ANALYSIS OF WEB-PROXY CACHE REPLACEMENT

ALGORITHMS UNDER STEADY-STATE CONDITIONS

∗

L. G. C

ardenas, A. Pont, J. Sahuquillo, J. A. Gil

Department of Computer Engineering, Polytechnic University of Valencia, Camino de Vera s/n 46071, Valencia, Spain

Keywords:

Performance Evaluation, Simulation, Proxy-Web, Replacement Algorithms.

Abstract:

Web-Proxy servers are used to reduce the bandwidth consumption and users’ perceived latency while navigat-

ing the WWW, by caching the most frequent objects accessed by users. Since they were introduced, most of

the evaluations studies related to Web-Proxy caches have focused on the replacement algorithms performance

using simulation techniques. But few of them have been done assuring the representativeness of the studies

and considering real traces and cache sizes.

This paper describes a methodology that permits fair performance comparison studies of replacement algo-

rithms, that is, the system reaches the steady-state and the results are provided showing narrow conﬁdence

intervals. An experimental evaluation study applying this methodology is also presented. The study uses a

trace-driven simulation framework, real traces containing more than one hundred million of user’s requests,

and compares three replacement algorithms implemented in actual Web-Proxy caches.

1 INTRODUCTION

Web-Proxy servers are placed between the users surf-

ing the Web and the original servers with the purpose

of caching the most frequently requested objects and

saving both latency and bandwidth. Due to proxy disk

space limitations, replacement algorithms are used by

the cache management to improve the disk space uti-

lization. Most of the Web-Proxy performance studies

have focused on the evaluation of these replacement

techniques using analytical or simulation models.

Simulation is the most common approach used

to model Web-Proxy server cache replacement algo-

rithms (Cao and Irani, 1997), (Arlitt et al., 1998), (Ar-

litt et al., 1999), (Jin and Bestavros, 2000), (Bahn

et al., 2002). There is a large amount of Web-Proxy

server cache replacement algorithms proposals, how-

ever, few of them can be implemented in an actual

Web-Proxy system such as Squid (Squid, 2005). This

∗

This work has been partially supported by the: i) Span-

ish Ministry of Education and Science and the European

Investment Fund for Regional Development (FEDER) un-

der grant TSI 2005-07876-C03-01, and ii) Mexican Gov-

ernment Grant CONACYT 177846/191901.

is because some of the parameters used in the evic-

tion mechanism are difﬁcult to estimate as they are

strongly trace-dependent.

In any evaluation study, it is important to pro-

vide two conditions in order to guarantee the repre-

sentativeness of the study: i) to reach a steady-state

system after an adequate warming phase, and ii) to

obtain results afterwards using conﬁdence intervals.

This paper presents an evaluation study of Web-Proxy

server replacement algorithms matching both condi-

tions, therefore accomplishing a fair comparison. We

show that the evaluation must reach a steady-state sys-

tem so reﬂecting accurate performance of the replace-

ment algorithm. The conﬁdence intervals show how

precise the estimation is for the evaluated metrics.

The study evaluates the most common metrics to

quantify the effectiveness of the replacement algo-

rithms: the Hit Ratio (HR) and the Byte Hit Ra-

tio (BHR), and additionally it includes the results of

the Delay Saved Ratio (DSR). We use a large set of

Web-Proxy cache traces obtained from a Web-Proxy

server cache of an University Campus and from the

IRCACHE Proxy-Server cache system. The obtained

results show a wide conﬁdence interval when mea-

253

G. Cárdenas L., Pont A., Sahuquillo J. and A. Gil J. (2007).

ANALYSIS OF WEB-PROXY CACHE REPLACEMENT ALGORITHMS UNDER STEADY-STATE CONDITIONS.

