AUTOMATING COMPLIANCE FOR CLOUD

COMPUTING SERVICES

Nick Papanikolaou

, Siani Pearson

, Marco Casassa Mont

and Ryan Ko

Cloud and Security Lab, HP Labs, Bristol, United Kingdom

Cloud and Security Lab, HP Labs, Singapore

Keywords: Cloud Computing, Compliance, Accountability, Natural Language Processing, Policy Enforcement.

Abstract: We present an integrated approach for automating service providers’ compliance with data protection laws

and regulations, business and technical requirements in cloud computing. The techniques we propose in

particular include: natural-language analysis (of legislative and regulatory texts, and corporate security

rulebooks) and extraction of enforceable rules, use of sticky policies, automated policy enforcement and

active monitoring of data, particularly in cloud environments. We discuss ongoing work on developing a

software tool for natural-language processing of cloud terms of service and other related policy texts. We

also identify opportunities for future software development in the area of cloud computing compliance.

1 INTRODUCTION

This paper presents tools and techniques for

automating compliance with law, regulations, and

other requirements, particularly in the context of

cloud computing. The most widely used definition

of cloud computing is by NIST (refer to (Mell and

Grance, 2011) for details on the service and

deployment models mentioned):

“Cloud computing is a model for enabling

convenient, on-demand network access to a shared

pool of configurable computing resources (e.g.,

networks, servers, storage, applications, and

services) that can be rapidly provisioned and

released with minimal management effort or service

provider interaction. This cloud model promotes

availability and is composed of five essential

characteristics, three service models, and four

deployment models.”

What makes compliance difficult for providers

of cloud computing services (referred to heretofore

as cloud service providers) is the sheer number and

complexity of laws and regulations that need to be

understood and enforced in their systems. Cloud

service providers tend to host their customers' data

and the computing infrastructure they use in several,

disparate data centers, which are physically located

in several different jurisdictions. If a customer's data

is stored in a data center located in Germany, for

example, it will be subject to German data protection

law, which is much more restrictive than data

protection law in many other countries. In addition

to national laws and regulations, there are

international agreements and treaties regarding the

transfer of data between different jurisdictions (aka.

transborder data flows), and the US-EU Safe

Harbor agreements are a well-known example.

Cloud service providers are expected to take all the

relevant rules into account and take appropriate

measures.

The way a cloud service provider handles its

customers’ data is usually specified in a written

contract or agreement which comprises the ToS

(Terms of Service) and SLA (Service Level

Agreement). No commonly accepted standard exists

for the format or content of cloud ToS and SLAs,

nor any consensus about the expected security and

privacy practices of service providers.

This poses difficulties for customers and

providers alike, who have expectations (and duties)

with regards to a given service offering. End-users

require clarity and understanding on issues such as:

• how long a provider keeps data which has been

stored or exchanged through its cloud services;

• how and when such data is destroyed;

• what remediation procedure exists in case of

data loss and in case of data breach,

• to what extent data will be shared with parties

external to the service provider and for what

631

Papanikolaou N., Pearson S., Mont M. and Ko R..

AUTOMATING COMPLIANCE FOR CLOUD COMPUTING SERVICES.

DOI: 10.5220/0003976906310637

In Proceedings of the 2nd International Conference on Cloud Computing and Services Science (CloudSecGov-2012), pages 631-637

ISBN: 978-989-8565-05-1

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

purpose (e.g. targeted advertising).

Enterprise customers typically require

assurances regarding:

• service availability (e.g. estimated downtime per

calendar month);

• cost of basic services versus added-value

offerings;

• how data stored by a provider is kept isolated

from other customers’ data (particularly for

multi-tenancy arrangements);

• encryption methods used, if any, and

authentication technologies;

• backup methods and regularity of backup;

• remediation procedures and compensation

offered in cases of data loss and data breach.

Although the field of cloud computing still lacks

well-defined standards and best practices, they are

actively being developed, and it is likely that cloud

service providers will have a business need to adopt

them in the future. This introduces another level of

compliance and, unless cloud service providers are

equipped with appropriate controls and tools, much

manual effort may be required to achieve it.

