Metering Homes: Do Energy Efficiency and Privacy Need to Be in
Libor Pol
and Petr Matou
Brno University of Technnology, Faculty of Information Technology, Bo
echova 2, 612 66 Brno, Czech Republic
Data Protection, GDPR, Meters, Wireless M-Bus, Energy Efficiency, Privacy.
The European directive on energy efficiency requires that all meters in multi-apartment buildings installed af-
ter 25 October 2020 shall be remotely readable devices where technically feasible and cost effective in terms of
being proportionate in relation to the potential energy savings. We observed that some manufacturers produce
meters that monitor energy consumption in very short intervals, for example, a minute, even though the direc-
tive expects to provide billing information to consumers only once a month starting from 2022. This paper
reviews privacy and security risks stemming from the high-frequency readouts and provides recommendations
for manufacturers and suppliers. The paper focuses on Wireless M-Bus metering devices sold and advertised
as a solution to fulfil the directive on energy efficiency requirements. We responsibly disclosed four issues
in the metering devices to Common Vulnerability Exposure database; real-world deployments are vulnerable.
Many recommendations and observations are also applicable to other protocols or deployments.
The European Union has strict law requirements on
privacy, personal life, and confidentiality. For exam-
ple, GDPR defines personal data as
any information relating to an identified or
identifiable natural person (‘data subject’);
an identifiable natural person is one who can
be identified, directly or indirectly, in partic-
ular by reference to an identifier such as a
name, an identification number, location data,
an online identifier or to one or more factors
specific to the physical, physiological, genetic,
mental, economic, cultural or social identity
of that natural person;
GDPR defines a data controller as any person
(legal or natural) that determines the purposes and
means of the processing of personal data. A controller
can delegate some processing to a data processor.
The Court of Justice of European Union (CJEU),
which is the highest European Court that interprets
the European legislation, upholds a broad meaning of
personal data and the responsibility of controllers in
its case-law (e.g., cases C-70/10, 131/12, C-212/13,
C-582/14, C-210/16, C-434/16, C40/17, C-623/17, C-
673/17, C-311/18, C-511/18).
Metering devices of electricity, water, and heat
consumption may reveal information on the private
lives of residents (Asghar et al., 2017; Kumar et al.,
2019; Brunschwiler, 2013; Chen et al., 2011; Erol-
Kantarci and Mouftah, 2013; Lisovich et al., 2010;
Wigan, 2014; Orlando and Vandevelde, 2021), for
example, about the occupancy or daily life cycles.
A household consumption analysis may yield loca-
tion data and reveal the habits of all members of the
household. Furthermore, a person can live alone in
a flat. Hence, metering devices can readily produce
personal data. The Article 29 Working Party (a Euro-
pean body consisting of European data protection su-
pervising authorities; currently transformed to Euro-
pean Data Protection Board) considers metering data
to be personal data (Article 29 Data Protection Work-
ing Party, 2011).
The European Commission applied the Article
29 Working Party opinion on smart metering to the
Commission Recommendation of 9 March 2012 on
preparations for the roll-out of smart metering sys-
tems (2012/148/EU). The European Commission also
asked European standard bodies to revise and secure
standards for smart metering (European Commision,
Wireless M-Bus is a protocol for metering data
cák, L. and Matoušek, P.
Metering Homes: Do Energy Efficiency and Privacy Need to Be in Conflict?.
DOI: 10.5220/0011139000003283
In Proceedings of the 19th International Conference on Security and Cryptography (SECRYPT 2022), pages 47-58
ISBN: 978-989-758-590-6; ISSN: 2184-7711
2022 by SCITEPRESS – Science and Technology Publications, Lda. All rights reserved
readouts in the range of tenths or hundreds of meters.
The meters always start the communication, so they
do not need to consume a battery to listen constantly
for incoming communication. As the use cases (in-
cluding those considered in this paper) cover readouts
performed by a person visiting the building, the data
transfers must occur frequently. Consequently, the
person that remotely reads the meters can go through
the building swiftly without unnecessary stops.
(Brunschwiler, 2013) found several security and
privacy risks in the Wireless M-Bus standard (EN
13757), including using weak keys and the lack of au-
thentication as the original security mechanisms used
shared keys. Consequently, additional security mech-
anisms were added to the standard, including mecha-
nisms that support authentication and ephemeral keys.
At the end of 2018, the European Parliament and
the Council amended the Directive 2012/27/EU on
energy efficiency. As a result, all meters in multi-
apartment buildings installed after 25 October 2020
shall be remotely readable devices where technically
feasible and cost effective in terms of being propor-
tionate in relation to the potential energy savings. We
believe that the legislators considered the recent stan-
dard updates for metering devices and considered the
metering data to be sufficiently protected. Never-
theless, the manufacturers and suppliers seem to sell
devices with the original security mechanisms based
on shared keys, without appropriate risk analysis and
with broken security.
There are several main contributions of this paper:
We analysed metering solutions by Enbra and
Kaden. During the work, we identified four vul-
nerabilities that were assigned Common Vulnera-
bility Exposure (CVE) numbers. As the vendors
did not cooperate during the disclosure procedure,
the metering based on the tested products is vul-
Additionally, we describe a case study deploy-
ment of the meters during which we highlight sev-
eral other issues causing the deployment likely not
to be compliant with data protection laws.
Finally, we provide recommendations on produc-
ing meters and their deployment that are compli-
ant with the data protection law.
This paper is organised as follows. Section 2 pro-
vides necessary theoretical background on the Euro-
pean Commission Recommendation of 9 March 2012
on preparations for the roll-out of smart metering sys-
tems (2012/148/EU), mainly from the security and
privacy perspective, and the key features of Wireless
M-Bus, common architectures, and security modes.
Section 3 introduces a case study of a metering sys-
tem that is currently being deployed. The rest of the
paper focuses mainly on the case study and the meters
deployed in the case study. Section 4 describes our
methodology for detecting flaws in the case study me-
tering. Section 5 describes the CVEs and other find-
ings that we reported to the manufacturers. Section 6
provides recommendations for manufacturers and ar-
chitects of similar systems that focuses on parameters
that build trust between the inhabitants of the metered
homes and the operators of the metering devices. The
paper is concluded in Sect. 7.
