Automating Security in a Continuous Integration Pipeline

Sohrab Chalishhafshejani

, Bao Khanh Pham

and Martin Gilje Jaatun

1, 2 a

IDE, UiS, Stavanger, Norway

SINTEF Digital, Trondheim, Norway

Keywords:

DevSecOps, DevOps, Software Security, Cyber Security, Continuous Integration.

Abstract:

Traditional approaches to software security are based on manual methods, which tend to stall development,

leading to inefﬁciency. To speed up a software development lifecycle, security needs to be integrated and

automated into the development process. This paper will identify solutions for automating the security phase

into a continuous software delivery process, integrating security tools into a Github repository by using Github

Actions to create automated vulnerability scanning workﬂows for a software project.

1 INTRODUCTION

Aggressive competition in software companies has

led to shortening applications’ time-to-market inter-

vals in order to receive feedback and evaluate the mar-

ket faster before further development. As a result, ag-

ile software development has been introduced to bring

the development team closer to business teams. This

model tries to add new features on each iteration of

the software lifecycle and build up features optimized

based on end-user needs (Kumar and Goyal, 2020).

In recent years, software development has been

shifting from delivering software as a product to a

Software-as-a-Service principle. Hence, the software

has been shifted from on-premises servers to cloud

solutions. This enables providers to deploy new soft-

ware features in short intervals without being con-

cerned about backward compatibility issues (Myr-

bakken and Colomo-Palacios, 2017).

Traditionally, the development team was respon-

sible for creating logic and core features of the pro-

gram, and the operation teams handled deploying the

app on the server/cloud. The two parties were nor-

mally only connected via ticketing systems, and prob-

lems along the way required sending and receiving

several tickets between the development and opera-

tions team.

The solution was to merge Development and Op-

erations into the DevOps paradigm, where operations

traditionally handled by the operations team such

as building and testing are automated, resulting in

https://orcid.org/0000-0001-7127-6694

shorter time to deploy changes, achieving continuous

development and delivery. Companies like Google

and Microsoft ﬁrst stepped into the game and intro-

duced pre-made DevOps utilities and software (Leite

et al., 2019).

In contrast, there are several trade-offs to this ap-

proach of software delivery. DevOps engineers try to

push code batches in short intervals and it will force

security teams to review the newly generated code

faster. Traditionally (Howard and Lipner, 2006) all

security analysis procedures like vulnerability scan-

ning and code review were done manually by the se-

curity team (Kumar and Goyal, 2020), resulting in ei-

ther delayed releases or insufﬁcient security if mis-

conﬁgurations, hardcoded passwords, or other dan-

gerous concerns slip through the controls.

There is a need for faster security checks and au-

tomated testing systems which can reduce the amount

of manual work needed to be performed by security

teams. Therefore, the DevSecOps concept was born

to effectively combine DevOps and Security; integrat-

ing an automated continuous security model with a

regular Continuous Integration and Continuous Deliv-

ery (CI/CD) pipeline through vulnerability scanning

tools. These tools are added to the many phases of

the software continuous delivery pipeline.

In this paper, we are going to look for possi-

ble ways to automate software security checks in

the DevSecOps procedure by building up a work-

ﬂow from security tools. This workﬂow has been

tested with three open-source projects and one real-

life project from the development organization that

serves as our case study (referred to in the following

Chalishhafshejani, S., Pham, B. and Jaatun, M.

Automating Security in a Continuous Integration Pipeline.

DOI: 10.5220/0011083500003194

In Proceedings of the 7th International Conference on Internet of Things, Big Data and Security (IoTBDS 2022), pages 231-238

ISBN: 978-989-758-564-7; ISSN: 2184-4976

231

by its pseudonym “ACME”). This will help compa-

nies to scale up security in the whole DevOps process

with a one-time effort by changing the pipeline and

integrating security into it.

2 MOTIVATION

Despite the successes of the Microsoft Security De-

velopment Lifecycle (Howard and Lipner, 2006) and

the focus that has been afforded software security in

the last decade and a half (McGraw, 2006; Williams

et al., 2018), the average developer still does not pos-

sess the requisite skills for developing secure soft-

ware (Oyetoyan et al., 2017). Traditionally, the need

for strong software security measures has not been

high enough on management’s radar to convince them

to invest more in it. Manual security procedures are

prone to human error, and are also slowing the whole

speed-to-market requirements of modern application

development environments.

