Combining SBFL with Mutation Testing: Challenges of a Practical

Approach

Anna Derezińska

and Sofia Krutko

Warsaw University of Technology, Institute of Computer Science, Nowowiejska 15/19, Warsaw, Poland

Keywords: Fault Localization, SBFL, Mutation Testing, MBFL.

Abstract: Research on fault localization techniques focuses on their efficiency and cost reduction. Spectra-Based Fault

Localization (SBFL) counts to the mostly used methods. Hybrid approaches have been shown to be beneficial.

We discuss the challenges of a revised approach combining SBFL with mutation testing. Certain unconvinced

issues of mutation testing have been identified, and a practical framework has been prepared to evaluate

different variants of the approach. Building a new repository with faulty programs has been launched in order

to study the approach not only on the commonly used legacy programs, but also on faulty programs of more

contemporary versions of the Java language and unit tests.

1 INTRODUCTION

Fault Localization in software belongs to very

laborious activities and, therefore, different methods

have been studied to automate them and support code

development and maintenance. Different approaches

have been proposed based on program analysis, such

as code slicing and its variants, machine learning-

based techniques, including various kinds of neural

network, statistical debugging, model-based

techniques, and a family of methods based on test

result spectra. An overview of the approaches to fault

localization can be found in (Wong et al., 2016).

Spectra-Based Fault Localization (SBFL) is an

approach which collects execution results of test

cases: whether a program passed a test or failed. The

results are related to program units and code coverage

outcomes. This set of data is called the program

spectrum. Later, the spectrum is used for the

calculation of the metrics associated with the units of

the program under test. These program units that have

the highest metric values are the most suspicious, i.e.

are considered as places of possible faults.

Mutation testing has been proposed to evaluate

the quality of an existing test suite of a program and

also to create new tests. An overview of different

topics and achievements of this research area can be

found in (Papadakis et al., 2019). Mutation testing is

https://orcid.org/0000-0001-8792-203X

based on the idea of fault injection. One or more faults

are injected into the program code. The modified

program, called a mutant, is run against test cases. If

the tests detect the fault(s), these tests are counted as

good in revealing faults. Otherwise, additional tests

could be developed, if possible. The main limitation

of mutation testing is the high cost to apply it in

practice. Mutation testing has also been used in some

approaches to mutation-based fault localization

(MBFL): (Papadakis and Le Traon, 2015), (Moon et

al., 2014).

One of the ways to improve fault localization

efficiency at a reasonable cost is to combine different

approaches to fault localization. It has been studied,

for example, SBFL combined with statistical

debugging (Jiang et al., 2019), a variety of methods

in (Zou et al., 2019), or SBFL followed by mutation

testing (Cui, 2020), (Lobo de Oliveira et al., 2018),

(Xu, Zou and Xue, 2020), (Dutta and Godboley,

2021).

This paper contributes to the latter approach. We

have revisited the combination of SBFL with

mutation testing and performed a basic case study.

After discussing the results of the case study, we point

out some questionable issues in test realization and

interpretation, and practical tool support. As a result,

a framework for the approach has been prepared that

could assist in answering the identified research

questions and supporting the evaluation of the code

544

Derezi

nska, A. and Krutko, S.

Combining SBFL with Mutation Testing: Challenges of a Practical Approach.

DOI: 10.5220/0011093500003176

In Proceedings of the 17th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2022), pages 544-552

ISBN: 978-989-758-568-5; ISSN: 2184-4895

of the newer technology than discussed in the

previous research. Moreover, a new repository of

contemporary Java programs with real faults has been

launched.

The paper is structured as follows. The next

Section gives an overview of SBFL methods and

some mutation testing approaches. Related work is

commented on in Section 3. In Section 4, we explain

the main idea of the approach that joins SBFL and

mutation testing illustrated with a case study. Then,

we discuss the problems and present practical

solutions to support the approach. Finally, Section 6

concludes the paper.

2 BACKGROUND

2.1 Fundamentals of Spectrum-Based

Fault Localization

Spectrum-Based Fault Localization (SBFL) methods

use a statistical approach to evaluate test results

(Wong et al., 2016). For each test, a program

spectrum contains its outcome (pass or fail) and

information about code units covered during its

execution. The goal of the analysis is to calculate the

expected chance that a code unit includes a fault.