This section introduces legal recommendations for
smart metering devices in the context of this paper.
Subsequently, the section introduces the Wireless M-
Bus protocol because we later focus on this protocol
in the case study.
2.1 Data Protection
The European Commission Recommendation of 9
March 2012 on preparations for the roll-out of smart
metering systems (2012/148/EU) explicitly mentions
that smart metering systems allow processing of data,
including predominantly personal data (see recitals
6–8 of the recommendation).
Furthermore, the recommendation highlights that
particular attention should be paid to security and
protection of the personal data processed by smart
metering systems (recital 9).
Moreover, data protection and information secu-
rity features should be built into smart metering sys-
tems before they are rolled out and used extensively
(recital 10). The ‘security and data protection by de-
sign’ principle should be supported at an early stage
in the development of smart grids (recital 11).
An assessment of the data protection impact car-
ried out by the operator and stakeholders prior to the
roll-out of smart metering systems will provide the in-
formation necessary in order to take appropriate pro-
tective measures. Such measures should be monitored
and reviewed throughout the lifetime of the smart me-
ter. (Recital 15)
Article 16 of the recommendation clarifies that Ar-
ticle 8 of the Charter of Fundamental Rights of the
European Union and Article 8(2) of the European
Convention on Human Rights require justifying any
interference with the right to the protection of per-
sonal data. The legitimacy of interference must be
assessed on a case-by-case basis in the light of the
cumulative criteria of legality, necessity, legitimacy
SECRYPT 2022 - 19th International Conference on Security and Cryptography
and proportionality. Any processing of personal data
which interferes with the fundamental right to the pro-
tection of personal data within the smart grid and
smart metering system therefore has to be necessary
and proportional for it to be considered fully in com-
pliance with the Charter.
CJEU considered the necessity and proportional-
ity in cases C-92/09, C-93/09, C-473/12, C-212/13,
C-13/16, C-708/18. Briefly, all processed data should
be strictly necessary and minimised to the necessary
The Dutch case of a blocked smart meter roll-out
due to its incompatibilities with the European Con-
vention on Human Rights is a well-known example of
a failed attempt to introduce mandatory smart meters
without considering the privacy and data protection
law (Cuijpers and Koops, 2012).
Article 18 of the recommendation 2012/148/EU
clarifies that the collected, stored, and processed per-
sonal data should be appropriate and relevant. Ac-
cording to article 21 of the recommendation, EU
Member States should clearly determine the roles and
responsibilities of data controllers and data proces-
Nevertheless, the Recommendation 2012/148/EU
is not legally binding for the manufacturers, owners,
and operators of the meters. As the data produced
by the meters are typically personal data, GDPR is
legally binding. GDPR (Art. 5) requires that personal
data are processed lawfully, fairly and transparently
in a manner that ensures accuracy, integrity, and con-
fidentiality. In the context of this paper, other arti-
cles raise requirements on the necessity of processing
without consent (Art. 6), transparency (Articles 12–
15), right to portability (Art. 20), responsibilities of
controllers and processors (Art. 24–36). We believe
that metering data processing following the Recom-
mendation 2012/148/EU is compatible with GDPR.
By diverging from the spirit of the Recommendation
2012/148/EU, data controllers and processors might
breach GDPR. See Section 6 for our recommenda-
tions stemming from GDPR.
2.2 Wireless M-Bus
Wireless M-Bus is a European standard (EN 13757)
suitable for remote readouts from the close vicinity
of the meter. For example, the person performing the
readout does not need to enter the flats, but they need
to be close to the building or in its corridors. Wireless
M-Bus meters are expected to be powered by batteries
so that the protocol is designed to minimise the energy
consumption of the meter.
Meters always initiate the Wireless M-Bus data
exchange. Each meter regularly (1) wakes up its
transmitter, (2) wirelessly transmits data hoping that
the data reaches a reading device. The standard pre-
sumes either (a) one-way or (b) bidirectional commu-
nication. When the meters do not support receiving
data, (3a) they immediately switch to a sleep mode
after each transmission; (3b) in bidirectional commu-
nication, the meters activate the receiver for a limited
time during which the reading device can initiate the
bidirectional communication. (4b) When the bidirec-
tional communication is finished, the meter falls into
the sleep mode.
A reading device can be permanently present and
forward read data for further processing, possibly via
the Internet. However, the device may be present only
occasionally (e.g., once per year or once per month)
to gather data required for billing.
Figure 1 shows an example of a Wireless M-
Bus meter deployment. The meter transmits data
regularly, mostly without the reading device present
(dashed lines). Occasionally, a reading device ap-
pears in the vicinity (full lines); the reading device
either listens only (the first appearance) or continues
with bidirectional communication (the second appear-
Figure 1: An example of a wireless M-Bus communication
between a meter and a reading device that is present occa-
As the data transmitted by the one-way communi-
cation cannot be negotiated by the reading device, the
format of each message (plain text) has to be always
the same.
It is possible to buy a Wireless M-Bus receiver
for about C 100. The software for Wireless M-Bus
parsing is readily available on Internet, e.g., the one
produced by (Brunschwiler, 2013). A good antenna
and an amplifier are likely to receive the signal hun-
dreds of meters from the building (Rouf et al., 2012).
Hence, the meters must implement strong security to
comply with the law (e.g., Article 32 of GDPR).
EN 13757-1 mandates deploying a unique key for
each meter. Additionally, different sets of keys should
be used to authenticate different actors having access
to the meter. For example, to increase transparency
to household members, they can receive a key that al-
lows them to read the transmitted data (which they
Metering Homes: Do Energy Efficiency and Privacy Need to Be in Conflict?
can use for their purposes). Another key can be used
to control the meter and access data gathered to pre-
vent meter manipulation and other management tasks.
Initially, the EN 13757 standard family specified
several security modes: plain text, DES (now depre-
cated and (Brunschwiler, 2013) did not observe this
cipher to be used in the wild), and AES with a sin-
gle shared key. However, these security modes guar-
antee neither integrity nor authentication. Therefore,
around 2015, EN 13757 introduced other security
modes that ensure authentication and integrity and use
ephemeral keys.
