems, exception of

the use of AMAS proposed for example by (Bonabeau

et al., 1999) and (Georg

e et al., 2009).

3 USE OF PATTERNS

Because patterns are able to describe generic solu-

tions for a recurring design problem, their use to de-

sign self-adaptive systems is very relevant. Moreover,

a very important task to develop a well performing

self-adaptive system, is to understand which pattern

to choose. Deﬁning how a pattern works in a self-

adaptive system and which kind of systems is covered

by a speciﬁc pattern, we created a preliminary taxon-

omy presented in Figure 1 (Puviani et al., 2013).

This table describes the different patterns arranged

in different levels:

• the single components level – ﬁrst row;

• the ensemble level where the environment is con-

sidered as the means of adaptation (e.g. a bio-

inspired system) – second row;

• the ensemble level where adaptation is delegated

to an external agent called Autonomic Manager

(AM) that manages all the other agents (e.g. cen-

tralised system with regard to the adaptation as-

pects) – third row;

• the ensemble level where adaptation is delegated

to the agents themselves though their direct com-

munication of adaptation mechanisms – fourth

row.

How these patterns are useful to build self-

adaptive systems has been demonstrated in different

works like (Puviani, 2012a), (Puviani et al., 2012a),

(Puviani et al., 2012b) and (Mayer et al., 2013).

With the aid of this taxonomy table and the cata-

logue of pattern presented in (Puviani, 2012b), we are

able to understand which pattern can describe the de-

sired features of a system. For example, the table tells

us that to build a system where it is important that the

mechanisms for adaptation are shared between all the

components, one of the patterns of the fourth row can

be used.

However, to better understand the functionality of

adaptation patterns, we aim at deeper analysing, with

the aid of simulations, the use of adaptation patterns.

So, we started analysing the “basic” pattern of each

ensemble level (the single level is delegated to the in-

ternal of each agent)

For space reasons we report only the studies on the ﬁrst

column of patterns in the taxonomy table

Agent-basedSimulationsofPatternsforSelf-adaptiveSystems

191

Figure 1: Taxonomy of self-adaptation patterns based on different composition mechanisms.

Figure 2: Reactive Stigmergy SCE Pattern.

First of all we present in the next subsections the

studied patterns. For space limitations in the follow-

ing we only report the “context” of the system that

will apply that pattern, and its main “behaviour”.

3.1 Reactive Stigmergy Service

Components Ensemble Pattern

Context. This patterns has to be adopted when:

1. there are a large amount of components acting to-

gether;

2. the components need to be simple component,

without having a lot of knowledge in their inter-

nal;

3. the environment is frequently changing;

4. the components are not able to directly communi-

cate one with the other.

Behaviour. This pattern has not a direct feedback

loop. Each single component acts like a bio-inspired

component (e.g. an ant). To satisfy its simple goal, the

component acts in the environment that senses with

its “sensors” and reacts to the changes in it with its

“effectors”. The different components are not able

to communicate one with the other, but are able to

propagate information (their actions) in the environ-

ment. Than they are able to sense the environment

changes (other components reactions) and adapt their

behaviour due to these changes.

Figure 3: Centralised AM SCE Pattern.

3.2 Centralised AM Service

Components Ensemble Pattern

Context. This patterns has to be adopted when:

1. the components are simple and an AM is neces-

sary to manage adaptation;

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

192

2. a direct communication between components is

necessary;

3. a centralised feedback loop is more suitable be-

cause a single AM has a global vision on the sys-

tem;

4. there are few components composing the ensem-

ble.

Behaviour. This pattern is designed around an unique

feedback loop. All the components are managed by

a unique AM that “controls” all the components be-

haviour and, sharing knowledge about all the compo-

nents, is able to propagate adaptation.

Figure 4: P2P Negotiation SCE Pattern.

3.3 P2P Negotiation Service

Components Ensemble Pattern

Context. This patterns has to be adopted when:

1. the components are proactive;

2. the components need to directly communicate one

with the other to propagate adaptation.

Behaviour. Each component is managed by an inter-

nal and implicit AM. The components directly com-

municate one with the other with a P2P communica-

tion protocol.

