COMBINING SELF-MOTIVATION WITH LOGICAL PLANNING

AND INFERENCE IN A REWARD-SEEKING AGENT

Daphne Liu and Lenhart Schubert

∗

Department of Computer Science, University of Rochester, Rochester, NY, U.S.A.

Keywords:

Self-aware agent, Self-motivated cognitive agent, Introspection.

Abstract:

We present our preliminary work on our framework for building self-motivated, self-aware agents that plan

continuously so as to maximize long-term rewards. While such agents employ reasoned exploration of feasible

sequences of actions and corresponding states, they also behave opportunistically and recover from failure,

thanks to their quest for rewards and their continual plan updates. The framework allows for both speciﬁc

and general (quantiﬁed) knowledge, epistemic predicates such as knowing-that and knowing-whether, for

incomplete knowledge of the world, for quantitative change, for exogenous events, and for dialogue actions.

Question answering and experimental runs are shown for a particular agent ME in a simple world of roads,

various objects, and another agent, demonstrating the value of continual, deliberate, reward-driven planning.

1 INTRODUCTION

Our interest is ultimately in intelligent, linguistically

competent agents. Such agents must be capable of

planning in an incompletely known world, inference

over a substantial knowledge base (including a self-

model), dialogue, and unceasing pursuit of their own

rewards. Many AI systems have demonstrated some

of these abilities, but none to our knowledge have in-

tegrated them all. We present a simple framework

for deﬁning such self-motivated cognitive agents in

simulated worlds and exemplify this with an agent

dubbed ME (for Motivated Explorer). Future work

will move the domain to the real world (rather than

more elaborate simulated worlds) and emphasize di-

alogue. ME can plan and think ahead (where actions

produce gradual change over time), deal with unfore-

seen events, make inferences about states (including

its own and other agents’ knowledge and wants), en-

gage in question-answering with the user and other

agents, and do so indeﬁnitely and autonomously,

driven by the expected cumulative rewards or costs of

its contemplated sequences of actions and anticipated

future states.

Unlike the type of self-motivated agent described

here, traditional planners have been constrained to act

and react in accord with user-speciﬁed goals, con-

∗

This work was supported by NSF grants IIS-0535105

and IIS-0916599.

straints and preferences. Self-motivation would seem

to lead to single-minded, self-indulgent behavior, but

this is not at all so. If the agent “enjoys” acquir-

ing knowledge, exploring its environment, convers-

ing, and satisfying perceived user goals, then it can

appear curious, interactive, and helpful. It may also

seem that such an agent could do no more than typ-

ical reinforcement learning (RL) agents. In fact, the

kind of agent envisaged and illustrated here conceives

of its world and its actions in logical descriptive terms

– it is a cognitive agent and thus able to plan ahead,

entertain beliefs about itself and other agents, and en-

gage in question-answering dialogue.

In Section 2, we describe what we mean by a

self-motivated cognitive agent, and our development

framework for implementing such agents. In Section

3 we detail how actions are deﬁned for an agent, the

planning process, and the somewhat altered syntax

and meaning of action deﬁnitions when we are speci-

fying “actual” actions (as carried out when “running”

the simulated world). In Section 4 we focus on the

reasoning (including introspection) performed by the

agent.

In Section 5, we instantiate the agent ME in a par-

ticular simulated world in order to demonstrate and

experiment with our framework. The simple sam-

ple world sufﬁces for illustrating and supporting the

points we wish to make. In Section 6 we then pro-

vide examples of question-answering by ME, and re-

257

Liu D. and Schubert L. (2010).

COMBINING SELF-MOTIVATION WITH LOGICAL PLANNING AND INFERENCE IN A REWARD-SEEKING AGENT.

In Proceedings of the 2nd International Conference on Agents and Artiﬁcial Intelligence - Agents, pages 257-263

DOI: 10.5220/0002700602570263

 SciTePress

port results of various “runs” of the agent in the sim-

ulated world, showing the advantages for the agent of

its deliberate, self-motivated style of continual plan-

ning. We conclude with a summary, a contrast with

related work, and future directions.