There have been proposed over thirty statistical

formulas to compute the suspiciousness of each code

unit. The summaries of selected formulas can be

found, for example, in (Wong et al., 2016) and

(Heiden et al., 2019). Based on the calculated metric,

we can obtain a ranking of the program elements in

descending order of suspiciousness.

As an example, suspiciousness s(j) of j-th code

unit is calculated with the Ochiai metric, one of the

popular SBFL methods, using the following formula

(Abreu, Zoeteweij, Golsteijn, and van Gemund,

2009):

𝑠

(

𝑗

)

𝑎



(𝑗)



(𝑎



(

𝑗

)

+𝑎



(

𝑗

)

)∗

(

𝑎



(

𝑗

)

+ 𝑎



(𝑗)

)

(1)

where

 a

(j) – the number of failed test cases that

cover unit j,

 a

(j) – the number of passed test cases that

cover unit j,

 a

(j) – the number of failed test cases that do

not cover unit j.

Following the notation used in unit testing

frameworks, in SBFL research, a failed test case is

one that has caused a program to fail, and a passed

test case is one that was passed by the code. The latter

is also called a successful test case (Wong et al.,

2016). Depending on the approach, in practice, a code

unit can be a code line, a statement, or a code block.

2.2 Mutation Testing in Fault

Localization

Fault localization can also use ideas of mutation

testing. In mutation testing, a mutant is a modified

program. A type of program modification is specified

by a mutation operator that typically reflects a

programming fault to be injected. Mutation tools

implement a set of mutation operators to inject faults

and create a set of mutants from an original program.

A mutant is killed if at least one of the tests detects

the injected fault. If the tests do not reveal any

difference in the program behavior, the mutant is said

to be alive.

Mutation-based methods identify suspicious

mutants and use them to find some faults that were

not previously localized in the original program. In

general, it is based on the following assumptions

(Papadakis and La Traon, 2015):

 Mutants-faults located in the same program

statements frequently exhibit a similar

behavior,

 Mutants-faults located in diverse program

statements exhibit different behaviors.

Evaluation of mutants should help detect which

tests are sensitive to faults in a given statement. This

could allow us to identify statements that are

potentially responsible for failed tests.

A basic method of mutation-based fault

localization is Metallaxis-FL (Papadakis and La

Traon, 2015). In this method, a mutant is classified as

killed if the test result is different from the test run on

the original program, i.e. a failed test was changed to

passed and a passed test was changed to a failed one.

A mutant M1 is said to have the same behaviour as

another mutant M2 if M1 and M2 are killed by the

same test cases. The degree of similarity in the test

cases that kill the mutants M1 and M2 defines the

behaviour similarity of these mutants.

Therefore, by measuring the number of mutants

killed by passing and failing test executions, one can

have an indication of the suspiciousness of those

mutants.

However, processing statements for which a

mutant was created could be questionable. In

Metallaxis-FL, if for a selected statement no mutant

was generated, its suspiciousness is treated as the

lowest and counted as zero. If for a statement more

than one mutant was created, the highest

suspiciousness is taken into account. A proposal of

Combining SBFL with Mutation Testing: Challenges of a Practical Approach

545

our modified approach to processing of results in

MBFL has been discussed in Sect. 5.

SBFL methods could also be combined with

mutation testing (Sect. 3.3).

3 RELATED WORK

3.1 Spectrum-Based Methods for Fault

Localization

Many SBFL methods have been developed that use

different formulas of suspiciousness. This raises the

question of the adequacy and efficiency of these

methods.

Nine SBFL methods have been evaluated in

experiments on a set of eight C programs, namely:

Jaccard, Tarantula, Ochiai, Sorensen-Dice,

Anderberg, Simple-matching, Rogers and Tanimoto,

Ochiai 2, Russel and Rao (Abreu, Zoeteweij,

Golsteijn, and van Gemund, 2009). In these

experiments, for each program, the Ochiai method

gave the highest accuracy in fault localization or at

least was as good as other methods. On average, the

results were 4% better for Ochiai than for other

methods.

