A SYSTEMATIC REVIEW OF OUTLIERS DETECTION

TECHNIQUES IN MEDICAL DATA

Preliminary Study

Juliano Gaspar

1,2

, Emanuel Catumbela

1,2

, Bernardo Marques

1,2

and Alberto Freitas

1,2

Department of Biostatistics and Medical Informatics, Faculty of Medicine, University of Porto, Porto, Portugal

CINTESIS - Center for Research in Health Technologies and Information Systems

University of Porto, Porto, Portugal

Keywords: Outliers detection, Data mining, Medical data.

Abstract: Background: Patient medical records contain many entries relating to patient conditions, treatments and lab

results. Generally involve multiple types of data and produces a large amount of information. These

databases can provide important information for clinical decision and to support the management of the

hospital. Medical databases have some specificities not often found in others non-medical databases. In this

context, outlier detection techniques can be used to detect abnormal patterns in health records (for instance,

problems in data quality) and this contributing to better data and better knowledge in the process of decision

making.

Aim: This systematic review intention to provide a better comprehension about the techniques used to

detect outliers in healthcare data, for creates automatisms for those methods in the order to facilitate the

access to information with quality in healthcare.

Methods: The literature was systematically reviewed to identify articles mentioning outlier detection

techniques or anomalies in medical data. Four distinct bibliographic databases were searched: Medline, ISI,

IEEE and EBSCO.

Results: From 4071 distinct papers selected, 80 were included after applying inclusion and exclusion

criteria. According to the medical specialty 32% of the techniques are intended for oncology and 37% of

them using patient data. Considering only articles that used administrative medical data, 59% of the

techniques were statistical based.

Conclusion: The area with outliers detection techniques most widely used in medical administrative data is

the statistics, when compared with techniques from data mining such as clustering and nearest neighbor.

1 BACKGROUND

Medical databases generally involve many different

types of data and produces a lot of information

(Kumar et al., 2008). The data typically consists in

records which may have several different types of

features such as patient age, blood group, weight,

clinical images, patient diagnoses, lab test results

and other details from patient treatments (Chandola

et al., 2009).

Patient medical records include many electronic

entries related to patient conditions and treatments

and their laboratory results. These are useful in

providing a better picture about the individual

patient, however, the benefits of such data in

decision support or in discovery of new clinical

knowledge are far from being exhausted

(Hauskrecht et al., 2007).

In latest years, with the exponential development

of information technology in hospitals, the volume

of medical data has increased significantly. At the

same time, new interest in the analysis of this

information has emerged, taking place not only as a

source for clinical decision making and research in

epidemiological studies, but also to support of

hospital management (Silva-Costa et al., 2010).

The value assigned to these data is directly

related to their quality. This way, as higher is the

quality of data, higher is its utility (Arts et al., 2002).

For healthcare organizations, this kind of

information is essential in providing healthcare, as

well as a consistent and careful financial

575

Gaspar J., Catumbela E., Marques B. and Freitas A..

A SYSTEMATIC REVIEW OF OUTLIERS DETECTION TECHNIQUES IN MEDICAL DATA - Preliminary Study.

DOI: 10.5220/0003168705750582

In Proceedings of the International Conference on Health Informatics (HEALTHINF-2011), pages 575-582

ISBN: 978-989-8425-34-8

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

management. On most systems, the quality of data is

completely neglected, this way, could become a

nightmare, when users of the information produced

are not aware about its veracity and quality (Silva-

Costa et al., 2010).

In health, this quality is even more important,

since a wrong decision by a clinician, may even lead

to death of the patient or, in a most extreme case,

may also have a more global reach, when this weak

quality is associated with the exchange of

documents. A professional takes the decision based

on surveys that sometimes and without him aware

that they are not the same patient that he is

addressing. For example, a study on the integration

of hospital information systems (Cruz-Correia et al.,

2006), it stated that about 0.1% (423 in 391,258) of

the documents associated with the process of clinical

patients in a hospital central contain identifying

information wrong.

Data mining a knowledge discovery in medical

databases are not substantially different from mining

in other types of databases. There are some

particularities in medical databases that are absent in

non-medical database (Cios, 2001).

One of these particularities are that the

physician’s interpretation of images, signals, or any

other clinical data, is written in unstructured free-

text, and because of this, standardize is very

difficult. Other feature of medical data mining is that

the underlying data structures of medicine are poorly

characterized mathematically, as compared to many

areas of the physical sciences. Physical scientists

could substitute data into formulas, equations, and

models that reflect the relationships among their data

(Cios, 2001).

1.1 Outliers Detection in Medicine

Outlier detection is very important to medicine,

because this data translate to significant information

and often critical data (Chandola et al., 2009). In

healthcare databases, outlier detection techniques are

used to detect anomalous patterns in patient records

which can contain valuable data as, for instance,

symptoms of a new disease.

