A Trusted Data Sharing Environment based on FAIR Principles and

Distributed Process Execution

Marcel Klötgen

1,2 a

, Florian Lauf

, Sebastian Stäubert

1,3 c

, Sven Meister

and Danny Ammon

1,4 e

SMITH consortium of the German Medical Informatics Initiative, Germany

Fraunhofer Institute for Software and Systems Engineering ISST, Dortmund, Germany

Institute for Medical Informatics, Statistics and Epidemiology, Leipzig University, Leipzig, Germany

Data Integration Center, Jena University Hospital, Jena, Germany

Faculty of Health/School of Medicine, Witten/Herdecke University, Witten, Germany

danny.ammon@med.uni-jena.de

Keywords: Health Information Interoperability, Workflow, Data Science, Modeling Information System Architecture.

Abstract: Provision and usage of distributed secondary-use data for medical research requires the implementation of a

distributed data use & access process and several sub-processes. The SMITH Service Platform (SSP) manages

process-based interactions with several Data Integration Centers (DIC), each being responsible for the

management and provision of suitable data sets in the context of a data use project. A trusted data sharing

environment is specified based on the implementation of Trusted Connectors as specified by the International

Data Spaces (IDS) Reference Architecture Model. Thus, a distributed data delivery sub-process enforces data

sovereignty aspects between all involved parties. In the future, a solidification of the concepts and a further

implementation of the trusted data sharing environment should be addressed.

1 INTRODUCTION

1.1 Background

In Germany, the need and demand for a rapid

development of new and appropriate treatment

methods, pharmaceuticals and technologies for

healthcare is increasingly important. Reusing, linking

and analyzing healthcare-related data from different

sources leverages the potential for the

implementation of secondary-use purposes and

medical research (Celi et al. 2013). Especially,

processing extensive real world data sets enables a

well-aimed validation of scientific hypotheses,

optimization of artificial intelligence applications, or

the derivation and recognition of influences and

correlations. Yet, several requirements regarding data

security and protection, regulatory and legal aspects,

https://orcid.org/0000-0003-4109-8641

https://orcid.org/0000-0003-0844-3722

https://orcid.org/0000-0002-7221-7415

https://orcid.org/0000-0003-0522-986X

https://orcid.org/0000-0001-8960-7316

and interoperability must be met for the provision of

data in the context of different secondary-use

purposes.

Smart Medical Information Technology for

Healthcare (SMITH) is one of four funded consortia

of the Medical Informatics Initiative (MII) (Löffler et

al.), (Semler et al. 2018), specifically striving to

optimize and interlock primary patient care and

secondary-use of data for medical research based on

the joint collaboration of universities, university

hospitals and IT-companies in Germany. SMITH

specifies a reference architecture for its distributed

Data Integration Centers (DIC) to be established at all

seven participating sites, thus ensuring a modular

architecture for processing and providing medical

data from consenting patients (Winter et al. 2018) in

an interoperable core data set format (Ammon et al.

2019). Cross-site use cases and operations involving

Klötgen, M., Lauf, F., Stäubert, S., Meister, S. and Ammon, D.

A Trusted Data Sharing Environment based on FAIR Principles and Distributed Process Execution.

DOI: 10.5220/0010869800003123

In Proceedings of the 15th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2022) - Volume 5: HEALTHINF, pages 583-589

ISBN: 978-989-758-552-4; ISSN: 2184-4305

583

several DICs, such as feasibility queries, data use

project management and data delivery, are supported

through interactions with the SMITH Service

Platform (SSP) and its standards-based interfaces,

allowing for a cross-site and centralized process

management and identical application of quality

principles. Yet, the concepts incorporate a low degree

of data sovereignty aspects, especially regarding

delivered data sets.

The International Data Spaces (IDS) (Otto et al.

2018) represent a rising concept for data spaces

especially addressed in Europe and steadily

developed by the International Data Spaces

Association (IDSA), striving to anchor its concepts

and architecture in European digitization strategies

such as Gaia-X (Cinzia Capiello et al. 2020). IDS

combines standards and technologies to create a data-

driven data economy while ensuring data sovereignty

(IDSA 2019). IDS connectors are gateway tools for

accessing such data spaces and are available in

different implementations (e.g., Trusted Connector or

Dataspace Connector). Different domains constitute

different IDS verticalizations (e.g., industrial data

space, agriculture data space, or medical data space).

