Tick Tock Break the Clock: Breaking CAPTCHAs on the Darkweb

David Holm Audran, Marcus Braunschweig Andersen, Mark Højer Hansen, Mikkel Møller Andersen,

Thomas B. Frederiksen, Kasper H. Hansen, Dimitrios Georgoulias and Emmanouil Vasilomanolakis

Aalborg University, Copenhagen, Denmark

Keywords:

Darkweb, CAPTCHA, Web Crawler, Machine Learning, Darkweb Marketplace, Darkweb Forum.

Abstract:

Nowadays, almost all major websites employ CAPTCHAs. This prevents website scraping, fake account

creation as well as DDoS or bruteforce attacks. For anonymity reasons, mainstream CAPTCHAs such as

Google’s reCAPTCHA cannot be used on the darkweb. Due to the evolution of machine learning and com-

puter vision, the CAPTCHA challenges used there, such as the clock CAPTCHA, are usually more arduous

than those found on the clearweb. This paper presents an automated system that uses machine learning to

break clock CAPTCHA challenges with a high success rate. We evaluate our system in a real world setting

against 725 clock challenges from live darkweb marketplaces. Our results show an accuracy of 96.83% while

maintaining low time requirements while analyzing, predicting and submitting the CAPTCHA solution.

1 INTRODUCTION

CAPTCHAs are widely used around the web to pre-

vent an assortment of attacks such as DDoS, web

crawling or creation of fake accounts. Since their in-

ception in 1996 (Guerar et al., 2021) a long range of

technologies have been developed. To attempt break-

ing these, a great deal of computer vision technologies

have been utilized as the majority of CAPTCHAs are

image-based. Accompanying this, machine learning

can now be used as it greatly increases the comput-

ers’ chance to successfully solve such a puzzle.

The advancements of the aforementioned tech-

nologies, and especially of machine learning, have

deprecated many CAPTCHA models. Despite the is-

sues this may present, it also creates an invitation for

creating new, more arduous models, that can distin-

guish a human from a machine. There is an ongoing

arms race, where one side is trying to create resilient

CAPTCHAs, while the other side is trying to break

them. This is also the case on the darkweb.

The CAPTCHAs found on the darkweb differ

from those on the clearweb since the desire to re-

main anonymous restricts which models can be used.

Newer CAPTCHAs, such as reCAPTCHA, require a

connection to Google services to check information

about the client, and is therefore not a viable choice

for darkweb sites. This has in turn increased the effort

put into making different types of CAPTCHAs to be

utilized on the darkweb (Georgoulias et al., 2021).

Using machine learning to develop a model that

can successfully solve CAPTCHA challenges re-

quires a labelled data set containing examples of

the CAPTCHA and corresponding answers. Such

supervised machine learning approaches cannot be

trained without proper labelled data. To fulﬁll this re-

quirement the CAPTCHA could be downloaded and

the answer manually ﬁlled in, however this could

take a lot of time depending on the amount of data

needed. Therefore having access to the source code

of the CAPTCHA can automate its generation. How-

ever, in most cases, especially on the darkweb, the

CAPTCHA code generation is proprietary and has to

be reverse engineered. Furthermore when utilizing

machine learning models, the model produced can be

limited to solve only one type of CAPTCHA. A small

modiﬁcation to the CAPTCHA algorithm might ren-

der the machine learning model highly ineffective.

A predominant darkweb CAPTCHA scheme is the

so-called clock CAPTCHA (Georgoulias et al., 2021)

(see Figure 1). The challenge is to correctly submit

the time of an analogue clock that contains several

misleading geometric shapes in under 60 seconds.

The clock comes in different variations, however the

general idea is the same. To this day, no method of

breaking the clock scheme has been developed and

disclosed. The main goal of this work is to break the

basic version of the clock CAPTCHA scheme along

with one variation, utilizing machine learning. To

achieve this goal we use the deep learning architecture

Audran, D., Andersen, M., Hansen, M., Andersen, M., Frederiksen, T., Hansen, K., Georgoulias, D. and Vasilomanolakis, E.

Tick Tock Break the Clock: Breaking CAPTCHAs on the Darkweb.

DOI: 10.5220/0011273300003283

In Proceedings of the 19th International Conference on Security and Cryptography (SECRYPT 2022), pages 357-365

ISBN: 978-989-758-590-6; ISSN: 2184-7711

357

ResNet50 to create a model which is able to predict

the time of the clock CAPTCHA given an image of it.

In addition, a web scraper is built providing the abil-

ity to automatically solve a challenge using the trained

model in real time on a Tor hidden service. We limit

ourselves and do not further expand our work on ad-

ditional clock variations, since it would prove to be a

never ending task, due to the highly dynamic nature

of the darkweb.

