Resilience of GANs against Adversarial Attacks

Kyrylo Rudavskyy and Ali Miri

Department of Computer Science, Ryerson University, Toronto, Canada

Keywords:

Machine Learning, Generative Adversarial Network, Adversarial Attack, Security.

Abstract:

The goal of this paper is to explore the resilience of Generative Adversarial Networks(GANs) against adver-

sarial attacks. Speciﬁcally, we evaluated the threat potential of an adversarial attack against the discriminator

part of the system. Such an attack aims to distort the output by injecting maliciously modiﬁed input during

training. The attack was empirically evaluated against four types of GANs, injections of 10% and 20% mali-

cious data, and two datasets. The targets were CGAN, ACGAN, WGAN, and WGAN-GP. The datasets were

MNIST and F-MNIST. The attack was created by improving an existing attack on GANs. The lower bound

for the injection size turned out to be 10% for the improvement and 10-20% for the baseline attack. It was

shown that the attack on WGAN-GP can overcome a ﬁltering defence for F-MNIST.

1 INTRODUCTION

A Generative Adversarial Network (GAN) was ﬁrst

proposed by Goodfellow et al. in 2014. It is a ma-

chine learning technique whose goal is to learn the

distribution of a set of data (Lucic et al., 2018). This is

accomplished similar to a two-player game, where the

players are neural networks. One player - called the

generator - transforms a sample from the normal dis-

tribution into a sample that resembles real data. The

other player - called the discriminator - tries to assess

if a sample is real or fake based on its knowledge of

the real data. After a sufﬁcient number of iterations,

the generator will produce samples that are hard to

distinguish from the real ones. Thus, it will learn to

transform a normal distribution into the data distribu-

tion.

GANs have a variety of applications. A recent

survey paper covers the more popular applications of

GANs (Alqahtani et al., 2021). The authors describe

a variety of use-cases in the audiovisual and medi-

cal domains. Moreover, GANs can generate synthetic

data to compensate insufﬁcient data (Wang et al.,

2019), imbalanced data (Engelmann and Lessmann,

2021), or provide privacy (Choi et al., 2017). Finally,

GANs are also used for malicious purposes such as

deepfakes. These are videos or images where a per-

son can appear to act or say almost anything (Yadav

and Salmani, 2019).

1.1 Problem Statement

It is clear from the above that GANs can be used in

mission-critical systems. Alternatively, one may wish

to disrupt a GAN in case of potential malicious us-

age of the latter. In both cases, the security of these

algorithms is of interest. Thus, the overarching goal

of this paper is to explore the resilience of Generative

Adversarial Networks against adversarial attacks.

It is a well-known fact that neural networks are

susceptible to attacks (Miller et al., 2020; Kaviani and

Sohn, 2021). Some researchers even think that cir-

cumstances enabling attacks on neural networks are

an innate characteristic of the deep learning process

(Ilyas et al., 2019). Since neural networks play a key

role in most GANs, it is reasonable to assume that

security problems from neural networks will affect

them.

Particularly worrisome are adversarial attacks.

These attacks were created to manipulate the output

of a neural network by modifying the input (Miller

et al., 2020). Since GANs are a cleverly designed sys-

tem of two or more neural networks, an adversarial

attack works by targeting one of these networks. In

fact, designing GANs that are resilient to such attacks

is an active area of research (Liu and Hsieh, 2019;

Bashkirova et al., 2019; Xu et al., 2019; Zhou and

ahenb

uhl, 2019). A possible impact of such an at-

tack is low-quality output, or synthetic data, that does

not resemble the original.

What is less understood is the feasibility of such

attacks in the real world. The reason is that scholars

often focus on defending either a single component of

390

Rudavskyy, K. and Mir i, A.

Resilience of GANs against Adversarial Attacks.

DOI: 10.5220/0011307200003283

In Proceedings of the 19th International Conference on Security and Cryptography (SECRYPT 2022), pages 390-397

ISBN: 978-989-758-590-6; ISSN: 2184-7711

a GAN or a narrow case, such as defending a cycle-

consistent GAN against itself. This is the gap that our

research is trying to close. In short, we want to inves-

tigate the impact of an adversarial attack on synthetic

data, which was not comprehensively examined be-

fore. The attack will be referred to as Monkey-Wrench

Attack (MWA).

