Feature Importance and Deep Learning for Android Malware Detection

A. Talbi

1,2

, A. Viens

, L.-C. Leroux

, M. Franc¸ois

, M. Caillol

and N. Nguyen

4,2

ole Judiciaire de la Gendarmerie Nationale, Cergy, France

ETIS Laboratory, CY Cergy Paris University, Cergy, France

CY Tech, CY Cergy Paris University, Cergy, France

eonard de Vinci P

ole Universitaire, Research Center, Paris La D

efense, France

Keywords:

Android Malware Detection, Static Analysis, Feature Importance, URL Embedding, Deep Neural Network.

Abstract:

Effective and efﬁcient malware detection is key in today’s world to prevent systems from being compromised,

to protect personal user data, and to tackle other security issues. In this paper, we worked on Android malware

detection by using static analysis features and deep learning methods to separate benign applications from

malicious ones. Custom feature vectors are extracted from the Drebin and the AndroZoo dataset and different

data science methods of feature importance are used to improve the results of Deep Neural Network classiﬁca-

tion. Experimental results on the Drebin dataset were signiﬁcant with 99.31% accuracy in malware detection.

We extended our work on more recent applications with a complete pipeline for the AndroZoo dataset, with

about 40,000 APKs used from 2014 to 2021 pre-tagged as reported malicious or not. The pipeline includes

static features extracted from the manifest ﬁle and bytecode such as suspicious behaviors, restricted and sus-

picious API calls, etc. The accuracy result for AndroZoo is 97.7%, conﬁrming the power of deep learning on

Android malware detection.

1 INTRODUCTION

Since the start of the 2010 decade, the smartphone

has become essential for everyone. As its place in

our daily life is growing, we trust it enough to entrust

it with important and sensitive data such as our bank

details or even medical data. Recently, Android is the

number one Operating System (OS) in the world (all

platforms), with about 40.39% of the global operating

system market share in 2021 (StatCounter, 2021).

At the same time, the prevalence of the Android

operating system, combined with its open nature, has

caused the number of Android malware to skyrocket.

To solve this problem, the research communities and

security vendors have designed many techniques to

identify and prevent Android malicious samples, and

two main classes of software approaches to Android

malware program analysis exists and have been stud-

ied: static and dynamic. Static approaches leverage

static code analysis to check whether an application

contains abnormal information ﬂows or calling struc-

tures, matches malicious code patterns, requests for

excessive permissions, and/or invokes APIs that are

frequently used by malware. Static analysis of an

Android application can rely on features extracted

from the manifest ﬁle or the Java bytecode, while dy-

namic analysis of Android applications can deal with

features involving dynamic code loading and system

calls that are collected while the application is run-

ning. However the main limitation to the use of dy-

namic analysis is that it requires the study of program

behavior, the execution of each instruction, and the

ability to modify instructions or registers during this

phase.

For the detection and classiﬁcation purposes, in

addition to the use of traditional and manual tech-

niques such as static and dynamic analysis, works us-

ing artiﬁcial intelligence and more particularly deep

learning, have shown encouraging results. Our ap-

proach combines static analysis on bytecode and data

retrieval from Android Package (APK) ﬁles for mul-

tiple feature extraction, with the use of 5-layers neu-

ral networks that are trained on a large amount of

data. For the experimental results, we obtained two

application databases: one from Drebin’s team (Arp

et al., 2014) but whose applications are a bit dated and

the other coming from AndroZoo (Allix et al., 2016),

which is an application database made available by

the University of Luxembourg to the scientiﬁc com-

munity.

Talbi, A., Viens, A., Leroux, L., François, M., Caillol, M. and Nguyen, N.

Feature Importance and Deep Learning for Android Malware Detection.

DOI: 10.5220/0010875500003120

In Proceedings of the 8th International Conference on Information Systems Security and Pr ivacy (ICISSP 2022), pages 453-462

ISBN: 978-989-758-553-1; ISSN: 2184-4356

 2022 by SCITEPRESS – Science and Technology Publications, Lda. All r ights reserved

453

On the Drebin data, we used already extracted fea-

tures such as permissions, activities, API calls, etc.

and we obtained an accuracy rate in detecting ma-

licious applications of 99.31%. With the AndroZoo

data, we selected only the applications after 2014,

and we extracted the features coming from the An-

droidManifest.xml ﬁle but also those coming from

the bytecode, such as suspicious behaviors, network

addresses, suspicious API calls, and restricted API

calls. We labelled an application as malicious if it was

ﬂagged by at least 4 antivirus on VirusTotal (Sood,

2017). Then we followed a process of cleaning and

formatting the data, selecting the best features, and

performing a dataset slicing. Finally, 5-layers deep

learning models are trained and optimized by adjust-

ing different parameters and we came up with results

offering very high accuracy.