Five SBFL methods (Tarantula, Ochiai, Op2,

Barinel, oraz DStar) have been used in experiments

conducted on programs with 3242 artificial faults and

323 real faults (Pearson, et al., 2017). The results

showed the superiority of the Op2 formulas over

other SBFL methods in the case of artificial faults.

However, the experiments also demonstrated that the

SBFL results of artificial faults are considerably

different from those of real faults. All five methods

gave similar results for real faults, but the best results

were for DStar and Ochiai.

Research carried out by (Zou, Liang, Xiong,

Ernst, and Zhang, 2019) aimed at comparison of

different groups of fault localization techniques.

SBFL was represented by two methods: Ochiai and

DStar. In the top 10 elements with the highest

suspicion, 44% of 357 faults were detected using

Ochiai and 45% using DStar. In this case, the SBFL

methods gave the best results compared to other fault

localization methods examined in the paper.

One of the problems is the range of suspicious

areas identified by SBFL that should be further

examined. In experiments reported in (Heiden et al.,

2019), while studding 10 of the most suspicious areas,

only 40% of faults could be detected. Therefore, and

additional post processing with other methods is

recommended.

3.2 Mutation-based Fault Localization

The mutation testing approach has been proposed for

fault localization by (Papadakis and La Traon, 2012),

and the idea extended to Metallaxis-FL (Papadakis

and La Traon, 2015). Similar prerequisites were used

in MUSE, a mutation-based approach using another

metric to calculate fault localization (Moon et al.,

2014). Direct mutation-based approaches are limited

by the high execution cost. Therefore, it could be

beneficial to pre-select a number of mutants, test

cases, test runs, or their combinations.

Mutation testing ideas have also been used in

program debugging and fixing of faulty programs

(Debroy and Wong, 2010).

3.3 Combination of SBFL with

Mutation-based Approaches

There are also several attempts to combine spectrum-

based methods with mutation-based methods to

locate faults.

In (Cui et al., 2020), a program is analyzed with

an SBFL (Ochiai and DStar). Then, mutants of the

program are generated and executed with MBFL.

Finally, the n-top suspicious statements according to

SBFL are re-ranked on the basis of the mutation

results using the Metallaxis and MUSE techniques.

The FTMES approach (Lobo de Oliveira et al.,

2018) has used only the set of failed test cases to

execute mutants and avoided the execution of passed

test cases, replacing the killing information with

coverage data. It has been shown that the approach

presented good solutions when the size of the failed

test case set is smaller than the set of passed test cases.

In the hybrid approach presented by (Xu, Zou, and

Xue, 2020), three different methods are combined.

First, the standard SBFL is used and the

corresponding program coverage is recorded. This

gives a ranking of the suspiciousness of the statement.

Then the k-top predicates (k = 10) are selected for

mutation testing. Only failed test cases are run against

mutants. Finally, the program slicing is applied.

The experiments on C programs reported in

(Dutta and Godboley, 2021) start with calculation of

a program spectrum with different SBFL methods

(Tarantula, Barinel, Ochiai, and DStar). The

programs are mutated and run against tests. The

mutation results are combined with the averaged

results of SBFL. An obstacle of this MBFL approach

is the high cost of mutation testing of whole

programs.

Most of the discussed works are limited to one

fault in a program.

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

546

4 CASE STUDY

In this Section, we present a case study on an

approach that combines SBFL with mutation testing.

4.1 A Subject of the Case Study

Case study experiments were carried out on a

program which performs a method of data

compression via textual substitution Lempel-Ziv-

Storer-Szymanski (LZSS) (Storer and Szymanski,

1982), which is a modification of the basic SL77

algorithm. The program has been implemented in

Java using the Spring Boot platform. The program

can be run in two modes: coding and decoding. It can

be called via a command line with appropriate options

to control its execution.

The program architecture is divided into two main

modules: encoder and decoder. These modules are

supplemented with Encoder and Decoder interfaces.

They are implemented by the classes EncoderImpl

and DecoderImpl. The first class realises the whole

functionality of the encoder module. The decoder

module contains five additional helper classes.

The program has been developed with a set of

twenty unit tests. The tests did not deal with the

functionality of the whole application, but the case

study was limited to a thorough testing of the

Encoder.encode() and Decoder.decode() methods, as

well as the selected helper methods. The tests give

100% class coverage, 95% method coverage, and

97% line coverage.

