BRL: A Toolkit for Learning How an Agent Performs Belief Revision

Aaron Hunter and Konstantin Boyarinov

Department of Computing, BC Institute of Technology, Burnaby, Canada

Keywords:

Belief Revision, Knowledge Representation, Learning.

Abstract:

Belief revision occurs when an agent receives new information that may conﬂict with their current beliefs.

This process can be modelled by a formal belief revision operator. However, in a practical scenario, simply

deﬁning abstract revision operators is not sufﬁcient. A truly intelligent agent must be able to observe how

others have revised their beliefs in the past, and use this information to predict how they will revise their

beliefs in the future. In other words, an agent must be able to learn the mental model that is used by other

agents. This process involves combining two traditionally distinct areas of Artiﬁcial Intelligence to produce a

general reasoning system. In this paper, we discuss challenges faced in using various learning approaches to

learn belief revision operators. We then present the BRL toolkit: software can learn the revision operator an

agent is using based on past revisions. This is a tool that bridges formal reasoning and machine learning to

address a common problem in practical reasoning. Accuracy and efﬁciency of the approach are discussed.

1 INTRODUCTION

Belief revision is the process in which an agent in-

corporates new information together with some pre-

existing set of beliefs. This is important in any rea-

soning context where it is useful for an agent to de-

velop a model of how other agents are likely to be-

have. There are many situations where we would like

to predict the behaviour of an agent, based on past

data. As an illustrative example, consider an agent

that is controlling a motorized vehicle. We know the

agent is rational, but we do not know exactly how the

agent makes decisions about actions such as stopping

and turning. We would like to be able to predict how

this agent will respond to new information. For ex-

ample, we may be interested in determining what it

will do if a small animal appears in front of it. By

looking at past revisions, we can try to learn if the

presence of small animals triggers a change in belief.

Note that we are not simply making predictions based

on past actions; we are trying to learn the underlying

revision operator so that we can accurately model the

reasoning process. This will provide a more robust

predictive model.

We are concerned with learning how an agent re-

vises their beliefs, based on past information. Of

course, there are many different approaches does not

involve machine learning at all. We will discuss this

approach, and provide a tool for automating the pro-

cess. We then to consider the application of machine

learning towards this task, considering some different

basic models. We then introduce the Belief Revision

Learner (BRL) toolkit; this is a software tool that uses

past revision data to predict how an agent will revise

their beliefs in the future.

2 PRELIMINARIES

2.1 Belief Revision

We introduce belief revision operators. These are for-

mal operators deﬁned in the setting of propositional

logic. We therefore assume an underlying vocabu-

lary V is a ﬁnite set of propositional variables. A

formula is a propositional combination of symbols in

V , formed using the usual connectives. A state is a

propositional interpretation of V ; in other words, a

state assigns true-false values to every variable. A

belief state is a set of states, informally representing

the set of states that an agent considers possible. An

AGM belief revision operator is a function ∗ that maps

a belief state K and a formula φ to a new belief state

K ∗ φ, while satisfying a particular set of postulates

(Alchourr

on et al., 1985).

Intuitively, the belief state K ∗ φ incorporates the

new information φ while keeping as much of K as

consistently possible. Hence, if φ is consistent with

Hunter, A. and Boyarinov, K.

BRL: A Toolkit for Learning How an Agent Performs Belief Revision.

DOI: 10.5220/0010899100003116

In Proceedings of the 14th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2022) - Volume 3, pages 753-756

ISBN: 978-989-758-547-0; ISSN: 2184-433X

753

K, then K ∗ φ is just the intersection of K and φ. This

is called belief expansion. But when φ is not consis-

tent with K, then the set of states believed following

revision will be the states where φ is true that are ‘as

close as possible’ to states in K. There is a well known

semantics based on orderings over possible states; we

refer the reader to (Katsuno and Mendelzon, 1992) for

a complete discussion.

For our purposes, the important thing to note is

that AGM revision operators are only appropriate for

single-shot belief revision. The problem is that the

revision process requires an ordering over states, but

the output is just a set of states. Hence, we do not

any ordering to use for subsequent revisions. To ad-

dres iterated belief revision, we could move to the

well-known Darwiche-Pearl approach (Darwiche and

Pearl, 1997). However, this introduces many compli-

cations.