There are many definitions for outliers which

differ in words found in different studies (Laurikkala

et al., 2000). According to Barnett and Lewis, an

outlier can be defined as “an observation, or subsets

of observations, appearing to be inconsistent with

the remainder of that set of data” (Barnett and

Lewis, 1994). In other words, an outlier is an

element that deviates from a standard set of data

from which it belongs. However, an outlier is always

an element of a group. An element is said outlier

when compared to a standard, therefore, an element

can be called outlier compared to the standard X and

not an outlier compared to standard Y (Silva, 2004).

1.1.1 Techniques

The outliers detection techniques debated in this

study are:

 Statistical: Statistical techniques fit a statistical

model, usually for normal behavior, to the given

data and then a statistical inference test is applied to

determine if an unseen instance belongs to the model

or not. Instances that have a low probability to be

generated from the learnt model, based on the

applied test statistic, are declared as outliers

(Chandola et al., 2009).

 Clustering: Is used to group similar data into

clusters. Even though clustering and outliers

detections appear to be fundamentally different from

each other, several clustering based outlier detection

techniques have been developed.

 Classification: This technique is used to learn a

model from a set of labeled data instances and, then,

classify a test instance into one of the classes using

the learned model. Classification based anomaly

detection techniques operate in a similar two-phase:

the training phase learns a classifier using the

available labeled training data and the testing phase

classifies a test instance as normal or anomalous

using the classifier (Chandola et al., 2009).

 Nearest Neighbor: Require a distance or

similarity measure defined between two data

instances, that can be computed in different ways

(Chandola et al., 2009). Techniques based on this

approach can be broadly grouped into two

categories: techniques that use the distance of a data

instance to its nearest neighbor as the anomaly score

and techniques that compute the relative density of

each data instance to compute its anomaly score.

 Mixture Models: Mixture models comprise a

finite or infinite number of components, possibly of

different distributional types, that can describe

different features of data (Marin et al., 2005). In

statistics, a mixture model is a probabilistic model

for density estimation using a mixture distribution.

A mixture model can be regarded as a type of

unsupervised learning or clustering.

 Spectral: Try to find an approximation of the

data using a combination of attributes that capture

the bulk of variability in the data (Chandola et al.,

2009). This technique defines subspaces in which

the anomalous instances can be easily identified.

HEALTHINF 2011 - International Conference on Health Informatics

576

1.2 Aim

This systematic review aims to provide a better

comprehension about the used techniques to detect

outliers in administrative healthcare data, to create

automatisms for those methods in order to facilitate

the access to information with quality, to make a

better decision by managers in health.

2 METHODS

2.1 Eligibility Criteria

We defined a pair review, independently, involving

the two reviewers in the study. The selection was

based on the studies titles and abstracts. The pair

review considered eligible articles that contained the

following criteria:

 The Inclusion covered the topics outlier

detection, anomaly detection, extreme data or gross

error, and the topics healthcare, health, medical,

medicine, clinical or patient.

 The exclusion criteria covered only the articles

that described the technique or method used.

Only selection by both reviewers was considered

adequate. In case of disagreement the decision was

based on a consensus meeting between the

reviewers.

To maximize specificity, a preliminary analysis

was performed with 20 papers, to evaluate and

synchronize the reviewers.

2.2 Review Team

The review team was composed by a Computer

Scientist, Juliano Gaspar, and a Medical Doctor,

Emanuel Catumbela, advised by a Computer

Scientist with expertise in medical informatics,

Professor Alberto Freitas.

The statistical analysis was performed by a

Statistician, Bernardo Marques, with PASW version

2.3 Search Methods

The search for studies was performed between May

and June 2010 in bibliographic databases. Since

there were no specific standardized MeSH terms, we

developed a search string that includes the concepts

of outlier or anomaly detection in healthcare. We

decided to not include restrictions on language or

date of published articles. Four distinct bibliographic

databases were searched: Medline (via Pubmed), ISI

(ISI Web of Knowledge), IEEE (IEEE Xplore) and

EBSCO (EBSCOhost

databases). The query search

string used in each database was:

(((outlier or outliers) and (detect or detection or

observation or analysis)) or ((anomalous and

data) and (detect or detection or observation or

analysis)) or “extreme data” or “gross error” or

“anomalous record” or “anomalous register”)

and (medical or medicine or clinical or patient or

care or health).

2.4 Definition of Variables

The variables analyzed in this preliminary review

are:

 Outliers Detection Techniques: statistical,

clustering, classification, nearest neighbor, mixture

models and spectral.

 Data Type: type of data used in the use of each

technique (eg.: images, biosinal, patient data).