4 AGENTS AND THE ROLE

BASED APPROACH

To evaluate patterns, we have implemented them us-

ing roles.

The “role theory” (Biddle, 1979) has been applied

to several computer science ﬁelds. For this reason

there are several deﬁnitions of the concept of role,

depending on the considered scenario. The interest-

ing feature of roles is that they can be used as a

paradigm to smartly model the view of a complex sys-

tem (Fowler, 1997). As the author said, role is deﬁned

as “a set of behaviours common to different entities,

with the possibility to apply them to an entity in order

to change its capabilities and behaviour”.

Roles are very important not only because can be

applied to existing entities to change their behaviour,

but also because they can be reused in different situa-

tions. For this reason they are considered as solutions

common to different problems, as the same way pat-

terns are considered as solutions common to different

systems. Roles can also be used to manage interac-

tions between components. These interactions are not

a priori deﬁned between components, but only occur

when the roles involved in the interaction are associ-

ated to components. It is important to note that roles

are tied to the local execution environment, thus they

represent context-dependent views of entities running

in that environment (B

aumer et al., 1998), granting

adaptability. Moreover roles grant portability and

generality: since they are tied to each interaction con-

text, they hide context details to components, which

are free to discard those “low-level” details. For all

these reasons role are deserving to build adaptation

patterns.

In order to play a role, a component must assume

it. In other words, a component must choose a speciﬁc

role, that means that the role assumption is consid-

ered an active process of the components adaptation.

In complex system, using the agent paradigm, we as-

sume that a role is a software component (e.g. a Java

class) that can be added to each service component

of the ensemble. In our approach, a role is modeled

as a set of capabilities and an expected behavior, both

related to the component (i.e. agent) that plays such

role.

Based on the concept of role, we exploit RoleSys-

tem (Cabri et al., 2003). RoleSystem is an interaction

infrastructure completely written in Java. This will

grant high portability and the capability to be associ-

ated with the main agent platforms. The agent plat-

form we chose to exploit RoleSystem is Jade (Bel-

lifemine et al., 2002), a FIPA compliant agent plat-

form.

The RoleSystem infrastructure is divided into two

parts, as shown in Figure 5: the upper one is inde-

pendent of the agent platform, while the lower part is

bound to the chosen agent platform (i.e. Jade).

As said before, agents are a key point of RoleSys-

tem. In applications exploiting the RoleSystem in-

frastructure, an agent is composed of two layers: the

subject layer, representing the subject of the role –

independent of the platform; and the wrapper layer,

which is the Jade agent in charge of supporting the

subject layer.

A speciﬁc agent, called Server Agent, is in charge

of managing the roles and their interactions for each

context/environment. It interacts with the wrapper

layer of agents by exchanging ACL messages format-

ted in an appropriate way.

Agent-basedSimulationsofPatternsforSelf-adaptiveSystems

193

Figure 5: RoleSystem: separation of domain.

Every agent is a subject that perform some actions

and on which some event can happened. So a “role”

is deﬁned as a set of actions that an agent assuming

that role can play, and a set of events that an agent

assuming that role can recognize. Based on this idea,

every agent can choose the role on its temporary and

immediate necessities.

We do not start from scratch, but starting from

the existing RoleSystem, we developed several Java

classes, both platform-independent and related to

Jade. The main platform-independent classes, that are

in the rolesystem.core and rolesystem.roles packages,

are reported in the UML diagram of Figure 6.

Figure 6: RoleSystem packages.

The connection between the subject layer and

the wrapper layer is granted by two Java objects,

instances of classes implementing respectively the

RoleSystem and RoleRegistration interfaces, which

provide methods to register agents with roles, to

search for agents playing a given role, to listen for

events and to perform actions. The RoleSystem inter-

face enables agents to perform preliminary operations

needed to assume a speciﬁc role; while the RoleRegis-

tration interface enables agents to perform operations

on the system via a speciﬁc registration (i.e., after that

the agent has assumed a role).

To play a role, an agent has to obtain an object that

implements the RoleRegistration interface, invoking

the reqRegistration method. The returned object rep-

resents the association between the agent and the spe-

ciﬁc role. As soon as an agent does not need to play

the assumed role, it can release the role registration

via the dismiss method. If the agent wants to assume

a role again (one just assumed or another one), it has

to require another registration via the reqRegistration

method.

