Targeted Linked-data Extractor

Pierre Maillot

, Thomas Raimbault

, David Genest

and St

ephane Loiseau

ESILV, P

ole Universitaire L

eonard de Vinci, 12 avenue L

eonard de Vinci, Courbevoie, France

LERIA, Facult

e des Sciences d’Angers, 4 Boulevard Lavoisier, Angers, France

Keywords:

Semantic Web, Linked Data, Extraction.

Abstract:

The Linked Data Cloud is too big to be locally manipulated by standard computers and all use-cases doesn’t

need to manipulate the whole cloud. To get exactly what is needed for a speciﬁc use-case, we need to obtain

the speciﬁc parts from each bases of the Linked Data Cloud. This paper proposes a method to smartly extract a

sub-part of the Linked Data Cloud driving by a list of resources called seeds. This method consist of extracting

data starting from seed resources and recursively expanding the extraction to their neighbours.

1 INTRODUCTION

Linked Data

is not anymore the domain of Seman-

tic Web enthusiasts and academics. Today the Linked

Data Cloud counts more than 300 bases in different

domains, of sizes varying between a few hundred to

several billions statements (known as triples). As it

became more widely recognized, new uses have ap-

peared and to each use corresponds a speciﬁc part of

a base, or of the whole Linked Data Cloud.

When there is need to locally manipulate the

Linked Data Cloud, some use-cases only need

speciﬁcs sub-parts of bases of the Linked Data Cloud.

Currently only base dumps allow us to manipulate lo-

cally data from the Linked Data Cloud. But dumps

can not be easily exploited by human (because they

contain raw data) or by a standard machine (because

of their size). In this paper we propose a method to

smartly extract real parts of the Linked Data accord-

ing to given speciﬁcations.

Our motivation to develop such a method came

from a previous work where we needed a “mini

Linked Data Cloud” to evaluate a novel approach

for querying a set of RDF bases. Works in similar

situations (Bail et al., 2012; Schmidt et al., 2011;

Morsey et al., 2011; Schmidt et al., 2008) used either

raw dumps, or random-generated datasets, or present

their datasets in theory only, without access to the

tools they used. To meet our needs, we have extracted

some sub-parts of (real) data from the universal

DBPedia base to create different bases in accordance

http://linkeddata.org/

with speciﬁc domains of the Linked Data Cloud.

Our contribution in this paper is to propose both

a method and an implementation, driven by seed

resources, to extract a focused sub-part of the Linked

Data Cloud. These resources have to be selected

such as the extracted sub-part contains the expected

statements.

This article is organized as follow, in Section 2 we

recall some principles about the Semantic Web and

the Linked Data. Section 3 details the method to ex-

tract sub-part of RDF bases. Section 4 presents an

example of utilization of our tool to generate data for

a benchmark. Section 5 shows details of our imple-

mentation of the method of extraction.

2 THE SEMANTIC WEB TODAY

The semantic web, or Web of data, is a collabora-

tive movement led by the W3C and proposes some

common methods to store, share, ﬁnd and combine

information. Some specially designed languages are

proposed: RDF for data description, RDFS and OWL

for deﬁnition of ontologies. We do not provide here

complete deﬁnitions of these languages. We just re-

call that a RDF (Klyne and Carroll, 2004) document

contains triples as (subject,predicate,object), and such

a document can be seen as a labeled directed multi-

graph, where each triple is an arc between the node

that represents its subject and the node that repre-

sents its object. Figure 1 shows an example of an

336

Maillot P., Raimbault T., Genest D. and Loiseau S..

Targeted Linked-Data Extractor.

DOI: 10.5220/0004758503360341

In Proceedings of the 6th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2014), pages 336-341

ISBN: 978-989-758-015-4

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

RDF graph representation. In this ﬁgure, white nodes

represent factual resources and gray nodes represent

types of factual resources.

Figure 1: RDF document.

RDFS (Brickley and Guha, 2004) provides basic

elements for the description of ontologies intended

to structure RDF resources. RDFS allows to (i) de-

clare types of resources (rdfs:Class) and their proper-

ties (rdf:Property) ; (ii) specify the signature of prop-

erties (rdfs:domain and rdfs:range) ; (iii) specify the

inheritance links among classes (rdfs:subClassOf) or

among properies (rdfs:subPropertyOf). Figure 2 de-

scribes some classes and properties, and their inher-

itance links.