2 SELF-MOTIVATED COGNITIVE

AGENT FRAMEWORK

We conceive of a self-motivated cognitive agent as

one whose activity is governed by continual reasoned

elaboration and execution of a life plan (as suggested

in (Morbini and Schubert, 2008); see also (Liu and

Schubert, 2009)). It is not assumed to have com-

plete knowledge either about the current world state

or about exogenous events, but it observes new or al-

tered facts as it goes. Such an agent manifests oppor-

tunistic behavior; i.e., as new facts become apparent

to it or actions fail, its continual planning will deal ap-

propriately with unanticipated opportunities and haz-

ards.

Accordingly, the framework and (Lisp-based)

platform treat planning as continual construction,

evaluation and partial execution of sequences of po-

tential actions. The evaluation assumes that both ac-

tions and states can be intrinsically rewarding or odi-

ous, where the extent of such utility or disutility de-

pends on the exact action parameters involved and

on arbitrary descriptive or numerical features of the

world and the agent. Actions and states with large

expected utility will tend to be favored by the plan-

ning process, which is designed to add up total utili-

ties over courses of action, and propagate these back

to allow a current choice of action that is seemingly

optimal “in the long run”.

To be cognitive, an agent should plan and do so

within an expressively rich language for describing,

and making inferences about, actions and the world.

We might have chosen a situation calculus-based

framework like Golog (e.g., (Ferrein et al., 2004)),

but both for ease of use in implementing a set of op-

erators and for planning efﬁciency we chose a more

STRIPS-like representation of actions and states. The

action representation allows for quantitativeprecondi-

tions and effects, handled by a general procedural at-

tachment syntax. The logic of state descriptions also

allows for propositional attitudes such as knowing-

that, knowing-whether and wanting. This is essential

for formalizing knowledge-acquisitionactions and for

answering questions about the agent’s own attitudes.

The current framework conﬁnes ME to a simu-

lated grid world. This consists of an arbitrary user-

deﬁned set of named locations, and named roads con-

necting some or all of these locations. Animate and

inanimate entities of speciﬁed types can be placed at

various locations. For animate entities (agents), the

speciﬁed ground literals may include ones like beliefs

and preferences. The types assigned to entities are

separately speciﬁed, allowing shared properties of en-

tities of that type to be listed. While ME is mobile and

exploratory, interacting with the user and other enti-

ties, all other entities are stationary and merely reac-

tive in their interactions with ME.

Aside from the general knowledge implicit in type

speciﬁcations, grid worlds allow for speciﬁcation of

arbitrary conditional knowledge, such as that every

sasquatch has an IQ of 50, or that if someone knows

p is true then p is true. These general facts are stated

in Horn clause-like form, with the important general-

izations that the antecedent conditions of the clause

may be positive or negative literals, and literals may

be based on attitudinal predicates like knows, with rei-

ﬁed arguments like (that (is edible fruit3)). These

clauses are used for bounded forward inference in

elaborating world state descriptions.

ME’s knowledge base is initialized so that it con-

tains the geographical knowledge about the world and

the general quantiﬁed conditional facts. Its world

model is also augmented with speciﬁc facts about it-

self, its initial location, and about the entities at that

location. ME’s knowledge is incomplete even about

entities at its current location. In particular, certain

predicates are marked as being occluded for ME. For

example, the predicate is in might be occluded, so if

(is in key1 box1) holds, ME does not know this even

when standing next to box1. Similarly knows would

generally be occluded, so that what another agent

knows is not immediately apparent to ME. However,

self-referentialfacts about ME such as (has ME key1)

and (not (knows ME (whether (is edible fruit3))))

are evident to ME (and thus added to ME’s world

model), despite the general occlusion of has and

knows. Also, ME may ﬁnd out and remember a fact

that would otherwise be occluded, perhaps because it

asked a question, read a note containing the fact, or

inferred it.

The incompleteness of ME’s knowledge has sev-

eral important consequences for the design of the cog-

nitive agent framework. One is that a distinction

needs to be made between the simulated world and

ME’s model of it, in terms of both the effects and the

termination conditions of actions (which may be de-

termined by external events, not anticipated by ME).

Another is that under conditions of incomplete knowl-

edge ME cannot use a full closed-world assumption

(CWA), and thus must be careful not only in its evalu-

ation of the truth or falsity of action preconditions and

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

258

effects, but also in its introspections concerning what

it knows and doesn’t know.