In Proceedings of the Third International Conference on Web Information Systems and Technologies - Internet Technology, pages 253-260

DOI: 10.5220/0001285702530260

 SciTePress

suring the Byte Hit Ratio, overlapping the results of

different replacement algorithms. As a consequence,

we can afﬁrm that there is a group of algorithms that

achieves similar performance when considering the

Byte Hit Ratio metric. This result is opposite to most

of the published conclusions in the literature, where

an algorithm achieves the best performance among

the evaluated algorithms. On the other hand, the re-

sults measuring the Hit Ratio metric have a narrow

conﬁdence interval allowing to select the best replace-

ment algorithm for the workload used.

The remainder of this paper is organized as fol-

lows. Section 2 describes the related work in

Web-Proxy server cache evaluations. Section 3 de-

scribes the experimental environment used. Section 4

presents the evaluation of the Web-Proxy server cache

replacement algorithms, and analyzes the experimen-

tal results. Finally, Section 5 presents some conclud-

ing remarks.

2 RELATED WORK

The most commonly evaluation technique used in

Web-Proxy cache evaluation studies is the trace-

driven simulation using a captured log as a workload

(Wooster and Abrams, 1997), (Cao and Irani, 1997),

(Arlitt et al., 1998), (Arlitt et al., 1999), (Jin and

Bestavros, 2000), (Bahn et al., 2002). Few of them

(Arlitt et al., 1998), (Arlitt et al., 1999) include in their

evaluation methodology a warming-phase, only one

of them (Wooster and Abrams, 1997) provides results

using conﬁdence intervals, and none of them provides

results in both conditions. These studies use the HR

and the BHR metrics to compare and to evaluate the

performance of the proposed replacement algorithms.

The HR indicates how efﬁcient a Web-Proxy server is,

and the BHR indicates how much of the total amount

of bytes requested are served from the cache (i.e., how

much trafﬁc volume can be saved). On the other hand,

time-related metrics are seldom used due to the difﬁ-

culty when modeling accurately the penalty time for

the Internet accesses. This section brieﬂy describes

these works.

Cao and Irani (Cao and Irani, 1997) propose the

GreedyDual-Size (GDS) replacement algorithm us-

ing a large set of captured logs with a restriction of

two million requests in each simulation. The GDS is

an extended version of the GreedyDual algorithm that

incorporates the object size, setting a cost/size value

for each object in the cache. They perform a trace

preprocessing discarding the log entries with a 304

HTTP response-code. Therefore, the simulation re-

sults could not reﬂect the current performance of the

replacement algorihtms because the log entries dis-

carded represent a large amount of the total of log en-

tries. Their proposal achieves the best performance

for the three metrics measured (the HR, the BHR, and

the Reduced Latency).

Arlitt et al. (Arlitt et al., 1998) (Arlitt et al.,

1999) propose and evaluate two formula-based re-

placement algorithms: Greedy-Dual Size Frequency

(GDSF) and the Least Frequently Used with Dynamic

Aging (LFUDA) using a single captured log of three

months length. The GDSF keeps the smaller size

popular requested objects in the cache (a smaller size

object has higher probability of being frequently re-

quested). On the other hand, the LFUDA keeps the

most popular objects in the cache, regardless of their

size. Both algorithms incorporate an aging mecha-

nism to avoid the cache pollution. The HR is cal-

culated considering the un-cacheable log entries as

misses and including the 304 status responde-code log

entries; and the BHR is calculated using only the logs

containing the object size information. The authors

provide results for the HR and the BHR metrics using

a warming phase of three weeks; but no conﬁdence in-

tervals are shown. Their results show that size-based

policies (i.e., the GDSF) achieve a better HR, and that

frequency-based policies (i.e, LFUDA) obtain a bet-

ter BHR. Both algorithms are currently implemented

in the Squid Proxy Cache (Squid, 2005).