A role is implemented by an abstract class, where

the features of the role are expressed by static ﬁelds

and static methods. The class that implements a role

has the same name of the role, and it is part of a pack-

age that represents the application scenario for such

role. A static and ﬁnal ﬁeld called ROLE ID identi-

ﬁes the role. Each action deﬁned in a role is built by a

static method, which is in charge of creating an appro-

priate instance of the class RoleAction and returning

it to the caller. Such a static method has the same

name of the corresponding action and one or two pa-

rameters: the former one is the agent addressee of the

event corresponding to the action; the latter param-

eter (optional) is the information content to perform

that action.

To perform an action, an agent playing a given

role must obtain the appropriate RoleAction instance,

invoking the corresponding static method of the role

class. Then, it has to invoke the doAction method of

RoleRegistration to actually perform the action, sup-

plying the previously created instance of RoleAction.

Then, when the server agent receives the request to

perform the action via the wrapper layer, translates

it into a known event, and sends it to the addressee

agent. To ﬁnd partners to interact with, an agent ex-

ploits the searchForRoleAgent methods made avail-

able by the RoleSystem interface, by which the agent

can get a list of the registrations related to a speciﬁc

role, each one speciﬁed by an identiﬁer.

Starting from RoleSystem we have implemented

a scenario of swarm robotics. There we develop ded-

icated Java classes representing the used roles (see

Section 5).

5 CASE STUDY

Since this work has been carried on in the frame-

work of the ASCENS project

, we use one of the case

study presented in the project to develop RoleSystem

http://ascens-ist.eu

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

194

classes and to implement different simulations.

In particular, we consider a swarm robotics sce-

nario: the disaster recovery scenario (Figure 7).

Figure 7: Disaster recovery scenario - ASCENS case study.

As reported in (Serbedzija et al., 2012), in the dis-

aster recovery case study, we imagine that a disas-

ter happened, such as the catastrophic failure of a nu-

clear plant, or a major ﬁre in a large building. We also

imagine that an activity of search and rescue must be

carried out. For instance, people may be trapped in-

side a building and they must be found and brought to

safety. Given the high danger of operating in such en-

vironment, it is realistic to think that an ensemble of

robots could be used to perform the most dangerous

activities. Among these activities, four are very rele-

vant: exploring the environment, mapping dangerous

areas and targets to rescue, performing the rescue, and

seal the dangerous areas. In particular, we analyse the

environment exploration task, to understand how dif-

ferent patterns behave in order to build such a system.

5.1 Environment Exploration

Implementation

In this scenario, an ensemble of robots (simulated by

agents) has the task to explore the environment in or-

der to map it. The ensemble is composed of a given

number of autonomous robots that are initially ran-

domly distributed in a room (e.g. each position is ran-

domly chosen once a robot is entered in the room).

The goal of the ensemble is strictly connected to the

utility of minimizing the time of completion of the

task. Another important utility of the system is to

provide an equal work balancing for all the compo-

nents that form the ensemble. A single robot does not

know in advance the number of components of the

ensemble. At the same way, the robot does not know

anything on the shape and the size of the environment.

To implement the simulations of this scenario we

have deﬁned a room of the size of 30x30 cells, with

15 obstacles in, randomly distributed. The obstacles

can be walls or something else (e.g. ruins from an

explosion), that cannot be removed by a robot. Due

to the size of the room we initially implemented 16

robots moving in (they are a right amount compared

to the size of the room, in order to be a swarm). In

Figure 8 we can see a screenshot of the environment.

Figure 8: Environment of the “environment exploration sce-

nario”.

In order to implement each pattern, we wrote one

or more speciﬁc role with RoleSystem, which robots

must play during their life.

The ﬁrst pattern we used to implement the sys-

tem was the “Reactive Stigmergy” pattern. This is

because the system’s requirements are well described

in the context of this pattern, and because usually, in

swarm robotics, the stigmergic mechanism is the one

that best ﬁts for adaptation.

