Deep Convolution Neural Network for Extreme Multi-label Text

Classiﬁcation

Francesco Gargiulo, Stefano Silvestri and Mario Ciampi

Institute for High Performance Computing and Networking, ICAR-CNR, Via Pietro Castellino 111 - 80131, Naples, Italy

Keywords:

Extreme Multi-label Text Classiﬁcation, Deep Learning, Deep Convolutional Neural Networks, Word

Embeddings.

Abstract:

In this paper we present an analysis on the usage of Deep Neural Networks for extreme multi-label and multi-

class text classiﬁcation. We will consider two network models: the ﬁrst one is formed by a word embeddings

(WEs) stage followed by two dense layers, hereinafter Dense, and a second model with a convolution stage

between the WEs and the dense layers, hereinafter CNN-Dense. We will take into account classiﬁcation

problems characterized by different number of labels, ranging from an order of 10 to an order of 30, 000,

showing the different performances of the neural networks varying the total label number and the average

number of labels for sample, exploiting the hierarchical structure of the label space of the dataset used for

experimental assessment. It is worth noting that multi-label classiﬁcation is an harder problem if compared to

multi-class, due to the variable number of labels associated to each sample. We will even investigate on the

behaviour of the neural networks as function of the training hyperparameters, analysing the link between them

and the dataset complexity. All the result will be evaluated using the PubMed scientiﬁc articles collection as

test case.

1 INTRODUCTION

The automatic classiﬁcation of the semantic content

of a media (image, text, video) has a paramount im-

portance in many tasks and in different application

domains. Usually, the classiﬁcation result is one or

more labels applied to each media. Many techniques

have been already proposed in literature, ranging from

ontology-based methods (Amato et al., 2014) to ma-

chine learning systems (Su et al., 2015), or using hy-

brid approaches (Alicante et al., 2016a) integrating

ontological knowledge and machine learning. The

availability of high computational power, in conjunc-

tion with the recent advances in the ﬁeld of the Deep

Learning (DL), have led the scientiﬁc community to

develop Deep Neural Network (DNN) models able

to outperform the previous state of the art systems.

Among all different media that need to be automat-

ically classiﬁed, textual documents have gained a

growing importance, due to the application of this

problem in various crucial tasks, like Information Re-

trieval, Question Answering or Natural Language Un-

derstanding. In this paper we consider the problem of

DL textual documents classiﬁcation.

In literature Natural Language text classiﬁcation

problem has been split in four different classes. The

ﬁrst one is the binary classiﬁcation, i.e. sentiment

analysis, usually applied both to short (i.e. tweets)

and long texts (reviews, news, etc.). In this case, only

one label belonging to positive or negative class must

be assigned to each sample. A more complex problem

is the multi-class classiﬁcation, where the single clas-

siﬁcation label belongs to a set with more than two

elements. When the labels belong to a multi-class

domain, but differently from the previous case each

document could be tagged with a variable number of

labels, ranging from one to total classes number, this

is a multi-label classiﬁcation problem. Finally, when

the latter scenario involves a very huge label set, it

can be identiﬁed as an additional class, namely the

extreme multi-label text classiﬁcation (XMTC) (Liu

et al., 2017). In details, XMTC refers to the auto-

matic assignment of the most relevant subset of labels

to a text document, but differently from classic multi-

label and multi-class classiﬁcation problems, where

the number of the labels is usually in the order of

ten, the peculiar aspect of XMTC is that the labels be-

long to extremely large set, in the order of thousands

or even more. This huge label space raises research

challenges, such as data sparsity and scalability. With

Gargiulo F., Silvestri S. and Ciampi M.

Deep Convolution Neural Network for Extreme Multi-label Text Classiﬁcation.

DOI: 10.5220/0006730506410650

In Proceedings of the 11th International Joint Conference on Biomedical Engineering Systems and Technologies (HEALTHINF 2018), pages 641-650

ISBN: 978-989-758-281-3

the availability of Big Data, the XMTC problem has

gained a growing attention from the researchers from

Machine Learning and DL ﬁelds.

Signiﬁcant advances in multi-label classiﬁcation

methodologies have been made in recent years, thanks

to the development of speciﬁc machine learning

methods, such as tree induction with large-margin

partitions of the instance spaces and label-vector em-

bedding in the target space. However, Deep Learning

(DL) has not been widely explored yet for this kind of

problems. Despite the recent attention of the research

community for the identiﬁcation of NN topologies for

XMTC task, the effects of different hyperparameters

settings have not still deeply analysed, even if it could

bring an improvement to the performance of each net-

work (Sutskever et al., 2013).

In this paper we present an analysis of a Deep

Neural Network performances, considering an in-

creasing number of labels, starting from a classic

multi-label problem to an XMTC problem. We also

investigate on the effects of training hyperparame-

ters (learning rate, momentum, batch size) and their

link with the label space size. We consider as case

study the PubMed papers repository, a Big Data col-

lection of medical domain scientiﬁc papers. Each pa-

per is labelled with a variable number of MeSH (Med-

ical Subject Headings), namely labels from a con-

trolled vocabulary used for indexing articles, manu-

ally assigned by human experts. Total MeSH number

is about 30, 000 and all MeSHs lie in a hierarchical

tree structure. To obtain a variable label set we con-

sider each level of the hierarchical tree, obtaining in

this way ﬁve different multi-label problems, ranging

from 16 to 27, 775 classes, making possible to anal-

yse the behaviour of the DNN with a simple multi-

label classiﬁcation problem and with XMTC prob-

lem, in a Big Data text source. The main contribution

is the comparison of the effects in term of complex-

ity and accuracy of different Stochastic Gradient De-

scent (SGD) hyperparameters settings. The proposed

approach and the obtained results can be useful to de-

ﬁne a baseline for the development of a ﬁne tuned DL

XMTC system.