Jin and Bestravos (Jin and Bestavros, 2000) pro-

pose the GreedyDual-Size Popularity (GDSP) algo-

rithm, and evaluate it using two captured logs (with

approximately four million requests in each log). The

GDSP uses an eviction mechanism similar to the

GDSF. They use the same trace prepocessing to dis-

card the log entries of Cao and Irani but they esti-

mate a penalty time for each log entry (simbolizing

an object transmission from the Web-Server) using a

mathematical formula, which does not consider the

beneﬁts of the current HTTP/1.1 protocol (i.e., per-

sistent connections) (Fielding et al., 1999). The pa-

rameters of this mathematical formula are estimated

using a least-square ﬁt. In the evaluation, the pro-

posed GDSP presents the best results for the HR, the

BHR and the Latency Saving Ratio metrics.

Bahn et al. (Bahn et al., 2002) propose the

Least Uniﬁed-Value (LUV) replacement algorithm

and compare it against a large set of replacement algo-

rithms using two captured logs with a small amount of

requests. For this purpose, the experiments consider

small cache sizes, unrealistic in the actual Web-Proxy

server caches. The main drawback of this study is the

trace preprocessing required to adjust a parameter by

the eviction mechanism. In spite of this disadvantage,

they conclude that the implementation is efﬁcient in

WEBIST 2007 - International Conference on Web Information Systems and Technologies

254

both time and space complexities. Their results show

the LUV as the best replacement algorithm for all the

metrics studied (HR, BHR, and the DSR). There is

no information about how the penalty times are esti-

mated to calculate the DSR, or how the traces are pre-

pared to feed the simulator. Finally, they neither use a

warming phase, nor estimate conﬁdence intervals.

3 EXPERIMENTAL

ENVIRONMENT

This section describes the simulation framework, the

workload, the performance metrics, and the replace-

ment algorithms used in this evaluation study.

3.1 Simulation Framework

We present in (Cardenas et al., 2004) an experimental

framework for modeling Web-Proxy server caching

replacement algorithms, and validate this framework

in (C

ardenas et al., 2005) againts several replacement

algorithms of a real Web-Proxy server cache. This

section summarizes the main features of such envi-

ronment.

The Multikey Web Cache Simulator (MSE) is an

object-oriented simulator, and allows an easy imple-

mentation of new cache replacement algorithms. This

simulator is composed by three modules: the ﬁlter

module, the cache-simulator module, and the statis-

tics module. The ﬁlter module prepares the Web-

Proxy server logs to feed the cache-simulator mod-

ule. The cache-simulator module models a Web-

Proxy cache replacement algorithm including the

cache characteristics of a parameters ﬁles. The statis-

tics module takes as input: i) the trace obtained in

the cache-simulator module, and ii) the number of

requests of the warming phase required to reach a

steady-state system. The statistics module generates a

results ﬁle for each metric evaluated (i.e., the HR, the

BHR, and the DSR) using conﬁdence intervals with a

95 % conﬁdence level.

3.2 Workload

This section describes the steps taken to prepare the

Web-Proxy server logs used in our evaluation study.

The traces used were obtained from the Web-Proxy

server logs of the Polytechnic University of Valen-

cia (UPV), and the IRCACHE Proxy-Cache system

(IRCache, 2005). These Web-Proxy servers use the

Squid Proxy Cache software (Squid, 2005), and every

trace represents approximately one month of brows-

ing activity. The prepared traces were LogJun05, Log-

Nov05 and LogMay06 from the UPV, and LogFeb06-

pb from the IRCACHE Proxy-Cache system. The

original total amount of log entries in the UPV are

hundreds of millions, while in the IRCACHE are tens

of millions.

The trace has a strong inﬂuence on the perfor-

mance of the replacement algorithm, therefore a cor-

rect trace preparation is required in order to obtain re-

sults reﬂecting the behavior of the replacement algo-

rithm. The trace preparation was made in two phases:

a) the ﬁltering of the un-cacheable content by the

Web-Proxy, and b) the replacing of inappropriate in-

formation registered in the original Web-Proxy server

log. The UPV Web-Proxy logs required a prior phase

excluding the log entries requesting content from the

campus Web-Servers.

