An Information Security Model for an IoT-enabled Smart Grid
Abeer Akkad
1,2 a
, Gary Wills
and Abdolbaghi Rezazadeh
Electronic and Computer Science Dept., University of Southampton, University Road, Southampton, U.K.
Information Systems Dept., Faculty of Computing and Information Technology, King Abdulaziz University, Jeddah, K.S.A
Keywords: IoT, Internet of Things, IoT-enabled Smart Grid, IoT & Security, Cybersecurity, Threats Modelling.
Abstract: The evolution of an Internet of Things-enabled Smart Grid affords better automation, communication,
monitoring, and control of electricity consumption. It is now essential to supply and transmit the data required,
to achieve better sensing, more accurate control, wider information communication and sharing, and more
rational decision-making. However, the rapid growth in connected entities, accompanied by the increased
demand for electricity, has resulted in several challenges to be addressed. One of these is protecting energy
information exchange proactively, before an incident occurs. It is argued that Smart Grid systems were
designed without any regard for security, which is considered a serious omission, especially for data security,
energy information exchange, and the privacy of both the consumers and utility companies. This research is
motivated by the gap identified in the requirements and controls for maintaining cybersecurity in the bi-
directional data flow within the IoT-enabled Smart Grid. The initial stages of the research define and explore
the challenges and security requirements, through the literature and industrial standards. The Threat
Modelling identified nine internet-based threats. The analysis proposes a security model which includes 45
relevant security controls and 7 security requirements.
The Smart Grid (SG) can be regarded as an extensive
Cyber-Physical System (CPS) (Dagle, 2012). It is
considered to be a critical infrastructure in all
communities worldwide. Globally, the energy market
is believed to be the most important asset that allows
a country to expand its economy (Bedi et al., 2018).
Moreover, as cities want to assure sustainable green
energy as a step towards their transformation into
smart cities, implementing a SG is considered the best
way to achieve this goal. Thus, the SG is one of the
largest applications of IoT (Reka and Dragicevic,
2018; Al-Turjman and Abujubbeh, 2019). The
McKinsey Global Institute predicted that the IoT will
have a significant economic contribution from $3.9 to
$11.1 trillion per year by 2025 (Manyika et al., 2015).
This influence will be felt in many areas and
applications, including homes, factories, retail
environments, offices, worksites, human health,
outside environments, cities, and vehicles (Dalipi and
Yayilgan, 2016).
The conventional power grid uses an analogue and
electromechanical infrastructure in which electricity
is transmitted from a centralised utility or power plant
to the consumer through long-distance and high-
voltage lines. The power is delivered to the
neighbourhood by a distribution system consisting of
transformers, distribution substations, and power
lines. In this unidirectional model, there is no
feedback from the consumer (Al Khuffash, 2018), so
utility companies depend on meter readings by
engineers to ensure that the balance of supply and
demand is met in an effective manner. Meter readings
provide insufficient information on the grid’s
condition and consumption, with no real-time energy
information (Al Khuffash, 2018). Consequently,
consumers are faced with being consumption-
conscious. Besides real-time challenges, there are
significant issues of exponential growth and changes
of demand, an outdated grid architecture, latency,
variations in load, many power outages, and increased
carbon emissions (Al Khuffash, 2018). New
infrastructure is needed that may overcome these
Akkad, A., Wills, G. and Rezazadeh, A.
An Information Security Model for an IoT-enabled Smart Grid.
DOI: 10.5220/0011042200003194
In Proceedings of the 7th International Conference on Internet of Things, Big Data and Security (IoTBDS 2022), pages 157-165
ISBN: 978-989-758-564-7; ISSN: 2184-4976
2022 by SCITEPRESS Science and Technology Publications, Lda. All rights reserved
challenges, and the evolution of a SG could handle
these drawbacks associated with the conventional
The electric utility sector is currently developing an
IoT-enabled SG. This is viewed as the largest-ever
installation of an IoT, with thousands of smart objects
and things such as smart meters, smart appliances,
and other sensors (Reka and Dragicevic, 2018). This
huge number of connected devices, besides the
increasing demand for electric energy, results in
significant challenges for a SG. Although the SG can
address the drawbacks of the traditional power
system, it involves issues of security, Big Data
processing, cost, centralisation, scalability,
interoperability, heterogeneity, and latency.