Figure 2: RDFS classes and properties.

A triplestore is a specially designed database for

storage and retrieval of RDF triples. In order to

query such a base, SPARQL (W3C, 2013) is the most

widely user language.

Linked Data

The Linked Data is a movement supported by a large

community, encouraging the publishing of open RDF

bases respecting three best practice rules:

• All resources must be represented by a dereferen-

cable URI.

• Bases must be interlinked

• Each base must be publicly accessible via a

SPARQL endpoint.

All Linked Data interlinked bases compose the

Linked Data Cloud, counting several hundred bases

in various domains and sizes. But today there is no

centralized authority maintaining a list of all available

bases. Currently the most complete list is available on

datahub

Table 1: Linked Data Cloud statistics by domains.

Domains Number

datasets

Triples %

Media 25 1,841 M 5.82 %

Geographic 31 6,145 M 19.43 %

Government 49 13,315 M 42.09 %

Publications 87 2,950 M 9.33 %

Cross-

domain

41 4,184 M 13.23 %

Life sciences 41 3,036 M 9.60 %

User-

generated

content

20 134 M 0.42 %

Total 295 31,634 M

Table 1 contains statistics

about the repartition of

Linked Data bases in major domains and their sizes

as of September 2011.

Table 2 contains information about 6 bases from

the Linked Data Cloud. These information where

produced by us in September 2013, using either

SPARQL1.1 endpoints where they were available (to

use queries containing the COUNT() function) or pro-

vided on the databases homepages. This table give a

quick overall sight of the diversity of the Linked Data

Cloud.

3 HOW TO EXTRACT FOCUSED

SUB-PARTS FROM LINKED

DATA SOURCES

Our goal is to extract from one or more RDF bases a

sub-part containing relevant statements according to a

speciﬁc topic. To drive the extraction to obtain the ex-

pected focused sub-part we use a set of resources from

which statements will be gradually extracted. The

extraction itself use a particular treatment for blank

nodes to avoid meaningless statement to be retrieved.

3.1 Driving the Extraction

As presented in (Kleinberg, 1999), on the Web it is

possible to extract a majority of authorities regard-

ing one topic by retrieving all connected pages to one

Non exhaustive list at: http://datahub.io/group/

lodcloud

from http://lod-cloud.net/state/

TargetedLinked-DataExtractor

337

Table 2: Statistics for some bases of the Linked Data Cloud.

Base # of

triples

# of

individ-

uals

# of

classes

# of

inter-

links

#1 instantiated

class

#2 instantiated

class

#3 instantiated

class

DBPedia

(en)

400M 3 770K 359 10

893K

foaf:Person

(33,61%)

dbOnto:Agent

(25,37%)

skos:Concept

(22,89%)

LOGD 9 951M 25 987M 248 5 787 purlConv:Cata-

logedDataset

(18,56%)

geo:Point

(7,68%)

logd:Point

(7,68%)

Enipedia 4 180K 2 102K 99 1 758 mediaWiki-

:Subject

(23,46%)

europa-

:Pollutant-

Release

(9,55%)

europa:Waste-

Transfer

(9,13%)

Jamendo 1 062K 290K 16 408 purlOnto-

:Playlist

(35,41%)

purlOnto:Signal

(15,72%)

purlOnto:Track

(15,72%)

LMDB 6 148K 503K 53 162K lmdb:ﬁlm

(17,01%)

lmdb:actor

(10,05%)

lmdb:director

(3,40%)

Revyu 20K 10K 5 75 redwood:Tag

(37,90%)

redwood-

:Tagging

(21,00%)

owl:Thing

(19,96%)

SW Dog

Food

539K 56K 92 603 foaf:Person

(16,39%)

swrcOnto-

:InProceedings

(7,11%)

foaf:Organi-

zation (4,90%)

known authority to a rank n. This approach has been

made ineffective for internet search algorithms be-

cause of the malicious use of links farm and others ex-

ploitations of algorithm properties, some of them are

listed in (Gyongyi and Garcia-Molina, 2005). How-

ever in the Semantic Web, we can adapt this idea by

extracting triples around selected resources (e.g. im-

portant resource about a given domain) to obtain most

of the relevant information in this domain. In this

case, instead of web pages, we obtain links around

a selected resource which all composed knowledge of

the domain.