Our main contributions in combining deep learn-

ing and static analysis for Android malware detection

are as follows. We proposed a detailed feature engi-

neering process by: i) including more feature types

on feature extraction, ii) grouping similar features,

iii) selecting important features from a large num-

ber of feature sets, and iv) embedding Uniform Re-

source Locator (URL) using Natural Language Pro-

cessing (NLP). For feature extraction, we obtained a

new set of features targeting suspicious actions from

Smali bytecode for AndroZoo dataset, which was not

used by Drebin.

The paper is organized as follows. Section 2 ref-

erences existing work related to malware detection by

using artiﬁcial intelligence techniques. Then, Sec-

tions 3 represents our methodology with 5 steps. The

feature extraction step is described in Subsection 3.1.

Subsections 3.2 and 3.3 focus, respectively, on the

grouping and selection of the most important features

required for the classiﬁcation of applications. In Sub-

section 3.4, an overview is provided on URL embed-

ding to improve the recognition of certain URLs used

more frequently in malware. Subsection 3.5 describes

the feeding of features into a deep neural network for

binary classiﬁcation, once these features have been

extracted and pre-processed. In Section 4, results ob-

tained with two datasets are presented and compared,

in the ﬁrst instance, the Drebin dataset, using their

pre-extracted features from the APK ﬁles, and then

on the AndroZoo dataset in which feature extraction

was performed by ourselves. Finally, conclusions and

perspectives are described in Section 5.

2 RELATED WORK

Over the past few years, many solutions have been

proposed to detect Android malware using machine

learning algorithms. Recent reviews such as (Naway

and Li, 2018), (Wang et al., 2019), and (Liu et al.,

2020) provided clear and comprehensive surveys of

the state of the art in the domain. (Naway and Li,

2018) gave an overview of the different papers using

deep learning algorithms for malware detection with

their different performances as well as datasets used.

(Wang et al., 2019) presented a comparative analysis

of 236 published papers on feature extraction tech-

niques for Android applications. (Liu et al., 2020)

complemented the previous reviews by surveying a

wider range of aspects concerning machine learning

development pipeline. For the rest of this section, we

will present several approaches which are most rele-

vant and closer to our work.

The authors in (Wu et al., 2012) ﬁrst extracted the

information from each application’s manifest ﬁle, and

then, applied the K-Means algorithm that enhances

the malware modeling capability. The number of

clusters is decided by Singular Value Decomposition

(SVD) method on the low rank approximation. They

used the K-Nearest Neighbors (KNN) algorithm to

classify the application as benign or malicious. The

comparison with Androguard tool showed a better

performance of this method. In addition, Droid Mat

is efﬁcient since it takes only half of time than Andro-

guard to predict 1,738 apps as benign apps or Android

malware.

(Arp et al., 2014) proposed DREBIN, a

lightweight method for the detection of Android

malware that enables identifying malicious appli-

cations directly on the smartphone. As the limited

resources impede monitoring applications at run-

time, DREBIN performed a broad static analysis,

gathering as many features of an application as

possible. These features were embedded in a joint

vector space, such that typical patterns indicative for

malware can be automatically identiﬁed and used

for explaining the decisions of their method. In an

evaluation with 123,453 applications and 5,560 mal-

ware samples, DREBIN outperformed several related

approaches and detected 94% of the malware with

few false alarms, where the explanations provided

for each detection reveal relevant properties of the

detected malware. On ﬁve popular smartphones, the

method required 10 seconds for an analysis on aver-

age, rendering it suitable for checking downloaded

applications directly on the device.

Recently, particular research has been focused on

tuning the network parameters. In (Hou et al., 2016),

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

454

different network architectures are tested while tun-

ing the parameters to reach a higher level in terms of

detection accuracy. In (Backes and Nauman, 2017),

the hyperparameters of Convolution Neural Network

(CNN) are tuned while using a dropout of 0.2 at each

convolution layer to reduce overﬁtting, which leads to

the conclusion that the largest network gives the high-

est statistical metric values.

In the work of (Nix and Zhang, 2017), a CNN is

built and evaluated for API call-based Android app

classiﬁcation. Long Short-Term Memory (LSTM)

technique is integrated to extract knowledge from

system API-call sequences. CNN results are com-

pared with respect to n-gram Support Vector Machine

(SVM) and the Naive Bayes algorithm and the perfor-

mance of CNN is much better compared to others.

In another study (Kapratwar et al., 2017), the au-

thors proposed a malware detection method inspired

by deep learning about the exhaustive combination of

static and dynamic analysis, which traces all possible

execution paths of a given ﬁle, then compares the ﬂow

graphs in real time for malware identiﬁcation. Their

premise is that deep learning with a deep architecture

can evolve high-level representations by associating

features from static analysis with those from dynamic

analysis, which can then better characterize Android

malware.

