An Adaptive Web Application Firewall

Miguel Calvo and Marta Beltr

Department of Computing, ETSII, Universidad Rey Juan Carlos, Madrid, Spain

Keywords:

Adaptive Controls, Risk-based Security, Web Application Firewall.

Abstract:

Web Application Firewalls (WAFs) are security products responsible for protecting web applications with

minimal cost and effort; by ﬁltering, monitoring, and blocking HTTP trafﬁc. Traditional WAFs work with

a rule-based approach, applying predetermined rules when the signatures of known attack patterns or trafﬁc

anomalies are identiﬁed. This kind of design has suffered signiﬁcant limitations in speciﬁc contexts since it is

impossible to conﬁgure the WAF the ﬁrst time and rely on that conﬁguration over time. This paper proposes

an adaptive WAF capable of context-aware risk-based adaptation, changing its conﬁguration to every speciﬁc

scenario, depending on the current value of risk indicators and on the level of risk tolerated at any given time.

The proposed solution is implemented, validated and evaluated in a real use case.

1 INTRODUCTION

Traditional Web Application Firewalls or WAFs work

the same way as traditional network ﬁrewalls: they

are rule-based security solutions, relying on a prede-

ﬁned set of rules that enable proper response when

the signature of a known attack pattern is detected, or

a trafﬁc anomaly is observed.

There are no one-rule-ﬁts-all scenarios in current

web applications security; no static conﬁguration is

general enough to cope with risk within all possible

situations. The variety and complexity of novel at-

tack patterns and threat agents lead organisations to

develop signiﬁcant efforts, therefore incurring high

labour costs, maintaining the WAFs rule-sets, and up-

dating attack signatures or legitimate trafﬁc patterns

(normal behaviour).

This paper proposes an intelligent and automated

approach to WAF adaptation, an adaptive WAF. With

a risk-based solution, security mitigations are ad-

justed to the asset’s environment and state and the risk

quantiﬁed or predicted at a given moment. The goal

is to change, autonomously, the behaviour of secu-

rity countermeasures by monitoring them (the WAF,

in our case), the protected asset (a web application)

and their operation context, quantifying the risk and

keeping it at the desired level.

The contributions of this paper are 1) The archi-

tecture of an Adaptation Tool based on a MAPE-K

feedback loop (Monitor-Analyze-Plan-Execute over a

shared Knowledge) capable of deciding if an adapta-

tion of the WAF is required and performing this adap-

tation when required. 2) The semantics of the policies

and rules that allows security managers and adminis-

trators to automate adaptation. 3) A prototype of this

Adaptation Tool that enables its validation and evalu-

ation within a real use case.

The rest of this paper is organised as follows. Sec-

tion 2 provides an overview of the background on un-

derlying concepts and the related work. Section 3

discusses the primary motivations for this work, with

some research challenges and opportunities. Section

4 describes the proposed architecture to add auto-

mated risk-based adaptation to Web Application Fire-

walls. Section 5 details the proposed solution im-

plementation, validation and evaluation. And ﬁnally,

Section 6 summarises our main conclusions and the

most interesting lines for future work.

2 BACKGROUND AND RELATED

WORK

2.1 On Web Application Firewalls

Security tools such as WAFs have been proposed to

protect websites, web applications, and web services.

These defensive solutions, like traditional ﬁrewalls,

offer an extra layer of protection by inspecting trafﬁc.

WAFs typically operate at the application layer of the

OSI (Open Systems Interconnection) model, inspect-

Calvo, M. and Beltrán, M.

An Adaptive Web Application Firewall.

DOI: 10.5220/0011146900003283

In Proceedings of the 19th International Conference on Security and Cryptography (SECRYPT 2022), pages 96-107

ISBN: 978-989-758-590-6; ISSN: 2184-7711

ing, mainly, HTTP trafﬁc. They are deployed between

the web server serving the website/application/service

and the Internet, acting as a shield and analysing re-

quests before responding to them and before trafﬁc

enters or leaves the web server. In this way, when

a potential attack is detected, the WAF itself apply

some kind of rule, for example, to block the request

so that it does not impact the protected asset (Garn

et al., 2021), (IS¸iker and So

Gukpinar, 2021).

There are mainly three types of WAF solutions:

signature-based WAFs, anomaly-based WAFs, and

Machine Learning-based WAFs. Signature-based

WAFs, the most common currently, require that the

attacks have previously occurred since they check the

trafﬁc searching for signatures associated with known

attack patterns. Therefore, they require a continuous

update of the signatures. And they are not capable

of identifying zero-day attacks. On the other hand,

anomaly-based WAFs require prior knowledge about

”normal” or ”legitimate” trafﬁc to/from the protected

web server. In this case, rules are applied, not when

the signature of a known attack is found but when an

anomaly is detected. Again, a continuous update of

normal or legitimate patterns is essential since the In-

ternet and its users’ behaviour evolve fast these days.

But if it is performed correctly, this kind of WAFs

are able to handle zero-day attacks. Finally, Machine

Learning-based WAFs use Machine Learning (ML) to

rely on models trained to overcome the limitations of

the rest of WAFs. A Machine Learning approach al-

lows a WAF to classify a request as malicious with-

out applying signature-matching or anomaly detec-

tion techniques. The goal is to decrease false pos-

itive and false negative rates while making it difﬁ-

cult for adversaries to cheat the WAF and reducing

the burden related to the WAF updates (signatures or

regular trafﬁc). But a Machine Learning model must

be trained and retrained (Applebaum et al., 2021),

(Babiker et al., 2018).