2.1 Problem Deﬁnition

The real question that arises here is what do we have

to automate? There are several phases in software

development that each can be a target by malicious

actors. It is recommended that organizations look

back at their whole infrastructure and try to under-

stand where they can apply security measures in their

DevOps environment. In addition, the infrastructure

of applications is now more volatile since it is shifted

more to Cloud Native apps and infrastructure as a ser-

vice (IaaS) platform. These security measures must

contain ways to ensure security. Containerized envi-

ronments and microservice development also create

new concerns which must be considered.

2.2 Use Cases/Examples

Despite some attention from the industry in recent

years, the amount of academic research on De-

vSecOps is still meager (Jaatun et al., 2017; Ra-

japakse et al., 2021). However, there are quite a

few practitioners who have researched, experimented,

and published their gray literature reports (white pa-

pers, blogs, articles, etc.) (Myrbakken and Colomo-

Palacios, 2017; Mao et al., 2020). Besides, there

is a growing choice of tools for companies to build

their own pipelines. All major service providers strive

to build and deliver the best platforms and frame-

works for their customers, and security companies

try to create tools that can be integrated with those

platforms. Major platforms include Github Actions,

Amazon Web Services, Microsoft Azure, and Gitlab.

Also, some companies choose to combine different

tools and platforms or develop tools for internal use.

2.3 Challenges

Although promising to bring practical results, the ap-

plication of automated security testing in the CI/CD

pipeline in practice also faces certain difﬁculties. Be-

low are the difﬁculties in applying DevSecOps men-

tioned by Myrbakken and Colomo-Palacios (Myr-

bakken and Colomo-Palacios, 2017).

• The new DevSecOps process must match the De-

vOps process; automated security checks have to

be integrated into the existing CI/CD pipeline and

have to be truly efﬁcient at its speed.

• Volatility implies changes to:

– Techniques – Security engineers must under-

stand the DevOps process and developers must

learn basic security skills and standards.

– Process speed – Security scanning tools are

time-consuming for each new build.

– Culture – There will be a change in the culture

of working at the company as security teams

and product development teams combine. In

addition, the understanding of security must

also be disseminated to all other departments

to get a truly secure process.

– Standards – New security standards will be ap-

plied and updated continuously.

• Choosing the right tool for each platform is also

a job that requires attention. Good tools are not

necessarily suitable for the platform used by the

company if they are not effectively integrated. Be-

sides, not all tools are available to be integrated.

Some tools have to be created or redeveloped from

existing open-source code.

3 DEVELOPMENT LIFECYCLE

Software development lifecycle (SDLC) is the pro-

cess of a software project being developed and op-

erated. It usually involves major stages such as plan-

ning, implementation, testing, operation, and mainte-

nance. Some of the oldest and most popular SDLC

models include the waterfall model or the V-Model

(Balaji and Murugaiyan, 2012). However, along with

the development of technology, those old models

were outdated and no longer suited to the needs of the

software development industry. At that time, Agile

IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security

232

was introduced as the preeminent software develop-

ment model, and later, other models were gradually

developed by researchers and engineers.

3.1 Agile Software Development

The Agile development story started when a group

of software consultants signed the Manifesto for Ag-

ile Software Development in 2001 (Rehkopf, 2001).

Traditional methods of software development like the

waterfall method did not take into account the un-

predictability aspect of the development environment

(Rao et al., 2011), focusing on sequential work it-

erations and preparing requirements for each part of

the design before moving to the next part. Testing

teams were only involved in the ﬁnal phase of de-

velopment and problems were hidden until the test-

ing phase. This method was not ﬂexible to market

and business. Any changes had to be completely re-

searched and put in the next release of development

(Balaji and Murugaiyan, 2012). On the other hand,

the Agile method was introduced and it has been the

leader for many years. Agile puts user feedback in

front and welcomes changes from the market or users

at any time during the development procedure.