The ﬁrst phase starts eliminating the log entries

with an un-cacheable HTTP status response-codes,

as stated in the HTTP/1.1 protocol (Fielding et al.,

1999). Then, we exclude the log entries request-

ing dynamic content, since this content is usually not

cached by a Web-Proxy server.

Table 1 shows the percentage over the total of the

log entries with a 200 and 304 HTTP status response-

code in the LogJun05, LogNov05, LogMay06 and

LogFeb06-pb traces after the ﬁrst phase preparation.

The log entries with a 304 HTTP status response-code

are a large amount of the total amount of requests in

every trace; in the UPV and the IRCACHE trace, this

percentage is never less than 33.71% and 15.17%, re-

spectively. Although, these type of requests are not

cached by a Web-Proxy, they are Web-Client valida-

tion messages of a content already stored in the Web-

Proxy server cache, therefore they must be considered

in the evaluation experiments.

Table 1: Percentages over the total of the 200 and 304 HTTP

status response-code log entries for the traces LogJun05,

LogNov05, LogMay06. and LogFeb06-pb.

HTTP LOG

response-code Jun05 Nov05 May06 Feb06-pb

200 62.18 60.99 60.73 84.83

304 37.82 39.01 39.27 15.17

In the second phase of the trace preparation we

replace log entries data ﬁelds. The ﬁrst step of this

phase is to identify which type of log entries require

the estimation of new information. There are two

cases: a) when the penalty time information does not

represent the transmission time of an object requested

to the Web-Server from the Web-Proxy server, and

b) when the response size information does not sym-

bolize the size of the object requested (like in the

ANALYSIS OF WEB-PROXY CACHE REPLACEMENT ALGORITHMS UNDER STEADY-STATE CONDITIONS

255

If-not-modiﬁed-since log entries) since the registered

value is the size of a validation message (approx. 250

bytes). Table 2 shows the duple Squid-HTTP status

response-code of the log entries and the cases where

a replace is required.

Table 2: Squid-HTTP status response-code of the log en-

tries and the cases where data replacement is required.

Response-code Object Size Penalty Time

TCP HIT/200 No Yes

TCP MISS/200 No No

TCP MISS/304 Yes Yes

TCP REF MISS/200 No No

TCP REF HIT/200 No No

TCP REF HIT/304 Yes Yes

TCP IMS HIT/200 No Yes

TCP IMS HIT/304 Yes Yes

TCP MEM HIT/200 No Yes

We use the Log-Logistic probabilistic distribution

function when we need to estimate the penalty time.

This function approximates the penalty times cumula-

tive distribution function of a Web-Proxy server cache

(including the long tail). The reason why we se-

lect this probabilistic distribution can be found in (Gil

et al., 2005). In the cases where we need to estimate a

new object size, we use an estimated mean object size

for its corresponding MIME type. The MIME (Multi-

purpose Internet Mail Extensions) (Freed and Boren-

stein, 1999b) (Freed and Borenstein, 1999a) groups

the type of responses using a well understood ”di-

facto” standard.

Table 3 shows the total amount of requests, the

trafﬁc volume, the total amount of unique objects

(Unique O.), the cache space required to store all the

unique objects, and the theoretical Hit Ratio (Max Hit

Ratio) that will be obtained using a Proxy with an in-

ﬁnite cache size for the LogJun05, LogNov05, Log-

May06 and LogFeb06-pb after the second phase trace

preparation.

Table 3: Main Statistics of the Traces LogJun05, LogNov05,

LogMay06. and LogFeb06-pb.

LOG

Statistic Jun05 Nov05 May06 Feb06-pb

Requests 34.1M 48.3M 37.8M 4.2M

Trafﬁc (GB) 730 834 725 150

Unique O. 5.4M 7.7M 6.4M 2.4M

Unique O.(GB) 225 243 193 92

Max Hit Ratio 84.13 84.14 83.03 42.23

3.3 Performance Metrics

As mentioned above, the performance metrics used in

our evaluation are: HR, BHR, and the DSR. The DSR

is calculated in our experiments because we can esti-

mate the penalty times for the log entry cases where

this information is not available in the log.