One major challenge when attempting to automate

data collection from platforms on the darkweb, is by-

passing the Distributing Denial of Service (DDoS)

protection mechanisms. Darkweb marketplaces and

vendor shops utilize CAPTCHAs with the goal of tak-

ing away the automation capabilities of web crawlers

(Soska and Christin, 2015). In essence, these mecha-

nisms are put in place to force individuals into man-

ually providing responses to challenges. This can

be a time-consuming task, especially when attempt-

ing to deploy crawlers in multiple platforms simul-

taneously, making the entire process of data collec-

tion challenging. Successfully bypassing these mech-

anisms in an automated manner, provides ease and

speed to the process, making research efforts more ef-

fective. Hence, we note that our work is only intended

for assisting researchers and the developed system is

available to researchers upon request, due to ethical

considerations (see Section 2).

In this paper we show that: i) It is possible to

develop a machine learning model to correctly solve

the clock CAPTCHA with 96.83% accuracy; ii) the

developed model can be utilized by a web scraper

to access services using the clock CAPTCHA, in a

timely manner; iii) the developed model can easily be

adapted to incorporate modiﬁed versions of the clock

while maintaining high accuracy.

2 ETHICAL ISSUES

In this section we want to address the ethical issues

associated with this paper. Our work is not intended

to be used in takedown attempts against the platforms

implementing the showcased CAPTCHAs, since lit-

erature characterizes them as a non-violent alternative

to street drug trafﬁcking (Martin and Christin, 2016).

Instead, our goal is to illustrate that solving the clock

CAPTCHA can be automated, and then utilized by a

web crawler to further automate data harvesting for

research purposes.

With regard to the site access, the marketplaces

that were part of our study are both publicly available

and free to access. Furthermore, we want to point out

that we did not in any way hinder the operation of any

of these platforms, or the experience of their users. In

order to complete our experiments, we only used site

mechanisms that are available to all users, and in a

manner that did not consume any additional resources

from the marketplaces’ side. Lastly, our research did

not involve any kind of user private data, hence there

is no risk of exposing the identity or private informa-

tion of any individuals.

3 BACKGROUND AND RELATED

WORK

Even though CAPTCHAs on the clearweb and the

darkweb have inherent differences, the methods for

breaking CAPTCHAs are the same in both domains.

Such methods, can be categorized in the following

three categories: machine learning methods, non ma-

chine learning methods and hybrid methods.

3.1 Machine Learning Methods

The development of deep learning has resulted in

great advances in CAPTCHA breaking. Challenges

previously deemed impossible for computers to solve

(e.g. advanced image recognition) are now solvable.

(Noury and Rezaei, 2020) showed a method for

breaking text-based CAPTCHAs of a ﬁxed length us-

ing convolutional neural networks, achieving up to

98.94% accuracy. Similarly, a deep learning method

for breaking text-based CAPTCHAs are described by

(Tang et al., 2018), where convolutional layers are

combined with max-pooling layers.

When it comes to breaking image-based

CAPTCHAs, sophisticated deep learning meth-

ods are necessary. Mittal et al. (Mittal et al., 2018)

describe a method for breaking a CAPTCHA using

the Inception V3 image recognition model, achieving

a mean accuracy of 91% in real time.

Another example of using deep learning to break

an image based CAPTCHA, is by (Hossen and Hei,

2021) using the neural-network ResNet18 architec-

ture. The authors utilize a pre-trained instance of

the model, that is trained using the ImageNet

data

set. This minimizes the required training needed for

the speciﬁc challenge. The focus of Hossen and Hei

was to provide a low-cost method for breaking the

CAPTCHA system, and they only required 143 min-

utes of training. They achieved an accuracy of 88% on

the test set. Additionally, they achieved an accuracy

of 95.93%, when providing the model with real-world

examples of challenges.

https://www.image-net.org/

SECRYPT 2022 - 19th International Conference on Security and Cryptography

358

3.2 Non Machine Learning Methods

While it is not widespread to apply non machine

learning methods for breaking CAPTCHAs, there

have been attempts using optical character recog-

nition (OCR). (Csuka and Gaastra, 2018) propose

a method using the OCR engine Tesseract (Smith,

2007) for breaking text-based CAPTCHAs on the

darkweb. They describe the performance of this

method as inferior to the applied machine learning

method in terms of success rate, but it does operate

faster and provides immediacy compared to the ma-

chine learning method.

According to (Weng et al., 2019) another non ma-

chine learning method for malicious activity, is using

underground CAPTCHA solving services. These ser-

vices consists of large amount of human labor solving

CAPTCHAs in exchange for money.

3.3 Hybrid Methods

Any information the computer is able to retrieve

or extract on the CAPTCHA challenge at hand im-

proves the accuracy of the computers decision. A

method used by (Sivakorn et al., 2016) aimed at

breaking Google’s widely used reCAPTCHA (Shet,

2014) utilised both deep learning methods and

Google’s own reverse image search engine. The chal-

lenge presented by reCAPTCHA is an image-based

CAPTCHA, as described in Section 3.4 of this paper.