 Medical domain: which defines the medical

specialty or domain of medicine used in the study is

employed.

 Clinical Stage: phase clinical notes that the

study is applied to diagnosis, prognosis, treatment,

or for assessing outcomes and performance.

Were also collected information if the data used

were primary, secondary or simulated, the country

where the study was conducted and the year of

publication.

3 RESULTS

The design of this systematic review showed the

following results: the search method found 2697

articles in Medline, 1169 in ISI, 185 in IEEE and

414 in EBSCO, a total of 4465 articles. After

eliminating duplicate articles 4071 were selected.

As a result, a total of 177 out of 4071 articles

were selected to be read entirely. In this preliminary

study we present and analyze 80 articles. Figure 1 is

a flowchart illustrating the different stages of paper

selection.

The agreement rate between reviewers during the

phase of studies selection was 72%.

The table 1 lists all outlier detection techniques

considered in this review. In the 80 articles analyzed

were identified 112 techniques, which were

classified into 6 categories. The “statistical”

technique appears with 55.4% of the studies.

A SYSTEMATIC REVIEW OF OUTLIERS DETECTION TECHNIQUES IN MEDICAL DATA - Preliminary Study

577

Figure 1: Flowchart illustrating the papers selection.

Table 1: List of outlier detection techniques.

Type N (%)

Statistical 62 55.4

Clustering 17 15.2

Classification 14 12.5

Nearest Neighbor 10 8.9

Mixture Models 6 5.4

Spectral 3 2.7

Total 112 100.0

It can be observed in Table 2 listing the 80

articles reviewed, grouped by techniques that each

presents. As described earlier, an article may appear

more than once, since some studies show more than

one technique.

According to the “clinical stage”, this study

showed that 81.3% of the techniques to detect

outliers for the diagnostic, while only 3.8% for

treatment.

Table 2: List of the articles by techniques.

Statistical

(Aalen et al., 2004; Ahdesmaki et al., 2005; Ahlers and Figg,

2006; Alameda and Suarez, 2009; Allen et al., 2010; Asare et

al., 2009; Bakhshi-Raiez et al., 2007; Beguin and Hulliger,

2004; Bickel, 2003; Booth and Lee, 2003; Branden and

Verboven, 2009; Breen et al., 2002; Cho et al., 2008;

Cluitmans and van de Velde, 2000; Cohen et al., 1996;

Comanor et al., 2006; Commowick and Warfield, 2009;

Cooney et al., 2003; Englesbe et al., 2009; Fomenko et al.,

2006; Freifeld et al., 2009; Ghosh, 2010; Ghosh and

Chinnaiyan, 2009; Glance et al., 2003; Glance et al., 2002;

Glance et al., 2007; Gold and Hoffman, 1976; Grotkjaer et al.,

2006; Hanauer et al., 2007; Hayes et al., 2007; Hojjatoleslami

et al., 1997; Hu, 2008; Hughes et al., 1997; Irigoien and

Arenas, 2008; Jackson et al., 2009; Jacobs, 2001; Kauffmann

and Huber, 2010; Kazmierczak et al., 2007; Liu and Wu, 2007;

Livesey, 2007; MacDonald and Ghosh, 2006; Mahadevan et

al., 2004; Meloun et al., 2004; Model et al., 2002; Nielsen and

Hansen, 2002; Nielsen et al., 2001; Oh and Gao, 2009;

Ohlssen et al., 2007; Penny and Jolliffe, 1999; Penny and

Jolliffe, 2001; Read, 1999; Rochelson et al., 2006; Rubin and

Chinnaiyan, 2006; Ryan, 2009; Song and Wyrwicz, 2009;

Tomlins et al., 2008; Van Leemput et al., 2001;

Vankeerberghen et al., 1995; Vellido and Lisboa, 2006;

Whitley and Ball, 2002; Wu, 2007; Zervakis et al., 2009)

Clustering

(Aggarwal and Yu, 2005; Azmandian et al., 2007; Beguin and

Hulliger, 2004; Bickel, 2003; Duan et al., 2009; Freifeld et al.,

2009; Gold and Hoffman, 1976; Goovaerts and Jacquez, 2004;

Grotkjaer et al., 2006; Hibbs et al., 2005; Irigoien and Arenas,

2008; Jackson et al., 2009; Janeja and Atluri, 2009; Koufakou

and Georgiopoulos, 2010; Mramor et al., 2007; Vellido and

Lisboa, 2006; Yang et al., 2007)

Classification

(Aggarwal and Yu, 2005; Baker and Jackson, 2008; Cardoso et

al., 2007; Commowick and Warfield, 2009; Gold and

Hoffman, 1976; Grotkjaer et al., 2006; Kazmierczak et al.,

2007; Law et al., 2001; Lopes et al., 2003; Mahadevan et al.,

2004; Oh and Gao, 2009; Ohlssen et al., 2007; Whitley and

Ball, 2002; Zervakis et al., 2009)

