Hoplite Antivirus for Adversarial Attacks: A Theoretical Approach

Anastasios Nikolakopoulos, Achilleas Marinakis, Vrettos Moulos and Theodora Varvarigou

School of Electrical & Computer Engineering, National Technical University of Athens, Greece

Keywords:

Adversarial Attacks, Adversarial Defenses, Adversarial Examples, Deep Neural Networks, Machine

Learning, Data Analysis, Artiﬁcial Intelligence.

Abstract:

In the scientiﬁc community of Machine Learning and Artiﬁcial Intelligence, Adversarial Attacks are evolving

to an emerging issue. Carefully perturbed data samples invade to deep neural networks and cause problems,

such as misclassiﬁcations and false / malformed outputs. The community has proposed multiple defense

strategies, in order to overcome this problem. This paper summarizes the existing (and most well-known)

adversarial attacks & defenses. Then, it proposes a potential solution to the issue, with a theoretical approach

of an antivirus software scenario, the Hoplite Antivirus. This approach could be a vital step towards addressing

the constantly evolving adversarial attacks, taking a note from the way software scientists defended (and keep

defending) against computer viruses.

1 INTRODUCTION

Deep Neural Networks are the newest trend in the

ﬁeld of Machine Learning. Since the beginning of

the 21st century, there has been a rapid increase in

interest around the ﬁeld of Deep Learning. In the

last decade, however, DNN model implementations

have been adopted in countless industries in the global

industry. Typical examples of Deep Learning tech-

niques are image categorization models, with net-

works such as ImageNet or DeepFace (the latter for

even more speciﬁc face recognition). But, in re-

cent years there has been a worrying phenomenon

that threatens to ”tarnish” the usefulness and the real

essence of Deep Neural Networks. In particular, these

networks are prone to attacks that can lead to incor-

rect pattern categorization. Feeding the system with

data, which have small and seemingly imperceptible

changes, can lead to incorrect classiﬁcations & con-

clusions.

Any Neural Network can be fooled by this kind

of malformed data, which has become widely known

as Adversarial Attacks / Adversarial Examples. This

paper will continue (Section 2) by brieﬂy analyzing

the existing adversarial attacks (Subsection 2.1), as

well as the defenses proposed by researchers around

the world (Subsection 2.2). Then (Section 3), a quick

look back in history will take place (Subsection 3.1),

which shall lead to the presentation of the Hoplite An-

tivirus (Section 3.2), a theoretical approach for prop-

erly addressing the adversarial attack issue. Since

these attacks are somewhat new to the science com-

munity, plenty of research is yet to be done. Along

with the study of the attacks, new ideas on how to deal

with them have to be proposed. Conclusions (Section

4) point out this need of further research. Hoplite An-

tivirus is one such idea. Before presenting this main

idea, however, it seems proper to go through the ex-

isting adversarial attacks and defenses.

2 ADVERSARIAL ATTACKS &

DEFENSES

2.1 Attacks

Starting with the attacks, these could be categorized

based on the purpose and the knowledge of the ad-

versary. Of course, one attack can belong in both a

purpose and a knowledge type. It could even be of

two purpose types. The attack types categorized by

the purpose of the adversary are as follows (Ozdag,

2018) (Xu et al., 2020):

• Poisoning Attacks, in which the adversary aims

to add perturbed data samples to a training dataset.

The attacker might also perform perturbation on

existing samples of the set.

• Evasion Attacks, in which the adversary care-

fully malforms speciﬁc samples from an exist-

Nikolakopoulos, A., Marinakis, A., Moulos, V. and Var varigou, T.

Hoplite Antivirus for Adversarial Attacks: A Theoretical Approach.