This research discusses the present challenges of
an IoT-enabled electricity Smart Grid, focusing on
securing the information flow that is essential for
better automation, sensing, controlling,
communicating, and timely decision-making (U.S.
Department of energy, 2018). The current research
proposes a comprehensive model for securing IoT-
enabled SG.
This paper is organised as follows: Section 2
defines the IoT-enabled SG and components
highlighting the security and the link between IoT and
SG. In section 3 the security requirements are
investigated. Section 4 looks at the threats modelling
and identifies the security threats and controls. Then,
the security model is proposed in section 5. Also, the
potential future work is briefly discussed.
This section of the paper offers an overview of IoT-
enabled SG, components, Then, the role of IoT in the
SG is explained highlighting the security of IoT-
enabled SG.
2.1 Definition of IoT-enabled Smart
The SG can be defined as the integration of ICT into
the existing electrical network, consisting of
renewable sources and involving its multiple domains
(generation, transmission, distribution, and
consumption) in the efficient automation and real-
time demand management of a reliable, sustainable,
bi-directional, and economic green electrical energy.
(IEEE, 2018; U.S. Department of energy, 2018;
EPRI, 2005).
2.1.1 What Makes the Grid Smart?
It is argued that digital technology is what makes the
grid smart (U.S. Department of energy, 2018). In
order to achieve this, information technology systems
have to be deployed to supply the data required for
better sensing, precise control, wider information
communication and sharing, powerful computing,
and better decision-making (U.S. Department of
energy, 2018).
2.2 Smart Grid Conceptual Model
The conceptual reference model by NIST (US
National Institute of Standards and Technology) is
commonly referred to in the sector (NIST, 2014).
However, the NIST model encounters a lack of detail
in terms of cybersecurity and information flow,
especially in the IoT infrastructure. The NIST model
contributes to the concept of the SG architecture only,
while this research fills in the gaps in the NIST model
to develop a case study that is useful for the related
sectors. NIST case studies and scenarios are limited
to privacy and some domains of SG without linking
security requirements, threats, and controls for each
access point in the system. Indeed, NIST IR and
NERC CIP measure the compliance of any
organisation with the policies.
2.3 IoT and Smart Grid
In this section, the role of IoT in the SG is explained.
Both Kaur and Kalra (2016) and Al-Ali and
Aburukba (2015) suggested that all objects in a SG
can be represented as IoT devices distributed
throughout the residential network, substations, and
utilities. These devices require tracking for
monitoring purposes, connectivity, and automation
(Al-Ali and Aburukba, 2015; Saleem et al., 2019).
The IoT is an enabling technology that brings internet
connectivity to the SG (Al-Ali and Aburukba, 2015;
Saleem et al., 2019). From the cyber-physical
systems point of view, SG is considered as one of the
biggest applications of IoT (Al-Turjman &
Abujubbeh, 2019; Reka & Dragicevic, 2018).
In SG, in the context of IoT each device is
connected to the internet. To facilitate communication
of information and receiving control commands via the
internet protocols, each must have a unique IP address
(Saleem et al., 2019). Under the IP addressing
schemas, IoT can offer monitoring and control capabi-
lities for SG, as discussed by Kaur and Kalra (2016).
This monitoring aspect can cover the generation plant,
distribution, storage, and finally consumption to
IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security
achieve efficiency management, demand management,
renewable energy needed measurement, and CO
emissions administration. Therefore, IoT devices
contribute to the reduction of wasted energy and the
accurate estimation of required energy.
Further, those devices exchange data in bi-
directional flow via the SG communication layer,
using several communication protocols, such as Wi-
Fi, Zigbee, WiMax, LET, and GPRS. IoT
standardises communication, reducing the number of
these protocols relating to the SG components (Al-Ali
and Aburukba, 2015). Both Saleem et al. (2019), and
Al-Ali and Aburukba (2015), emphasised that IoT
technologies enable SG to communicate across all its
multiple subsystems of generation, transmission,
distribution, and consumption. Al-Ali and Aburukba
(2015) stated that each device can exchange data and
commands from the control centres and utilities.
Mugunthan and Vijayakumar (2019) supported the
claim that IoT technologies have afforded SG with
the cloud, 5G, mobile wireless networks, application
programming interfaces (APIs), machine learning,
AI, predictive analytics, and Big Data management.