Nearest Neighbor

(Antao et al., 2008; Beguin and Hulliger, 2004; Chen et al.,

2008; Duan et al., 2009; Freifeld et al., 2009; Goovaerts and

Jacquez, 2004; Irigoien and Arenas, 2008; Jackson et al., 2009;

Janeja and Atluri, 2009; Koufakou and Georgiopoulos, 2010)

Mixture Models

(Ghosh, 2010; Ghosh and Chinnaiyan, 2009; Hu, 2008; Lopes

et al., 2003; Model et al., 2002; Penny and Jolliffe, 2001)

Spectral

(Cohen Freue et al., 2007; Hubert and Engelen, 2004; Song

and Wyrwicz, 2009)

Table 3 lists the data types more frequently

found in this study. They are, respectively, “Patient

Data” (37.5%) and “Genomic Data Sets” (32.1%)

followed by “Images” (15.1%) which includes, for

example, the two-dimensional images, three-

dimensional, electroencephalography, magnetic

resonance imaging and ultrasonography.

Table 4 presents the medical domain data. Found

in the medical specialties, the “oncology” (32.1%)

and “genetics” (15.2%) are the areas of health with

more usage of outlier detection techniques.

However, studies specifically related to

administrative medical data, “healthcare and quality

indicators” (24.1%), are ranked in second when

compared to medical specialties.

HEALTHINF 2011 - International Conference on Health Informatics

578

Table 3: Data Type.

Type N (%)

Patient Data 42 37.5

Genomic Data Sets 36 32.1

Images 17 15.1

Mass Spectrometry 6 5.4

Biosignal 4 3.6

Blood 4 3.6

Others 3 2.7

Total 112 100.0

Table 4: Medical Domain.

Specialties

N (%)

Oncology 36 32.1

Healthcare and Quality Indicator 27 24.1

Genetics 17 15.2

Neurology 13 11.6

Biochemistry 7 6.3

Clinical Analysis 4 3.6

Others 8 7.1

Total 112 100.0

Considering only the administrative medical

data, “healthcare and quality indicator”, is

presented in Table 5 a cross table between

techniques described and the data types used by the

authors of the studies.

Table 5: Administrative Medical Data.

Data Type

Patient

Data

Biosignal Total

Techniques N N N (%)

Statistical 14 2 16 59.3

Clustering 4 0 4 14.8

Nearest Neighbor 4 0 4 14.8

Classification 3 0 3 11.1

Total 25 2 27 100.0

Table 5 one can observe that the data used to

analyze administrative medical data, the main focus

of this review, are “patient data” (92.6%) and

“biosignal” (7.4%).

4 DISCUSSION

This review shows that, considering only

administrative medical data, statistical techniques

are the most commonly used (59%), followed by

clustering (15%) and nearest neighbor (15%). Even

considering only administrative medical data, the

techniques mainly use data such as "patient data".

Methods used to detect outliers in healthcare

databases are mostly applied for diagnosis (81%).

Considering medical specialty, oncology and genetic

studies are the most applied.

Thus, we conclude that statistical techniques are

widely used in administrative medical data, and that

techniques from data mining such as clustering and

nearest neighbor are still little used in this context.

There is a considerable field for developing

techniques to detect outliers in medical data

management, based on clustering and nearest

neighbor, beyond of the statistics techniques already

widespread.

4.1 Limitations

A major difficulty observed in this systematic

review was the variety of names used to define

outliers. The lack of objectivity and clarity to

describe the methods and techniques used in some

articles, demanded the reviewers to have a special

attention to distinguish which outlier detection

technique was used by the author in his study.

4.2 Future Works

In future work, we will implement a prototype for

detection of outliers in medical administrative

databases using clustering techniques, nearest

neighbor techniques, beyond statistical techniques.

The aim is to improve the process of decision

making the department directors and hospital

administrators, providing them with data with more

quality and accuracy.

ACKNOWLEDGEMENTS

The authors would like to thank the support given by

the research project HR-QoD - Quality of data

(outliers, inconsistencies and errors) in hospital

inpatient databases: methods and implications for

data modeling, cleansing and analysis (project

PTDC/SAU-ESA/75660/2006).

A SYSTEMATIC REVIEW OF OUTLIERS DETECTION TECHNIQUES IN MEDICAL DATA - Preliminary Study

579

REFERENCES

Aalen, O. O., Fosen, J., Weedon-Fekjaer, H., Borgan, O.,

and Husebye, E. (2004). Dynamic analysis of

multivariate failure time data. Biometrics 60, 764-773.