DOI: 10.5220/0010721600003058

In Proceedings of the 17th International Conference on Web Information Systems and Technologies (WEBIST 2021), pages 585-592

ISBN: 978-989-758-536-4; ISSN: 2184-3252

585

ing classiﬁcation dataset (or adds some to an ex-

isting one). The trained DNN will fail to clas-

sify the malformed examples, fulﬁlling the ad-

versary’s goal. Thus, the adversarial examples

“evade” the DNN’s classiﬁcation.

• Targeted Attacks, where the adversarial exam-

ples created by the attacker are fed to the DNN

with the purpose of wrong classiﬁcation to a spe-

ciﬁc class / label. With his/her perturbed data

sample, the adversary wishes to achieve a classi-

ﬁcation of a targeted label, which happens to be a

different one from the original “true” label of the

“clean” (non-perturbed) data sample.

• Non-targeted Attacks, where the adversarial ex-

amples created by the attacker are fed to the DNN

with the purpose of wrong classiﬁcation (same as

before), but without a speciﬁc wrong class / label.

Here, the adversary’s goal is not to target a spe-

ciﬁc label for classiﬁcation. He/she only wishes

for the malformed data samples to be falsely clas-

siﬁed to a label other than their “true” and original

one.

One could assume that both poisoning and eva-

sion attacks could be part of the non-targeted ones.

Now, lets move on to the attack types categorized by

the knowledge of the adversary (Xu et al., 2020)

(Chakraborty et al., 2018). These are:

• White-box Attacks, explaining all the scenarios

where the adversary has access to vital informa-

tion of the neural network and the system itself.

Such information can be the DNN’s architecture,

its hyperparameters, the training dataset, informa-

tion about the dataset, etc. White-box attacks are

considered as the most difﬁcult to defend against,

since the attacker can carefully craft extremely ef-

ﬁcient data samples, based on his/her knowledge

upon the network.

• Black-box Attacks, containing all the cases

where the attacker has no access to information re-

garding the network, neither the training dataset.

Thus, he/she is conﬁned to limited knowledge

about the targeted DNN / system. Usually, the

adversarial examples created are based on experi-

ence from interacting with the DNN (that is, mon-

itoring the DNN’s results and trying to understand

some classiﬁcation patterns).

• Semi-white or Grey-box Attacks, are terms re-

lated to cases where the adversary has some

knowledge regarding the network or the train-

ing dataset. However, the amount of information

he/she possesses is not enough in order to craft

“perfect” adversarial examples.

As already mentioned, an attack usually belongs to

one purpose type and one knowledge type (it could

even belong to more than one, mainly in the purpose

category).

2.1.1 White-box Approaches

It is time to go through the existing and most fa-

mous attacks proposed until today. Splitting them in

white and black-box ones, we start with the attacks of

the ﬁrst kind (that is, the white-box) (Ozdag, 2018)

(Chakraborty et al., 2018) (Tram

er et al., 2017) (Xu

et al., 2020) (Yuan et al., 2019).

Limited Memory BGFS (L-BGFS) (Szegedy

et al., 2013), is one of the ﬁrst adversarial attacks

published. The algorithm’s main target is to locate

the minimal distorted adversarial example x

, given an

original and “clean” data sample x. This means that

the adversarial example x’s distance must be small

enough from the original x, for the DNN classiﬁer to

be tricked and consider x

as a true data sample. How-

ever, x’s perturbation must be enough, for the model

to classify it in the targeted label t and not in the true

label y. So, L-BGFS aims to ﬁnd a “balanced” dis-

tance, with the minimal distortion that tricks the DNN

to consider x

as a real x, but at the same time misclas-

sify it in the desired label t. Due to its nature (repet-

itive process) the algorithm is considered as a time

consuming and resource greedy adversarial attack.

Fast Gradient Sign Method (FGSM) (Goodfel-

low et al., 2014), is one of the most famous adver-

sarial attacks (and also one of the ﬁrst, along with

L-BGFS). It follows a different strategy than that of

L-BGFS. As a one-step process, it is also drastically

more efﬁcient in terms of both time and resources.