To foster the medical domain, the project

PanDa@IDS realizes the concept of data donations

using IDS connectors (Fraunhofer Institute for

Software und Systems Engineering ISST 2021). By

embedding the Trusted Connector in SMITH,

scientists can retrieve data sets via IDS technology,

thus incorporating domain-specific negotiation

processes missing from the IDS-based technology.

1.2 Requirements

Sharing healthcare-related data for secondary-use

purposes raises great potential, yet requires

fundamental constraints at the same time. Scientists

require the ability to retrieve and process large

amounts of distributed primary care data from

different DICs. This implies the specification of

cohorts and data items to be retrieved, such as data on

the prevalence of cardiac diseases among a specific

age-class, the submission and evaluation of a

common data usage proposal form, and the

conclusion of contracts between all parties. In order

to enforce data sovereignty aspects, such as a limited

utilization period of the retrieved data sets, scientists

must employ trusted applications or environments for

accessing or analyzing the data sets, e.g. a web

interface implementing structured views and

traversing operations for the data. When the contract

becomes invalid, the trusted application should

prevent access to the data sets.

Several requirements are realized by SMITH and

PanDa@IDS, addressing FAIR data principles

(Wilkinson et al. 2016) with the MII Core Data Set

based on HL7 FHIR (Ammon et al. 2019) and legal

and regulatory aspects of data sharing including

anonymization or pseudonymization. Findability (the

capability to easily find data and metadata),

interoperability (the capability of data sets to integrate

with one another and to be used for analysis,

processing and storage) and reusability (the capability

of data sets to be replicated or combined in different

environments) of data sets and metadata according to

the FAIR principles are ensured by the use of the MII

Core Data Set for data management tasks at each

DIC, the use of FHIR Search as a compatible query

language incorporating the core data set and the Data

Use & Access macro-process described in chapter

3.1. Accessibility (the capability of data sets to be

accessed by users) is ensured by the setup of the data

sharing environment, including the use of open

interfaces based on international standards, and the

provision of user interfaces through the SSP.

Therefore, the data sharing environment must

incorporate the following additional requirements:

• Scalability: The data sharing environment

must be able to integrate different actors and

systems and therefore support different

requirements and actions of its users, such as

different legal frameworks or ethical

assumptions.

• Process Interoperability: The data sharing

environment must support the integration of

different systems for the visualization and

execution of distributed tasks based on a

common process and representation.

• Information Interoperability: The data

sharing environment must provide its usage

and project management data in a common

interoperable representation.

• Trusted Data Sharing: The involved

systems and components must provide a

trusted environment for data sharing based on

technical measures, such as certification or

authentication of components and secure data

transfer.

• Trusted Data Usage: The involved systems

and components must provide a trusted

environment for data utilization in the context

of a data use project, technically managing

access and utilization according to the

contract.

HEALTHINF 2022 - 15th International Conference on Health Informatics

584

This work focuses on the definition of an

architecture, which is able to address the

aforementioned requirements for a trusted data

sharing environment, thus leveraging data

sovereignty concepts in the context of medical

research. Additionally, a concept for distributed

standards-based process execution is presented.

2 STATE OF THE ART

Several recent projects and organizations have

produced results and inspiration for the idea of a

trusted data sharing environment. The LIFE Research

Center for Civilization Diseases acts as a data

provider for secondary-use data gained from patient

care of the university hospital Leipzig. The LIFE data

sharing approach incorporates the OAIS reference

model (Kirsten et al. 2017) and covers the needs for

organizational and IT infrastructure for data sharing.

LIFE is able to provide data sets in the context of a

data use project, yet lacks the capabilities to

coordinate cross-organizational data provision with

different data providers and especially enforce the

contracted usage policies for delivered data.

The IDS Reference Architecture Model defines a

common infrastructure for data sharing scenarios

based on standardized interfaces and self-descriptive

services, but has not yet achieved the desired maturity

level realizing the requirements of secondary-use data

sharing of the healthcare domain, such as the

integration of existing processes (IDSA 2019).