In recent years, research on WAF tools and their

improvement for the protection of web assets has

been focused mainly on applying Machine Learning

or Deep Learning to these solutions. In this sense,

to mention just some signiﬁcant examples, (Valenza

et al., 2020) proposes a mechanism that replaces poli-

cies with Machine Learning. (Domingues Junior and

Ebecken, 2021), on the other hand, proposes the eval-

uation of headers and URIs at a high level using

Machine Learning and classiﬁers applied to rule en-

gines such as ModSecurity; (Betarte et al., 2018),

and (Moradi Vartouni et al., 2015) proposals focus on

applying Machine Learning techniques based on ex-

pected n-gram frequencies to exploit WAFs, (Gogoi

et al., 2021) focuses on the detection of XSS attacks

through a WAF that uses Machine Learning. There

are also approaches, such as (Tekerek and Bay, 2019),

based on learning too but using Artiﬁcial Neural Net-

works. Another exciting research is shown in (Ito and

Iyatomi, 2018), which focuses on a WAF system to

identify malicious HTTP requests using a character-

level Convolutional Neural Network. The framework

proposed in (Shahid et al., 2022) combines a classi-

ﬁer based on Deep Learning and a cookie analysis

engine; (Tan and Hoai, 2021) proposes an original

mechanism, applicable to WAFs, in which HTTP re-

quests are transformed into anomalous univariate data

points.

2.2 On Risk-based Security

The rise of sophisticated web attacks and the wide

variety of new technologies and paradigms in recent

years (such as Industry 4.0, Cloud Computing or the

Internet of Things) have made conventional security

mechanisms insufﬁcient. It is necessary to explore

more intelligent and adaptive ones that protect differ-

ent types of assets in current infrastructures (Nafea

and Amin Almaiah, 2021), (Ande et al., 2020). It

is common to ﬁnd the term dynamic security among

these new solutions. This paradigm opens the door to

technologies capable of automatically reconﬁguring

and adapting when changes are detected in the envi-

ronment in which they operate, when speciﬁc threats

are detected, when the risk tolerated by the organisa-

tion changes, etc.

Two main categories can be found in previous

works in this research area. First, adaptive secu-

rity, which, depending on the environment or state,

is capable of modifying the architecture or behaviour

(Elkhodary and Whittle, 2007), (Djoudi et al., 2014),

(Boudko and Abie, 2019) of security controls and mit-

igations. Second, risk-based security, which focuses

on the analysis of the different risks that an organ-

isation’s assets may suffer and prioritising different

factors (such as the cost of mitigation, functionality,

quality of experience, etc.), can make the pertinent

changes to reduce that risk to an acceptable level.

In this way, risk-based security requires adequate

and constant monitoring and evaluation of risks and

the existence of prior planning. It is necessary to iden-

tify the assets and the threats that may arise to apply

this approach. It is also required to ﬁnd the existing

vulnerabilities and create the different risk proﬁles of

each asset or group, assigning them a score. Also, it

is necessary to decide how this risk will be handled

when it arises. The most signiﬁcant difﬁculty in these

tasks is usually quantifying the risk and translating the

score obtained into a balanced decision. In dynamic

An Adaptive Web Application Firewall

risk-based security solutions, decision-making is fre-

quently based on different metrics and indicators such

as IoCs (Indicators of Compromise), IoAs (Indicators

of Attack) or KRIs (Key Risk Indicator).

Focusing on current research on risk-based secu-

rity, we can see many proposals focused on identity

and access management for emerging technologies

and environments; for example, (Chen et al., 2016)

for Cloud, (Steinegger et al., 2016), for Web Applica-

tions, and (Martinelli et al., 2018) for IoT.

3 MOTIVATION, CHALLENGES

AND OPPORTUNITIES

As introduced in the previous section, Machine

Learning offers good results when applied to tradi-

tional WAFs, detecting zero-day attacks and avoiding

the requirement of continuous updates of signatures

and trafﬁc patterns. However, these solutions also

pose new challenges and difﬁculties, in many cases

hard to solve or requiring a high investment of human

and ﬁnancial resources and knowledge.

Among these difﬁculties, we can highlight the

large-scale optimisation problem. This setback is

largely observed when training some mathematical

models used in Machine Learning. In this sense,

training data poisoning is one of the biggest concerns

in the WAF detection line. It is tough to identify if the

data or information we use to train ML algorithms has

been manipulated. Poisoned or unreliable data may

cause both false positives and false negatives (Gam-

bella et al., 2021), (Sun et al., 2020).

Another signiﬁcant difﬁculty with ML applied to

WAFs is the need to retrain the models from time to

time and the computational cost required by many of

the techniques used for this task. In addition, it must

be taken into account that this retraining requires an

investment of time and human resources, as well as

the need to have datasets that meet the necessary ex-

pectations (Kumeno, 2019), (Schelter et al., 2018).

This research proposes an alternative approach,

an adaptive WAF capable of overcoming some lim-

itations observed in the traditional solutions without

adding ML and, therefore, avoiding all these difﬁcul-

ties. Approaches such as MAPE-K (Lara et al., 2019)

or (Calvo and Beltr

an, 2022) offer a new opportunity

that is able to substantially reduce the necessary re-

sources and costs, with effective results in terms of

dynamicity and adaptation capability. The rest of this

paper proposes the architecture of a new category of

WAF, the adaptive WAF or risk-based WAF.

Figure 1: Proposed architecture for the risk-based WAF.

4 PROPOSED ARCHITECTURE

4.1 Overview

The proposed approach to design a risk-based WAF

is to add the capability of adaptation from outside

the WAF, with a separation of concerns design strat-

egy. The WAF is still a WAF; the Adaptation Tool

is designed explicitly to perform adaptation. In this

way, the adaptation capabilities are generic and can

be added to any WAF-type product with which inte-

gration is possible. In addition, it avoids redesigning

existing WAFs by adding complexity and cost.