The algorithm’s target is to apply a one-step appli-

cation of carefully selected noise of very little value

(usually imperceptible to the naked eye) to a selected

data sample x. The created adversarial example x

is able to trick the deep neural network, leading to

wrong classiﬁcation in a targeted label t. However, a

non-targeted version of FGSM has been published as

well. Since the adversarial example creation process

is quicker and faster, FGSM allows for the generation

of large amounts of perturbed data samples.

DeepFool (Moosavi-Dezfooli et al., 2016), is an

adversarial attack that follows a different approach

in the example generation process, compared to L-

BGFS and FGSM. The algorithm’s aim is to “escape”

the decision boundaries of a classiﬁer F (for a speciﬁc

data sample x), in order to misclassify the malformed

example x

in a label / class other than the original.

Trained classiﬁers “draw” decision boundaries around

given data samples. By examining these boundaries

(and using DeepFool), an adversary can locate a spe-

DMMLACS 2021 - 2nd International Special Session on Data Mining and Machine Learning Applications for Cyber Security

586

ciﬁc path which will lead a perturbed example x

out

of them, passing to another decision boundary and

therefore leading to misclassiﬁcation. DeepFool is

considered as an efﬁcient adversarial attack.

Jacobian-based Saliency Map Attack (JSMA)

(Papernot et al., 2016a), is another approach of ad-

versarial example generation. The idea is based on

the images’ saliency maps. The algorithm works as

follows: Given a speciﬁc data sample x, a repeti-

tive search takes place for the pixel that impacts the

DNN’s output the most. Then, this pixel is perturbed,

leading the classiﬁer F to falsely classify the gener-

ated x

to a targeted label t. Based on this logic, one

can understand that JSMA’s approach (regarding the

attack scenario) differs a lot, compared to the previous

attacks.

Basic Iterative Method (BIM) & Projected

Gradient Descent (PGD) (Kurakin et al., 2016a)

(Kurakin et al., 2016b), are two very similar attacks

and that is the reason they are often listed together.

Both attacks can be seen as an “expansion” of the

original FGSM. That is because they both utilise

an iterative version of the one-step FGSM model.

Through this repetitive process, carefully selected

noise is applied to a data sample x. A function named

Clip() is also presented, limiting the level of distor-

tion in each repetition. This way, the generated ex-

ample x

is not overly malformed. Both BIM & PGD

algorithms have proven to be better than FGSM, pen-

etrating through DNNs with implemented defenses

against adversarial attacks. The main and actual dif-

ference between the two is that PGD initiates the pro-

cess after selecting a random data sample x (and pro-

ceeding to generate x

), whereas BIM works with a -

speciﬁed by the user - sample x.

Carlini & Wagner’s (C&W) Attack (Carlini and

Wagner, 2017), is a well known and efﬁcient adver-

sarial model. It has proven to be “better” than both

L-BGFS and FGSM, in terms of efﬁciency and at-

tack success over partially robust DNNs. It shares

the same strategy with L-BGFS and that is why it

could be considered as an “expansion” over the clas-

sic L-BGFS (like BIM & PGD with FGSM). The al-

gorithm’s aim is to ﬁnd the least distorted adversarial

example x

, given an original data sample x. At the

same time, a x

with the best score for the targeted la-

bel t is detected. The ﬁnal generated x

is a “balance”

between the least distorted selection and the one with

maximum score to the targeted label t. The main dif-

ference between C&W and L-BGFS is the use of loss

functions in each case. C&W uses a margin loss func-

tion, whereas L-BGFS uses a cross entropy loss func-

tion.

Another white-box attack is the Ground Truth

Adversarial Example Attack, where the Reluplex

algorithm is utilised (Katz et al., 2017). Through the

use of Reluplex, the least distorted adversarial exam-

ple is found. However, the process is not the same

with the ones in L-BGFS and C&W. One more attack

is the Universal Attack (Moosavi-Dezfooli et al.,

2017), where a generic perturbation is found. This

perturbation can be applied to many data samples.

