Network Intrusion Detection: A Comprehensive Analysis of

CIC-IDS2017

Arnaud Rosay

1 a

, Eloïse Cheval

2 b

, Florent Carlier

3 c

and Pascal Leroux

3 d

STMicroelectronics, Rue Pierre-Félix Delarue, Le Mans, France

Polytech Nantes, Nantes University, Rue Christian Pauc, Nantes, France

CREN, Le Mans University, Avenue Olivier Messiaen, Le Mans, France

Keywords:

Network Intrusion Detection, CIC-IDS2017, CSE-CIC-IDS2018, CICFlowMeter, LycoSTand, LYCOS-

IDS2017, Machine Learning.

Abstract:

With an ever increasing number of connected devices, network intrusion detection is more important than

ever. Over the past few decades, several datasets were created to address this security issue. Analysis of

older datasets, such as KDD-Cup99 and NSL-KDD, uncovered problems, paving the way for newer datasets

that solved the identiﬁed issues. Among the recent datasets for network intrusion detection, CIC-IDS2017

is now widely used. It presents the advantage of being available as raw data and as ﬂow-based features in

CSV ﬁles. In this paper, we analyze this dataset in detail and report several problems we discovered in the

ﬂows extracted from the network packets. To address these issues, we propose a new feature extraction tool

called LycoSTand, available as open source. We create LYCOS-IDS2017 dataset by extracting features from

CIC-IDS2017 raw data ﬁles. The performance comparison between the original and the new datasets shows

signiﬁcant improvements for all machine learning algorithms we tested. Beyond the improvements on CIC-

IDS2017, we discuss other datasets that are affected by the same problems and for which LycoSTand could be

used to generate improved network intrusion detection datasets.

1 INTRODUCTION

We live in a world where interactions with connected

devices are ubiquitous. Computers, smartphones, IoT,

connected cars are used every day. But this connected

world is under threat from cyberattacks making net-

work security more important than ever. The impacts

of computer network intrusions can be severe. This is

typically the case when healthcare infrastructures are

blocked or when hackers remotely take control of a

connected vehicle.

Such cyberattacks can be prevented by the use

of Network Intrusion Detection Systems (NIDS). To

study network intrusion detection, KDD-Cup99 (Lee

et al., 1999) was one of the earliest publicly avail-

able datasets, released in 1999, and has been widely

used. An initial review of this dataset (McHugh,

2000) has put in light some issues that were fur-

ther analyzed (Tavallaee et al., 2009). A derived

https://orcid.org/0000-0001-5937-5331

https://orcid.org/0000-0003-2961-4973

https://orcid.org/0000-0003-0314-3667

https://orcid.org/0000-0002-4447-7244

dataset referred to as NSL-KDD addresses some of

the shortcomings of KDD-Cup99. Subsequently, sev-

eral datasets were published by the Canadian In-

stitute for Cybersecurity (CIC), University of New

Brunswick, Canada, such as CIC-IDS2017 (Cana-

dian Institute for Cybersecurity, 2017b), CSE-CIC-

IDS2018 and CIC-DDOS2019 (Sharafaldin et al.,

2019). These datasets present the advantage of being

available in two forms: a record of Ethernet frames

in Packet CAPture (PCAP) ﬁles and a list of net-

work ﬂow characteristics extracted from the Ethernet

frames in CSV ﬁles.

Our main contributions consist of four parts. First,

we present an in-depth analysis of CIC-IDS2017

showing some inherent issues in its CSV ﬁles. Five

classes of problems were identiﬁed: feature dupli-

cation, feature calculation errors, erroneous proto-

col detection, inconsistent TCP termination ﬂows and

doubts on labels. Second, since this dataset is not

provided with the tool to put labels, we propose a

new network ﬂow extractor called LycoSTand work-

ing with a labelling solution speciﬁc to this dataset.

LycoSTand solves all the issues discovered during

Rosay, A., Cheval, E., Carlier, F. and Leroux, P.

Network Intrusion Detection: A Comprehensive Analysis of CIC-IDS2017.

DOI: 10.5220/0010774000003120

In Proceedings of the 8th International Conference on Information Systems Security and Privacy (ICISSP 2022), pages 25-36

ISBN: 978-989-758-553-1; ISSN: 2184-4356

our analysis. CIC-IDS2017 PCAP ﬁles were pro-

cessed with our tools to generate a new dataset called

LYCOS-IDS2017. The tools and the resulting dataset

are publicly available: http://lycos-ids.univ-lemans.

fr/. Then, Machine Learning (ML) algorithms were

used to measure performance of both datasets. We

show that the corrections provided by LycoSTand im-

prove standard metrics for all the tested algorithms.

At last, we considered four other recent datasets based

on the same features extractor as CIC-IDS2017. We

found several artifacts in each showing that they suf-

fer from the problems identiﬁed on CIC-IDS2017.

All these datasets could very likely be enhanced by

using LycoSTand to extract features from available

PCAP ﬁles.

This paper presents in Section 2 works related to

IDS. A comprehensive analysis of CIC-IDS2017 is

provided in Section 3. Section 4 presents our tools

used to create LYCOS-IDS2017, a corrected dataset

detailed in 5. The performance impacts of all the cor-

rection we brought are provided in Section 6. A short

analysis in Section 7 shows that several other CIC

datasets are affected by the issues identiﬁed in this

paper and could beneﬁt from feature extraction with

LycoSTand. Finally, Section 8 concludes this paper

and identiﬁes ideas for future work.

2 RELATED WORK

With the rise of computer networks and the Internet,

many research have been conducted on network in-

trusion detection using different datasets. KDD-Cup

dataset has been used since 1999 and still appears in

recent publications. However, it presents several is-

sues (McHugh, 2000). To enable researchers to in-

vestigate new IDS models, a part of its shortcom-

ings were solved in a new dataset called NSL-KDD

(Tavallaee et al., 2009). This dataset contains selected

records from its predecessor to remove redundant

records and to better balance the size of classes by

difﬁculty level. Although it does not address all prob-

lems of KDD-Cup99, NSL-KDD is a better dataset.

Several other IDS datasets have been created.

University of Twente proposed a dataset (Sperotto

et al., 2009) aiming to be representative of real trafﬁc

and complete from a labelling perspective. UNSW-

NB15 (Moustafa and Slay, 2015) is a simulation-

generated IDS dataset containing modern attacks

grouped into nine different attack families. Although

the tool generating the trafﬁc is based on informa-

tion about real attacks listed in security vulnerability

website (CVE), the simulation may not perfectly re-

ﬂect the network trafﬁc generated by the tools used by

hackers.