For this pattern, we implemented the “Explorer”

role. With this role a robot starts to explore the cells in

its surrounding, following an anti-clockwise random

movement. Using the moveRandom(RoleRegistration

registration) method described in the following, a

robot leaves a pheromone every time it explores a new

cell, and when it senses this pheromone, left by other

robots in a cell, it is able to understand that this cell

has been explored by others. The simulation ends

when every robot does not ﬁnd any free cell unex-

plored (by itself) in a range of 10 cells. An example

of code of the “Explorer” role is reported in Figure 9.

We performed hundreds of simulations using this

pattern and in Figure 10 we show the average time of

the goal’s satisfaction (A), using 16 robots, and the

standard deviation. As we can see, the average time

is about 418000 millisec. In these simulations every

robot colors the pavement of the room (while it leaves

the pheromone) of a different colour. However, at the

end of these simulations, only few colors appear on

the screen. This is because it happens that most of

the time a robot explores again a cell just explored by

Agent-basedSimulationsofPatternsforSelf-adaptiveSystems

195

Figure 9: Code of the “Explorer” role.

Figure 10: Cross-section of 10 simulations that uses the Re-

active Stigmergy pattern.

another robot. This is a drawback of patterns based

on stigmergy.

To overcome this, we implemented the same sys-

tem using also the the “Centralised AM” pattern and

the “P2P” pattern.

For the “Centralised AM” pattern we imple-

mented the “Manager” and the “Slave” roles. An ex-

ample of code of the “Manager” role is reported in

Figure 11.

The manager, communicating with all the robots,

receives the information about their positions and the

explored area. Then it merges all the received infor-

mation to create a map of the explored area and it

shares this map with the other robots that are able to

understand the perimeter of the known area in order

to explore the exterior of that area.

An example of the code of the “Slave” role is re-

ported in Figure 12.

With this method the robot-slave is able to update

its knowledge with the data of all the other robots,

by updating its myKnownSquares variable with data

given by the manager.

The exploration ends if the built map ﬁnd a closed

perimeter explored (the perimeter is outlined by ob-

stacles in closed cells) or if all the robots do not ﬁnd

unexplored areas in the surrounding of a radius of 10

cells.

As we can see from Figure 10, adopting this pat-

tern the average time of the goal’s satisfaction (B) is

better than the same system developed using the “Re-

active Stigmergy” pattern; nevertheless, it remains

high (it was compared with expected results studied

in previous works). This is due to the need for co-

ordinating a large number of robots in an unknown

environment. The fact of not knowing the environ-

ment makes it very difﬁcult to well coordinate the

robots, because the manager knows the other robots’

positions and the explored area, but it does not know

which area still misses to be explored.

Moreover, if the AM fails (example not reported in

this simulation), it has to be replaced by negotiation.

Here, the simplest and less time consuming strategy

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

196

Figure 11: Example of the “Manager” role.

Figure 12: Example of the “Slave” role.

for negotiation is that the ﬁrst robot that senses the

AM is out of work, become the new AM. This so-

lution is also the most dangerous one because more

than one robot may become AM. Other solutions uses

negotiation algorithms.

Instead, the “P2P” pattern does not suffer from the

limitation of having a single point of failure. Further-

more, more than the “Reactive Stigmergy” pattern, in

this pattern the adaptation mechanism is shared be-

tween components. In the “P2P” pattern we devel-

oped the “Negotiator” role that permits a component

to share its knowledge with neighbours in a range of

Agent-basedSimulationsofPatternsforSelf-adaptiveSystems

197

Figure 13: Example of the “Negotiator” role.

10 cells and to negotiate with them which cell has to

be explored next.

An example of the code of the “Negotiator” role

is reported in Figure 13.

With this role the time necessary to exchange

adaptation messages between neighbours does not in-

validate the ultimate satisfaction of the goal: compo-

nents are able to coordinate themselves in little groups

and if some of them expire, the adaptation of the

whole system goes on, as the Negotiator role allows it.

Figure 10 shows the average time (C) in simulations

that use this pattern.

