Commonsense Reasoning in a Deeper Way: By Discovering Relations

between Predicates

Wenguan Huang and Xudong Luo

∗

Institute of Logic and Cognition, Department of Philosophy, Sun Yat-sen University,

Guangzhou, China

Keywords:

Knowledge Representation, Commonsense Reasoning, ConceptNet, Natural Language Processing.

Abstract:

One of the biggest drawbacks of nowadays AI reasoning systems is their lack of commonsense. To address

the issue, some commonsense knowledge bases and a bunch of reasoning mechanisms with them have been

developed to tackle this problem. However, most of them concentrate on the relation between entities (e.g.,

“cat” and “ﬁsh”), but few discuss the relation between predicates (e.g., “angry” and “shout”), which fall into

a deeper level of commonsense. To the end, in this paper, we develop a commonsense reasoning framework,

which focuses on this type of commonsense knowledge. More speciﬁcally, ﬁrst we give a formal deﬁnition of

this kind of commonsense. Then we construct a set of knowledge by extending the predicate set of ConceptNet,

and apply information extraction technique to capture them from corpus. Finally, to evaluate our framework,

we conduct experiments against a part of the Winograd Schema Challenge, which, its author claimed, is an

alternative of Turing Test. The result of our experiments conﬁrms the effectiveness of our framework.

1 INTRODUCTION

Humans have an extremely powerful capability of in-

ferring the meaning even it is expressed implicitly

in a sentence. For example, we can understand the

metaphor, sarcasm, or humor. Such a capability is

built upon the huge scale of commonsense knowl-

edge, which we human gather for ages. For example,

by saying that this smart phone is light but cannot put

into my pocket”, we can immediately know that this

phone is too big. However, for an intelligent system

that lacks of commonsense, it is a tough task to infer

“size is too big” from “cannot put into the pocket”.

With the importance of commonsense reasoning

in many AI tasks (from natural language understand-

ing to computer vision, planning and reasoning), a lot

of studies have been done to arm machines with com-

monsense knowledge bases, so that they can deal with

commonsense reasoning (Davis and Marcus, 2015).

For example, researchers have built up some com-

monsense knowledge bases such as Freebase (Bol-

lacker et al., 2008), YAGO (Rebele et al., 2016),

and ConceptNet (Speer and Havasi, 2013). Most of

them are structured like an entity-relation graph. That

is, they represent a commonsense fact as a relation

among two entities (e.g., HasProperty(phone, big)),

∗

The corresponding author.

and store it in a graph.

Most studies focus on the relation between enti-

ties, but few studies are concerned with the relation

of predicates. The former is important for forming the

whole semantic network, while the latter is signiﬁcant

for umasking the causality (or correlativity) between

predicates. For instance, in the above example, we

can make such an inference with the commonsense

knowledge of “if A cannot put into B, then it may be

the case that A is too large”. Note that it cannot be

represented in any of the above bases, since it does

not describe any relation between entities, but the re-

lation between two predicates “cannot put into” and

“too big”. To this end, in this paper we study how to

extract the relations between predicates.

The relation between predicates can have a lever-

age on commonsense reasoning, by discovering the

causality and relativity between them. We can trans-

fer from the former predicates to the latter predicate.

On the other hand, ﬁnding out these relations can also

generate more commonsense knowledge, by applying

it to the existing commonsense knowledge bases. In

this way, we can make the knowledge base more com-

plete.

To tackle the problem, in this paper, we ﬁrst intro-

duce a set of predicates P to expand the expressive-

ness beyond ConceptNet’s built-in predicates (Speer

Huang W. and Luo X.

Commonsense Reasoning in a Deeper Way: By Discovering Relations between Predicates.

DOI: 10.5220/0006120504070414

In Proceedings of the 9th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2017), pages 407-414

ISBN: 978-989-758-220-2

407

and Havasi, 2013). Then we present and discuss a ma-

nipulable deﬁnition of this kind of relation. Further,

we propose two measures to ﬁnd out these predicate-

relation commonsense knowledge, which we termed

as rule patterns, based on ConceptNet.