The Hit Ratio (equation 1) indicates the percent-

age of web objects served from the proxy cache. It

is a measure of how efﬁcient is the cache manage-

ment. Although the HR is the most used metric in

Web-Proxy cache evaluation studies, there is not evi-

dent how this metric quantiﬁes the beneﬁts about the

Web-Proxy from the users’ point of view.

HR =

i=1

Hit

j=1

Requests

(1)

The Byte Hit Ratio (equation 2) indicates how

much of the total amount of bytes requested have been

served from the cache. Some authors (Wessels, 2001)

(Rabinovich, 2002) claim that the BHR is directly re-

lated to other metrics such as the saved bandwidth.

BHR =

i=1

Hit

i(Bytes)

j=1

Requests

j(Bytes)

(2)

The Delay Saved Ratio (equation 3) is a time-

related metric and has been deﬁned as the sum of

penalty times of the hits (as if they were all misses)

over the sum of the penalty times from all the requests

(again, as if they were all misses). This metric indi-

cates the amount of penalty times saved by the Web-

Proxy server, instead of being served by the original

Web-Server.

DSR =

i=1

Hit

i(P enaltyT ime)

j=1

Requests

(P enaltyT ime)

(3)

3.4 Replacement Algorithms

The replacement algorithms select which objects

must be evicted from the cache when space is only

required for a new incoming object. We evaluate

the replacement algorithms implemented in the Squid

Proxy Cache (Squid, 2005), a real Web-Proxy system,

because many of the theoretical proposals in the liter-

ature require a parameter estimation obtained from a

preprocessing of the traces in order to perform opti-

mally.

The Least Recently Used (LRU) is the most pop-

ular replacement algorithm implemented in a Web-

Proxy server. This algorithm exploits the temporal

locality of the user’s accesses, and it is very simple to

WEBIST 2007 - International Conference on Web Information Systems and Technologies

256

implement because the eviction mechanism requires

only the access time-stamp. The Greedy Dual Size

Frequency (GDSF) and the the Least Frequently Used

Dynamic Aging (LFUDA) are formula-based algo-

rithms. The GDSF tries to maximize the HR metric,

and the LFUDA tries to maximize the BHR metric.

The eviction mechanism of the GDSF uses equation

4 and the LFUDA uses equation 5 to estimate a value,

which is used as a key, to select which objects are

evicted from the cache (the objects with the smaller

key gets evicted ﬁrst). L is an aging mechanism used

to avoid the pollution of the cache, expelling from the

cache not-recently referenced objects with a high fre-

quency of access.

GDSF =

F requency

Size

+ L (4)

LF UDA = F requency + L (5)

4 EVALUATION STUDY

This section presents the methodology of our Web-

Proxy Server cache evaluation. As mentioned above

two conditions are necessary to guarantee the accu-

racy of any study: i) to reach a steady-state, and ii) to

obtain results with narrow conﬁdence intervals. First,

we perform a small set of experiments to analyze the

importance of reaching a steady-state system for the

evaluation of Web-Proxy server cache replacement al-

gorithms. Then, we explain the steps of the proposed

methodology used in this evaluation study. Finally,

we present the obtained results of the evaluation.

4.1 Reaching the Steady-State System

The steady-state condition is reached when the Hit

Ratio of the Web-Proxy cache is stable over time, in

spite of the user’s accesses variations. To reach this

state, a warming phase is needed to avoid the cold

misses; this kind of misses could alter the results of

any performance evaluation.

Table 4 shows the Hit Ratio (HR), the Byte Hit Ra-

tio (BHR), and the Delay Saved Ratio (DSR) obtained

in a simulation experiment of an inﬁnite cache using

the LogMay06 trace: i) without a warming phase, ii)

with a warming phase of twenty million requests, and

iii) the percentage difference in these two states. An

inﬁnite cache size would contain all the objects re-

quested to a Proxy and in our case all the objects in-

cluded in the trace. Notice that the results obtained

with and without a warming phase present signiﬁcant

differences that can alter the conclusions of any study.