In this paper, we evaluate a Wireless M-Bus solution
for water consumption metering deployed to flats of
associations of co-owners (condominiums) in multi-
apartment buildings to fulfil the amended Directive
2012/27/EU requirements on energy efficiency. We
obtained remotely readable Wireless M-Bus meters
offered by two vendors, Enbra (the radio module is
manufactured by Apator) and Kaden, in an e-shop.
Hence, anyone can buy these meters. We selected En-
bra based on an offer for an association of co-owners
that we had seen before starting this research. We
bought a reading set offered by Enbra. Kaden was se-
lected as the first another manufacturer that we found
in the offers of Wireless M-Bus meters.
Kaden meters have a built-in module that cannot
be detached. Enbra meters have a detachable radio
module. Although the Enbra meter and the radio
module have different serial numbers, for simplicity,
when we refer to a meter, we mean the meter com-
bined with the radio module. Similarly, the ID of the
meter means the ID of the radio module. We explic-
itly refer to the radio module to distinguish between
the meter and the radio module.
The offer of Enbra (supplier) to an association of
co-owners in multi-apartment buildings mentions that
the meters transmit data using one-way Wireless M-
Bus. Nevertheless, neither does the offer warn that
data processed by the meters will likely process per-
sonal data
, nor does the offer explain the security.
Such an offer does not raise red flags to the general
public. As all co-owners are typically not specialised
in computer security, no one objects.
The supplier offers two types of deployment:
1. No additional permanent infrastructure besides
the metering devices. Such deployment requires
Despite EN 13757-1 (Section 4.3) and EN 13757-7
(Section 9.1) warning that metering data should be treated
as private data of the user in most cases
that a person enters the building and performs
readouts for the billing.
2. Wireless M-Bus gateways proxy the messages to
the remote server of the supplier. The supplier
informed the association that data sent over the
Internet are not encrypted. Once on the server,
the readouts should be available to the household
members and the association of co-owners.
We studied two deployments without permanent
infrastructure. As far as we are aware, both associa-
tions did not receive the keys, risk analysis prescribed
by EN 13757-1, or technical documentation on the
transmitted data. One association received informa-
tion on frequent message transfers following a data
subject request.
During our research (see Sect. 5.1), we learnt that
the Enbra meters are capable of detecting events (like
a water leak, unoccupied flats, etc.). As far as we
are aware, neither association was informed that the
meters can detect events.
We decided to evaluate EN 13757 as well as current
literature to determine privacy and security threats
that might arise in the case study system introduced
in the Sect. 3.
4.1 Confidentiality and Key
EN 13757-1, Sect. 4.3.2 anticipates performing a se-
curity requirement analysis and threat analysis. One
should assess the risks and alternatives according to
ISO/IEC 27033 or ISO/IEC 15408 as suggested by
EN 13757. As already mentioned in Sect. 3, the asso-
ciations did not receive any analysis.
EN 13757-1 and EN 13757-7 stress that key
management is an important task that needs to be
solved to provide confidentiality, integrity, and non-
repudiation. According to EN 13757-1, the keys re-
quire a high level of protection, and the principle of
the need to know should be applied. Depending on
the deployment and the threat analysis results, the key
might need to be changed during the lifetime of the
meter. Different sets of keys might be needed for dif-
ferent clients, and unique keys need to be used for
each meter. The key cannot be derived from the data
like the ID of the meter.
(Chen et al., 2011) successfully detected house-
hold activities such as taking a shower, using a wash-
ing machine or dishwasher from readouts of 15-
SECRYPT 2022 - 19th International Conference on Security and Cryptography
minute periods. Some devices can have a distinct
pattern of energy consumption. The pattern could
be used to fingerprint such a device (Lisovich et al.,
2010; Kelly and Knottenbelt, 2015; van Megen and
Mueller, 2010; Hurri et al., 2011). Consequently,
an adversary can reveal the manufacturer or even the
model of household appliances without ever entering
the household. Such information is convenient for
burglars, profiling, and marketing.
Hence, we studied the timing between the read-
outs and the information quality of each readout. We
also focused on key management as poor key manage-
ment might endanger the confidentiality of the mea-
surements (Asghar et al., 2017).
4.2 Zero Consumption Detection
Subsection 4.1 anticipates that the key of a meter
leaks; directly or as a tool able to decrypt and decode
the messages. Nevertheless, zero consumption detec-
tion may be possible even without a leaked shared
key. AES is a block cipher, so the same input (in-
cluding the initialisation vector IV) yields the same
output. That is the reason why EN 13757-7 explicitly
warns against zero consumption detection.
Computer science literature also highlights the
risk of zero consumption detection (Erol-Kantarci and
Mouftah, 2013; Lisovich et al., 2010). If there is a
consumption, typically, there is also a person that uses
the water. Vice versa, if the water is not being con-
sumed for some time, there is probably no one in the
flat. Long-term observations can reveal the patterns of
being away from home (Lisovich et al., 2010). This
information can be misused for commercial purposes,
criminal activities such as burglaries and stalking.
Consequently, we focused on an analysis of
methods to determine zero consumption without the
knowledge of the encryption key.
4.3 Integrity
Brunschwiler reported that Wireless M-Bus Secu-
rity Mode 5 devices are vulnerable to replay attacks
Jam-and-Replay and Shield-and-Replay (Brun-
schwiler, 2013, Section 4.4.2, 4.4.3). An attacker can
intercept messages sent by Wireless M-Bus Security
Mode 5 devices at time T. The attacker can replay
these messages during readouts at T + several months.
Consequently, we focused on the ability to per-
form replay attacks against the deployed case study
4.4 Identifiability
Enbra claims that it is impossible to identify the flat
where a specific meter is being placed. We focused
on methods that disprove the claim.
This section focuses on the findings of this paper. We
reported issues to CVE database. CVE is a worldwide
database used for responsible disclosure. The idea is
to confidentially report detected vulnerabilities to the
IT manufacturers and vendors and provide them with
time to fix the vulnerability or explain more details
about the vulnerability. Once the vulnerability is fixed
or excessive time passes during which the vendor does
not respond or cannot fix the underlying problem, the
vulnerability is exposed to anyone in the world so that
the customers and users can apply countermeasures to
the vulnerabilities such as workarounds or avoid the
vulnerable components.