In Figure 14 we represent the comparison of the

use of the different patterns in term of time of goal

satisfaction. We can see that the “P2P” pattern has

on average the best performances related to the use of

the “Centralised AM” pattern without and with failure

of the AM, and related to the “Reactive Stigmergy”

pattern where the time is 120% more that the “P2P”

one.

6 CONCLUSIONS

As emerged from the simulations, where all patterns

end satisfying the goal, all the developed patterns

make it possible to have a self-adaptive system. How-

ever, in different conditions (due to the environment

or to other components of the system) simulations

Figure 14: Comparison of the average time of goal satisfac-

tion.

show that some perform better than others.

This implementation of different patterns on the

same case study, gives us the possibility to add impor-

tant speciﬁcation to the initial taxonomy. The analysis

of the different simulations reported above, permits us

to write a “table of applicability” that describes pat-

terns and their performances (see Figure 15). As said

before, due to space limitations, in this paper we re-

ported simulations and analysis only of the basic pat-

terns, one for each level of adaptation – ﬁrst column of

the taxonomy table (see (Puviani, 2012b)). Moreover,

we need to recall that, for each pattern, the addition of

an external manager over a component (that can be a

component or another AM) will add a level of auto-

nomicity but the way adaptation is propagated inside

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

198

Figure 15: “Table of applicability” of patterns.

the pattern remains the same for all the patterns of a

speciﬁc level (same row). We aim at extending the

simulations to other patterns in order to complete the

“table of applicability”.

In the table we can see which pattern better cre-

ates a self-adaptive system under certain conditions,

and which features a pattern shows. For example, if

we would like to develop a system where the environ-

ment is perfectly known from at least one component,

the “Centralised AM” pattern will perform better than

the “Reactive Stigmergy” SCE pattern. Otherwise, if

in our system we have no mechanisms for a direct

communication for adaptation between components,

the “Reactive Stigmergy” SCE pattern has to be pre-

ferred.

Agents enabled us to simulate patterns for com-

plex self-adaptive systems, and with the aid of adap-

tation patterns, users are able to develop the most

performative self-adaptive system, based on different

system conditions.

On this way future work can concern implement-

ing simulations in different scenarios that will conﬁrm

and complete our “table of applicability”.

ACKNOWLEDGEMENTS

Work supported by the ASCENS project EU FP7-

FET, Contract No. 257414.

REFERENCES

aumer, D., Riehle, D., Siberski, W., and Wulf, M. (1998).

The role object pattern. In Washington University

Dept. of Computer Science. Citeseer.

Bellifemine, F., Caire, G., Trucco, T., and Rimassa, G.

(2002). Jade programmers guide. Jade version, 3.

Biddle, B. (1979). Role theory: Concepts and research.

Krieger Pub Co.

Bonabeau, E., Dorigo, M., and Theraulaz, G. (1999).

Swarm intelligence: from natural to artiﬁcial systems.

Oxford University Press, USA.

Cabri, G. and Capodieci, N. (2013). Runtime Change of

Collaboration Patterns in Autonomic Systems: Mo-

tivations and Perspectives. In Proceedings of the

Ninth International Symposium on Frontiers of In-

formation Systems and Network Applications (FINA),

Barcelona, Spain, March 2013.

Cabri, G., Leonardi, L., and Zambonelli, F. (2003). Imple-

menting Role-based Interactions for Internet Agents.

In The 2003 International Symposium on Applica-

tions and the Internet (SAINT), Best Paper Award Or-

lando,Florida,USA, January 2003.

Agent-basedSimulationsofPatternsforSelf-adaptiveSystems

199

Cheng, B., de Lemos, R., Giese, H., Inverardi, P., Magee,

J., Andersson, J., Becker, B., Bencomo, N., Brun, Y.,

Cukic, B., et al. (2009). Software engineering for self-

adaptive systems: A research roadmap. In Cheng,

B., Lemos, R. d., Inverardi, P., and Magee, J., edi-

tors, Software Engineering for Self-Adaptive Systems,

volume 5525 of Lecture Notes in Computer Science,

pages 1–26. Springer.

Ferber, J. (1999). Multi-agent systems: an introduction to

distributed artiﬁcial intelligence, volume 1. Addison-

Wesley Reading.