The solution to breaking this, presented by (Sivakorn

et al., 2016), consists of modules, that each assigns

labels to an image. Most of the modules are deep

learning based, but one of the modules is the Google

reverse image search engine. The tags and labels pro-

vided by each module are then compared, and a deci-

sion for each image in the challenge is made.

3.4 Darkweb CAPTCHAs

CAPTCHA schemes like Google’s reCAPTCHA can-

not be used on the darkweb, due to anonymity is-

sues. For this reason, more traditional CAPTCHA

scheme types are used. The most prominent

ones being image-based CAPTCHAs and text-based

CAPTCHAs (Georgoulias et al., 2021).

Text-based CAPTCHAs present an image of a

string of random letters, with the goal being for the

user to identify each letter. The images are often

obscured, colored or blurred, to make it harder for

machines to recognize the letters, but still remaining

fairly easy for a human.

Image-based CAPTCHAs work by presenting a

question and a set of images to the user, and then

requiring the user to pick an image/images thereof,

that correspond to the question asked (Alqahtani and

Alsulaiman, 2020). Alternatively, the user might be

presented with a single image and are then required

to answer the question by describing the image or

its contents usually by picking from a set of options.

The images shown are usually in poor quality and/or

have shapes, lines or gibberish text that are easy for

a person to distinguish from but hard for a machine.

Image-based CAPTCHAs are considered to be the

most advanced and secure type of CAPTCHA, as it

is based on image details, which makes it hard for a

machine to solve (Brodi

c et al., 2016).

(a) Dread

forum clock

(b) Cartel

marketplace clock

Figure 1: Three variations of the clock CAPTCHA in the

darkweb.

The CAPTCHAs found on the darkweb, although

using these traditional ideas, have been improved

upon, making them more innovative than the ones

found on the clearweb. One of the most predomi-

nant schemes can be found on Figure 1, which illus-

trates different adaptations of the clock CAPTCHA.

To solve the scheme, the correct time must be se-

lected within a certain time frame. The challenge for

machines being to distinguish the patterns and shapes

from the clock’s pointers. This type of image-based

CAPTCHA is widely adopted on darkweb market-

places, with some variations depending on the hidden

service. Two well-known hidden services the Dread

forum and the White House Market have provided

a public GitHub repository with code for what they

call “EndGame V2 - Onion Service DDOS Preven-

tion Front System”

. This system provides several

services with one of them being the clock CAPTCHA

scheme as seen on Figure 1. Due to this variation

being publicly available, it is one of the more com-

monly used. Other variations can be seen on Figures

1 and 1. The clock found on the Cartel marketplace

differentiates by having a different background with

patterns as well as placing shapes around the center.

The Cocorico marketplace, places the url of the site

horizontally across the middle of the clock, which is

a technique often used on darkweb CAPTCHAs.

https://github.com/onionltd/EndGame

Tick Tock Break the Clock: Breaking CAPTCHAs on the Darkweb

359

4 THREAT MODEL

In this section we discuss the threat model followed in

this paper in terms of the capabilities of the attacker

and the required accuracy of an attack to be consid-

ered practically successful.

4.1 Attacker Capabilities

We assume that the attacker is able to produce labelled

data for the supervised machine learning algorithm.

This assumption comes with the limitation that with-

out labelled data the whole process would require sig-

niﬁcant manual work.

Moreover, we assume that the attacker is able to

both contact the (Tor) hidden service of the target

website and is also able to download an image of

the CAPTCHA clock. Furthermore, on the one hand

the attacker requires high computational power (es-

pecially RAM) to be able to train the residual neu-

ral network that we will be utilizing in this paper.

On the other hand, upon training the model, the at-

tacker is able to run the prediction on a typical com-

puter with no signiﬁcant computational capabilities.

In that sense, and excluding the training phase, our

threat model follows the work of (Bock et al., 2017).

4.2 Attack Accuracy

The deﬁnition of when a CAPTCHA scheme is con-

sidered broken is not simple. The debate for this is

very opinionated and no deﬁnitive accuracy threshold

has been agreed upon (Bursztein and Bethard, 2009).

When designing a CAPTCHA scheme the original

design goal states that ”automatic scripts should not

be more successful than 1 in 10000 attempts”, which

equates to an accuracy of 0.01% (Chellapilla et al.,

2005). This is widely regarded as too ambitious, as

random guesses would be able to reach an accuracy

higher than this. Instead, many regard 1% accuracy

to be the threshold, as the accuracy of random guesses

would be within the acceptable margin, and therefore

not able to deem the scheme broken (Bursztein et al.,

2011). Others argue that 5%, or even higher percent-

ages, are more reasonable (Baecher et al., 2010).