In order to evaluate the discussed approach, a fault

has been injected into the encode() method of the

EncoderImpl class on line 40. As a result, three unit

tests detected this error and failed.

4.2 Spectrum-Based Fault Localization

in the Case Study

In SBFL, suspiciousness degrees are assigned to code

extracts according to a program spectrum. A program

spectrum can be presented in a tabular form, as in

Table 1. A code line is selected as a basic code unit,

since most code coverage tools support line coverage.

Four test cases are identified in columns. The eight

rows correspond to selected code lines that include an

executable code. The first column includes the line

numbers. In the next columns, line coverages are

given, where ‘1’ denotes a line covered by the test in

this column, while ‘0’ means that a line was not

covered by the test. The last row brings the results of

the test execution: 1 – the program passed the test, 0

– the program failed for the test.

Table 1: Part of the spectrum of the LZSS program

(EncodedImpl class).

Line Test1 Test2 Test3 Test4

34 1 1 1 1

35 0 0 1 1

36 0 0 1 1

38 1 1 1 1

39 1 1 1 1

40 1 1 1 1

41 1 1 1 0

42 1 1 1 0

Test

result

0 0 0 1

Based on the formula of the Ochiai method (Sect.

2.1), the suspiciousness of the program lines was

calculated. The selected code lines in Table 1 were

covered only by tests 1-4. The suspiciousness of these

code lines is shown in Table 2.

Table 2: Suspiciousness of selected lines of the LZSS

program (Ochiai SBFL).

Line Failed

tests

Passed

tests

Suspiciousness

34 3 1 0.87

35 1 1 0.34

36 1 1 0.34

38 3 1 0.87

39 3 1 0.87

40 3 1 0.87

41 3 0 1

42 3 0 1

None of the tests of other classes has failed; hence,

the suspiciousness of other classes of the decoder

module equals zero. Therefore, after this first step in

fault localization, other classes were excluded except

the one that includes an injected fault.

The EncoderImpl class consists of four methods

and includes 84 lines of executable code. Lines 41

and 42 were assigned the highest suspiciousness,

value 1, as they were executed by failed tests only.

Next, 38 lines get suspiciousness equal to 0.87,

including line 40 that comprises the injected fault.

Code lines with the three highest degrees of

suspiciousness have been selected to be used in the

further evaluation.

4.3 Mutation-based Fault Localization

of the Case Study

After using the SBFL method, the code area under

concern was bounded to 61 lines of code. To this area,

mutation testing was applied. This method requires

the creation of many mutants and the execution of

Combining SBFL with Mutation Testing: Challenges of a Practical Approach

547

tests several times. Therefore, any limitation of the

number of suspicious code lines is worthwhile.

Mutants have been generated with (Pitest, 2021),

currently the most efficient mutation testing tool of

Java programs. The following Pitest mutation

operators have been used:

 BOOLEAN_FALSE_RETURN

 BOOLEAN_TRUE_RETURN

 CONDITIONALS_BOUNDARY_MUTATO

 EMPTY_RETURN_VALUES

 INCREMENTS_MUTATOR

 INVERT_NEGS_MUTATOR

 MATH_MUTATOR

 NEGATE_CONDITIONALS_MUTATOR

 NULL_RETURN_VALUES

 PRIMITIVE_RETURN_VALS_MUTATOR

 VOID_METHOD_CALL_MUTATOR

The results of the mutation testing for selected

lines are shown in Table 3. For each line, mutants are

identified that introduced changes in this code area.

In the column ‘Mutant’, the symbol ‘-‘ means that no

such mutant was generated, while numbers 1, 2, 3

denote consecutive numbers of mutants that refer to

this area. In the following columns, the results of tests

1-4 that are run against those mutants are given

accordingly. The number ‘0’ means that the program

failed the test, ‘1’ the program passed the test.

Table 3: Results of mutant testing for the selected code lines

of the LZSS program.

Line Mutant Test1 Test2 Test3 Test4

34 1 0 0 0 1

34 2 0 0 0 1

34 3 0 0 0 1

35 - - - - -

36 1 0 0 0 1

38 - - - - -

39 1 0 0 0 1

40 1 1 1 1 0

40 2 0 0 0 1

41 1 0 0 0 1

42 - - - - -

When comparing the results of the mutant tests

with the outcomes of the original program (Table 1),

we can observe that only for mutant number 1 when

referred to line 40 the results for all tests differ from

the original ones. For all other mutants, all tests gave

the same results as for the original program.