2.4 Smart Grid and Security
SG affords many opportunities, but it also presents
security challenges. To get the most out of SG, it is
essential to develop a highly secure information
system. it is argued that automation systems such as
SCADA were designed without any regard for
security (Aloul, 2012). Moreover, Modbus, which
exchanges SCADA information to control industrial
processes, was not intended for critical security
environments such as SG (Aloul, 2012). Thus,
securing the information system in SG must be
assigned the highest priority, since power assets
represent critical national infrastructure that may
attract terrorists and state actors. Any damage, such
as security attacks on the power grid, could cause
chaos across whole cities. Electric Power Research
Institute (ERPI) reported that one of the main
concerns in SG implementation worldwide is
security. Security challenges of IoT-enabled SG can
arise for many reasons. First, the entities in SG
communicate using the IP-based communication
network, exchanging sensitive and private data
between both consumers and utility companies. Such
networks are susceptible to many types of security
threat, such as man-in-the-middle, denial of service,
eavesdropping, and replay attacks, as shown in
section 3. Secondly, SG consists of various
components that communicate with one another,
which requires interaction among these technologies.
Accordingly, this communication introduces access
points in SG that are vulnerable to security attacks
(Mahmood et al., 2016). Thirdly, SG uses wireless
sensor networks to connect smart meters, for
example. It has been argued that wireless networks
are insecure (He et al., 2013). Fourthly, by allowing
unauthorised access to SG, the bi-directional
information flow may expose SG to many threats.
Fifthly, utilising IoT in SG may cause it to inherit
IoT’s security issues. For monitoring and control
purposes with IoT devices, SG should use the internet
(Ghasempour, 2019).
There are several security concerns over IoT
technologies stemming from their exposure to the
internet. The exposure can allow an attacker to tamper
with the data. Besides, the ever-increasing number of
IoT devices used in SG makes it more vulnerable to
attack (Kimani et al., 2019).
Security modelling has been carried out for the Smart
Grid but these studies either focused on a part of the
SG or they only partly covered the security controls.
Some topics in the cybersecurity design stage, such as
session mismanagement, have not been well
investigated. Many challenges relating to security are
still open. It is vitally important to develop an
appropriate model to address all the information
security challenges for the whole IoT-enabled SG.
Although the studies discussed the optimisation of
cost and performance, this research focuses on
identifying the main potential access points that are
vulnerable to internet-based threats in the SG, and all
relevant security controls that could mitigate the
internet-based threats and are applicable to each
access point, in a comprehensive modelling approach
that fills in the missing details in the NIST conceptual
model without considering their cost of
This section is focused on identifying the security
requirements, Threats, and controls that contribute to
the security of the SG information system.
4.1 Method for Model Development
This section charts the research roadmap to develop a
security model for IoT-enabled SG that fills in the
An Information Security Model for an IoT-enabled Smart Grid
lack of details on the NIST model. Figure 1 presents
the steps the research has undertaken for the
development process. In Step 1, the security
requirements were reviewed from international
industrial standards and from academic publications.
Then, both sets were combined and compared to
generate the Security Requirements. In Step 2, threat
modelling was carried out, based on the NIST
conceptual model to identify the access points. Then,
common internet-based threats were explored. Next,
security threats and requirements were both identified
using STRIDE analysis and classification. Step 3
assigned the identified threats to the access points,
according to functions and the information system
processed at each access point. In Step 4, the security
controls were grouped by the security requirements.
Finally, at Step 5 the security controls were mapped
to the access points by assessing threats effects to find
out the desired security requirements.
Figure 1: Development of the Security Model.
4.2 Security Requirements
The security requirements gleaned from literature and
industrial standards and authorities are reviewed and
analysed as the following (Mrabet et al., 2018;
Benmalek et al., 2019; Das and Zeadally, 2019;
Tufail et al., 2021):
1. Confidentiality: Ensuring that access to
transmitted data is restricted to authorised people. It
prevents the unauthorised disclosure of information.
In Smart Grid, the transmitted data could be sensitive,
such as personal information about a consumer’s
activities and billing data.
2. Integrity: Guarding the information and the
source of the information against any tampering or
unauthorised manipulation. Information could be
power measurements or price signals. A loss of
integrity may lead to false decision-making about
energy management.
