A Distributed Intelligent Intrusion Detection System based on Parallel

Machine Learning and Big Data Analysis

Faten Louati

1,4 a

, Farah Barika Ktata

2,4

and Ikram Amous Ben Amor

3,4

Faculty of Economics and Management of Sfax, Tunisia

Higher Institute of Applied Sciences and Technology of Sousse, Tunisia

National School of Electronics and Telecommunications of Sfax, Tunisia

Multimedia, InfoRmation Systems and Advanced Computing Laboratory (MIRACL), Tunisia

Keywords:

Intrusion Detection, Big Data, Reinforcement Learning, Multi Agent System.

Abstract:

Networking security continue to be a serious challenge for all domains because of the increasing number of

attacks launched every day due to the advent of connected devices and the emergence of the Internet. Hence,

Intrusion detection system comes into focus, especially with the inception of big data challenges. In this

paper, we propose a distributed and parallel intrusion detection system suitable for big data environments

using machine learning-based multi agent system and big data analysis.

1 INTRODUCTION

Machine Learning (ML) techniques are investigated

for malicious purposes as well as for good purposes.

In fact, Hackers spares no effort to beneﬁt from the

novel technologies and intelligent ML algorithms to

launch novel attacks. For this reason, researchers are

facing a very serious challenge, they should ﬁnd so-

lutions to secure networks from zero day attacks and

win the war. The largest amount of proposed solu-

tions is based on Intrusion Detection Systems (IDS).

An IDS is a kind of software that monitors, ana-

lyzes networking trafﬁcs and send an alert automat-

ically once a malicious activity is detected (Louati

and Ktata, 2020). Two major techniques are used in

the intrusion detection ﬁeld, namely signature-based

technique (misuse detection) and anomaly-based de-

tection (behavioral detection). Signature-based tech-

nique is based on a set of rules (signatures) stored in a

database and present the attacks known by the system.

The technique consists of comparing the activities of

the network with the stored patterns, if any similarity

is detected, then an alarm is sent automatically to the

administrator. The main advantage of this technique

is that it reduces considerably the false alarm rate.

However, it fails to detect new attacks, even a little

deviation in known attacks can deceive it. However,

hackers quickly learned to use a variety of techniques

https://orcid.org/0000-0002-8582-6092

to modify their attacks to avoid detection. Thus, sig-

nature database should be frequently updated which

is a hard task. Anomaly-based detection in turn con-

sists of comparing the activities in the network with

the normal behavior. Hence, the alarm is triggered

when an abnormal event is detected. Therefore, this

technique can efﬁciently detect known, as well as un-

known attacks. However, it generates a high false

alarm rate, which is the main drawback of this tech-

nique.

Most of the existing and well-used IDSs are

signature-based (Kukielka and Kotulski, 2008), so

they usually fail to detect unseen attacks, also they

are not able to handle big data requirements. To

tackle this problem, we propose an intelligent and dis-

tributed IDS using multi agent system based on paral-

lel ML algorithms.

The remaining part of the paper is organized in the

following way: In section 2 we discuss same previ-

ous works. The description of the proposed IDS and

our contributions are introduced in section 3. Finally,

section 4 concludes the entire work and describes our

future plans.

2 RELATED WORKS

Several previous works are investigated to build an in-

trusion detection mechanism for networks. Recently,

152

Louati, F., Ktata, F. and Ben Amor, I.

A Distributed Intelligent Intrusion Detection System based on Parallel Machine Learning and Big Data Analysis.

DOI: 10.5220/0010886300003118

In Proceedings of the 11th International Conference on Sensor Networks (SENSORNETS 2022), pages 152-157

ISBN: 978-989-758-551-7; ISSN: 2184-4380

with the emergence of ML, many researches beneﬁt

from it. In instance, (Diro and Chilamkurti, 2017)

presented distributed and parallel IDS for IoT using

DL. Experimental results on the NSL KDD dataset

show that DL provides greater accuracy compared

to other ML algorithms, however, it consumes larger

time in training.