3 ACTIONS, PLANNING, AND

SIMULATION

Operators, or action types, are deﬁned for ME in a

STRIPS-like syntax, with a list of parameters, a set of

preconditions and a set of effects; an action also has

an anticipated reward value and an expected duration.

Consider the following drink operator with formal pa-

rameters ?h for ME’s thirst level, ?x for the item to be

drunk, and ?y for the location of the item. From ME’s

perspective, if it is thirsty and at the same location as a

potable item, knows whether the item is potable, and

there is no adverse environmental event, then ME can

drink the item for 1 time unit and completely relieve

its thirst.

(setq drink

(make-op :name ’drink :pars ’(?h ?x ?y)

:preconds ’((is_thirsty_to_degree ME ?h)

(> ?h 0) (is_at ME ?y)

(is_at ?x ?y) (potable ?x)

(knows ME (whether (potable ?x)))

(not (there_is_adversity)))

:effects ’((is_thirsty_to_degree ME 0)

(not (is_thirsty_to_degree ME ?h)))

:time-required 1 :value 50))

A plan consists of a sequence of actions. An ac-

tion is created by replacing the formal parameters of

an operator with actual values obtained by unifying

its preconditions with facts in ME’s knowledge base.

An action can be created in a given state only if ME

ﬁnds its preconditions to be true according to ME’s

knowledge in that state; such an action is applicable

though ME might not elect to perform it. ME plans

by ﬁrst doing a forward search from a given state s,

followed by back-propagation to s of the anticipated

rewards and costs of the various actions and states

reached, to determine a/the seemingly best sequence

of actions. The forward search is bounded by a pre-

speciﬁed search beam, which speciﬁes the number of

lookahead levels (the length of the contemplated se-

quences of actions), the branching factor and the al-

lowable operators at each level. Informed by the pro-

jective lookahead, ME will execute the ﬁrst action of

a/the seemingly best plan and update its knowledge

with the action effects and its new observations of

non-occluded local facts.

Since ME’s knowledgeof the world is incomplete,

the actual effects of its actions may diverge from the

effects expected by the agent. For example, if we

model traveling (from ME’s perspective) as a multi-

step action, but also allow for spontaneous ﬁres that

bring travel to a halt, then ME may not reach its ex-

pected destination. Given this divergencebetween ex-

pectations and reality, we clearly need to distinguish

between ME’s conception of its actions and the “ac-

tual” actions in the simulated world. Space does not

permit the illustration of “actual” operators, but their

syntax is much like that of ME’s operators, except

that preconds and effects are replaced by startconds,

stopconds, deletes, and adds.

In the simulation, actual actions and exogenous

events may be tracked in parallel in unit time steps.

An active actual action will continue for another

time step iff none of its stop conditions as given by

stopconds are true in the current world state. The ac-

tion will terminate immediately if any one of them

is true in the current world state. In either case, the

world state will be updated, by computing the effects

as given by deletes and adds, followed by bounded

forward inference in conjunction with general world

knowledge. At the same time, ME’s world model will

be updated by computation of ME’s observation of

the non-occluded local facts in the new state.

When an action stops, whether successfully or

unsuccessfully, ME performs its plan search and

chooses a step to execute, as already described. This

makes its planning opportunistic and robust in the

event of failure – it always bases its choice of the next

action on a seemingly best course of action starting in

the situation at hand.

The uniform procedural attachment technique is

used in both preconditions and effects of actions. It

enables both quantitative reasoning and dialogue.

Some action preconditions and effects may con-

tain evaluable terms (those whose operators are

among +, −, ∗, /, <, <=, =, >=, >, random,

and function names ending in ?). The system

will evaluate these terms when verifying precon-

ditions and when applying effects. For example,

(is tired to degree ME (+ ?f (∗ 0.5 (elapsed time?)))),

an effect of walk.actual, speciﬁes that the increase

in ME’s fatigue level as a result of the walking

action will be half the distance it walks. Similarly

(knows USER (that (answer to ynq? ?q))), an effect

of answer ynq, will have (answer to ynq? ?q)

evaluated as an answer formula when ap-

plied; the result might for example be

(knows USER (that (not (can fly guru)))).