The rest of this paper is organised as follows. Sec-

tion 2 reviews the related work. Sections 3 to 5 detail

our framework. Section 6 evaluates our framework

against Winograd Schema Challenge (Levesque et al.,

2011). Finally, Section 7 concludes the paper with fu-

ture work.

2 RELATED WORK

The most common methodology to deal with com-

monsense is collecting a huge number of common-

sense facts to enable computer systems to have com-

monsense. A well-known commonsense knowledge

base, which we are based on, is ConceptNet (Speer

and Havasi, 2013). ConceptNet is a semantic net-

work containing millions commonsense knowledge

contributed by volunteers.

Other knowledge bases like YAGO (Rebele et al.,

2016) and Freebase (Bollacker et al., 2008) have sim-

ilar network-like structures, but ConceptNet exceeds

them because it focuses on commonsense facts yet

others just concern facts.

Several alternative approaches have been pro-

posed to tackle commonsense reasoning concerning

the relation between predicates. For example, Liu and

Singh (2004) proposed a number of graph-based algo-

rithms, which can turn reasoning problems into graph

problems. Morover, Speer et al. (2008) proposed a

novel reasoning method, called AnalogySpace, based

on matrix representation and SVD technique. The

key idea behind AnalogySpace is to imitate the anal-

ogy reasoning, which is a kind of induction inference.

This work diversiﬁes the inference method yet is lim-

ited as it mainly depends on the similarity between

predicates.

Recently, Angeli and Manning (2014) proposed

a natural logical inference system for inferring com-

monsense facts. By using natural logic, a reason-

ing problem can be embedded in a search framework,

which can then be converted into a search tree prob-

lem. However, with the limitation of natural logic, the

form of reasoning is bounded under just a few types

of relation such as inheritance and transitivity.

In the ﬁeld of reasoning on ontologies, Kazakov

et al. (2009) proposed two role axioms of inclusion

and transitivity to characterise relations between pred-

icates. Nonetheless, they still only concern with in-

heritance (inclusion) and transitivity. There are more

remain not mentioned, such as causality. Moreover,

more ﬂexible relation even between predicates and

concepts, e.g., the causality between “eat” and “hun-

gry”, are not considered.

On the other hand, relation extraction falls into the

ﬁeld of information extraction. Tandon et al. (2011)

proposed a web-scale relation extraction method to

extract commonsense knowledge based on seeds from

a knowledge base. It uses the idea of pattern match-

ing but makes progress upon it, which is similar to our

extraction method. There are still other studies in the

similar line such as (Soderland et al., 2010).

Another rule-mining approach proposed in

(Berger-Wolf et al., 2013) tries to extract rule-like

knowledge about relations in ConceptNet. For

instance, pAtLocation, PartOf , AtLocationq is a rule,

since triple ptextbook, classroom, schoolq can be an

instance of this rule, if the following is valid:

AtLocationptextbook, classroomq^

PartOf pclassroom, schoolq

ÑAtLocationptextbook, schoolq.

Our approach is inspired by this work (i.e., we termed

such a rule pattern as syllogism rule pattern), but in

our work, the elements of such triple are not only rela-

tions but also predicates extracted from ConceptNet,

which can make a dramatical improvement upon the

reasoning breadth. Also we discover a more general

deﬁnition of rule pattern and discuss more measures

to extract them.

3 DISCOVERING MORE

PREDICATES

In this section we present a method to discover more

predicates from ConceptNet, by which we can con-

struct more ﬂexible and meaningful commonsense

knowledge.

3.1 Predicates Expansion

ConceptNet represents assertions with pattern Ppa, bq,

where P stands for binary predicate modifying con-

cepts a and b. Although ConceptNet has around 20

predicates (or relations) (e.g., IsA, RelatedTo and

AtLocation), it is far from enough to do predicate rea-

soning, for example, from “Mike reads a book” to

“Mike learns something”, since it does not have read

and learn as predicates, so we need to put more pred-

icates into account.