There is also a need for tools that ensure what

we might call self-compliance, namely compliance

of a cloud service provider with its own stated

policies. To date there is no obvious way of ensuring

that the Terms of Service stated by cloud service

providers are actually adhered to fully in practice.

We are interested in developing software tools to

enable cloud service providers to be accountable

with regards to their data governance practices. In

the context of this paper accountability refers to the

goal of preventing harm to a cloud provider's

customers by enforcing adequate protections on

these customers' data, and having available effective

reporting and auditing mechanisms. See (Pearson,

2011) for a discussion of definitions of

accountability.

While accountability in the broadest sense can be

guaranteed only through a combination of law,

regulation and technical enforcement mechanisms

(e.g. in the context of privacy, such mechanisms are

Privacy Enhancing Technologies), our focus is on

the technical aspects. What is practically required

for a cloud provider to be accountable is a set of

tools to track the location, flows, and accesses of its

customers' data. As we shall see, this capability

allows a provider to readily demonstrate compliance

to the law and adherence to all relevant regulations

and other restrictions. More importantly, this

capability allows any instances of non-compliance to

be detected easily, so that suitable corrective action

can be taken.

There is currently no widely accepted

methodology or toolset for technically achieving

accountability in cloud computing, with potential

solutions being heavily dependent on the particular

platform and virtualization technology used by a

vendor. What is clear is that a variety of mechanisms

need to be put into place to protect against data

leakage and to enforce legislation and other related

restrictions on the storage and transfer of data,

especially across national borders.

This paper presents ongoing work on developing

software tools to automate compliance in the cloud,

particularly natural-language processing of cloud

a framework enabling cloud service providers to

achieve accountability. Finally the paper identifies

several classes of software tools to develop in the

future, in order to further automate accountability in

the cloud.

1.1 Previous and Related Work

In previous work the authors have developed

technical mechanisms for controlling the flow of

data in an IT infrastructure, notably through the use

of privacy controls (Casassa Mont et al., 2010) ,

sticky policies (Pearson et al., 2011) , and policy

enforcement (Papanikolaou et al., 2011). Although

the cited works do not specifically focus on cloud

computing scenarios, we expect these techniques to

be readily extendable and adaptable to suit the needs

of a cloud service provider.

• Comparison of policies and decision support

• Automated enforcement of security and privacy

rules

Related work in the context of website privacy

policies includes May and Gunter’s formalism of

policy relations, which are formal relationships

defined over the intended semantics (or the authors’

interpretation thereof) of P3P (May et al., 2009) . In

a previous paper (Papanikolaou et al., 2011) we

developed a mapping from P3P to CSP, enabling

direct comparison of privacy policies using the

model-checker FDR.

The EnCoRe research project is developing a

platform for expressing and enforcing privacy

preferences for personal data; recent case studies

include a system for managing data held within an

enterprise’s HR systems, and health data stored

about individuals and tissue samples in a biobank.

Through the use of a suitable policy enforcement

architecture, legal and regulatory privacy rules,

along with individuals’ privacy preferences, can be

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

632

automatically enforced so that unauthorized and/or

unsuitable access to data is prevented. In (Casassa

Mont et al., 2010) we proposed a simple conceptual

model for representing privacy rules, which can be

directly mapped to technically enforceable access

control policies (expressed e.g. using XACML).

2 TECHNIQUES FOR

EXTRACTING AND

ENFORCING SECURITY AND

PRIVACY RULES IN CLOUD

COMPUTING

INFRASTRUCTURE

We are working on tools to automate many of the

processes required to ensure that a provider is

accountable, although we recognise the difficulty of

mapping and linking legal and regulatory

requirements - which are high-level and expressed in

natural language - to technically enforceable policies

on particular data items.