1.2 Findings

Our paper will show that adversarial attacks on GANs

are challenging to execute in practice. This is likely

because GANs have a degree of innate resilience to

noisy data (Bora et al., 2018; Thekumparampil et al.,

2018). Of the four GAN variants, only one proved to

be vulnerable across datasets. In addition, the attack

required modifying 10-20% of input data.

However, in conditions that more closely resemble

a real-world application of GANs, the attack proved

to be more successful. The GAN version that was

more vulnerable is one of the most advanced archi-

tectures proposed to date (Lucic et al., 2018). More-

over, the modiﬁcations of input data evaded detection

on the more sophisticated dataset. Advanced GAN ar-

chitectures and sophisticated datasets are more likely

to be employed in applications.

In the setting mentioned above, the attack was also

improved. An adversarial crafting process was de-

vised that improved attack performance over the base-

line approach. Moreover, a lower bound on the injec-

tion size was established for both cases. Finally, our

adversarial samples were harder for a human operator

to identify as malicious.

The stealth of adversarial samples is signiﬁcant

because they produce unexpected results and might

be spotted during production. However, if the opera-

tor fails to identify the malicious intent behind these

irregularities, the operator may fail to attribute a sys-

tem malfunction to them. This will lead to the opera-

tor forgoing additional security measures and putting

the data into production.

The above high-level conclusions rest on a series

of contingent results. Most of the latter will be de-

rived empirically and substantiated in Section 4. Be-

low is a list of ﬁndings that, to the best of our knowl-

edge, were not produced before:

F.1. The improved attack is likely to outperform the

existing attacks when the loss function is complex

and the dataset is sophisticated. Performance is

measured by observing higher output distortion

for equal size injections.

F.2. If the above conditions are met, the improved at-

tack will likely overcome the countermeasure ap-

plied herein with greater success than the existing

attack. Success is deﬁned the same way as above.

F.3. Our version of the attack required an injection of

at least 10%, while the baseline had a lower bound

in the 10-20% range.

F.4. It is likely possible to visually conceal the im-

proved attack from a human operator.

2 RELATED WORKS

This section will commence with descriptions of

GANs used in this paper starting with the original one

(Goodfellow et al., 2014). Although the latter was not

used, it will be provided as a base model of the tech-

nology. Let P

represent an unknown data distribu-

tion, then the discriminator, D, is trained to assign a

probability of sample belonging to P

, while the gen-

erator, G, is trained to create samples that resemble

the original data. This process estimates data distri-

bution, P

, by implicitly creating a generator distri-

bution, Q

. Finally, a GAN builds G by learning to

transform samples from the normal distribution, P

The process is expressed by a two-player minimax

game with the following objective function:

min

max

V (D, G) = E

x∼P

[logD(x)]+

z∼P

[log(1 − D(G(z)))]

(1)

Solving it minimizes Jensen–Shannon Divergence

(JSD) between the distributions P

and Q

(Gong

et al., 2019).

A straightforward extension of a GAN - called a

Conditional GAN (CGAN) - was achieved by condi-

tioning it on a class label (Mirza and Osindero, 2014).

It was further extended with an Auxiliary Conditional

GAN (AC-GAN) by adding a third component that de-

termines a sample’s probability of belonging to a cer-

tain class (Odena et al., 2017).

A breakthrough in GANs came with the introduc-

tion of a Wasserstein GAN (WGAN) (Arjovsky et al.,

2017). The authors use a different measure of simi-

larities between distributions - Wasserstein or Earth

Mover Distance (EM) which is smoother. Gulra-

jani et al. (Gulrajani et al., 2017) further improve it

by replacing weight clipping with a gradient penalty.

This architecture is called a Wasserstein GAN with

Gradient Penalty (WGAN-GP). The performance of

GANs will be measured with Fr

echet Inception Dis-

tance (FID) (Heusel et al., 2017).

Projected Gradient Descent (PGD) is an adversar-

ial attack and was chosen here because it is consid-

ered to be a universal ﬁrst-order optimization attack

(Madry et al., 2018). It works by adding perturba-

tions to a sample, which forces a neural network to

Resilience of GANs against Adversarial Attacks

391

misclassify the sample. Madry formulated it as fol-

lows. Let δ lie in l

∞

-ball, S , around a sample x from

distribution D with corresponding label y and let θ be

model parameters, then

min

ρ(θ), ρ(θ) = E

(x,y)∼D



max

δ∈S

L(θ, x + δ, y)



(2)

The inner optimization produces adversarial pertur-

bations, δ, which is the PGD attack proposed by the

author. The outer optimization is a countermeasure to

PGD. Its strength is varied by the ε parameter or the

norm which can make it more noticeable to the naked

eye.