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

408

3.1.1 Predicate Set Constructing

ConceptNet has a great deal of original concepts that

should be viewed as predicates, such as “eat”. The

idea for ﬁnding out such concepts is that a word or

phrase that can act as predicate normally has particu-

lar Part of Speech (PoS). For example, normally the

verbs can be regarded as predicates. Hence, we con-

struct a set of concepts, called predicate set P , to in-

clude all the concepts that has predicate-required PoS.

The following are the PoS of the words and

phrases that can be predicates:

PoSList:

VERB; VERB NOUN; ADV VERB; VERB PREP; VERB PREP

NOUN; VERB NOUN PREP NOUN; ADJ; ADV ADJ

The construction of predicate set P is straightfor-

ward. In ConceptNet, many concepts have detailed

informations expressed in URI. For example, concept

thank is represented as

{c{en{thank{v{express gratitude or ¨¨¨

where “v” after “thank” means that its PoS is verb.

Hence, we can iterate and check the concepts’ PoS

denoted in URI, and add it into P if its PoS is in the

PoS list. For those who do not show their PoS explic-

itly, we apply Stanford PoS tagger (Toutanova et al.,

2003) to the original sentence of that concept in Con-

ceptNet.

The previous syntactic rule of assertions can be

expressed as

a Ñ r c c (1)

where a, r and c represent assertion, relation and con-

cept, respectively. This rule means an assertion can

be represented as a sequence of a relation, a concept,

and another concept.

After constructing predicate set P , the syntactic

rules are as follows:

a Ñ r c c | r c p | r p c | r p p (2)

a Ñ p c

| p c a (3)

where p stands for concepts in P , and c

stands for

any number of c.

Rule (2) is a variant of Rule (1), but Rule (3) does

let our system become much more expressive. For

example we can express sentences including clause

like:

T hinkppeople, Desirepmonkey, eat bananaqq

3.1.2 Valuation

Here we present a method to valuate the truth of as-

sertions.

It is easy to deﬁne the valuation of assertions with

built-in predicates. The only thing that we need to do

is to look up whether the assertion is in ConceptNet

or not. If it is, return true; otherwise, return false. The

hard part is the assertions with predicates in P . For

example, the modiﬁer of assertion hel pppolice, kidq

does not act as a relation in ConceptNet. The truth

values of these assertions normally depend on con-

text. That is, hel pppolice, kidq is not always true nor

always false. However, for such predicates, we can

still judge whether the assertion is reasonable or not.

By saying reasonable, we mean the assertion may

make sense in most common contexts. For instance,

hel pppolice, kidq is much more reasonable than asser-

tion like helpppolice, penq or hel pptiger, kidq. This is

because it is common for people to think police ofﬁ-

cers should help a kid, while the latter is rather non-

sense. We claim that this kind of statements, though

cannot be determined to be true or false, also contain

implicit commonsense.

Putting these ideas together, we can formally give

the deﬁnition of valuation as follows:

Deﬁnition 1. A reasonable condition of predicate p,

denoted as vppq, is a set of pairs tpS, Oqu. In every

pair, S and O represent the subject equivalence set

and object equivalence sets, respectively.

Deﬁnition 2. An assertion φ is reasonable if and only

if, its subject, object pair ps

, o

q P vpp

q, where p

the predicate of φ.

For example, suppose vpholdq is tpdoctor,

needleq, psecretary, filequ. Then assertion “A sec-

retary holds a ﬁle” is reasonable, while “A secretary

holds a needle” is not.

3.2 Subject-object Set

The remained procedure is to construct subject-object

set vppq for every predicate p in P . The idea of con-

structing these sets is as follows: ﬁrstly ﬁnd an origi-

nal set of objects and subjects from corpus, then add

their synonyms, superior and siblings (e.g., “apple”

and “banana”) into the set. Thus, it is converted

into an information extraction problem: ﬁrst match

out the sentence from corpus containing the speciﬁc

predicate, then ﬁnd the subject and object by Ollie

(Schmitz et al., 2012).

To extend the set, we also need add their syn-

onyms, superiors and siblings. This can be done by

ConceptNet, since synonyms and superiors have cor-

responding relations Synonym and IsA, and siblings

correspond to those who owns the same superiors.

Note that we may get pairs containing pronoun, and

named entities, which are not desired, and so should

be excluded.