Usage control enforces constraints on the usage of

data beyond its provision, incorporating definitions

for authorization, obligations, and conditions (Park

and Sandhu 2004). An implementation for distributed

systems is defined in (Pretschner et al. 2006). These

principles are relevant for subsequent enforcement of

usage control based on negotiation and distribution

methods described in the following sections.

3 CONCEPT

3.1 Distributed Process Management

The delivery of data is part of a centrally managed,

scalable and distributed macro-process, addressing

several regulatory and administrative aspects of the

management of cross-site data use projects. This

macro-process is specified by the MII as Data Use &

Access (DUA) and consists of different tasks,

grouped into several phases:

1. Data Usage Proposal Provision Phase: A

scientist describes the planned data use

project and provides all necessary

information for the retrieval of the desired

data based on a common data use proposal

form to selected DICs.

2. Data Usage Proposal Evaluation Phase:

The Use & Access Committees (UAC) of

the selected DICs receive and evaluate the

provided data usage proposal individually,

based on individually relevant formal,

regulatory and content-related aspects.

3. Contracting Phase: The scientist and

project management actors of all

participating DICs agree on the rules and

regulations determining the usage of the

data sets and sign a common contract.

4. Data Preparation and Delivery Phase:

Once the contracting phase has been

successful, the DICs process and provide

anonymized or pseudonymized data sets

meeting the data use project criteria

individually, thus implementing the

required security requirements. The

involved scientists retrieve the provided

data sets for utilization.

5. Exploitation and Closing Phase: At the

end of the data use project, a closing phase

begins, allowing scientists and DICs to

exchange relevant project results.

These phases of the distributed DUA macro-

process involve several tasks to be executed by

different roles, organizations or systems. The macro-

process is managed centrally in order to maintain

control of the overall process state and execution,

while the assignment of tasks to different

organizations, systems or roles realizes task

distribution. Data delivery is part of the data

preparation and delivery phase and implemented as a

distributed sub-process.

3.2 Data Space Transactions

Trust between two interacting parties can be achieved

through the involvement of a Trusted Third Party

(TTP), which is trusted by the two parties each. The

TTP is responsible for performing sensitive tasks,

such as the management and merge of distributed data

sets or the authorization of data delivery and

utilization. The provision and retrieval of distributed

data sets involve the following actors according to the

IDS Reference Architecture Model (IDSA 2019):

A Trusted Data Sharing Environment based on FAIR Principles and Distributed Process Execution

585

• Data Owner: The DICs managing and

processing data for primary and

secondary use purposes according to

DUA.

• Data User: The scientists utilizing data

sets in the context of data use projects

based on previously agreed contracts

according to DUA.

• Data Provider: A component of the

DIC, responsible for and implementing

the actual delivery of processed data sets

in the context of a data use project.

• Data Consumer: A component operated

by the Data User actor, implementing a

secure environment and reception point

for data sets from multiple Data Provider

actors in the context of a data use project.

Aiming at a secure and reliable cross-site retrieval

and usage of distributed data sets, the TTP system is

partially implemented by the Data Consumer

component. Relocation of TTP functionality of the

data delivery sub-process allows for the central

execution of several services and operations without

the need to involve another substitutional system. The

relocated tasks of the data delivery sub-process to the

Data Consumer include the merge of previously

distributed data sets and authorization of data

processing operations. The Data Consumer thus

represents a fully integrated system extension and

strengthens data sovereignty and usage control by

providing a secure environment for data utilization

according to the contracts, thus addressing the

requirements trusted data sharing and trusted data

usage by creating a secure and closed data space.

As represented in figure 1, the DUA macro-

process and its process model and instances are

managed centrally by a Business Process Engine.

Process instances are mapped to a representation that

ensures interoperability with distributed actors and

service providers for distributed process execution,

thus ensuring the requirements scalability and

process interoperability. Distributed sub-processes

are addressed as tasks within the macro-process,

allowing for individual implementations of task

execution workflows by each Data Provider based on

individually relevant regulations or demands. The

Data Providers now act as Task Performers with their

own workflow management. Therefore, all required

input and output parameters must be provided with

the tasks, along with assignment and orchestration

data for the notification and activation of responsible

actors and systems. The input parameters are used for

displaying or processing of information during the

execution of individual sub-processes. Once the

distributed execution of a task is complete, the results

are registered as output parameters, along with a

resulting status of the task for process management.