As it can be seen in ﬁgure 1, the proposed solution

works as follows:

1. The WAF administrator deﬁnes the different Mea-

surements that will enable the risk-based adapta-

tion of the WAF. These measurements (basic or

extended metrics and indicators or events) will be

sent from different sources (internal or external)

to the Decision element. These sources may be:

(a) The Environment. For example, external

sources such as social networks, third-party

threat intelligence, the status of other services

or servers outside the infrastructure, etc.

(b) The Asset (or assets) to protect. In this case,

the web server and the rest of the servers are

running the protected application or service.

tional layers added to the WAF to increase or

decrease performance or security. For example,

a load balancer or an anti-Distributed Denial of

Service solution (anti-DDoS).

2. When these measurements are received, they are

analysed to decide if a policy or rule should be

triggered.

3. If this is the case, these policies and rules de-

termine the adaptation that must be carried out;

SECRYPT 2022 - 19th International Conference on Security and Cryptography

therefore, the pertinent changes or modiﬁcations

to the “Control” (the WAF and/or the tools that

complement it) that must be performed. For ex-

ample, changing the WAF conﬁguration to start

working through allow-lists, adding a new secu-

rity layer such as anti-DDoS (anti-Distributed De-

nial of Service), etc. Integration with the adapted

WAF is required to perform these changes auto-

matically (via scripting, plugins, etc.).

4.2 Measurement

The adaptive WAF needs to quantify the risk to make

the right adaptation decisions at the right time. Com-

paring the risk taken or expected to be taken in the

future with the risk tolerance of the protected appli-

cation allows security measures to be relaxed or rein-

forced at any point in time. Several questions must

be asked: what we should measure, when should we

make the measurement, and which data sources are

available. It has to be considered that without a good

measurement strategy, the proposed solution loses ef-

fectiveness and could even become counterproductive

(false positives, false negatives, unnecessary adapta-

tions consuming resources, temporary blocks of ar-

chitecture, etc.).

These measurements, as already mentioned, can

be done in the assets to be protected (the application

and servers), in the control itself (in the WAF or any

other additional security layer) or in the environment.

In this way, and just to mention a few examples for

the collection and extraction of measurements, com-

mon data sources for the adaptive WAF will be logs

(at the application, servers, the WAF), trafﬁc analy-

sers, IDPS (Intrusion Detection and Prevention Sys-

tem) or SIEM (Security Information and Event Man-

agement), anti-malware solutions and endpoint pro-

tection systems, open sources (social networks, gov-

ernment data, press, information shared by other or-

ganisations) or threat hunting and intelligence prod-

ucts.

The speciﬁc measures to be performed by the

adaptive WAF will depend on each organisation’s spe-

ciﬁc objectives in securing the application or web ser-

vice with the WAF and its strategies for managing

risk. But some speciﬁc measures can be mentioned

in the context of WAFs:

• The number of HTTP requests received per pe-

riod.

• The number of HTTP errors (404, 500, etc.) per

period.

• The number of requests to malformed URIs

and/or unexpected URIs that are requested in a pe-

riod.

• Requests from IP addresses in a block-list and/or

from addresses that are not in the allow-list.

• Number of database queries per period.

• Number of UPDATE and/or DELETE functions

on the database per period.

• Number of simultaneously connected database

users.

• Volume of Tweets or other social network interac-

tions that mention a speciﬁc topic at a given time.

• Terrorist alert level of a country at a given time.

• Number of Distributed Denial of Service (DDoS)

attacks in a recent period.

How to quantify risk from these measures with

risk scores is beyond the scope of this paper, as are the

methods for deciding whether that risk is acceptable

or has changed sufﬁciently to justify an adaptation of

the WAF.

4.3 Decision

When risk-related metrics are received in the Deci-

sion element, they are analysed to know if their val-

ues must trigger any action. Therefore, although the

measurements may be frequent, the execution of poli-

cies and rules, i.e., verifying whether it is necessary to

carry out a WAF adaptation, is not performed with the

same assiduity. In this way, excessive consumption of

resources (CPU, memory) is avoided.

To understand decision-making, ﬁrst, it is neces-

sary to know the structure of the policies and the rules

deﬁned for the proposed solution.

• In the case of policies they state, mainly, the

“Adaptation conditions”. These break down into

different predicates (as many as required) com-

posed of one or more observable triggers and

states (as many as required with AND-OR oper-

ators) and one or more rules. A Trigger occurs

when a risk score or RS exceeds a certain thresh-

old or changes a certain degree, a State corre-

sponds with a situation, condition, the situation of

the conﬁguration of the asset or the control. For

example, you can see in table 1 a policy contain-

ing adaptation conditions from 1 to N, each one

expressed as a predicate. Predicate 1 states that

the observation of the Trigger1 (RiskScore1 > X)

leads to the execution of the adaptation rule A. In

the same way, the Predicate 2 states that the ob-

servation of the Trigger2 (RiskScore2 < Y ) leads

to the execution of the adaptation rule B and

the Predicate N states that the observation of the

StateN for the control leads to the execution of the

adaptation rule N

An Adaptive Web Application Firewall

Table 1: Policy deﬁnition.

Adaptation conditions:

Predicate 1: observed(Trigger1 when RS1

greaterThan X) → Rule A.

Predicate 2: observed(Trigger2 when RS2 small-

erThan Y) → Rule B.

Predicate N: observed(StateN) → Rule N.

• On the other hand, the rules (see table 2) mainly

contain timing and certain controls.

– Timing. Rules can be periodic, event-driven or

on-demand. Periodic rules activate with a timer

(periodically); event-driven activate only when

a speciﬁc event is observed; and, on-demand,

leave the rule on standby until an administrator

activates the control manually.

– Controls. They specify the action that is per-

formed to apply the adaptation. In addition,

they determine the artefact or mechanism that

can be used to connect the Adaptation Tool to

the WAF. For example, connection via SSH to a

control panel, connection via HTTP to the ser-

vice that increases security by adding an extra

layer, etc.