Fowler, M. (1997). Dealing with roles. In Proceedings of

PLoP, volume 97, Monticello, Illinois, USA.

Georg

e, J.-P., Peyruqueou, S., R

egis, C., and Glize, P.

(2009). Experiencing self-adaptive mas for real-time

decision support systems. In Demazeau, Y., Pav

on,

J., Corchado, J., and Bajo, J., editors, 7th Interna-

tional Conference on Practical Applications of Agents

and Multi-Agent Systems (PAAMS 2009), volume 55

of Advances in Intelligent and Soft Computing, pages

302–309. Springer Berlin Heidelberg.

Gomaa, H. and Hashimoto, K. (2012). Dynamic self-

adaptation for distributed service-oriented transac-

tions. In Proceedings of the 2012 International Work-

shop on Software Engineering for Adaptive and Self-

Managing Systems, pages 11–20, Zrich, Switzerland.

IEEE Computer Society.

Mayer, P., Klarl, A., Hennicker, R., Puviani, M., Tiezzi, F.,

Pugliese, R., Keznikl, J., and Bure

s, T. (2013). The

Autonomic Cloud: A Vision of Voluntary, Peer-2-Peer

Cloud Computing. In Proceedings of 3rd Workshop

on Challenges for Achieving Self-Awareness in Auto-

nomic Systems, pages 1–6, Philadelphia, USA.

Puviani, M. (2012a). Adaptive System’s Conﬁguration in

a Swarm Robotics Scenario. Awareness magazine,

page 3.

Puviani, M. (2012b). Tr 4.2: Catalogue of architec-

tural adaptation patterns. Technical report, ASCENS

Project.

Puviani, M., Cabri, G., and Frei, R. (2012a). Self-healing

in Ensembles’ Adaptive Collaborative Patterns. In 1st

International Conference on Through-life Engineer-

ing Services (TESConf 2012), page 361367, Shriven-

ham, UK.

Puviani, M., Cabri, G., and Leonardi, L. (2012b). Adaptive

Patterns for Intelligent Distributed Systems: a Swarm

Robotics Case Study. In Proceedings of the 6th Inter-

national Symposium on Intelligent Distributed Com-

puting - IDC 2012, pages 241 – 246. Sringer.

Puviani, M., Cabri, G., and Zambonelli, F. (2013). A Tax-

onomy of Architectural Patterns for Self-adaptive Sys-

tems. In Sixth International C* Conference on Com-

puter Science & Software Engineering, pages 77–85,

Porto (P). ACM.

Salehie, M. and Tahvildari, L. (2009). Self-adaptive soft-

ware: Landscape and research challenges. ACM

Transactions on Autonomous and Adaptive Systems

(TAAS), 4(2):14.

Serbedzija, N., Massink, M., Brambilla, M., Latella, D.,

Dorigo, M., and Birattari, M. (2012). Ensemble model

syntheses with robot, cloud computing and e-mobility.

ASCENS Deliverable D, 7.

Weyns, D., Iftikhar, M., Malek, S., and Andersson, J.

(2012a). Claims and supporting evidence for self-

adaptive systems: A literature study. In Software

Engineering for Adaptive and Self-Managing Systems

(SEAMS), 2012 ICSE Workshop on, pages 89 –98.

Weyns, D., Malek, S., and Andersson, J. (2012b). Forms:

Unifying reference model for formal speciﬁcation of

distributed self-adaptive systems. ACM Transactions

on Autonomous and Adaptive Systems, 7(1):8.

Weyns, D., Schmerl, B., Grassi, V., Malek, S., Mirandola,

R., Prehofer, C., Wuttke, J., Andersson, J., Giese, H.,

and G

oschka, K. (2012c). On patterns for decentral-

ized control in self-adaptive systems. Software Engi-

neering for Self-Adaptive Systems II, pages 76–107.

Weyns, D., Schmerl, B., Grassi, V., Malek, S., Mirandola,

R., Prehofer, C., Wuttke, J., Andersson, J., Giese, H.,

and G

oschka, K. M. (2013). On patterns for decen-

tralized control in self-adaptive systems. In Software

Engineering for Self-Adaptive Systems II, pages 76–

107. Springer.

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

200
