IS THE APPLICATION OF ASPECT-ORIENTED

PROGRAMMING CONSTRUCTS BENEFICIAL?

First Experimental Results

Sebastian Kleinschmager and Stefan Hanenberg

Department for Computer Science and Business Information Systems, University of Duisburg-Essen, Germany

Keywords: Aspect-Oriented Software, Experiment, Empirical Research.

Abstract: Aspect-oriented software development is an approach which addresses the construction of software artefacts

which traditional software engineering constructs fail to modularize: the so-called crosscutting concerns.

However, although aspect-orientation claims to permit a better modularization of crosscutting concerns, it is

still not clear whether the application of aspect-oriented constructs has a measurable, positive impact on the

construction of software artefacts. This paper addresses this issue by an empirical study which compares the

specification of crosscutting concerns using traditional composition techniques and aspect-oriented

composition techniques using the object-oriented programming language Java and the aspect-oriented

programming language AspectJ.

1 INTRODUCTION

A typical argument for aspect-oriented software

development (AOSD, (Filman et. al, 2004) is that

aspects permit a better modularization of so-called

crosscutting concerns. Such arguments focus on the

readability and maintainability of software

constructed from the aspect-oriented approach (see

further (K. De Volter and T. D’Hondt, 2004)).

However, such arguments address pieces of software

that are constructed in order to be maintained and

extended for some amount of time – from a software

manager’s point of view the use of aspect-oriented

techniques rather looks like an investment into the

future. But such arguments do not address whether

aspect-oriented techniques can be applied to reduce

code in order to safe development time. However, it

seems pursuable that aspect-orientation already safes

time because of a reduced number of lines of code

caused by the underlying modularization techniques.

One example for aspect-oriented techniques that

is quite often cited in literature is logging (c.f. (J.

Janssen and W. Laatz, 2003) among many others):

invocations to the logger need to appear in a large

number of modules. Furthermore, the pieces of code

that are to be specified need to be adapted within

each module in order to pass for example the method

name or the actual parameters. Without using

techniques that permit to specify the logging

behavior, hand coding such a feature possibly

requires a large amount of development time and

causes in that way additional development costs.

From that point of view is seems clear that aspect-

oriented programming techniques decrease

significantly the development time.

From the other perspective, one can argue that

aspect-oriented programming bring additional

abstractions and therefore additional complexity into

the development of software (cf. e.g. (F. Steimann,

2006)). Such additional complexity reduces the

development speed in such a way that the possible

advantage of the technology turns out to be rather a

burden for the developer and rather increases the

development time.

Although both arguments seem to be reasonable

they contradict each other. From the scientific point

of view this situation is not satisfactory, because

both arguments rely on speculations. According to

the appeal formulated in (W. Tichy, 1998) empirical

methods (cf. (N. Juristo and A. Moreno, 2001; Shull

et. al, 2008)) are an approach to address this

problem. This would permit to strengthen (or

weaken) arguments based on observed data.

This paper introduces a controlled experiment that

studies the development costs in terms of

196

Kleinschmager S. and Hanenberg S. (2009).

IS THE APPLICATION OF ASPECT-ORIENTED PROGRAMMING CONSTRUCTS BENEFICIAL? - First Experimental Results .

In Proceedings of the 11th International Conference on Enterprise Information Systems - Databases and Information Systems Integration, pages

196-201

DOI: 10.5220/0002007301960201

 SciTePress

development time caused by the specification of

redundant code in the object-oriented programming

language Java in comparison to the aspect-oriented

programming language AspectJ. Section 2 describes

the experimental design and argues why we only

focus on static crosscutting code. Section 3 describes

how the experiment was performed. Section 4

evaluates the results. After discussing the results in

section 5, we present related work in section 6.

Finally, we conclude the paper.

2 EXPERIMENT

Our study relies on static crosscutting code, i.e. code

which does not need any dynamic condition fulfilled

at runtime in order to determine whether it should be

executed. In aspect-oriented terms spoken, we study

only aspects with underlying static join points (cf.

e.g. (S. Hanenberg, 2006)). Although the main focus

of research in the area of aspect-oriented

programming language constructs is in the area of

dynamic constructs (cf. e.g. (K. Gybels and J.