For attackers aiming at breaking CAPTCHAs, the

accuracy goal is usually a lot higher. (Hossen and

Hei, 2021) present an accuracy goal of above 50%,

aiming at developing a low-cost attack against the

hCaptcha system. (Aboufadel et al., 2005) state that a

CAPTCHA is considered broken if a computer algo-

rithm can solve the scheme 4 out of 5 times on aver-

age, implying an accuracy goal of above 80%.

In reality, the viable accuracy is dependent on the

amount of resources the attacker possesses and the

cost of the attack (Bock et al., 2017). An attacker

with many resources, that would be able to attack

the CAPTCHA scheme tens or hundreds of thousands

times, might only need an accuracy of 1% for the at-

tack to be worthwhile. Similarly, an attacker with lim-

ited resources might need an accuracy of above 50%

to even consider the attack.

Furthermore, many darkweb sites implement a

lockout function, that blacklists the user if the

CAPTCHA scheme has been failed three times. This

obstacle demands a certain level of accuracy of the at-

tack, for it to be viable to use in automation, i.e., with

a web scraper.

Based on the aforementioned previous work and

the fact that in most darkweb marketplaces and fo-

rums one can try to solve a CAPTCHA at least twice

before being blacklisted we expect an accuracy higher

than 80% to be more than satisfactory. For a 80%

model success rate and the user having 2 attempts

to successfully solve the CAPTCHA, the probability

P of a crawler providing the correct solution at least

once is calculated at 96% :

P(SucceedAtLeastOnce) = 1 −P(FailBothAttempts)

= 1 − 1

Fail ∗ 2

Fail

= 1 − 20% ∗ 20%

= 96%

5 SYSTEM OVERVIEW

Our automated CAPTCHA breaking system solves

the darkweb clock scheme using machine learning.

The system can be reduced into three main steps: i)

model setup, ii) model training and iii) model usage.

2. The ﬁrst two steps take place on an AI cloud, where

Figure 2: Architectural overview of the entire CAPTCHA

breaking system.

the model is set up and trained with the generated pic-

tures. The AI Cloud is a separate system, which is uti-

lized due to the computational resources it provides.

The model is then downloaded and saved to a local

computer. On the local computer the model is used

by the scraper, which connects to a Tor site, that uses

the clock CAPTCHA. The scraper downloads the im-

age from the CAPTCHA and predicts the answer to it,

using the model from the AI Cloud. The architectural

overview of the system is visualized in Figure The

SECRYPT 2022 - 19th International Conference on Security and Cryptography

360

system depends on two different programming envi-

ronments. The image generation is C++ code, based

on the Lua code found in the EndGame repository,

and the machine learning training and web scraper

is created in Python. The aforementioned individual

steps are elaborated in the following sections.

6 ResNet50 VS THE DARKWEB

CLOCK CAPTCHA

In this section we go over the details that surround

setting up, training, and using the model.

6.1 Setting up the Model

We divide the model assembly into 3 distinct proce-

dures: the data generation, preprocessing, and the use

of ResNet50.

6.1.1 Data Generation

In order to obtain labeled data, the code for the clock

CAPTCHA was extracted from the EndGame code

base mentioned in Section 3.4 and rewritten into a

C++ program with additional functionality. The pro-

gram is able to generate PNG clock images along with

a text ﬁle containing the time shown on each of the

generated clocks. The program has the ability to gen-

erate both the clock from the code base, and the clock

found on the Cartel marketplace, as seen on Figure

1. The program takes two arguments, where the ﬁrst

argument is the number of iterations. One iteration

will generate 720 images for each of the two clock

types. Hereof the number 720 stems from the fact

that an analogue clock is divided into 12 hours and 60

minutes, amounting to 12 ∗ 60 = 720 different clock

hand positions. The program will generate an image

for each of these possibilities. The second argument

should be either 0, 1 or 2, and will determine if the

program should generate the Dread forum clock (0),

the Cartel marketplace clock (1), or both (2).

6.1.2 Preprocessing

In order for the model to be able to train on the gen-

erated data, it is ﬁrst necessary to preprocess the im-

ages. First, the images are loaded along with the cor-

responding labels. We decided to retain as much in-

formation as possible from the images, and therefore

kept all 3 RGB channels in the picture instead of con-

verting them to e.g., greyscale. The size of the image

is then re-scaled to ensure that it is 190x190 pixels,

as that is the size used in most cases in the darkweb.

The images are then normalized, changing the pixel

intensity range values from 0 − 255 to 0 − 1. This

makes it easier for the model to converge, and limits

the amount of zero-gradients during training.

6.1.3 Using ResNet50

To solve the clock CAPTCHA we use a residual neu-

ral network. The challenge lies withing accurately de-

termining the time on the clock, which has 720 pos-

sible solutions. Therefore, the type of deep learning

problem is a multi-class classiﬁcation problem with

720 classes, with one class per possible time on the

clock. Provided a CAPTCHA challenge, the classiﬁer

generates 720 probabilities, each giving how likely

the corresponding class is for the provided challenge.