We call seed a set of resources chosen to start the

extraction. The seed resources can be either classes

or individuals.

To extract the focused sub-part targeted by a seed

as target, we ﬁrstly use a DESCRIBE query about

each seed resource. In SPARQL, a DESCRIBE query

applied on a resource returns all triples containing this

resource both as subject and as object. The result

composes the ﬁrst rank of the extraction. Secondly

we list all new resources appearing in the previous re-

sulting triples and we repeat this operation on each of

them to retrieve the next rank extraction. The follow-

ing ranks are obtained by the same way.

Figure 3 is a graphical representation of an extrac-

tion from one seed resource to rank 2. Our extrac-

tor follow the algorithm 3.1, given a seed L

and a

maximum rank n. In other words this algorithm re-

cursively and non-naively extracts parts of RDF bases

by expanding the information on a selected resource

to its neighbours.

Figure 3: Extraction to rank 2 from one seed resource.

3.2 Parameters

To obtain a focused sub-part of the Linked Data Cloud

on a chosen topic there are two parameters to conﬁg-

ure the algorithm.

For a chosen topic, the seed has to contain target

resources linked to most of the relevant resources to

this topic. For example, the seed of an extraction can

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

338

Algorithm 3.1: Extraction of statements centred on a re-

source s.

Input: E : End point . SPARQL Endpoint

Input: s : Resource . Seed resource

Input: n : Integer . Extraction rank

Output: g : Triple set . Extracted statements

function EXTRACTSEEDRANK(E, s, n)

l = [] . Next rank resource list

if n > 0 then

g = Q

(E, s)

for all t ∈ g do

if sub ject(t) == s AND

isU RI(ob ject(t)) then

l+ = ob ject(t)

else

if ob ject(t) == s then

l+ = sub ject(t)

end if

. Hidden n-ary relations

if sub ject(t) == s AND

isBlankNode(ob ject(t)) then

g+ = Q

(E, t)

end if

end for

for all s

∈ l do

g+ = ExtractSeedRank(s

, n − 1)

end for

else

return g

end if

end function

Algorithm 3.2 : Request retrieving all triples with state-

ment x’s object as subject.

Input: E : Endpoint . SPARQL Endpoint

Input: x : Statement . (subject, predicate, object)

Output: g : Triples set

function Q

(E,x)

return result of query on E

CONSTRUCT {

object(x) ?var1 ?var2.

}

WHERE {

object(x) ?var1 ?var2.

}

end function

be a list of individuals from a given class or the class

itself (e.g. to extract some cinematographic informa-

tion from DBPedia we can use the “Movie” class, or

more precisely a list of all ﬁlms produced by Quentin

Tarantino).

The choice of the maximum rank of the extraction

limit the size on the extracted sub-part and also deter-

mines how much concentrated the sub-part of a base

will be around a seed resource. Note that in theory it is

possible to retrieve all statements of a base by choos-

ing the highest class in the ontology (e.g. rdfs:Resource

or owl:Thing) and a very high maximum rank. Even if

this extraction mechanism comes easily to mind, the

quality of the extraction result depends heavily on the

meticulous choice of the seed (as it is underlined in

(Morsey et al., 2011)).

Algorithm 3.3: Request retrieving all statements contain-

ing resource r as subject or object.

Input: E : Endpoint . SPARQL Endpoint

Input: r : Resource

Output: g : Triple set

function Q

(E,r)

return result of query on E

DESCRIBE r

end function

3.3 Hidden n-ary Relations

During an extraction, it could be possible to retrieve

some triples containing a blank node at the last ex-

tracted rank. This kind of triple can be paraphrased as

“this resource is linked to an unidentiﬁed resource”.

In RDF, blank nodes are used to represent anonymous

resources to enable the creation of n-ary relations in a

binary relation representation model. To avoid these

meaningless statements in the extraction process, we

regroup statements by considering blank nodes as hid-

den n-ary relations, as proposed in (Tummarello et al.,

2005). As a consequence, we consider all groups of

triples containing the same blank node in the same

rank.