2 RELATED WORKS

The problem of multi-label and multi-class classiﬁ-

cation involves many different ﬁelds. In particular,

it is a challenging problem in computer vision and

Natural Language Understanding (NLU) areas. In the

ﬁrst case, DL methodologies have been successfully

applied in multi-label image classiﬁcation. For ex-

ample, in (Zhu et al., 2017) the authors proposed to

exploit semantic relations between various labels of

an image to improve multi-label image classiﬁcation

task. This improvement has been obtained using a

Spatial Regularization Network (SNR) that generates

attention maps for all labels and captures the under-

lying relations between them through learnable con-

volution. The regularized classiﬁcation results have

been applied to a ResNet-101 (He et al., 2016) net-

work, signiﬁcantly improving the baseline classiﬁca-

tion performances.

While DL multi-class and multi-label image clas-

siﬁcation produces state of the art performances, the

same problem applied to text classiﬁcation has many

still open issues. Methodologies derived from Nat-

ural Language Processing, like Latent Dirichlet Al-

location (Blei et al., 2003) have been used in text

classiﬁcation ( (Zhang et al., 2017b), (Pavlinek and

Podgorelec, 2017)) with good results in term of ac-

curacy. More recently, alongside classic methodolo-

gies, various DNN-based solutions have been pro-

posed. A simple but effective approach is presented

in (Wang et al., 2015), where the authors approached

the problem of multi-label text classiﬁcation applied

to keywords identiﬁcation of scientiﬁc papers. They

used a Word Embeddings (WEs) swallow neural net-

work as an external knowledge base for both key-

word extraction and generation, showing promising

results. A similar approach based on WEs is de-

scribed in (Qiang et al., 2017), where an effective

model that uses WEs and Markov Random Fields to

obtain topic modelling over short texts is proposed.

In (Nam et al., 2014) a simple NN approach for large-

scale multi-label text classiﬁcation tasks is proposed,

showing the effectiveness of cross entropy error func-

tion and demonstrating the usefulness of DL in this

setting. The authors proved that simple NN mod-

els equipped with advanced techniques such as Recti-

ﬁed Linear Units, dropout, and AdaGrad outperform

non NN approaches on six large-scale textual datasets

with different characteristics.

A solution to multi-label text classiﬁcation prob-

lem has been proposed even in (Hughes et al., 2017),

where it is described the use of a Deep CNN ap-

plied to sentences of clinical NL texts, in order to

sentence level classiﬁcation. In this task, the use of

the proposed DNN outperforms the WEs based meth-

ods. The authors of (Yogatama et al., 2017) char-

acterized the performance of discriminative and gen-

erative Long Short Term Memory (LSTM) models

for text classiﬁcation, showing that generative mod-

els substantially outperform discriminative models.

In (Yan et al., 2017) the authors proposed an inno-

vative Recurrent Neural Network (RNN), namely a

LSTM-based multi-label ranking model for document

classiﬁcation, consisting of two LSTMs used respec-

tively for adaptive data representation process and

uniﬁed learning-ranking process. The ﬁrst LSTM is

used to learn document representation by incorporat-

ing the document labels, while in the latter the order

of the documents labels is rearranged in accordance

with a semantic tree, in which the semantics are com-

patible with and appropriate to the sequential learn-

ing of LSTM. Connectionist Temporal Classiﬁcation

is performed in rankLSTM to address the error prop-

agation for a variable number of labels in each docu-

ment. The experiments with document classiﬁcation

conducted on three typical datasets reveal impressive

performance. The authors of (Schwenk et al., 2017)

explored the use of Very Deep Convolutional Neural

Networks (VDCNN) in multi-class text classiﬁcation,

proving the effectiveness of their proposed method-

ology with large scale training set. In (Wang and

Tian, 2016) is analysed the use of Residual Network

(ResNet) to improve the performance of LSTM RNN

in multi-label text classiﬁcation task, showing that di-

rect adaptation of ResNet performs well in sequence

classiﬁcation. When combined with the gating mech-

anism in LSTM, residual learning signiﬁcantly im-

prove LSTM performances. In (Nigam, 2017), DL

models have been applied to the multi-label classiﬁ-

cation task for assigning ICD-9 labels to textual med-

ical notes, ﬁnding that a Recurrent Neural Network

(RNN) and a RNN with Long Short-term Memory

(LSTM) units show an improvement over the Binary

Relevance Logistic Regression model.

It often happens that the classes lie in a hierarchi-

cal structure, such as a taxonomy. In (Baker and Ko-

rhonen, 2017) is applied a new method for hierarchi-

cal multi-label text classiﬁcation that initializes a neu-

ral network ﬁnal hidden layer such that it leverages la-

bel co-occurrence relations, such as hypernymy. The

model has been assessed on two hierarchical multi-

label text classiﬁcation tasks in the biomedical do-

main, using both sentence and document-level clas-

siﬁcation, showing promising results.

Another common NN topology used for text clas-

siﬁcation is the one formed by both CNN and RNN.

In (Chen et al., 2017) this model has been applied

to multi-label text categorization. The proposed ap-

proach, through an ensemble application of convolu-

tional and recurrent neural networks, is able to capture

both the global and the local textual semantics and

to model high-order label correlations, having at the

same time a tractable computational complexity. The

experimental assessment shows that this approach

achieves the state-of-the-art performance when the

CNN-RNN model is trained using a large size dataset.