In this way, when a trigger is activated, it starts

the execution of the associated policies and checks the

rules linked to it. Once located, they are analysed:

• If a timer exists (periodic rule), the rule will con-

tinue its ﬂow when its period ﬁnishes.

• If the rule is event-driven, the rule will wait until

the event occurs. This event can be the trigger

that executed the policy in the ﬁrst place, but it

can also be a different one.

• If the rule is on-demand, the rule will wait un-

til the WAF administrator (who will be notiﬁed

by email, SMS or the decided way) intervenes to

continue with the ﬂow and carry out the actions

manually.

Regardless of the rule timing, when the rule is exe-

cuted, the speciﬁc actions to be carried out and the re-

quired artefacts will be extracted from the “Controls”

section. The actions summarise the required adapta-

tion and the script, conﬁguration, tool, etc., that must

be modiﬁed. The artefacts will be used to connect to

the WAF and perform the actions.

4.4 Adaptation

The adaptation of the WAF is achieved by perform-

ing different actions through components, plugins,

scripts, or pieces of code that will be executed in the

different elements of the WAF from the Adaptation

Table 2: Rule deﬁnition.

Timing:

Event: observed(TriggerM); or

On Demand: true/false; or

Timer: Adaptation period value (in seconds).

Controls:

Action: Script that will apply the adaptation.

Artefact: Mechanism used to connect to the

control.

Tool. These elements enable the proper modiﬁcations

of the adapted control, adding or removing security

layers, modifying the conﬁguration, etc. They de-

pend on the control to be adapted, i.e., on the speciﬁc

type/model of WAF.

Some examples of adaptations can be the activa-

tion or deactivation of the WAF, the addition or re-

moval of rules, the selection of allow-lists or block-

lists, the migration of a local WAF to a WAF as a Ser-

vice solution (or vice versa), the addition of an anti-

DDOS layer to the WAF, etc.

As mentioned before, WAF adaptations, once de-

cided, are performed through artefacts. These arte-

facts are responsible for communicating the Adapta-

tion Tool to the different elements of the WAF and

facilitating reuse. They are connectors or generic con-

nection mechanisms such as SSH connections, HTTP

connections, speciﬁc APIs, etc.

5 PROTOTYPE, VALIDATION

AND EVALUATION

A prototype of the proposed adaptive WAF has been

implemented to protect a web asset. The protected

website consists of an afﬁliate store of products sold

by other stores. Administrators register different

products (with their associated information: title,

description, price, characteristics, photographs, etc.)

and a personal evaluation of the product (highlighting

its qualities and drawbacks). In addition, users who

visit the web can buy the product through an afﬁliate

link, which redirects them to the stores that sell the

product. This redirection, generated with a particular

link, reports a small beneﬁt for each sale.

The web application is developed using Vue.js,

NodeJS and MySQL technologies. It is deployed on

two different servers (each with Ubuntu Server 20.04

operating system, 2 vCores, 2 GB of RAM and 80 GB

of hard drive). The ﬁrst (with a Nginx web server in-

stalled) is responsible for hosting both the frontend

and the backend of the application and, therefore,

is the user’s gateway to the application; the second

(with MySQL Community Server installed) contains

SECRYPT 2022 - 19th International Conference on Security and Cryptography

100

the database server where, among other things, all the

information associated with the different products dis-

played in the afﬁliate store is stored.

The store is made up of three main pages:

• A list of all the existing products

in the database (accessible through

https://example.com/products; includes pagi-

nation, to avoid returning all the products at

once).

• The one that shows the information

of each product (accessible through

https://example.com/product/ID, where each

of the product identiﬁers replaces ID).

• A last one to facilitate the search for

users who use the web (accessible through

https://example.com/search; the different search

parameters are sent by a POST method).

The WAF protecting this site is ModSecurity (Spi-

derLabs, 2022), an open source web application ﬁre-

wall. The choice has been supported by a large

amount of existing documentation and the ease of use,

the ﬂexibility offered by this WAF and, of course, the

possibility of integrating it with the application to be

protected and the web server that serves it (the v3 is

used to have the standalone engine built from scratch

in C++ easily integrated into Nginx). This solution

provides real-time monitoring, logging, and ﬁltering

of HTTP requests based on user-deﬁned rules written

in a rule conﬁguration language named SecRules.

The WAF is installed and conﬁgured on the same

server that hosts the backend and frontend of the ap-

plication, relying on signature-based detection. The

limitations of this WAF in the considered scenario are

that with a relaxed conﬁguration of the rules, few at-

tacks are blocked while with a restrictive conﬁgura-

tion, this blocking rate increases at the cost of block-

ing many of the legitimate requests made by users.

Finally, the proposed Adaptation Tool prototype is

hosted on a separate server with Ubuntu Server 20.04

Operating System, 2 vCores, 2 GB of RAM, and

80 GB of hard drive. This server is on the same in-

ternal network as the web server and database server.

5.1 Implementation

The prototype implementation is illustrated in ﬁgure

2. First, it is worth highlighting the measurements

selected to decide about the WAF adaptation. These

measurements come from three different data sources

(regarding the asset and the environment), speciﬁ-

cally:

• On the one hand, HTTP requests of type 400

(internal measurement). This information is ex-

Figure 2: Prototype implementation.

tracted from the Nginx server logs and sent to the

decision element every minute. The metric con-

sists of a numerical value corresponding to the

number of new HTTP requests of type 400 per

minute. A small Python script has been developed

that reads the information from the Nginx log in

real-time and sends it via HTTP to the server host-

ing the Adaptation Tool.

• Another required measurement is the resource

consumption (CPU and RAM memory) at the web

server. The information is extracted from the

server itself and consists of two numerical values

corresponding to the percentage of CPU and the

percentage of RAM memory that has been con-

sumed, on average, in the last hour. To extract

these metrics, a Python script is executed at the

web server, making periodic measurements and

sending the information via HTTP to the server

hosting the Adaptation Tool.