Agile meant that software development cycles

were reduced and ﬁnished products could be shipped

faster. This is beneﬁcial to companies, since prod-

ucts are exposed to users faster and feedback could

be gathered to polish the current development process

based on user needs. Recent years have seen the intro-

duction of agile variants such as Kanban (Huang and

Kusiak, 1996) and Scrum

. Kanban focuses more on

maximizing efﬁciency and reducing work currently

in progress by each team based on their capabilities.

The Scrum method tries to create short development

runs called Sprints to create software and evaluate it

at each iteration (Rehkopf, 2020). These methods are

the foundation of software delivery lifecycles and will

play a big role in software development companies.

3.2 DevOps Methodology

The ﬁrst Agile real-world implementations (Rehkopf,

2001) were mainly concerned about how it is possible

to improve the overall development experience. How-

ever, developers were only focusing on code delivery

at the time. The path for the codebase to reach clients

was taken care of by the operation team. These two

teams were incomplete with different pathways of de-

livery ideology. Development teams were based on

swift actions and changes while the operations team

https://www.scrum.org/resources/what-is-scrum

only focused on stability and predictability of soft-

ware changes. DevOps is a unique software delivery

methodology that focuses on principles and practices

to bridge the gap between development and opera-

tion teams, with continuous feedback and response

pipelines which will also result in reduced software

development cycle time (Jabbari et al., 2016).

The main difference between Agile and DevOps

is that DevOps heavily focuses on collaboration be-

tween Development and Operations teams. In addi-

tion, it has been creating standards for pipelines and

automated delivery methods which helps developers

to publish their code into production with less has-

sle. This will lift the workforce from operation teams

and make them available to monitor the product and

work closely with the development team to ﬁx prob-

lems along the way in production (Leite et al., 2019).

Automation is one of the key roles in DevOps prac-

tices and should be applied whenever and wherever

possible. There are several areas in which DevOps

have been constantly focusing on improvement which

are mentioned below.

3.3 DevOps Focus Areas

In the previous section, we have identiﬁed DevOps

principles like increased deployment frequencies and

reduced time to market. Achieving these goals re-

quires fundamental changes in several areas in the

software development environment.

3.3.1 Team Collaboration

In a software project, the collaboration between teams

is a key to keep products stable since changes are

implemented fast and on the go. Reducing delays

and communication gaps is important, and can only

be applied by new tools and cultural change in the

whole software company. Collaboration software en-

ables development and operation teams to go beyond

emails, physical meetings, and regular talks and bring

on a new level of connectivity (Hegde and Singh,

2020). Tools like Slack, Jira, Trello, and Codesourcer

are examples of collaboration technologies that are

widely used in industry to connect teams that are

sometimes even geographically far away from each

other. However, they should be accompanied by a

reform in the mindset of teams to include coopera-

tion and teamwork culture in the employees. Regu-

lar feeds from different phases of application devel-

opment like unit testing and code analysis enable all

parties to detect and solve issues faster.

Automating Security in a Continuous Integration Pipeline

233

3.3.2 Automation Wherever Possible

In practice, phases of an SDLC are often continu-

ous. The lifecycle is repeated over and over again,

and steps like planning, developing, building, testing,

or deploying the software are continuous cycles (Vir-

mani, 2015). When applying DevOps to those stages,

one of the most important things we need to pay at-

tention to is optimizing the performance of the work.

To do that, the automation of repetitive steps without

the intervention of engineers is essential. Processes

like building, testing, and deploying often repeat in

large numbers, even with very small changes to the

code. To handle these phases manually, the develop-

ers and operators will take a lot of time to complete.

Therefore, DevOps encourages automation wherever

possible. Automation saves more time during repet-

itive tasks, such as building and testing newly added

code or modiﬁed old code (Ebert et al., 2016). By

using automation, engineers can have more time for

other stages that cannot be automated, such as plan-

ning, coding, or debugging.

3.3.3 Monitoring

Since automation is a critical DevOps goal, monitor-

ing is indispensable for automation to follow its exact

trajectory. Monitoring the system to make sure the

system, pipeline, and tools are working as they should

be. Once a problem occurs at any stage, it’s easier and

more efﬁcient to resolve it with a carefully monitored

system (Schlossnagle, 2018). In fact, software logs

are often cumbersome and confusing, which makes

it difﬁcult for engineers to analyze and process them.