3. Availability: Guarantee timely and reliable
access to the information (NISTIR 7628, 2014). The
power system needs to be available whenever
required by authorised entities. A loss of availability
may cause power cuts. Availability is about the
uptime and downtime of the SG system.
4. Authentication: Validating the identity of any
communicated entities (devices/users) in the SG. For
example, smart meters need to be authenticated so
that the utility company can bill the correct consumer.
Data authentication plays a significant role in proving
that the transmitted data are genuine, using
verification features such as digital signatures.
5. Authorisation: Granting the required rights to an
authenticated device/user to access SG resources. The
access control is that which guarantees that SG
resources are accessed by the correctly identified
6. Privacy: Guaranteeing that any private data
belonging to the consumer cannot be obtained
without permission and are used for pre-approved
purposes only. An attacker can extract information on
private data from the smart meter such as
consumption readings.
7. Non-repudiation: Assuring that the
accountability of any data transaction has been
undertaken between entities without any denial of
responsibility. It means assuring the traceability of
the system by recording each transaction by node,
device, consumer, and utility (Mrabet et al., 2018).
4.3 Internet-based Threats
Below are the common types of internet-based
cybersecurity threats found in the literature and
analysed using the STRIDE modelling technique as
described in the next section(Cisco, 2017; Marinos
and Lourenço, 2018; Mrabet et al., 2018; Otuoze et
al., 2018; Tonyali et al., 2018; Benmalek et al., 2019;
Das and Zeadally, 2019; Ganguly et al., 2019; Kimani
et al., 2019; Gunduz and Das, 2020; Tufail et al.,
1. Spoofing/Impersonation: This is an active attack
that aims to communicate on behalf of a legal entity
through unauthorised access, by stealing its identity.
An attacker may impersonate another’s smart meter
identity in order to pay lower electric charges – or let
the other pay.
Step 5. Map the Security Controls to the Access points
Step 5.1 Assess threat effect to
find out the desired Security
Step 5.2 Assign the controls to
each Requirement
Step 4. Categorise the Controls by Security Requirement
Step 4.1 Review Security Controls
from literature, Microsoft
documentation, and standards [
Step 4.2 Use the
description of each
security control
Step 4.3 Group
the controls by
Step 3. Assign Threats to the Access points
Step 3.1 Analyse each access point
according to their functionality,
operations processed, and
information systems located there
Step 3.2 Consider the
threats they could
encounter when processing
such operations
Step3.3 Review
the literature
Step 2. Threat Modelling
Step 2.1
Characterise the
Step 2.2 Identify
Assets and Access
Step 2.3 Exploring the
common internet-based
Step 2.4 Apply
STRIDE analysis
and classification
Step 1. Generate the SG Security Requirements
Step 1.1 Review the
security requirements from
international industrial
Step 1.2 Review the
security requirements
from published literature
Step 1.3 Compare and
combine the collected
security requirements
IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security
2. Eavesdropping/Traffic analysis/Man-In-The-
Middle (MITM): These are passive attack capturing
the transmitted data by intercepting the
communication between two entities in the SG. In
Traffic analysis, the attacker intercepts the
communication, analyses the network traffic, and
then extracts information from patterns to locate key
entities such as substations or disclose sensitive
information such as future price information.
3. Replay attack: A replay attack is an active attack
that intercepts the communication between two
entities by recording, observing, copying the
transmitted data, and then replaying a selected part of
the copied data back in an attack. It manipulates the
data before sending it back.
4. Data tampering: This strikes when an attacker
manipulates the exchanged data, such as dynamic
prices that are announced before peak times, making
them cheaper. Consequently, it can increase
consumer consumption instead of reducing it. This, in
turn, overloads the power network and causes power
5. Denial of Service (DOS)/Jamming channel:
This is an active attack that floods the entire system,
resources, or bandwidth, with a high number of fake
requests to overload the system, slow it, or corrupt
data transmission, thus making the SG unavailable.
This congested traffic prevents authorised entities
from accessing the system. A jamming channel attack
is a type of DOS threat. A distributed DOS (DDOS)
threat involves system servers or resources being
flooded by multiple attackers.
6. Malware injection: This is the execution of
malicious software on the SG, such as viruses,
spyware, rootkits, adware, malvertising, ransomware,
Trojan horses, or worms. It aims to damage, steal,
delete, modify, or disable, the main functions in smart
meters, or utility servers.