Data delivery is represented as a service task,

which is added on demand (e.g. functionality of a user

interface) for a distributed implementation of sub-

processes. All input parameters of the data delivery

task must include references to the data use project or

the prepared data sets, identification or recipient

information of the Data Consumer, and metadata of

the data use project, including relevant contracting

parameters.

Figure 1: Distributed process management.

HEALTHINF 2022 - 15th International Conference on Health Informatics

586

Figure 2: Components of the data sharing environment.

3.3 The Data Delivery Sub-Process

The data delivery sub-process is comprised of several

service tasks to be performed by the Data Provider

and the Data Consumer, respectively. This allows for

an integration of the Data Consumer in the distributed

project management through the implementation of a

secure data space environment, making it a central

actor of the DUA process. The tasks of the Data

Providers include the retrieval of the data delivery

parameters provided by the task of the macro-process,

the retrieval of prepared data sets for data delivery,

the creation of policies representing the contract

parameters, and the sending these data sets and

policies. The Data Consumer receives, stores and

merges the data sets of a data use project and activates

the provided policies. All operations performed on

the retrieved data sets are authorized through policy

enforcement, representing and enacting the contract

parameters. Policies are created by the Data Provider

based on the task input parameters such as the data

use project metadata, and delivered to the Data

Consumer with the provided data sets.

4 IMPLEMENTATION

As depicted in figure 2, the SSP supports the

execution and documentation of all DUA macro-

process tasks of the involved actors through a

dedicated web interface, the SMITH Marketplace.

When the requested data sets are available, the

involved scientist receives a task and uses the SSP

web interface to authenticate and start the delivery of

data sets from all involved DICs based on the

distributed process management concept. The Data

Consumer application of the scientist receives and

processes the data sets, allowing supported

interactions with the data by the scientist, such as

viewing or accessing (e.g., the scientist can use the

Data Consumer’s web interface to view the received

data sets).

The DUA macro-process is managed by the SSP

and its integrated Business Process Engine (BPE). As

shown in figure 2 and in order to ensure

interoperability with distributed actors and systems

for task execution, each instance of a DUA macro-

process is synchronously provided according to the

IHE Cross-Enterprise Workflow Document (XDW)

profile based on a central Cross-Enterprise Document

Sharing (XDS) Affinity Domain, thus implementing

the requirements scalability and process

interoperability. The XDW tasks are routed to their

designated performers using the name and

notificationRecipient attributes. The Data Provider

and Data Consumer components are implemented as

IDS Connectors based on the Trusted Connector

reference implementation (Schütte et al.) and

extended to support the distributed data delivery sub-

process. The data sets to be delivered are retrieved

from the XDS-based data source of a DIC, and

additional XACML policies are created and

generated, representing the contract parameters such

as duration of the data use project. In order to fulfil

the requirements trusted data sharing and trusted

data usage, the Data Consumer additionally

implements the merge of received data sets of a data

use project and the enforcement of the attached

XACML policies through a Policy Enforcement Point

(PEP). The User Interface (UI) component

implements possible usage scenarios of the data sets

representing the data use project.

5 DISCUSSION

A basic range of functions of the envisioned SMITH

infrastructure, including a first iteration of the DIC

architecture and the distributed DUA macro-process,

has been developed and is envisioned to be

productive at the end of 2021. The IDS-based data

delivery sub-process is not part of the current setup,

yet has been developed and integrated as a

demonstrator. Using a set of test data, the

demonstrator proves the ability to perform all phases

A Trusted Data Sharing Environment based on FAIR Principles and Distributed Process Execution

587

of the DUA process with all actors, including the

transfer and provision of data sets and usage policies

representing crucial contracting parameters. The

demonstrator also contains a basic web interface of

the Data Consumer, which is capable of displaying

the retrieved data and exemplifies the enforcement of

policy rules. Thus, the requirements addressing

scalability, process interoperability and information

interoperability could be met. The requirements of

trusted data sharing and trusted data usage could

only be met partially with the need to further

implement certain aspects, such as a certification of

involved components, proper authorization of data

retrieval by the Data Provider, and the

implementation of a user interface or API of the Data

Consumer, allowing the required flexible and

authorized use of received data sets.