2.2 Machine Learning

In this paper, we are concerned with two kinds of Ma-

chine Learning. At the outset, we will consider Rein-

forcement Learning. Basically reinforcement learn-

ing is based on the idea that an agent is rewarded for

achieving a goal. Agents learn to maximize their ex-

pected reward by choosing actions that are likely to

get them closer to their goal. The well-known Q-

Learning approach is a representative example of re-

inforcement learning; the simple, classic version of

the algorithm is described in (Mitchell, 1997)

We also consider learning approaches based on

classiﬁcation. A classiﬁcation learning problem in-

volves predicting how different data points will be

classiﬁed. The standard example is the play tennis

problem, where we have information about whether

an agent played tennis under different weather con-

ditions. Using a classiﬁcation learning algorithm, we

can predict whether they will play tennis or not based

on the past data. We assume that the reader is familiar

with classiﬁcation learning, as described in (Raschka

and Mirjalili, 2019).

3 EXACT MATCHING

3.1 Modelling

The BRL software to be introduced in this paper is

actually a collection of tools for reverse engineering

a belief revision operator. In the simplest case, we

assume that we have a history that consists of a set

of triples (K, φ, K

) where K

was the result when K

was revised by φ in the past. Informally, each triple

is understood to mean that there was a past situation

where the agent initially believed K, then received the

information φ and then believed K

We remark that this situation is not particularly

reasonable in practice. The problem is that we are

unlikely to know the complete belief state of an agent

before and after an observation. However, if we do

have this kind of data, there is a natural approach. We

can simply check every available revision operator to

see if it is consistent with the data. This is obviously

a very computationally expensive approach.

3.2 Implementation

The ﬁrst application of BRL we consider is the exact

matching problem. In this case, we are looking for the

set of revision operators ∗ that satisfy K ∗ φ = K

for

every historical example. This is addressed through a

command line application written in C++ that essen-

tially performs an exhaustive search.

In the exact matching module of BRL, the input is

a comma separated text ﬁle, where each row contains

an initial belief state K, a formula φ that was given

for revision, and the new belief state that resulted. We

represent states by expressions of the form {p : 1 q :

0}, indicating that p is true and q is false. Belief states

are just sets of states. For example, a single line in the

history might read as follows:

{p:1 q:1}{p:0 q:0}, (p|q)&-(p&q), {p:1 q:0}

This line indicates that, when the belief state

{{p, q},

0} was revised by (p ∨q)∧¬(p∧q), then the

new belief state was {{p}}.

Given a set of instances in this format, BRL iter-

ates over all possible revision operators and returns

those that are consistent with the past revisions. For

our purposes, the set of possible revision operators is

the set of parametrised difference(PD) operators de-

ﬁned in (Peppas and Williams, 2018). We focus on

PD operators because they are simple to specify, but

they can capture a large class of revision operators.

The output returns a set of ranks over propositional

variables, which eah deﬁne a PD operator. A sample

run of the program is shown in Figure 1.

The output gives a compact representation of all

PD operators consistent with the input. These oper-

ators are found relatively quickly, because BRL in-

cludes an efﬁcient revision solver and it uses OpenMP

to test many operators in parallel. As a result, the run

times are acceptable for small examples. For larger

examples, the speed could be improved by using an

ALLSAT solver for the computationally hard parts of

the revision (Hunter and Agapeyev, 2020). We leave

this optimization for future work.

We summarise the average run times for up to 9

variables:

ICAART 2022 - 14th International Conference on Agents and Artiﬁcial Intelligence

754

Figure 1: Exact Matching Interface.

Variables Runtime Variables Run time

2 2 ms 6 730 ms

3 34 ms 7 10000 ms

4 46 ms 8 182000 ms

5 105 ms 9 30min

4 LEARNING

4.1 Modelling

Now suppose that we do not have an exact history.

Instead, we have a ﬁxed formula φ for revision and

a ﬁxed goal formula G. The history is a list of past

initial belief states K, along with a 0-1 value that indi-

cates if G was believed in the past when K was revised

by φ. We refer to these as classiﬁcation histories. Our

goal in this case is to use machine learning to deter-

mine, for any possible intitial beliefs, if we should

expect the agent to believe G after revision by φ.

We brieﬂy argue why we feel that classiﬁcation

learning provides a better model for learning in this

case than reinforcement learning. The fundamen-

tal idea underlying machine learning is to maximize

the expected discounted reward. This means that we

are assuming an agent makes choices that iteratively

work towards a goal. Consider, for example, an agent

that solves a maze. If we use reinforcement learning

to solve this problem, the agent will learn an action

policy. However, the action policy will generally be

monotonic, in the sense that choosing a “good” move

will take the agent closer to the reward.

By contrast, when we are modelling belief change

with AGM revision operators, there is no such con-

straint. After each revision, we have no information

about the ordering to use for the next revision. This

means data about agent behaviour need not be mono-

tonic, and in fact we will not have any meaningful

notion of a sequence of revisions. For this reason, we

focus on the use of classiﬁcation learning algorithms

for our toolkit.