Commonsense Reasoning in a Deeper Way: By Discovering Relations between Predicates

409

We ﬁnd out that novels may contain lots of pro-

noun and person name, while newspapers contain lots

of named entities. So we decide to choose short

stories such as fables from Project Gutenberg (Hart,

1971) as corpus. Also, the example sentences of dic-

tionaries are good resource too.

4 RELATION OF PREDICATES

In this section, we will discuss the deﬁnition of rela-

tion between predicates.

The commonsense knowledge is normally in

a form of Ppa, bq, e.g., “IsA(Labrador, dog)”

and “HasA(dog, four legs)”. In order to imply

“HasA(Labrador, four legs)” from the above two

pieces of commonsense, an implicit causal relation

between IsA and HasA is required. That is, if a con-

cept A belongs to the other concept B, then A may also

has the properties that B has. In this piece of rule-like

knowledge, A and B are viewed as variables, which

can apply any concept to it. Note that the premise is

unnecessarily commonsense knowledge, it could be

other context depended statement, and this rule still

holds. We believe that this causality or correlativity

between predicates is also another kind of common-

sense knowledge. However, the form of this common-

sense remains unclear, so in this section we try to give

it a formal deﬁnition, terming it as rule patterns.

4.1 Rule Patterns

In (Berger-Wolf et al., 2013), a syllogism like rule pat-

tern is deﬁned as a triple of relations pρ

, ρ

, γq.

One of the shortages is that they only cover rela-

tions that are predeﬁned in ConceptNet. After care-

fully deﬁning the predicates in P , we can extend its

scope to P , and term such a rule pattern as a syllo-

gism rule pattern. It will extend the scope of applica-

tion considerably, but this may reduce the reliability

of the rule pattern. That is because in the pure relation

version, its premises are always true, while the pred-

icate version concerns only with “reasonable”, which

may lead to a more general but less true situation.

We deﬁne the syllogism rule pattern formally as

follows:

Deﬁnition 3. A syllogism rule pattern is a tuple

pρ

, ρ

, γq, satisfying

1. ρ

, ρ

and γ are predicates in P or ConceptNet,

and

2. normally for any concepts r, s, t P C , if ρ

pr, sq and

ps, tq hold, then γpr, tq holds,

where C represents the concepts set of ConceptNet.

Similarly, we can also deﬁne another kind of rule

pattern termed associative rule pattern with only two

predicates as follows:

Deﬁnition 4. An associative rule pattern is a tuple

pρ, γq, satisfying

1. ρ and γ are predicates in P or ConceptNet, and

2. normally for any concepts r, s P C, if ρpr, sq holds,

then γpr, sq holds.

For example, peat, Desiresq is an associative rule

pattern, since for concept tuple pcat, f ishq, if “Cat

eats ﬁsh”, then “Cat desires ﬁsh”. Note that we

use normally in the deﬁnition to make the inference

fuzzier, since it is hard and unnecessary to ﬁnd the

absolute valid and justiﬁed rules in commonsense rea-

soning.

The negative version of rule pattern is straightfor-

ward, e.g., HasPropertypr, sq is true if and only if

HasPropertypr, sq is not true.

4.2 Extended Rule Patterns

The rule patterns we deﬁned above are expressive, yet

they still cannot deal with the following case. Con-

sider an intuitive commonsense knowledge: if r is up-

set then r will yell at s. It cannot be represented by

the rule patterns we deﬁned above. Since the predi-

cates HasProperty and Yell do not have the associa-

tive relation. That is, we cannot say that if some-

one has a property of something, then she/he yells at

it. Rather, upset and yell seem to have the implicit

relation. More concretely, HasPropertypupsetq and

yell have the causal relation (i.e., if someone is upset,

she/he may yell at someone else”). In order to cover

this kind of knowledge, we extend the deﬁnition to

make it more ﬂexible as follows:

Deﬁnition 5. An extended associative rule pattern is

a tuple pρ, γq, where ρ and γ are either predicates in

P or ConceptNet, or simple concepts in ConceptNet,

satisfying:

rule label rule label

ρpr,sq

γpr,sq

σpr,ρq

γpr,sq

ρpr,sq

σpr,γq

σpr,ρq

σpr,γq

where σ P tHasProperty, IsA, CapableOf u; r, s P C ;

and

denote the causal relation that “if A then B”.