4 REASONING ABOUT WORLD

STATES AND MENTAL STATES

Since ME does not generally know all the current

facts, it cannot make full use of the CWA (unlike

COMBINING SELF-MOTIVATION WITH LOGICAL PLANNING AND INFERENCE IN A REWARD-SEEKING

AGENT

259

many traditional planners). But we do not want to

abandon the CWA altogether, as it would be inefﬁ-

cient to enumerate and maintain all the negative pred-

ications that hold even in simple worlds. Thus, ME

uses the CWA only for (non-epistemic) predications

in which ME is the subject of the predication. In this

respect its self-knowledge is assumed to be complete.

But when the predication concerns a non-ME subject,

ME applies the CWA only for (1) predications about

road connectivity and navigability (and even here the

CWA could easily be weakened), and (2) (a) when

the subject is a local entity currently colocated with

ME or one ME has visited, and (b) the predication

is non-occluded. In all other cases, the mere absence

of a predication from the world model is not inter-

preted as supporting its negation – its truth value may

simply be unknown. Of course, ME may learn that

(not p) holds for some predication p even if p is not

subject to the CWA. In such a case, it stores that nega-

tive literal in its world model. Therefore, in checking

whether a literal p is true or false, where p is not sub-

ject to the CWA, ME will not conclude “unknown”

merely because p is absent from its world model – it

also checks whether the negation is explicitly known.

ME updates its knowledge of the non-occluded prop-

erties of an entity only when it (re)visits its location,

and its knowledge of the occluded properties of that

entity when it takes appropriate actions to (re)discover

them.

In the case of autoepistemic predications, ME

judges their truth value by an introspection algorithm

rather than closed-world inference. In evaluating a

predication of form (knows SUBJ (that p)) (e.g.,

(knows ME (that (can talk guru)))), the algorithm

considers the two cases SUBJ = ME and SUBJ 6=

ME. In the ﬁrst case, ME uses the methods in the

previous paragraph to determine whether p is true,

false or unknown, and judges the autoepistemic pred-

ication to be true, false or false respectively (i.e., in

the latter two cases, ME does not know p to be true).

In the case SUBJ 6= ME, ME judges the epistemic

predication true only if SUBJ is identical to the sub-

ject of p (thus making a similar knowledge assump-

tion about other agents as for itself (Kaplan and Schu-

bert, 2000)), and false otherwise (a negative closure

assumption that could be weakened). The method for

predications of form (knows SUBJ (whether p)) is

much the same. But in the case SUBJ = ME, when

p is found to be true, false or unknown, the autoepis-

temic predication is judged to be true, true or false re-

spectively. In the case SUBJ 6= ME, ME again judges

the epistemic predication as true only if SUBJ is iden-

tical to the subject of p, and false otherwise.

ME’s inference capabilities are important in its

attempt to conﬁrm or disconﬁrm action precondi-

tions, including knowledge preconditions in actions

like asking an agent whether p is true (viz., not know-

ing whether p is true, but believing that the agent

knows whether p is true). Similarly, the inference

capabilities are crucial in answering questions, in-

cluding ones that test ME’s introspective capabilities.

Given a question, ME will either inform the user if

it doesn’t know the answer, or otherwise verbalize its

answer(s) as English sentence(s).

ME also performs bounded forward inference for

any state that it reaches in its simulated world or

in its lookahead, based on all of its current factual

knowledge and all of its general quantiﬁed knowl-

edge. For example, from (knows guru (that p))

ME can infer both p and (knows guru (whether p));

from (sasquatch moe) and general knowledge

((sasquatch ?x) => (has IQ ?x 50)) where variable

?x is assumed to be universally quantiﬁed over the do-

main, ME can infer that (has IQ moe 50).

5 EXPERIMENTAL AGENT

We implemented a version of ME in our framework to

demonstrate self-motivated question-answering, and

the beneﬁts of ME’s opportunistic behavior resulting

from its continual, deliberate, reward-seeking plan-

ning.

5.1 Simulated World

We situate ME in a very simple simulated world, yet

one sufﬁciently subtle to illustrate the above features.

This world is inhabited by animate agents ME and

guru, along with inanimate objects pizza, juice, note

and piano. There are four locations home, grove,

plaza and company, with roads path1, path2 and

path3 as shown in Figure 1. Object pizza is edible and

at home; juice is potable and at plaza; note is read-

able, at home, and contains the knowledge whether

piano is playable; piano is playable and at home.

For demonstration purposes, pizza and juice are pre-

sumed inexhaustible. Agent guru knows whether

pizza is edible, whether note is readable, and whether

juice is potable.