7. Phishing: Phishing that is included in this
research’s scope is internet-based Phishing such as
email Phishing and search engine/websites Phishing
that tricks users into believing that a message is from
a trustworthy organisation, asking them to click a
malicious link to obtain sensitive information. When
users respond, the attacker can use this information to
access the system (CISA, 2009).
8. SQL injections: A Structured Query Language
(SQL) injection executes a harmful SQL query
statement on the server that uses SQL, aiming to force
the server to disclose information, modify, or delete
the database contents. According to Cisco, this SQL
query is entered by the attacker using a website search
box on the client-side interface of the application and
is used to target database applications.
9. False data injection: This type of attack sends
fake information into the network, such as false meter
readings or wrong prices. It causes false state
estimation for the SCADA system and may cause a
power system failure. Thus, it influences the
electricity market financially by tampering with
market price information.
4.4 Threat Modelling
This research used the STRIDE technique for threat
modelling. Security requirements can be mapped to
threats to show the effect of each threat and the
required security criteria of the system. It is argued
that security requirements for the system can be
defined clearly once the threats are identified, as
shown in Figure 2. Threats are mapped to STRIDE
categories using STRIDE definitions and the threats
definitions of this research provided at section 4.3.
Each identified threat is mapped to STRIDE
categories based on the main effect of that threat at
the first instance. Then, threats are mapped to security
requirements based on STRIDE mapping as well as
the literature (Mrabet et al., 2018; Stellios et al.,
2018; Gunduz and Das, 2020; Tufail et al., 2021).
Security controls are countermeasures to mitigate,
delay or prevent threats in order to strengthen the
information system against threats. The controls are
approaches that ensure security requirements. The
security controls are taken from the literature and
Microsoft documentation (2009). Security controls
are then categorised by security requirements using
the description of each security control, as shown
Table 1 at appendix A. In addition, all the standards,
including NIST IR, NERC CIPS (1-9), NIST IR7628,
and NIST SP 800-53, are reviewed as well as the
publications (Mrabet et al., 2018; Das and Zeadally,
2019; Ganguly et al., 2019; Kimani et al., 2019) to
map the security controls to the security
4.5 Identifying Access Points
This step articulates the main access points that are
vulnerable to internet-based threats in the IoT-
enabled SG by reviewing publications, and the
vulnerability analysis compiled by the U.S. electric
sector issued by Idaho National Laboratory (Glenn
An Information Security Model for an IoT-enabled Smart Grid
Denial of service
Elevation of
analysis/ (MITM)
Replay attack
Data tampering
Denial of Service (DOS)/
Jamming channel
Malware injection
SQL injections
False data injectio
Figure 2: SG Threat modelling.
Figure 3: The proposed Security Model.
et al., 2017). Figure 3 Shows seven access points that
are most likely to be exploited to execute cyber-
attacks: (1) Smart Meters and Smart Appliances; (2)
Transmission Stations, Distribution Substations, and
Smart automation devices for transmission and
distribution (Switches, Sensors, Actuators,
Transformers, Voltage regulator, Capacitors); (3)
Generation Plant and Information Communication
IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security
Technology (ICT) Systems; (4) Advanced Metering
Infrastructure (AMI); (5) SCADA (Supervisory
Control and Data Acquisition)/SAS (Substations
Automation Systems)/ Control Centre; (6) Utility
data centre; (7) Market.
In conclusion, the proposed security model shown in
Figure 3 consists of seven security requirements, nine
threats, seven access points, and thirty-eight security
The model addresses the limitation found in the
NIST model as NIST is a very high-level conceptual
model lacking details that make the proposed model
more practical and useful for the related sectors to
This research will be beneficial to system
designers, information security practitioners, and
stakeholders to consider the key requirements and
challenges, identify the security threats and
vulnerabilities, and maintain the required
mechanisms through the initial stages of the
development of a SG system design.
For the future work, the next phase of this research is
to have the model validated by experts in the industry
including threats, access points, requirements, and
controls. The initial reviews confirmed this model
and the importance of it to support the energy sector
towards securing automated Smart Grids. Then, the
model will be verified by formal modelling.
Al-Ali, A.R. and Aburukba, R. (2015) ‘Advanced role of
internet of things in the smart grid technology’, Journal
of Computer and Communications, pp. 229–233.