In another register of Android permission based

malware detection technique, (Dong, 2017) gathered

a huge set of both malware and benign applications

through web crawler and developed a tool to decom-

pile applications to source code and manifest ﬁles au-

tomatically. Then permissions with other informa-

tion are extracted for each app, to ﬁnally take advan-

tage of machine learning algorithms, including Lo-

gistic Regression Model, Tree Model with ensemble

techniques, Neural Network and an ensemble model

to ﬁnd patterns and more valuable information. This

method generated a good accuracy, F-score and over-

all performance of malicious application prediction.

The default model with one hidden layer and total

perceptron’s returns an accuracy of 93% and F-score

90%.

(Ganesh et al., 2017) proposed a deep learning-

based malware detection to identify and categorize

malicious applications. The study partially used

Drebin dataset. The method investigated permission

patterns based on a CNN and they identiﬁed malware

with 93% accuracy on a dataset of 2,500 Android ap-

plications, of which 2,000 were malicious and 500

were benign.

Also using the Drebin dataset, (Li et al., 2018)

proposed an Android malware characterization and

identiﬁcation approach that uses deep learning algo-

rithms to address the urgent need for malware detec-

tion. Extensive experimental results showed that their

approach achieved over 90% accuracy with only 237

features.

(Kim et al., 2019) presented a different approach

that uses various kinds of features to reﬂect the prop-

erties of Android applications from several aspects.

The features are reﬁned using existence-based or

similarity-based feature extraction method for effec-

tive feature representation on malware detection. Be-

sides, a multimodal deep learning method is proposed

to be used, for the ﬁrst time, as a malware detection

model and recorded an accuracy of 85%.

(Pektas¸ et al., 2020) used the API call graph as

a graph representation of all possible execution paths

that a malware can track during its runtime. The em-

bedding of API call graphs transformed into a low

dimension numeric vector feature set is introduced

to the DNN. Then, similarity detection for each bi-

nary function is trained and tested effectively. This

study also focused on maximizing the performance

of the network by evaluating different embedding al-

gorithms and tuning various network conﬁguration

parameters to ensure the combination of the hyper-

parameters and to reach the highest statistical metric

value.

It is within this framework that our work ﬁts, with

the objective of optimizing the detection precision by

using DNN as well as the feature importance and the

extraction of additional features.

3 OUR METHODOLOGY

Our objective is to determine if an application is a

malware from its APK, with a high precision. To this

end, we train a deep learning model from a database

of APKs. Our methodology is divided in ﬁve steps.

First, we extract various features from the APKs,

such as permissions, app components, suspicious API

calls, network address, etc. Then, we preprocess all

these features in order to optimize the vectors that will

be fed as the inputs of our deep learning models by us-

ing feature grouping and feature ﬁltering techniques.

In parallel, a URL embedding framework is carried

out. And after training our models with different ar-

chitectures, we analyze the results to understand the

predictions and the improvements to carry on. The

ﬂowchart in Figure 1 goes over this whole process.

The numbers from the Drebin dataset (detailed later

in Section 4) are used to illustrate the vector size re-

duction.

Feature Importance and Deep Learning for Android Malware Detection

455

Figure 1: Methodology Flowchart (Drebin Dataset).

3.1 Feature Extraction

In order to perform malware detection from static

analysis, the ﬁrst step is to extract the needed fea-

tures from the applications that are in APK format.

There exists different types of features suggested by

Drebin and proven to be effective, that are divided

into 8 groups, ranging from S1 to S8 as shown in Ta-

ble 1.

The S1 to S4 sets are extracted from AndroidMan-

ifest.xml which provides data supporting the instal-

lation and later execution of the application. It in-

cludes the requested hardware components such as

camera, GPS, etc., the permissions that the applica-

tion needs in order to access protected parts of the sys-

tem or other applications, the components of the ap-

plication which include all activities, services, broad-

cast receivers and content providers, and also ﬁltered

intents.

The features S5 to S8 are from the Dalvik byte-

code. The restricted API calls (S5) are retrieved by

static analysis of the bytecode by taking all the API

calls of the application and looking at what permis-

sions are needed to use these APIs. So if one of these

permissions is not mentioned in the AndroidMani-

fest.xml ﬁle, then the API combined with the needed

permission is picked up and set as a feature, as this

can sometimes imply an exploit used by malware to

perform an action without permission. S6 (Used Per-

missions) contains permissions that are asked by the

application at some point during its execution. The

selection of suspicious APIs (S7) is done based on

the list of most used APIs by malware. Finally, S8

contains the list of IP addresses and URLs present in

the bytecode.

Table 1: Drebin and AndroZoo Static Feature Sets Sug-

gested by (Arp et al., 2014) and Additional Set S9.