Aggarwal, C. C., and Yu, P. S. (2005). An effective and

efficient algorithm for high-dimensional outlier

detection. Vldb J 14, 211-221.

Ahdesmaki, M., Lahdesmaki, H., Pearson, R., Huttunen,

H., and Yli-Harja, O. (2005). Robust detection of

periodic time series measured from biological systems.

BMC Bioinformatics 6, 117.

Ahlers, C. M., and Figg, W. D. (2006). ETS-TMPRSS2

fusion gene products in prostate cancer. Cancer Biol

Ther 5, 254-255.

Alameda, C., and Suarez, C. (2009). Clinical outcomes in

medical outliers admitted to hospital with heart

failure. Eur J Intern Med 20, 764-767.

Allen, D. P., Stegemoller, E. L., Zadikoff, C., Rosenow, J.

M., and Mackinnon, C. D. (2010). Suppression of deep

brain stimulation artifacts from the

electroencephalogram by frequency-domain Hampel

filtering. Clin Neurophysiol.

Antao, T., Lopes, A., Lopes, R. J., Beja-Pereira, A., and

Luikart, G. (2008). LOSITAN: a workbench to detect

molecular adaptation based on a Fst-outlier method.

BMC Bioinformatics 9, 323.

Arts, D., Keizer, N., and Scheffer, G.-J. (2002). Defining

and Improving Data Quality in Medical Registries: A

Literature Review Case Study, and Generic

Framework. J Am Med Inform Assoc 9, 600-611.

Asare, A. L., Gao, Z., Carey, V. J., Wang, R., and Seyfert-

Margolis, V. (2009). Power enhancement via

multivariate outlier testing with gene expression

arrays. Bioinformatics 25, 48-53.

Azmandian, F., Kaeli, D., Dy, J. G., Hutchinson, E.,

Ancukiewicz, M., Niemierko, A., and Jiang, S. B.

(2007). Towards the development of an error checker

for radiotherapy treatment plans: a preliminary study.

Phys Med Biol 52, 6511-6524.

Baker, R., and Jackson, D. (2008). A new approach to

outliers in meta-analysis. Health Care Management

Science 11, 121-131.

Bakhshi-Raiez, F., Peek, N., Bosman, R. J., de Jonge, E.,

and de Keizer, N. F. (2007). The impact of different

prognostic models and their customization on

institutional comparison of intensive care units. Crit

Care Med 35, 2553-2560.

Barnett, V., and Lewis, T. (1994). Outliers in Statistical

Data (England).

Beguin, C., and Hulliger, B. (2004). Multivariate outlier

detection in incomplete survey data: the epidemic

algorithm and transformed rank correlations. J R Stat

Soc Ser A-Stat Soc 167, 275-294.

Bickel, D. R. (2003). Robust cluster analysis of

microarray gene expression data with the number of

clusters determined biologically. Bioinformatics 19,

818-824.

Booth, D. E., and Lee, K. (2003). Robust regression-based

analysis of drug-nucleic acid binding. Anal Biochem

319, 258-262.

Branden, K. V., and Verboven, S. (2009). Robust data

imputation. Comput Biol Chem 33, 7-13.

Breen, H. J., Rogers, P. A., and Johnson, N. W. (2002).

Improvements in methods of periodontal probing:

comparison of relative attachment level data selected

by outlier reduction protocols from Florida disc probe

measurements. J Clin Periodontol 29, 679-687.

Cardoso, F. F., Rosa, G. J., and Tempelman, R. J. (2007).

Accounting for outliers and heteroskedasticity in

multibreed genetic evaluations of postweaning gain of

Nelore-Hereford cattle. J Anim Sci 85, 909-918.

Chandola, V., Banerjee, A., and Kumar, V. (2009).

Anomaly Detection: A Survey. ACM Computing

Surveys 41.

Chen, D., Lu, C.-T., Kou, Y., and Chen, F. (2008). On

Detecting Spatial Outliers. GeoInformatica 12, 455-

475.

Cho, H., Kim, Y. J., Jung, H. J., Lee, S. W., and Lee, J. W.

(2008). OutlierD: an R package for outlier detection

using quantile regression on mass spectrometry data.

Bioinformatics 24, 882-884.

Cios, K. (2001). Medical data mining and knowledge

discovery (Physica-Verlag).

Cluitmans, P. J. M., and van de Velde, M. (2000). Outlier

detection to identify artefacts in EEG signals. In

Proceedings of the 22nd Annual International

Conference of the Ieee Engineering in Medicine and

Biology Society, Vols 1-4, J. D. Enderle, ed. (New

York, Ieee), pp. 2825-2826.