Many IDS datasets were reviewed and evaluated

against 11 criteria (Gharib et al., 2016). These

characteristics were used to create CIC-IDS2017

(Sharafaldin et al., 2018), a new dataset released by

the Canadian Institute for Cyber Security (CIC) at

the University of New Brunswick. This dataset con-

tains trafﬁc recorded for 5 days, including normal

trafﬁc and attacks launched by machines running Kali

Linux with its set of penetration testing toolset. CIC-

IDS2017 is now widely used to study performance of

machine learning algorithms in network intrusion de-

tection (Gamage and Samarabandu, 2020; Yang et al.,

2021; Ho et al., 2021; Maseer et al., 2021).

Although CIC-IDS2017 was intended to address

the issues of previous IDS datasets, a very limited

number of study have been conducted to identify po-

tential problems. A detailed analysis of this dataset

(Panigrahi and Borah, 2018) revealed four shortcom-

ings of different importance. CIC-IDS2017 data is

scattered in many ﬁles, meaning that users have to ag-

gregate all ﬁles to use them. This generates a dataset

that is huge and heavy to process. These ﬁrst two

problems are rather common in machine learning and

do not affect performances of intrusion detection. It is

also reported that many samples have missing values

and that classes are highly imbalanced. Another study

(Rosay et al., 2021) identiﬁed that some features ex-

tracted from PCAP ﬁles are poorly computed. One

can expect these issues to impact the performance of

ML algorithms. Other issues covering several aspect

were found (Engelen et al., 2021): attack simulation,

feature extraction, ﬂow construction and labelling.

It should be noted that a vast majority of pub-

lications rely on the CSV ﬁles provided by CIC

to study the performance of machine learning algo-

rithms. Based on the problems mentioned above, it is

natural to wonder whether the ﬁndings remain valid if

the CSV are badly generated.

We propose to go further in the analysis to pro-

vide more insights about the ﬂow construction issue,

to highlight more problems affecting CIC-IDS2017

and to provide our solution as open source software to

generate a corrected dataset from the raw data avail-

able in the PCAP ﬁles of CIC-IDS2017 and some

other dataset released by the CIC. In addition, we pro-

pose a benchmark of machine learning algorithms to

compare CIC-IDS2017 and LYCOS-IDS2017.

3 COMPREHENSIVE ANALYSIS

A ﬁrst step of the analysis consists of understanding

how the dataset was created and its content. Then,

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

in an attempt to reproduce the ﬂow-based features of

CIC-IDS2017 from the PCAP ﬁles, we discovered

several problems both in the original CSV ﬁles and

CICFlowMeter (Canadian Institute for Cybersecurity,

2017a), the tool generating the features.

3.1 CIC-IDS2017 Description

The dataset was recorded on a real network whose

infrastructure is divided into two parts. The ﬁrst one

contains 4 machines launching the attacks towards the

second one containing 10 victim machines. 50 GByte

of raw data in PCAP ﬁles are provided together with

a set of 84 features in CSV ﬁles. Network trafﬁc was

recorded for 5 days, resulting in a total of 2,830,743

instances.

The network trafﬁc is classiﬁed into 15 classes.

One of them corresponds to normal trafﬁc, while the

others 14 are different attacks.

Features were extracted from the PCAP ﬁles with

a tool called CICFlowMeter (formerly ISCXFlowMe-

ter) (Canadian Institute for Cybersecurity, 2017a;

Draper-Gil. et al., 2016; Lashkari et al., 2017). The

source code of this tool is available. The tool can gen-

erate up to 84 features related to bidirectional ﬂows.

Forward and backward directions are deﬁned by the

source and destination of the ﬁrst packet of a ﬂow.

Flows are identiﬁed by a source IP and port, a destina-

tion IP and port, and a protocol forming the FlowID.

Some characteristics such as packet length or inter-

arrival time generate statistical features: minimum,

maximum, mean, standard deviation and variance val-

ues in both directions. In a Transmission Control

Protocol (TCP) connection, synchronization (SYN),

acknowledgment (ACK), ﬁnish (FIN) or reset (RST)

ﬂags are used to indicate the status of the connection.

Some other ﬂags like push (PSH) or urgent (URG)

provide additional useful information. Statistics on

these ﬂags are used as features of the dataset. Flow

duration is measured between SYN and FIN ﬂags for

most TCP connections. In case of User Datagram

Protocol (UDP), the end of a ﬂow is a timeout, as

for some TCP communications. The exhaustive list

of features generated by CICFlowMeter is presented

in (Rosay et al., 2021).

3.2 Discovered Issues

The CICFlowMeter source code has evolved over

time without a clear version tag, making it impossible

to know the exact version to use to reproduce the fea-

tures extracted from the dataset. However, all avail-

able versions of the tool generate ﬁles with a sufﬁx

"_Flow.csv" while the CSV ﬁles of the dataset were

generated with a different sufﬁx "_ISCX.csv". This

sufﬁx corresponds to an earlier version of the tool that

is not available in the source code. Therefore, it is im-

possible to reproduce the CSV ﬁles from the provided

PCAP ﬁles.

Comparisons between the CSV ﬁles generated by

CICFlowMeter, hereafter referred to as CFM ﬁles,

and the original CSV ﬁles, hereafter referred to as

ISCX ﬁles, revealed some discrepancies. We found

that some issues appear in both CFM and ISCX ﬁles,

while others appear only in one of them. They are

classiﬁed into ﬁve categories: feature duplication,

feature miscalculations, wrong protocol detection, in-

adequate TCP session termination and labelling issue.

3.2.1 Feature Duplication

We identiﬁed 4 duplicated features in ISCX ﬁles. The

ﬁrst duplicated feature is the average packet length

per ﬂow which is calculated for both features: "Aver-

age Packet Size" and "Packet Length Mean". Then,

the average forward packet length in the ﬂow "Fwd

Packet Length Mean" which is the same as what is

called segment in "Fwd Segment Size Avg". The

same thing is observed in the opposite direction with

"Bwd Packet Length Mean" and "Bwd Segment Size

Avg". The fourth duplicated feature in ISCX ﬁles,

corrected in CICFlowMeter code, is the "Fwd Header

Length" with "Fwd Header Length.1". Since the code

used to generate ISCX ﬁles is not available, we will

only explain the remaining miscalculations in CFM

ﬁles using CICFlowMeter code.

3.2.2 Feature Miscalculations

We found 34 miscalculated features in ISCX ﬁles.

Most likely due to updates in the CICFlowMeter

code, some features were corrected in the latest ver-

sion of the tool (downloaded on 03-23-2021) on

which we based our study. We found 23 remaining

mistakes in feature calculation, this number lowers to

21 if we keep only the non-duplicated features.