Al-Turjman, F. and Abujubbeh, M. (2019) ‘IoT-enabled
smart grid via SM: An overview’, Future Generation
Computer Systems, 96, pp. 579–590.
Aloul, F.A. (2012) ‘The Need for Effective Information
Security Awareness’, Journal of Advances in
Information Technology, 3(3), pp. 176–183.
Bedi, G., Venayagamoorthy, G.K., Singh, R., Brooks, R.R.
and Wang, K.C. (2018) ‘Review of Internet of Things
(IoT) in Electric Power and Energy Systems’, IEEE
Internet of Things Journal, 5(2), pp. 847–870.
Bekara, C. (2014) ‘Security issues and challenges for the
IoT-based smart grid’, Procedia Computer Science, 34,
pp. 532–537.
Benmalek, M., Challal, Y. and Derhab, A. (2019)
‘Authentication for Smart Grid AMI Systems: Threat
Models, Solutions, and Challenges’, Proceedings - 2019
IEEE 28th International Conference on Enabling
Technologies: Infrastructure for Collaborative
Enterprises, WETICE 2019, pp. 208–213.
CISA (2009) ‘Understanding Digital Signatures | CISA’.
Cisco (2017) What Is a Cyberattack? - Most Common
Types - Cisco. Available at:
(Accessed: 21 February 2020).
Dagle, J.E. (2012) ‘Cyber-physical system security of smart
grids’, 2012 IEEE PES Innovative Smart Grid
Technologies, ISGT 2012, pp. 1–2.
Dalipi, F. and Yayilgan, S.Y. (2016) ‘Security and privacy
considerations for IoT application on smart grids:
Survey and research challenges’, Proceedings - 2016
4th International Conference on Future Internet of
Things and Cloud Workshops, W-FiCloud 2016, pp.
Das, A.K. and Zeadally, S. (2019) Data Security in the
Smart Grid Environment, Pathways to a Smarter Power
System. Elsevier Ltd. doi:10.1016/B978-0-08-102592-
EPRI Electric Power Research Institute (2005) EPRI Smart
Grid Resource Center. Available at:
Ganguly, P., Nasipuri, M. and Dutta, S. (2019) ‘Challenges
of the Existing Security Measures Deployed in the
Smart Grid Framework’, Proceedings of 2019 the 7th
International Conference on Smart Energy Grid
Engineering, SEGE 2019, pp. 1–5.
Ghasempour, A. (2019) ‘Internet of things in smart grid:
Architecture, applications, services, key technologies,
and challenges’, Inventions, 4(1)..
Glenn, C., Sterbentz, D. and Wright, A. (2017) Cyber
Threat and Vulnerability Analysis of the U.S. Electric
Sector, Inl (Idaho National Laboratory).
Gunduz, M.Z. and Das, R. (2020) ‘Cyber-security on smart
grid: Threats and potential solutions’, Computer
Networks, 169, p. 107094.
He, D., Kumar, N., Chen, J., Lee, C.C., Chilamkurti, N. and
Yeo, S.S. (2013) ‘Robust anonymous authentication
protocol for health-care applications using wireless
medical sensor networks’, Multimedia Systems, 21(1),
pp. 49–60.
IEEE (2018) About - IEEE Smart Grid. Available at:
(Accessed: 4 December 2019).
Al Khuffash, K. (2018) Smart grids—Overview and
background information, Application of Smart Grid
Technologies. Elsevier Inc. doi:10.1016/b978-0-12-
Kimani, K., Oduol, V. and Langat, K. (2019) ‘Cyber
security challenges for IoT-based smart grid networks’,
International Journal of Critical Infrastructure
Protection, 25, pp. 36–49..
Mahmood, K., Ashraf Chaudhry, S., Naqvi, H., Shon, T.
and Farooq Ahmad, H. (2016) ‘A lightweight message
authentication scheme for Smart Grid communications
in power sector’, Computers and Electrical
Engineering, 52, pp. 114–124.
An Information Security Model for an IoT-enabled Smart Grid
Manyika, J., Chui, M., Bisson, P., Woetzel, J., Dobbs, R.,
Bughin, J. and Aharon, D. (2015) Unlocking the
potential of the Internet of Things | McKinsey &
Company, McKinsey.