• On the other hand, tweets that contain a shop URL

(external measurement). This information is ex-

tracted by a script that relies on the Twitter API. It

analyses the information, in real-time, in search of

Tweets that contain a URL belonging to the pro-

tected website. The metric submitted to the deci-

sion element consists, in this case, of a numerical

value that corresponds to the number of new ap-

pearances on Twitter per hour; it is sent via HTTP

to the server hosting the Adaptation Tool.

In this way, the Decision element receives the

number of HTTP requests of type 400 per minute,

the resources average consumption in the last hour

(CPU and RAM) and the number of tweets that con-

tain a shop URL per hour. This information is re-

An Adaptive Web Application Firewall

101

ceived through a web service (created in NodeJS) and

stored in a MySQL database (deployed on the server

where the Adaptation Tool is located).

The service itself, each time it receives a metric

obtained from new measurements, checks to see if

they are within the thresholds set by the WAF admin-

istrator and the security manager. A 400 “Bad Re-

quest” is an HTTP response status code that indicates

that the server is unable to process the request sent by

the client due to invalid syntax. If an adversary is try-

ing to perform an SQL injection attack or is trying to

scrape data from the store, all the IDs are likely gone

through, leading to numerous errors. Therefore, it is

considered in this use case as a risk indicator. The

number of URLs linked from Twitter may work, on

the other hand, as a risk indicator of a Distributed De-

nial of Service attack (DDoS), qualiﬁed by the con-

sumption of resources at the web server. Therefore:

• For HTTP requests of type 400, a trigger is

launched (and policies will be analysed) when 50

requests per minute are exceeded. The opposite

trigger is launched when this value ins below 50.

In this way, the WAF can be adapted to apply

more or less restrictive conﬁgurations depending

on this measurement (risk indicator).

• For Tweets with URLs, a trigger is launched when

the number of tweets per hour exceeds 100. But

the adaptation to a restricting conﬁguration can be

relaxed if the resource consumption at the server

is not of concern.

In this prototype, two policies and four rules have

been deﬁned:

• Policy 1. This policy is activated when: (1) It

is detected that HTTP requests of type 400 ex-

ceed the conﬁgured threshold and the WAF is not

working in “allow-list” mode; (2) It is detected

that the type 400 HTTP requests fall below the

established threshold for more than 30 measure-

ment periods (over 30 minutes) and, in addition,

the WAF is working in the allow-list mode. As

a result of the ﬁrst activation, rule 1 applies, and

because of the second, rule 2 applies. Table 3

shows this policy with the format proposed in ta-

ble 1, where Trigger1 (HIGH-HTTP 400 Cod) is

observed each time HTTP requests of type 400 per

minute > 50, State1 (OFF-WAF-ALLOWLIST)

is observed when the WAF is not in the “allow-

list” mode, Trigger2 (LOW-HTTP 400 Cod) is

observed each time HTTP requests of type 400 per

minute < 50 during 30 minutes and State2 (ON-

WAF-ALLOWLIST) is observed when the WAF

is in the “allow-list” mode.

– Rule 1. The ﬁrst rule associated with policy

1 is executed, following the timing conﬁgured

by the administrator (“Timing” section of the

rule), when the same event that triggered the re-

lated policy occurs (exceeding the threshold for

HTTP requests type 400). Therefore, it is done

as soon as it is analysed. Applying this rule runs

the script “waf-allowlist.py” on the WAF, using

the artefact “ssh-connection.py” to connect to

the ModSecurity WAF.

– Rule 2. In this case, the rule, when triggered,

waits until the o’clock hours. Once that time

arrives, the “waf-normal.py” script is executed

using the “ssh-connection.py” artefact to con-

nect to the WAF.

• Policy 2). The activation of this policy occurs

when: (1) It is detected that the number of Tweets

with URLs of the store exceeds the established

threshold and the WAF is not working with ac-

cess restrictions by country; (2) It is detected

that the resource consumption at the web server

is below the conﬁgured threshold and, in addi-

tion, the WAF is working with access restrictions

by country. As a result of the ﬁrst activation,

rule 3 applies and, by the second, rule 4. Table

4 shows this policy with the format proposed in

table 1, where Trigger3 (HIGH-URL on Tweets)

is observed each time tweets per hour > 100,

State3 (OFF-WAF-COUNTRY) is observed when

the WAF is not working with access restrictions

by country, Trigger4 (LOW-WS Consumption) is

observed each time CPU consumption < 70% &

RAM consumption < 80% during 60 minutes and

State4 (ON-WAF-COUNTRY) is observed when

the WAF is working with access restrictions by

country.

– Rule 3. The ﬁrst rule associated with pol-

icy 2 is executed when the event that triggered

the related policy occurs (exceeding the thresh-

old number of Tweets containing URLs to the

store), therefore, it is analysed automatically.

This rule runs the “waf-restricted.py” script us-

ing the “ssh-connection.py” artefact.

– Rule 4. The fourth and last rule, also associ-

ated with policy 2, is executed when the web

server has kept average CPU and RAM con-

sumption below 55%. When this condition is

met, it is the “waf-not-restricted.py” script us-

ing the “ssh-connection.py” artefact that is re-

sponsible for applying the adaptation.

Table 5 shows these two policies in JSON

(JavaScript Object Notation). This standard ﬁle for-

mat has been selected to implement the prototype of

the adaptive WAF because it enables data objects in-

SECRYPT 2022 - 19th International Conference on Security and Cryptography

102

Table 3: Policy 1 for the prototype.

Adaptation conditions:

Predicate 1: observed(Trigger1 and State1 ) →

Rule 1.