The proposed intrusion detection framework in

(Rathore and Park, 2018) is based on semi-supervised

learning. To this end, the authors combine two algo-

rithms, namely, Extreme Learning Machine (ELM),

in which the neural network is composed of a sin-

gle hidden layer, and semi supervised Fuzzy c-means

(SFCM) which is based on the concept of different

types of prior knowledge to enhance clustering per-

formance. In this paper labels are considered as the

prior knowledge.

(Pajouh et al., 2018) used deep recurrent neural

network (RNN) to detect malware by analyzing ap-

plication’s operation codes. The evaluation of the pro-

posed model achieved an accuracy of 98%.

The work in (Mahmudul et al., 2019) compared

different ML algorithms, namely, logistic Regression,

support vector machine (SVM), decision tree, random

forest and artiﬁcial neural network and the results

show that random forest is the most efﬁcient tech-

nique in detect attacks for IoT networks with 99.4%

of accuracy rate.

(Zhang et al., 2019) proposed an intrusion detec-

tion scheme using genetic algorithm (GA) and deep

believe network (DBN). Evaluation on NSL KDD

dataset provided more than 99% of detection rate.

Multi agent system (MAS) approach has been also

exploited in detection task. In instance, (Achbarou

et al., 2018) proposed a distributed IDS (DIDS) for

cloud computing that combines both misuse detec-

tion and anomaly detection techniques. The pro-

posed model is based on a number of agents. The

authors performed a comparison between their model

and similar systems that not used MAS and they con-

cluded that IDS with MAS worked better in term of

efﬁciency and detection time.

Other works used MAS approach in intrusion de-

tection such as (Al-Yaseen et al., 2016) in which au-

thors used two classiﬁers with MAS namely SVM and

ELM, and (Mehmood et al., 2018) which used naive

Bayes algorithm.

There are some existing works that used reinforce-

ment learning (RL) algorithm with MAS technology

in intrusion detection task for IoT such as (Servin and

Kudenko, 2007), however, there is a lack of commu-

nication between agents which is an essential require-

ment to create MAS.

(Arel et al., 2010) provided an IDS based on DRL

for cloud computing.

(Nie et al., 2021) introduce an IDS for green IoT

(composed of a number of devices connected to ap-

plication) based on DRL, the model performs good

results (more than 99% of prediction rate).

(Sethi et al., 2020), (Gu et al., 2020) and (Arel

et al., 2010) propose an IDS for cloud computing and

IoT based on DRL.

Ather works investigated zero shot learning (ZSL)

such as, (Zhang et al., 2020) who used ZSL based on

autoencoder. This method gives 88.3% of accuracy

rate with NSL KDD dataset.

(Zerhoudi et al., 2020) proposed an IDS using zero

shot recognition via graph embedding. The results

show an accuracy rate = 88.3% in NSL KDD dataset.

Although those cited works performed very good

results, their proposed solutions are not suitable for

new environments based on big data. Hence, they are

not able to deal with big data challenges.

Few papers focus on Intrusion detection systems

in big data frameworks (Hassan et al., 2020), such as

the work of (Terzi et al., 2017) which detects network

anomaly from Netﬂow data using clustering algo-

rithm. The work was tested on the CTU-i3 dataset and

performs 96% of accuracy rate. However, it causes

hiqh false alarm rate (FAR).

In addition, (Hassan et al., 2020) used conven-

tional neural network (CNN) and weight dropped

long short-term memory (WDLSTM) network in big

data context. Experiments are performed on UNSW-

NB15 and show good results (e.g. accuracy=97.17%).

3 METHODOLOGY

3.1 Concepts

3.1.1 Big Data

The term big data dates back to 2005, it is typically

deﬁned with three words: volume, velocity and vari-

ety (the famous 3Vs of big data):

• Volume: Size of the data; Big data refers to a huge

amount of data.