However, quite a few engineers today still use purely

manual debugging tools, which results in a signiﬁ-

cant reduction in productivity. With automated assis-

tive tools, monitoring and measurement can be better

accomplished (Ebert et al., 2016). System monitor-

ing and automation are interrelated, where monitoring

makes automation more accurate, while automation

makes monitoring faster.

3.4 CI/CD Pipeline

The CI/CD pipeline, which has the basic components

Continuous integration (CI) and Continuous Deliv-

ery (CD), is basically an Agile-based pipeline for

SDLC optimization. The CI/CD pipeline is intri-

cately constructed to ensure phases of software de-

velopment can be continuous. In recent times, the

CI/CD pipeline has gradually become an important

component in software development, making SDLC

more ﬂexible, more efﬁcient, and faster. Finally, with

the rise of cloud solutions and big cloud providers

releasing command-line tools for deploying applica-

tions, continuous deployment has been added to the

SDLC as a ﬁnal step on the pipeline. Here we focus

on each of these phases in detail.

3.4.1 Continuous Integration

CI is the process that allows software developers to

integrate new code into the original repository as well

as share them throughout the workﬂow. Along with

that, CI automation also allows detecting any error

at an early stage to commit the problem to be solved

immediately when it occurs (Virmani, 2015). When

the new code is merged with the existing repository, a

new version will be activated. After the build is com-

pleted, test runs are automatically performed against

the build to ensure nothing goes wrong. The integra-

tion is continuous (making it to be the ”C” in CI).

The build automatically veriﬁes the code every time

the developer pushes their changes to the repository.

Therefore, development teams may determine prob-

lems early and have time to come up with solutions.

3.4.2 Continuous Delivery

Inspired by distributors and deliveries, CD is a soft-

ware engineering approach based on software produc-

tion in short cycles, which makes it easy for publish-

ers to test, build, and deploy regularly. At the same

time, it also reduces costs and risks when changes oc-

cur. CD is considered as an extension of the CI, and

is the regular code upgrade to ensure the quality as-

surance (QA) (Chen, 2015). The CD phase occurs

at the end of the CI cycle and is responsible for the

automatic distribution of the integrated code from the

development stage to the production stage (Virmani,

2015). CD is not only tasked with automatically send-

ing the integrated code, but also ensuring the code is

sent with no errors or delays. This phase helps devel-

opers to incorporate new code into the main branch

with a high degree of consistency. The CD part of

the cycle is also responsible for checking code qual-

ity and performing checks to ensure a functional build

can be released into the production environment.

3.4.3 Continuous Deployment

CI/CD process made massive changes in codebase

manageable and possible during the daytime. Contin-

uous deployment is another ”CD” with a purpose be-

yond continuous delivery (Shahin et al., 2017). Con-

tinuous deployment tries to deliver these changes to

end-users at a more accelerated speed. This approach

tries to automate the deployment process and de-

liver up to hundreds of deploys in a day. Currently,

IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security

234

tech giants like Facebook and Flickr have adopted

this method. Software as service solutions and API-

Driven(Goteti, 2015) software facilitates projects to

have daily updates hidden from the end-users (Savor

et al., 2016). In conclusion, continuous delivery re-

leases software to deployment as soon as the tests

have passed in development. It will make features

time to market even lower than before.

4 SECURITY IN SOFTWARE

DEVELOPMENT

When it comes to software security, there are many

possible approaches, one of them is the security of

the product itself which may contain the issues that

the code and builds carry full security features. To

ensure this, engineers can implement a variety of

methods such as periodically scanning for vulnerabil-

ities in software, both static and dynamic code; con-

stantly checking and updating libraries or dependen-

cies; make sure not to use sensitive hard-coded vari-

ables; etc. Essentially, product security is to ensure

that products that are deployed will not create vulner-

abilities that could compromise the system on which

the product is installed. On the other hand, security

problems of the development process should also be

considered. Since systems used to develop products

may be subject to attacks from cyber criminals or ad-

versaries, engineers must ensure thorough construc-

tion of a pipeline or SDLC. This system must be con-

sidered carefully in terms of security such as conﬁ-

dentiality, availability, and integrity. In general, the

two views above are similar to the two sides of the

coin, they must coexist and support each other so that

the product can be considered secure (Assal and Chi-

asson, 2018; Talukder et al., 2009).