Cohen Freue, G. V., Hollander, Z., Shen, E., Zamar, R. H.,

Balshaw, R., Scherer, A., McManus, B., Keown, P.,

McMaster, W. R., and Ng, R. T. (2007). MDQC: a

new quality assessment method for microarrays based

on quality control reports. Bioinformatics 23, 3162-

3169.

Cohen, Y. C., Olmer, L., and Mozes, B. (1996). Two-

dimensional outcome analysis as a guide for quality

assurance of prostatectomy. Int J Qual Health Care 8,

67-73.

Comanor, W. S., Frech, H. E., 3rd, and Miller, R. D., Jr.

(2006). Is the United States an outlier in health care

and health outcomes? A preliminary analysis. Int J

Health Care Finance Econ 6, 3-23.

Commowick, O., and Warfield, S. K. (2009). A

Continuous STAPLE for Scalar, Vector, and Tensor

Images: An Application to DTI Analysis. IEEE

Transactions on Medical Imaging 28, 838-846.

Cooney, R. N., Haluck, R. S., Ku, J., Bass, T., MacLeod,

J., Brunner, H., and Miller, C. A. (2003). Analysis of

cost outliers after gastric bypass surgery: What can

we learn? Obesity Surgery 13, 29-36.

Cruz-Correia, R., Vieira-Marques, P., Ferreira, A.,

Oliveira-Palhares, E., Costa, P., and Costa-Pereira, A.

(2006). Monitoring the integration of hospital

information systems: How it may ensure and improve

the quality of data. Stud Health Technol Inform 121,

176-182.

HEALTHINF 2011 - International Conference on Health Informatics

580

Duan, L., Xu, L. D., Liu, Y., and Lee, J. (2009). Cluster-

based outlier detection. Annals of Operations

Research 168, 151-168.

Englesbe, M. J., Dimick, J. B., Fan, Z., Baser, O., and

Birkmeyer, J. D. (2009). Case Mix, Quality and High-

Cost Kidney Transplant Patients. American Journal of

Transplantation 9, 1108-1114.

Fomenko, I., Durst, M., and Balaban, D. (2006). Robust

regression for high throughput drug screening.

Comput Methods Programs Biomed 82, 31-37.

Freifeld, O., Greenspan, H., and Goldberger, J. (2009).

Multiple Sclerosis Lesion Detection Using

Constrained GMM and Curve Evolution. Int J Biomed

Imaging 2009, 715124.

Ghosh, D. (2010). Discrete nonparametric algorithms for

outlier detection with genomic data. J Biopharm Stat

20, 193-208.

Ghosh, D., and Chinnaiyan, A .M. (2009). Genomic

outlier profile analysis: mixture models, null

hypotheses, and nonparametric estimation.

Biostatistics 10, 60-69.

Glance, L. G., Dick, A. W., Osler, T. M., and Mukamel,

D. (2003). Using hierarchical modeling to measure

ICU quality. Intensive Care Medicine 29, 2223-2229.

Glance, L. G., Osler, T. M., and Dick, A. W. (2002).

Identifying quality outliers in a large, multiple-

institution database by using customized versions of

the Simplified Acute Physiology Score II and the

Mortality Probability Model II0. Crit Care Med 30,

1995-2002.

Glance, L. G., Osler, T. M., Mukamel, D. B., and Dick, A.

W. (2007). Use of a matching algorithm to evaluate

hospital coronary artery bypass grafting performance

as an alternative to conventional risk adjustment. Med

Care 45, 292-299.

Gold, E. M., and Hoffman, P. J. (1976). Flange detection

cluster analysis. Multivariate Behavioral Research 11,

217-235.

Goovaerts, P., and Jacquez, G. M. (2004). Accounting for

regional background and population size in the

detection of spatial clusters and outliers using

geostatistical filtering and spatial neutral models: the

case of lung cancer in Long Island, New York.

International Journal of Health Geographics 3, 14-23.

Grotkjaer, T., Winther, O., Regenberg, B., Nielsen, J., and

Hansen, L. K. (2006). Robust multi-scale clustering of

large DNA microarray datasets with the consensus

algorithm. Bioinformatics 22, 58-67.

Hanauer, D. A., Rhodes, D. R., Sinha-Kumar, C., and

Chinnaiyan, A. M. (2007). Bioinformatics approaches

in the study of cancer.

Curr Mol Med 7, 133-141.

Hauskrecht, M., Valko, M., Kveton, B., Visweswaran, S.,

and Cooper, G. F. (2007). Evidence-based anomaly

detection in clinical domains. AMIA Annu Symp

Proc, 319-323.

Hayes, K., Kinsella, A., and Coffey, N. (2007). A note on

the use of outlier criteria in Ontario laboratory quality

control schemes. Clin Biochem 40, 147-152.