Therefore, we could suspect that there is a fault in line

40, which corresponds to the fault introduced before

the method evaluation.

4.4 Discussion

The application of an SBFL method as a first step

resulted in the limitation of a considered area to 73%

of the code under test. Therefore, the mutation testing

approach could have been applied to a smaller part of

a program and pointed directly at the suspicious area.

Taking into account the labor intensity of mutation

testing, it positively influences the cost of the

approach.

It is also important to note that the considered area

has been successfully limited to only one class, which

in Java means that the search area is limited to one

file. As was shown in (Parnin and Orso, 2011),

programmers do not follow the ranked suspiciousness

list linearly. They usually start with a file where the

highest-ranked element is located and go through all

the suspicious elements in the class, even if these

elements have a lower ranking value. This means that,

with respect to fault detection efficiency, the

following situation would be beneficial: even if the

highest-ranked element is not the faulty one, it should

at least point to the file that includes some faults. This

situation also occurred in the case study.

After the mutation test is applied to the selected

area, the faulty line has been correctly identified. This

could be counted as the success of the combination of

two selected methods (Ochiai and Metallaxis).

However, in general, this could not be true. In the case

presented, the fault was correctly localized because a

mutant created has changed an incorrect result to a

correct one.

5 CHALLENGES OF A

PRACTICAL APPROACH

Based on the experience of the case study, we have

identified a few problematic points and addressed

research questions. We also discuss tool support

issues of the developed framework.

5.1 Obtaining Program Spectra

A crucial prerequisite for SBFL is high code coverage

by tests. However, a simple code coverage is not

sufficient. In the formulas of all SBFL methods, an

important factor is the number of tests that failed and

cover the j-code unit. In general, to practically apply

SBFL methods and calculate statistical values, many

test cases should be associated with a program.

Moreover, multiple coverage is necessary, which

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

548

means that many, or at least several, test cases should

cover the same code elements.

The SBFL evaluation in a case study was based

on the Ochiai algorithm, counted as one of the more

efficient methods in several experiments. However, it

has not yet been concluded which method is the best.

Moreover, in the framework, it could be a good idea

to use several SBFL methods and combine their

results to select suspicious areas that could be further

evaluated in mutation testing.

The spectrum of the LZSS programs was

generated with the support of the Intelij Idea Code

Coverage Agent. Code coverage could be obtained,

for example, through CodeCoverage Agent or

JaCoCo. However, commonly used coverage tools

report on line coverage but do not provide the

information necessary to calculate spectra, that is,

which test covered a single line. Therefore, in the case

study, the test cases were executed separately and the

final information was merged using those separate

test results.

Some tools that support spectra-based analysis

obtain information from unit tests of Junit3 and Junit4

(GZoltar, 2022), but not from Junit5. In the developed

framework, JaCoCo has been incorporated, and the

process has been automated to acquire all the spectra

also from the currently used Junit5 library.

5.2 Processing of Failed Tests in

Mutation Testing

In Metallaxis, the suspiciousness of a statement is 0 if

none of the failed tests has been changed to a passed

one. This makes the approach hardly useful in many

cases. If a method returns a type of limited set of

values (like a Boolean or enum), there is a chance to

get a correct test result after introducing a mutation

that compensates for an existing fault. However, if a

result type returned by a method or its behavior is

more complex, then it is less probable that a

combination of two faults, i.e. an original with the one

injected by mutation, give a correct program result. If

a fault were in such an expression, the tests would fail.

Therefore, in the framework, the number of tests

changed from pass to fail should be counted in

suspiciousness evaluation, even though the non-

failure test was changed to the introduction of a

passed due to a mutation introduction in this

expression.

After the execution of the tests, the mutation tool

returns the state of execution of a mutant, ‘killed’ or

‘live’, and the information which tests have killed the

mutant. This could be used to automate the fault

localization process. However, Pitest does not allow

us to run mutants against tests that fail in an original

program. This could be logical for the typical

application of mutation testing, but is a limitation if

we want to use the results for fault localization

purposes. Moreover, it could be possible that a mutant

run with a failed test gives a positive result.