The more samples successfully affected, the better the

generic perturbation. Other attacks are the Spatially

Transformed Attack (Xiao et al., 2018) (distorting

parts of the image data samples through spatial trans-

formation techniques), Poison Frogs (Shafahi et al.,

2018) (poisoning the training dataset with pairs of

malformed data samples x

and original labels y, dras-

tically affecting the correct training process) and the

Real World Attacks (Eykholt et al., 2018) (Atha-

lye et al., 2018) (putting stickers in road signs in

order to trick real-the DNNs in autonomous vehi-

cles, craft 3D printed objects to confuse other real-

time classiﬁers). Other white-box attacks might have

been implemented and proposed / published as well.

However, the aforementioned ones are the most well

known and tested so far.

2.1.2 Black-box Approaches

Moving on to the black box attacks, not much can be

said or written regarding these. That is because, the

primary research ﬁeld seems to be more focused on

white-box attacks and defenses against them. There

might be a good reason for that, stated later on. There

are two main approaches to black-box attacks. First,

there is the Substitute Model Attack (Papernot et al.,

2017). It might as well be the most famous black-box

approach. The steps followed by the adversary are:

1. Compose a substitute training dataset which will

be much like the real one (an effort to gather in-

formation related to the real dataset is needed).

2. Feed the targeted DNN classiﬁer F with the sub-

stitute dataset created. Then, get the results / la-

bels and create a new dataset of data samples /

labels (x, y). Choose a substitute DNN and train it

with the new set of x, y tuples.

3. Augment the new dataset and re-train the substi-

tute DNN classiﬁer F

4. Use white-box adversarial methods to attack the

classiﬁer F

. Gather the most successful attacks

and initiate them to the original targeted DNN.

The steps above are actually the most well-known

way of initiating a black-box adversarial attack. How-

ever, another black-box approach is known as Zeroth

Hoplite Antivirus for Adversarial Attacks: A Theoretical Approach

587

Order Optimisation (Chen et al., 2017). It follows a

different logic and its steps are the following: i) We

assume that the adversary has access to the predic-

tion conﬁdence scores of the targeted classiﬁer F. ii)

Then, these scores are thoroughly examined, in order

to obtain gradient information of F. iii) All the infor-

mation extracted will be used for selecting and initiat-

ing a proper white-box attack. Zeroth Order Optimi-

sation is an interesting black-box approach, but it is

not widely used. However, both attack scenarios have

one main common thing, and that is their ﬁnal step.

Both scenarios end up implementing white-box algo-

rithms, in order to attack a DNN. So, in a few words,

black-box attacks are actually white-box ones, with

the addition of a few steps to get there. This might be

the reason why research groups focus on white-box

attacks and defenses against them. Another approach

is known as Semi-white or Grey-box Attack, which

utilises Generative Adversarial Networks (GANs)

to directly generate adversarial examples. The ad-

versary is supposed to have partial knowledge of the

DNN and its training dataset. Therefore, he/she crafts

adversarial examples from a carefully selected GAN.

2.2 Defenses

It’s time to go through the most “famous” defenses

against adversarial attacks. First, it is worth high-

lighting that the ideal defense would be against white-

box attacks, not black-box ones. That is because,

if a DNN is highly secure against adversaries who

seem to know everything about these, all other attacks

(with lesser pre-existing knowledge) will be of equal

or lower “difﬁculty” levels. If one can create a robust

DNN against white-box techniques, all black-box at-

tacks shall automatically fail. That might be another

reason why the research community’s focus is primar-

ily on defenses and their white-box attacks. Back to

the defenses themselves, they can be divided based on

three main categories. These are: i) Gradient Mask-

ing (the efforts of hiding DNNs gradient information),

ii) Robust Optimisation (making DNNs more robust

against attacks) and iii) Adversarial Examples De-

tection (the efforts of detecting malformed data sam-

ples). Let us analyze these three categories (Ozdag,

2018) (Tram

er et al., 2017) (Chakraborty et al., 2018)

(Xu et al., 2020) (Yuan et al., 2019). . .