With this list of probabilities, it is then possible to ex-

tract the highest one to ﬁnd the classiﬁers best guess

for a solution to the challenge.

The architecture we have chosen to use is the

ResNet50 architecture. This architecture consists of

an initial convolutional layer followed by a max pool-

ing layer, 48 convolutional layers divided into resid-

ual building blocks with 3 layers in each, aw well

as an average pooling layer. Moreover, we added a

dropout layer with a rate of 0.7, that randomly sets in-

puts to 0, with a frequency of the rate at each step

This aids in avoiding over-ﬁtting the model, essen-

tially dropping some information randomly during

training. In addition, a ﬁnal dense layer is added,

mapping the output of the ﬁnal layer to the number

of possible classes, in our case 720, using softmax ac-

tivation.

The entire implementation of our deep learning

model is implemented in Python using the Keras

API

. Keras provides both an untrained and trained

version of the ResNet50 architecture. We utilized the

untrained architecture and performed the necessary

alterations of it to suit our challenge.

6.2 Training the Model

Training of a deep residual network is a complex and

resource heavy task, which can take a long time. The

model used in this paper builds upon the ResNet ar-

chitecture, and is trained on an AI Cloud with opti-

mized hardware for this speciﬁc task. The node which

training has been performed on contains 96 ’Intel(R)

Xeon(R) Platinum 8168 CPU @2.70GHZ’ CPUs, has

128GB RAM allocated and utilizes two ’Tesla V100-

SXM3-32GB’ GPUs to parallelize the training. Being

https://keras.io/api/layers/regularization layers/

dropout/

https://keras.io/

Tick Tock Break the Clock: Breaking CAPTCHAs on the Darkweb

361

able to utilize hardware this powerful cut the other-

wise long training phase very short.

While training the deep learning model, we found

that a batch size of 64 gave the best results. In order to

optimally utilize the GPUs available to us for training,

the batch size is scaled up according to the number of

GPUs, giving each GPU the intended batch size to

work with. The same is done for the learning rate.

The dataset used consists of 72, 000 samples, and

is split into 80% for training and 20% for testing. The

training set is split up further, using 20% as the vali-

dation set. The reasoning behind this, is with access

to the publicly available source code used for gen-

erating the CAPTCHA challenge we are attacking,

we solved the challenge of data collection by being

able to generate our own labelled data automatically.

This allowed for the generation of perfectly balanced

datasets of any size, that are identical to the data the

model would be faced with in the evaluation and test-

ing phase. Furthermore the whole dataset is shufﬂed

before being split up into training and test sets, to en-

sure that every class is represented in each of the sets.

The metrics the model is judged by is the loss and

the accuracy. The loss is sparse categorical cross en-

tropy loss, a function used to calculate the loss of the

predictions made by the model in its current state,

compared to the true labels. The loss is used to indi-

cate to the model, how well it predicted in the current

iteration of training. The categorical cross entropy for

n number of predictions, is deﬁned as:

Loss = −

∑

i=1

· log ˆy

(1)

where y

is the actual label, and ˆy

is the prediction

made by the model. The accuracy is standard classi-

ﬁcation accuracy, i.e., the number of accurate predic-

tions divided by the total number of predictions. The

reasoning behind using standard classiﬁcation accu-

racy is that the dataset which the model builds upon is

equally distributed among all possible classiﬁcations.

Three different models have been trained on the

AI Cloud. Initially our focus was the model with the

most generic type of the clock, as seen on Figure 1.

The ﬁrst edition of the model was only trained on

the Endgame variation of the clock. The results from

the Dread forum clock showed a high accuracy and

low loss (see Table 1). However, when tested against

the clock variations illustrated on Figures 1 and 1, the

model was unsuccessful. At that point it was obvious

that the slightest changes in the clock resulted in the

performance of the model deteriorating drastically. To

combat this, but to also test the adaptability of the

model training approach to modiﬁed versions of the

clock, clocks like the one found on the Cartel market-

place had to be generated. After analyzing the proper-

ties of the speciﬁc clock variation, and modifying the

clock generation code, we were able to successfully

generate these as well. Hence, we decided to build a

combined model for two clock types which is trained

on a equally distributed amount of both clocks at a 1:1

ratio, 36, 000 samples of each. The training was set to

200 epochs, with early stopping if the validation loss

reaches a lower value than 0.05, using the Adam opti-

mizer (Kingma and Ba, 2014) with a learning rate of

0.0001. Training on the generic clock alone lasted

for 708 seconds, reaching 11 epochs. Training on

the Cartel marketplace clock lasted for 301 seconds,

reaching 4 epochs. Training on the combined model

lasted for 759 seconds, reaching 12 epochs. The re-

sults of the training can be seen in Table 1.