Figure 4 shows that a naive extraction could con-

tain triples with a blank node as object, without the

triples giving them their meaning as an n-ary relation.

Figure 4: Schema representing the difference between a

naive extraction method and the extraction method, starting

from URI

to rank 1.

TargetedLinked-DataExtractor

339

Table 3: Distribution of class instantiation in DBPedia and in our extracted bases.

Base Person Place Organisation Work Other

DBPedia 23,12% 17,06% 5,48% 9,57% 44,76%

Academic

Journals

2,76% 1,78% 7,59% 41,29% 46,58%

Berlin 48,66% 8,09% 12,10% 5,63% 25,52%

Cat 34,21% 2,63% 2,63% 2,63% 57,89%

Elvis 9,54% 0,87% 1,95% 75,27% 12,37%

Legal Case 0,95% 0,00% 0,05% 0,08% 98,92%

Moon 0,40% 97,11% 0,13% 0,07% 2,28%

Paris 53,37% 2,18% 11,46% 5,08% 27,91%

Potato 3,23% 0,00% 9,68% 0,00% 87,10%

Tarantino’s

Movies

41,74% 0,41% 4,55% 7,02% 46,28%

Zola’s Books 1,47% 1,47% 0,00% 19,12% 77,94%

For instance, if a statement containing a blank

node b

as object appears at a rank n, then all state-

ments containing b

as subject must appear at rank

n, instead of appearing at rank n + 1 in a naive

approach. These groups of statements are called

Concise Bounded Description, proposed in (Stickler,

2005), and are considered as an optimal form of de-

scription of a resource. Figure 4 represents an extrac-

tion from the seed composed by the singleton {URI

}

to rank 1, considering the blank node between the

seed and both URI

and URI

as a 3-ary relation. So,

the rank 1 extraction contains the URI

to URI

4 USE-CASE: DATA

GENERATION FOR

BENCHMARKING

For some uses, especially for benchmarking, it is in-

teresting to locally handle data from the Linked Data

Cloud and specially only needed sub-part from this

big cloud to a given use-case. There is a limited of-

fer of benchmarks to evaluate query methods or en-

gines on the Linked Data. Most of these benchmarks

use dumps from the most known bases of the Linked

Data Cloud (Bail et al., 2012; Schmidt et al., 2011)

or use random generator (Schmidt et al., 2008). So,

the choice is either using huge bases with real data

or manageable bases with fake data. Using real data

at an acceptable scale for a “standard” computer

as base dumps often contain at least several million

triples.

In a previous work, to test a new approach for

querying a set of distant RDF bases, as presented in

(Raimbault and Maillot., 2013), we needed a mini-

Linked Data Cloud where each base is composed with

Less than 10 cores, less than 10Gb RAM.

real data on a speciﬁc domain, is small enough to be

processed in our experimental environment, and has a

SPARQL endpoint.

We present here the experience of an extraction

use-case we used in this previous work, according to

the method presented in Section 3. To evaluate our

approach we needed to evaluate different method of

querying the Linked Data Cloud. For practical rea-

son we chose to only use DBPedia, the biggest multi-

domain base in the Linked Data Cloud, to have the

same ontology for every base. Even with the same on-

tology we aimed to keep the “structural” differences

between each base as those between each base of the

Linked Data Cloud. These differences resided in the

instantiation distribution in each class for each base,

i.e. in each specialized domain, there is more indi-

viduals of the classes representatives of the domain

subject (e.g. Animal in Life Science, Document in

Publication, etc.) than others.

We extracted with 2 as maximum rank, 10 differ-

ent bases for our tests

. The seeds were chosen to

represent some speciﬁc domains of the Linked Data

Cloud:

• The Cat class (in the “Life Sciences” domain)

• The Scientiﬁc Journal class (in the “Publications”

domain)

• The Legal Case class (in the “Government” do-

main)

• The Potato individual (in the “Life Sciences” do-

main)

• The Moon individual

• The singer Elvis Presley (in the “Media” domain)

• The city of Paris (in the “Geographic” domain)

• The city of Berlin (in the “Geographic” domain)

by using our tool 10 times

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

340

• The list of all ﬁlms realized by Quentin Tarantino

(in the “Media” domain)

• The list of all books written by Emile Zola (in the

“Media” domain)

Table 3 shows the distribution of class instantiations

for each extracted base compared to their source DB-

Pedia

. The differences in instantiation repartition

show that the seeds-driven extraction returned bases

different from their source and different from each

other.