Key techniques that should be used to achieve a

significant degree of automation include:

Natural-language processing, in particular,

extraction of policy rules from legislative and

regulatory texts and corporate rulebooks; these rules

should be represented in a form that can be

interpreted by a technical enforcement mechanism

(esp. a Policy Enforcement Point or PEP), but

possibly also so that they can be incorporated into a

compliance checker of information governance

software (cf. Governance / Risk Management

Compliance (GRC) Platforms, widely used in

industry). It should be noted here that no natural-

language processing system can operate with 100%

accuracy, but use of such systems can help to reduce

significantly the overall amount of human

intervention in the process of policy creation and

management. In this paper we present two

techniques involving natural-language processing,

that we are currently investigating:

• automated information extraction

• segmentation and tagging of terms of service for

decision support

Use of sticky policies: by strongly binding

policies to the data they are associated with, it is

easier for providers to control accesses to data

within their cloud infrastructure and there is no need

for a central policy repository. From the point of

view of automating accountability, the use of sticky

policies is a very useful technique. Sticky policies

provide a means of data encryption, since the data

which a policy is bound to cannot be accessed unless

that policy is complied with.

Automated policy enforcement: the

deployment of control points throughout a cloud

provider's infrastructure where policy rules can

automatically be enforced and human users only

notified in case of failure or error is essential. We

refer to the following current and future HP Labs

European and TSB research projects for more

related work on policy enforcement: EnCoRe,

Information Stewardship in the Cloud, and

TrustDomains.

Active monitoring for compliance: we believe

that it is fundamental for cloud providers to have in

their infrastructure mechanisms for automatically

detecting compliance problems and potential sources

of such problems. It is possible to formulate and

regularly check system invariants corresponding to

conditions that should never occur at certain end

points, such as links between a provider's data

centres, and particularly cross-border links.

There is scope for integration of several of the

different approaches described so far into a natural-

language processing pipeline, which can be

integrated with technical enforcement mechanisms

to achieve compliance for privacy: this starts with

the initial task of analysing natural-language privacy

texts, to the extraction of formalized rules and their

automatic enforcement. We are working on

developing tools for automating privacy in cloud

computing and, for this, natural-language analysis of

provider ToS, international laws and regulations will

need to be combined with suitable enforcement

methods such as distributed access control, sticky

policies and policy-based obfuscation.

Figure 1 depicts the integration of the techniques

mentioned as a pipeline; each arrow shows a flow

between processes. The processing of raw text

describing laws, regulations, business rules and

machine-readable rules are to be typically performed

outside the cloud service provider’s infrastructure,

while the resulting machine-readable rules are fed

into the infrastructure to enforce appropriate control

on the customers’ data. The mechanisms of policy

enforcement, and particularly the use of sticky

policies which are attached to data, are to be

implemented within the cloud service provider’s

infrastructure.

AUTOMATINGCOMPLIANCEFORCLOUDCOMPUTINGSERVICES

633

Figure 1: Extracting and enforcing cloud terms of service using a semi-automated tool.

Figure 2: Extracting and enforcing cloud terms of service using a semi-automated tool.

3 A SOFTWARE TOOL FOR

ANALYSING CLOUD TERMS

OF SERVICE

Figure 2 presents our current model for analysing

cloud terms of service.

We are developing a tool for marking up and

extracting information from cloud terms of service,

namely, the contract documents that describe a

customer’s relationship with a cloud service

provider. Our tool is not fully automated as it

requires, as a first step, a human user to indicate

which sections of such documents describe which

types of rules; this process is referred to as semantic

annotation. Our tool provides a text editor with

functions to highlight portions of text that describe

restrictions, obligations, and other types of

constraint with a particular colour. Output from the

tool includes a marked-up version of the original

contract, with semantic tags. This output can then be

fed into a separate processor, which is work in

progress, whose functions include information

extraction and rule generation. These functions are

described in more detail next.

3.1 Automated Information Extraction

Having analysed several real-world cloud ToS, we

have observed that:

• Cloud ToS are almost always formatted as

rich-text web documents with headings and

numbered paragraphs (“clauses” – in the legal

sense, not the grammatical sense of the word).

• Significant portions of these texts contain

disclaimers, enabling the service provider to

refuse being held accountable in certain cases

(these parts of the ToS actually state what the

provider will not be expected to do, rather than

what the provider’s actual practices are).

• If a service provider has several similar

offerings (e.g. in the case of AWS) there will

typically be two documents of interest – (i) a

core agreement which sets out the main terms

of service, and (ii) separate ToS for each of the

different offerings (e.g. in the case of AWS

offerings include: EC2, S3, EBS, SQS, SNS,

SES, VPC, FWS, SimpleDB, GovCloud). See

http://aws.amazon.com for more details on

these services.