S1 Hardware Components S5 Restricted API Calls

S2 Requested Permissions S6 Used Permissions

S3 App Components S7 Suspicious API Calls

S4 Filtered Intents S8 Network Addresses

S9 Suspicious Actions (AndroZoo only)

The notable differences concerning our exploita-

tion of the datasets are that Drebin was already con-

stituted of the extracted features (from S1 to S8). But

for AndroZoo, we only had the list of APKs, the fea-

tures are extracted with our own scripts by using the

general idea of Drebin for the S1 to S8 features. In ad-

dition, a new set of features named ”Suspicious Ac-

tions” (S9) has been extracted. The interest of this

set of features is that it gathers combined actions that

represent proven malicious behaviors. For example,

when a malware tries to intercept the incoming SMS,

it has to run a daemon in back-end listening incoming

SMS and to exﬁlter them through the HTTP protocol.

So the features from S9 target speciﬁc malicious tech-

niques which are exﬁltration of phone data and con-

ﬁguration, geolocation data leakage, exﬁltration of in-

terface connection information, abuse of telephony

service, interception of audio and telephony streams,

establishment of remote connections, Personal Infor-

mation Manager (PIM) data leakage, operations on

external memory, modiﬁcation of PIM data, arbitrary

code execution, and service denial. The extraction

of these features was performed with the Python li-

brary Androwarn, by using Smali which is an assem-

bler/disassembler for the dex format used by Dalvik

bytecode.

These features are then one-hot encoded, which

creates a sparse vector where each dimension is 1 if

the feature is present, and 0 otherwise. Some of the

sets contain very little possible distinct values. The

number of possible permissions in S6 (Used Permis-

sions) is limited by Android OS whereas the num-

ber of unique network addresses can be substantially

large. For some of the sets, the one-hot encoded rep-

resentation of every possible features may be subopti-

mal. In fact, most of the dimensions of S3 (App Com-

ponents) and S8 (Network Addresses) do not bring

much information to the neural network, but rather

add noise. It inspired us to perform feature selection

and feature engineering on S1 to S8 sets, in order to

reduce memory and computing time of our feature

generation and network training. By selecting only

the best features, we expect the same or just a small

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

456

decrease in results but with limited computing time.

However, feature engineering is expected to add in-

formation to the network, increasing the overall accu-

racy.

For S8, due to the nature of URLs, only a small

subset is used in different apps, and most of them are

unique. Consequently, one-hot encoding URLs may

not bring any information to the neural network, and

does not capture the similarity between two pages of

the same website, or similar URLs. We developed an

URL embedding framework to capture the represen-

tation of the URLs used in the app in the same-sized

numerical vector, which is supposed to capture more

information than just the re-use of a speciﬁc URL.

This framework is discussed in Section 3.4.

3.2 Feature Grouping

A lot of features extracted from the appli-

cation are texts, separated by dots. For

example, a permission feature looks like

‘com.android.launcher.permission.READ SETTINGS’,

and it’s similar for the other subsets. But not all

the parts of the text have the same information.

For the permissions, we select only the last part of

the text, after the last dot: ‘READ SETTINGS’.

Taking only this part regroups a lot of differ-

ent features ﬁnishing by the same text, like:

’com.motorola.launcher.permission.READ SETTINGS’,

or ’org.adw.launcher.permission.READ SETTINGS’.

To illustrate the new features, Figure 2 represents

the percentage of malware applications in the Drebin

dataset which have these speciﬁc features.

Figure 2: Percentage of Drebin Malware Applications with

Permission Grouped Features.

Thereby, we have a new permission feature

’READ SETTINGS’ created by this process, which

we do for all the subsets. We choose to keep the

original features for the subsets of small dimensions,

like the permissions (S2 and S6) or intents (S4). But

for large subsets like activities in S3, we keep only

the regrouped features. By this process, we reduced

the number of unique values from 234,887 (URLs ex-

cluded) to 48,914 for Drebin (Figure 1), and we added

new information.

3.3 Feature Selection

Our objective now is to reduce more the number of

unique features in order to increase the efﬁciency of

the model’s training. For that, we rank all the features

by their importance to the malware application pre-

diction in order to keep only the best ones. To have

a precise estimation of the importance of each fea-

ture, we combine the importance of the features from

5 different algorithms: the Pearson Correlation, the

Chi-Squared metric, and 3 machine learning models

which are Logistic Regression, Random Forest and

LightGBM. For each algorithm, we rank the features

by their importance to the prediction. But to have a

more precise ranking, we deﬁne a score for each fea-

ture, according to its ranking for each algorithm, us-

ing the rank product.

Table 2 illustrates the ranking for the permission

subset of the Drebin dataset. The column Top Algo

represents the number of algorithms that the feature is

in the top 80% of the ranking, the column Score stores

the rank product score and is used for ﬁltering the fea-

tures. With this ranking, we can ﬁlter the n top fea-

tures of each set. The more features are selected, the

more the deep learning model will have one-encoded

input and will take time to optimize the weights of

each feature. In our study, we selected all the fea-

tures with a score less than 300, which corresponds to

2,118 features with the Drebin dataset (Figure 1).