In (Liu et al., 2017) extreme multi-label text clas-

siﬁcation (XMTC) with DL models is described. In

details, a family of new CNN models tailored for

multi-label classiﬁcation is presented. The proposed

model is tested with different datasets, producing very

good results in all cases. Large scale multi-label

text classiﬁcation is analysed even in (Berger, 2015),

where the problem of automatic PubMed articles la-

belling is approached. They explored how both a

CNN and a RNN with a Gated Recurrent Unit (GRU)

can independently be used with pre-trained WEs to

solve the XMTC problem. On a data set with more

than two million documents and 1, 000 potential la-

bels, the authors demonstrated that a GRU provides

substantial improvement over a Binary Relevance

model with a bag-of-words representation. Similarly,

in (Zhang et al., 2017a) a DL method applied to ex-

treme multi-label learning (XML) is presented. The

paper aims to better explore the label space by build-

ing and modelling an explicit label graph, proposing

a practical deep embedding method for XMTC. The

main contribution is the ideas of non-linear embed-

ding and modelling label space with graph priors at

the same time. Extensive experiments show that this

method performs competitively against state-of-the-

art systems. A comparison between different machine

learning models for XMTC is presented in (Baumel

et al., 2017), analysing the performances obtained in

this task applied to ICD-9 codes of Electronic Health

Records assignment. Support Vector Machines, Con-

tinuous Bag of Words, CNNs and GRUs have been

considered, demonstrating that the latter two models

provide the best results.

3 METHODOLOGY

Different DNNs have been proposed in literature for

multi-label text classiﬁcation. In all of them it is pos-

sible to identify the following three groups of layers,

hereinafter modules:

• Word Embeddings module;

• Feature Extraction module;

• Classiﬁcation module.

In this paper we consider this simple but effective

paradigm applied to two network topologies: Dense

and CNN-Dense, respectively depicted in the left-side

and in the right-side of the Figure 1.

The Dense network is composed by a WEs mod-

ule, which represents the input text, followed by a

classiﬁcation module composed by two fully con-

nected dense layers, which classify the output. The

CNN-Dense network has an additional Feature Ex-

traction module composed by a 1D Convolutional

Figure 1: Graphical representation of the DNN models

used. The yellow blocks represent the word embeddings

module, the green blocks are the feature extraction layers

and the blue blocks represent the classiﬁcation layers.

layer followed by a max pooling layer which acts as

feature extractor, sited between the WEs and classiﬁ-

cation modules.

In the following of this section we will describe

the details of these networks and the methodology

used to analyse their performances with increasing la-

bels number. We also brieﬂy explain the details of

different Stochastic Gradient Descent (SGD) training

hyperparameters considered in our analysis.

3.1 Word Embeddings Module

In this scenario the Word Embeddings is mapped con-

ceptually into one layer and so we will refer to him

as layer or module indifferently. The Word Embed-

dings (Mikolov et al., 2013) layer is a shallow neu-

ral network that maps the input text into a vector

space. Previous experiments (see (Gargiulo et al.,

2017b), (Gargiulo et al., 2017a), (Alicante et al.,

2016b)) have shown the effectiveness of a Natural

Language Processing (NLP) applied to input text be-

fore the training phase.

In order to obtain optimal performances, this layer

has been pre-trained, applying on input text the fol-

lowing NLP: tokenization, punctuation and symbols

removing, stop-words ﬁltering, lemmatization. We

used in WEs training the skip-gram algorithm with

hierarchical softmax, due to the better performances

observed with the dataset used in the experimental as-

sessment, if compared with continuous bag of words

and negative sampling.

The output of this layer is a dictionary of word

vectors, containing a vector for each word from the

training set. The word vectors will be represent the

whole text formed by the words in title and abstract

of each PubMed document.

3.2 Feature Extraction Module

The Feature Extraction Module is used only in the

CNN-Dense network. It consists of two cascading

layers, a 1D Convolution Neural Network (1D-CNN)

followed by a Max Pooling (MP). The 1D-CNN layer

takes as input the WEs vectors corresponding to each

word of title abstract of all papers from PubMed

dataset. The layer is formed by 100 ﬁlters with kernel

size equals to 5 striding of one position at time; the

activation function is a Rectiﬁed Linear Unit (ReLU).

The convolution input needs a ﬁxed input size,

but the total word of each sample is not constant.

To overcome this problem, the maximum number of

words has been chosen equals to 500, considering the

average word number of dataset equals to 127 after

the NLP preprocessing (see Section 4.1). In case of

shorter word number, a zero padding is applied, while

in case of samples with more than 500 words, we dis-

card the last words of the text.

The 1D-CNN is followed by a MP layer of size

2. The result of this module is the automatic extrac-

tion of the features, which will be used into the next

classiﬁcation layer.

3.3 Classiﬁcation Module

The classiﬁcation module is composed by two dense

fully connected layers: the ﬁrst one has 64 and 512

outputs respectively for Dense and CNN-Dense net-

work topologies, while the second and ﬁnal layer of

the whole DNN has an output number equals to the

number of classes L to be predicted and so it varies

depending on the different label number considered

(see section 4.1).

3.3.1 Loss Function

Following (Nam et al., 2014) results, the chosen loss

function is the sigmoid cross entropy 1:

loss(x, y) = −

∑

l∈L



· log

1 + exp(−x

)





(1 − y

) · log

exp(−x

)

1 + exp(−x

)



(1)

where y

and x

are respectively the prediction and the

target for each label l ∈ L. The sigmoid cross entropy

loss function optimizes a multi-label one-versus-all

loss based on max-entropy and then is well suited for

multi-label problems.