DataProtectionLaws

IndustryRegulations

StandardsandBestPractices

CloudTermsofService

Processingof

RawText

Generationof

machine‐

readablerules

Rule

Database

Policy

Enforcement

Engine

Customer

Data

StickyPolicies

ActiveMonitoring

CLOUDSERVICEPROVIDER’SINFRASTRUCTURE

CloudTermsofService

Semantic

Annotation

Information

Extraction

Rule

Generation

Policy

Enforcement

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

634

A recent legal research paper (Bradshaw et al.,

2010) documented the features and caveats of

different cloud service level agreements, including

discussions of both the general service descriptions

and the terms and conditions available online.

While a cloud service provider may employ legal

experts to draw up their terms and conditions in

writing, it is the developers and system

administrators that are responsible for making sure

these terms are indeed enforced in the infrastructure

used for a particular cloud offering. It is in the

interest of the latter to have machine readable rules

that are in 1:1 correspondence with the statements

made in the written ToS.

Natural-language analysis of the written ToS can

certainly assist in the creation of such rules; if the

written style of an ToS is very prescriptive,

enforceable rules are easier to generate

automatically. Otherwise human intervention will be

required to ensure that generated rules are:

• correct: namely, that they express what actions

a system needs to implement to make sure the

requirements of the ToS are fulfilled on a

constant basis;

• as complete as possible: namely, that the

machine readable rules capture all those aspects

of the ToS that can be enforced automatically.

We are not aware of any previous work that

addresses the whole lifecycle of natural-language

analysis of privacy texts with the goal of enforcing

suitable rules, e.g. in an enterprise setting (although

the EU CONSEQUENCE project mentioned before

does take an holistic approach it does not involve

natural-language analysis). As stated in the

Introduction, achieving compliance with privacy

legislation and regulations is a central concern in

enterprises, and means of automating compliance are

highly desirable. Since new privacy rules are almost

exclusively expressed using natural-language, means

of automatically analysing the appropriate texts and

extracting rules from them necessary – the resulting

rules can then be incorporated into existing

enterprise rule-bases, such as those used in

compliance checkers or information governance

(GRC) platforms.

The most naïve analysis seeks to find in the text

of an ToS occurrences of particular verbs, namely

verbs which are prescriptive by nature; examples

include:

“The Provider will provide a backup of data

[…]”;

“The User will not upload pornographic images

to the service”

since these typically arise in statements expressing

duties and obligations (see also (Bradshaw et al.,

2010; Breaux et al. 2011; Breaux et al., 2006 )).

Certain verb groups appear in phrases expressing

rights, typically rights of the customer but not

necessarily:

“The Customer may request in writing a full

copy of data held [...]”

“The Provider can refuse to provide access to the

service at any time [...]”

In the case of simple prescriptive sentences it is

possible to represent the information given by a

triple

(verb, subject, object)

In a Prolog program this would be declared as a

Horn clause of the form

verb(subject, object).

Such a representation says nothing of the nature

of the rule or (legal) clause appearing in the ToS, but

may assist a service provider in automatically

generating a set of access control rules for

enforcement within its infrastructure. Our tool uses a

form of markup referred to as a formal requirements

specification language (RSL); the RSL we are using

is due to Breaux and Gordon (Breaux and Gordon,

2011).

3.2 Semantic Annotation and Tagging

of Cloud Terms of Service

Extending the method of simple analysis presented

in the previous section, our tool is designed to detect

delimiters and punctuation, so that long-winded

sentences of legalese may be separated into their

constituent parts. In a given sentence, those

secondary clauses, which serve only to explicate

and/or amplify the main thrust of the sentence, may

be ignored (subject to interpretation and the

judgment of a human user, of course; this suggests

the process cannot be completely automated), and a

semantic representation can be built of the remaining

constituents of the sentence.

An interesting toolkit that we are considering to

use to automate part of this task is GATE (“General

Architecture for Text Engineering”) (Cunningham et

al., 2011) , whose user interface provides a helpful

facility for tagging and colour-coding portions of

text of particular semantic relevance. The technique

that applies here is known as semantic annotation.