Defense GAN (Def-GAN) is a pre-processing

countermeasure against adversarial input attacks,

such as PGD (Samangouei et al., 2018). This method

will be used extensively in this paper. The idea is that

assuming the defender possesses enough clean data

to train a GAN, they can use that GAN to ﬁlter out

adversarial samples.

Security of GANs was considered before (Liu and

Hsieh, 2019; Zhou and Kr

ahenb

uhl, 2019; Xu et al.,

2019; Bashkirova et al., 2019). One method is to per-

form adversarial training of the discriminator but it

fails at stronger levels of PGD (Liu and Hsieh, 2019).

Another approach is to apply adversarial regulariza-

tion to the discriminator which may negatively af-

fect convergence (Zhou and Kr

ahenb

uhl, 2019). A

method to protect the generator was proposed (Xu

et al., 2019). It is not applicable because the target

of our work is the discriminator. Finally, the work

by Xu etal. was extended to cycle-consistent GANs

(Bashkirova et al., 2019). However, these differ sig-

niﬁcantly from the GANs considered here

3 METHODOLOGY

3.1 Attack Description

A GAN can be viewed as a “student-teacher” system

and MWA works by nudging the learning vector in the

wrong direction. Forcing the teacher - the discrimina-

tor - to assign a surplus of value to bad examples will

provide wrong training directions to the student - the

generator. Alternatively, the goal can be achieved by

doing the opposite - making the teacher assign too lit-

tle value to legitimate examples. In this paper these

two types of bad examples are referred to as Early

Epoch Decoy (EED)

and Downgrade Decoy (DGD),

Sometimes the term “Early Stop Decoys” is used in-

stead of “Early Epoch Decoys”

respectively. They can also be seen as two variations

of MWA.

Starting with the ﬁrst type, decoys are created

by replacing a subset of data with bogus informa-

tion while keeping the labels intact. For example,

one could simply replace these samples with normal

noise. However, normal noise is easy to detect, so a

different source of bogus data was used.

Instead of normal noise, we used samples gener-

ated by a GAN that was trained for only an epoch or

two. In this paper, these samples are referred to as

EEDs. For this purpose, a GAN is trained using simi-

lar settings as the victim GAN. As a result, adversarial

samples will share similarities with the original data,

making them harder to remove. Moreover, by overem-

phasizing their value to the teacher, the hope is that

the system will treat premature convergence as a de-

sirable goal.

The discriminator will be nudged to overestimate

the value of decoys using the following technique.

Once decoys are created, a PGD attack will be ap-

plied to this subset of data. The discriminator is es-

sentially a classiﬁer, so theoretically, it is possible to

modify samples with PGD such that the discriminator

will classify them according to the attacker’s needs.

In this case, the discriminator will classify decoys as

more likely to be real.

In the downgrade variation the opposite occurs.

PGD is applied such that the discriminator assigns lit-

tle value to a subset of legitimate data. The concept of

attacking a GAN by applying PGD to a subset of the

training data is not new and was mentioned in Section

2. However, to the best of our knowledge, the early

epoch approach had not been tried before.

Once malicious samples are produced, they are

combined with the rest of the dataset and given to

a victim GAN for training. If the above hypothesis

holds, the victim will produce either more malformed

samples or a larger number of them. In both cases, the

generating process will be compromised.

Finally, MWA can be considered a white-box

attack because the attacker assumes knowledge of

GAN hyperparameters and network architectures but

not direct access to the weights. Typically, a black-

box attack assumes little knowledge of the above

(Miller et al., 2020). However, this limitation can be

overcome using a method called transferability that

uses a surrogate model (Madry et al., 2018; Miller

et al., 2020). The attack schematic can be seen in Fig.

SECRYPT 2022 - 19th International Conference on Security and Cryptography

392

Figure 1: MWA Topology

3.2 Data

This paper used two datasets: Modiﬁed National

Institute of Standards and Technology Database

(MNIST) (Lecun et al., 1998) and Fashion-MNIST

(F-MNIST) (Xiao et al., 2017). F-MNIST was de-

signed as a “direct drop-in replacement” (Xiao et al.,

2017, p.1) for MNIST and is more sophisticated. The

authors divided the dataset into 60k training and 10k

testing samples. Finally, as recommended for vi-

sion datasets, images are normalized to [-1,1] with a

mean of 0.5 and standard deviation of 0.5 (Goodfel-

low et al., 2016, p.419).