4.2 Implementation

The classiﬁcation learning module of BRL uses the

Flask framework to implement a variety of classiﬁca-

tion algorithms. Figure 2 provides an image of the

interface.

In the classiﬁcation module, the available history

is concerned with a single goal formula G. The input

for BRL in this case is a classiﬁcation history. Each

instance in such a history consists of an initial belief

state K, a formula φ, and a 0-1 value for G. A 1 value

means that G was believed in the past when K was

revised by φ. A 0 value means it was not believed.

Hence, each instance has the following form:

{p:0 q:0 r:1}{p:1 q:1 r:0}, p|(q&r), 0

Given a set of instances of this form, BRL uses clas-

siﬁcation learning algorithms to predict if K ∗ φ |= G

for new initial belief states.

For testing the system, we specify a revision op-

erator and then generate a large set of instances based

on this operator. We then use the software to deter-

mine if we should predict K ∗ φ |= G for any new be-

lief state K. Table 1 shows the experimental results

obtained when the software was tested for 5 differ-

ent algorithms on a randomly generated set of roughly

28,000 instances. The different metrics for accuracy

are deﬁned in (Raschka and Mirjalili, 2019), and they

each have a maximum value of 1.

We can see that all of the ML algorithms tested

actually provide reasonably accurate predictions. The

accuracy of the predictions means that BRL is able to

effectively determine whether or not an agent will be-

lieve the target formula, given arbitrary initial belief

states. Hence, our results suggest that ML algorithms

provide an effective method for learning how an un-

known belief revision operator will respond to a new

observation.

BRL: A Toolkit for Learning How an Agent Performs Belief Revision

755

Figure 2: Classiﬁcation Learning Interface.

Table 1: System Performance of Classiﬁcation Learning.

ML Algorithm Precision Recall F1 Running Time

BaggingClassiﬁer (SGD) 0.91469 0.965 0.93917 214.52

RandomForestClassiﬁer 0.96689 0.73 0.83191 4.4737

SGDClassiﬁer 0.85027 0.795 0.82171 0.35567

BaggingClassiﬁer (DecisionTree) 0.96970 0.96 0.96482 110.54

DecisionTreeClassiﬁer 0.96059 0.975 0.96774 0.48756

5 CONCLUSION

The problem of deriving plausibility information for

revision from examples has been addressed in theoret-

ical work (Liberatore, 2015). However, there has been

little research on the development of practical tools

for learning revision operators from data. This idea

is discussed in (Hunter, 2018), but that work focuses

only on the feasibility of ID3 learning without any

experimentation or software development. As such,

BRL is really the ﬁrst fully implemented sofware tool

for learning revision operators from data.

Our results demonstrate that exact matching is

only feasible for small examples. However, the ML

approach provides a viable method to learn something

about the revision operator an agent is using. In many

practical situations, this is sufﬁcient. More impor-

tantly, we argue that our approach here is a useful for

Artiﬁcial General Intelligence in that it demonstrates

how machine learning can be used together with for-

mal methods to develop a practical reasoning tool.

REFERENCES

Alchourr

on, C., G

ardenfors, P., and Makinson, D. (1985).

On the logic of theory change: Partial meet func-

tions for contraction and revision. Journal of Symbolic

Logic, 50(2):510–530.

Darwiche, A. and Pearl, J. (1997). On the logic of iterated

belief revision. Artiﬁcial Intelligence, 89(1-2):1–29.

Hunter, A. (2018). Learning belief revision operators. In

Proceedings of the Canadian Conference on Artiﬁcial

Intelligence, pages 239–245.

Hunter, A. and Agapeyev, J. (2020). GenC: A fast tool for

applications involving belief revision. In Proceedings

of the Twenty-Ninth International Joint Conference on

Artiﬁcial Intelligence, IJCAI 2020, pages 5219–5221.

Katsuno, H. and Mendelzon, A. (1992). Propositional

knowledge base revision and minimal change. Arti-

ﬁcial Intelligence, 52(2):263–294.

Liberatore, P. (2015). Revision by history. Journal of Arti-

ﬁcial Intelligence Research, 52:287– 329.

Mitchell, T. M. (1997). Machine learning, International

Edition. McGraw-Hill Series in Computer Science.

McGraw-Hill.

Peppas, P. and Williams, M. (2018). Parametrised differ-

ence revision. In Proceedings of the International

Conference on Principles of Knowledge Representa-

tion and Reasoning (KR), pages 277–286.

Raschka, S. and Mirjalili, V. (2019). Python Machine

Learning: Machine Learning and Deep Learning with

Python, Scikit-Learn, and TensorFlow 2, 3rd Edition.

Expert insight. Packt Publishing, Limited.

ICAART 2022 - 14th International Conference on Agents and Artiﬁcial Intelligence

756