3.3.2 SGD Hyperparameters

A key aspect in DNN training is the optimal hyper-

parameters setting, but despite its crucial importance,

this is a very difﬁcult task (Ilievski et al., 2017). Some

hyperparameters are directly related to the the net-

work structure and topology, i.e. the number of hid-

den layers, the number of hidden units and the choice

of activation function. Other hyperparameters inﬂu-

ence the training phase, because they are involved in

Stochastic Gradient Descent (SDG) function, during

the update of the parameters of the network.

The SGD algorithm updates the parameters θ of

the objective J(θ) following the equation 2:

θ = θ − l

∇

J(θ, x

, y

) (2)

where x

, y

is a sample/label pair from the training set

and l

is the learning rate. Each parameter update in

SGD is usually computed with a minibatch and not a

single example. The previous equation 2 shows that

the l

and the batch size will directly inﬂuence the re-

sults of the DNN training, being the SGD a function

of both them. In addition to that, due to the SGD iter-

ative nature, another important hyperparameter is the

number of iterations.

SGD can not solve easily ravines, namely the areas

where the function surface curves much more steeply

in one dimension than in another (Sutton, 1986). This

happens around local optima and causes oscillations

of the SGD and its very slow convergence. Momen-

tum (Polyak, 1964) is a method to accelerate the func-

tion along the shallow ravine. The momentum update

is given by the following equation 3:

=µv

t−1

+ l

∇

J(θ, x

, y

)

θ =θ −v

(3)

where v

is the velocity at iteration t and µ is the

momentum coefﬁcient. The effects of the modiﬁca-

tion of SGD equation with momentum can be ex-

plained in analogy with a ball pushed down a hill.

The ball accumulates momentum, becoming faster

and able to reach the top of the next hill that it founds

on its way. The same thing happens with parame-

ters update: the momentum term increases updates

for dimensions whose gradient points in the same di-

rections and reduces updates for dimensions whose

gradient changes directions. In this way, the SGD can

gain faster convergence and reduce its oscillations.

A further improvement to momentum SGD has

been contributed by Nesterov with accelerated gradi-

ent (Nesterov, 1983), which is equal to:

=µv

t−1

+ l

∇

J(θ − µv

t−1

, x

, y

)

θ =θ − v

(4)

The term θ− µv

t−1

in equation4 approximates the

next parameters update (only the gradient calculation

is missing, but in case of small differences this ap-

proximation is good). Thus, the gradient is calculated

not to current parameters θ like in previous equa-

tion 3, but to an approximation of future position.

The effects of this modiﬁcation result in an increased

responsiveness, because the velocity is corrected in

order to take into account the next position. In this

way, momentum increases or decreases adjusting it-

self to the future variations, helping the convergence

of SGD.

The proposed methodology aims to analyse the ef-

fects of above described SGD hyperparameters (learn-

ing rate l

, batch size, momentum µ and use of Nes-

terov method), examining their link with label set size

in an XTMC problem trained with a Big Data source,

as shown in next section 4.

4 EXPERIMENTAL

ASSESSMENT

In this section we ﬁrst describe the details and the fea-

tures of the datasets used in the experimental assess-

ment. Then, we report the parameters used in Word

Embeddings layer to obtain pre-trained WEs and the

evaluation metrics considered. Finally, we present

the obtained results, considering an increasing labels

number and showing the effects of different learning

rate and momentum values on the performance of the

DNNs.

4.1 Dataset Description

The experimental assessments has been performed

using the PubMed papers collection

. PubMed is a

free search engine maintained by US National Library

of Medicine and specialized for medical and biolog-

ical scientiﬁc articles. The Big Data architecture de-

scribed in (Gargiulo et al., 2017a) has been used to

extract from PubMed repository a dataset formed by

a total number of 11, 150, 090 papers. Only the titles

and the abstracts of each article have been consid-

ered, in addition to the corresponding labels, named

MeSH (Medical Subject Heading). Each document

from the dataset is labelled with a variable number

of classes, which belong to a large set of 27, 755

different MeSHs, organized in a hierarchical struc-

ture

. The same MeSH can be located in one or

https://www.ncbi.nlm.nih.gov/pubmed/

The MeSH hierarchical structure can be browsed at

https://meshb.nlm.nih.gov/treeView

more branches of the tree. All these features iden-

tify a multi-class multi-label problem, as described in

section 1. Starting from this dataset, we created ﬁve

different training sets with an increasing number of

classes. The next table 1 summarizes the text features

of the original dataset.

Table 1: Overall Statistics of PubMed Papers Collection:

N is the total document number, E(Words) is the average

number of words per document in the considered dataset,

after the NLP.

Dataset N E(Words)

PubMed 11, 150, 090 127

In order to obtain different label sets, we process

the labels of each document, exploiting the MeSH hi-

erarchical structure and creating ﬁve different sets,

with respectively 16, 116, 676, 6, 339, and 27, 755

classes. The ﬁrst one is formed by the 16 MeSH

classes corresponding to the root level of the MeSH

hierarchical structure, which indexes the main cate-

gories. In this case, we substituted all labels with

their corresponding root class label, obtaining the ﬁrst

training set. In the same way, we then considered the

MeSHs respectively from the ﬁrst, the second and the

third level after the root of the tree structure, and like

the ﬁrst case, we substituted each label of the origi-

nal dataset with its corresponding parent of ﬁrst, sec-

ond and third level label, obtaining respectively 116,

676 and 6, 339 labels. At least, we considered the

original dataset with MeSHs from all levels, formed

by 27, 755 classes. As we can see, the ﬁrst dataset

belongs to a multi-label problem, the second dataset

is a simpliﬁed version of an XMTC problem, while

the last three datasets can be properly considered as

XMTC problems.