5.1 Preliminary Analysis of the Meters
After we bought Enbra and Kaden meters, we ob-
served the messages transmitted by these meters.
Data are secured with the original EN 13757 AES
mode (Security Mode 5) without the possibility of dif-
ferent roles (e.g., a user authenticates to the meter us-
ing a unique AES key). We did not receive any mean-
ingful technical documentation containing the key nor
other data necessary to decode deciphered messages
although we explicitly asked. We did not receive any
risk analysis prescribed by EN 13757-1.
Enbra meters transmit data with a period of 80
seconds for about 12 hours per day Monday to Fri-
day; and with a period of 300 seconds during Monday
to Friday nights, Saturdays, and Sundays. All trans-
missions produce data of the same length and with the
same Wireless M-Bus headers (not encrypted) except
an 8-bit access number counter. The meters set the
bidirectional bit meaning that they are capable of bidi-
rectional communication. Apator website (the manu-
facturer of the radio module) confirms that the meters
are indeed bidirectional. According to Apator, it is
possible to manage the meters remotely. The meters
save historical data on the consumption, provide data
on current consumption and meter value, and detect
several events such as zero consumption, meter tam-
pering, and water leaks. It is possible to change the
key by anyone who knows the old key. Effectively, ev-
eryone who knows the key can brick the device by as-
signing a key that the adversary immediately deletes
Metering Homes: Do Energy Efficiency and Privacy Need to Be in Conflict?
(the plain text would not be decryptable, so even if
the device would continue transmitting, no one could
utilise the readouts).
Kaden meters transmit data with a period of 1
minute for about 10 hours per day and 15 minutes
during nights. The meter does not differentiate be-
tween workdays and weekends. The meter produces
two messages during each transmission interval. One
message is shorter and the other longer. The longer
message changes at the end of a month; we suppose
that it carries historical consumption data. The bidi-
rectional flag is not set, meaning that there is no way
to communicate with the meter. We did not find any
communication port that could be used to configure
the meter.
5.2 Broken Key Management:
As mentioned in the Sect. 5.1, both Enbra and Kaden
meters are distributed without the encryption key.
Even so, both offer a reading device. According to
Enbra, the security of the system is guaranteed with a
proprietary content of the plain text message.
We bought the reading device offered by Enbra.
The reading device automatically deciphers the con-
sumption reported by meters ordered together with
the reading device and meters deployed by both as-
sociations of co-owners.
How is the reading device able to decipher the
messages? It must have known or computed the
key. It seems likely that the encryption depends on a
shared key, or, that is possible to derive the key from
the serial number of the radio module sent in the plain
text part of each message. It is possible that the meters
use different keys. However, the observations show
that if this was the case, these keys or the algorithm
to derive them must had been shared with the reading
set. It is not clear who knows the key(s).
As an adversary only needs a compatible reader to
read the consumption, the confidentiality of the water
metering is endangered. Such security violates EN
13757-1, which mandates unique keys for each meter
that cannot be derived from other data like serial num-
bers. EN 13757-1 expects a key management policy
to be developed.
If the EN 13757 is violated, it is likely that also
the Article 32 of GDPR is violated as it requires that:
Taking into account the state of the art, the
costs of implementation and the nature, scope,
context and purposes of processing as well
as the risk of varying likelihood and severity
for the rights and freedoms of natural per-
sons, the controller and the processor shall
implement appropriate technical and organi-
sational measures to ensure a level of security
appropriate to the risk [...]
As the case study system provides data in 5-
minutes periods or 80-second periods, the household
activities detection should be better than those ob-
served by (Chen et al., 2011).
Moreover, it is possible that the shared keys do not
have sufficient strength. In such a case, an adversary
can leverage tools like Hashcat to recover the key. We
did not try this experiment yet.
If a (shared) key leaks, many consequences can
follow, which are hard to enumerate. For example,
smart home appliances and gateways vendors can in-
corporate the leaked keys to gain a marketing advan-
tage for their products. Should the keys be shared,
an owner of such a smart home gateway can monitor
the activities of the neighbours (possibly without the
knowledge that such processing takes place). In the
worst-case scenario, such an appliance can be con-
nected to the Internet without sufficient security, and
energy consumption details can start to leak to the In-
ternet. As the meter is not in the direct ownership of
the households, even a skilled technician is unable to
prevent leakage of his or her data. Moreover, if the
AES key leaks, one can reconfigure the devices and
even change the encryption key. To mitigate the issue,
a sound key management policy has to be in place. A
shared key between the metering devices and easily
guessable keys should not be deployed as both can
make the leak worse.
As a countermeasure, we suggest that Enbra
changes the keys in conformance with EN 13757-1
the keys must be unique to each meter, and all
bits should be randomly generated. As far as we
are aware, Kaden meters do not provide any way to
change the key. The obvious solution is to replace the
5.3 Zero Consumption Detection
without Key
The IV used by the AES cipher contains an 8-bit ac-
cess number counter that is incremented with every
transmission. The changing IV indeed prevents the
detection of zero consumption in successive readouts.
However, once the 8-bit counter overflows (after 256
messages), the ciphertext is the same if the plain text
message does not change. Once an adversary detects
a repeated message, they know the last consumption
that was metered. While the messages repeat, it is
clear that the meter value does not change. Later, the
adversary can learn when the meter changes again (or
something else changes in the payload) — the cipher-
SECRYPT 2022 - 19th International Conference on Security and Cryptography
text changes compared to the previous occurrence of
the counter value.