• The most common mistake is due to a type issue

in calculation (integer division instead of ﬂoating-

point division). This affects 11 features: 6 related

to bulks, 4 related to subﬂows and 1 to down-

link/uplink ratio.

• For each new packet, backward bulk features are

updated, independently from the packet direction.

The same way, forward bulk features are never

updated. This leads to erroneous values for all 6

bulk-related features.

• The subﬂow count is updated depending on a test

on timestamp values. Due to misplaced parenthe-

Network Intrusion Detection: A Comprehensive Analysis of CIC-IDS2017

sis, the test is always true and so the subﬂow count

is increased for each new packet received.

• The ﬁrst packet of each ﬂow is used twice to up-

date the packet length features, this impacts 3 fea-

tures which are the mean, standard deviation and

total packet length.

• TCP-related features contain errors. The SYN and

PSH ﬂag counts are inverted, as are the FIN and

URG ﬂag counts. Both forward and backward

counts for PSH and URG are never updated. The

initial TCP window size in backward direction is

updated with each packet received and therefore

contains the last value instead of the initial one.

3.2.3 Wrong Protocol Detection

CICFlowMeter processes packets according to the

protocol that is detected. Unfortunately, the tool

sometimes fails to detect it. We observed two types

of protocol detection issues due to poor analysis of

the Ethernet frames.

• A ﬁrst level of detection should depend on the

Ethertype ﬁeld of the Ethernet header. CI-

CFlowMeter assigns all packets in the PCAP ﬁle

to IPv4 or IPv6. Instead of using the Ethertype

ﬁeld, the tool checks whether the packet contains

an IPv4 or IPv6 header. If a sequence of bytes

in the payload looks like an IPv4 or IPv6 header,

the packet is classiﬁed accordingly, whatever the

Ethertype ﬁeld. An analysis of the PCAP ﬁle

contents shows that Address Resolution Protocol

(ARP), Link Layer Discovery Protocol (LLDP)

and Cisco Discovery Protocol (CDP) packets are

present and misclassiﬁed. To illustrate this, some

ARP packets are interpreted as IPv4 packets with

IP addresses 8.0.6.4 and 8.6.0.1 corresponding to

values of the ARP header ﬁelds.

• A second level of analysis should be based on

the protocol ﬁeld of the IPv4 header. Simi-

larly to IPv4 or IPv6 detection, CICFlowMeter

checks whether the packet contains a TCP or UDP

header. A sequence of bytes in the payload can

be misinterpreted as a TCP or UDP header. If

the tool does not detect TCP or UDP, the packet

is classiﬁed in another group that does not corre-

spond to any IPv4 protocol. The analysis shows

that the PCAP ﬁles contain Internet Control Mes-

sage Protocol (ICMP), Internet Group Manage-

ment Protocol (IGMP) and Stream Control Trans-

mission Protocol (SCTP) packets. TCP and UDP

packets are classiﬁed according to IANA proto-

col numbers while most other packets are asso-

ciated with a ’0’ protocol. We observed that CI-

CFlowMeter classiﬁes ICMP packets sometimes

Figure 1: TCP sequence diagram.

as TCP, sometimes as UDP and sometimes as nei-

ther. Another side effect appears with fragmented

frames. UDP fragments are not recognized as

UDP and are treated like other protocols with a

’0’ tag, except for the ﬁrst packet that contains the

UDP header.

3.2.4 Inconsistent TCP Termination Flows

In CICFlowMeter, ﬂows are closed either when the

duration exceeds a predeﬁned timeout of 120s, or

if the received packet carries a ’FIN’ ﬂag. TCP is

a connection-oriented protocol with handshakes. A

typical example is depicted in Figure 1.

When a new TCP communication is started, a ﬁrst

ﬂow is created. It will contain all the packets from the

3-way handshake and the data transfer. This ﬂow is

closed when the ﬁrst packet of the ﬁnal 4-way hand-

shake is received. A second ﬂow is created containing

the second and third packets of this handshake. Fi-

nally, the last packet will create a third ﬂow. The TCP

state machine is complex and many other session ter-

mination cases can occur. This behavior causes three

problems:

• If no other communication using the same ad-

dresses/ports is started, this third ﬂow will be

closed by timeout. Otherwise, the last packet of

the ﬂow will be aggregated with those of the new

communication.

• Since the ﬂow-based features are similar for four-

way handshakes under normal and attack trafﬁc,

they may negatively impact the performance of

machine learning depending on the label attached

to the second and third ﬂows. In addition, we ob-

served inconsistency in the attack labels in ISCX

ﬁles: some second and third ﬂows are labelled as

benign while others are labelled as attacks, creat-

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

ing even more confusion for ML algorithms.

• If a TCP communication is aborted by a ’RST’

ﬂag, CICFlowMeter does not consider it as clos-

ing the ﬂow. Any further communication with the

same identiﬁer will be merged into the ﬂow that

should have been closed by the ’RST’ ﬂag.

3.2.5 Doubts About Labelling

A comparison between the information available on

the website presenting CIC-IDS2017 data (Canadian

Institute for Cybersecurity, 2017b) and the dataset

content revealed some discrepancies, raising doubts

about the correctness of the dataset labelling. This

point can be illustrated by portscan attacks.

• The website mentioned that portscan attacks oc-

cur with and without ﬁrewall enabled while all

portscan attacks in ISCX use the ﬁrewall IP ad-

dress (172.16.0.1).

• Some ﬂows using the attackers IP address when

the ﬁrewall is disabled (205.174.165.73) are la-

belled as benign. These ﬂows were analyzed with

Wireshark and the trafﬁc pattern is very similar

to the portscan attack: many short ﬂows on many

different ports and terminating with a TCP reset.

This seems to conﬁrm that the information on the

website is correct but that some of the labels are

wrong.

A CIC-IDS2017 author conﬁrmed that if there are dis-

crepancies between the website and the ISCX labels,

priority should be given to the labels. He also con-

ﬁrmed that the labelling was achieved using a pro-

prietary package that is not publicly available. Al-

though the patterns in PCAP ﬁles clearly show that

some ﬂows labelled as benign correspond to portscan

behaviour, it is not possible to formally conﬁrm the

labelling issue.

In summary, the aggregation of packets to cre-

ate ﬂows is incorrect due to poor protocol detection.

Many features are miscalculated. Improper termina-

tion of TCP sessions creates similar ﬂows with differ-

ent labels. These major problems impact the perfor-

mance of machine learning algorithms that are com-

monly used for network intrusion detection.