Initially ME is at home, not tired, and has a hunger

level of 4.0 and a thirst level of 2.0. In addition

to knowledge of the road network and the existence

of the objects at home, ME knows whether pizza

is edible, that juice is at plaza, and that guru lo-

cated at grove can talk and knows whether juice is

potable. ME has the following operators at its dis-

posal (where associated reward levels are indicated

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

260

pizza

juice

PLAZA

path1

path2

path3

GROVE

COMPANY

HOME

piano

guru

note

Figure 1: The experimental world.

parenthetically): eat (2 * ME’s hunger level at the on-

set of the action), drink (50), walk (3 - ME’s fatigue

level at the onset of the action), sleep (ME’s fatigue

level at the onset of the action), play (3), read (5),

ask other agents whether something is true (3), and

answer the user’s yes/no and wh-questions (10).

Any state s reached by ME in its projective looka-

head has an inherent value, based on the following

criteria comparing s with its parent state. Answer-

ing a user question yields 50 utility points; becom-

ing not bored gains ME 1 point; becoming more tired

(thirstier, hungrier) costs ME points equal to the in-

crease in ME’s fatigue (thirst, hunger) level. Con-

versely, leaving a user question unanswered costs ME

20 points; becoming bored costs ME 1 point; becom-

ing less tired (thirsty, hungry) gains ME points equal

to the decrease in ME’s fatigue (thirst, hunger) level.

These criteria, along with the operators’ anticipated

rewards, suggest that ME likes drinking and answer-

ing user’s questions the most.

A potentially multi-step action faces the possibil-

ity of interference by two types of exogenous events,

namely rain and ﬁre, but only ﬁre may disrupt the ac-

tion (e.g., sleeping, traveling). Spontaneous rain has

a 33% chance of starting; once begun, it has a 25%

chance of stopping. As long as there is no rain, a

spontaneous ﬁre has a 5% chance of starting; once

started, it has a 50% chance of dying by itself, and

also goes out when there is rain.

5.2 Question-Answering

ME’s dialogue interaction is handled uniformly via

ME’s planning and procedural attachment capabili-

ties. Input questions currently must be expressed in

the same syntax as that for symbolically representing

knowledge in the simulated world. A yes/no ques-

tion is preﬁxed with ask-yn; a wh-question, with ask-

wh. Though more than one question can be entered

at a time, ME handles questions independently, and

it may be some time until ME chooses to answer a

question as the next best action to perform.

The following example is self-explanatory.

>> (listen!)

((ask-yn user (is_tasty pizza))

(ask-yn user (not (is_bored ME))))

ACTION: (ANSWER_YNQ (IS_TASTY PIZZA))

Answer: (ME DOES NOT KNOW WHETHER PIZZA IS TASTY)

ACTION: (ANSWER_YNQ (NOT (IS_BORED ME)))

Answer: (IT IS NOT THE CASE THAT ME IS BORED)

A wh-question of the form (ask-wh user r) must

have at least one variable (indicated by preﬁx ?) in r.

For instance, (not (likes ME ?x)) corresponds to the

question “what does ME not like?” while (is at ?y ?z)

translates to “where is every entity located?”. In com-

puting the answer(s), ME attempts to unify r with

facts in its current knowledge base; for each set s of

bindings found for the variables in r, ME forms the

corresponding answer by replacing variables in r with

bindings in s. ME uses the weakened CWA to verbal-

ize its responses as follows.

>> (listen!)

((ask-wh user (is_tired_to_degree ME ?x))

(ask-wh user (is_animate ?y))

(ask-wh user (is_bored ?z)))

ACTION: (ANSWER_WHQ (IS_TIRED_TO_DEGREE ME ?X))

ANSWER: (ME IS TIRED TO DEGREE 1.5)

ACTION: (ANSWER_WHQ (IS_ANIMATE ?Y))

ANSWER: (ME IS ANIMATE) (GURU IS ANIMATE)

ACTION: (ANSWER_WHQ (IS_BORED ?Z))

ANSWER: (ME DOES NOT KNOW WHETHER ANYTHING IS BORED)

6 RESULTS

We give further examples of ME’s question-

answering, and empirical results showing the advan-

tages of ME’s opportunistic behavior (due to its self-

motivated, deliberate, continual planning) in the con-

text of the simulated world in Section 5.1.