3.4 URL Embedding

In order to use the URLs found in the APKs, they

have to be represented in a ﬁxed-length vector. To

this end, we used the work of (Yuan et al., 2018) en-

abling a URL to be represented in a ﬁxed-size vector

space. Their work has shown that it is beneﬁcial to

split the URL into different parts in order to improve

the representation and subsequently the performance

of the machine learning models. For example, a URL

can be divided into 5 parts: protocol, sub-domain, do-

main, domain sufﬁx, and URL path. In our frame-

work, we divided URLs into 3 parts: P1 (Protocol),

Feature Importance and Deep Learning for Android Malware Detection

457

Table 2: Permission Features Ranking for Drebin Dataset.

Feature Pearson Chi-

Square

Logistic

Regression

Random

Forest

LightGBM Top

Algo

Score

android.permission.SEND SMS 1 1 29 2 7 5 3.324

READ SMS 3 3 156 4 13 5 9.39

SEND SMS 2 2 30 1 722 4 9.717

ACCESS COARASE LOCATION 845 791 1127 1682 2865 2 1294.141

. . .

P2 (sub-domain + domain + domain sufﬁx), and P3

(URL path). The usefulness of the URL parts decom-

position is that two URLs with the same protocol, and

the same domain, but with a different path, will have

2/3 of their vector representation identical.

Then, we train a character model that gives repre-

sentation of each character in a vector space via lan-

guage modeling. We model our URLs into a sequence

of characters: U = c

...c

. The characters c

∈ V

are part of a vocabulary V , that contains all possible

characters in the URL corpus. Subsequently, we use

this character model to build a vector representation

of each part of a URL by averaging all the charac-

ter vectors of that part and then we concatenate these

vector representations to obtain the representation of

the whole URL. The workﬂow is described in Figure

Almost always, an application accesses not one

but multiple URLs or IP addresses. Since the rep-

resentation of all the URLs of an application has to be

of ﬁxed size, the last step is the aggregation of these

representations. We used two types of autoencoders

to this end. One Long Short-Term Memory (LSTM)

autoencoder that accepts variable-length URL repre-

sentation that outputs one compressed representation,

and another autoencoder that accepts padded lists of

URL representations. As shown in Figure 4, the au-

toencoder takes k URLs in its input layer, and the

middle hidden layer is a vector of features that carries

most of the important information. This URL encod-

ing allows us to reduce the number of URL unique

values from 310,447 to 300 (Figure 1). The imple-

mentation of these autoencoders is successful but as

described later in Section 4, the contribution is negli-

gible, as they could not learn a meaningful represen-

tation of all the URLs used in an application.

3.5 Deep Learning Classiﬁcation

Once each feature has been extracted and pre-

processed, we can feed it into a DNN for binary clas-

siﬁcation or multi-class classiﬁcation. As the number

of input dimensions is still pretty high, DNNs are the

most suitable algorithms to perform these classiﬁca-

tions. In fact, they are able to construct high-level,

intermediate feature representations (or concepts) in

the hidden layers that can model complex relation-

ships between input features. Many different ma-

chine learning algorithms have been used to tackle the

detection of Android malware, but DNNs have been

shown to have very good results.

The number of neurons in the input layer corre-

sponds to the size of our feature vectors, while the

number of neurons in the output layer corresponds

to the number of classes we want to predict (2 for a

binary classiﬁcation and 3 or more for a multi-class

classiﬁcation). For our training, we used Tensorﬂow

2.0 with CUDA enabled to parallelize calculations on

the GPU. However, they are costly to train. We tried

different types of network architectures, all with fully

connected layers. Since the use of DNN with 2 lay-

ers composed of 256 neurons each is recommended

in several works (Li et al., 2018), we used this infor-

mation to test our different models and compared the

performance of the 2, 3 and 4 layer conﬁgurations for

the binary and multi-class classiﬁcation cases. The

hidden layers contain between 256 and 512 neurons

each that are connected to a softmax layer, outputting

probabilities for the classes ’Malware’ or ’Benign’.

To optimize the DNN model, we can act on the fol-

lowing hyper parameters: number of hidden layers,

number of neurons per layer, backpropagation algo-

rithm, cost function, and activation function.

As backpropagation algorithm, we have tested the

stochastic gradient descent algorithm and the Adam

algorithm. Adam is an adaptive learning rate opti-

mization algorithm that was designed speciﬁcally for

training of DNNs. In this algorithm, the learning

rate is calculated for each variable and depends on

3 parameters with recommended values: β

= 0.9,

= 0.999, and ε = 1e

−8

To avoid overﬁtting, we have split randomly our

dataset into three subsets. The training set takes 70%

of the dataset and is used to train the model. The val-

idation set to compute at each epoch the metrics on

a set that has not been used for training. The test set

allows us to calculate at the end the capacity of the

network to generalize on a new data set. The con-

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

458

Figure 4: Multiple URL Compressed Representation.

fusion matrix and the different metrics are calculated

from this set.