In the above deﬁnition, the label column describes

the types of ρ and γ. If it is a common concept in Con-

ceptNet, we label it as ‘c’, while if it is a predicate in

P or ConceptNet, we label it as ‘p’. So, (upset, yell)

is labeled as ‘cp’. And the associative rule pattern is

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

410

Table 1: Deﬁnition of Extended Syllogism Rule Pattern.

rule label rule label rule label rule label

pr,sq,ρ

ps,tq

γpr,tq

ppp

σpr,ρ

q,ρ

pr,sq

γpr,sq

cpp

σps,ρ

q,ρ

pr,sq

γpr,sq

pcp

pr,sq,ρ

ps,tq

σpr,γq

ppc

σpr,ρ

q,σps,ρ

γpr,sq

ccp

σpr,ρ

q,ρ

pr,sq

σpr,γq

cpc

σps,ρ

q,ρ

pr,sq

σpr,γq

pcc

σpr,ρ

q,σpr,ρ

σpr,γq

ccc

actually a special case whose label is ‘pp’, i.e., ρ and

γ are always predicates.

And σ appears only when ρ or γ is concept. It is

decided by the PoS of this concept. The correspond-

ing transformations are:

PoS Relation of σ

noun Ñ IsA

adjective Ñ HasProperty

verb Ñ CapableOf

For simplicity, we only consider the above three

straightforward and commonly used cases.

Here is an example illustrating the extended as-

sociative rule pattern: (hungry, eat) is a rule pattern,

with label ‘cp’, where hungry is a concept (labeled

with c) and eat is a predicate (labeled with p). σ in

this case is default as HasProperty. Thus, if we know

that “Mike is hungry”, we can imply that “Mike eats

something”.

Similarly, we also extend the syllogism rule pat-

tern to include the above interior relation between

verbs and properties:

Deﬁnition 6. A extended syllogism rule pattern is a

triple pρ

, ρ

, γq, where ρ

, ρ

and γ are predicates in

P or ConceptNet, or simple concepts in ConceptNet,

satisfying the rules as shown in Table 1

4.3 Reverse Rule

An important variation of rule pattern is the reverse

rule. Every rule can have a reverse version, which

changes the role of subject and object of the conclu-

sion. This is necessary if we consider a commonsense

rule (eat, tasty), which we want to express is: “If A

eats B, then B is tasty.” However, according to the def-

inition, it is explained as: “If A eats B, then A is tasty.”

To differentiate them we use r(eat, tasty) to denote it

instead, which reverses the role of subject and object

in conclusion. Formally, the reversed version of rule

pρ, γq is deﬁned as follows:

Deﬁnition 7. A reversed associative rule pattern is a

tuple rpρ, γq with a preﬁx r, satisfying

1. ρ and γ are predicates in P or ConceptNet, and

2. normally for any concepts r, s P C, if ρpr, sq holds,

then γps, rq holds.

Note that the syllogism rule pattern and their ex-

tension also have the corresponding reverse version

rules, but we omit it for the lack of space.

5 EXTRACTION OF RULE

PATTERNS

After the discussion of rule patterns, in this section

we will present an efﬁcient approach for extracting

rule patterns.

The extraction can be divided into two steps: First

we discover a set of potential rule patterns, and then

use conditional probabilities to denote their conﬁ-

dence computing by Bayesian method. For those who

reach a certain threshold, we regard them as valid

rules; otherwise, we discard them.

In a sentence, connectives almost always occur,

with a certain relation between the predicates, before

and behind it. Our approach focuses on six connec-

tives: if, because, so, but, though, and and. Each of

them has the corresponding regular expression based

on text pattern. So, we can use these text patterns to

extract potential rules from corpus.

More speciﬁcally, we ﬁnd out all the sentences

that contain connective ﬁrstly, then extract the predi-

cates from two clauses of it. The extraction process is

implemented by Stanford Dependency Parser (Socher

et al., 2013). Note that when extracting the predicates,

if the predicates are IsA, HasProperty or CapableOf,

we also need to consider the extended situation of rule

pattern mentioned above, and take the objects of these

predicates into account (e.g., IsA(pet) instead of just

IsA).