These differences can be also observed in the values

of the Max Hit Ratio numerically calculated (see Ta-

ble 3) for the inﬁnite cache size when simulations

with a warming phase are carried out. Therefore the

steady-state is a required condition for any evaluation

study.

Table 4: The HR, BHR and DSR with and without a warm-

ing phase, and difference with an inﬁnite cache under the

trace LogMay06.

Metric Non-warming Warming Difference

HR 82.71 85.63 3.53

BHR 69.91 74.88 7.10

DSR 69.35 73.75 4.4

Table 5 shows the HR,the BHR, and the DSR ob-

tained in a simulation experiment of a 8GB cache us-

ing the GDSF replacement algorithm without a warm-

ing phase, and with a warming phase of: 5, 10, 15, 20,

25, 30, 35 million requests using the LogMay06 trace.

As we can observe, the values obtained using the HR

and the DSR metric are higher as the amount of the

requests of the warming phase increases; as opposite,

the values obtained in the BHR metric decrease. Be-

sides, we can observe the variation of the values of the

different metrics (compare to the non-warming exper-

iment) as we increment the amount of log entries used

in the warming phase.

Table 5: HR, BHR and DSR without a warming phase,

and using different warming phase length of a 8GB cache

simulation experiment with the GDSF using the trace Log-

May06.

Warming Metric

Amount HR BHR DSR

No 81.07 38.04 61.77

5M 82.14 37.28 63.04

10M 82.47 36.92 63.25

15M 82.90 36.33 63.53

20M 83.17 36.47 63.74

25M 83.23 35.91 63.78

30M 83.73 35.62 66.15

4.2 Methodology

The evaluation methodology used is organized in the

following steps. First, we select the number of re-

quests of the warming phase, allowing to reach a

steady-state system. Throughout all the experiments

we use a twenty million requests warming phase for

the UPV traces, and two million requests for the IR-

CACHE traces. This amount of requests will allow

to ﬁll the cache space, and to perform a substancial

ANALYSIS OF WEB-PROXY CACHE REPLACEMENT ALGORITHMS UNDER STEADY-STATE CONDITIONS

257

amount of evictions as training; no results are col-

lected from this period. Then, we estimate the con-

ﬁdence intervals for all the metrics (the HR, the BHR

and, the DSR). Our conﬁdence intervals are calcu-

lated with a conﬁdence level of 95%.

4.3 Results

The experiments consider cache sizes ranging from

1GB to 32GB typically used in Web-Proxy cache sys-

tems (IRCache, 2005). Simulation experiments with

a cache size larger than 32GB are worthless, because

the results obtained with a cache size of 32GB using

the HR metric are very close to the Inﬁinite Cache

Hit Ratio. For comparison purposes, we calculate the

Inﬁnite Hit Ratio (IHR), the Inﬁnite Byte Hit Ratio

(IBHR), and the Inﬁnite Delay Saved Ratio (IDSR)

for all the studied traces. These values allow us to

compare the simulation results of different cache sizes

with the results of an inﬁnite cache.

Figure 1 shows the HR obtained for the traces

LogJun05, LogNov05, LogMay06 and LogFeb06-pb

using cache sizes from 1 to 32GB. The GDSF ob-

tains the best HR in all the traces evaluated for all the

cache sizes employed. This is indeed an algorithm

that maximizes the HR, as in all traces the IHR is al-

most reached with 32GB cache size. As we observe

in the ﬁgure, the results measuring the HR have a nar-

row conﬁdence interval; therefore allows to select the

GDSF as the best replacement algorithm as stated in

the literature.