2.2.1 Gradient Masking

Starting with Gradient Masking, this category in-

cludes two main defensce strategies. First one is the

Defensive Distillation (Hinton et al., 2015) (Paper-

not et al., 2016b). This strategy is about “distilling” a

training dataset and the result of a DNN classiﬁer F,

using softmax. The steps followed are: 1) Train a net-

work F using a dataset of items and labels (x, y tuples)

and set a temperature value T for softmax. Using a

temperature T , the softmax generated values are af-

fected. 2) Generate and store the scores of F (that

is, the scores after softmax). 3) Train a new model

F2 with the data - scores collected from step 2, using

the same temperature value T for softmax. 4) Initi-

ate the classiﬁcation process for the test set, changing

the temperature T value to T = 1. The result is that,

all data exiting the “distilled” F2 classiﬁer will have

hidden gradient information for the DNNs (mainly

cause of the changes in temperature), which means

that the adversaries will not be able to obtain gra-

dient info from them. The second gradient masking

strategy is called Shattered Gradients. Its about us-

ing a preprocessor, through which all data are passed

before being fed to the network. For example, pre-

processors can crop, compress, increase (or reduce)

the quality of image data samples, etc. This way, the

connection between inputs and outputs becomes un-

clear, something that makes the gradient information

retrieval efforts by adversaries more difﬁcult. The

shattered gradients defense shares many similarities

with the spatial transformation attacks listed above.

Unfortunately, the current gradient masking methods

are not very successful in blocking most attacks. They

might “confuse” the adversary, but only for a while. . .

2.2.2 Robust Optimisation

On to Robust Optimisation, this category’s techniques

can be characterised as the most successful, in terms

of countering adversarial attacks. One such technique

is Regularization. Through this approach, the dis-

torted inputs of a DNN will not have a big impact in

the output, meaning the classiﬁer’s results. “Regular-

izing” the input data samples, malformed adversarial

examples might lose their “power” (since they will be

amongst the regularised data) and, eventually, might

be classiﬁed to the correct classes / labels. So, given

a perturbed example x

which has been subject to reg-

ularisation, it shall probably be classiﬁed to the cor-

rect label y, just like the original x will do. Another

technique is the Adversarial (Re)training. The de-

fenders create adversarial examples (using known al-

gorithms such as FGSM and PGD/BIM) and either

mix them with an existing training dataset, or directly

train the DNN. The trained model is expected to “un-

derstand” future incoming adversarial examples and

classify them as normal data samples. In case of PGD,

the network is trained exclusively with adversarial ex-

amples (FGSM approaches are usually a mix of clean

and perturbed data). Apart from generating adversar-

ial data directly from these algorithms, another way

DMMLACS 2021 - 2nd International Special Session on Data Mining and Machine Learning Applications for Cyber Security

588

is to use malformed samples created through other

DNNs. Using one-step FGSM to attack classiﬁers F1

and F2, the defenders collect the examples x1

and

which succeeded in penetrating them. Then, these

samples are mixed with the original training dataset

of F, hoping that these “proven” adversarial samples

will make it more robust. One last technique is the

Certiﬁed Defenses. The strategy used is the same

with the one found in the Ground Truth Adversarial

Attack. Through speciﬁc algorithms (such as Relu-

plex), a repetitive search takes place, in order to ﬁnd a

circle (generated by a radius r), inside of which all po-

tential x values will be considered as natural. Outside

the circle (values further than the radius r), x values

might be adversarial samples. This way, a “certiﬁ-

cate” is given, for a speciﬁc x neighbour.