3.3 Decoys

As described in Section 3.1, the ﬁrst step of MWA

is to create decoys. Downgrade decoys are taken di-

rectly from the training data. Early epoch decoys,

on the other hand, need crafting. They were pro-

duced by creating four types of GANs: CGAN, AC-

GAN, WGAN, and WGAN-GP. The neural network

architectures of the discriminator and the generator

for these GANs were borrowed from PyTorch-GAN

package that was used as part of our implementation.

To save computational power, only one class out

of the ten available was used with CGANs and AC-

GANs. Since these two architectures are conditional,

it is possible to specify which class one prefers to gen-

erate. However, GANs themselves were created from

the entire training dataset.

3.4 Adversarial Perturbations

At this stage of the attack, decoys are modiﬁed such

that the discriminator will either overestimate or un-

derestimate them. This is accomplished by adding ad-

versarial perturbations using PGD described in Sec-

tion 2. The goal is to create a specially crafted noise -

referred to as adversarial perturbations - and add it to

Wrench Icon By Estelle DB - Own work, CC

BY-SA 4.0, https://commons.wikimedia.org/w/index.php?

curid=57721428

https://github.com/eriklindernoren/PyTorch-GAN

the decoys. These perturbations change the discrimi-

nator’s valuation. Since PGD requires a model to craft

samples, a fully trained discriminator from the decoy

production step (ref. Section 3.3) was used. Visual

examples of the result can be seen in Figure 2.

Figure 2: Examples of EEDs (top row) and DGDs (bottom

row) trained on MNIST (left col) and F-MNIST (right col).

The biggest challenge at this stage was providing

an appropriate loss function to PGD as stipulated in

Equation 2. Binary Cross Entropy (BCE) was chosen

for WGAN, WGAN-GP, and CGAN. The target was

either 1.0 (early stop) or 0.0 (downgrades), and the in-

put was whatever validity the discriminator assigned,

passed through a Sigmoid function. Again, since the

discriminator can be viewed as a binary classiﬁer (i.e.

real or fake), BCE is an appropriate choice.

The loss function for performing PGD on the AC-

GAN discriminator was constructed differently. The

reason is that the discriminator is composed of two

neural networks that share the same base network.

One network measures data validity, while the other

predicts the label. Both must be used during the PGD

step because the networks are intertwined. For this

reason, the loss function was similar to the one used

in the actual AC-GAN. However, only the part that

evaluates loss on the real data was used. The code

was based on the Advertorch library created by Bo-

realisAI (Ding et al., 2019). PGD parameter ε = 1.0

was used.

3.5 Detection

This section proposes a method for defending against

MWA. The countermeasure used is based on Def-

GAN described in Section 2. Def-GAN relies on

a clean generator to detect adversarial samples. To

source the generator, the same GAN was used as the

one for the decoys and PGD steps above, sections 3.3

and 3.4 respectively. This decision was made to re-

Resilience of GANs against Adversarial Attacks

393

duce computational complexity.

However, using the same GAN possibly created a

new problem. Since GANs used for crafting decoys

and building the detector were the same, they were

trained on the same data. Moreover, the detector usu-

ally would be trained on a subset of the data and not

the whole of it. As a result, detection ﬁgures might be

more optimistic than they should be.

Def-GAN was used in its capacity as a detector

as described in the original paper. Detection perfor-

mance was measured by creating ROCs and AUC for

different thresholds.

4 ANALYSIS

Four GAN variants were trained on both datasets con-

taining 10% and 20% of malicious decoys constructed

according to MWA from above. Each combination

of architecture, dataset, percentage, and decoy type

constitutes a parameter set for a single experiment.

To produce viable statistics, each experiment was re-

peated 50 times.

4.1 Null Hypothesis

To evaluate whether MWA had any effect on a GAN,

two null hypotheses must be rejected:

H.1. The attack had no effect on a GAN.

H.2. Comparable results can be achieved with a sim-

ple injection of random, bogus data.

To address the ﬁrst hypothesis, FID scores of an attack

- parameterized as described above - will be compared

to the FID scores of a clean GAN. A similar approach

will be taken for the second null hypothesis. The dif-

ference is that instead of using a clean GAN, a substi-

tute will be trained on data containing bogus samples.