In the Pitest case study, the results were collected

for positive tests. Failed tests have been processed by

running mutants separately and collecting their

results. To automate the process for all types of tests,

the functionality of Pitest could be extended.

5.3 Differentiating Failed Tests in

Mutation Testing

Another problem is differentiating between various

types of failed test results. In mutation testing, we are

primarily interested in whether or not a mutant was

killed by any test. In the proposed approach, different

values obtained from failed tests could be

distinguished. In the determination of the final

suspiciousness, we could take into account tests that

change a program result in the following way:

 from pass to fail,

 from fail to pass,

 from fail to fail with the same result (“fail

invariant”),

 from fail to fail with another result (“fail

diversely”).

Therefore, a mutation testing platform should also

process test outcomes and, then, compare. Analyzing

these data could be beneficial, as the influence of the

results of a faulty program on the efficiency of the

fault location remains an open research question.

Research question 1: How will counting the tests

that failed with another result because of mutation as

tests that changed from fail to pass affect fault

localization efficiency?

5.4 Mutation Efficiency

An important aspect of mutation testing is its

efficiency. To achieve substantial savings in time and

space, the platform should provide additional

functionalities. The first one is the possibility of

precisely identifying the units (lines) of code that

should be mutated. The bigger the program, the more

costly the addition of a single mutant can be. Hence,

the result retrieved from SBFL should be used as a

direct line-by-line input for a mutation engine.

Secondly, the optimisation functionality already

provided by Pitest should be used. This optimisation

excludes from running the tests that do not cover a

code unit where a mutation is located. Therefore, the

Combining SBFL with Mutation Testing: Challenges of a Practical Approach

549

functionality provided by Pitest should be modified,

as it is impossible to collect complete coverage for a

failed test. That is why, in addition to all tests that

pass on the original program and cover the mutant,

failed tests should be run for each mutant.

5.5 Re-ranking Code Units for Which

No Mutants Were Generated

As mentioned above, the MBFL approach ranks all

code units without mutations as code with 0

suspiciousness. However, in the case of combining

spectrum- and mutation-based fault localization,

these units still have a ranking from the SBFL

technique. This might result in the actual faulty

statement being pushed to the bottom of the final

ranking if there are no available mutation operations

for the statement. We have not found any research on

whether reusing the SBFL suspiciousness ranking in

the final ranking could eliminate these scenarios and

improve the overall effectiveness of the combined

techniques. This open issue has to be verified.

Research Question 2: Will keeping the SBFL

score as the final score when no mutations were

created affect the effectiveness of spectrum-mutation-

based fault localization?

5.6 Evaluation of the Approach with

Contemporary Software

FL approaches are usually evaluated on programs that

include artificial or real faults. In (Pearson et al.,

2017), the same localization methods have been

compared using both types of faults. It was observed

that the results of artificial faults were not adequate

for evaluating programs with real faults. Therefore,

most of the research focused on programs with real

faults, eg., those collected in the Defects4J repository

(Just, Jalalj, and Ernst, 2014), (Defects4J, 2021).

To overcome certain limitations of Defects4J,

other sets of Java programs have been collected, e.g.

Bugs.jar (Saha et al., 2018) and BEARS Benchmark

(Madeiral et al., 2019).

However, the programs in these repositories are

written in Java 8 or earlier versions, and their unit

tests are in Junit 3 or Junit 4. In 2021, the 17

version

of Java was published. Although previous Java

versions are still commonly used, programs in Java

before version 8 could be treated as legacy code.

Since 2017, unit tests can be written with the Junit5

library. Therefore, a collection of faulty programs has

been launched in a new BugsRepo repository to

evaluate the approach also on some programs

developed using contemporary technology.

Research Question 3: Will evaluation of real

faults and newer versions of Java and Junit confirm

the results of previous research?

5.7 Framework Design

To address the above-mentioned issues, a new

spectrum-mutation-based fault localization

framework has been developed. The framework

consists of two parts: spectrum processing and

mutation processing. The spectrum module uses the

JaCoCo Java agent to instrument code classes. It

discovers the Junit5 tests, runs them sequentially, and

collects after each test the coverage data from the

agent. Based on the results, the SBFL suspiciousness

ranking is calculated for a range of different metrics.