6.1 Extended Example of QA

The following, including knows-whether and knows-

that questions, is a concatenation of several dialogue

exchanges between ME and the user, showing only

ME’s actions to answer user questions and ME’s cor-

responding verbalized English answers while omit-

ting system output. The examples showcase ME’s

ability to introspect positively and negatively using

the relaxed CWA.

ACTION: (ANSWER_YNQ (KNOWS GURU

(WHETHER (LIKES GURU PIZZA))))

ANSWER: (GURU KNOWS WHETHER GURU LIKES PIZZA)

ACTION: (ANSWER_YNQ (KNOWS GURU

(WHETHER (LIKES ME PIZZA))))

ANSWER: (ME DOES NOT KNOW WHETHER GURU KNOWS

WHETHER ME LIKES PIZZA)

ACTION: (ANSWER_YNQ (CAN_FLY GURU))

ANSWER: (IT IS NOT THE CASE THAT GURU CAN FLY)

ACTION: (ANSWER_YNQ (KNOWS GURU

(THAT (CAN_FLY GURU))))

ANSWER: (GURU KNOWS THAT IT IS NOT THE CASE

THAT GURU CAN FLY)

COMBINING SELF-MOTIVATION WITH LOGICAL PLANNING AND INFERENCE IN A REWARD-SEEKING

AGENT

261

6.2 Opportunistic Behavior

We report experiments wherein ME’s behavior shows

both opportunism and foresight. The success of a run

is measured in terms of the net utility (NU), summed

over the entire sequence of actions and corresponding

states. We conducted ten independent runs of ME’s

opportunistic behavior, using a ﬁve-level lookahead

with a branching factor of 3 for state nodes at each

level. Each run was for 20 steps where at each step

ME chose and performed a/the next best action. ME

obtained an NU of 181.30 averaged over the ten runs

ranging from NU 101.0 to NU 217.75.

The following shows ME’s sequence of 20 actions

for one of the runs, wherein no spontaneous ﬁre oc-

curred, and ME’s NU was 191.0. Each action was

logged along with its ﬁrst iteration, anticipated dura-

tion, and time in the simulated world when that iter-

ation began; also, each multi-step action was logged

again with its ﬁnal iteration.

((EAT 4.0 PIZZA HOME) 1 1 0)

((WALK HOME PLAZA PATH2 0.0) 1 2 2)

((WALK HOME PLAZA PATH2 0.0) 2 2 3)

((WALK PLAZA HOME PATH2 1.0) 1 2 5)

((WALK PLAZA HOME PATH2 1.0) 2 2 6)

((SLEEP 2.0 0.0) 1 8.0 8)

((SLEEP 2.0 0.0) 4 8.0 11)

((WALK HOME GROVE PATH1 0.0) 1 2 13)

((WALK HOME GROVE PATH1 0.0) 2 2 14)

((ASK+WHETHER GURU (POTABLE JUICE) GROVE) 1 1 16)

((WALK GROVE HOME PATH1 1.0) 1 2 18)

((WALK GROVE HOME PATH1 1.0) 2 2 19)

((SLEEP 2.0 1.0) 1 8.0 21)

((SLEEP 2.0 1.0) 4 8.0 24)

((EAT 2.0 PIZZA HOME) 1 1 26)

((WALK HOME PLAZA PATH2 0.0) 1 2 28)

((WALK HOME PLAZA PATH2 0.0) 2 2 29)

((DRINK 2.0 JUICE PLAZA) 1 1 31)

((WALK PLAZA HOME PATH2 1.0) 1 2 33)

((WALK PLAZA HOME PATH2 1.0) 2 2 34)

((SLEEP 2.0 0.0) 1 8.0 36)

((SLEEP 2.0 0.0) 4 8.0 39)

((WALK HOME GROVE PATH1 0.0) 1 2 41)

((WALK HOME GROVE PATH1 0.0) 2 2 42)

((ASK+WHETHER GURU (READABLE NOTE) GROVE) 1 1 44)

((WALK GROVE HOME PATH1 1.0) 1 2 46)

((WALK GROVE HOME PATH1 1.0) 2 2 47)

((SLEEP 2.0 1.0) 1 8.0 49)

((SLEEP 2.0 1.0) 4 8.0 52)