Marinos, L. and Lourenço, M. (2018) ENISA Threat
Landscape Report 2018 15 Top Cyberthreats and
Trends, European Union Agency For Network and
Information Security. doi:10.2824/622757.
Mrabet, Z. El, Kaabouch, N., Ghazi, Hassan El and Ghazi,
Hamid El (2018) ‘Cyber-security in smart grid: Survey
and challenges’, Computers and Electrical Engineering,
67, pp. 469–482.
NIST (2014) NIST Special Publication 1108R3 NIST
Framework and Roadmap for Smart Grid
Interoperability Standards, Release 3.0, NIST Special
Publication. doi:10.6028/NIST.SP.1108r3.
NISTIR 7628 (2014) NISTIR 7628 Guidelines for Smart
Grid Cyber Security, Revision 1, NIST.
Otuoze, A.O., Mustafa, M.W. and Larik, R.M. (2018)
‘Smart grids security challenges: Classification by
sources of threats’, Journal of Electrical Systems and
Information Technology, 5(3), pp. 468–483.
Reka, S.S. and Dragicevic, T. (2018) ‘Future effectual role
of energy delivery : A comprehensive review of
Internet of Things and smart grid’, Renewable and
Sustainable Energy Reviews, 91 (April), pp. 90–108.
Saleem, Y., Crespi, N., Rehmani, M.H. and Copeland, R.
(2019) ‘Internet of Things-Aided Smart Grid:
Technologies, Architectures, Applications, Prototypes,
and Future Research Directions’, IEEE Access, 7, pp.
Stellios, I., Kotzanikolaou, P., Psarakis, M., Alcaraz, C. and
Lopez, J. (2018) ‘A survey of iot-enabled cyberattacks:
Assessing attack paths to critical infrastructures and
services’, IEEE Communications Surveys and
Tutorials, 20(4), pp. 3453–3495.
Tonyali, S., Akkaya, K., Saputro, N., Uluagac, A.S. and
Nojoumian, M. (2018) ‘Privacy-preserving protocols
for secure and reliable data aggregation in IoT-enabled
Smart Metering systems’, Future Generation Computer
Systems, 78, pp. 547–557.
Tufail, S., Parvez, I., Batool, S. and Sarwat, A. (2021) ‘A
survey on cybersecurity challenges, detection, and
mitigation techniques for the smart grid’, Energies,
14(18), pp. 1–22.
U.S. Department of energy (2018) Smart Grid System
Report: 2018 Report to Congress.
Table 1: Mapping security controls to security requirements.
Security controls Code
1. Keyed cryptographic hash functions (HMAC), digital signatures, and Random numbers
2. Physically Unclonable Functions (PUF) Aun2
3. MAC-attached, and HORS-signed messages Aun3
4. Secure Sockets layer Certificates (SSL Certificates) and Transport Layer Security
5. Multi-factor authentication mechanism Aun5
6. Automatic lockouts Aun6
7. Attribute-Based Encryption Aur1
8. Attribute Certificates Aur2
9. Attribute-Based Access Control System based on XACML (Extensible Access Control
Markup Language)
10. Role-Based Access Control and allow/block listing Aur4
Confidentiality (C) 11. Symmetric and asymmetric algorithms and Public Key Infrastructure certificate (PKI) C1
12. Anonymisation P1
13. Trusted aggregators P2
14. Homomorphic encryption P3
15. Perturbation models P4
16. Verifiable computation models, and zero-knowledge proof systems P5
17. Data obfuscation techniques P6
IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security
Table 1: Mapping security controls to security requirements (cont.).
Security controls Code
18. Cryptographic hashing functions and session keys
19. Digital watermarking
20. Automated patch management for flaw remediation
21. Adaptive cumulative sum algorithm
22. Secure Phasor Measurement Units (PMUs) installation
23. Load profiling algorithms
24. Timestamps
25. Sequence numbers
26. Query sanitisation
27. Nonces
28. Use multiple alternate frequency channels according to a hardcoded sequence
29. Frequency quorum rendezvous between connected nodes
30. Anomaly Intrusion Detection Systems (IDS)
31. Specification-based IDS
32. Intrusion Prevention Systems (IPS)
33. Quality of Services (QoS)
34. Load balancing
35. Operating system-independent Applications
36. Mutual Inspection technique
37. Unique keys and digital signatures
38. Transaction log
An Information Security Model for an IoT-enabled Smart Grid