Next, the top N suspicious code units (code lines) are

passed to the mutation module.

Mutation testing is performed with a modified

Pitest. This mutation tool has been extended with all

the required functionalities mentioned in Sections

5.2-5.4. During mutation testing, only the most

SBFL-suspicious units are taken into account.

Then, the final suspiciousness ranking is

produced.

6 CONCLUSIONS

Selected aspects of a process that combines SBFL

with MBFL have been presented. In the case study,

the suspicious code was considerably limited by

SBFL, and using MBFL to this area only, a previously

injected fault was found. To generalize the idea, new

recommendations are provided for processing the test

results of both approaches, which could improve the

efficiency and performance of fault detection. Most

of the suggestions refer to interpretation of failed tests

in mutation testing. We have formulated three

research questions that need further investigation.

A platform has been prepared to effectively

support the approach and further research on the

selection of different variants of SBFL metrics and

the processing of mutation testing results. It would

allow us to answer the identified research questions.

We have planned to carry out experiments with

real faults using not only legacy projects, as typically

in research, but also more contemporary projects in

terms of the Java language and Junit library. A new

bug repository will help to evaluate the known results,

for older Java and Junit versions, on newer

applications. Moreover, this supports the

development of tools that are compatible with newer

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

550

technologies. Without current easy-to-use tools, fault

localization can hardly be used in real life projects.

In the future, the platform could also be combined

with other fault localization approaches (Wong et al.,

2016), (Zakari et al., 2020), as well as fault prediction

methods (Caulo,2019), (Catal, 2011).

REFERENCES

Abreu, R., Zoeteweij, P., Golsteijn, R., van Gemund,

A.J.C., 2009. A practical evaluation of spectrum-based

fault localization. The Journal of Systems and Software,

82(11), 1780-1792. doi:10.1016/j.jss.2009.06.035.

Caulo, M., 2019. A taxonomy of metrics for software fault

prediction. 27th ACM Joint Meeting on European

Software Engineering Conference and Symposium on

the Foundations of Software Engineering. ESEC/FSE

2019, pp. 1144–1147. doi:10.1145/3338906.3341462.

Catal, C., 2011. Software fault prediction: A literature

review and current trends. Expert Systems with

Applications, vol. 38, no. 4, pp. 4626-4636. doi:

10.1016/j.eswa.2010.10.024.

Cui, Z., Jia, M., Chen, X., Zheng, L., Liu, X., 2020.

Improving software fault localization by combining

spectrum and mutation. IEEE Access vol 8, 172296-

172307. doi:10.1109/ACCESS.2020.3025460.

Debroy V., Wong, W.E., 2010. Using mutation to

automatically suggest fixes for faulty programs. In:

Third International Conference on Software Testing,

Verification and Validation, pp. 65–74.

doi:10.1109/ICST.2010.66.

Defects4j on GitHub. [Online] [Accessed 29 Dec 2021]

Available from https://github.com/rjust/defects4j.

Dutta A., Godboley S., 2021. MSFL: A model for fault

localization using mutation-spectra technique. In:

LASD’2021, Lean and Agile Software Development.

LNBIP, vol 408. pp 156-173, Springer, Cham. doi:

10.1007/978-3-030-67084-9_10.

GZoltar – Java library for automatic debugging. [Online]

[Accessed 25 Jan 2022] Available from

https:/github.com/GZoltar/gzoltar.

Heiden, S., Grunske, L., Kehrer, T., Keller, F., van Hoorn,

A., Filieri, A., Lo, D., 2019. An evaluation of pure

spectrum-based fault localization techniques for large-

scale software systems. Journal of Software: Practice

and Experience. 49(8) pp. 1197-1224.

doi:10.1002/spe.2703.

Jiang, J., Wang, R., Xiong, Y., Chen, X., Zhang, L., 2019.

Combining spectrum-based fault localization and

statistical debugging: an empirical study. In: ASE’19,

IEEE/ACM International Conference on

Automated Software Engineering. pp. 502-514. IEEE

Comp. Soc. doi.10.1109/ASE.2019.00054.