Brichau, 2003; L. Prechelt, 2001; Ostermann et. al,

2005)) we reduce our view on aspect-orientation to

static elements because static crosscutting can be

unambiguously determined, i.e. for the resulting

redundant code fragments it can be clearly defined

where and how they should appear.

Next, we are interested in the development time

required to fulfill a programming task that consists

of the specification of redundant code. Hence, we

defined an experiment where developers are

requested to fulfill a programming task in a pure

object-oriented as well as in an aspect-oriented way.

In this experiment, time is the free variable and the

number of fulfilled programming tasks represents

the dependent variable.

Within the experiment subjects were ask to

specify a number of redundant lines of code into a

target application. As a target application, we used a

self-specified game consisting of 9 classes within 3

packages with 110 methods, 8 constructors, and 37

instance variables written in pure Java (version 1.6).

Each class was specified in its own file. The game

consists of a small graphical user interface with an

underlying model-view-controller architecture.

Using this application two tasks needed to be

done, each one in pure Java (version 1.6) and

AspectJ (version 1.6.1) whereby the order of the

programming language was randomly chosen.

First Task: Logging

The first was to add a logging-feature to the

application, where each method (but no

constructors) should be logged. Thereto, a

corresponding logger-interface was provided that

expects from each method its return type, the name

of the classes where the method was declared in, an

array type String with the formal parameter names

and an array of its actual parameters.

class C ... {

...

public R m(int i,A a) {

Logger.log(“C”, “m”, “R”,

new Object[] {i, a},

new String[] {int, A});

…method body…

}

...

}

Figure 1: Exemplary log-invocation in pure Java.

For the object-oriented solution, for a public

method m in class C with parameter types int and A

(and the corresponding parameter names i and a) and

the return type R the corresponding invocation of the

logger in pure Java that needed to be defined by the

developer looks like shown in Figure 1.

The expected type names are simple names, i.e.

no package names were expected by the logger.

Altogether, such a line needed to be added to all 110

methods.

For the aspect-oriented solution, the aspect

definition, consisting of the keyword aspect, an

aspect name and the corresponding brackets was

given to the subject. A good AspectJ (and short)

solution for this task is to specify a pointcut that

refers to the target classes via their package

descriptions and a corresponding advice that reads

from thisJoinPoint the method signature and the

actual parameters. An example for such a piece of

code is shown in figure 2.

pointcut logging():

execution(* game.*.*(..)) ||

execution(* filesystem.*.*(..)) ||

execution(* gui.*.*(..));

before(): logging() {

MethodSignature m = (MethodSignature)

thisJoinPoint.getSignature();

Logger.log(

m.getReturnType().

getSimpleName(), m.getName(),

m.getDeclaringType().getSimpleName(),

thisJoinPoint.getArgs(),

m.getParameterTypes()

);

}

Figure 2: Exemplary log-invocation in AspectJ.

IS THE APPLICATION OF ASPECT-ORIENTED PROGRAMMING CONSTRUCTS BENEFICIAL? - First

Experimental Results

197

Second Task: Nullpointer-Checks

The second task was to add nullpointer-checks to all

non-primitive parameters of all methods in the

application (without constructors). In case one of the

non-primitive parameters was null, an

InvalidGameStateException should be thrown

(which was part of the application). For the object-

oriented solution, 36 methods needed to be adapted.

3 EXPERIMENT EXECUTION

20 subjects participated in the experiment. The

subjects performed their tasks in identical

environmental settings (machines, rooms, etc.). As

an IDE, Eclipse has been used. All subjects were

students within their fifth semester or later.

Each student was taught a short introduction into

AspectJ which took about 1.5 hours. This tutorial

(including exercises) was not meant to be an

exhaustive training in AspectJ. Instead, only those

language constructs that were required in the

experiment were introduced. Constructs such as

declare precedence statements or handler pointcuts

or further advanced constructs in AspectJ were not

trained.

After dividing the subjects into two groups, one

group worked on the previous tasks in the object-

oriented way and later on in the aspect-oriented way,

the other group vice versa. Based on the results of

the questionnaire, both groups had a similar number

of subjects with high as well as with low

development experience. The aspect-oriented groups

did not get any hints how to solve the task. The only

thing delivered to them was the aspect declaration

(without pointcuts and advices).