Table 1: Overview of the performance of the different mod-

els on the test set.

Model Accuracy Loss

Dread Forum Clock 0.992 0.029

Cartel Marketplace Clock 0.996 0.025

Combined 0.988 0.048

6.3 Using the Model

To use the model a web scraper was developed ca-

pable of navigating to a given list of URLs either

via direct input or via reading the URLs from a text

ﬁle. The scraper loads the machine learning model

and utilizes Selenium

to open a web browser and

navigate to the site. The browser chosen in this case

was Google Chrome which does not support Tor na-

tively however does support utilizing a proxy to con-

nect with. A Tor proxy was therefore set up on the

default 9050 port. After connecting the webdriver

which selenium operates by, the browser navigates

to the site requested. As most of these sites con-

tain a queuing system to avoid DDoS attacks, it waits

until the clock CAPTCHA appears on screen before

continuing. Once this happens the scraper ﬁnds the

clock image, downloads it, resizes it to 190x190 pix-

els, passes it into the model and awaits its response.

Finally, the scraper passes the response to the site and

clicks the submit button. If the prediction is accu-

rate, the CAPTCHA is bypassed successfully. If the

model produces an incorrect result, the site generates

a new clock challenge and the procedure is repeated.

Should this result also be incorrect, the scraper exits

the site, since after the third incorrect submission the

Tor identity of the scraper will be banned from the

site. The scraper automatically detects whether or not

it was successful by checking if the CAPTCHA exists

https://www.selenium.dev/

SECRYPT 2022 - 19th International Conference on Security and Cryptography

362

after clicking the submit button. If not, it assumes it

has successfully bypassed the CAPTCHA mechanism

and navigated to the home page of the site.

The trained model, along with its weights is

loaded by the scraper using the Keras API. A function

in the Python script used to make predictions, is then

able to make a prediction for a single image, and re-

turn the numerical label as a tuple, in an hour/minute

format. It then utilizes a dictionary loaded from a

JSON ﬁle, containing the mapping of numerical la-

bels to actual labels, to convert the values.

To test the model we utilize the scraper on 9 pop-

ular darkweb websites, that either contain the Cartel

marketplace or the Dread Forum CAPTCHA clock

variation. Each website is visited 20 times, however

visits that experience connection errors are being ex-

cluded from the ﬁnal data set. The time measurements

are taken purely on the runtime of each metric, while

ignoring any time used on waiting in the DDoS queue,

connecting to the site, etc.

7 RESULTS AND DISCUSSION

To perform the evaluation of our deep learning model

we will be using the SKLearn Metrics module

which provides a function to write out a classiﬁcation

report. It provides the metrics precision, recall and

F1-score for each class in the data set, and an aver-

age for each metric across all classes. For each class,

Table 2: ResNet50 model performance test set.

Precision Recall F1-score Support

0:0 1.00 1.00 1.00 20

0:1 1.00 1.00 1.00 20

0:2 1.00 1.00 1.00 20

...

11:58 1.00 0.90 0.95 20

11:59 1.00 1.00 1.00 20

Accuracy 0.99 14400

Macro avg 0.99 0.99 0.99 14400

Weighted avg 0.99 0.99 0.99 14400

a true positive is correctly labelling the image as the

given class, and a false positive is labelling the image

as the given class even though it is not. A true neg-

ative is correctly not labelling the image as the given

class, and a false negative is incorrectly not labelling

the image as the given class.

The evaluation of our model will be performed on

a new labelled test data set consisting of 14, 400 im-

ages, with a combination of two different variations of

https://scikit-learn.org/stable/modules/generated/

sklearn.metrics.classiﬁcation report.html

the clock CAPTCHA. This test data set was balanced

with 10 instances of each possible class for both vari-

ations of the clocks. The evaluation was performed

on a standard computer with an Intel i5-4210U (1.70

GHz) CPU and 8GB of RAM, and the Ubuntu 20.04.3

LTS operating system.

The time required for this computer to load the

model, load all of the 14, 400 challenges and provide

a solution was 41 minutes and 44 seconds. This is

an average of 0.17 seconds for each prediction on a

standard computer. As shown in Table 2, our model

achieves an accuracy of 99% on the test data set,

and an average precision, recall and F1-score of 99%

across all classes.

7.1 Clocks in the Wild

The scraper was programmed with the functionality to

run in both a sequential and a parallel mode. The par-

allel mode utilizes a thread-pool allowing the scraper

to run on several sites at once. Nevertheless, due to

the fact that threads share resources, the time to solve

a CAPTCHA on a site is increased quite drastically.