The transmission interval of the meters considered
in the case study can yield such an overflow after sev-
eral hours, which means that not only can an adver-
sary detect unoccupied flats, but long-term observa-
tions can reveal patterns in daily activities. The stan-
dard correctly advises using a timestamp or another
counter, but it does not explicitly describe the over-
flow issue. Apator claims:
To assure confidentiality of the metering data,
the RF transmitted consumption data is se-
cured with the AES-128 + CBC encryption
algorithm (which guarantees variation of the
transmitted data when no volume changes oc-
Indeed, EN 13757 mandates using Cipher Block
Chaining (CBC) for the applied security mode. How-
ever, CBC affects each message separately; the en-
cryption of a message is not chained to the previ-
ous message. We reported the issue with zero con-
sumption detection from overflowed access number
counter and suggested modifications of the standard
text to the European Committee for Standardization
(CEN), the standard body behind EN 13757. How-
ever, there are no revisions of the standard planned at
the moment. Moreover, we found meters vulnerable
to zero consumption detection using this method, as
further discussed in subsection 5.3.1.
5.3.1 CVE-2021-34576: Zero Consumption
Detection of Kaden Meters without Key
Recall that Kaden meters produce two messages ev-
ery readout period. By observing the messages of
Kaden meters, we detected that the shorter message of
48 bytes (application payload) seems to hold the cur-
rent metered value. Each of the short and long mes-
sages increment the access number counter value; the
counter value overflows every 256 messages. Hence,
the IV repeats after 2 hours 8 minutes during day be-
tween 9 a.m. and 7 p.m., or 15 hours 12 minutes oth-
Suppose there was no metered consumption be-
tween the messages with the repeated IV. We ob-
served that the first 32 bytes of the ciphertext of the
payload of the shorter message repeat while the fi-
nal 16 bytes are different. Whenever a consumption
occurred between the messages with the repeated IV,
the encrypted payload of these two messages with the
same IV was completely different. One can deduce
that (1) the metered value is located in the starting
16 bytes of the 48-bytes-long message and (2) there
seems to be a value that changes frequently located
in the final 16 bytes of the message even without any
consumption. The employed encryption scheme does
not offer full confidentiality in such configuration.
Hence, an adversary can observe whether there was
water consumption during the overflow time range
without the encryption key. Consequently, the at-
tacker can infer information about someone being in
the flat or not, daily patterns, and similar information.
Figure 2 shows an example of the vulnerability in
Kaden devices protected by the original AES mode
(Security mode 5).
Meter value 1234.5, counter 100, time 10:00 cipher text AAA
Meter value 1234.8, counter 102, time 10:01 cipher text BBB
Meter value 1234.8, counter 104, time 10:02 cipher text CCC
Meter value 1234.8, counter 170, time 10:35 cipher text DDD
Meter value 1234.8, counter 172, time 10:36 cipher text EEE
Meter value 1234.8, counter 100, time 12:08 cipher text FFF
Meter value 1234.8, counter 102, time 12:09 cipher text BBG
Meter value 1234.8, counter 104, time 12:10 cipher text CCH
Meter value 1234.8, counter 170, time 12:43 cipher text DDI
Meter value 1234.9, counter 172, time 12:44 cipher text JJJ
Figure 2: An example of the vulnerability in Kaden meters.
In the example, an adversary can detect at 12:09 that the
meter value has not changed since 10:01 as the beginning
of the ciphertext starts to repeat after 12:09. As the begin-
ning of the ciphertext observed at 12:43 is the same as at
10:35 but the following ciphertext changes completely, the
adversary can detect that the meter value changed between
12:43 and 12:44.
An adversary can determine if the consumption
was zero or non-zero. The adversary cannot detect the
metered value if the consumption changes. Because
there is a message sent every minute during the day,
the attacker can learn the time when the water was
metered for the last time (with the delay of 2 hours
and 8 minutes during days and 15 hours 12 minutes
during nights). The attacker can detect water con-
sumption in the following sent message; the cipher-
text differs from the previous message with the same
counter number (IV).
5.4 CVE-2021-34572: Vulnerable to
Replay Attacks
Although we lack technical documentation of the ra-
dio modules, we think that Enbra meters send a times-
tamp: (1) Wireless M-Bus Security Mode 5 initiali-
sation vectors repeats every 256 messages, or every
5.6 hours during peak hours in the default configu-
ration of AT-WMBUS-16-2. As the ciphertext of the
observed messages with the same IV changes without
consumption, the plain text of the message with the
same IV must differ. We suspect that this is due to the
Metering Homes: Do Energy Efficiency and Privacy Need to Be in Conflict?
presence of a timestamp. (2) We changed the system
data on the reading set. Even so, the reading software
by Enbra displayed the real date and not the system
date. Hence, we conclude that the data was parsed
from the message sent by the meter.
A timestamp protects against replay attacks. The
reader can compare the time reported by the meter
and the system time and detect message replays (of
course, the reader should accommodate errors due to
clock shifts).
The reading software by Enbra provides an export
functionality to the CSV format. Exported data can be
used for further processing, e.g., to provide billing de-
tails. However, exported CSV data does not contain
the time observed at the meter but instead provides
the system time of the readout. As the software does
not notify the user that a readout from the past ap-
peared and it is impossible to check the CSV data for
time stamps from the past, replay attacks described
by (Brunschwiler, 2013) and similar are likely to re-
main undetected by the users of the software. Hence,
an attacker can replay past data to influence single or
multiple meter readouts. Consequently, the integrity
of the billing information is affected (the incorrect bill
is lower).
As a workaround, persons performing the readout
can check the original transmission date in the read-
ing software by Enbra before they export data to CSV.
However, such a task is time-consuming and error-
prone due to the likely fatigue from comparing unaf-
fected data from the majority of the readouts that are
expected to happen without an attacker.
5.5 Identifiability of the Meter
Enbra claims that it is impossible to identify the flat
where a specific meter is being placed. However, this
claim is invalid.
The radio module number is visible on the mod-
ule. Consequently, every person with physical ac-
cess to the meter (for example, entering the bath-
room where it is installed in the flats of the as-
sociations) can easily learn the module number.
Note that the very same number can be observed
in the unencrypted part of the Wireless M-Bus
When the supplier replaced old meters with Wire-
less M-Bus meters, all co-owners needed to sign
a protocol about the replacement. The protocol
contains the numbers of radio modules and me-
ters and is available to some or all the co-owners
depending on the rules of the association.