For each task, all subjects received a set of JUnit

test cases that each subject could execute within his

IDE. The set of test cases covered all subtasks that

needed to be fulfilled. For example, there was an

amount of test cases that covered for the first task all

methods to be logged that checked, whether the

expected log-entries corresponded to the logs

actually performed by the code. In order to finish a

task and to switch to the next task, subjects were

required to pass all test cases of the current task. The

subjects were not required but allowed to use the test

cases while they fulfilled their tasks. The actions

performed by each subject were logged in a way that

permitted later on to compute how many subtasks

have been achieved at what points in time.

Furthermore, a screen recorder ran throughout the

whole experiment for each subject in order to permit

later on to extract information about each subject.

4 RESULTS

Figure 3 shows the collected data from the

experiment (all times are expressed in seconds). For

both tasks, the complete time to fulfill the task was

measured. In order to remove the time required by

the participants to understand the task, the starting

point was set to the moment when subjects started to

write code. The end point was set to the moment

when the subjects fulfilled all test cases.

Furthermore, the descriptive statistics, i.e. the sum,

arithmetic mean, minimum, maximum and standard

derivation is shown in Figure 3.

logging

null-pointer

check

subjec

(sec.)

-t

(sec.)

-t

1 4556 4912 -356 107,81% 1110 437 673 39,37%

2 4922 847 407

17,21% 683 1154 -471 168,96%

3 3015 2258 757 74,89% 768 355 413 46,22%

4 7947 4916 3031 61,86% 862 2722 -1860 315,78%

5 6318 5468 850 86,55% 2036 451 158

22,15%

6 7271 5017 2254 69,00% 1065 516 549 48,45%

7 2840 661 2179 23,27% 694 271 423 39,05%

8 4715 3758 957 79,70% 1494 355 1139 23,76%

9 4826 9902 -5076 205,18% 957 897 60 93,73%

10 2614 2581 33 98,74% 733 513 220 69,99%

11 12240 8146 4094 66,55% 915 375 540 40,98%

12 4985 7177 -2192 143,97% 1777 1510 267 84,97%

13 3791 872 2919 23,00% 630 237 393 37,62%

14 3354 566 2788 16,88% 739 415 324 56,16%

15 2727 3770 -1043 138,25% 419 348 71 83,05%

16 3001 2004 997 66,78% 441 119 322 26,98%

17 3249 682 2567 20,99% 612 189 423 30,88%

18 4586 4515 71 98,45% 684 416 268 60,82%

19 2565 3569 -1004 139,14% 390 208 182 53,33%

20 6705 5074 1631 75,67% 1069 5164 -409

483,07%

logging

null-pointer

check

(sec.)

sum 96227 76695 18078 16652

min 2565 566 390 119

max 12240 9902 2036 5164

mean 4811 3834,8 903,9 832,6

std. deriv. 2367 2624,3 434,21 1184

Figure 3: Results.

First, it turns out that there is a large variety in

the development speed among the subjects. For

example, for the object-oriented logging task the

slowest subject (subject no. eleven) is approximately

five times slower than the fastest subject (subject

ICEIS 2009 - International Conference on Enterprise Information Systems

198

19). The same is true for the object-oriented null-

pointer check task: while here the fastest subject is

still subject 19, the slowest one is subject five. For

the aspect-oriented solutions, the time differences

between slowest and fastest are even more extreme:

in the logging task, the slowest subject is more than

17 times slower than the fastest one; in the null-

pointer check task it is more than 43 times slower.

Considering the comparison of time required for

the object-oriented versus the time required for the

aspect-oriented solution, it turns out that for the

logging task 5 subjects were slower using the aspect-

oriented approach. In the second task, three subjects

were slower using the aspect-oriented approach.

Although we do not consider the comparison of

absolute times between the subjects to be

meaningful (due to the different development

speeds), it turns out that the sums of times for the

aspect-oriented solutions are in both cases less than

the sums of times for the object-oriented solutions.

If we concentrate on the maximum increase of

development speed for a single subject, we can see

that for the logging task the use of aspect-orientation

is only 17% of the time required for the object-

oriented solution (subject 14). For the null-pointer

check task we see that the time required by the

aspect-orientated solution is only 22% of the time

required by the object-oriented solution (subject 5).