7.1.1 Sequential Mode

In the sequential mode, the scraper performed very

well in both ﬁnding the CAPTCHA and inserting the

result as indicated in Figure 3. The scraper utilized

the combined model as described in Section 6.2 as

the initial Dread forum model was unable to bypass

the clock found on the Cartel marketplace (see Fig-

ure 1). As seen in Figure 3, the time spent by the

scraper to ﬁnd and download the image is about 0.05

seconds on average. The prediction itself averages at

0.12 seconds, and inserting the answer that the model

predicted takes 0.3 seconds, all in all resulting in a

scraper which can solve a clock CAPTCHA scheme

on a site in approximately 0.5 seconds on average.

Figure 3: Average runtime of the scraper in seconds, per site

and in sequential mode. The presented data were calculated

only from successful connections.

Tick Tock Break the Clock: Breaking CAPTCHAs on the Darkweb

363

7.1.2 Parallel Mode

In parallel mode, discovering the CAPTCHA image

and acquiring it took an average of 0.6 seconds, while

the prediction from the model averaged at 2.6 sec-

onds. Lastly, the result submission was executed in

approximately 3.6 seconds, contributing towards an

average total of 6.9 seconds, for the entire process

(see Figure 4). The parallel mode does also require

more computational resources, since Selenium opens

a new browser instance for each URL to scrape, while

the sequential mode opens a new tab in the same

browser instance. Hence, choosing the optimal mode

depends on the use case (e.g. commencing crawling

on one platform at a time, or several at the same time).

Figure 4: Average runtime of the scraper in seconds, per site

and in parallel mode. The presented data were calculated

only from successful connections.

7.1.3 Mode Comparison

Running the scraper in sequential mode on all 9 mar-

ketplaces is calculated at a total average of 4.5 sec-

onds, for all of the CAPTCHA challenges to be suc-

cessfully solved. In parallel mode, this number goes

up to 6.9 seconds and is equal to the average presented

on Figure 4, since in the speciﬁc mode this number

is already calculated with all of the CAPTCHAs be-

ing solved simultaneously. We consider these two av-

erages to be important since they provide an estima-

tion of the time a user would need to run the scraper

one platform at a time or on several platforms concur-

rently, without the identity of the platforms being a

factor. Furthermore, the disparity between the two re-

sults, is attributed to the aforementioned need for ad-

ditional computational resources that the scraper re-

quires when operating in parallel mode.

7.1.4 Scraper Evaluation

We tested our system by performing a total of 702

marketplace visits, both in parallel and sequential

mode. As shown on Table 3, the scraper had to per-

form an extra attempt to solve the challenge in 23 oc-

casions. This translates into the scraper being able to

solve the CAPTCHAs from the 679 remaining mar-

ketplace visits, on the ﬁrst try. The resulting number

of challenges solved amounts to a total of 725, with an

overall accuracy of 96.83% (702 out of 725). Lastly,

in all of the 702 visits, regardless of whether it took

one or two attempts, the scraper managed to provide

automated access to the platform via bypassing the

CAPTCHA mechanism in 100% of the cases.

The results described above were achieved on a

computer with an Intel(R) Core(TM) i7-6500U CPU

@ 2.50GHz and 8GB of RAM running the Parrot

Linux operating system version 5.0.

Table 3: Performance of the scraper.

CAPTCHAs Retries Accuracy Site Visits Success Rate

725 23 96.83% 702 100%

8 CONCLUSION

In this work, we present a high performance attack

on the clock CAPTCHA found on multiple darkweb

marketplaces and forums, utilizing a deep residual

machine learning model, trained with a self generated

dataset, on a high performance AI Cloud. The result

is a model achieving an F1-score of 0.99 on 14, 400

separately generated clock instances. Combining this

model with a web scraper, we successfully tested our

system against 725 CAPTCHA challenges, which be-

long to two different variations of the darkweb clock

CAPTCHA, with a 96.83% accuracy.

One limitation of this paper, is that our model is

over-ﬁtted, ﬁtting too closely to the training set and

thus does not perform well on unseen data. The cause

of this issue stems from the fact that the dataset is

uniform in terms of the clock image itself. The model

places great importance on the features of these spe-

ciﬁc clocks, hence modifying the target CAPTCHAs

results in a weaker performance of the model. How-

ever, we do illustrate that adapting the training data to

different variations of the clock, which we can easily

generate by modifying our data generation program,

is an effective solution to the over-ﬁtting problem.

This gives our automated CAPTCHA solving system

great adaptability for future changes.

Another limitation is that the training of a model

requires a lot of memory. Training on 72, 000 images

requires somewhere between 64 − 128GB of RAM,

which is not available on a standard computer. This

SECRYPT 2022 - 19th International Conference on Security and Cryptography

364

requirement of RAM stems from the individual im-

age ﬁle size including all RGB channels and the sheer

amount of images we used to train the model.