Limitations of the current system affect the

specification and selection of desired data based on

the core data set definition. Thus, only data items

previously defined in the MII Core Data Set can be

retrieved, such as observation resources encoded as

ICD. Another major limitation is attributed to the

implementation of data interaction mechanisms of the

Data Consumer. Utilization and processing of

retrieved data sets will be limited to the Data

Consumer’s API or user interface, such as viewing

the data sets in the case of the demonstrator. It is

therefore relevant to find a balanced solution based on

future research and requirements analyses

incorporating the needs of researchers and citizens

equally, which addresses data sovereignty as well as

utilization requirements, e.g. a limited FHIR-based

API.

The context of data usage, organizational

dependencies and regular constraints according to

EU’s General Data Protection Regulation (GDPR) or

even regional laws determines the application of data

protection measures. Thus, each DIC is responsible

for the appropriate application of data protection

measures before providing data sets. Data Use

Projects involving several DICs usually provide fully

anonymized data sets based on the application of

Privacy Preserving Record Linkage (PPRL) methods

implemented by additional components (the FHIR

Transfer Services) of a DIC in compliance with

GDPR, while some regional laws allow the provision

of data sets containing personal information within

the same organization.

Future steps will address user validation activities

as well as the implementation of additional

requirements and possible operation of Data Provider

and Data Consumer components by the SMITH DICs

until 2022.

6 CONCLUSION

The union of a centrally managed, distributed DUA

process through the central SSP with distributed IDS

components in the DIC infrastructure and relocation

of TTP functionality to trusted Data Consumers as a

part of a data delivery sub-process addresses several

current requirements of data sharing. The concept

applies and realizes several data sovereignty aspects

to distributed secondary-use data for medical

research, addressing the technical enforcement of a

data use contract on joined data sets, and thus creates

a trusted data sharing and usage environment. Future

steps should address the solidification of the concepts

within SMITH and the implementation of further

aspects of the trusted data sharing and usage

environment.

ACKNOWLEDGEMENTS

This publication of the SMITH consortium was

supported by the German Federal Ministry of

Education and Research, grant number 01ZZ1803J,

and the Fraunhofer Internal Programs under Grant

No. Anti-Corona 840239. The research is based on

the results of several working groups of the Medical

Informatics Initiative (MII), the SMITH consortium

and the PanDa@IDS consortium.

REFERENCES

Ammon, D., Bietenbeck, A., Boeker, M., Ganslandt, T.,

Heckmann, S., Heitmann, K., Sax, U., Schepers, J.,

Semler, S., Thun, S. & Zautke, A. (2019). Der

Kerndatensatz der Medizininformatik-Initiative.

Interoperable Spezifikation am Beispiel der

Laborbefunde mittels LOINC und FHIR. mdi – Forum

der Medizin, Dokumentation und Medizin-Informatik

(21), 113–117.

Celi, L. A., Mark, R. G., Stone, D. J. & Montgomery, R. A.

(2013). “Big Data” in the Intensive Care Unit. Closing

the Data Loop. Am J Respir Crit Care Med (187(11)),

1157–1160. doi:10.1164/rccm.201212-2311ED

Cinzia Capiello, Avigdor Gal, Matthias Jarke, Jakob Rehof

& Cinzia Cappiello. (2020). Data Ecosystems:

Sovereign Data Exchange among Organizations

(Dagstuhl Seminar 19391). Dagstuhl Reports 9 (9), 66–

134. https://drops.dagstuhl.de/opus/volltexte/2020/11

845.

Fraunhofer Institute for Software & Systems Engineering

ISST. (2021). PanDa@IDS: Pandemic-related data

donation based on data sover-eignty principles of the

Medical Data Space. Dortmund. Zugegriffen: 10. Mai

HEALTHINF 2022 - 15th International Conference on Health Informatics

588

2021. https://www.isst.fraunhofer.de/en/business-

units/healthcare/projects/PanDaIDS.html.