4 LycoSTand: A NEW

FLOW-BASED EXTRACTOR

Given all the problems to be resolved and the lack

of a clear baseline for CICFlowMeter, we decided to

create and publicly release a C program called Lyco-

STand so that it could be used to reproduce our results

or to process PCAP ﬁles from other datasets as an al-

ternative to CICFlowMeter. It relies on the libpcap li-

brary to parse Ethernet packets. This tool was devel-

oped and validated on Ubuntu 18.04, using libpcap-

dev version 1.8.1-6ubuntu1.18.04.2 and gcc compiler

version 7.5.0.

This program takes the PCAP ﬁles, analyzes the

packets and calculates 82 ﬂow-based features. We

mainly reused the features from CIC-IDS2017 except

for the miscalculations mentioned in Section 3.2.2. It

creates one CSV ﬁle containing all the features for

each PCAP ﬁle. The complete list of features is de-

scribed at http://lycos-ids.univ-lemans.fr/.

A major difference between LycoSTand and CI-

CFlowMeter is the handling of TCP session termina-

tions. UDP ﬂows are exclusively closed with a time-

out of 120s (conﬁgurable in LycoSTand). For TCP,

we decided to close ﬂows as soon as a packet with

the ’RST’ or ’FIN’ ﬂag is received. In such a case,

the ﬂowID is stored in a ’TCP_terminated’ list. When

a TCP packet is received, we check if its ﬂowID is

in this list. If it is in the TCP_terminated list, packets

belonging to the TCP session termination are dropped

until a packet with a ’SYN’ ﬂag is received, indicat-

ing that a new ﬂow is starting. The ’TCP_terminated’

list is cleaned up with each new packet by comparing

the timestamp difference with the maximum duration

of a TCP session termination. The packet processing

is described in Algorithms 1 and 2.

When a ﬂow begins, all its features are initialized

to 0. They are updated when a subsequent packet be-

longing to the same ﬂow is received. The computation

of the running statistics is based on the incremental

technique originally proposed by Welford (Welford,

1962).

The protocol detection is based on the Ethertype

extracted from the Ethernet header and the IP protocol

ﬁeld extracted from the IPv4 header. This solves the

issues described in Section 3.2.3.

The current version of LycoSTand is publicly

available at http://lycos-ids.univ-lemans.fr/. It gener-

ates ﬂows from IPv4 packets but it could be extended

to process other packet types such as IPv6, ARP or

LLDP. Another limitation of our tool is related to run-

time. Our focus was on creating reliable datasets, not

on being time-optimized. Attacks such as portscan

or DoS/DDoS create many ﬂows in a short period of

time, and due to the use of singly linked lists, the

amount of time it takes to search through the lists is

in O(n), where n is the number of ongoing ﬂows. We

ran LycoSTand on a laptop based on an Intel Core

i7-8750H processor with 16GByte of RAM and the

analysis of CIC-IDS2017 PCAP ﬁles took about 16

hours. A future version of the tool could use other

Network Intrusion Detection: A Comprehensive Analysis of CIC-IDS2017

Algorithm 1: Packet processing.

while True do

wait for next packet

clean TCP terminated list

extract ﬂow identiﬁers from received packet

search ﬂow in list of ﬂows

if IPv4 packet then

if ﬂow is not in list of ﬂows then

if TCP packet then

if ﬂow is not in TCP terminated

list then

if packet hasn’t ’FIN’ nor

’RST’ ﬂag then

create new ﬂow

calculate its initial

statistics

else

add ID to TCP

terminated list

else

if packet has ’SYN’ ﬂag

then

create new ﬂow

calculate its initial

statistics

remove ID from TCP

terminated list

else

create new ﬂow

calculate its initial statistics

else

if ﬂow not terminated then

update running statistics

else

terminateFlow(packet, ﬂow)

data structures such as the hashmap to reach an amor-

tized research duration in O(1).

5 LycoS-IDS2017: A CORRECTED

DATASET

To conﬁrm the corrections made on the feature extrac-

tor have an impact on machine learning, we created a

new dataset by processing the PCAP ﬁles from CIC-

IDS2017 with LycoSTand. Since the original dataset

was labelled with a proprietary package, we devel-

oped our own solution. This program is written in

Python. Our labelling solution relies on the trafﬁc

Algorithm 2: Flow termination.

Procedure terminateFlow( packet, f low)

close existing ﬂow

if ﬂow ended by timeout then

if TCP packet then

if packet has ’FIN’ or ’RST’ ﬂag

then

add ID to TCP terminated list if

it is not there yet

else

create new ﬂow

calculate its initial statistics

else

create new ﬂow

calculate its initial statistics

else

add ID to TCP terminated list if it is not

there yet

return

analysis we carried out with Wireshark, which re-

vealed that labels can be assigned using source and

destination addresses and ports coupled with times-

tamps. We did not use time information provided on

CIC website but adjusted time according to the trafﬁc

analysis.

The resulting dataset and program are publicly

available at http://lycos-ids.univ-lemans.fr/. We use

different techniques to attach a label to each ﬂow:

• The reference (Canadian Institute for Cybersecu-

rity, 2017b) provides information about the time

period and the addresses or ports involved in the

various attacks.

• We analyzed the PCAP ﬁles with Wireshark to

conﬁrm the labels. By observing the attack pat-

terns, we were able to adjust the duration of the

attacks.

• We found out that a lot of ﬂows recorded on

Thursday afternoon were labelled as benign in

CIC-IDS2017, while the pattern is most likely a

portscan attack. As it corresponds to inﬁltration

attacks, this behavior can be explained by the fact

that this attack is composed of two phases. As ex-

plained in (Sharafaldin et al., 2018), a ﬁle contain-

ing a vulnerability is downloaded and then, the

attacker runs a portscan attack. We believe that

CIC-IDS2017 authors labelled the second phase

as benign trafﬁc. In the absence of detailed in-

formation from the authors, it is impossible to

identify with absolute certainty which ﬂows are

truly benign trafﬁc and which should have been

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

Table 1: CIC-IDS2017 trafﬁc instances.

Trafﬁc CIC-IDS2017 LYCOS-IDS2017

BENIGN 2,273,097 1,395,659

Bot 1,966 735

DDoS 128,027 95,683

DoS GoldenEye 10,293 6,765

DoS Hulk 231,073 158,988

DoS Slowhttptest 5,499 4,866

DoS Slowloris 5,796 5,674

FTP-PATATOR 7,938 4,003

Heartbleed 11 11

Inﬁltration 36 0

PortScan 158,930 160,106

SSH-PATATOR 5,897 2,959

WebAttack BruteForce 1,507 1,360

WebAttack SQL Injection 21 12

WebAttack XSS 652 661

Total 2,830,743 1,837,500

labelled inﬁltration. To avoid errors in our la-

bels, we decided to drop all packets from Thurs-

day afternoon. Consequently, LYCOS-IDS2017

does not contain any inﬁltration attacks.