In this case, bogus samples will be EEDs before PGD.

For simplicity, it will be referred to as a bogus GAN.

For an easy comparison, notch boxes are created

from FID scores generated by a single combination

of experiment parameters over 50 trials. If notches

do not overlap, this means the difference between the

two groups is statistically signiﬁcant (0.05 p-value)

(Krzywinski and Altman, 2014). However, to dismiss

a null hypothesis, a stricter measure was taken than

the standard p-value.

This difference was not sufﬁcient to manifest vi-

sually on the generated samples during experiments.

Used code from https://github.com/sky4689524/

DefenseGAN-Pytorch

For this reason, the measure was tightened. To dis-

miss a null hypothesis, the entire boxes must not over-

lap. Moreover, such an approach guarantees statisti-

cal signiﬁcance.

Figure 3: FID Scores of attacks on GANs. The tuples on the

x-axis represent experiment parameters: injection size (%),

PGD strength (ε), PGD norm, decoy type. The numbers

on the boxplots indicate the medians. The columns with

PGD strength of 0.0 represent the bogus GANs needed to

reject H.2.. The clean column refers to H.1.. A higher score

implies less similiarty.

4.2 Performance Summary

This subsection will analyze which attacks reject null

hypotheses using Figure 3. Out of the 32 attack com-

binations, 13 passed both null hypotheses and can be

considered successful. In the rest of the cases, the at-

tack is considered failed. The results are summarized

in the table below.

Table 1: Cases where both null hypothesis were rejected

marked by a dataset were it happened. M - MNIST, F -

FMNIST.

GAN EED 10% EED 20% DGD 10% DGD 20%

AC-GAN M/F M M

WGAN M

WGAN-GP M/F M/F M/F M/F

The ﬁrst observation from the table is that the

Wasserstein family of GANs is more vulnerable to

both early epoch and downgrade variations of the at-

tack. As was noted in Section 2, Wasserstein GANs

use a more sophisticated measure to construct the loss

function. This supports the part of ﬁnding F.1. that re-

SECRYPT 2022 - 19th International Conference on Security and Cryptography

394

lates loss function complexity to attack success.

Our next observation is that success varies within

each family. Again, as noted in Section 2, AC-GAN

is a more advanced version of CGAN and WGAN-

GP of WGAN. In both cases, advancement stems

from improvements of the loss functions. Also, in

both cases, these improvements made the loss func-

tions more complex. This further supports the claim

in ﬁnding F.1. that attack success improves with loss

function complexity.

Finally, from Table 1 we can see that target data

can be a signiﬁcant factor in the success of the at-

tack. The attack succeeded eight times on MNIST and

ﬁve on F-MNIST. Moreover, EEDs succeeded consis-

tently across datasets, while downgrades succeeded

more often on MNIST. This implies that the claim in

ﬁnding F.1. relating the improved attack’s success to

dataset complexity is correct.

4.3 Detection Analysis

Having established the conditions for a successful at-

tack, it is important to establish whether it is possi-

ble to prevent it. The defensive strategy chosen here

is based on ﬁltering out malicious samples from the

training data. The precise mechanics of this process

were described in Section 3.5.

ROC curves plot the relationship between detected

malicious samples and false alarms. The technical

term for the ﬁrst one is True Positive Rate (TPR) and

False Positive Rate (FPR) for the second one. In our

case, FPR implies the portion of the dataset that must

be abandoned to eliminate a number of decoys that

stems from a corresponding TPR.

It is impossible to establish a commonly accept-

able FPR because it depends on the case. For exam-

ple, in some situations, eliminating 10% of the data is

unacceptable, while 50% might be dispensable in oth-

ers. However, to proceed with the analysis, we will

consider a 20-30% sacriﬁce of the dataset to be the

threshold of an acceptable loss of data.

To visualize the effect of the countermeasure on

the attack, a ﬁgure similar to Figure 3 will be created.

However, this ﬁgure will contain FIDs that we would

have received if we ﬁltered the data before training

the GAN. These numbers were simulated as follows.