The signal strength decreases with distance and
the number of obstacles (see Figure 3). Indeed,
we were able to experimentally detect the signal
of a known radio module (we visually read the
number printed on the radio module) outside the
building at the place where no other signal was
present. We preselected the signal strength mea-
surement location so that the known radio module
was the closest and with the least number of ob-
stacles. Moreover, we measured signal strength
inside a building. We were able to identify meters
in flats from measurement taken from the corri-
dors of the building, see Tab.1. We expect that all
meters in a building can be located with one suc-
cessive message received per flat per meter (about
1–2 minutes per flat for the meters considered in
the case study introduced in Sect. 3).
The zero consumption detection vulnerability
(CVE-2021-34576) or access to metered values
(CVE-2021-34571) can be leveraged to correlate
the persons entering or leaving the building and
detected (zero) consumption of the meters.
The building
meter A meter B meter C
signal strength
position Y
signal strength
position X
signal strength
position Z
Figure 3: An example of a possible signal strength mea-
surement. The signal of Meter A is strong at X, moderate at
Y, and weak at Z. The signal of Meter B is strong at Y, and
moderate at X and Z. The signal of meter C is strong at Z,
moderate at Y, and weak at X.
5.6 CVE-2021-34573: Misleading Event
As mentioned in Sect. 3, Apator advertise that the
meters detect events such as zero consumption, meter
tampering, and water leakage. The reading software
by Enbra seems to be able to read such events and
even export them to the CSV format.
One of the events is backflow. We back flowed
about 0.015 cubic meters through the meters. The
reading software by Enbra did not report the back-
flow event. We are not sure what the issue is: Was the
threshold reached? Is it a bug in the meter? Maybe
the meter does signal the event, but the reading soft-
ware by Enbra cannot parse the event. Unfortunately,
the responsible disclosure procedure did not clear the
SECRYPT 2022 - 19th International Conference on Security and Cryptography
Table 1: Average signal strength measurements. Note that
each flat has two meters. Flat D is located above flat A.
Flats B, C, and D are located on the same floor.
Meter 1 in flat A
50.48 % corridor in front of flat A
42.90 % corridor in front of flat D
42.58 % just below flat A
26.06 % another place below flat A, several walls
25.59 % a far away place below flat A
18.71 % corridor in front of flat B
Meter 2 in flat A
47.10 % corridor in front of flat A
34.62 % corridor in front of flat D
32.26 % just below flat A
28.39 % corridor in front of flat B
17.42 % a far away place below flat A
15.68 % another place below flat A, several walls
Meter 1 in flat D
66.29 % corridor in front of flat D
46.45 % corridor in front of flat B
25.59 % just below flat A
25.16 % corridor in front of flat C
11.81 % another place below flat A, several walls
2.90 % a far away place below flat A
Meter 2 in flat D
72.25 % corridor in front of flat D
36.94 % corridor in front of flat B
30.54 % corridor in front of flat C
9.68 % just below flat A
Additionally, the reading software by Enbra re-
ported meter malfunction Radio module was removed
three times during our first readout. However, there
was an Apator seal that should indicate if the radio
module was removed. The seal was intact on our
modules. The meter had not been used for several
months before it had been shipped to us, as was vis-
ible from historical volumes saved at the end of sev-
eral preceding months before the readout. We expect
that the condition for reporting the event of zero con-
sumption should had been triggered before the read-
out. The reading software by Enbra does not report
zero consumption. Even more, when studying the me-
ters in one of the affected associations of co-owners,
we noticed that the very same error was also shown
but only on a limited number of meters. All the meters
that we noticed showed Radio module was removed
three times. We did not see any other error or number
of removals. Is it just a coincidence?
We suspect that the event reporting in the reading
software by Enbra does not work as it should. The
integrity of data can be corrupted without detection.
Different events may be represented to the user re-
sulting in confusion. A flat owner can be accused of
radio module removal even though the event did not
really occur. As a workaround, we suggest ignoring
the events or interpret them with a grain of salt.
This section discusses recommendations that should
be considered by the manufacturers and suppliers of
the metering devices. Recall the recital 11 of The
European Commission Recommendation of 9 March
2012 on preparations for the roll-out of smart meter-
ing systems (2012/148/EU) focusing on security and
data protection by design, see Sect. 2.1 for more de-
tails. Although we focus on the lessons learned in the
previous sections, we believe they can be generalised
to other metering devices, even using protocols other
than Wireless M-Bus.
6.1 Proportionality, Necessity, and Data
European data protection law requires the processed
personal data to be proportionate, necessary and min-
imised. Should the law require yearly readouts, the
devices should by default transmit only the yearly
balance (Article 29 Data Protection Working Party,
2011). Once the law changes to monthly readouts,
the device should provide the data. Of course, one can
tolerate a preparation phase during which the devices
provide monthly readout earlier than required. The
more detailed the readings, the more privacy-sensitive
the data becomes (Asghar et al., 2017; Cuijpers and
Koops, 2012).
According to an e-shop selling the radio modules
of the case study (Sect. 3), they can be configured
to change the records being available in the trans-
mitted frames. Hence, it might be possible to al-
ter the behaviour of the meters according to changes
in law and signed contracts. Therefore, we recom-
mend that manufacturers implement such configura-
bility into meters that are being designed and those
that can be upgraded.
The readouts containing current consumption and
flow rate are clearly not needed by the law and should
not be transmitted by default (Cuijpers and Koops,
2012; Orlando and Vandevelde, 2021). For successful
deployment, the events supported by the radio mod-
ules (meter tampering, water leakage, etc.) of the
case study system seem to be a good idea. Suppose
the meters are configured not to sent current con-
sumption and flow rate but instead report the events.
Metering Homes: Do Energy Efficiency and Privacy Need to Be in Conflict?
Such configuration is suitable for the deployment with
gateways and the webserver (see the offered type of
deployment with gateways in Sect. 3) as the events
would detect water leaks, meter tampering, etc. with-
out unnecessarily sacrificing the privacy of the inhab-
itants. Some events like water leaks could trigger an
(Orlando and Vandevelde, 2021) focused on gain-
ing trust including the issues of frequent read outs. To
increase the trust between the manufacturer, supplier,
and household members, we suggests building meters
with physical switches to control the frequency of the
readouts. In the case of the proxying data to a web-
server (or custom readouts mentioned later), someone
may be interested in the detailed information about
energy consumption (Asghar et al., 2017). The hard-
ware switch could enable such choices. The informed
consent can be obtained in the webserver; if the user
refuses to consent, the webpage can show instructions
about the hardware switch and its current and desired
There is also a question if the modules should
transmit during nights and weekends. It seems not
to be necessary for the deployment without transfers
to the webserver. In the use case with a webserver,
such transfers are beneficial for event detection.