5.1 Veriﬁcation

Once the potential rule patterns are constructed, we

need a method to judge whether they are reasonable or

not. The intuition of veriﬁcation is computing a conﬁ-

dence for each rule pattern according to ConceptNet,

then its validness can be determined by a predeﬁned

threshold.

We use Bayesian formula to calculate conﬁdence

Commonsense Reasoning in a Deeper Way: By Discovering Relations between Predicates

411

for an associative rule pattern r:

“ ppγ | ρq “

ppγ, ρq

ppρq

. (4)

Assume that there are n possible pairs of concept, and

npρq represents the number of concept pairs that can

be modiﬁed by ρ. Then ppρq “

npρq

, and ppγ, ρq “

npγ,ρq

denote the probabilities that both premises are

true. So, we have:

“ ppγ | ρq “

npγ, ρq

npρq

. (5)

This equation is to denote how probable γ happens if

ρ happens.

To determine whether a rule pattern is reason-

able, a threshold of conﬁdence ε is needed. Accord-

ing to Berger-Wolf et al. (2013), we select ε as 5%.

So, for every potential rule patterns, if its conﬁdence

ą 0.05, it can be regraded as a rule pattern that is

normally valid, or make sense. Note that the conﬁ-

dence rate is low even the rule is valid because of the

sparsity of ConceptNet.

The veriﬁcation of syllogism rule is similar. The

conﬁdence c

of a rule pattern is deﬁned as follows:

“ ppγ | ρ

, ρ

q “

ppγ, ρ

, ρ

ppρ

, ρ

, (6)

where ppρ

, ρ

q presents the probability that both

premises are true, and ppγ, ρ

, ρ

q presents the proba-

bility of truth of γ, ρ

and ρ

at the same time.

5.2 Bias Analysis

In order to analyse the bias induced through out

the process, we randomly pick 15 short stories from

“Fifty Famous People” (Hart, 1971), and annotate

the commonsense knowledge as test set manually.

There are 57 pieces of commonsense knowledge in

it. Among them, 39 are concerned with the relations

between predicates, and others are facts. Our system

ﬁnds out 24 rules, while 15 are valid, i.e., we reach

the precision of 0.625 and recall of 0.385. As far as

we know, there may be following main biases:

1. Subclauses. When the dependency parser encoun-

ters a sentence with subclauses, it works less efﬁ-

ciently, which also lead to a wrong predicate ex-

traction.

2. Double objects. The predicates with double ob-

jects (e.g., “bring me home”) suffer from the dif-

ﬁculty on constructing the subject-object set. It

leads to a low quality of veriﬁcation of these pred-

icates.

3. Connectives. Some of the commonsense knowl-

edge does not appear with connectives, or am-

biguous one like “as”.

6 EVALUATION

For the evaluation part, we apply our system to the

Winograd Schema Challenge (WSC) (Levesque et al.,

2011). WSC is suggested as an alternative to Tur-

ing Test (Turing, 1950) because of its practical ad-

vantages.

An original example of WSC is as follows:

Joan made sure to thank Susan for all the help she

had given. Who given help?

– Answer 0: Susan

– Answer 1: Joan

For adults who speak English, the answer to this ques-

tion is obvious; while for computers, it is a really hard

question. WSC is technically a pronoun resolution

task, but a tough one, since one cannot get the correct

answer simply by syntactic analysis (a deep analysis

on semantics or even pragmatics is needed). There-

fore, most state-of-art pronoun resolvers perform not

very well when facing this challenge.

Some studies have tried to tackle this problem.