Predicate 2: observed(Trigger2 and State2) →

Rule 2.

terchange (attribute–value pairs and arrays, or other

serializable values) using human-readable text. It is a

language-independent data format that can be gener-

ated and parsed by humans, applications and servers.

Different code snippets enable the execution of the

Adaptation, running the actions expressed in the four

deﬁned rules:

• ssh-connection.py. It is responsible for establish-

ing the connection, via SSH, between the server

that hosts the Adaptation Tool and the web server

(where the WAF is running).

• waf-allowlist.py. This second piece of code, asso-

ciated with rule number 1, connects to the server

with the WAF (taking advantage of the functions

contained in “ssh-connection.py”) and (1) Queries

the database to extract all existing product identi-

ﬁers (IDs); (2) Modiﬁes the WAF conﬁguration

ﬁle, activating an allow-list and including in it all

the URLs to products previously extracted from

the database; (3) Restarts the WAF for the changes

to take effect.

• waf-normal.py. It is associated with rule 2, and

after making the connection with the WAF (using

“ssh-connection.py”): (1) Modiﬁes the WAF con-

ﬁguration ﬁle, deactivating the allow-list for prod-

ucts; (2) Restart the WAF service for the changes

to take effect.

• waf-COUNT-restricted.py. Associated with rule

3, connects via SSH with the WAF and: (1) Modi-

ﬁes the WAF conﬁguration ﬁle to restrict access to

the web application only from some speciﬁc coun-

tries; (2) Restarts the WAF service for the changes

to take effect.

• waf-not-restricted.py. It is associated with rule

4. After making the SSH connection with the

WAF: (1) Modiﬁes the WAF conﬁguration ﬁle,

deactivating the access restriction by country; (2)

Restarts the WAF service for the changes to take

effect.

Table 6 shows the four proposed rules, again writ-

ten in JSON. Each rule requires a name, the speciﬁ-

cation of a timing and the controls. In this prototype,

rules 1, 3 and 4 are event-driven, therefore, governed

by a trigger. Rule 2 is periodic, therefore, governed by

a cron expressed with ﬁve digits: minute, hour, day,

Table 4: Policy 2 for the prototype.

Adaptation conditions:

Predicate 1: observed(Trigger3 and State3 ) →

Rule 3.

Predicate 2: observed(Trigger4 and State4) →

Rule 4.

month, day of week (the ∗ represents any value, the 0

is to perform the adaptation only at the o’clock hours).

The four rules use as an “Artefact” the code allowing

the connection via SSH, each one of them performs

a different “Action” thanks to the already introduced

code snippets.

Table 5: Policies 1 and 2 for the prototype written in JSON.

[ {

"name": "Policy1",

"conditions": [{

"antecedent": [

"HIGH-HTTP_400_Cod",

"OFF-WAF-ALLOWLIST"

"consequent": ["Rule1"]

},{

"antecedent": [

"LOW-HTTP_400_Cod",

"ON-WAF-ALLOWLIST"

"consequent": ["Rule2"]

}]

},{

"name": "Policy2",

"conditions": [{

"antecedent": [

"HIGH-URL_on_Tweets",

"OFF-WAF-COUNTRY"

"consequent": ["Rule3"]

},{

"antecedent": [

"LOW-WS_Consumption",

"ON-WAF-COUNTRY"

"consequent": ["Rule4"]

}]

5.2 Experimental Results

Different experiments have been performed to vali-

date and evaluate the proposed approach (see table 7).

The performed experiments have covered the entire

An Adaptive Web Application Firewall

103

Table 6: Rules 1 to 4 for the prototype written in JSON.

[ {

"name": "Rule1",

"timing": {

"period": null,

"on-demand": false,

"trigger": "HIGH-HTTP_400_Cod",

"controls": [ {

"action": "waf-allowlist.py",

"artefact": "ssh-connection.py",

}],

}, {

"name": "Rule2",

"timing": {

"period": "0 * * * *",

"on-demand": false,

"trigger": null

"controls": [ {

"action": "waf-normal.py",

"artefact": "ssh-connection.py",

}],

}, {

"name": "Rule3",

"timing": {

"period": null,

"on-demand": false,

"trigger": "HIGH-URL_on_Tweets"

"controls": [ {

"action": "waf-COUNT-restricted.py",

"artefact": "ssh-connection.py",

}],

}, {

"name": "Rule4",

"timing": {

"period": null,

"on-demand": false,

"trigger": "LOW-WS_Consumption"

"controls": [ {

"action": "waf-not-restricted.py",

"artefact": "ssh-connection.py",

}],

}]

application for one week, although, in this section,

we focus on the results obtained when protecting the

“https://example.com/product/ID” page. As a base-

line for performance, two ModSecurity deployments

have been considered with two different levels of

paranoia: one with a “relaxed” conﬁguration working

with a block-list and allowing requests from different

countries, and one with a “restricting” one working

with an allow-list and accepting only requests from

IPs at selected countries. The Adaptive ModSecurity

is our prototype, implemented as described in the pre-

vious section.

During this week, 50 legitimate users of the appli-

cation (sending 400 legitimate requests per day each

to the protected application) and 400 potential attacks

per day have been simulated, including SQL injec-

tion and DDoS attacks, because the rules and poli-

cies included in the evaluated prototype are intended

to block this type of attack. These attacks are carried

out with the OWASP ZAP and Burp Suite tools and

different known payloads.

Table 7 shows the average CPU and RAM con-

sumption due to the WAF on the web server, the aver-

age CPU and RAM consumption due to the execution

of additional tools on a different server (the server to

execute the Adaptation Tool in the case of our proto-

type), the number of blocked and successful attacks

during the week, the number of blocked legitimate re-

quests and the type of task that needs to be performed

by the WAF administrator prior to this week of exper-

iments in order to achieve the obtained results.