If we concentrate on the maximum decrease of

development speed, we see that for the logging task

subject 9 spent more than twice the time for solving

it in an aspect-oriented way. For the null-pointer

check we see that it took subject 20 five times more

time to solve it in an aspect-oriented way.

In order to check whether there is a significant

difference in the object-oriented and the aspect-

oriented approach, we first check whether a pair-

samples t-test can be applied. A pair-samples t-test

requires (according to e.g. (J. Bortz, 1999)) that the

underlying sample comes from a normally

distributed population. Therefore, we applied the

Shapiro–Wilk test (S. S. Shapiro and M. B. Wilk,

1965) which checks these characteristics. However,

the result of the test is that the hypothesis, that the

sample comes from a normally distributed

population, needs to be rejected.

Hence, we need to apply a less restrictive

statistical method: the Wilcoxon signed-rank test

(see e.g. (J. Bortz, 1999)) which compares two

related samples with respect to their central

tendency.

According to this, we formulate the null

hypothesis :

H0: The median of the object-oriented and the

aspect-oriented solution are equal.

The alternative hypothesis is

H1: The median of the object-oriented and

the aspect-oriented solution differs.

Performing the Wilcoxon-test on the logging

task, we find with under significance level of 5%

that here is a difference in the medians of the object-

oriented and the aspect-oriented solution (hence, the

null hypothesis is rejected). A comparison of

positive and negative ranks reveals that the median

of the aspect-oriented solution is significantly lower

than the median of the object-oriented solution.

Repeating the same test on the null-pointer check

reveals the same results.

Hence, in both cases we can determine that

aspect-oriented construction reveals better results

that the object-oriented way. In both cases this

difference is significant.

5 DISCUSSION

Our intention was to study the different development

times for static crosscutting code using Java and

AspectJ. Thereto, two tasks were given to subjects

(logging and null-pointer check). It turned out, that

we were able to detect a significant difference in the

development time in the logging example as well as

in the null-pointer check examples. From that

perspective is looks obvious that the application of

aspect-oriented constructs for the specification of

redundant code is more appropriate then the use of

object-oriented constructs. However, we should also

be aware of the kind of redundant code

specifications: in both cases the number of

redundant code lines is relatively high (110 and 36

lines of code). We think that we can conclude here

that aspect-oriented constructs turn out to be

beneficial in situations where the number of

redundant code lines is relatively high. Whether the

application of aspect-oriented constructs turns out to

be beneficial in situations with rather a low number

of redundant code can be doubted – however, the

experiment is not able to make any statement about

this. Furthermore, it should be noted that the impact

of further potential influencing factors (for example

the training of aspect-oriented constructs in the

beginning of the experiment) has not been studied.

IS THE APPLICATION OF ASPECT-ORIENTED PROGRAMMING CONSTRUCTS BENEFICIAL? - First

Experimental Results

199

6 RELATED WORK

The work that is directly related to our experiment is

the one conducted by Walker et al (Walker, et. al,

1999). Here, a number of subjects performed a

number of tasks on an object-oriented system using

the aspect-oriented language AspectJ. The main

difference to our experiment is, that there developers

had much more freedom about how to use the

language in order to achieve a certain goal. Our

experiment was in that way much more restricted.

Further related approaches are for example studies

on the maintainability of aspect-oriented software

(cf. (M. Bartsch and R. Harrison, 2007)). Also,

studies about the design stability (see (Greenwood

et. al, 2007)) or language specific features such as

the study performed in (Coelho et. al, 2008) are in

that way related that the impact of aspect-oriented

language constructs on some piece of software is

being tested. The main difference between those

approaches and the here describes experiment is,

that we try to focus only on the development time

and neglects currently all other desirable attributes

of software.

7 CONCLUSIONS AND FUTURE

WORK

In this paper we presented an experiment that

compares the use of aspect-oriented constructs for

the purpose of specifying static crosscutting code

with the corresponding specification using ordinary

language constructs. In the experiment, 20 subjects

performed two static crosscutting tasks on an object-

oriented program using an object-oriented language

as well as an aspect-oriented. The experiment

showed that for tasks with a relative high number of

redundant code lines the application of aspect-

oriented techniques turns out to be useful.

Altogether, it should be mentioned that empirical

knowledge, especially in the area of aspect-

orientation, hardly exists and controlled experiments

are rather rare. Hence, the here presented experiment

cannot be considered as a final answer to the

question of how beneficial aspect-orientation is.