Lastly, with the goal of further improving our cur-

rent system, we also experimented with the Resnet18

architecture. We trained a new model using the ex-

act same parameters as we did with the Resnet50 ar-

chitecture and evaluated it with the SKLearn Met-

rics module. Our preliminary results suggest that the

model is able to achieve an accuracy of 100%, with

an average precision, recall and F1-score of 100%

across all classes, showing a lot of promise for future

implementations. Since Resnet18 is a signiﬁcantly

lighter architecture than Resnet50, we will focus on

this model in our future work.

REFERENCES

Aboufadel, E., Olsen, J., and Windle, J. (2005). Break-

ing the holiday inn priority club captcha. The College

Mathematics Journal, 36(2):101–108.

Alqahtani, F. H. and Alsulaiman, F. A. (2020). Is image-

based captcha secure against attacks based on machine

learning? an experimental study. Computers & Secu-

rity, 88:101635.

Baecher, P., Fischlin, M. G. L., Langenberg, R., L

utzow,

M., and Schr

oder, D. (2010). Captchas: The good, the

bad, and the ugly. Sicherheit 2010. Sicherheit, Schutz

und Zuverl

assigkeit.

Bock, K., Patel, D., Hughey, G., and Levin, D. (2017). un-

captcha: a low-resource defeat of recaptcha’s audio

challenge. In 11th {USENIX} Workshop on Offensive

Technologies ({WOOT} 17).

Brodi

c, D., Petrovska, S., Jevti

c, M., and Milivojevi

c, Z. N.

(2016). The inﬂuence of the captcha types to its solv-

ing times. In 2016 39th International Convention

on Information and Communication Technology, Elec-

tronics and Microelectronics (MIPRO), pages 1274–

1277.

Bursztein, E. and Bethard, S. (2009). Decaptcha: breaking

75% of ebay audio captchas. In Proceedings of the 3rd

USENIX conference on Offensive technologies, vol-

ume 1, page 8. USENIX Association.

Bursztein, E., Martin, M., and Mitchell, J. (2011). Text-

based captcha strengths and weaknesses. In Proceed-

ings of the 18th ACM conference on Computer and

communications security, pages 125–138.

Chellapilla, K., Larson, K., Simard, P. Y., and Czerwin-

ski, M. (2005). Building segmentation based human-

friendly human interaction proofs (hips). In Interna-

tional Workshop on Human Interactive Proofs, pages

1–26. Springer.

Csuka, K. and Gaastra, D. (2018). Breaking captchas on the

dark web.

Georgoulias, D., Pedersen, J. M., Falch, M., and Vasilo-

manolakis, E. (2021). A qualitative mapping of dark-

web marketplaces. In Symposium on Electronic Crime

Research (eCrime). IEEE.

Guerar, M., Verderame, L., Migliardi, M., Palmieri, F., and

Merlo, A. (2021). Gotta captcha ’em all: A survey

of twenty years of the human-or-computer dilemma.

2021-10-06.

Hossen, M. I. and Hei, X. (2021). A low-cost attack against

the hcaptcha system.

Kingma, D. P. and Ba, J. (2014). Adam: A method for

stochastic optimization. arXiv preprint: 1412.6980.

Martin, J. and Christin, N. (2016). Ethics in cryptomar-

ket research. International Journal of Drug Policy,

35:84–91.

Mittal, S., Kaushik, P., Hashmi, S., and Kumar, K. (2018).

Robust real time breaking of image captchas us-

ing inception v3 model. In 2018 Eleventh Inter-

national Conference on Contemporary Computing

(IC3), pages 1–5.

Noury, Z. and Rezaei, M. (2020). Deep-captcha: a deep

learning based CAPTCHA solver for vulnerability as-

sessment. CoRR, abs/2006.08296.

Shet, V. (2014). Are you a robot? introducing ”no captcha

recaptcha”. https://security.googleblog.com/2014/12/

are-you-robot-introducing-no-captcha.html.

Sivakorn, S., Polakis, J., and Keromytis, A. D. (2016). I’m

not a human : Breaking the google recaptcha.

Smith, R. (2007). An overview of the tesseract ocr engine.

In Ninth International Conference on Document Anal-

ysis and Recognition (ICDAR 2007), volume 2, pages

629–633.

Soska, K. and Christin, N. (2015). Measuring the lon-

gitudinal evolution of the online anonymous market-

place ecosystem. In 24th USENIX security symposium

(USENIX security 15), pages 33–48.

Tang, M., Gao, H., Zhang, Y., Liu, Y., Zhang, P., and

Wang, P. (2018). Research on deep learning tech-

niques in breaking text-based captchas and designing

image-based captcha. IEEE Transactions on Informa-

tion Forensics and Security, 13(10):2522–2537.

Weng, H., Zhao, B., Ji, S., Chen, J., Wang, T., He, Q.,

and Beyah, R. (2019). Towards understanding the

security of modern image captchas and underground

captcha-solving services. Big Data Mining and Ana-

lytics, 2(2):118–144.

Tick Tock Break the Clock: Breaking CAPTCHAs on the Darkweb

365