The text from the original dataset has been pre-

processed using NLP techniques brieﬂy described in

previous section 3 (see (Gargiulo et al., 2017b) for

further details), lower-casing, lemmatizing, removing

punctuation and stop words. The preprocessed text

has been used to train the WEs layers, using the pa-

rameters described in next subsection 4.2.

The obtained datasets have been split in training

sets and test sets, randomly selecting the 99% of the

samples for the training set and the remaining 1% for

the test set; the latter has been further divided in ten

smaller test sets, each one formed by approximately

2, 500 samples. The following table 2 summarizes the

main features of the obtained datasets in terms of class

numbers, document numbers, average number of la-

bels per document, average number of documents per

label.

The multi-label PubMed article classiﬁcation

Table 2: Dataset statistics as function of deeper level of

MeSH hierarchy selected. In the table L is the total class

number, L

∗

is the average number of labels per document

and L

is the average number of documents per label.

MeSHDepth L L

∗

0 16 5.88 4, 100, 528.63

1 116 8.57 824, 077.34

2 676 10.17 167, 800.57

3 6, 339 11.12 19, 557.78

All 27, 755 12.91 5, 188.15

problem is one of the tasks of BioAsq

, a research

challenge on biomedical semantic indexing and ques-

tion answering. The experimental results obtained in

this paper can add further details to latest BioAsq re-

sults (Nentidis et al., 2017), helping the research com-

munity to solve this hard XMTC problem.

4.2 Word Embeddings Parameters

The Word Embeddings (WEs) layer is a shallow neu-

ral network able to produce a vector representation

of the words of the training set. The obtained vec-

tor space is used for all experiments with different

datasets, because only label number changes between

various training sets, while the text from title and ab-

stract of the papers remains the same. Thus, the WEs

layers is the same in all tested DNNs.

In our experimental assessment, the WEs has

been pre-trained using Gensim framework (

Reh

rek

and Sojka, 2010), an effective Python implementa-

tion for WEs training. We used skip-gram algorithm

with hierarchical softmax (Mikolov et al., 2013),

setting a vector size equals to 512, a window size

equals to 5, discarding the words that appears only

one time in the training set and setting a threshold

for higher-frequency words to be randomly down-

sampled equals to 0.0001.

4.3 Evaluation Metrics

To evaluate the performance of the models we use the

commonly used F-measure metric, which is equal to

the harmonic mean of recall (ρ) and precision (π). ρ

and π (

Ozg

ur et al., 2005) are deﬁned as follows:

T P

+ FP

, ρ

T P

+ FN

(5)

where T P

(True Positive) is the number of doc-

uments assigned correctly to class i; FP

(False Pos-

itive) is the number of documents that do no belong

http://bioasq.org/

to class i but are assigned to class i incorrectly by the

classiﬁer; and FN

(False Negative) is the number of

documents that are not assigned to class i by the clas-

siﬁer but which actually belong to class i.

In this paper we consider the micro-averaging: in

this case the F-measure is computed globally over all

category decisions and ρ and π are obtained by sum-

ming over all individual decisions:

micro

T P

T P + FP

∑

i=1

T P

∑

i=1

(T P

+ FP

)

(6)

micro

T P

T P + FN

∑

i=1

T P

∑

i=1

(T P

+ FN

)

(7)

micro

2πρ

π + ρ

(8)

The F

micro

values are in the interval (0;1) and

larger values correspond to better performances; in

literature these values are usually expressed as a per-

centage, as we did in the following.

4.4 Experimental Results and

Discussion

We evaluated the performances of the DNNs de-

scribed in section 3, considering an increasing label

number and analysing the effects of different SGD hy-

perparameters settings in terms of π

micro

, ρ

micro

and

micro

measures.

To give an idea of the models complexity, the

next table 3 reports the number of parameters of the

networks in function of the MeSH Depth and conse-

quently of the number of classes involved.

Table 3: Model parameters as function of MeshDepth and

consequently of the labels number (L).

MeSHDepth L

#Parameters

Dense CNN-Dense

0 16 16, 385, 104 13, 263, 620

1 116 16, 391, 604 13, 314, 920

2 676 16, 428, 04 13, 602, 200

3 6, 339 16, 796, 099 16, 597, 319

All 27, 755 18, 188, 139 27, 493, 727

As described above, the label set size is increased

exploiting the MeSH hierarchical structure. The cor-

responding DNNs parameters are inﬂuenced only in

the last dense layer, which is directly related to the

classes number. For this reason, only the last two

XMTC problems, corresponding to MeSH depth 3

and all, show a signiﬁcantly larger parameters num-

ber, if compared with the ﬁrst three cases. This effect

is more evident on the CNN-Dense models because

the ﬁrst dense layer has 512 units respect of the 64 of

the Dense topology. The different number of the cho-

sen hidden units (ﬁrst dense layer) between the two

topologies depends on the number of elements in in-

put to the ﬁrst dense layer that, for the CNN-Dense

scenario, is considerably reduced by the Feature Ex-

traction Module (CNN-MaxPooling).