Instead, we rather consider this as a first and

necessary step in order to explore quite a large field.

REFERENCES

Bartsch, M.; Harrison, R.: An exploratory study of the

effect of aspect-oriented programming on

maintainability, Software Quality, 2007.

Bortz, J.: Statistik für Sozialwissenschaftler, 5te Auflage,

Springer, 1999

Box, G.; Jenkins, G. M.; Reinsel, G.: Time Series

Analysis, Forecasting and Control, Prentice Hall,

1994.

Coelho, R.; Rashid, A.; Garcia, A.; Ferrari, F.; Cacho, N.;

Kulesza, U.; von Staa, A.; Pereira de Lucena, C.:

Assessing the Impact of Aspects on Exception Flows:

An Exploratory Study. ECOOP 2008: 207-234

Curtis, B.: Substantiating program variability, Proceedings

of the IEEE, 69(7), July 1981.

De Volder, K.; D’Hondt, T.: Aspect-Oriented Logic

Metaprogramming, in (Filman et. al, 2004), 2004.

Filman, R.; Elrad, T.; Clarke S.; Aksit, M. (eds.): Aspect-

Oriented Software Development, Addison-Wesley

Longman, Amsterdam, 2004.

Phil Greenwood, Thiago Bartolomei, Eduardo Figueiredo,

Marcos Dosea, Alessandro Garcia, Nelio Cacho,

Cláudio Sant’Anna1, Sergio Soares, Paulo Borba, Uirá

Kulesza, On the Impact of Aspectual Decompositions

on Design Stability: An Empirical Study, Proceedings

of ECOOP 2007, pp. 176-200

Gybels, K.; Brichau, J.: Arranging language features for

more robust pattern-based crosscuts. Proceedings of

AOSD, 2003, pp- 60-69.

Hanenberg, S.: Design Dimensions of Aspect-Oriented

Systems, PhD thesis, University of Duisburg-Essen,

Institute for Computer Science and Business

Information Systems, 2006.

Janssen, J.; Laatz, W.: Statistische Datenanalyse mit

SPSS, 4th edition, Springer, 2003.

Juristo, N.; Moreno, A.: Basics of Software Engineering

Experimentation, Kluwer Academic Publishers, 2001.

Kellens, A.; Mens, K.; Brichau, J., Gybels, K.: Managing

the Evolution of Aspect-Oriented Software with

Model-based Pointcuts, Proceedings of the European

Conference on Object-Oriented Programming, 2006,

501-525.

Kiczales, G.; Lamping, J.; Mendhekar, A.; Maeda, C.;

Lopes, C.; Loingtier, J.-M.; Irwin, J.: Aspect-Oriented

Programming. Proceedings of European Conference

on Object-Oriented Programming (ECOOP), 1997,

p.220-242.

Ostermann, K.; Mezini, M.; Bockisch, C.: Expressive

Pointcuts for Increased Modularity. Proceedings of

European Conference on Object-Oriented

Programming (ECOOP), 2005, pp. 214-240

Prechelt, L.: Kontrollierte Experimente in der

Softwaretechnik, Springer, 2001.

Shapiro, S. S. and Wilk, M. B. (1965). "An analysis of

variance test for normality (complete samples)",

Biometrika, 52, 3 and 4, pages 591–611

Shull, F., Singer, J., Sjøberg, D. (eds.), Guide to Advanced

Empirical Software Engineering, Springer, 2008.

ICEIS 2009 - International Conference on Enterprise Information Systems

200

Steimann, F.: The paradoxical success of aspect-oriented

programming, ACM SIGPLAN Notices, Volume 41 ,

Issue 10 (October 2006), pp. 481 - 497

Tichy, W.: Should Computer Scientists Experiment More?

IEEE Computer 31(5), 1998, pp. 32-40.

J.Walker, R.; Baniassad, E.; Murphy, G.: An Initial

Assessment of Aspect-oriented Programming,

Proceedings of the 21st International Conference on

Software Engineering (16–22 May 1999, Los Angeles,

CA, USA).

IS THE APPLICATION OF ASPECT-ORIENTED PROGRAMMING CONSTRUCTS BENEFICIAL? - First

Experimental Results

201