4.1 DevSecOps

In a traditional software development process, secur-

ing a product was often done independently by the

security team, separate from the development team.

However, a prerequisite for DevOps is speed, the

combination of the development team and the op-

eration team and leaving the security team to work

separately does not meet the needs of the industry.

Hence, in recent times, the DevSecOps concept was

posed as an upgrade for DevOps, when it was aimed

at integrating additional security into DevOps proper-

ties (Myrbakken and Colomo-Palacios, 2017).

DevSecOps arise with the requirement of secure

output from the DevOps process. However, it is chal-

lenging in real-world implementations to introduce

security to the DevOps process. Firstly, there are sev-

eral toolsets available for DevSecOps. This brings in-

consistency between each organization’s implemen-

tation. Operations teams may be proﬁcient in differ-

ent programming languages and tools written based

on them. There is currently a lack of standard De-

vSecOps implementation speciﬁcations. This leads to

different opinions between operation teams with other

parts of the organization. In addition, new DevOps se-

curity tools have to be tested themselves to ensure the

overall security of the organization (Rajapakse et al.,

2021).

4.2 Security Requirements of the

Organization

Security baselines are a group of pre-deﬁned conﬁg-

urations and checks which ensure that the develop-

ment environment complies with companies’ overall

security policies. These policies are established by

well-known tech giants or even governmental organi-

zations to keep businesses and companies safe from

cyber threats. For instance, ”Microsoft Windows se-

curity baselines”

is an example of security base-

lines provided by Microsoft corporation.Companies

can have different deﬁnitions of security baseline in

their environment. For instance, a company providing

an online Application Programming Interface (API)

for travel ticket booking may have a lower security

baseline compared to a ﬁnancial company handling

sensitive transaction data. Security baselines can be

broken into sections and applied as release gates. Re-

lease gates are critical checkpoints in an SDLC. These

gates halt speciﬁc software release processes in case

of reaching a security weakness threshold (Chung,

2018). Introducing several release gates at once will

exhaust developers by lots of failed builds and re-

leases. They have to be introduced gradually while

the development team gets to know the new workﬂow

of the pipeline. It is possible to integrate release gates

in several SDLC stages like design, coding, testing,

and deploying. As a result, these security checks can

improve overall software quality and security in long-

term usage.

4.3 Where to Start

Deﬁning a security testing baseline starts by estab-

lishing minimum expectations from tests to be valid.

Several industry-standard references have been al-

ready working on application security baselines in the

https://docs.microsoft.com/en-us/windows/security/

threat-protection/windows-security-baselines

Automating Security in a Continuous Integration Pipeline

235

past. The Open Web Application Security Project

(OWASP) is the leading foundation supporting open

source software security projects. The OWASP

Application Security Veriﬁcation Standard (ASVS)

project tries to document several in-depth veriﬁca-

tion steps to ensure application security at different

security baselines. ASVS consists of 3 levels which

makes it suitable for different companies with differ-

ent security requirements. In this paper, we are trying

to cover basic ASVS recommendations which can be

covered by automated tests. This includes code scan-

ning, static and dynamic security testing, and moni-

toring.

5 INSERTING SECURITY IN THE

CI/CD PIPELINE

It is possible to insert automated security measure-

ments to improve and assess the security of software

before it reaches the users. The following sections

present different parts of the pipeline which can be

strengthened by security measures.

5.1 IDE Plugins and Linters

Text editor applications are being used every day

by developers to produce and commit code. Error-

checking tools created as a plugin for text editors

are commonly called linters. E.g., the Visual Studio

code editor maintains several linters like ESLint

and

SonarLint

. When using linters, several bugs and se-

curity issues are prevented even before reaching the

pipeline. In addition, it is possible to integrate linters

in the pipeline process. Each alternative has advan-

tages and disadvantages. Plugin linters will reduce

the pipeline running time because it has already ﬁxed

parts of issues before reaching the pipeline, and it is

less likely that the pipeline fails.