We used the Nesterov correction (see sec-

tion 3.3.2) in all cases, because our experiments con-

ﬁrmed that it produces a slight enhancements of about

1% in all values. Then, a ﬁrst result is that in XMTC

problem trained with Big Data the Nesterov momen-

tum provides a little performances boost.

The details of the results of the experiments

are summarized in Table 4 and Table 5, where

the performances are reported in terms π

micro

and F

micro

(see Section 4.3), for different

StepsPerE poch, Learning Rate l

and Momentum val-

ues. The StepsPerE poch value is directly related to

MiniBatchSize, being the latter one equals to the total

samples number divided by the Steps Per Epoch.

MiniBatchSize =

#TotalSamples

StepsPerE poch

(9)

The obtained results show that the best network

topology between the two analysed is the CNN-

Dense, demonstrating the need of the feature ex-

traction module. It is worth noting that in all con-

sidered cases the best results are obtained using a

StepsPerE poch value equals to 10, 000, conﬁrming

the usefulness of a smaller MiniBatch size with a Big

Data training set.

It is interesting to analyse the hyperparameters

values selected to achieve the best performances given

the Depth Level, considering at the same time the

dataset characteristics (see Table 2). When the prob-

lem is a simple multi-label for the 0 − Level with 16

classes, the best results are obtained using a slower

learning rate equals to 0.01 and a momentum equal

to 0, which do not increases the convergence speed

of the SGD. On the other hand, increasing the num-

ber of labels involved considering an higher Depth-

Level corresponding to real XMTC problem, the re-

sults show a different behaviour of the performance

in function of the hyperparameters. In fact, in the

latter cases, the learning rate speed that achieves the

best performances is equal to 0.1. In addition to that,

the use of smaller batch size in conjunction with an

higher momentum value equals to 0.5, considerably

increases XMLT performances.

The overall results show that there is a signiﬁ-

cant performances boost (resulting in some cases in

a F

micro

improvement of more than 10%) with the use

Table 4: F

micro

, π

micro

and ρ

micro

obtained using Dense network topology. The values are evaluated considering the datasets

depicted in the Table 2 from which a training set and ten different test sets was extracted, the results are obtained as an average

of the ones obtained on the ten test sets. The table shows the performance behaviour considering 100 epochs, two values of

StepsPerE poch, two learning rate (l

) values and, for each of them, two momentum (µ) values. The best values per row are

highlighted in bold.

StepsPerE poch = 1, 000

Depth

= 0.01 l

= 0.1

µ = 0 µ = 0.5 µ = 0 µ = 0.5

micro

0 82.97% 82.59% 83.35% 82.92% 82.15% 83.70% 81.66% 81.65% 81.67% 79.52% 77.98% 81.13%

1 56.48% 74.70% 45.40% 59.82% 74.04% 50.18% 63.77% 72.69% 56.80% 63.47% 70.98% 57.40%

2 33.71% 73.64% 21.86% 36.74% 73.35% 24.51% 44.94% 70.40% 33.00% 48.05% 69.68% 36.67%

3 13.86% 84.19% 7.55% 13.86% 84.19% 7.55% 27.29% 72.41% 16.81% 28.96% 70.79% 18.20%

All 9.21% 63.80% 4.96% 9.21% 63.80% 4.96% 9.21% 63.80% 4.96% 9.21% 63.80% 4.96%

StepsPerE poch = 10, 000

Depth

= 0.01 l

= 0.1

µ = 0 µ = 0.5 µ = 0 µ = 0.5

micro

0 83.78% 84.79% 82.81% 83.51% 84.61% 82.44% 81.16% 82.30% 80.06% 78.07% 77.02% 79.15%

1 65.40% 76.58% 57.06% 66.46% 76.09% 59.00% 66.00% 74.68% 59.13% 64.35% 72.53% 57.83%

2 44.12% 74.53% 31.33% 47.28% 74.16% 34.70% 52.52% 73.82% 40.76% 53.62% 73.64% 42.15%

3 25.14% 75.52% 15.08% 26.43% 76.38% 15.98% 31.28% 77.88% 19.57% 34.81% 77.02% 22.49%

All 9.21% 63.80% 4.96% 9.21% 63.80% 4.96% 18.57% 72.95% 10.64% 20.15 73.54% 11.68%

Table 5: F

micro

, π

micro

and ρ

micro

obtained using CNN-Dense network topology. The values are evaluated considering the

datasets depicted in the Table 2 from which a training set and ten different test sets was extracted, the results are obtained as

an average of the ones obtained on the ten test sets. The table shows the performance behaviour considering 100 epochs, two

values of StepsPerE poch, two learning rate (l

) values and, for each of them, two momentum (µ) values. The best values per

row are highlighted in bold.

StepsPerE poch = 1, 000

Depth

= 0.01 l

= 0.1

µ = 0 µ = 0.5 µ = 0 µ = 0.5

micro

0 83.16% 83.55% 82.78% 83.28% 83.52% 83.03% 82.36% 82.15% 82.58% 81.33% 81.18% 81.47%

1 62.57% 73.05% 54.17% 64.49% 73.48% 57.46% 65.66% 73.43% 59.38% 64.98% 73.88% 58.00%

2 36.84% 66.81% 25.83% 40.87% 69.25% 28.99% 51.58% 69.04% 41.16% 52.89% 69.14% 42.83%

3 13.86% 84.19% 7.55% 13.86% 84.19% 7.55% 14.12% 84.26% 7.71% 28.94% 69.27% 18.29%