The list of attacks and the number of instances

for each dataset is presented in Table 1. We observe

that almost every label has less instances in LYCOS-

IDS2017 than in CIC-IDS2017. It is consistent to

have less instances for the majority of labels basically

because of the TCP session terminations discarded.

For Portscan, there is a certain amount of TCP ses-

sions that end with a ’RST’ ﬂag and then another one

begins with a ’SYN’ ﬂag for the same ﬂowID, this be-

havior leads to more ﬂows in the Lycos ﬁle than in the

ISCX ﬁle.

An uncertainty remains for our labelling program

in one speciﬁc case. The number of WebAttack XSS

in Lycos ﬁle is surprisingly high compared to ISCX.

We suspect that CIC-IDS2017 contains some benign

trafﬁc using the same IP addresses and ports as the

attack. Here again, we regret not having access to

the original labelling package. Despite doubts about

our labels for this attack, we decided to keep it in

the dataset. By publishing our tools, we hope that

more people can investigate and potentially improve

our work.

6 PERFORMANCE IMPACTS

FOR INTRUSION DETECTION

As explained in Section 5, LYCOS-IDS2017 is cre-

ated from the CIC-IDS2017 PCAP ﬁles to solve the

identiﬁed issues. In this section, we deﬁne an experi-

mental setup to compare performance of both datasets

with several ML algorithms. The creation of training,

cross-validation and test sets is explained in Section

6.1. In a second step, we detail the ML algorithms

in Section 6.3. Then, the metrics used to evaluate the

performance are developed in Section 6.3. Finally, the

performance comparison between CIC-IDS2017 and

LYCOS-IDS2017 is presented in Section 6.4.

6.1 Data Preparation

This section presents the different steps to prepare the

data injected as input to our model. After data clean-

ing, ﬂows from different classes are sampled in train-

ing, cross-validation and test sets. Then, a feature se-

lection is applied before a standardization step.

6.1.1 Data Clean-up

CIC-IDS2017 contains more than 280,000 instances

with all empty features. These unwanted samples

were removed. A negligible number of instances con-

taining ’NaN’ or ’Inﬁnity’ were dropped. Due to the

miscalculation of features, some features are always

null. This is the case for ’Bwd PSH Flags’, ’Bwd

URG Flags’, ’Fwd Avg Bytes/Bulk’, ’Fwd Avg Pack-

ets/Bulk’, ’Fwd Avg Bulk Rate’, ’Bwd Avg Bytes-

/Bulk’, ’Bwd Avg Packets/Bulk’, ’Bwd Avg Bulk

Rate’. Therefore, we decided to remove these fea-

tures. Finally, we removed inﬁltration because this

attack is not available in LYCOS-IDS2017.

For LYCOS-IDS2017, we only removed the three

URG ﬂag related features that are always null as all

the other features deleted from CIC-IDS2017 were

due to calculation errors and they become informa-

tive in LYCOS-IDS2017. A cross-check in the PCAP

ﬁles conﬁrmed that URG ﬂag is not set in any packet.

Time information in a dataset can be useful for

concept drift analysis but knowing that the Ethernet

frames were recorded for 5 consecutive days, this

dataset is not suitable for studying concept drift. In

addition, since we do not want the model to learn

when an attack occurs, the ’Timestamp’ feature can-

not be considered informative.

Each instance is characterized by its source and

destination ports and IP addresses, its protocol and all

these information gathered in a ﬂowID. As the ﬂow

identiﬁer is redundant with other features, it was re-

moved from the dataset. We also decided to drop the

source and destination IP addresses and source port

because these features are not relevant in a generic

intrusion detection system and can be learned by the

IDS.

Network Intrusion Detection: A Comprehensive Analysis of CIC-IDS2017

Table 2: Dataset split.

Trafﬁc Training set Cross-validation set Test set

benign 220,316 110,158 110,158

bot 367 183 183

ddos 47,841 23,920 23,920

dos_goldeneye 3,382 1,691 1,691

dos_hulk 79,494 39,747 39,747

dos_slowhttptest 2,433 1,216 1,216

dos_slowloris 2,837 1,418 1,418

ftp_patator 2,001 1,000 1,000

heartbleed 5 2 2

portscan 79,465 39,732 39,732

ssh_patator 1,479 739 739

webattack_bruteforce 680 340 340

webattack_sql_injection 6 3 3

webattack_xss 317 158 158

Total 440,632 220,312 220,312

6.1.2 Creation of Training Set, Cross-validation

Set and Test Set

As shown in Table 1, the datasets are highly imbal-

anced at two different levels. First, the normal trafﬁc

(BENIGN) represents ∼80% of the whole trafﬁc and

second, some attacks (Heartbleed, Inﬁltration, We-

bAttack SQL injection) are represented by a very lim-

ited number of instances. This is known to be a chal-

lenge for supervised learning. The general idea is to

build training and test sets by randomly selecting 50%

of each attack for the training set, 25% for the cross-

validation set and 25% for the test set, ensuring that

each instance is used only once. Since CIC-IDS2017

and LYCOS-IDS2017 do not contain exactly the same

number of attacks, we tuned the composition of train-

ing and test sets to obtain the same number of in-

stances and allow for a fair comparison. Then, each

set is supplemented with randomly selected instances

of normal trafﬁc without replacement. The result is

a dataset that is balanced in term of normal trafﬁc

versus attacks, but still imbalanced in terms of at-

tack types. Only training and cross-validation sets are

used during the training phase. Final performance is

measured with data from the test set that was never

used during the training. The exact composition of

the training, cross-validation and test sets is provided

in Table 2.

6.1.3 Data Pre-processing

Data pre-processing is essential to prepare the

datasets for an efﬁcient training. In particular, the

neural network learns best when all features are scaled

to the same range. This is especially useful when the

inputs are at very different scales. In our implemen-

tation, Z-score normalization was selected as it has

better results than min-max scaling on the selected

dataset. Since some features may contain high val-

ues, the relevant information may be compressed by

the min-max scaler into a narrow range, negatively

impacting the classiﬁer performance. For each feature

, the transformation of each x

value to its standard-

ized value x

n,i

is given by (1) where µ

)

and σ

)

are respectively the mean and standard deviation val-

ues of feature F

)

n,i

)

− µ

)

(1)

6.2 Algorithms

The performance of the datasets is evaluated on tradi-

tional ML algorithms and a simple neural network.