2.2.3 Adversarial Examples Detection

Moving on to the third category, Adversarial Exam-

ples Detection, it houses these techniques that aim to

identify adversarial samples before they “enter” the

DNN zone. This can be achieved by the “installa-

tion” of auxiliary neural networks before the main

DNN model, which try to distinguish the adversarial

examples from the normal data. Moreover, a statis-

tic analysis can take place, between normal and per-

turbed data samples. The knowledge extracted can

then be applied to models that distinguish incoming

samples, based on their properties. Last but not least,

another technique is the repetitive process of slightly

modifying the DNN’s parameters, and observation for

substantial changes in the outputs. Maybe, these input

samples that got different labels from the classiﬁer, af-

ter the parameter modiﬁcation process, are malformed

adversarial examples.

3 HOPLITE: AN ANTIVIRUS FOR

ADVERSARIAL ATTACKS

3.1 Looking Back at History

As of today, no efﬁcient solution has been found for a

highly robust deep neural network against adversarial

attacks. All proposed defended seem to be insufﬁ-

cient, providing low levels of robustness (even some-

times little to none, in case the adversary has slightly

modiﬁed his/her samples), or the process seems to be

costly in terms of resources and time. In a few words,

there seem to be no proper defense mechanisms for

DNNs. Is there a way to surpass this issue? Let us ex-

amine the problem from a different viewpoint. Maybe

a lesson can be taught from recent history.

During the 1980s, the computer science research

community started to analyze the potential threats of

computer software, coming from any possible mali-

cious parts of code. It was the beginning of the com-

puter viruses research, which today is considered as

an entirely independent science and research section,

within the boundaries of computer science. However,

almost 40 years ago, computer viruses were mainly

only parts of theoretical scenarios in research publi-

cations and scientiﬁc papers. The community seemed

to be anxious about a potential computer virus out-

break, with many kinds of malicious software pene-

trating thousands of PCs in the future. More specif-

ically, Fred Cohen, a researcher at IBM, published

a demonstration that ”there is no algorithm that can

perfectly detect all possible viruses”. In a way, such

a publication could have made many software engi-

neers even more pessimist, regarding the hopes of

making computers robust and capable of defending

viruses. However, history showed that engineers man-

aged to overcome the rising computer virus issue and,

slowly but steadily, build antivirus systems (such as

antivirus software) capable of detecting the vast ma-

jority of existing viruses.

Today, there is a whole market of antivirus soft-

ware available to consumers. These frameworks tend

to function based on a classic pattern: The user buys

an antivirus software, installs it on his/her personal

computer and then the software proceeds to get daily

security updates over the internet. These updates

contain information about new viruses and any kinds

of data necessary, for the software to provide secu-

rity and robustness to its PC. So, an antivirus soft-

ware provider cares for the distribution of its soft-

ware program, which then must be regularly updated

with newer virus data. This is the pattern on which

most antivirus frameworks are based. What if we

could learn something from the way computer scien-

tists faced the (computer) virus case? Let us keep in

mind the three main open issues of today’s adversarial

defenses:

• Although there are many defense strategies, none

of them applies to multiple attacks at once. Most

of the defenses proposed, appeal to speciﬁc attack

models.

• Many defense methods are costly in terms of time

and computer resources, in order to be applied to

DNNs.

• Adversarial attacks are constantly evolving, mak-

ing the task of robust DNNs creation even more

difﬁcult.

How could these issues be addressed to, considering

how we have dealt (and continue to do so) with com-

Hoplite Antivirus for Adversarial Attacks: A Theoretical Approach

589

puter viruses? All the aforementioned defense models

can be viewed as a State-of-the-Art (related work), re-

garding this paper’s proposal for effectively blocking

adversarial attacks.