Just, R., Jalali, D., Ernst, M. D., 2014. Defects4J: a database

of existing faults to enable controlled testing studies for

Java programs. In: ISSTA’2014, International

Symposium on Software Testing and Analysis.

doi:10.1145/2610384.2628055.

Lobo de Oliveira, A.A., Camilo-Junior, C. G., Noronha de

Andrade Freitas, E., Rizzo Vincenzi, A. M., 2018.

FTMES: A failed-test-oriented mutant execution

strategy for mutation-based fault localization. In: IEEE

29th International Symposium on Software Reliability

Engineering, pp. 155-165. doi:

10.1109/ISSRE.2018.00026.

Madeiral, F., Urli, S., de Almeida Maia, M., Monperrus,

M., 2019. BEARS: An extensible Java bug benchmark

for automatic program repair studies. In: SANER’2019,

IEEE 26

Conference on Software Analysis, Evolution

and Reengineering. pp. 468-478. doi:

10.1109/SANER.2019.8667991.

Moon, S., Kim, Y., Kim, M., Yoo, Y., 2014. Ask the

mutants: mutating faulty programs for fault

localization. In: Proceedings of IEEE International

Conference on Software Testing, pp. 153–162. doi:

10.1109/ICST.2014.28.

Papadakis, M., Kintis, M., Zhang, Jie, Jia, Y., Le Traon, Y.,

and Harman, M., 2019. Chapter Six - Mutation testing

advances: an analysis and survey. Advances in

Computers. 112, pp. 275-378. Elsevier.

doi:10.1016/bs.adcom.2018.03.015.

Papadakis M, Le Traon Y. 2012. Using mutants to locate

“unknown” faults. In: IEEE Fifth International

Conference on Software Testing, Verification and

Validation, pp. 691–700. doi:10.1109/ICST.2012.159.

Papadakis, M., Le Traon, Y. 2015. Metallaxis-FL:

Mutation-based Fault Localization. Software Testing,

Verification and Reliability 25, pp. 605-628.

doi:10.1002/stvr.1509.

Parnin C, Orso A., 2011. Are automated debugging

techniques actually helping programmers? In:

ISSTA’2011, Proceedings of the 2011 International

Symposium on Software Testing and Analysis, pp.199-

209. doi:10.1145/2001420.2001445.

Pearson, S., Campos, J., Just, R., Fraser, G., Abreu, R.,

Ernst, M.D., Pang, D., Keller, B., 2017. Evaluating and

improving fault localization. In: IEEE/ACM 39th

International Conference on Software Engineering

(ICSE), pp. 609-620. IEEE doi:10.1109/ICSE.2017.62.

Pitest.org.[Online] [Accessed 29 Dec 2021] Available

from: https://pitest.org/.

Saha, R., Lyu, Y., Lam, W., Yoshida, H., Prasad, M., 2018.

Bugs.jar: A large-scale, diverse dataset of real-world

Java bugs. In: IEEE/ACM 15

International

Conference on Mining Software Repositories (MSR),

pp. 10-13. doi:10.1145/3196398.3196473.

Storer, J.A., Szymanski, T.G., 1982. Data compression via

textual substitution. Journal of the ACM. 29(4) pp. 928-

951. doi:10.1145/322344.322346

Wong, E., Gao, R., Li, Y., Abreu, R., Wotawa, F., 2016. A

survey on software fault localization. IEEE

Transactions on Software Engineering 42(8), pp. 707-

740. doi:0.1109/TSE.2016.2521368.

Zakari, A., Lee, S.P., Abreu, R., Ahmed, B.H., Rasheed,

R.A., 2020. Multiple fault localization of software

programs: a systematic literature review. Information

and Software Technology, 124, 106312.

doi:10.1016/j.infsof.2020.106312.

Combining SBFL with Mutation Testing: Challenges of a Practical Approach

551

Zou, D., Liang, J., Xiong, Y., Ernst, M. D. Zhang, L. 2019.

An empirical study of fault localization families and

their combinations. IEEE Transactions on Software

Engineering, 47(2), 332-347. doi:10.1109/TSE.2019.2

892102.

Xu, X., Zou, C., Xue, J., 2020. Every mutation should be

rewarded: Boosting fault localization with mutated

predicates. In: International Conference on Software

Maintenance and Evolution. IEEE pp.196-207.

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

552