4 EXPERIMENTAL RESULTS

4.1 Datasets

We ﬁrst worked on the Drebin dataset using their al-

ready extracted features sets. The Drebin dataset con-

tains 123,453 benign applications and 5,560 malware,

divided in 179 malware classes. This dataset has been

assembled from 2010 to 2012 from various Android

application platforms. The advantages of this dataset

are that it is large and the features have already been

extracted from the AndroidManifest.xml ﬁle and from

the bytecode.

Next, we used the AndroZoo dataset to set up an

end-to-end pipeline, from the extraction of the fea-

tures from the manifest ﬁle and the bytecode of the

APKs to neural network learning and testing. This

database is huge, totaling more than 15,500,000 ap-

plications, with various information. We extracted

39,156 APKs from AndroZoo, with a proportion of

12,882 malware that have been identiﬁed by at least

4 antivirus programs as containing malicious code

and 26,274 benign applications from Google markets.

The release dates of these APKs vary from 2014 to

2021, hence some of them are really recent. In An-

droZoo, information about the size, the origin mo-

bile markets and the number of VirusTotal antiviruses

that recognized the app as a malware, or a benign

are given. The number of antiviruses recognizing an

application as malware spans from 0 to 57, and so

we chose to classify as malicious an application with

this number superior or equal to 4 whereas the benign

apps are required to have 0 positive scans.

4.2 Results

4.2.1 Drebin

With the Drebin dataset, we tried different architec-

tures of our model with different input. An accuracy

around 99% with only feature grouping and feature

selection is achieved. By adding URL embedding,

we found that the accuracy did not increase. On the

contrary, the feature importance techniques work well

without URL embedding and we have with the best

architecture up to 99.31% of accuracy, as shown in

Table 3. This architecture is composed of 3 layers

(1024, 512 and 256 cells) and trained with 60 epochs.

The input used are the features with a score less than

300 for the feature selection.

The column F1 represents the F1-score that subtly

combines precision and recall. And in the last column

we have indicated the False Negative Rate (FNR), be-

cause we think it is important to point out the mal-

ware that passes through the analysis without being

detected as such.

Table 3: Results on Drebin Dataset.

Model Accuracy F1 FNR

Best architecture 0.99317 0.99644 0.00532

Our predictions for the best architecture are quite

interesting because we have only 22 false positives

and 66 false negatives. The false positives are not very

concerning as it is better to predict that a benign ap-

plication may be a malware than to miss identifying

a malware application. We tried to understand where

these 66 false negatives come from, and how we can

improve our results. For that, we focus on the differ-

ent malware classes, as the Drebin dataset indicates

the type of malware. Table 4 shows the top classes

the most present in the dataset, with the number of

applications in each family, the accuracy of predic-

tion and the average of the false and true positives

rates. As we can see, the Gappusin class is one of the

top classes that our model has difﬁculties to predict.

Figure 3: Single URL Embedding Workﬂow.

Feature Importance and Deep Learning for Android Malware Detection

459

We analyzed with SHAP (Lundberg and Lee, 2017)

how the predictions of this class are done. We noticed

that it’s mostly the absence of typical features, which

are usually in the malware, that confused our model

to predict it malware. This class of malware is very

similar to the benign class.

Table 4: Malware Families of Drebin Dataset.

Family Apps Accuracy FP TP

FakeInstaller 104 0.98 0.03 0.97

Plankton 74 0.99 0.04 0.96

Opfake 64 0.95 0.07 0.93

Gappusin 12 0.25 0.68 0.32

...

Then, we analyzed the feature importance of our

deep learning model, to understand what are the main

characteristics of the decision of the model. Figure

5 gives the feature importance represented by SHAP.

In this diagram the highest elements are the ones with

the most inﬂuence on the model. The horizontal lo-

cation (x-axis) of points shows whether the effect of

that location is associated with a higher or lower pre-

diction, the red dots represent a positive inﬂuence and

the blue dots a negative inﬂuence. This means the

more the red dot is on the right and features is on the

higher part, the more the model will predict that the

application is a malware. We can see that the pres-

ence of features like ’com’, or ’getSubscriberid’ im-

plies that the application is more likely to be a mal-

ware. Rather the presence of the features ’android’

or ’android.permission.ACCESS FINE LOCATION’

implies that the application is more likely to be be-

nign.

Figure 5: Feature Importance for Drebin Dataset.

Another interesting criteria is the importance of

each set in the prediction. For that, we sum up the

features of importance for each subset as shown in

Figure 6. We can conclude that the permission subset

is by far the most important subset to predict if an

application is a malware in Drebin dataset.

Figure 6: Subset Importance for Drebin Dataset.