All 9.21% 63.80% 4.96% 9.21% 63.80% 4.96% 9.21% 63.80% 4.96% 0.01% 100.00% 0.00%

StepsPerE poch = 10, 000

Depth

= 0.01 l

= 0.1

µ = 0 µ = 0.5 µ = 0 µ = 0.5

micro

0 84.33% 85.37% 83.30% 84.17% 85.20% 83.33% 82.30% 83.07% 81.55% 80.79% 81.51% 80.09%

1 68.56% 77.19% 61.67% 69.02% 77.33% 62.32% 68.85% 76.62% 62.51% 67.56% 75.39% 61.21%

2 52.37% 74.57% 40.35% 54.67% 75.01% 43.01% 57.06% 76.36% 45.55% 57.01% 76.20% 45.54%

3 24.62% 74.31% 14.75% 27.81% 74.68% 17.09% 39.93% 75.67% 27.12% 45.87% 74.78% 33.08%

All 9.21% 63.80% 4.96% 9.21% 63.80% 4.96% 20.45% 69.00% 12.01% 22.20% 72.11% 13.12%

of a feature extraction module, the setting of a smaller

MiniBatch size, the selection of a faster learning rate

and an higher momentum value of SGD.

5 CONCLUSION AND FUTURE

WORK

In this paper we presented an analysis on the usage

of two typologies of DNN, Dense and CNN-Dense

for extreme multi-label and multi-class text classiﬁ-

cation (XMTC). We considered multi-label classiﬁ-

cation problems characterized by different number of

labels, ranging from an order of about 10 to an or-

der of about 30, 000. The considered task is harder

than a normal multi-class text classiﬁcation due to

variable label number (multi-label) associated to each

sample. We analysed the performances and the be-

haviours of the networks considering the effects of the

training hyperparameters of the SGD function, with

an increasing classes number and average number of

labels per sample, using a Big Data training source

extracted from PubMed repository. We performed a

preliminary empirical evaluation of the link between

the SGD hyperparameters and the dataset complex-

ity, providing an overview of the performances and

the optimal settings of learning rate, momentum and

batch size for the considered problem.

As future works we are planning to investigate the

impact of the hyperparameters on other DNN topolo-

gies, and we are considering to build a completely

new topology customized for the hierarchical XMTC

problems.

In addition, we will investigate on the use of hi-

erarchical label structure, exploiting the better perfor-

mances of higher label levels to correct the results ob-

tained with deeper cases.

REFERENCES

Alicante, A., Benerecetti, M., Corazza, A., and Silvestri,

S. (2016a). A distributed architecture to integrate on-

tological knowledge into information extraction. In-

ternational Journal of Grid and Utility Computing,

7(4):245–256.

Alicante, A., Corazza, A., Isgr

o, F., and Silvestri, S.

(2016b). Semantic Cluster Labeling for Medical Re-

lations, pages 183–193. Springer.

Amato, A., Di Martino, B., Scialdone, M., and Venticinque,

S. (2014). Personalized Recommendation of Seman-

tically Annotated Media Contents, pages 261–270.

Springer International Publishing, Prague, Czech Re-

public.

Baker, S. and Korhonen, A. (2017). Initializing neural net-

works for hierarchical multi-label text classiﬁcation.

In BioNLP 2017, pages 307–315, Vancouver, Canada.

ACL.

Baumel, T., Nassour-Kassis, J., Elhadad, M., and Elhadad,

N. (2017). Multi-label classiﬁcation of patient notes

a case study on icd code assignment. arXiv preprint

arXiv:1709.09587.

Berger, M. J. (2015). Large scale multi-label text classiﬁ-

cation with semantic word vectors. Technical report,

Stanford University.

Blei, D. M., Ng, A. Y., and Jordan, M. I. (2003). Latent

dirichlet allocation. Journal of machine Learning re-

search, 3(Jan):993–1022.

Chen, G., Ye, D., Xing, Z., Chen, J., and Cambria, E.

(2017). Ensemble application of convolutional and

recurrent neural networks for multi-label text cate-

gorization. In 2017 International Joint Conference

on Neural Networks, IJCNN 2017, pages 2377–2383,

Anchorage, AK, USA. IEEE.

Gargiulo, F., Silvestri, S., and Ciampi, M. (2017a). A big

data architecture for knowledge discovery in pubmed

articles. In 2017 IEEE Symposium on Computers and

Communications, ISCC 2017, pages 82–87, Herak-

lion, Greece. IEEE.

Gargiulo, F., Silvestri, S., Fontanella, M., Ciampi, M., and

De Pietro, G. (2017b). A deep learning approach for

scientiﬁc paper semantic ranking. In International

Conference on Intelligent Interactive Multimedia Sys-

tems and Services, pages 471–481, Vilamoura, Portu-

gal. Springer.

He, K., Zhang, X., Ren, S., and Sun, J. (2016). Deep resid-

ual learning for image recognition. In 2016 IEEE Con-

ference on Computer Vision and Pattern Recognition

(CVPR), pages 770–778.

Hughes, M., Li, I., Kotoulas, S., and Suzumura, T. (2017).

Medical text classiﬁcation using convolutional neural

networks. CoRR, 235:246–250.

Ilievski, I., Akhtar, T., Feng, J., and Shoemaker, C. A.

(2017). Efﬁcient hyperparameter optimization for

deep learning algorithms using deterministic rbf sur-

rogates. In Proceedings of the Thirty-First AAAI Con-

ference on Artiﬁcial Intelligence (AAAI-17), pages

822–829, San Francisco, California, USA. AAAI.

Liu, J., Chang, W., Wu, Y., and Yang, Y. (2017). Deep learn-

ing for extreme multi-label text classiﬁcation. In Pro-

ceedings of the 40th International ACM SIGIR Con-

ference on Research and Development in Information

Retrieval, pages 115–124, Shinjuku, Tokyo, Japan.