With our method, we created a set of bases shar-

ing common resources but treating different topics by

extracting speciﬁcs parts of a Linked Data base, al-

lowing us to evaluate our approach for querying a set

of base of the Linked Data Cloud at a manageable

scale.

5 IMPLEMENTATION

Our tool is based on bash scripts and simple java

tools

based on the Jena

framework.

Our tool is available at http://der3i.labs.esilv.fr/

download/RdfExtractor.zip

6 CONCLUSIONS

We have presented a method for extracting targeted

sub-part of RDF bases, driving by a list of selected re-

sources called seed. This method non-naively extracts

parts of a RDF base by recursively expanding the in-

formation on each selected resource and its neigh-

bours. This method can be used to create a dataset

with real data for benchmarking query approach on

several RDF base, as it is needed through the Linked

Data Cloud.

In future works we plan to use this method in a

process to create benchmarks for the Linked Data by

using statistics gathered during the extraction to au-

tomatically suggest associated queries. Furthermore

this method could be used as a tool in user interface

for the generation of RDF base summaries.

AKNOWLEDGEMENTS

This work has been funded by

Ecole Sup

erieure

d’Ing

enieur L

eonard de Vinci (ESILV) in the frame

Statistics about DBPedia are from http://wiki.

dbpedia.org

For the querying of a remote base.

http://jena.apache.org/

of the French cooperative project TIMCO, P

ole de

Comp

etitivit

e Systematic (FUI 13).

REFERENCES

Bail, S., Alkiviadous, S., Parsia, B., Workman, D.,

Van Harmelen, M., Goncalves, R. S., and Garilao, C.

(2012). Fishmark: A linked data application bench-

mark. In Joint Workshop on Scalable and High-

Performance Semantic Web Systems (SSWS+ HPCSW

2012), page 1.

Brickley, D. and Guha, R. V. (2004). RDF Vocab-

ulary Description Language 1.0: RDF Schema.

http://www.w3.org/TR/rdf-schema/.

Gyongyi, Z. and Garcia-Molina, H. (2005). Web spam tax-

onomy. In First international workshop on adversar-

ial information retrieval on the web (AIRWeb 2005).

Kleinberg, J. M. (1999). Authoritative sources in a hy-

perlinked environment. Journal of the ACM (JACM),

46(5):604–632.

Klyne, G. and Carroll, J. J. (2004). Resource Descrip-

tion Framework (RDF): Concepts and Abstract Syn-

tax. http://www.w3.org/TR/rdf-concepts/.

Morsey, M., Lehmann, J., Auer, S., and Ngomo, A.-C. N.

(2011). Dbpedia sparql benchmark–performance as-

sessment with real queries on real data. In The Se-

mantic Web–ISWC 2011, pages 454–469. Springer.

Raimbault, T. and Maillot., P. (2013). Vues d’ensembles de

documents RDF. In Actes du 31

eme congr

es INFOR-

SID, pages 387–402, Paris, France.

Schmidt, M., G

orlitz, O., Haase, P., Ladwig, G., Schwarte,

A., and Tran, T. (2011). Fedbench: a benchmark suite

for federated semantic data query processing. In The

Semantic Web–ISWC 2011, pages 585–600. Springer.

Schmidt, M., Hornung, T., Lausen, G., and Pinkel, C.

(2008). Sp2bench: A sparql performance benchmark.

CoRR, abs/0806.4627.

Stickler, P. (2005). Concise bounded description.

W3C Member Submission. http://www.w3.org/

Submission/CBD/.

Tummarello, G., Morbidoni, C., Puliti, P., and Piazza, F.

(2005). Signing individual fragments of an rdf graph.

In Special interest tracks and posters of the 14th inter-

national conference on World Wide Web, pages 1020–

1021. ACM.

W3C (2013). SPARQL 1.1 Query Language. http://

www.w3.org/TR/sparql11-overview/.

TargetedLinked-DataExtractor

341