6.2.1 Classical Machine Leaning

The same training, cross-validation and test sets were

used for various classical ML algorithms available

in the scikit-learn Python library: i) Decision Tree,

ii) Random Forest, iii) k-nearest neighbors, iv) Lin-

ear Discriminant Analysis, v) Quadratic Discriminant

Analysis, vi) Support Vector Machine.

The Decision Tree (DT) classiﬁer is based on

CART algorithm which produces a binary tree. The

gini criterion is used to measure impurity. Ran-

dom Forest (RF) contains 100 trees and the classiﬁer

also uses gini impurity to split the data. K-Nearest

Neighbors (k-NN) is conﬁgured to sort data based

on the ﬁve nearest neighbors using the Euclidean

distance. Linear Discriminant Analysis (LDA) and

Quadratic Discriminant Analysis (QDA) are classi-

ﬁers able to generate linear and quadratic boundaries

between classes respectively. Due to the size of the

training set, it would not be adequate to use a non-

linear kernel. Therefore, we used linear Support Vec-

tor Machine (SVM).

6.2.2 Neural Network

Multi-layer perceptron (MLP) is a fully connected,

feed-forward neural network classiﬁer. Our MLP

takes as inputs the normalized values of the selected

features and contains two hidden layers of 256 nodes

with SELU (Klambauer et al., 2017) activation func-

tion. The output layer is composed of 14 nodes and

uses a softmax activation function.

The model was implemented in Python, using

TensorFlow-2.3 as deep learning framework. The

training set is divided into mini-batches of 32 in-

stances. MLP learns classiﬁcation by adjusting the

w weights between the neural network nodes to re-

duce the cross-entropy loss function L(w) as deﬁned

in (2) where y is the ground truth label and ˆy the pre-

dicted class. L(w) is optimized with Adam algorithm.

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

Three parameters α, β

and β

described in (Kingma

and Ba, 2015) allow to conﬁgure this optimizer.

L(w) = − [y · log( ˆy) + (1 − y) · log (1 − ˆy)] (2)

The MLP was trained during 25 epochs. Potential

over-ﬁtting of the neural network is controlled by

evaluating the cross-validation set. Dropout rate is ad-

justed so that the difference in performance between

the training and cross-validation sets remains small.

Hyper-parameters tuning is a tricky task that involves

ﬁnding the right set of values to get the highest per-

formance. A random search strategy (Bergstra and

Bengio, 2012) was applied to tune dropout rate, α,

while keeping the default value β

= 0.999. The

search was conducted in two stages. In the ﬁrst phase,

we look for the best parameters in a wide range of val-

ues which are reﬁned in a second phase. These ranges

are [0.5 − 0.01] for dropout_rate, [0.0001 − 0.002]

for α and [0.80 − 0.99] for β

. A second range of

parameters was tested around the best parameters ob-

served during the ﬁrst phase. The procedure was used

twice to tune α and β

at the same time, and then to

tune the dropout rate. We applied this method for both

dataset. The hyper-parameter values are given in (3)

and (4).

our dataset











α = 0.0003175219400915

= 0.9158410351985389

dropout_rate = 0.1185905448

(3)

cic dataset











α = 0.0003590920789688

= 0.8662527597085028

dropout_rate = 0.20886178816

(4)

6.3 Evaluation Metrics

Several key insights can be extracted by comparing

the predictions and the actual classes. True Positive

(TP) is the number of attacks correctly predicted as

attacks. True Negative (TN) is the number of normal

instances classiﬁed as normal trafﬁc while False Pos-

itive (FP) and False Negative (FN) are respectively

the number of normal instances classiﬁed as attacks

and the number of attacks predicted as normal traf-

ﬁc. Different metrics can be derived from the infor-

mation contained in the confusion matrix. True Neg-

ative Rate (TNR), Accuracy (Acc), Precision (Prec)

and Recall (Rec) are deﬁned in (Maniriho and Ah-

mad, 2018). The f

score is the harmonic mean of

Precision and Recall. False Positive Rate (FPR) in (5)

is the percentage of benign trafﬁc classiﬁed as attacks.

FPR =

T N + FP

(5)

The Matthews Correlation Coefﬁcient (MCC) was

ﬁrst introduced by B.W. Matthews (Matthews, 1975)

in the context of biomedical research. It is an in-

teresting measure taking into account all elements of

the confusion matrix in a correct way for imbalanced

dataset. In such a situation, accuracy is not adequate

because it may be a high value even if the entire mi-

nority class is misclassiﬁed. Since intrusion detec-

tion datasets are intrinsically imbalanced, MCC is an

essential metric for such an application. It is also

known as a robust metric when positive and negative

cases are of equal importance (Chicco et al., 2021).

It provides a value between −1 and +1. A perfect

prediction corresponds to MCC = 1. At the opposite,

MCC = −1 denotes a total disagreement between the

predictions and the actual classes. A random predic-

tion would correspond to MCC = 0.

6.4 Results

After training the different classiﬁers, the test set was

used to measure their performance as a 14-class clas-

siﬁer. The resulting confusion matrices were simpli-

ﬁed by aggregating all attacks into a single class to

obtain a binary classiﬁer. Table 3 details the com-

puted metrics for each dataset.

While classiﬁers differ in performance with CIC-

IDS2017, all but one reach the same level of per-

formance with LYCOS-IDS2017. The difference is

particularly important for classiﬁers that performed

worse with CIC-IDS2017. LDA is the algorithm that

improved the most but remains the worst. Its accuracy

increased from 88.10% to 96.93% while the false pos-

itive rate decreased from 22.08% to 6.27%. Resolv-

ing the CIC-IDS2017 problems has most likely im-

proved the possibility to linearly separate the classes,

but the dataset is still not completely linearly sepa-

rable. This hypothesis is conﬁrmed by the improved

results of SVM using a linear kernel. QDA produces

better results than LDA. LDA assumes a covariance

matrix that is common to all classes in a dataset. Since

QDA performs better than LDA, we can conclude that

the assumption of a common covariance matrix is not

fulﬁlled in our dataset. The best results are obtained

with the decision tree and the random forest. These

algorithms behave like rule-based intrusion detection

systems that are known to produce good results. The

metrics of neural network are very slightly below the

best algorithms. This can be explained by the very

limited training phase, with only 25 epochs. We can

expect the MLP to get better results with a longer

training.

Table 4 presents the training duration and the time

needed to infer the complete test set which contains

Network Intrusion Detection: A Comprehensive Analysis of CIC-IDS2017

Table 3: Performance comparison.