As demonstrated by the obtained results, the re-

laxed WAF conﬁguration consumes few resources on

the web server but allows a higher number of attacks

to succeed than the restrictive conﬁguration. In return,

this restrictive conﬁguration consumes much more re-

sources (CPU and RAM). The adaptive approach pro-

posed in this work manages to block almost the same

number of attacks as the restrictive conﬁguration. The

ﬁgures are slightly worse because the adaptation that

takes the WAF from the relaxed to the restrictive con-

ﬁguration is not performed until it is observed that the

risk is above the established threshold. But there is

hardly any difference with the more restrictive static

conﬁguration. Other adaptive policies or rules could

be explored to bring the results of the adaptive WAF

even closer to those of the static WAF with the re-

stricting conﬁguration in terms of rate of blocked at-

tacks (from the current 79% to 85%).

And yet, it consumes fewer resources than if it

were applied, statically, all the time. An additional

advantage shown in the table is not related to the re-

duction in resource consumption, but the improved

accessibility of the application. When the restrictive

conﬁguration is continually applied, legitimate users

in certain countries, for example, may be blocked by

the WAF. However, with the adaptive WAF, restrictive

settings are only applied when strictly necessary (us-

ing rule 3), so the rest of the time, these users will be

able to use the application without restrictions.

In addition, the average time it takes for the WAF

to change its conﬁguration has been measured when

this change is automatic (rules 1, 3 and 4 in our proto-

type, in rule 2 the change is periodic). In other words,

once a speciﬁc policy is evaluated, and it is decided

SECRYPT 2022 - 19th International Conference on Security and Cryptography

104

Table 7: Experimental results.

WAF relaxed WAF restricting Adaptive WAF

CPU consumption web server (%) 16.48 17.01 16.73

RAM consumption web server (%) 40.51 49.98 46.3

CPU consumption additional server

(%)

- - 8.21

RAM consumption additional

server (%)

- - 24.18

Number of blocked attacks 1792 2381 2214

Rate of blocked attacks – true posi-

tives (%)

64 85 79

Number of successful attacks 1008 419 586

Number of blocked legitimate re-

quests

134 1567 359

Rate of blocked legitimate requests

– false positives (%)

4.8 56 12.8

Workload for WAF admin. WAF static conﬁgu-

ration and signatures

update

WAF static conﬁgu-

ration and signatures

update

Rules, policies, and

signatures update

that the WAF needs to be adapted, the time it takes to

evaluate the corresponding rule and to make the adap-

tation is measured, and therefore, to make the changes

that the administrator wishes to make to the WAF. An

average time of 16.1 s with a standard deviation of

8.4 s has been measured. It has to be pointed that no

HTTP request suffers this latency, this time is required

to decide about the WAF adaptation and to perform

it (to change the WAF conﬁguration). The runtime

performance of the Adaptive ModSecurity is exactly

the same as the performance of ModSecurity, each re-

ceived request is analysed in 1 to 15 ms.

There is no version of ModSecurity that uses Ma-

chine Learning to be included in the table compari-

son. But we can deduce that the CPU and RAM con-

sumption on the web server would be high (due to

the complexity of the models used), that an additional

server would be needed to train and retrain these mod-

els ofﬂine (the adaptive WAF requires this additional

server to execute the Adaptation Tool instead, but re-

source consumption is limited), that the burden for the

WAF administrator (or the data science specialist sup-

porting him/her) would be related to building the suit-

able dataset and training and retraining the models.

The latency added to each request would be higher

than a few ms due to the complexity to the models ap-

plied to classify them as legitimate or malicious. And

the unknown, in this case, is how much it would im-

prove the WAF’s ability to block attacks (especially

zero-day attacks that signatures cannot block) and to

avoid blocking legitimate requests. All the observed

improvements should be in these two last respects.

6 CONCLUSIONS

Web Application Firewalls (WAFs) are used to protect

websites, applications and services. They may offer

in-depth security as long as they are frequently conﬁg-

ured correctly and updated (signatures, standard traf-

ﬁc patterns).

Machine Learning can be used to avoid this work-

load because WAF solutions can learn by themselves,

relying on these techniques. But they require the

availability of the appropriate datasets and a new kind

of workload related to the training and retraining of

the learning models.

This paper proposes a new approach, adaptive

WAFs, based on adding an external Adaptation Tool

to WAFs, capable of performing measurement, apply-

ing policies and adaptation rules deﬁned by adminis-

trators and managers, and adjusting the way the WAF

works to the risk that is being taken (and that one

wishes to take) at any given moment. A prototype

of the proposed approach has been implemented to

protect a web application, allowing us to validate the

Adaptation Tool and evaluate it with the ModSecurity

WAF.

The proposed adaptive WAF has shown signiﬁ-

cant improvements in resource consumption, blocked

attacks, ease of conﬁguration, and ﬂexibility in risk

management compared to traditional WAFs. All this

without requiring large datasets and complex mod-

elling processes (training and retraining) as in the case

of emerging ML approaches.

An Adaptive Web Application Firewall

105

ACKNOWLEDGMENT

This research has been partially supported by the

Madrid region (EdgeData, Grant Ref. P2018/TCS-

4499). Miguel Calvo is supported by grants from the

Rey Juan Carlos University (ref. C-PREDOC21-007).

REFERENCES

Ande, R., Adebisi, B., Hammoudeh, M., and Saleem, J.

(2020). Internet of things: Evolution and technolo-

gies from a security perspective. Sustainable Cities

and Society, 54:101728.

Applebaum, S., Gaber, T., and Ahmed, A. (2021).

Signature-based and machine-learning-based web ap-

plication ﬁrewalls: A short survey. Procedia Com-

puter Science, 189:359–367. AI in Computational

Linguistics.

Babiker, M., Karaarslan, E., and Hoscan, Y. (2018). Web

application attack detection and forensics: A sur-

vey. In 2018 6th International Symposium on Digital

Forensic and Security (ISDFS), pages 1–6.