Re-training the GANs on smaller numbers of de-

coys was computationally prohibitive. For this rea-

son, an approximation was made. FID scores in Fig-

ure 3 exhibited approximately a linear relationship to

the amount of decoys. This applies to both types of

decoys and bogus data. Thus, the new FID scores in

Figure 4 were simulated by exploiting this linear rela-

tionship. FID scores were linearly projected to lower

Figure 4: FID Scores After Filtering. The tuples on the x-

axis represent the injection size , PGD strength, and decoy

type. The numbers on the boxplots indicate the medians and

the TPRs.

size injections. New sizes were determined using

TPRs that correspond to the acceptable FPR range.

TPRs were averaged over iterations.

The attack was successful only for WGAN-GP: on

F-MNIST at 10% of EEDs and at 20% for both types

of decoys. Two implications stem from the above.

First, the attack survived the countermeasure only for

the most advanced GAN (Lucic et al., 2018) and on

the more sophisticated dataset. More, EEDs survived

twice, while downgrades only once. This proves ﬁnd-

ing F.2. that our proposed attack is likely to evade de-

tection for more complex loss functions and datasets.

Moreover, judging from FID dynamics in Figure

4, 10% is the lower bound for EEDs. For downgrades,

the lower bound is somewhere in the 10-20% range.

Together, these facts support ﬁnding F.3..

Now let us consider visual inspection as a defen-

sive tool. As was mentioned, MWA with downgrade

decoys corresponds to efforts from earlier literature.

These decoys are easier to identify as malicious (ref.

Fig. 2). Individual items can be discerned and the

noise always follows a similar pattern. This indicates

a lack of randomness and a possible presence of in-

tent.

The situation with EEDs is different. Often the

original data cannot be discerned at all and the noise

does not follow an obvious pattern (ref. Fig. 2). Thus,

we conclude that it is likely possible to conceal EEDs

from a human observer. This supports ﬁnding F.4..

Resilience of GANs against Adversarial Attacks

395

4.4 Decoy Comparison

For the purpose of this comparison, only cases that

pass both null hypotheses will be examined. From

Figure 3 we can see that EEDs outperformed down-

grades in all cases, but two: (1) AC-GAN trained on

MNIST with 10% decoys, and (2) WGAN trained on

MNIST with a 20% injection.

It is possible to conclude that EEDs outperform

downgrades quantitatively with standard statistical

signiﬁcance (Krzywinski and Altman, 2014). But is

statistical signiﬁcance enough to claim an improve-

ment in this domain? When EEDs outperform down-

grades, they do so with an average FID increase of ap-

proximately 5%. Which is the ﬁrst argument to sup-

port ﬁnding F.1. that existing attack proposals were

improved upon.

Now, let us consider decoy performance after ap-

plying the countermeasure. In this case, the attack is

successful only for WGAN-GP trained on F-MNIST

with a 10% and 20% injection. In the 20% case, the

bogus GAN used as a basis for H.2. had a median FID

of 119. EEDs and DGDs had FIDs of 130 and 124,

respectively. The ﬁrst one was 9% higher and the sec-

ond one was 4% higher than the H.2. median. In the

10% case, only EEDs succeeded and outperformed

H.2. with 3.5%.

This tells us that the early epoch approach outper-

forms the downgrades when the attack rejects the null

hypotheses and evades detection. Moreover, this hap-

pens with standard statistical signiﬁcance. Noting that

the downgrade approach is an existing scientiﬁc pro-

posal, the result forms another argument towards ﬁnd-

ing F.2. that an improvement was achieved. However,

in both cases, improvement is true only for complex

loss functions and datasets.

5 CONCLUSIONS AND FUTURE

WORK

This paper aimed to explore the vulnerability of

GANs to adversarial input attacks. Speciﬁcally, it was

unclear what conditions are necessary for such an at-

tack to succeed and whether it is possible to defend

against. An attack was devised based on a known ap-

proach to answer these questions. The latter was im-

proved by using different source data for crafting ad-

versarial samples. Empirical results showed that this

is indeed a superior approach.

The gains were made on the more sophisticated

dataset or GANs with more advanced loss functions.

A similar pattern held when trying to break through a

countermeasure. The attacks overcame the defence

only on the F-MNIST dataset and WGAN-GP ar-

chitecture. Our version succeeded for injections of

10% and 20%, while the baseline succeeded only with

20%. In both cases, our version achieved a higher FID

score, which indicates better performance.

However, when a countermeasure was not ap-

plied, both attacks were successful more often, with

EEDs performing better. Finally, the adversarial sam-

ples proposed in this paper are more difﬁcult to iden-

tify visually.