Dataset Algorithm Accuracy (%) Precision (%) Recall (%) f

score (%) False Positive Rate (%) MCC

LYCOS-IDS2017

LDA 96.59 94.00 99.54 96.69 6.35 0.9335

QDA 99.83 99.93 99.73 99.83 0.08 0.9966

SVM 99.50 99.61 99.40 99.51 0.38 0.9901

k-NN 99.95 99.91 99.96 99.93 0.10 0.9986

DT 99.92 99.92 99.92 99.85 0.08 0.9985

RF 99.96 99.95 99.98 99.96 0.06 0.9996

MLP 99.72 99.88 99.55 99.72 0.12 0.9943

CIC-IDS2017

LDA 88.10 81.63 98.33 89.21 22.12 0.7785

QDA 97.72 96.00 99.59 97.76 4.15 0.9550

SVM 96.98 95.78 98.30 97.02 4.33 0.9400

k-NN 99.31 98.87 98.75 98.61 1.10 0.9864

DT 99.88 99.87 99.89 99.88 0.13 0.9976

RF 99.90 99.90 99.91 99.90 0.10 0.9981

MLP 99.10 98.44 99.79 99.11 1.58 0.9821

Table 4: Execution time.

Algorithm Training (s) Inference (s)

LDA 4.874 0.933

QDA 3.138 2.782

SVM 336.908 0.071

k-NN not applicable 1,519.312

DT 9.879 0.036

RF 64.731 1.850

MLP 231.748 0.801

220,312 instances.

Among the algorithms achieving the best metrics,

we observe that k-NN is the worst in term of inference

time. This is explained by the nature of the algorithm.

k-NN is a lazy classiﬁer that does not need a training

phase but measure the distance between the instance

to be classiﬁed and all other instances in order to ﬁnd

the majority class of k nearest neighbors. This algo-

rithm is not suitable for big datasets. Clearly, Ran-

dom Forest requires more time than Decision Tree,

both for training and for inference. Since these al-

gorithms perform similarly, there is no need to use

RF. The longest training is observed with the neural

network. Nevertheless, as more and more comput-

ers contain hardware accelerators for neural network,

the inference time might be signiﬁcantly reduced and

MLP could remain an interesting alternative to other

algorithms.

7 BEYOND CIC-IDS2017

The CIC website contains 19 datasets. CI-

CFlowMeter has been used to generate 5 of them:

(1) CIC-IDS2017, (2) CIC-AndMal2017 (Lashkari

et al., 2018), (3) CSE-CIC-IDS2018, (4) CIC-

InvesAndMal2019 (Taheri et al., 2019) and (5) CIC-

DDoS2019 (Sharafaldin et al., 2019). We have shown

that the features extracted from the PCAP ﬁles for (1)

are affected by the problems we have identiﬁed. One

can expect the same issues to be present in all datasets

generated by CICFlowMeter. A complete analysis of

the PCAP ﬁles for each of these datasets would be

an overwhelming task. We preferred to focus on the

detection of four artifacts in the CSV ﬁles.

• The ﬁrst artifact corresponds to the presence of

a constant value for the bulk features, indicating

miscalculation.

• Another marker is the detection of the IP address

8.0.6.4 as explained in Section 3.2.3, indicating

that ARP packets are classiﬁed as IP packets con-

ﬁrming Ethertype detection problems.

• All ﬂows indicating an IP protocol, source and

destination ports equal to 0 but not having an IP

address 8.0.6.4 are IP packets that are neither TCP,

nor UDP. This situation corresponds to an erro-

neous protocol detection.

• The fourth artifact corresponds to the presence of

a ﬂow having two packets with a FIN ﬂag that are

sometimes classiﬁed as benign and sometimes as

an attack. This indicates inconsistent TCP termi-

nation ﬂows.

We found that all datasets containing CSV ﬁles

generated by CICFlowMeter contain these artifacts.

This conﬁrms that CICFlowMeter is the source of

the issues. Since the authors of these datasets pro-

vided raw data, LycoSTand presents an interesting al-

ternative to extract ﬂow-based features from existing

PCAP ﬁles.

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

8 CONCLUSION

Having a reliable and publicly available IDS dataset

is an important concern for researchers in this do-

main. The Canadian Institute for Cybersecurity is a

major provider of IDS datasets. We analyzed one of

them and identiﬁed the key issues. Some features are

not calculated correctly, the protocols are partly in-

correct, and the way TCP packets are grouped into

ﬂows is not suitable for machine learning processing.

Next, we proposed LycoSTand as a tool for process-

ing PCAP ﬁles and generated a new dataset from the

CIC-IDS2017 PCAP ﬁles. The tool and dataset are

publicly available so that they can be used to replicate

and improve our results.

A fair comparison of the original dataset with

LYCOS-IDS2017 demonstrated that the corrections

made by our tool have a positive impact on all tested

machine learning algorithms. Metrics such as accu-

racy, precision and recall are above 99.5% for all al-

gorithms, with the exception of LDA, which, in any

case, improves signiﬁcantly from 88% to 96%. The

best results are obtained with Random Forest which

outperforms all other algorithms for all metrics. Fi-

nally, we observe that SVM or QDA that do not rank

well for CIC-IDS2017 become interesting algorithms

for LYCOS-IDS2017. This shows that a corrected

dataset may help researchers to reconsider the choice

of algorithms in their IDS studies.

The issues we identiﬁed in CIC-IDS2017 only ex-

ist in CSV ﬁles. This shows how important it is to

provide raw data along with the ﬂow-based features.

Problem markers were found in all ﬁve datasets gen-

erated with CICFlowMeter. However, they are still

interesting because their PCAP ﬁles can be processed

with LycoSTand to obtain better ﬂow-based datasets.

Because most of the publications related to these

datasets rely on algorithms processing the CSV ﬁles,

it is important to make available a corrected version

so that ﬁndings of research work are not impacted by

the erroneous CSV ﬁles.

Future work could be considered on the datasets

published by CIC and listed in section 7 with the goal

to conﬁrm suspected issues. In addition, with the

rise of IoT devices, it would be interesting to study

how such devices can be protected from network in-

trusions. We intend to improve LycoSTand execution

time, deploy the model on a resource-constrained sys-

tem and replicate attacks to investigate whether the

training on the dataset can detect intrusion attacks

launched with a penetration testing toolset. Such re-

search could highlight some limitations of the ML-

based IDS solution for embedded system and deter-

mine if the current dataset is prone to concept drift.

REFERENCES

Bergstra, J. and Bengio, Y. (2012). Random search for

hyper-parameter optimization. The Journal of Ma-

chine Learning Research, 13:281–305.

Canadian Institute for Cybersecurity (2017a). Applica-

tions - cicﬂowmeter (formerly iscxﬂowmeter). https:

//www.unb.ca/cic/research/applications.html. Last

checked on Nov 27, 2021.