For example, Sharma et al. (2015) proposed a method

to search for the needed commonsense knowledge

from web to answer the given question. Rahman and

Ng (2012) proposed a hybrid method by integrating

8 techniques with machine learning algorithms, and

it reaches the correctness of 73%. The error analysis

in their work shows that one of the most contributed

component, Google, is not good at handling schema

that requires a deep understanding of the connection

between two clauses. Another most important tech-

nique, narrative chains, can capture the relationship

between the verb events in the two clauses. However,

it cannot capture the relationship between the clauses

that are not only verbs, e.g., phrases or cases that are

with adjective. So, narrative chains can be regraded as

special case of the associative rule pattern. However,

our method can capture the relationship between two

clauses (predicates), which is difﬁcult for the above

systems.

Thus, we select 49 out of 273 schemas, which

are hard for the above systems, to deal with (i.e., the

schemas that one of or both of the events are not de-

scribed by verbs). And apply our system to this set

of schemas, 33 of them can be successfully answered,

and an accuracy of 67.35% is achieved.

The overall process is as follows. Given a schema,

ﬁrstly extract predicate set S used in the text part and

query predicate p

in the question; then construct a

set of potential rules, and verify them. In a potential

rule, the last predicate (conclusion’s predicate) should

be p

, because we want to lead to a conclusion with

, to answer the question. Other predicates are from

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

412

Table 2: Results of some schema.

schema valid rule conﬁdence

ﬁsh-worm case pHasPropertyphungryq, eatq 6.04%

man-son case pHasPropertypweakq, liftq 7.20%

pay-generous case ppay, HasPropertypgenerousqq 5.87%

woman-daughter case pgive birth, IsApwomanqq 8.07%

hire-take-care case rphire, take care of q 5.14%

For the valid rules, we apply them to the text, and

see what kind of answer the rules would lead to. If

both kinds of answer can be led to, we compare the

conﬁdence of the rules and choose the highest one;

otherwise, we fail to answer this question and guess

an answer instead. For example, if the predicate set

of the above schema is tthank, give hel pu, and

the question’s predicate p

is give hel p, then there

are only two potential rules: pthank, give hel pq and

rpthank, give hel pq. After verifying, we ﬁnd out

their conﬁdence are 2.92% and 7.45% respectively

(the later one has a higher conﬁdence). As a re-

sult, we can apply it to thankpJoan, Susanq and get

give hel ppSusan, Joanq. Hence, the answer is Susan.

The rest of the schemas, especially those who re-

quire commonsense facts or complicated cases (e.g.,

with subclauses), remain not easy to be dealt with by

our system. Therefore, in future it is interesting to

extend our system so that it can deal with such com-

monsense facts.

Table 2 shows ﬁve example schemas that are difﬁ-

cult for other systems, but are easily tackled using the

corresponding valid rule pattern used in our system.

All of the cases require an understanding of the rela-

tionship between two clauses, while in each schema

one of the clauses contains non-verb predicate. So in

this bunch of schemas, other systems can only answer

them randomly.

7 CONCLUSION

It has been a tough struggle for researchers to arm

AI systems with commonsense. Most commonsense

reasoning approaches proposed till now focus on the

relation between entities. Instead, in this paper we

make another attempt and develop a commonsense

reasoning approach, which aim to extract the relation

between predicates. We argue that the correlative re-

lation between two predicates (e.g., thank and help)

also hold an interior commonsense knowledge.

More speciﬁcally, we ﬁrst discuss the deﬁnition of

these kinds of commonsense, then we show a pattern

matching based approach to ﬁnd out the relation from

corpus, and ﬁnally we apply our system to tackle a

part of the Winograd Schema Challenge, which re-

sult shows that our system can successfully answer

the daily questions that are hard for other systems.

In the future, it is interesting to identify other rule

patterns. In this paper, we deﬁne two rule patterns

(i.e., associative rule pattern and syllogism rule pat-

tern). Maybe they are not enough to exhaust all the

possibilities of conclusions, as we discussed in the

evaluation section. Hence, it is necessary to identify

more of them, to tackle the subordinate clause case,

and the double object case, and so on.

ACKNOWLEDGMENTS

This research was partially supported by the Bairen

Plan of Sun Yat-sen University, the Natural Sci-

ence Foundation of Guangdong Province, China (No.

2016A030313231) and the National Fund of Social

Science (No. 13BZX066).

REFERENCES

Angeli, G. and Manning, C. D. (2014). Naturalli: Natu-

ral logic inference for common sense reasoning. In

EMNLP, pages 534–545.