Figure 2 shows the BHR obtained for the traces

LogJun05, LogNov05, LogMay06 and LogFeb06-pb

using cache sizes from 1 to 32GB. We ﬁrst observe a

wide conﬁdence interval, compared to the conﬁdence

intervals obtained measuring the HR, this is the ef-

fect of the high size variation in the requested ob-

jects. This has a direct consequence: we cannot se-

lect an unique best algorithm, but a group of algo-

rithms with similar performance which vary depend-

ing on the workload. Therefore, we can afﬁrm that the

performance of the LFUDA (the algorithm below the

IBHR in the ﬁgure), is as good as the LRU (the sec-

ond below the IBHR) because the conﬁdence intervals

overlap. The GDSF algorithm obtains the worst BHR

for the used traces.

Figure 3 shows the DSR of the traces LogJun05,

LogNov05, LogMay06 and LogFeb06-pb using cache

sizes from 1 to 32GB. Again, we observe a wider con-

ﬁdence interval, as in the results obtained measuring

the BHR. The top group of algorithms for this met-

ric is conformed by the LFUDA and the GDSF, while

in the IRCACHE trace any of the studied algorithms

could be selected as the best one.

The narrow conﬁdence interval obtained in the HR

metric is a consequence of the system stability during

the simulation experiments. The HR is estimated cal-

culating the ratio of the total amount of hits over the

total amount of requests. This ratio is stable after the

system reaches the warming phase.

On the other hand, the BHR is estimated using

the response size. This value could vary in several

orders of magnitude from request to request (from a

few KB to some GB). As a consequence, there is a

wide conﬁdence interval in the BHR metric caused

by the variations of the responses size. Finally, the

wide conﬁdence interval obtained in the DSR metric

is originated by the variations of the penalty times.

5 CONCLUSIONS

A large amount of research works has focused on the

evaluation of Web-Proxy server cache replacement al-

gorithms using simulated systems using the captured

logs as workload. Among these works, few compar-

isons include a warming phase to reach the steady

state, only one obtain results using conﬁdence inter-

vals, and none include both of these conditions. As a

consequence, the results obtained and the conclusions

reached could have a low representativeness and be

questionable.

This paper describes a methodology to fairly com-

pare Web-Proxy server cache replacement algorithms

when accomplishing the mentioned conditions. The

preliminary experiments results show that an evalu-

ation of Web-Proxy server cache replacement algo-

rithms without reaching the steady-system could alter

the obtained results.

We show the experimental results for the most

common Web-Proxy server cache replacement algo-

rithms using the proposed evaluation methodology.

The comparison shows that when using conﬁdence

intervals no replacement algorithm can be identiﬁed

as the best one, as it is usually presented in the litera-

ture, but a group of best-performing algorithms. The

results obtained using the Hit Ratio metric have nar-

row conﬁdence intervals generated by the system sta-

bility, therefore, we select the GDSF as the replace-

ment algorithm that maximizes this metric (as also

mentioned in the literature). But, as the conﬁdence

intervals for the Byte Hit Ratio metric are wider (due

to the response size variations), we can afﬁrm that the

LFUDA and the LRU perform equally good. As a

consequence, we can select any of these algorithms to

reduce the trafﬁc, and as the LRU presents less CPU

overload than the LFUDA, the LRU could be the best

choice to reduce the bandwith consumption.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

258

32 16 8 4 2 1

SIZE (GB)

LogJun05

GDSF

LFUDA

LRU

INF

32 16 8 4 2 1

SIZE (GB)

LogNov05

GDSF

LFUDA

LRU

INF

32 16 8 4 2 1

SIZE (GB)

LogMay06

GDSF

LFUDA

LRU

INF

32 16 8 4 2 1

SIZE (GB)

LogFeb06-pb

GDSF

LFUDA

LRU

INF

Figure 1: The Hit Ratio of traces LogJun05, LogNov05, LogMay06. and LogFeb06-pb.