Finally, Table 5 compares the different measures

from other related work that worked exclusively with

the Drebin dataset. And we can see that our method

and that of (Li et al., 2018), both use neural networks,

achieve the best results. This table compares differ-

ent metrics, features, the algorithm used and a brief

description of their contribution.

4.2.2 AndroZoo

We also worked with the AndroZoo dataset, and we

used 27,410 (70%) apps for the training set, 5,873

(15%) apps for the test set and 5,873 (15%) for the

validation set. The training and test set was com-

posed of 32.9% of malware. We trained a neural net-

work with an input layer, followed by two 256 cells

dense layers, and a softmax layer. Unlike Drebin’s

dataset, we extracted ourselves the features of the

APKs, which can induce a slight difference in the re-

sults. Moreover, we extracted the additional feature

”Suspicious action” which is not present in Drebin.

With AndroZoo dataset, the best accuracy reached

is 97.7%, which is indeed very promising with feature

importance. We see that feature selection is really ef-

fective on this new dataset, because with substantially

fewer features, the network manages to gain in each

test metric as shown in Table 6. Moreover, the com-

puting time of training by selecting only the most im-

portant features is signiﬁcant.

With Androzoo the predictions are interesting be-

cause we have only 65 false positives (which repre-

sents 3.3% of FPR against 4.2% with Drebin dataset)

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

460

Table 5: Comparison Table of Published Works with Drebin Dataset.

Reference Measures Features Algorithm Contribution

(Arp et al., 2014) Acc: 94% S1, S2, S3, S4, S5, S6, S7, S8 SVM Online and explainable malware

detection

(Li et al., 2018)

Prec: 97.15%

Recall: 94.18%

F1: 95.64%

S2, S6, S5, S7 DNN Automatic detection engine to

detect malware families

(Shiqi et al., 2018) Acc: 95.7% S5, S7 DBN Combination with image texture

analysis for malware detection

Our method

Acc: 99.31%

Recall: 99.46%

F1: 99.64%

S1, S2, S3 , S4, S5, S6, S7, S8 DNN Feature grouping and feature se-

lection

Table 6: Results on AndroZoo Dataset.

Model Accuracy F1 FNR

Best architecture 0.97701 0.98288 0.01776

and 70 false negatives (which corresponds to 1.77%

of FNR against 0.53% with Drebin dataset).

In Figure 7, the most important feature families

are presented, and we can see that the added feature

(Suspicious actions) has the most important weight,

seconded by the permissions, while it is the permis-

sion set which has the heaviest weight with Drebin

dataset. This probably means that we could signiﬁ-

cantly increase the results of the ﬁrst model (Drebin

dataset) if the ”Suspicious actions” features have been

added.

Figure 7: Subset Importance for AnrdoZoo Dataset.

To analyse the feature importance of the deep

learning model fed by AndroZoo dataset, we gener-

ated a SHAP diagram that shows the feature impor-

tance. We can see in Figure 8 the red dots that indi-

cate how much the feature is present, and the blue dot

means the contrary, and as for the previous SHAP di-

agram, the further the dot is on the right the more this

feature is likely to represent a malware, and on the

left benign. Thus we can see that the presence of fea-

tures ’READ PHONE STATE’ or ’com’ implies that

the application is more likely to be a malware. And

the presence of the feature ’RecyclerView’ indicates

that the application is more likely to be benign.

Figure 8: Feature Importance for AndroZoo Dataset.

During the experimentation phase, the hardware

characteristics used are the following for the training

of the models without the feature selection: Processor

Intel(R) Core(TM) i3-10100F CPU 3.60 GHz, 16 Gb

RAM, GPU NVIDIA GeForce GTX 1650 SUPER.

And for the training of the models with the features

selection, the hardware characteristics used are: Pro-

cessor Intel(R) Xeon(R) CPU E5-2678 v3 2.50 GHz,

12 Gb RAM, GPU.

5 CONCLUSIONS

To conclude this study, our work contributes to the

research ﬁeld of malware detection for Android ap-

plication by improving the detection rate. We based

our work on the research paper of Drebin (Arp et al.,

2014), and we achieved 99.31% of accuracy, superior

Feature Importance and Deep Learning for Android Malware Detection

461

than the highest rate with exclusively the same dataset

from other related work. In addition, we extended

our working dataset with more recent data extracted

from AndroZoo APKs, and we improved the accu-

racy by using deep learning techniques and by the ex-

traction of multiple and additional features from byte-

code and the AndroidManifest.xml ﬁle. Our method-

ology has proven to be effective with an accuracy of

nearly 97.7% in detecting recent Android malware by

binary classiﬁcation. A dataset consisting of features

extracted from nearly 80,000 recent applications with

about 30,000 malware will be made available on the

Internet, as well as the script to extract these features

from a raw AndroZoo dataset.