Berger-Wolf, T., Diochnos, D. I., London, A., Pluh

ar, A.,

Sloan, R. H., and Tur

an, G. (2013). Commonsense

knowledge bases and network analysis. Common-

sense.

Bollacker, K., Evans, C., Paritosh, P., Sturge, T., and Tay-

lor, J. (2008). Freebase: A collaboratively created

graph database for structuring human knowledge. In

Proceedings of the 2008 ACM SIGMOD International

Conference on Management of data, pages 1247–

1250. ACM.

Davis, E. and Marcus, G. (2015). Commonsense reasoning

and commonsense knowledge in artiﬁcial intelligence.

Communications of the ACM, 58(9):92–103.

Hart, M. (1971). Project gutenberg. Project Gutenberg.

Kazakov, Y. et al. (2009). Consequence-driven reasoning

for horn shiq ontologies. In IJCAI, volume 9, pages

2040–2045.

Levesque, H. J., Davis, E., and Morgenstern, L. (2011). The

Winograd schema challenge. In AAAI Spring Sympo-

Commonsense Reasoning in a Deeper Way: By Discovering Relations between Predicates

413

sium: Logical Formalizations of Commonsense Rea-

soning.

Liu, H. and Singh, P. (2004). Commonsense reasoning in

and over natural language. volume 3215 of Lecture

Notes in Computer Science, pages 293–306.

Rahman, A. and Ng, V. (2012). Resolving complex cases

of deﬁnite pronouns: The winograd schema chal-

lenge. In Proceedings of the 2012 Joint Conference

on Empirical Methods in Natural Language Process-

ing and Computational Natural Language Learning,

pages 777–789.

Rebele, T., Suchanek, F., Hoffart, J., Biega, J., Kuzey, E.,

and Weikum, G. (2016). Yago: A multilingual knowl-

edge base from Wikipedia, Wordnet, and Geonames.

In The Semantic Web ISWC 2016, volume 9982 of

Lecture Notes in Computer Science, pages 177–185.

Schmitz, M., Bart, R., Soderland, S., Etzioni, O., et al.

(2012). Open language learning for information ex-

traction. In Proceedings of the 2012 Joint Conference

on Empirical Methods in Natural Language Process-

ing and Computational Natural Language Learning,

pages 523–534. Association for Computational Lin-

guistics.

Sharma, A., Vo, N. H., Gaur, S., and Baral, C. (2015). An

approach to solve winograd schema challenge using

automatically extracted commonsense knowledge. In

2015 AAAI Spring Symposium Series. Citeseer.

Socher, R., Bauer, J., Manning, C. D., and Ng, A. Y.

(2013). Parsing with compositional vector gram-

mars. In the Association for Computational Linguis-

tics, pages 455–465.

Soderland, S., Roof, B., Qin, B., Xu, S., Etzioni, O.,

et al. (2010). Adapting open information extraction

to domain-speciﬁc relations. AI Magazine, 31(3):93–

102.

Speer, R. and Havasi, C. (2013). ConceptNet 5: A large

semantic network for relational knowledge. In The

Peoples Web Meets NLP, pages 161–176. Springer.

Speer, R., Havasi, C., and Lieberman, H. (2008). Anal-

ogyspace: Reducing the dimensionality of common

sense knowledge. In Proceedings of the 23rd National

Conference on Artiﬁcial Intelligence, volume 1, pages

548–553.

Tandon, N., De Melo, G., and Weikum, G. (2011). Deriving

a web-scale common sense fact database. In Proceed-

ings of the Twenty-Fifth AAAI Conference on Artiﬁcial

Intelligence, pages 152–157.

Toutanova, K., Klein, D., and Manning, C. D. (2003).

Feature-rich part-of-speech tagging with a cyclic de-

pendency network. In Proceedings of the 2003 Con-

ference of the North American Chapter of the Associ-

ation for Computational Linguistics on Human Lan-

guage Technology, volume 1, pages 252–259.

Turing, A. M. (1950). Computing machinery and intelli-

gence. Mind, 59(236):433–460.

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

414