Sections 4 and 5 show that the meters considered
in this paper fulfil the conditions for data protection
impact assessment as Article 35(1) of GDPR reads:
Where a type of processing in particular us-
ing new technologies, and taking into account
the nature, scope, context and purposes of the
processing, is likely to result in a high risk to
the rights and freedoms of natural persons, the
controller shall, prior to the processing, carry
out an assessment of the impact of the envis-
aged processing operations on the protection
of personal data. A single assessment may ad-
dress a set of similar processing operations
that present similar high risks.
A typical association of co-owners does not have
enough knowledge to carry the assessment. There-
fore, we believe that the supplier should have the
knowledge to perform the assessment.
6.2 Transparency
Previous research shows that consumers need to be
adequately informed about the risks and privacy im-
plications of smart meters (Cuijpers and Koops, 2012;
Asghar et al., 2017).
The case study system transmits data through the
air inside the household. Therefore, it seems straight-
forward that the household members (data subjects)
should be allowed to use that data for their purposes,
e.g., to create a smart home (for example, to detect
water leaks).
The manufacturers and suppliers should create the
meters so that the communication is either one-way
only or bidirectional with authentication and sup-
port of different roles. The deployment should allow
household members to read the data without the pos-
sibility to modify the configuration, stored events, and
other data outside of the privileges of their role. (As-
ghar et al., 2017) identified value-added services as an
important part of smart metering deployment.
GDPR gives data subjects the right to access per-
sonal data even if it was not obtained directly from
data subjects. Article 20 gives data subjects rights
to data portability if the processing is carried out by
automated means and based on consent or contract.
By providing the access key for read-only readouts,
the controller provides trust through transparency and
fulfils the GDPR, Art. 20 requirements.
6.3 Security
Suppose an adversary can deploy Wireless M-Bus
readers in the vicinity or inside the building. In that
case, encryption is the critical part of the security of
the meters. EN 13757 considers the security policy
selection a crucial task in terms of confidentiality, in-
tegrity, authentication, and non-repudiation. We be-
lieve that the standard is correct, and the security anal-
ysis of all smart metering systems should take all four
requirements seriously.
Hence the key management should be considered
a crucial task. The key should not be shared between
meters under any circumstance. EN 13757-1 cor-
rectly suggests changing the key several times within
the lifetime of the meters. See the security analysis
(subsection 5.2) for more details on the risks of bad
key management.
(Article 29 Data Protection Working Party, 2011)
recommends end-to-end encryption of data produced
by smart meters. We believe that this recommenda-
tion is crucial to ensure the confidentiality of the data
to protect the privacy of the household. Hence, both
the communication between the meter and a reading
device (for example, a gateway) should be encrypted.
Also, the transit over the Internet should be encrypted.
6.4 Controllership
Recall that the European Commission Recommenda-
tion of 9 March 2012 on preparations for the roll-
out of smart metering systems (2012/148/EU) calls
SECRYPT 2022 - 19th International Conference on Security and Cryptography
for clear determination of responsibilities of data con-
trollers and data processors.
CJEU recently decided in several cases concern-
ing issues in cotrollership, see C-210/16, C-25/17,
and C-40/17. For example, Advocate General Men-
gozzi (Mengozzi, 2018, paragraph 68) considers that
it is necessary to rely upon a factual than formal
analysis. The European Parliament resolution of
25 March 2021 on the Commission evaluation re-
port on the implementation of the General Data Pro-
tection Regulation two years after its application
(2020/2717(RSP)) explicitly mentions ICT manufac-
turers being considered controllers of personal data.
The case study deployment raises uncertainties
(see also Sect. 3) about the controllership:
Is the association of co-owners a sole or joint
controller? There are no doubts that the asso-
ciation agreed with the placement of the meters
on their premises; hence it determines the means.
However, the desired purpose is to provide billing
information for co-owners (i.e., it was only in-
terested in yearly or monthly readouts). Conse-
quently, it seems that other controllers jointly de-
termine the means and purposes of the processing.
As the buyer (association of co-owners) was mis-
led by the offer that the system is only one way, it
could not evaluate risks associated with the bidi-
rectional communication, like the possibility of
attacks based on insufficient validation of inputs
that can trigger command injections, buffer over-
flows, and other common vulnerabilities. More-
over, such an association lacks knowledge about
the privacy and security issues outlined in Sect. 4.
Furthermore, the law should not expect such or-
ganisations to gain the expected knowledge of
both a skilled technician and a skilled lawyer.
Such knowledge is highly specialised and requires
extensive training that is, we believe, outside the
possibilities of a typical association of co-owners.
Is the supplier a sole or joint controller? Recall
that the supplier likely provided false information
in the offer (that the meters are one-way, but ac-
cording to other information, including the con-
tent of each transmitted unencrypted part of the
messages sent by the meters, the meters allow
bidirectional data transfers). The supplier pos-
sesses technical knowledge, albeit it seems that it
lacks the knowledge of the law and the content of
the standards it explicitly claims to follow.
Is the manufacturer of the radio module a sole
or joint controller? We are not certain about the
documentation that was provided to the supplier.
Since the supplier offers software tailored for its
products and since the meters seem to be config-
urable in terms of data being sent, the manufac-
turer probably should not be considered a con-
troller. However, the manufacturer selected the
security mode and is possibly the only entity that
can update the firmware of the radio module with
more suitable encryption schemes.
We believe that the supplier should have the nec-
essary technical knowledge to deploy the metering
system and provide the technical expertise to main-
tain the system and periodically review its security
(Article 32 of GDPR), for example, against publicly
published attacks (Brunschwiler, 2013). On the other
hand, the supplier should not be forced to provide
such a service for free.