Hibbs, M. A., Dirksen, N. C., Li, K., and Troyanskaya, O.

G. (2005). Visualization methods for statistical

analysis of microarray clusters. BMC Bioinformatics

6, 115.

Hojjatoleslami, A., Sardo, L., and Kittler, J. (1997). An

RBF based classifier for the detection of

microcalcifications in mammograms with outlier

rejection capability. Paper presented at: Neural

Networks,1997, International Conference on.

Hu, J. (2008). Cancer outlier detection based on

likelihood ratio test. Bioinformatics 24, 2193-2199.

Hubert, M., and Engelen, S. (2004). Robust PCA and

classification in biosciences. Bioinformatics 20, 1728-

1736.

Hughes, S. L., Ulasevich, A., Weaver, F. M., Henderson,

W., Manheim, L., Kubal, J. D., and Bonarigo, F.

(1997). Impact of home care on hospital days: a meta

analysis. Health Serv Res 32, 415-432.

Irigoien, I., and Arenas, C. (2008). INCA: new statistic for

estimating the number of clusters and identifying

atypical units. Stat Med 27, 2948-2973.

Jackson, M. C., Huang, L., Luo, J., Hachey, M., and

Feuer, E. (2009). Comparison of tests for spatial

heterogeneity on data with global clustering patterns

and outliers. Int J Health Geogr 8, 55.

Jacobs, R. (2001). Outliers in Statistical Analysis: Basic

Methods of Detection and Accommodation.

Janeja, V. P., and Atluri, V. (2009). Spatial outlier

detection in heterogeneous neighborhoods. Intell Data

Anal 13, 85-107.

Kauffmann, A., and Huber, W. (2010). Microarray data

quality control improves the detection of differentially

expressed genes. Genomics 95, 138-142.

Kazmierczak, S. C., Leen, T. K., Erdogmus, D., and

Carreira-Perpinan, M. A. (2007). Reduction of multi-

dimensional laboratory data to a two-dimensional

plot: a novel technique for the identification of

laboratory error.

Clinical Chemistry & Laboratory

Medicine 45, 749-752.

Koufakou, A., and Georgiopoulos, M. (2010). A fast

outlier detection strategy for distributed high-

dimensional data sets with mixed attributes. Data Min

Knowl Discov 20, 259-289.

Kumar, V., Kumar, D., and Singh, R. K. (2008). Outlier

Mining in Medical Databases: An Application of Data

Mining in Health Care Management to Detect

Abnormal Values Presented In Medical Databases.

IJCSNS International Journal of Computer Science

and Network Security.

Laurikkala, J., Juhola, M., and Kentala, E. (2000).

Informal Identification of Outilers in Medical Data.

Intelligent Data Analysis in Medicine and

Pharmacology.

Law, G. R., Cox, D. R., Machonochie, N. E., Simpson, J.,

Roman, E., and Carpenter, L. M. (2001). Large tables.

Biostatistics 2, 163-171.

Liu, F., and Wu, B. (2007). Multi-group cancer outlier

differential gene expression detection. Comput Biol

Chem 31, 65-71.

Livesey, J. H. (2007). Kurtosis provides a good omnibus

test for outliers in small samples. Clin Biochem 40,

1032-1036.

A SYSTEMATIC REVIEW OF OUTLIERS DETECTION TECHNIQUES IN MEDICAL DATA - Preliminary Study

581

Lopes, H. F., Müller, P., and Rosner, G. L. (2003).

Bayesian Meta-analysis for Longitudinal Data Models

Using Multivariate Mixture Priors. Biometrics 59, 66-

75.

MacDonald, J. W., and Ghosh, D. (2006). COPA--cancer

outlier profile analysis. Bioinformatics 22, 2950-2951.

Mahadevan, V., Narasimha-Iyer, H., Roysam, B., and

Tanenbaum, H. L. (2004). Robust model-based

vasculature detection in noisy biomedical images.

IEEE Trans Inf Technol Biomed 8, 360-376.

Marin, J. M. M., Kerrie, L., and Robert, C. (2005).

Bayesian modelling and inference on mixtures of

distributions, Vol 25 (Elsevier).

Meloun, M., Hill, M., Militký, J., Vrbiková, J., Škrha, J.,

and Stanická, S. (2004). New methodology of

influential point detection in regression model

building for the prediction of metabolic clearance rate

of glucose. Clinical Chemistry & Laboratory Medicine

42, 311-322.

Model, F., Konig, T., Piepenbrock, C., and Adorjan, P.

(2002). Statistical process control for large scale

microarray experiments. Bioinformatics 18 Suppl 1,

S155-163.

Mramor, M., Leban, G., Demsar, J., and Zupan, B. (2007).