5.2 Static Code Analysis

Static Code Analysis (SCA)tries to discover vulnera-

bilities while the code is not in running mode. This

type of analysis is often associated with white-box

analysis due to access to the source code of the appli-

cation. SCA uses methods like Taint Analysis (Kurni-

awan et al., 2018) and Data-Flow Analysis (Kronjee

et al., 2018). Taint analysis tries to detect patterns re-

lated to injection vulnerabilities. It tries to identify

https://owasp.org/asvs

https://eslint.org/docs/about/

https://www.sonarlint.org/features/

tainted variables and traces them to possible vulnera-

ble functions known as a ‘sink’.

5.3 Dynamic Security Testing

Dynamic Application Security Testing (DAST) tools

try to have a black box view of the application. There

is no prior knowledge about the codebase or database

design for these tools while running. The goal is to

simulate and assess conditions in real life when the

software is exposed to the network. This type of

tool is developed to be running on already deployed

apps in a simulated production environment. Organi-

zations normally deploy software in speciﬁc environ-

ments via containerization applications like Docker

and Kubernetes

. Containerization tools will give a

suitable environment for the app to run over particular

ﬁrewall and storage conﬁgurations. DAST tools try to

access the application deployed on containers over or-

dinary network connection means like HTTP requests

or database connection requests (S

onmez and Kilic¸,

2021). Requests to the application can be tweaked to

do a stress test on the whole application. Scenarios

such as Denial of Service attacks and other known at-

tacks can be simulated. Zed Attack Proxy (Bennetts,

2013) and Burpsuite

are examples of dynamic appli-

cation security tools. DAST tools consist of mecha-

nisms to bypass some security measures to go deeper

into the scanning process. For instance, it is possi-

ble to bypass authentication by injecting authentica-

tion data in requests. As a result, organizations can

estimate their software resistance to known attacks in

case somebody acquires credentials and bypasses the

authentication checkpoints.

6 PROPOSED SOLUTION

We aim to improve the software security pipeline in 3

main areas; development, pre-deployment, and post-

deployment phase. The goal is a solution that has

minimum conﬁgurations per repository, and can eas-

ily reproduce outcomes on different pipelines. This is

important in the later adoption of the work since it can

be implemented with a minimum of additional burden

on the development team.

https://www.docker.com/

https://kubernetes.io/

https://portswigger.net/burp/enterprise

IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security

236

6.1 CI Tools

The ﬁrst step is choosing the right CI tool. The ﬁrst

important feature to be considered is the ability to host

the product on-premises or on the cloud. The second

factor is integration and support. Finally, container-

ization support is a must for the tool chosen for secu-

rity testing. Containers enable developers to develop,

test and deploy software more reliably by keeping the

environment continuously the same. We have chosen

Github Actions

as our tool since it meets all require-

ments mentioned above.

6.2 Security Tools

Github Actions combines features of a pipeline with

Github source control and repository management ca-

pabilities. Individual software developers and compa-

nies active in cyber security can release tools based on

the Github Actions platform. It brings new capabili-

ties for security players in the market to integrate their

tools with the platform.

6.3 Scanning & Dependency Checking

Codebases are always prone to include vulnerabili-

ties that are easily detectable by machines. Although

there could be possible logical vulnerabilities in appli-

cations, it is possible to prevent others by automated

pipelines. There have been several comparisons be-

tween SCA tools (Mantere et al., 2009; Kaur and

Nayyar, 2020).

We have tried several tools like SonarQube, Snyk,

and Fortify; here there is not a clear winner since each

tool is presenting better features in different sectors.

E.g., SonarQube provides extensive capabilities in de-

tecting code smells and providing code review while

Snyk is better at dependency scanning and security

measures.

6.4 Open-port Scanning

We have used Github Actions to provide monitoring

capabilities. A script will run the NMap

applica-

tion at different time intervals during the day. NMap

is a free open source software that is widely used by

network administrators to perform network discov-

ery and auditing. We have used NMap software in

our automated pipeline to watch over the company’s

deployed apps and report which ports are currently

https://docs.github.com/en/actions

https://nmap.org/book/man.html

open. Later on, the company can use this data to de-

tect misconﬁgurations or internal mistakes which lead

to open exposed ports in their network.