• Velocity: The speed of the data; Big data charac-

terized by its speed of movement.

• Variety: Diversity of data; Varied Big data are

coming from diverse sources, it could be struc-

tured, non structured or semi structured.

A Distributed Intelligent Intrusion Detection System based on Parallel Machine Learning and Big Data Analysis

153

3.1.2 Multi Agent System

Multi agent system is a collection of entities called

agents that are communicating with each other. Ac-

cording to the deﬁnition of FIPA (Foundation for the

Intelligent Physical Agent), an agent is a kind of en-

tity with autonomy, activity, mobility, re-activity, so-

ciality, intelligence and other features (FIPA, 2002)

(Wooldridge, 2009). (Oprea, 2004) deﬁnes the multi-

agent system equation as it ”states that in a multi-

agent system a task is solved by agents that commu-

nicate among them.”

3.2 Proposed Solution

Our solution consists of merging machine learning al-

gorithms with Big data analysis techniques to create

an intrusion detection system able to perform detec-

tion in new big data environments. Big data means

a huge amount of data and that what new machine

learning algorithms need to make their models.

Also beneﬁting from multi agent system is a

promising idea as multi agent systems help to im-

prove reliability and availability and ensure informa-

tion collecting, sharing and processing in distributed

networks.

Figure 1 depicts the structure of our solution: The

model is composed of a combination of multi agent

system, machine learning algorithm and big data ana-

lytic. Firstly, the network trafﬁc is collected by Agent

Sniffer then sent to the Agent preprocessor to be pro-

cessed. After that, the data are sent to Hadoop frame-

work to be analyzed in parallel manner. This frame-

work in turn is composed of a name node which con-

sists of an Agent decision maker and a number of data

nodes (at least three nodes). The agent decision maker

runs reinforcement learning (RL) algorithm -which is

sub-ﬁled of machine learning- in the name node and

detect intrusions.

RL is about an agent interacting with the envi-

ronment, learning an optimal policy, by trial and er-

ror (and not by simple recognition of data that may

have been provided to it which is the case of tradi-

tional ML techniques): the program repeats one or

more experiences a large number of times in order to

learn to take good choices and avoid bad choices in a

given situation. This learning method allows agents

to understand the environment in which they operate,

to build their own decision-making mechanism, and

to act with more rationality. Moreover, this learning

technique could ultimately make agents even smarter

by allowing them to react to unexpected situations.

See (Li, 2017) for deep details.

Due to the dynamic changes of networks, new

kinds of attacks are emerging every day. DRL could

be a good choice to deal with this challenge as it is

enable the agent to learn with a rational manner by

optimizing its choices from previous experiences sim-

ulated by himself.

All the agents in the MAS ensure communications

between them.

Merging Big data analysis, recent machine learn-

ing algorithms and multi agent system seems promis-

ing solution since it performs 1) parallels of the pro-

cessing of large volume of data by means Hadoop

framework, 2) Excellent classiﬁcation of the data us-

ing efﬁcient machine learning classiﬁers and 3) En-

hance time consumption and performance using multi

agent system.

3.3 Experiments

This paper presents a work in progress, the implemen-

tation of this framework is not yet achieved. So far,

we build an IDS based on Deep Reinforcement learn-

ing agent, This agent is expected to be executed in the

name node.

RL agent is trained on NSL KDD which is a very

large dataset so it well represents the context of big

data. NSL KDD (NSL, ) is an enhanced version of

KDD 99 benchmark dataset (Ring et al., 2019) and is

well known and wide used by researchers in intrusion

detection ﬁeld. Figure2 describes the dataset which

is composed of three sub-datasets KDDTrain+20%

composed of 25192 samples, KDDTrain+ composed

of 125973 samples and KDDTest+ composed of

22544 samples. The dataset is about 42 feature; the

last one presents whether the record is normal or one

of the four known networking attacks namely, Denial

of Service (DoS) Probe, User to Root (U2R) and Re-

mote to Local (R2L).