We believe that such an approach is highly

beneficial for the visual representation of the terms

and conditions contained in a given cloud ToS.

AUTOMATINGCOMPLIANCEFORCLOUDCOMPUTINGSERVICES

635

4 APPLICATIONS AND FUTURE

WORK

Here we discuss applications of the above

techniques and particularly, what other types of tools

need to be developed to improve compliance in

cloud computing.

4.1 Decision Support Tools

We believe that being able to efficiently (and

automatically) extract security and privacy

stipulations from cloud ToS is also a key business

advantage, enabling decision support in enterprises

for the selection of cloud services and providers as

necessary during the course of their daily operations.

4.2 Software Tools for Visualising and

Understanding Policies

It has often been noted that presenting privacy

policies and similar documents describing terms and

conditions directly to end-users rarely draws their

attention, and often users tend to click through any

agreements of this sort if they require access to a

service, thus ignoring details which could have

significant consequences to them and their data.

Since cloud services are almost exclusively

purchased online, and terms and conditions are

always presented on-screen to users, it is unlikely

that customers of these services will pay due

attention to the fine print; we believe that security

and privacy policies should be presented in a more

visually appealing fashion, which aids

comprehension and allows users to compare

competitors’ data handling practices. This idea is

certainly not new, and several previous authors have

developed and demonstrated ways to help users

visualise and understand terms and conditions; the

P3P policy language (Cranor et al., 2002) was

designed in part to allow the development of visual

tools to understand privacy policies. Research

projects such as PRIME, PrimeLife, and EnCoRe

have developed user interfaces and dashboards for

privacy settings and preferences. Clearly these

efforts need to continue and be extended to

applications specific to cloud computing.

Through analysis of cloud ToS, it should

certainly be possible to generate comprehensible

visual representations of a service providers’

security and privacy practices. Of course, unless

such representations are standardised, this task will

be non-trivial.

4.3 Software Tools for Checking

Compliance of Cloud Terms of

Service with Prevailing Laws,

Regulations and Standards

Cloud service providers are likely to audit their

systems on a regular basis to ensure that their

policies are valid and conform to current law,

standards and best practices, adapting ToS and

actual practices as necessary.

From this perspective, natural-language analysis

can be used to extract rules from legislation and

standards; these rules can then be compared and

contrasted to ToS rules, triggering changes and

extensions as required.

The extraction and representation of policy rules

can then be seen as but the first part in a larger

process or lifecycle. ToS have to be maintained,

adapted, enforced, and audited. One can envisage

how metrics for similarity of ToS can be defined or

other measures for determining the degree of

compliance to a particular industry best practice.

This is clearly a very promising direction for

investigation, with important implications for

enterprises.

4.4 Software Tools for Generating

Model or Template Cloud Terms of

Service

Natural-language analysis of cloud ToS can help to

detect language patterns that are common to such

texts. This could be extremely useful in designing

templates or ‘model ToS’. To have industry

agreement on what constitutes a model ToS would

be an important step for cloud computing, and

hopefully pave the way for the establishment of

standard policies and commonly agreed security

levels.

Taking this further, it is possible to develop

natural-language generation tools which

mechanically produce the text of cloud ToS for

particular applications. If standards were to be

established for the security levels specified by cloud

ToS, the format and content of these documents

would be well-established, making document

generation significantly automatable.

5 CONCLUSIONS

We believe that it is beneficial and possible for

cloud service providers to automate a number of

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

636

tasks related to the requirement of accountability.

We have identified some specific techniques,

namely: natural-language analysis of law, regulation

and corporate guidelines on security and privacy of

customer data in order to generate technically

enforceable policies; use of sticky policies to

achieve a strong binding between data and the

stipulations that apply to the use and dissemination

of that data; and active monitoring of a cloud

provider's infrastructure to detect potential

compliance problems. More in-depth analyses of

ways to achieve accountability in the cloud are

available in some of our previous work (see also

(Casassa Mont et al., 2010); (Pearson, 2011);

(Pearson et al., 2011) ; (Mowbray et al., 2010) ; (Ko

et al., 2011a) ;(Ko et al., 2011b) ).