6.5 SSL/TLS Evaluation

We have been working on the pipeline to provide se-

curity checks to check for SSL/TLS version and con-

ﬁguration. This test will be part of the pipeline and

can be run automatically in time intervals.

6.6 Integration and Automation

Github Actions use virtual machine runner instances

to run pipelines. Each pipeline occupies portions of

the runner’s computational power and bandwidth us-

age. It is important that our automated pipeline is efﬁ-

cient, only running tests and builds whenever needed.

It is possible to run tests on special conditions and

Github runners will initiate the action whenever the

trigger conditions are met. If all the pipeline tests run

on every push to the repositories, this will exhaust the

runners, and jobs will be in long queues before they

could be completed. In addition, speciﬁc tests like

SSL/TLS scans are time-consuming and will keep the

runners busy for longer periods. We tried to develop

smart pipelines that try to expand the runner’s idle

time by assigning pipeline triggers to persons com-

mitting the code. As an example, user experience

and UI design teams’ commits are ignored by runners.

Developers’ commits will trigger static analysis, code

coverage, and code smell pipelines. SSL/TLS scans

and port scans work in parallel in time intervals with-

out attachment to commits. Finally, commits to mas-

ter will run all possible runners to check before the

new code is added to the system (Github, 2021).

7 CONCLUSION

In this paper we have studied challenges and iden-

tiﬁed solutions for integrating security in a DevOps

Continuous Integration pipeline. We have constructed

a DevSecOps pipeline which has been deployed in a

software development organization, and preliminary

feedback is positive. For further work, it would be in-

teresting to assess the impact of the new pipeline in a

longitudinal case study.

ACKNOWLEDGEMENTS

This paper is based on the two ﬁrst authors’ MSc the-

sis at the University of Stavanger.

Automating Security in a Continuous Integration Pipeline

237

REFERENCES

Assal, H. and Chiasson, S. (2018). Security in the soft-

ware development lifecycle. In Fourteenth Symposium

on Usable Privacy and Security (SOUPS 2018), pages

281–296, Baltimore, MD. USENIX Association.

Balaji, S. and Murugaiyan, M. S. (2012). Waterfall vs.

V-Model vs. Agile: A comparative study on SDLC.

International Journal of Information Technology and

Business Management, 2(1):26–30.

Bennetts, S. (2013). Owasp zed attack proxy. AppSec USA.

Chen, L. (2015). Continuous delivery: Huge beneﬁts, but

challenges too. IEEE Software, 32.

Chung, A. (2018). How DevOps can use quality gates for

security checks.

Ebert, C., Gallardo, G., Hernantes, J., and Serrano, N.

(2016). DevOps. IEEE Softw., 33(3):94–100.

Github (2021). Events that trigger workﬂows.

Goteti, H. (2015). API Driven development , bridging the

gap between providers and consumers.

Hegde, V. and Singh, A. (2020). Team collaboration in De-

vOps: Accenture.

Howard, M. and Lipner, S. (2006). The Security Develop-

ment Lifecycle. Microsoft Press.

Huang, C.-C. and Kusiak, A. (1996). Overview of Kan-

ban systems. International Journal of Computer Inte-

grated Manufacturing, 9(3):169–189.

Jaatun, M. G., Cruzes, D. S., and Luna, J. (2017). Devops

for better software security in the cloud. In Proceed-

ings of the 12th International Conference on Avail-

ability, Reliability and Security, ARES ’17, pages

69:1–69:6, New York, NY, USA. ACM.

Jabbari, R., bin Ali, N., Petersen, K., and Tanveer, B.

(2016). What is DevOps? a systematic mapping study

on deﬁnitions and practices. In Proceedings of the Sci-

entiﬁc Workshop Proceedings of XP2016, pages 1–11.

Kaur, A. and Nayyar, R. (2020). A comparative study of

static code analysis tools for vulnerability detection in

C/C++ and JAVA source code. Procedia Computer

Science, 171:2023–2029. Third International Con-

ference on Computing and Network Communications

(CoCoNet’19).