((EAT 2.0 PIZZA HOME) 1 1 54)

((READ 0.0 NOTE) 1 1 56)

((WALK HOME PLAZA PATH2 0.0) 1 2 58)

((WALK HOME PLAZA PATH2 0.0) 2 2 59)

ME’s chosen seemingly best action in itself alone

may not be immediately rewarding to ME, but rather

is anticipated by ME to lead to a most rewarding se-

quence of actions. For example, though ME might

not get a reward for walking from home to grove, it

may very well foresee a high reward resulting from

traveling to grove to meet guru, asking guru to learn

about note’s readability (knowledge which ME does

not have), going home where note is, and eventually

reading note. Thus, the use of the reasoned, projec-

tive lookahead enables ME to exhibit foresight and

opportunism in its behavior.

6.3 Goal-Directed Behavior

We made ME purely goal-directed by modifying its

metrics of rewards and penalties for actions and states

in the lookahead calculation. We designated drink-

ing juice as ME’s sole goal and made ME uninter-

ested in actions other than asking guru to acquire bev-

erage knowledge, traveling to reach guru and juice

and drinking juice. This was done by setting the an-

ticipated rewards of operators other than drink and

ask+whether to 0, leaving the anticipated reward of

the former unchanged at 50 and that of the latter at

3, rewarding the acquisition of knowledge and the

relieving of thirst in a state reached, while ignoring

other changes in a state reached.

ME’s sequence of actions was deterministic as

follows, yielding an actual NU of 61.0. This was man-

ually calculated using the ME’s original (just as in the

opportunistic) metrics of rewards and penalties for ac-

tions and states reached. To ﬁnd out about the pota-

bility of juice, ME must walk from home to grove

and ask guru; with the projective lookahead, having

knowledge about juice will incline ME to walk to

plaza and drink juice there.

((WALK HOME GROVE PATH1 0) 1 2 0)

((WALK HOME GROVE PATH1 0) 2 2 1)

((ASK+WHETHER GURU (POTABLE JUICE) GROVE) 1 1 3)

((WALK GROVE HOME PATH1 1.0) 1 2 5)

((WALK GROVE HOME PATH1 1.0) 2 2 6)

((WALK HOME PLAZA PATH2 2.0) 1 3 8)

((WALK HOME PLAZA PATH2 2.0) 2 3 9)

((WALK HOME PLAZA PATH2 2.0) 3 3 10)

((DRINK 4 JUICE PLAZA) 1 1 12)

Compared with the opportunistic behavior of Sec-

tion 6.2, the NU of 61.0 here is substantially lower.

Instead of doggedly pursuing the sole goal of drink-

ing juice, ME saw and seized additional opportu-

nities in Section 6.2, including eating pizza to sate

hunger, asking guru to ﬁnd out note’s being readable,

sleeping to relieve fatigue, and reading note for en-

joyment. The results establish that ME beneﬁts from

awarenessand exploitation of opportunitiesfor imme-

diate rewards, not only distant ones.

7 CONCLUSIONS

Our framework has demonstrated the feasibility of

combining planning, inference and dialogue in a

completely self-motivated cognitive agent. ME as

exempliﬁed empirically plans deliberately and con-

tinuously, and acts opportunistically in accord with

its reasoned expectations about future rewards and

penalties. It does so by drawing on its speciﬁc and

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

262

Table 1: Domain-independent Capabilities [column - ME

agent, DS: dialog systems, GDP: goal-directed planners,

RLA: RL agents, CVR: cognitive (virtual) robots, GA:

game agents].

Mental

modeling

Self

motivation

Dialogue

Exogenous

events

Logical

inference

Logical

planning

Incomplete

knowledge

Probabilities

Plan

hierarchies

Learning

ME DS GDP RLA CVR GA

general knowledge about itself and its environment,

including both introspective (autoepistemic) knowl-

edge and knowledge about mental states of other

agents.

Table 1 summarizes the distinctive features of our

framework vis-`a-vis ﬁve previously studied frame-

works.

A cell is green to indicate that the surveyed

systems of that kind all exhibit that capability, red to

indicate that none of them have that capability, or yel-

low to indicate that some of them have (some of) that

capability.