ACM.

Mikolov, T., Chen, K., Corrado, G., and Dean, J. (2013).

Efﬁcient estimation of word representations in vector

space. CoRR, abs/1301.3781.

Nam, J., Kim, J., Loza Menc

ıa, E., Gurevych, I., and

urnkranz, J. (2014). Large-scale multi-label text

classiﬁcation - revisiting neural networks. In Machine

Learning and Knowledge Discovery in Databases -

European Conference, ECML PKDD 2014, pages

437–452, Nancy, France. Springer.

Nentidis, A., Bougiatiotis, K., Krithara, A., Paliouras, G.,

and Kakadiaris, I. (2017). Results of the ﬁfth edition

of the bioasq challenge. In Proceedings of the BioNLP

2017 workshop, pages 48–57, Vancouver, Canada.

ACL.

Nesterov, Y. (1983). A method for unconstrained convex

minimization problem with the rate of convergence

o(1/kˆ 2). In Doklady AN USSR, volume 269, pages

543–547.

Nigam, P. (2017). Applying deep learning to icd-9 multi-

label classiﬁcation from medical records. Technical

report, Stanford University.

Ozg

ur, A.,

Ozg

ur, L., and G

ung

or, T. (2005). Text catego-

rization with class-based and corpus-based keyword

selection. Computer and Information Sciences-ISCIS

2005, pages 606–615.

Pavlinek, M. and Podgorelec, V. (2017). Text classiﬁca-

tion method based on self-training and lda topic mod-

els. Expert Systems with Applications, 80(Supplement

C):83 – 93.

Polyak, B. T. (1964). Some methods of speeding up the con-

vergence of iteration methods. USSR Computational

Mathematics and Mathematical Physics, 4(5):1–17.

Qiang, J., Chen, P., Wang, T., and Wu, X. (2017). Topic

modeling over short texts by incorporating word em-

beddings. In Advances in Knowledge Discovery and

Data Mining - 21st Paciﬁc-Asia Conference, PAKDD

2017, pages 363–374, Jeju, South Korea. Springer.

Reh

rek, R. and Sojka, P. (2010). Software Framework for

Topic Modelling with Large Corpora. In Proceedings

of the LREC 2010 Workshop on New Challenges for

NLP Frameworks, pages 45–50. ELRA.

Schwenk, H., Barrault, L., Conneau, A., and LeCun, Y.

(2017). Very deep convolutional networks for text

classiﬁcation. In Proceedings of the 15th Conference

of the European Chapter of the Association for Com-

putational Linguistics, EACL 2017, volume 1, pages

1107–1116, Valencia, Spain. ACL.

Su, F., Rong, C., Huang, Q., Qiu, J., Shao, X., Yue, Z., and

Xie, Q. (2015). Attribute extracting from wikipedia

pages in domain automatically. In Information Tech-

nology and Intelligent Transportation Systems - Vol-

ume 2, Proceedings of the 2015 International Con-

ference on Information Technology and Intelligent

Transportation Systems, ITITS 2015, pages 433–440,

Xi’an, China. Springer.

Sutskever, I., Martens, J., Dahl, G. E., and Hinton, G. E.

(2013). On the importance of initialization and mo-

mentum in deep learning. In Proceedings of the

30th International Conference on Machine Learning,

ICML 2013, volume 28, pages 1139–1147, Atlanta,

Georgia, USA. JMLR.

Sutton, R. S. (1986). Two problems with backpropaga-

tion and other steepest-descent learning procedures

for networks. In Proceedings of 8th annual conference

of cognitive science society, pages 823–831. Erlbaum.

Wang, R., Liu, W., and McDonald, C. (2015). Using word

embeddings to enhance keyword identiﬁcation for sci-

entiﬁc publications. In Databases Theory and Ap-

plications - 26th Australasian Database Conference,

ADC 2015, pages 257–268, Melbourne, VIC, Aus-

tralia. Springer.

Wang, Y. and Tian, F. (2016). Recurrent residual learn-

ing for sequence classiﬁcation. In Proceedings of the

2016 Conference on Empirical Methods in Natural

Language Processing, EMNLP 2016, pages 938–943,

Austin, Texas, USA. ACL.

Yan, Y., Wang, Y., Gao, W.-C., Zhang, B.-W., Yang, C.,

and Yin, X.-C. (2017). Lstm2: Multi-label ranking for

document classiﬁcation. Neural Processing Letters.

Yogatama, D., Dyer, C., Ling, W., and Blunsom, P. (2017).

Generative and discriminative text classiﬁcation with

recurrent neural networks. CoRR, abs/1703.01898.

Zhang, W., Wang, L., Yan, J., Wang, X., and Zha, H.

(2017a). Deep extreme multi-label learning. CoRR,

abs/1704.03718.

Zhang, Y., Ma, J., Wang, Z., and Chen, B. (2017b). LF-

LDA: A topic model for multi-label classiﬁcation. In

Advances in Internetworking, Data & Web Technolo-

gies, The 5th International Conference on Emerging

Internetworking, Data & Web Technologies, EIDWT-

2017, pages 618–628, Wuhan, China. Springer.

Zhu, F., Li, H., Ouyang, W., Yu, N., and Wang, X. (2017).

Learning spatial regularization with image-level su-

pervisions for multi-label image classiﬁcation. In The

IEEE Conference on Computer Vision and Pattern

Recognition (CVPR). IEEE.