Visualization-based cancer microarray data

classification analysis. Bioinformatics 23, 2147-2154.

Nielsen, F. A., and Hansen, L. K. (2002). Modeling of

activation data in the BrainMap (TM) database:

Detection of outliers. Human Brain Mapping 15, 146-

156.

Nielsen, F. A., Hansen, L. K., and Kjems, U. (2001).

Modeling of locations in the BrainMap database:

Detection of outliers. NeuroImage 13, S211-S211.

Oh, J. H., and Gao, J. (2009). A kernel-based approach for

detecting outliers of high-dimensional biological data.

BMC Bioinformatics 10 Suppl 4, S7.

Ohlssen, D. I., Sharples, L. D., and Spiegelhalter, D. J.

(2007). A hierarchical modelling framework for

identifying unusual performance in health care

providers. Journal of the Royal Statistical Society:

Series A (Statistics in Society) 170, 865-890.

Penny, K. I., and Jolliffe, I. T. (1999). Multivariate outlier

detection applied to multiply imputed laboratory data.

Statistics In Medicine 18, 1879-1895.

Penny, K. I., and Jolliffe, I. T. (2001). A Comparison of

Multivariate Outlier Detection Methods for Clinical

Laboratory Safety Data. Journal of the Royal

Statistical Society: Series D (The Statistician) 50, 295.

Read, R. J. (1999). Detecting outliers in non-redundant

diffraction data. Acta Crystallogr D Biol Crystallogr

55, 1759-1764.

Rochelson, B., Vohra, N., Krantz, D., and Macri, V.J.

(2006). Geometric morphometric analysis of shape

outlines of the normal and abnormal fetal skull using

three-dimensional sonographic multiplanar display.

Ultrasound in Obstetrics & Gynecology 27, 167-172.

Rubin, M. A., and Chinnaiyan, A.M. (2006).

Bioinformatics approach leads to the discovery of the

TMPRSS2:ETS gene fusion in prostate cancer. Lab

Invest 86, 1099-1102.

Ryan, A. M. (2009). Effects of the Premier Hospital

Quality Incentive Demonstration on Medicare Patient

Mortality and Cost. Health Services Research 44, 821-

842.

Silva-Costa, T., Marques, B., and Freitas, A. (2010).

Problemas de Qualidade de Dados em Bases de

Dados de Internamentos Hospitalares. Paper

presented at: 5ª Conferência Ibérica de Sistemas e

Tecnologias de Informação (Santiago de Compostela).

Silva, F. R. (2004). Uma abordagem para detecção de

outliers em dados categoricos. In Instituto de

Computação (Campinas, SP Universidade Estadual de

Campinas).

Song, X., and Wyrwicz, A. M. (2009). Unsupervised

spatiotemporal fMRI data analysis using support

vector machines. NeuroImage 47, 204-212.

Tomlins, S. A., Rhodes, D. R., Yu, J., Varambally, S.,

Mehra, R., Perner, S., Demichelis, F., Helgeson, B. E.,

Laxman, B., Morris, D. S., et al. (2008). The role of

SPINK1 in ETS rearrangement-negative prostate

cancers. Cancer Cell 13, 519-528.

Van Leemput, K., Maes, F., Vandermeulen, D.,

Colchester, A., and Suetens, P. (2001). Automated

segmentation of multiple sclerosis lesions by model

outlier detection. IEEE Transactions on Medical

Imaging 20, 677-688.

Vankeerberghen, P., Smeyersverbeke, J., Leardi, R., Karr,

C. L., and Massart, D.L. (1995). Robust Regression

and Outlier Detection for NonLinear Models Using

Genetic Algorithms. Chemometrics Intell Lab Syst 28,

73-87.

Vellido, A., and Lisboa, P. J. (2006). Handling outliers in

brain tumour MRS data analysis through robust

topographic mapping. Comput Biol Med 36, 1049-

1063.

Whitley, E., and Ball, J. (2002). Statistics review 1:

presenting and summarising data. Crit Care 6, 66-71.

Wu, B. (2007). Cancer outlier differential gene expression

detection. Biostatistics 8, 566-575.

Yang, S., Guo, X., Yang, Y. C., Papcunik, D., Heckman,

C., Hooke, J., Shriver, C. D., Liebman, M. N., and Hu,

H. (2007). Detecting outlier microarray arrays by

correlation and percentage of outliers spots. Cancer

Inform 2, 351-360.

Zervakis, M., Blazadonakis, M. E., Tsiliki, G., Danilatou,

V., Tsiknakis, M., and Kafetzopoulos, D. (2009).

Outcome prediction based on microarray analysis: a

critical perspective on methods. BMC Bioinformatics

10, 53.

HEALTHINF 2011 - International Conference on Health Informatics

582