Our main contribution in this paper has been to

describe ongoing work on developing software tools

for automated information extraction of cloud terms

of service, and to identify classes of related software

tools needed to achieve full accountability in cloud

computing. There is clearly much work to be done to

achieve this important goal for the sake of future

cloud service users.

REFERENCES

Mell, P., Grance, T. The NIST Definition of Cloud

Computing: Recommendations of the National

Institute of Standards and Technology. NIST Special

Publication, 2011, 800-145.

Bradshaw, S., Millard, C., Walden, I. 2010. Contracts for

Clouds: Comparison and Analysis of the Terms and

Conditions of Cloud Computing Services. Queen

Mary University of London, School of Law Legal

Studies Research Paper No. 63/2010.

Breaux, T. D., Gordon, D. G. 2011 Regulatory

Requirements as Open Systems: Structures, Patterns

and Metrics for the Design of Formal Requirements

Specifications. Technical Report CMU-ISR-11-100,

Institute for Software Research, Carnegie-Mellon

University.

Breaux, T. D., Vail, M.W., and Antón, A.I. 2006. Towards

Regulatory Compliance: Extracting Rights and

Obligations to Align Requirements with Regulations.

In Proceedings of 14th IEEE International

Requirements Engineering Conference (RE’06), 2006.

Cunningham, H., Maynard, D., Bontcheva, K., Tablan,

V., Aswani, N., Roberts, I., Gorrell, G., Funk, A.,

Roberts, A., Damljanovic, D., Heitz, T., Greenwood,

M.A., Saggion, H., Petrak, J., Li, Y., Peters, W. 2011.

Text Processing with GATE (Version 6). Department

of Computer Science, University of Sheffield.

Cranor, L., Langheinrich, M., Marchiori, M., Presler-

Marshall, M., Reagle, J. 2002. The Platform for

Privacy Preferences 1.0 (P3P1.0) Specification. W3C

Recommendation.

May, M., Gunter, C., Lee, I., Zdancewic, S. 2009. Strong

and Weak Policy Relations. In Proceedings of the

2009 IEEE International Symposium on Policies for

Distributed Systems and Networks (POLICY '09).

IEEE Computer Society, Washington, DC, USA, pp.

33-36, 2009.

Papanikolaou, N., Creese, S., Goldsmith, M. Refinement

checking for privacy policies. Science of Computer

Programming. Article in Press, DOI:10.1016/

j.scico.2011.07.009.

Casassa Mont, M., Pearson, S., Creese, S., Goldsmith, M.,

Papanikolaou, N. A Conceptual Model for Privacy

Policies with Consent and Revocation Requirements.

In Proceedings of PrimeLife/IFIP Summer School

2010: Privacy and Identity Management for Life,

Lecture Notes in Computer Science, Springer (2010).

Pearson, S. Toward Accountability in the Cloud. View

from the Cloud, IEEE Internet Computing, IEEE

Computer Society, July/August issue, vol. 15, no. 4,

2011.

Pearson, S., Casassa Mont, M., Kounga, G. 2011.

Enhancing Accountability in the Cloud via Sticky

Policies. Secure and Trust Computing, Data

Management and Applications, Communications in

Computer and Information Science, vol. 187, Springer

Verlag, Heidelberg, pp. 146-155.

Mowbray, M., Pearson, S. and Shen, Y. 2010. Enhancing

privacy in cloud computing via policy-based

obfuscation. Journal of Supercomputing. DOI:

10.1007/s11227-010-0425-z.

Ko, R. K. L, Jagadpramana, P., Mowbray, M., Pearson, S.,

Kirchberg, M., Liang, Q., Lee, B.S. 2011a.

TrustCloud: A Framework for Accountability and

Trust in Cloud Computing, 2nd IEEE Cloud Forum for

Practitioners (ICFP), IEEE Computer Society,

Washington DC, USA.

Ko, R.K.L., Lee, B. S., Pearson, S. 2011b. Towards

achieving accountability, auditability and trust in

cloud computing. A. Abraham et al. (Eds.), ACC

2011, Part IV, CCIS 193, pp. 432–444, Springer-

Verlag, Heidelberg.

AUTOMATINGCOMPLIANCEFORCLOUDCOMPUTINGSERVICES

637