Different areas of improvement can be studied,

such as optimizing hyperparameters, exploiting a

greater mass of applications from the AndroZoo

dataset, and extending the extracted features from

bytecode to improve the model. Ongoing work on

multi-class classiﬁcation to better categorize Android

malware families is actually carried out. It is also in-

teresting to study the cases of APK predicted as false

positives, to understand why they were tagged as mal-

ware. Manual reverse engineering techniques could

eventually reveal unknown attacks that were not de-

tected by classical antivirus.

REFERENCES

Allix, K., Bissyand and, T., F., Klein, J., and Le Traon, Y.

(2016). AndroZoo: Collecting Millions of Android

Apps for the Research Community. In Proceedings of

the 13th International Conference on Mining Software

Repositories, pages 468–471, New York, NY, USA.

Arp, D., Spreitzenbarth, M., Hubner, M., Gascon, H.,

Rieck, K., and Siemens, C. (2014). Drebin: Effec-

tive and explainable detection of Android malware in

your pocket. In Network and Distributed System Secu-

rity Symposium, volume 14, pages 23–26, San Diego,

California, USA.

Backes, M. and Nauman, M. (2017). Luna: Quantifying

and leveraging uncertainty in Android malware analy-

sis through Bayesian machine learning. In IEEE Euro-

pean Symposium on Security and Privacy (EuroS P),

pages 204–217, Paris, France.

Dong, Y. (2017). Android malware prediction by permis-

sion analysis and data mining. In PhD, University of

Michigan-Dearborn.

Ganesh, M., Pednekar, P., Prabhuswamy, P., Sreedharan, D.,

Park, Y., and Jeon, H. (2017). CNN-based Android

malware detection. San Diego, CA, USA.

Hou, S., Saas, A., Ye, Y., and Chen, L. (2016). Droiddelver:

An Android malware detection system using deep be-

lief network based on api call blocks. In Interna-

tional Conference on Web-Age Information Manage-

ment, volume 9998, pages 54–66, Nanchang, China.

Kapratwar, A., Di Troia, F., and Stamp, M. (2017). Static

and dynamic analysis of Android malware. In Inter-

national Conference on Information Systems Security

and Privacy, pages 653–662, Porto, Portugal.

Kim, T., Kang, B., Rho, M., Sezer, S., and Im, E. G.

(2019). A multimodal deep learning method for An-

droid malware detection using various features. IEEE

Transactions on Information Forensics and Security,

14(3):773–788.

Li, D., Wang, Z., and Xue, Y. (2018). Fine-grained Android

malware detection based on deep learning. In IEEE

Conference on Communications and Network Security

(CNS), Beijing, China.

Liu, K., Xu, S., Xu, G., Zhang, M., Sun, D., and Liu, H.

(2020). A Review of Android Malware Detection Ap-

proaches Based on Machine Learning. IEEE Access,

8:124579–124607.

Lundberg, S. and Lee, S.-I. (2017). A uniﬁed approach to

interpreting model predictions. Seattle, WA.

Naway, A. and Li, Y. (2018). A Review on The Use of

Deep Learning in Android Malware Detection. In In-

ternational Journal of Computer Science and Mobile

Computing, volume 7, pages 42–58.

Nix, R. and Zhang, J. (2017). Classiﬁcation of An-

droid apps and malware using deep neural networks.

In 2017 International Joint Conference on Neural

Networks (IJCNN), pages 1871–1878, Anchorage,

Alaska, USA.

Pektas¸, Abdurrahman, and Acarman, T. (2020). Deep learn-

ing for effective Android malware detection using API

call graph embeddings. Soft Computing, 24(2):1027–

1043.

Shiqi, L., Shengwei, T., Long, Y., Jiong, Y., and Hua, S.

(2018). Android malicious code classiﬁcation using

deep belief network. KSII Transactions on Internet

and Information Systems, 12(1).

Sood, G. (2017). virustotal: R Client for the virustotal API.

R package version 0.2.1.

StatCounter (June 2021). Operating system market share

worldwide”. https://gs.statcounter.com/os-market-

share.

Wang, W., Zhao, M., Gao, Z., Xu, G., Xian, H., Li, Y., and

Zhang, X. (2019). Constructing Features for Detect-

ing Android Malicious Applications: Issues, Taxon-

omy and Directions. volume 7, pages 67602–67631.

Wu, D.-J., Mao, C.-H., Wei, T.-E., Lee, H.-M., and Wu,

K.-P. (2012). Droidmat: Android malware detection

through manifest and API calls tracing. In Seventh

Asia Joint Conference on Information Security, pages

62–69, Tokyo, Japan.

Yuan, H., Yang, Z., Chen, X., Li, Y., and Liu, W. (2018).

URL2Vec: URL modeling with character embeddings

for fast and accurate phishing website detection. pages

265–272, Melbourne, Australia.

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

462