In our future work, we expect to allow for de-

grees of uncertainty in ME’s knowledge. As well,

we plan to implement learning by modiﬁcation of

the agent’s anticipated utility for certain actions and

states, so as to favor rewarding action sequences and

avoid adverse sequences based on the agent’s past ex-

perience. Lastly, we expect to generalize the frame-

work to do hierarchical planning, which is essential

for dealing with the complexities of dialogue about

the real world.

REFERENCES

Allen, J. F., Chambers, N., Ferguson, G., Galescu, L., Jung,

H., Swift, M., and Taysom, W. (2007). PLOW:a col-

Sample references are (Ferguson and Allen, 1998;

Allen et al., 2007) for DS, (Fikeset al., 1972; Kautz and Sel-

man, 1992; Sacerdoti, 1975) for GDP, (Singh et al., 2002;

Walker, 2000; Singh et al., 1994) for RLA, (Vere and Bick-

more, 1990; Nilsson, 1984; Tacke et al., 2004; Ferrein et al.,

2004) for CVR, and (Dinerstein et al., 2008; Davies and

Mehdi, 2006) for GA.

laborative task learning agent. In Proceedings of the

22nd National Conference on Artiﬁcial Intelligence

(AAAI 2007).

Davies, N. and Mehdi, Q. (2006). BDI for intelligent agents

in computer games. In Proceedings of the 8th Interna-

tional Conference on Computer Games: AI and Mo-

bile Systems (CGAIMS 2006).

Dinerstein, J., Egbert, P., Ventura, D., and Goodrich, M.

(2008). Demonstration-based behavior programming

for embodied virtual agents. Computational Intelli-

gence, 24(4):235–256.

Ferguson, G. and Allen, J. F. (1998). TRIPS: An integrated

intelligent problem-solving assistant. In Proceedings

of the 15th National Conference on Artiﬁcial Intelli-

gence (AAAI 1998).

Ferrein, E., Fritz, C., and Lakemeyer, G. (2004). On-line

decision-theoretic Golog for unpredictable domains.

In Proceedings of the 27th German Conference on Ar-

tiﬁcial Intelligence (KI 2004).

Fikes, R., Hart, P., and Nilsson, N. (1972). Learning and

executing generalized robot plans. Artiﬁcial Intelli-

gence, 3(4):251–288.

Kaplan, A. N. and Schubert, L. K. (2000). A computational

model of belief. Artiﬁcial Intelligence, 120(1):119–

160.

Kautz, H. A. and Selman, B. (1992). Planning as satisﬁabil-

ity. In Proceedings of the Tenth European Conference

on Artiﬁcial Intelligence (ECAI 1992).

Liu, D. H. and Schubert, L. K. (2009). Incorporating plan-

ning and reasoning into a self-motivated, communica-

tive agent. In Proceedings of the 2nd Conference on

Artiﬁcial General Intelligence (AGI 2009).

Morbini, F. and Schubert, L. (2008). Metareasoning as an

integral part of commonsense and autocognitive rea-

soning. In AAAI-08 Workshop on Metareasoning.

Nilsson, N. J. (1984). Shakey the robot. Technical Report

323, AI Center, SRI International.

Sacerdoti, E. D. (1975). A structure for plans and behavior.

Technical Report 109, AI Center, SRI International.

Singh, S., Litman, D., Kearns, M., and Walker, M. (2002).

Optimizing dialogue management with reinforcement

learning: Experiments with the njfun system. Journal

of Artiﬁcial Intelligence Research, 16:105–133.

Singh, S. P., Barto, A. G., Grupen, R., and Connolly, C.

(1994). Robust reinforcement learning in motion plan-

ning. In Advances in Neural Information Processing

Systems 6, pages 655–662. Morgan Kaufmann.

Tacke, M., Weigel, T., and Nebel, B. (2004). Decision-

theoretic planning for playing table soccer. In Pro-

ceedings of the 27th German Conference on Artiﬁcial

Intelligence (KI 2004).

Vere, S. and Bickmore, T. (1990). A basic agent. Computa-

tional Intelligence, 6(1):41–60.

Walker, M. A. (2000). An application of reinforcement

learning to dialogue strategy selection in a spoken di-

alogue system for email. Journal of Artiﬁcial Intelli-

gence Research, 12:387–416.

COMBINING SELF-MOTIVATION WITH LOGICAL PLANNING AND INFERENCE IN A REWARD-SEEKING

AGENT

263