32 16 8 4 2 1

BHR

SIZE (GB)

LogJun05

GDSF

LFUDA

LRU

INF

32 16 8 4 2 1

BHR

SIZE (GB)

LogNov05

GDSF

LFUDA

LRU

INF

32 16 8 4 2 1

BHR

SIZE (GB)

LogMay06

GDSF

LFUDA

LRU

INF

32 16 8 4 2 1

BHR

SIZE (GB)

LogFeb06-pb

GDSF

LFUDA

LRU

INF

Figure 2: The Byte Hit Ratio of traces LogJun05, LogNov05, LogMay06. and LogFeb06-pb.

ANALYSIS OF WEB-PROXY CACHE REPLACEMENT ALGORITHMS UNDER STEADY-STATE CONDITIONS

259

32 16 8 4 2 1

DSR

SIZE (GB)

LogJun05

GDSF

LFUDA

LRU

INF

32 16 8 4 2 1

DSR

SIZE (GB)

LogNov05

GDSF

LFUDA

LRU

INF

32 16 8 4 2 1

DSR

SIZE (GB)

LogMay06

GDSF

LFUDA

LRU

INF

32 16 8 4 2 1

DSR

SIZE (GB)

LogFeb06-pb

GDSF

LFUDA

LRU

INF

Figure 3: The Delay Saved Ratio of traces LogJun05, LogNov05, LogMay06. and LogFeb06-pb.

REFERENCES

Arlitt, M., Cherkasova, L., Dilley, J., Friedrich, R., and Jin,

T. (1999). Evaluating content management techniques

for Web proxy caches. In Proceedings of the Work-

shop on Internet Server Performance (WISP99).

Arlitt, M., Friedrich, R., and Jin, T. (1998). Performance

evaluation of Web proxy cache replacement policies.

Lecture Notes in Computer Science, 1469:193+.

Bahn, H., Koh, K., Min, S. L., and Noh, S. H. (2002).

Efﬁcient replacement of nonuniform objects in web

caches. IEEE Computer, 35(6):65–73.

Cao, P. and Irani, S. (1997). Cost-aware www proxy

caching algorithms. In USENIX Symposium on Inter-

net Technologies and Systems.

ardenas, L. G., Gil, J. A., Sahuquillo, J., and Pont, A.

(2005). Emulating web cache replacement algorithms

versus a real system. In 10th IEEE Symposium on

Computers and CommunicationsISCC2005.

Cardenas, L. G., Sahuquillo, J., Pont, A., and Gil, J. A.

(2004). The multikey web cache simulator: a platform

for designing proxy cache management techniques. In

12th Euromicro Conference on Parallel, Distributed

and Network based Processing PDP2004.

Fielding, R., Gettys, J., Mogul, J., Frystyk, H., Masinter,

L., Leach, P., and Berners-Lee, T. (1999). Hyper-

text transfer protocol – http/1.1. RFC 2616 - Network

Working Group.

Freed, N. and Borenstein, N. (1999a). Multipurpose internet

mail extensions part one: Format of internet message

bodies. RFC 2045 - Network Working Group.

Freed, N. and Borenstein, N. (1999b). Multipurpose inter-

net mail extensions part two: Media types. RFC 2046

- Network Working Group.

Gil, J. A., C

ardenas, L. G., Sahuquillo, J., and Pont, A.

(2005). Modeling penalty times in proxy-web cache

systems. Technical report, Deparment of Computer

Engineering (DISCA) UPV.

IRCache (2005). Proxy-web traces. http://www.ircache.net.

Jin, S. and Bestavros, A. (2000). Popularity-aware

greedydual-size web proxy caching algorithms. In

Proceedings of the 20th International Conference on

Distributed Computing Systems (ICDCS2000).

Rabinovich, M. (2002). Web caching and replication.

Addison-Wesley.

Squid, T. (2005). Squid web proxy cache.

http://www.squid-cache.org.

Wessels, D. (2001). Web caching. O’Reilly.

Wooster, R. P. and Abrams, M. (1997). Proxy caching that

estimates page load delays. In World Wide Web con-

ference.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

260