We believe that the contract between the supplier
and the buyers (e.g., an association of co-owners)
should clearly determine the roles of the parties.
Should the deployed meters transmit data frequently
(especially without the presence of the official read-
ing device), the buyer should be clearly notified, and
the controllership for frequent data transfers should
be clearly determined. The buyer should be (1) no-
tified that the law requires to take security seriously
and (2) offered a service to maintain the security of
the metering system.
The European law provides strict guarantees for the
data protection of European citizens. The European
Commission, the European Parliament, and European
Council created data protection laws and recommen-
dations, including GDPR. However, the fast growth of
smart gadgets, including smart meters attached with-
out the consent of data subjects in their homes, does
not always follow the law and the spirit of the law.
We provide a case study and list several uncertain-
ties and possible issues in metering devices currently
being deployed in Europe. The ignorance of process-
ing only necessary and minimised data results in pri-
vacy risks. The insecure configuration provides data
subjects at risk of profiling and burglary. Low trans-
parency does not create trust between the data sub-
jects and the manufacturers and suppliers of the me-
tering devices.
This paper focuses on a case study of a meter-
ing system with remote reading capabilities being de-
ployed in associations of co-owners in Europe. As
both the data protection laws and standards expect to
carry risk analysis and data protection impact assess-
ments, we analyse the risks of the system. By examin-
ing two Wireless M-Bus meters and a reading set, we
Metering Homes: Do Energy Efficiency and Privacy Need to Be in Conflict?
identified 4 CVEs and several other privacy and secu-
rity risks in the products. Unfortunately, the affected
companies did not react to the responsible disclosure
procedure and did not fix the underlying issues. Fi-
nally, this paper provides several recommendations
in Sect. 6. We believe that the recommendations are
generic and valid for any smart metering system, not
only those considered in the case study.
According to Art. 58 GDPR, European data pro-
tection authorities can, for example, order the con-
troller or processor to bring processing operations
into compliance with the provisions of this Regula-
tion [...], impose a temporary or definitive limitation
including a ban on processing, and impose an admin-
istrative fine. Schneier expects that EU enforcement
will be harsh (Schneier, 2018, Chapter 10). Manu-
facturers of smart gadgets should start to take the law
and the risks for data protection seriously if they plan
to sell the goods on European markets.
We believe that our recommendations show that
privacy and energy efficiency are not in conflict.
This work was supported in part by the Brno Univer-
sity of Technology grant FIT-S-20-6293 (Application
of AI methods to cyber security and control systems).
Article 29 Data Protection Working Party (2011). Opinion
12/2011 on smart metering. Available online at
opinion-recommendation/files/2011/wp183\ en.pdf.
Asghar, M. R., D
an, G., Miorandi, D., and Chlam-
tac, I. (2017). Smart meter data privacy: A
survey. IEEE Communications Surveys Tutorials,
Brunschwiler, C. (2013). Wireless M-Bus Se-
curity. Whitepaper Black Hat USA 2013.
Research/Praesentationen/blackhat\ 2013\ wmbus\
security\ whitepaper.pdf.
Chen, F., Dai, J., Wang, B., Sahu, S., Naphade, M., and
Lu, C.-T. (2011). Activity analysis based on low sam-
ple rate smart meters. In Proceedings of the 17th
ACM SIGKDD International Conference on Knowl-
edge Discovery and Data Mining, pages 240–248,
New York, NY, USA. ACM.
Cuijpers, C. and Koops, B.-J. (2012). Smart metering and
privacy in Europe: lessons from the Dutch case. In
Gutwirth, S., Leenes, R. E., de Hert, P., and Poullet,
Y., editors, European data protection: Coming of age,
pages 269–293. Springer.
Erol-Kantarci, M. and Mouftah, H. T. (2013). Smart grid
forensic science: applications, challenges, and open
issues. IEEE Communications Magazine, 51(1):68–
European Commision (2011). M/487 EN: Programming
Mandate Addressed to CEN, CENELEC and ETSI
to Establish Security Standards. Available online at
Hurri, P., Neuvo, N., Mikkola, T., Bunn, E., Kaakkola, I.,
and Kivimaa, K. (2011). Smartgrid energy-usage-
data storage and presentation systems, devices, proto-
col, and processes including a visualization, and load
fingerprinting process. US Patent US8949050B2 of
Kelly, J. and Knottenbelt, W. (2015). The UK-DALE
dataset, domestic appliance-level electricity demand
and whole-house demand from five UK homes. Mas-
ter’s thesis.
Kumar, P., Lin, Y., Bai, G., Paverd, A., Dong, J. S.,
and Martin, A. (2019). Smart grid metering net-
works: A survey on security, privacy and open re-
search issues. IEEE Communications Surveys Tuto-
rials, 21(3):2886–2927.
Lisovich, M. A., Mulligan, D. K., and Wicker, S. B. (2010).
Inferring personal information from demand-response
systems. IEEE Security Privacy, 8(1):11–20.
Mengozzi, P. (2018). Opinion of advocate general men-
gozzi. CJEU Case C-25/17, ECLI:EU:C:2018:57.
Orlando, D. and Vandevelde, W. (2021). Smart meters’ roll
out, solutions in favour of a trust enhancing law in the
eu. Journal of Law, Technology and Trust, 2(1).
Rouf, I., Mustafa, H., Xu, M., Xu, W., Miller, R., and
Gruteser, M. (2012). Neighborhood watch: Security
and privacy analysis of automatic meter reading sys-
tems. In Proceedings of the 2012 ACM Conference on
Computer and Communications Security, pages 462–
473, New York, NY, USA. ACM.
Schneier, B. (2018). Click here to kill everybody : secu-
rity and survival in a hyper-connected world. W.W.
Norton & Company Ltd. ISBN 978-0-393-60888-5.
van Megen, F. and Mueller, U. (2010). Classifying devices
by fingerprinting voltage and current consumption.
US Patent US20110313582A1 of Microsoft Technol-
ogy Licensing LLC.
Wigan, M. (2014). User issues for smart meter technology.
IEEE Technology and Society Magazine, 33(1):49–53.
SECRYPT 2022 - 19th International Conference on Security and Cryptography