The countermeasure remains an open question.

Other approaches were proposed that may perform

better but with additional costs. Given that some

GANs are defenceless using the current countermea-

sure, future work will investigate the cost-beneﬁt

equilibrium of other defences.

REFERENCES

Alqahtani, H., Kavakli-Thorne, M., and Kumar, G. (2021).

Applications of Generative Adversarial Networks

(GANs): An Updated Review. Archives of Compu-

tational Methods in Engineering, 28(2):525–552.

Arjovsky, M., Chintala, S., and Bottou, L. (2017). Wasser-

stein Generative Adversarial Networks. In Proceed-

ings of the 34th International Conference on Machine

Learning, pages 214–223. PMLR.

Bashkirova, D., Usman, B., and Saenko, K. (2019). Ad-

versarial self-defense for cycle-consistent GANs. In

Wallach, H. M., Larochelle, H., Beygelzimer, A.,

d’Alch

e-Buc, F., Fox, E. B., and Garnett, R., editors,

Proceedings of the 32nd Annual Conference on Neu-

ral Information Processing Systems 2019, NeurIPS

2019, December 8-14, 2019, Vancouver, BC, Canada,

pages 635–645.

Bora, A., Price, E., and Dimakis, A. G. (2018). Ambient-

GAN: Generative models from lossy measurements.

In Proceedings of the 6th International Conference

on Learning Representations, ICLR 2018, Vancouver,

BC, Canada, April 30 - May 3, 2018, Conference

Track Proceedings. OpenReview.net.

Choi, E., Biswal, S., Malin, B., Duke, J., Stewart, W. F.,

and Sun, J. (2017). Generating Multi-label Discrete

Patient Records using Generative Adversarial Net-

works. In Proceedings of the 2nd Machine Learning

for Healthcare Conference, pages 286–305. PMLR.

Ding, G. W., Wang, L., and Jin, X. (2019). Advertorch

v0.1: An Adversarial Robustness Toolbox based on

PyTorch. arXiv:1902.07623 [cs, stat].

Engelmann, J. and Lessmann, S. (2021). Conditional

Wasserstein GAN-based oversampling of tabular data

for imbalanced learning. Expert Systems with Appli-

cations, 174:114582.

Gong, M., Xu, Y., Li, C., Zhang, K., and Batmanghelich, K.

(2019). Twin Auxiliary Classiﬁers GAN. Advances

in neural information processing systems, 32:1328–

1337.

SECRYPT 2022 - 19th International Conference on Security and Cryptography

396

Goodfellow, I., Bengio, Y., and Courville, A. (2016).

Deep Learning. MIT Press, Cumberland, UNITED

STATES.

Goodfellow, I. J., Pouget-Abadie, J., Mirza, M., Xu, B.,

Warde-Farley, D., Ozair, S., Courville, A., and Ben-

gio, Y. (2014). Generative adversarial nets. In

Proceedings of the 27th International Conference on

Neural Information Processing Systems - Volume 2,

NIPS’14, pages 2672–2680, Cambridge, MA, USA.

MIT Press.

Gulrajani, I., Ahmed, F., Arjovsky, M., Dumoulin, V., and

Courville, A. C. (2017). Improved training of wasser-

stein GANs. In Guyon, I., Luxburg, U. V., Bengio, S.,

Wallach, H., Fergus, R., Vishwanathan, S., and Gar-

nett, R., editors, Proceedings of the 30th Annual Con-

ference on Neural Information Processing Systems.

Curran Associates, Inc.

Heusel, M., Ramsauer, H., Unterthiner, T., Nessler, B., and

Hochreiter, S. (2017). GANs trained by a two time-

scale update rule converge to a local nash equilib-

rium. In Guyon, I., von Luxburg, U., Bengio, S.,

Wallach, H. M., Fergus, R., Vishwanathan, S. V. N.,

and Garnett, R., editors, Proceedings of the 30th An-

nual Conference on Neural Information Processing

Systems 2017, December 4-9, 2017, Long Beach, CA,

USA, pages 6626–6637.

Ilyas, A., Santurkar, S., Tsipras, D., Engstrom, L., Tran,

B., and Madry, A. (2019). Adversarial Examples Are

Not Bugs, They Are Features. In Proceedings of the

32nd Annual Conference on Neural Information Pro-

cessing System, Vancouver, BC, Canada, Vancouver,

BC, Canada. Curran Associates, Inc.