Canadian Institute for Cybersecurity (2017b). Intrusion de-

tection evaluation dataset (cicids2017). https://www.

unb.ca/cic/datasets/ids-2017.html. Last checked on

Nov 27, 2021.

Chicco, D., Tötsch, N., and Jurman, G. (2021). The

matthews correlation coefﬁcient (mcc) is more reli-

able than balanced accuracy, bookmaker informed-

ness, and markedness in two-class confusion matrix

evaluation. BioData Mining, 14(1):13.

Draper-Gil., G., Lashkari., A. H., Mamun., M. S. I., and

Ghorbani., A. A. (2016). Characterization of en-

crypted and vpn trafﬁc using time-related features. In

Proceedings of the 2nd International Conference on

Information Systems Security and Privacy (ICISSP),

volume 1, pages 407–414. INSTICC, SciTePress.

Engelen, G., Rimmer, V., and Joosen, W. (2021). Trou-

bleshooting an intrusion detection dataset: the ci-

cids2017 case study. In 2021 IEEE Security and Pri-

vacy Workshops (SPW), pages 7–12.

Gamage, S. and Samarabandu, J. (2020). Deep learning

methods in network intrusion detection: A survey and

an objective comparison. Journal of Network and

Computer Applications, 169:102767.

Gharib, A., Sharafaldin, I., Lashkari, A. H., and Ghorbani,

A. A. (2016). An Evaluation Framework for Intrusion

Detection Dataset. In International Conference on In-

formation Science and Security (ICISS), pages 1–6.

Ho, S., Jufout, S. A., Dajani, K., and Mozumdar, M.

(2021). A novel intrusion detection model for detect-

ing known and innovative cyberattacks using convo-

lutional neural network. IEEE Open Journal of the

Computer Society, 2:14–25.

Kingma, D. P. and Ba, J. (2015). Adam: A method for

stochastic optimization. 3rd International Conference

for Learning Representations.

Klambauer, G., Unterthiner, T., Mayr, A., and Hochre-

iter, S. (2017). Self-normalizing neural networks. In

Advances in Neural Information Processing Systems,

pages 971–980.

Lashkari, A. H., Gil, G. D., Mamun, M. S. I., and Ghorbani,

A. A. (2017). Characterization of tor trafﬁc using time

based features. In Proceedings of the 3rd International

Conference on Information Systems Security and Pri-

vacy - Volume 1: ICISSP,, page 253–262. SciTePress.

Lashkari, A. H., Kadir, A. F. A., Taheri, L., and Ghor-

bani, A. A. (2018). Toward developing a system-

atic approach to generate benchmark android malware

datasets and classiﬁcation. In 2018 International Car-

nahan Conference on Security Technology (ICCST),

pages 1–7.

Network Intrusion Detection: A Comprehensive Analysis of CIC-IDS2017

Lee, W., Stolfo, S. J., and Mok, K. W. (1999). Min-

ing in a data-ﬂow environment: Experience in net-

work intrusion detection. In Proceedings of the Fifth

ACM SIGKDD International Conference on Knowl-

edge Discovery and Data Mining, KDD ’99, pages

114–124, New York, NY, USA. ACM.

Maniriho, P. and Ahmad, T. (2018). Analyzing the Perfor-

mance of Machine Learning Algorithms in Anomaly

Network Intrusion Detection Systems. In 4th Interna-

tional Conference on Science and Technology (ICST),

pages 1–6.

Maseer, Z. K., Yusof, R., Bahaman, N., Mostafa, S. A.,

and Foozy, C. F. M. (2021). Benchmarking of ma-

chine learning for anomaly based intrusion detection

systems in the cicids2017 dataset. IEEE Access,

9:22351–22370.

Matthews, B. (1975). Comparison of the predicted and

observed secondary structure of T4 phage lysozyme.

Biochimica et Biophysica Acta (BBA) - Protein Struc-

ture, 405(2):442–451.

McHugh, J. (2000). Testing Intrusion Detection Systems: A

Critique of the 1998 and 1999 DARPA Intrusion De-

tection System Evaluations As Performed by Lincoln

Laboratory. ACM Trans. Inf. Syst. Secur., 3(4):262–

294.

Moustafa, N. and Slay, J. (2015). UNSW-NB15: A com-

prehensive data set for network intrusion detection

systems (UNSW-NB15 network data set). In Mili-

tary Communications and Information Systems Con-

ference (MilCIS), pages 1–6.

Panigrahi, R. and Borah, S. (2018). A detailed analysis

of cicids2017 dataset for designing intrusion detec-

tion systems. International Journal of Engineering &

Technology, 7(3.24):479–482.

Rosay, A., Riou, K., Carlier, F., and Leroux, P. (2021).

Multi-layer perceptron for network intrusion detec-

tion. Annals of Telecommunications - annales des télé-

communications.

Sharafaldin, I., Lashkari, A. H., and Ghorbani, A. A.

(2018). Toward Generating a New Intrusion Detec-

tion Dataset and Intrusion Trafﬁc Characterization. In

Proceedings of the 4th International Conference on

Information Systems Security and Privacy (ICISSP),

volume 1, pages 108–116. SciTePress.

Sharafaldin, I., Lashkari, A. H., Hakak, S., and Ghorbani,

A. A. (2019). Developing realistic distributed denial

of service (ddos) attack dataset and taxonomy. In In-

ternational Carnahan Conference on Security Tech-

nology (ICCST), pages 1–8.

Sperotto, A., Sadre, R., van Vliet, F., and Pras, A. (2009).

A labeled data set for ﬂow-based intrusion detection.

In Nunzi, G., Scoglio, C., and Li, X., editors, IP Op-

erations and Management, pages 39–50, Berlin, Hei-

delberg. Springer Berlin Heidelberg.

Taheri, L., Kadir, A. F. A., and Lashkari, A. H. (2019). Ex-

tensible android malware detection and family classi-

ﬁcation using network-ﬂows and api-calls. In Interna-

tional Carnahan Conference on Security Technology

(ICCST), pages 1–8.

Tavallaee, M., Bagheri, E., Lu, W., and Ghorbani, A. A.

(2009). A detailed analysis of the KDD CUP 99 data

set. In IEEE Symposium on Computational Intelli-

gence for Security and Defense Applications, pages

1–6.

Welford, B. (1962). Note on a method for calculating cor-

rected sums of squares and products. Technometrics,

4(3):419–420.

Yang, L., Moubayed, A., and Shami, A. (2021). Mth-ids:

A multi-tiered hybrid intrusion detection system for

internet of vehicles. IEEE Internet of Things Journal,

pages 1–1.

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy
