ONLINE SHARED EDITING

FOR INTRODUCTORY PROGRAMMING COURSES

Hosung Song

Department of Information and Computing Sciences (Computer Science)

University of Wisconsin-Green Bay

2420 Nicolet Drive, Green Bay, WI 54311, U.S.A.

Keywords:

Shared editing, Intro-programming courses, Pair programming, Remote instruction, Online learning, Remote

collaboration.

Abstract:

This paper argues how online shared editing can beneﬁt teaching/learning intro-programming courses like

CS1 and CS2. Various available tools supporting online shared editing are surveyed. A simple but novel Java-

based online shared editing framework named Olshed is also presented and demonstrated. Olshed is a suite of

Swing-based Java classes that supports easy development of online shared editing applications or extension of

existing applications for online shared editing. As a proof-of-concept example, DrJava (an educational Java

IDE) is extended with Olshed to provide real-time online shared editing facility.

1 INTRODUCTION

Real-time online collaboration has become very hot

and important in the ubiquitously networked environ-

ment these days. In a real-time online collaboration

environment, a group of users can edit a single docu-

ment simultaneously and remotely using online real-

time communication. This allows easier and more

seamless collaboration between colleagues when they

try to write a document collaboratively. Traditionally,

they exchanged their shared documents as email at-

tachments non-real-time, resulting in somewhat de-

graded collaboration performance. With the advent

of real-time online collaboration technology, they can

actually work on the same document at the same time

even regardless of their geographic locations. In sum-

mary, online shared document-editing and collabora-

tion service can be very beneﬁcial and its future looks

very promising.

In software development (especially coding), it

is no longer a news that pair programming is one

of the important aspects of “Extreme Program-

ming” methodology (Beck, 2005), which is becom-

ing fairly popular in many modern software develop-

ment projects. In pair programming, two coworkers

always code together in person simultaneously. One

worker takes the role of “driver,” entering all code

through the keyboard. The other worker takes the role

of “navigator” or “observer,” reviewing each line of

code as it is typed in. Many beneﬁts of pair program-

ming were identiﬁed and presented in (Cockburn and

Williams, 2000). Pair programming technique has

been suggested and tried for teaching/learning intro-

ductory programming courses too (Nagappan et al.,

2003). By letting two students solve a coding prob-

lem using pair programming technique, students can

even learn better from each other, on top of the orig-

inal beneﬁts of pair programming. However, many

students these days have hard time to meet in per-

son and program in pair due to their busy schedules

and life styles. This makes the idea of “Remote Pair

Programming” more appealing especially with ubiq-

uitous availability of high-speed Internet access these

days. Remote pair programmingwith online real-time

shared editing can also be very useful in intro pro-

gramming courses for other reasons like remotely as-

sisting a student to identify simple syntax errors or

tutoring of programming skills. No matter what sit-

uation two collaborators are in, a good tool support

enabling remote pair programming is critical. One

of the most important features of such a tool support

is real-time online shared/collaborative editing of text

document ﬁles.

In this paper, a number of available such tools

are surveyed and compared in terms of their features

(available or lacking), usability, and suitability for

teaching intro-programming courses. Olshed (On-

Line SHared EDiting), a simple Swing-based Java li-

489

Song H. (2010).

ONLINE SHARED EDITING FOR INTRODUCTORY PROGRAMMING COURSES.

In Proceedings of the 2nd International Conference on Computer Supported Education, pages 489-492

DOI: 10.5220/0002860904890492

 SciTePress

brary for online shared editing developed by the au-

thor, is also introduced for the ﬁrst time. Olshed is

shown to be easily integrable with already existing

Java applications, by demonstrating Olshed-extended

DrJava (Allen et al., 2002), an educational Java IDE.

The paper progresses as follows: Section 2 surveys

select real-time online shared/collaborative editing

tools. Section 3 explains the author’s Olshed library

and Olshed-extended DrJava is presented. Finally,

section 4 concludes this paper by describing future

plans for Olshed.

2 SURVEY OF EXISTING

SHARED EDITING TOOLS

There have been quite many available existing real-

time online shared editing tools. Most of them can be

sorted into three categories: IDE-based, web-based,

or stand-alone desktop applications.

2.1 IDE-based Shared Editors

IDEs (Integrated Development Environments) are in-

dispensable these days for software development ac-

tivities. Therefore, it is no surprise to see quite a few

real-time online shared editing supports for widely

used IDEs such as Eclipse. Especially, there are quite

a few available Eclipse plugins supporting shared

editing. Some notable ones are listed here with ref-

erences:

• DocShare/Cola plugin in Eclipse Communication

Framework (Lewis, 2007)

• Saros (Lau, 2009)

• XPairtise (The XPairtise Team, 2008)

• Sangam (The Sangam Project Team, 2008)

Most Eclipse plugins for shared editing utilizes some

sort of central messaging server, especially a gen-

eral purpose one such as XMPP/Jabber server. Once

the plugin is installed, the ﬁrst initiator can share her

source code editor with another participant. Depend-

ing on the implementations, only two participants can

share a document (ECF DocShare/Cola) or any num-

ber of participants can do so (Saros). Some Eclipse

plugin like Saros allows the participants to be as-

signed a speciﬁc role (e.g. exclusive driver, shared

driver, exclusive observer). Also plugins can differ

from the number of ﬁles that can be shared (only one

for ECF DocShare/Cola, an entire project with mul-

tiple source ﬁles for Saros). Overall, Eclipse plu-

gins supporting shared-editing can be very useful if

Eclipse is extensively used. However, the gravity of

the solution (the heavy-weight nature of Eclipse itself

and the need for a remote public messaging server or

a local private server) can be an inhibitor for this ap-

proach. Shared editing over a publicly available re-

mote messaging server can be pretty slow too.

2.2 Web-based Shared Editors

A web-based shared editing support can be viewed as

a shared editor embedded in a web browser. Because

a web browser cannot save and/or compile a source

code ﬁle yet, users need to copy-and-paste collabo-

ratively edited source code into an IDE and perform

required compilation and debugging there. This could

be a major inconvenience for intro-programming

course purposes, but the ubiquity of web browsersand

no need for installing anything are major attractions

to this category. The following are somewhat well-

known shared editing web applications/services:

• Etherpad

• CollabEdit

• MobWrite (Fraser, 2009)

All web-based shared editing applications heavily uti-

lizes Javascript technology to make it possible to do

real-time dynamic browser updates. All of them pro-

vide a very similar work ﬂow. The ﬁrst participant

connects to the web site providing the shared-editing

service, click a button for creating a public document

(also called a pad) that can be shared-edited, and the

returned URL is sent to other participants by email or

instant messages. The later participants just need to

browse the delivered URL to join the shared-editing

session. Etherpad provides probably most advanced

features such as displaying each individual partici-

pant’s entry in a different color (called Authorship

Colors) and the Time Slider feature allowing any par-

ticipant to navigate through all the revision history of

the shared document.

2.3 Stand-alone Desktop Shared Editors

Stand-alone desktop shared editor applications may

not have a ﬁrm ground these days due to the recent

proliferation of IDE and browser-based applications.

However, when a remote server for sharing is not de-

sired or a light-weight application is desired instead of

a heavy IDE, a simple stand-alone shared editor appli-

cation could be a good choice. Here are some select

stand-alone desktop shared editing applications.

http://etherpad.com/

http://collabedit.com/

CSEDU 2010 - 2nd International Conference on Computer Supported Education

490

• Notepad++ with NetNote plugin (The Notepad++

Project Team, 2009)

• ACE: A Collaborative Editor (ACE Project Team,

2006)

• Gobby (0x539 Dev Group, 2009)

• SubEthaEdit

There are actually quite a lot more than the ones se-

lected above. For more complete list, readers are re-

fer to http://en.wikipedia.org/wiki/Collaborative real-

time editor. Usage-wise, stand-alone desktop shared

editing applications are not too different from the

other two categories, except two points. Firstly, some

applications are not cross-platform (Notepad++ is

Windows-only and SubEthaEdit is Mac-only) due to

the adopted development frameworks. Secondly, net-

working can be just one-to-one (Notepad++) or many-

to-many with auto-client discovery protocols such as

Bonjour (SubEthaEdit and ACE). They are mostly

pretty light-weight, but their suitability for beginning

students in programming is not the best yet.

3 OLSHED: A SWING-BASED

JAVA LIBRARY FOR ONLINE

SHARED EDITING

As surveyed above, there are lots of available exist-

ing real-time online shared-editing applications (ei-

ther desktop or web-based). However, CS1/2 students

or instructors may have hard time to pick one suitable

for their needs. Eclipse plugins may not be feasible

if Eclipse is not used for a course due to its heavy

weight. Even though Eclipse is used, installing and

using additional plugins can be difﬁcult for begin-

ning CS1/2 students. Light-weight desktop or web-

based shared editor applications lack the integration

with compiler and debugger. Therefore, it can be ar-

gued that enabling a light-weight IDE (e.g. DrJava

or BlueJ) with a simple shared-editing feature would

be highly desirable. Since most light-weight IDEs are

also written in Java with Swing GUI framework, it

is natural to develop a Swing-based Java Library for

shared editing.

Olshed (OnLine SHared EDiting)

, developed by

the author and presented here for the ﬁrst time, is a

suite of Java classes to easily extend any Swing-based

Java applications with real-time online shared editing

feature. Communication is done by a simple multi-

threaded Java chat server with custom protocol mes-

http://www.codingmonkeys.de/subethaedit/

Available at http://icsa.uwgb.edu/ songh/olshed/ as

open source software.

Existing Java App.

- GUI hooks to Olshed features

(e.g. buttons or menu items)

- Instance var. for Olshed obj.

- Document object w/ methods:

insertString()

remove()

- Event dispatching thread invokes

Olshed’s Doc. listener methods

whenever there’s a document change.

Olshed module (class)

- Instance var. for main GUI frame

- DocumentListener methods: creates and

sends an Olshed msg. to chat server

whenever it’s invoked.

insertUpdate()

changeUpdate()

removeUpdate()

- Runnable method (sep. thread): receives

incoming Olshed msgs. from chat server,

decodes it and invokes corresponding

Document methods in main frame.

run(): runs in sep. listener thread

Olshed-extended Java app

Olshed Chat Server

thread

thread thread

TCP socket

streams

Olshed-extended Java app

TCP socket

streams

TCP socket

streams

Figure 1: Olshed Architecture.

sage formats through standard Java I/O streams. Ol-

shed library utilizes Java’s Swing framework’s Docu-

mentListener

and Document

interfaces.The Olshed

main class implements DocumentListener interface

implementing three update methods (change, insert,

and remove) and an instance of the Olshed main class

is added as a DocumentListener to the associated

Document object of the target Swing Java application

that is extended for online shared editing. This way,

every document update on the target application’s

document model will be notiﬁed to the Olshed doc-

ument listener code. Upon being notiﬁed, the Olshed

document listener code creates and sends a message

to the Olshed chat server through the output stream of

the socket connection established earlier. The Olshed

chat server relays the message to all connected Olshed

clients. Incoming messages are handled by a separate

chat-listener thread through the input stream of the es-

tablished socket connection. The Olshed chat-listener

thread (in the client) then invokes the corresponding

update method (insertString(), remove(), or createPo-

sition()) on the registered Document object from the

target application. Figure 1 shows the overall archi-

tecture of Olshed.

Necessary modiﬁcation of the target application’s

code is minimal thanks to the full utilization of Swing

framework. The target application’s code needs to be

extended with necessary GUI hook(s) to Olshed fea-

tures (like buttons or menu items) and an instance of

the Olshed main class, which just needs to be instanti-

ated in the constructor of the target application’s main

GUI class. The Olshed main class’s constructor also

initiates a socket connection to the Olshed chat server

http://java.sun.com/docs/books/tutorial/uiswing/events/

documentlistener.html

http://java.sun.com/j2se/1.5.0/docs/api/javax/swing/

text/Document.html

ONLINE SHARED EDITING FOR INTRODUCTORY PROGRAMMING COURSES

491

(the connection parameters should be passed to the

constructor) and starts a chat-listener thread. The in-

stantiated Olshed object should later be told about the

actual Document object on which shared editing will

be conducted. At that time, the Olshed main class’s

instance is also added to the Document object as a

DocumentListener object.

As a proof-of-concept realization of Olshed, Dr-

Java (Allen et al., 2002), a well-known educational

Java IDE, was extended with Olshed for real-time on-

line shared editing. It was easily done by follow-

ing the simple extension strategy described above,

without serious modiﬁcation to DrJava’s original code

base. Any number of DrJava+Olshed application in-

stances can perform shared editing of a single Java

source code ﬁle document as long as they are all con-

nected to the same Olshed chat server. This is a strong

evidence that Olshed can be easily applicable to any

existing Swing-based Java applications.

The development of Olshed is still in its infant

stage. Currently, the document consistency mainte-

nance algorithm is yet to be implemented. The lack

of the feature can possibly result in out-of-sync doc-

uments across Olshed clients at this point. As long

as the current infantile Olshed is used in a purely

driver-and-observer model, this shouldn’t be a big is-

sue for the time being. Currently Olshed can share

only a single document among two or more partici-

pants. The current Olshed chat server implementation

allows only one group of shared editing participants.

Lifting these restrictions should not be difﬁcult.

4 CONCLUSIONS

In this paper, it was informally argued that real-time

online shared editing can signiﬁcantly beneﬁt not only

general remote collaboration like pair programming

but also teaching and learning of introductory pro-

gramming courses. Available existing online shared

applications were surveyed. Hoping a light-weight

IDE-based shared editing environment for use by stu-

dents and instructors of intro-programming courses,

the author developed and presented Olshed, a simple

Swing-based Java library allowing an easy extension

of existing Swing Java applications with real-time on-

line shared editing. As a proof-of-conceptproject, Dr-

Java, a well-known Java IDE written in Java, was ex-

tended for shared editing with Olshed. The full source

code of Olshed and Olshed-extended DrJava is avail-

able as an open source project.

There are many needed future work topics for Ol-

shed. The most imminent feature that’s needed is

to maintain document consistency under concurrent

write access to a single document. An OT (Opera-

tional Transformation)-based algorithm (Sun and El-

lis, 1998) will be soon implemented and integrated.

Other desirable features would be related to the Ol-

shed chat server, such as supporting multiple con-

current editing groups and supporting multiple doc-

uments editing per each concurrent editing group.

REFERENCES

0x539 Dev Group (2009). Gobby. http://gobby.0x539.de/.

ACE Project Team (2006). Ace - a collaborative editor.

http://sourceforge.net/projects/ace/.

Allen, E., Cartwright, R., and Stoler, B. (2002). Drjava: A

lightweight pedagogic environment for java. In Pro-

ceedings of ACM SIGCSE Symposium 2002.

Beck, K. (2005). Extreme Programming Explained - Em-

brace Change. Addison-Wesley, 2nd edition.

Cockburn, A. and Williams, L. (2000). The costs and

beneﬁts of pair programming. In Proceedings of the

1st International Conference on Extreme Program-

ming and Flexible Processes in Software Engineering

(XP2000).

Fraser, N. (2009). google-mobwrite.

http://code.google.com/p/google-mobwrite/.

Lau, S. (2009). Saros - Distributed Pair Programming for

Eclipse. https://www.inf.fu-berlin.de/w/SE/DPP.

Lewis, S. (2007). RT Shared Editing - Eclipsepedia.

http://wiki.eclipse.org/RT Shared Editing.

Nagappan, N., Williams, L., Ferzli, M., Wiebe, W., Yang,

K., Miller, C., and Balik, S. (2003). Improving the cs1

experience with pair programming. In Proceedings of

ACM SIGCSE Symposium 2003.

Sun, C. and Ellis, C. (1998). Operational transformation

in real-time group editors: Issues, algorithms, and

achievements. In Proceedings of the ACM Conference

on Computer-Supported Cooperative Work.

The Notepad++ Project Team (2009). Notepad++.

http://notepad-plus.sourceforget.net/.

The Sangam Project Team (2008). Sangam - Eclipse Plugin.

http://sangam.sourceforge.net/.

The XPairtise Team (2008). XPairtise - Pair Programming

for Eclipse. http://xpairtise.sourceforge.net/.

CSEDU 2010 - 2nd International Conference on Computer Supported Education

492