Betarte, G., Gimenez, E., Martinez, R., and Pardo, A.

(2018). Improving web application ﬁrewalls through

anomaly detection. In 2018 17th IEEE International

Conference on Machine Learning and Applications

(ICMLA), pages 779–784.

Boudko, S. and Abie, H. (2019). Adaptive cybersecurity

framework for healthcare internet of things. In 2019

13th International Symposium on Medical Informa-

tion and Communication Technology (ISMICT), pages

1–6.

Calvo, M. and Beltr

an, M. (2022). A model for risk-based

adaptive security controls. Computers & Security,

115:102612.

Chen, A., Xing, H., She, K., and Duan, G. (2016). A dy-

namic risk-based access control model for cloud com-

puting. In 2016 IEEE International Conferences on

Big Data and Cloud Computing (BDCloud), Social

Computing and Networking (SocialCom), Sustain-

able Computing and Communications (SustainCom)

(BDCloud-SocialCom-SustainCom), pages 579–584.

Djoudi, B., Bouanaka, C., and Zeghib, N. (2014). Model

checking pervasive context-aware systems. In 2014

IEEE 23rd International WETICE Conference, pages

92–97.

Domingues Junior, M. and Ebecken, N. F. (2021). A new

waf architecture with machine learning for resource-

efﬁcient use. Computers & Security, 106:102290.

Elkhodary, A. and Whittle, J. (2007). A survey of ap-

proaches to adaptive application security. In Interna-

tional Workshop on Software Engineering for Adap-

tive and Self-Managing Systems (SEAMS ’07), pages

16–16.

Gambella, C., Ghaddar, B., and Naoum-Sawaya, J. (2021).

Optimization problems for machine learning: A sur-

vey. European Journal of Operational Research,

290(3):807–828.

Garn, B., Sebastian Lang, D., Leithner, M., Richard Kuhn,

D., Kacker, R., and Simos, D. E. (2021). Combinato-

rially xssing web application ﬁrewalls. In 2021 IEEE

International Conference on Software Testing, Veriﬁ-

cation and Validation Workshops (ICSTW), pages 85–

94.

Gogoi, B., Ahmed, T., and Saikia, H. K. (2021). Detection

of xss attacks in web applications: A machine learn-

ing approach. International Journal of Innovative Re-

search in Computer Science & Technology (IJIRCST),

9(issue-1):2347–5552.

IS¸iker, B. and So

Gukpinar, I. (2021). Machine learning

based web application ﬁrewall. In 2021 2nd Interna-

tional Informatics and Software Engineering Confer-

ence (IISEC), pages 1–6.

Ito, M. and Iyatomi, H. (2018). Web application ﬁrewall

using character-level convolutional neural network. In

2018 IEEE 14th International Colloquium on Signal

Processing Its Applications (CSPA), pages 103–106.

Kumeno, F. (2019). Sofware engneering challenges for ma-

chine learning applications: A literature review. Intel-

ligent Decision Technologies, 13:463–476. 4.

Lara, E., Aguilar, L., Sanchez, M. A., and Garc

ıa, J. A.

(2019). Adaptive Security Based on MAPE-K: A Sur-

vey, pages 157–183. Springer International Publish-

ing, Cham.

Martinelli, F., Michailidou, C., Mori, P., and Saracino, A.

(2018). Too long, did not enforce: A qualitative hier-

archical risk-aware data usage control model for com-

plex policies in distributed environments. In Proceed-

ings of the 4th ACM Workshop on Cyber-Physical Sys-

tem Security, CPSS ’18, page 27–37, New York, NY,

USA. Association for Computing Machinery.

Moradi Vartouni, A., Shokri, M., and Teshnehlab, M.

(2015). Auto-threshold deep svdd for anomaly-based

web application ﬁrewall.

Nafea, R. A. and Amin Almaiah, M. (2021). Cyber security

threats in cloud: Literature review. In 2021 Interna-

tional Conference on Information Technology (ICIT),

pages 779–786.

Schelter, S., Biessmann, F., Januschowski, T., Salinas, D.,

Seufert, S., and Szarvas, G. (2018). On challenges

in machine learning model management. IEEE Data

Eng. Bull., 41:5–15.

Shahid, W. B., Aslam, B., Abbas, H., Khalid, S. B., and

Afzal, H. (2022). An enhanced deep learning based

framework for web attacks detection, mitigation and

attacker proﬁling. Journal of Network and Computer

Applications, 198:103270.

SpiderLabs (2022). Modsecurity waf.

Steinegger, R. H., Deckers, D., Giessler, P., and Abeck, S.

(2016). Risk-based authenticator for web applications.

In Proceedings of the 21st European Conference on

Pattern Languages of Programs, EuroPlop ’16, New

York, NY, USA. Association for Computing Machin-

ery.

Sun, S., Cao, Z., Zhu, H., and Zhao, J. (2020). A sur-

vey of optimization methods from a machine learn-

ing perspective. IEEE Transactions on Cybernetics,

50(8):3668–3681.

SECRYPT 2022 - 19th International Conference on Security and Cryptography

106

Tan, H. H. and Hoai, T. V. (2021). Web application anomaly

detection based on converting http request parameters

to numeric. In 2021 15th International Conference

on Advanced Computing and Applications (ACOMP),

pages 93–97.

Tekerek, A. and Bay, O. (2019). Design and implementation

of an artiﬁcial intelligence-based web application ﬁre-

wall model. Neural Network World, 29(4):189–206.

Valenza, A., Demetrio, L., Costa, G., and Lagorio, G.

(2020). Waf-a-mole: An adversarial tool for assess-

ing ml-based wafs. SoftwareX, 11:100367.

An Adaptive Web Application Firewall

107