IDSA. (2019). Reference Architecture Model: Version 3.0 |

April 2019. Berlin. Zugegriffen: 10. Mai 2021.

https://internationaldataspaces.org/use/reference-

architecture/.

Kirsten, T., Wagner, J., Kiel, A., Rühle, M. & Löffler, M.

(2017). Selecting, Packaging, and Granting Access for

Sharing Study Data. Experiences and Recent Software

Developments in the LIFE Study. INFORMATIK 2017

2017.

Löffler, M. Univ.-Prof. Dr. med. habil., Scherag, A. Univ.-

Prof. Dr. rer. physiol. & Marx, G. Univ.-Prof. Dr. med.

(Hrsg.). Smart Medical Information Technology for

Healthcare. https://www.smith.care/konsortium/.

Zugegriffen: 25. März 2020.

Otto, B., Hompel, M. ten & Wrobel, S. (2018). Industrial

Data Space. In R. Neugebauer (Hrsg.), Digitalisierung

(Bd. 51, S. 113–133). Berlin, Heidelberg: Springer

Berlin Heidelberg.

Park, J. & Sandhu, R. (2004). The UCON ABC usage

control model. ACM Transactions on Information and

System Security (TISSEC) 7, 128–174.

doi:10.1145/984334.984339

Pretschner, A., Hilty, M. & Basin, D. (2006). Distributed

usage control. Communications of the ACM 49.

doi:10.1145/1151030.1151053

Schütte, J., Brost, G. & Wessel, S. Der Trusted Connector

im Industrial Data Space. Garching.

https://www.aisec.fraunhofer.de/content/dam/aisec/Do

kumente/Publikationen/Studien_TechReports/deutsch/

IDS-Paper_Datensouveraenitaet.pdf.

Semler, S. C., Wissing, F. & Heyder, R. (2018). German

Medical Informatics Initiative. A National Approach to

Integrating Health Data from Patient Care and Medical

Research. Methods of Information in Medicine (57).

doi:10.3414/ME18-03-0003

Wilkinson, M., Dumontier, M., Aalbersberg, I. J., Appleton,

G., Axton, M., Baak, A., Blomberg, N., Boiten, J.-W.,

da Silva Santos, L., Bourne, P., Bouwman, J., Brookes,

A., Clark, T., Crosas, M., Dillo, I., Dumon, O.,

Edmunds, S., Evelo, C., Finkers, R., Gonzalez-Beltran,

A., Gray, A., Groth, P., Goble, C., Grethe, J. S., Heringa,

J., Hoen, P., Hooft, R., Kuhn, T., Kok, R., Kok, Joost,

Lusher, Scott J., Martone, M. E., Mons, A., Packer, A.

L., Persson, B., Rocca-Serra, P., Roos, M., van Schaik,

R., Sansone, S.-A., Schultes, E., Sengstag, T., Slater, T.,

Strawn, G., Swertz, M. A., Thompson, M., van der Lei,

J., van Mulligen, E., Velterop, J., Waagmeester, A.,

Wittenburg, P., Wolstencroft, K., Zhao, J. & Mons, B.

(2016). The FAIR Guiding Principles for scientific data

management and stewardship. Scientific Data.

Winter, A., Stäubert, S., Ammon, D., Aiche, S., Beyan, O.,

Bischoff, V., Daumke, P., Decker, S., Funkat, G.,

Gewehr, J. E., Greiff, A. de, Haferkamp, S., Hahn, U.,

Henkel, A., Kirsten, T., Klöss, T., Lippert, J., Löbe, M.,

Lowitsch, V., Maassen, O., Maschmann, J., Meister, S.,

Mikolajczyk, R., Nüchter, M., Pletz, M. W., Rahm, E.,

Riedel, M., Saleh, K., Schuppert, A., Smers, S.,

Stollenwerk, A., Uhlig, S., Wendt, T., Zenker, S., Fleig,

W., Marx, G., Scherag, A. & Löffler, M. (2018). Smart

Medical Information Technology for Healthcare

(SMITH). Data Integration based on Interoperability

Standards. Methods of Information in Medicine (57).

doi:10.3414/ME18-02-0004

A Trusted Data Sharing Environment based on FAIR Principles and Distributed Process Execution

589