Kaviani, S. and Sohn, I. (2021). Defense against neural

trojan attacks: A survey. Neurocomputing, 423:651–

667.

Krzywinski, M. and Altman, N. (2014). Visualizing sam-

ples with box plots. Nature Methods, 11(2):119–120.

Lecun, Y., Bottou, L., Bengio, Y., and Haffner, P.

(Nov./1998). Gradient-based learning applied to

document recognition. Proceedings of the IEEE,

86(11):2278–2324.

Liu, X. and Hsieh, C.-J. (2019). Rob-GAN: Generator, Dis-

criminator, and Adversarial Attacker. In Proceedings

of the 2019 IEEE/CVF Conference on Computer Vi-

sion and Pattern Recognition (CVPR), pages 11226–

11235.

Lucic, M., Kurach, K., Michalski, M., Bousquet, O., and

Gelly, S. (2018). Are GANs created equal? a large-

scale study. In Proceedings of the 32nd International

Conference on Neural Information Processing Sys-

tems, NIPS’18, pages 698–707, Red Hook, NY, USA.

Curran Associates Inc.

Madry, A., Makelov, A., Schmidt, L., Tsipras, D., and

Vladu, A. (2018). Towards deep learning models re-

sistant to adversarial attacks. In Proceedings of the

6th International Conference on Learning Represen-

tations, ICLR 2018, Vancouver, BC, Canada, April 30

- May 3, 2018, Conference Track Proceedings. Open-

Review.net.

Miller, D. J., Xiang, Z., and Kesidis, G. (2020). Adversarial

Learning Targeting Deep Neural Network Classiﬁca-

tion: A Comprehensive Review of Defenses Against

Attacks. Proceedings of the IEEE, 108(3):402–433.

Mirza, M. and Osindero, S. (2014). Conditional Generative

Adversarial Nets. arXiv:1411.1784 [cs, stat].

Odena, A., Olah, C., and Shlens, J. (2017). Conditional

Image Synthesis with Auxiliary Classiﬁer GANs. In

Proceedings of the International Conference on Ma-

chine Learning, pages 2642–2651. PMLR.

Samangouei, P., Kabkab, M., and Chellappa, R. (2018).

Defense-gan: Protecting classiﬁers against adversarial

attacks using generative models. In Proceedings of the

6th International Conference on Learning Represen-

tations, ICLR 2018, Vancouver, BC, Canada, April 30

- May 3, 2018, Conference Track Proceedings. Open-

Review.net.

Thekumparampil, K. K., Khetan, A., Lin, Z., and Oh, S.

(2018). Robustness of conditional GANs to noisy

labels. In Bengio, S., Wallach, H. M., Larochelle,

H., Grauman, K., Cesa-Bianchi, N., and Garnett,

R., editors, Proceedings of the 31st Annual Con-

ference on Neural Information Processing Systems

2018, NeurIPS 2018, December 3-8, 2018, Montr

eal,

Canada, pages 10292–10303.

Wang, Z., Myles, P., and Tucker, A. (2019). Generating

and Evaluating Synthetic UK Primary Care Data: Pre-

serving Data Utility & Patient Privacy. In Proceed-

ings of the 2019 IEEE 32nd International Symposium

on Computer-Based Medical Systems (CBMS), pages

126–131, Cordoba, Spain. IEEE.

Xiao, H., Rasul, K., and Vollgraf, R. (2017). Fashion-

MNIST: A Novel Image Dataset for Benchmarking

Machine Learning Algorithms. arXiv:1708.07747

[cs, stat].

Xu, Z., Li, C., and Jegelka, S. (2019). Robust GANs against

Dishonest Adversaries. In Proceedings of the Interna-

tional Conference on Machine Learning Workshop on

Security and Privacy of ML.

Yadav, D. and Salmani, S. (2019). Deepfake: A Survey

on Facial Forgery Technique Using Generative Adver-

sarial Network. In Proceedings of the 2019 Interna-

tional Conference on Intelligent Computing and Con-

trol Systems (ICCS), pages 852–857.

Zhou, B. and Kr

ahenb

uhl, P. (2019). Don’t let your Dis-

criminator be fooled. In Proceedings of the 7th In-

ternational Conference on Learning Representations,

ICLR 2019, New Orleans, LA, USA, May 6-9, 2019.

OpenReview.net.

Resilience of GANs against Adversarial Attacks

397