Kronjee, J., Hommersom, A., and Vranken, H. (2018).

Discovering software vulnerabilities using data-ﬂow

analysis and machine learning. In Proceedings of the

13th International Conference on Availability, Relia-

bility and Security, ARES 2018, New York, NY, USA.

Association for Computing Machinery.

Kumar, R. and Goyal, R. (2020). Modeling continuous se-

curity: A conceptual model for automated DevSecOps

using open-source software over cloud (adoc). Com-

puters & Security, 97:101967.

Kurniawan, A., Abbas, B. S., Trisetyarso, A., and Isa,

S. M. (2018). Static taint analysis traversal with ob-

ject oriented component for web ﬁle injection vulner-

ability pattern detection. Procedia Computer Science,

135:596–605.

Leite, L., Rocha, C., Kon, F., Milojicic, D., and Meirelles, P.

(2019). A survey of DevOps concepts and challenges.

ACM Computing Surveys, 52(6).

Mantere, M., Uusitalo, I., and Roning, J. (2009). Com-

parison of Static Code Analysis tools. In 2009 Third

International Conference on Emerging Security Infor-

mation, Systems and Technologies, pages 15–22.

Mao, R., Zhang, H., Dai, Q., Huang, H., Rong, G., Shen,

H., Chen, L., and Lu, K. (2020). Preliminary ﬁndings

about DevSecOps from Grey Literature. In 2020 IEEE

20th International Conference on Software Quality,

Reliability and Security (QRS), pages 450–457.

McGraw, G. (2006). Software Security: Building Security

In. Addison-Wesley.

Myrbakken, H. and Colomo-Palacios, R. (2017). DevSec-

Ops: a multivocal literature review. In International

Conference on Software Process Improvement and

Capability Determination, pages 17–29. Springer.

Oyetoyan, T. D., Jaatun, M. G., and Cruzes, D. S. (2017). A

lightweight measurement of software security skills,

usage and training needs in agile teams. International

Journal of Secure Software Engineering, 8(1):1–27.

Rajapakse, R., Zahedi, M., Ali Babar, M., and Shen, H.

(2021). Challenges and solutions when adopting De-

vSecOps: A systematic review. Information and Soft-

ware Technology.

Rao, K. N., Naidu, G. K., and Chakka, P. (2011). A study of

the Agile software development methods, applicabil-

ity and implications in industry. International Journal

of Software Engineering and its applications, 5(2):35–

45.

Rehkopf, M. (2001). Manifesto for agile software develop-

ment.

Rehkopf, M. (2020). Kanban vs. Scrum: which Agile are

you?

Savor, T., Douglas, M., Gentili, M., Williams, L., Beck,

K., and Stumm, M. (2016). Continuous deploy-

ment at Facebook and OANDA. In 2016 IEEE/ACM

38th International Conference on Software Engineer-

ing Companion (ICSE-C), pages 21–30.

Schlossnagle, T. (2018). Monitoring in a DevOps world.

Commun. ACM, 61(3):58–61.

Shahin, M., Ali Babar, M., and Zhu, L. (2017). Continu-

ous integration, delivery and deployment: A system-

atic review on approaches, tools, challenges and prac-

tices. IEEE Access, 5:3909–3943.

onmez, F. O. and Kilic¸, B. G. (2021). Holistic web ap-

plication security visualization for multi-project and

multi-phase dynamic application security test results.

IEEE Access, 9:25858–25884.

Talukder, A., Maurya, V., Santhosh, B., Jangam, E., Muni,

S., Kp, J., Samanta, S., and Pais, A. (2009). Security-

aware software development life cycle (SaSDLC) -

processes and tools. In 2009 IFIP International Con-

ference on Wireless and Optical Communications Net-

works, pages 1 – 5.

Virmani, M. (2015). Understanding DevOps & bridging the

gap from continuous integration to continuous deliv-

ery. In Fifth International Conference on the Inno-

vative Computing Technology (INTECH 2015), pages

78–82, Piscataway, NJ. IEEE.

Williams, L., McGraw, G., and Migues, S. (2018). En-

gineering security vulnerability prevention, detection,

and response. IEEE Software, 35(5):76–80.

IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security

238