Firstly, the dataset was preprocessed. The prepro-

cessing phase is composed of three steps 1)Numeri-

calization; as there are symbolic and categorical fea-

tures in the dataset 2)Removing attributes with miss-

ing data 3) Data scaling because the data have varying

ranges.

The RL agent is based on deep Q network(DQN)

algorithm which the neural network is composed of 1

input layer (122 neurons, i.e the number of features

of NSL KDD data set after being preprocessed), three

hidden layers composed of 80, 50 and 20 neurons re-

spectively and an output layer composed of 5 neurons

which refer to the ﬁve classes (normal, DoS, U2R,

Probe and R2L). All the layers are fully connected

and use Relu as activation function. Tables 2 and 1

describe the parameters of the model which performs

good results (see Table 3).

SENSORNETS 2022 - 11th International Conference on Sensor Networks

154

Figure 1: The sructure of the proposed solution.

Figure 2: Description of NSL KDD dataset (Saporit, 2019).

Table 1: Reinforcement learning components.

Algorithm Environment States Actions Rewards

DQN Network Features of the dataset attack types + normal 1 if good classiﬁcation

0 if not

The objective of this paper is to share our solution

and explain our idea. The next step consists of :

1) Improving the results

2) Implementing the whole proposed scheme, i.e.

Hadoop and multi agent system

3) Performing experimentation with the dataset as

well as real network trafﬁc

4) Performing near-real time detection.

A Distributed Intelligent Intrusion Detection System based on Parallel Machine Learning and Big Data Analysis

155

Table 2: Reinforcement learning parameters.

Policy Epsilon greedy

Optimizer Adam

batch size 1

minibatch size 500

decay rate 0.99

gamma 0.001

Table 3: Experimental results.

Accuracy 75.65%

Precision 79.51%

F1 score 72.58%

Recall 75.65%

4 CONCLUSION

In this paper, we presented a short description of our

proposed solution for security problem in networks.

We introduced ﬁrstly the general context of this re-

search, then we listed a number of existing solution.

in literature. Next we described our solution and our

contributions. This work is an initial proposal; The

next steps are implementation and evaluation of our

proposed model using conventional metrics to show

its efﬁciency in the detection of zero-day attacks in

real time.

REFERENCES

Nsl kdd. https://www.unb.ca/cic/datasets/nsl.html.

Achbarou, O., Kiram, M., Bourkoukou, O., and Elbouanani,

S. (2018). A Multi-agent System-Based Distributed

Intrusion Detection System for a Cloud Comput-

ing: MEDI 2018 International Workshops, DETECT,

MEDI4SG, IWCFS, REMEDY, Marrakesh, Morocco,

October 24–26, 2018, Proceedings, pages 98–107.

Al-Yaseen, A. P. D. W., Othman, Z., and Ahmad Nazri,

M. Z. (2016). Real-time multi-agent system for an

adaptive intrusion detection system. Pattern Recogni-

tion Letters, 85.

Arel, I., Liu, C., Urbanik, T., and Kohls, A. (2010). Rein-

forcement learning-based multi-agent system for net-

work trafﬁc signal control. Intelligent Transport Sys-

tems, IET, 4:128 – 135.

Diro, A. and Chilamkurti, N. (2017). Distributed attack de-

tection scheme using deep learning approach for inter-

net of things. Future Generation Computer Systems.

FIPA (2002). Fipa abstract architecture speciﬁca-

tion. Available from: http://www. ﬁpa.org/

specs/ﬁpa00001/SC00001L.html.

Gu, T., Abhishek, A., Fu, H., Zhang, H., Basu, D., and

Mohapatra, P. (2020). Towards learning-automation

iot attack detection through reinforcement learning.

In 2020 IEEE 21st International Symposium on ”A

World of Wireless, Mobile and Multimedia Networks”

(WoWMoM), pages 88–97.

Hassan, M. M., Gumaei, A. H., Alsanad, A., Alrubaian, M.,

and Fortino, G. (2020). A hybrid deep learning model

for efﬁcient intrusion detection in big data environ-

ment. Inf. Sci., 513:386–396.

Kukielka, P. and Kotulski, Z. (2008). Analysis of differ-

ent architectures of neural networks for application in

intrusion detection systems. 2008 International Mul-

ticonference on Computer Science and Information

Technology, pages 807–811.

Li, Y. (2017). Deep reinforcement learning: An overview.

Louati, F. and Ktata, F. (2020). A deep learning-based

multi-agent system for intrusion detection. SN Applied

Sciences, 2.

Mahmudul, H., Islam, M, Z., and M.M.A., H. (2019). At-

tack and anomaly detection in iot sensors in iot sites

using machine learning approaches. 7.

Mehmood, A., Mukherjee, M., Ahmed, S. H., Song, H., and

Malik, K. (2018). Nbc-maids: Na

ıve bayesian classi-

ﬁcation technique in multi-agent system-enriched ids

for securing iot against ddos attacks. The Journal of

Supercomputing, 74.

Nie, L., Sun, W., Wang, S., Ning, Z., Rodrigues, J. J.

P. C., Wu, Y., and Li, S. (2021). Intrusion detection

in green internet of things: A deep deterministic pol-

icy gradient-based algorithm. IEEE Transactions on

Green Communications and Networking, 5(2):778–

788.

Oprea, M. (2004). Applications of multi-agent systems. In

IFIP Congress Tutorials.

Pajouh, H. H., Dehghantanha, A., Khayami, R., and Choo,

K.-K. R. (2018). A deep recurrent neural network

based approach for internet of things malware threat

hunting. Future Gener. Comput. Syst., 85:88–96.

Rathore, S. and Park, J. (2018). Semi-supervised learning

based distributed attack detection framework for iot.

Appl. Soft Comput., 72:79–89.

Ring, M., Wunderlich, S., Scheuring, D., Landes, D., and

Hotho, A. (2019). A survey of network-based intru-

sion detection data sets. Comput. Secur., 86:147–167.

Saporit, G. (2019). A deeper dive into the nsl-kdd

data set. https://towardsdatascience.com/a-deeper-

dive-into-the-nsl-kdd-data-set-15c753364657.

Servin, A. and Kudenko, D. (2007). Multi-agent reinforce-

ment learning for intrusion detection. In Adaptive

Agents and Multi-Agents Systems.

Sethi, K., Kumar, R., Prajapati, N., and Bera, P. (2020).

Deep reinforcement learning based intrusion detection

system for cloud infrastructure. In 2020 International

Conference on COMmunication Systems NETworkS

(COMSNETS), pages 1–6.

Terzi, D. S., Terzi, R., and Sagiroglu, S. (2017). Big data

analytics for network anomaly detection from netﬂow

data. In 2017 International Conference on Computer

Science and Engineering (UBMK), pages 592–597.

Wooldridge, M. (2009). An Introduction to MultiAgent Sys-

tems. Wiley Publishing, 2nd edition.

Zerhoudi, S., Granitzer, M., and Garchery, M. (2020). Im-

proving intrusion detection systems using zero-shot

recognition via graph embeddings. In 2020 IEEE 44th

SENSORNETS 2022 - 11th International Conference on Sensor Networks

156

Annual Computers, Software, and Applications Con-

ference (COMPSAC), pages 790–797.

Zhang, Y., Li, P., and Wang, X. (2019). Intrusion detection

for iot based on improved genetic algorithm and deep

belief network. IEEE Access, 7:31711–31722.

Zhang, Z., Liu, Q., Qiu, S., Zhou, S., and Zhang, C. (2020).

Unknown attack detection based on zero-shot learn-

ing. IEEE Access, 8:193981–193991.

A Distributed Intelligent Intrusion Detection System based on Parallel Machine Learning and Big Data Analysis

157