3.2 The Hoplite Approach

The idea is simple. What if we could apply the main

antivirus software pattern, to that of the DNNs’ ad-

versarial defense problem? What if we saw the issue

from a different point of view, that of providing pre-

trained and already robust DNNs as software pack-

ages? In a few words, what if we implemented an

antivirus ”model” for adversarial attacks? How can

we achieve that? This is our deﬁnition of antivirus:

A deep neural network, to which multiple defense

strategies will be pre-applied, being pre-trained with

datasets of high data quality and be made available

as software to consumers / users / machine learning

engineers. The DNN will be re-trained in a speciﬁc

frequency / basis with newer adversarial examples

(which were previously unknown) and the users who

have an older version, will be notiﬁed of the newer,

more robust version. The main provider will create

multiple DNN solutions, based on different datasets,

needs and use case scenarios. This way, users will

have the opportunity to select among different kinds

of pre-trained and robust DNNs, based on their needs.

Of course, generating a DNN and applying multiple

defense strategies to it shall take plenty of time, whilst

it shall be resource-greedy. However, since this DNN

will be made available to all consumers globally, the

time and resource issue will actually be eliminated,

since only the main provider will be responsible of it.

So, this is the Hoplite Antivirus Proposal: A se-

ries of pre-trained and robust DNNs, with multi-

ple defense strategies implemented upon them, dif-

ferent dataset base (for different consumer needs)

and constant re-training with newer adversarial

examples. These DNNs will be made available to the

public, as secure software packages, and ready to be

used by users / machine learning engineers. The soft-

ware package’s internal (source code) will be inac-

cessible, assuring security and eliminating white-box

attack scenarios. At the same time, these software

packages will ”play-along” with a series of program-

ming languages, ready to be used by scripts / pro-

grams written in Python, R, Java, etc.

The term ”hoplite” was selected from the ancient

hoplites, ﬁerce Greek soldiers / warriors protecting

their city-states. They were mainly armed with spears

and shields, and their armor protected all the vital

parts of the torso. Usually, the hoplites formed the

Phalanx formation when in combat, making their at-

Figure 1: The Hoplite Antivirus’s architectural concept.

tacks very efﬁcient, whilst being able to effectively

defend themselves against the enemy. In a few words,

a hoplite warrior was able to defend himself prop-

erly and ”do his job” at the same time. In our case,

each pre-trained and robust DNN can be seen as a

standalone hoplite, ready to defend against adversar-

ial attacks and function (classify) properly. The Pha-

lanx of DNN hoplites will be the main DNN provider,

generating different deep neural networks (with mul-

tiple dataset bases) and making them available to con-

sumers, as seen in Figure 1. If, for example, a ma-

chine learning engineer wishes to use a DNN specif-

ically for images of road signs, he/she will select the

most ”tailored” DNN from the main provider. The

provider can even offer services of custom DNN cre-

ation for consumers.

This idea could actually work. History has shown

that using pre-trained software for detecting viruses,

and then constantly updating it with newer virus data,

is an efﬁcient solution against malware. The same

pattern can be applied to the adversarial defense is-

sue. Pre-train deep neural networks, pre-implement

multiple defense strategies and make them available

to the public, then constantly re-train them with newer

adversarial examples. This way, all three main is-

sues mentioned before are being eliminated. First, the

implementation of more-than-one defense strategies

will appeal to many attack models at once. The Ho-

plite main provider will carefully examine the DNNs

training dataset and then choose the best-suited de-

fense algorithms to implement. Second, only the

main provider will face the issue for cost in terms of

time and resources. All consumers will simply get

the DNNs as software packages, at a glance. Third,

evolving adversarial attacks will no longer be an is-

sue, since the Hoplite provider will keep re-training

the deep neural networks with newer adversarial ex-

amples.

DMMLACS 2021 - 2nd International Special Session on Data Mining and Machine Learning Applications for Cyber Security

590

All that is left to do, is focus on studying and re-

searching this approach. It could be a vital solution

to the emerging adversarial attacks’ danger. Taking a

note from the way we dealt with computer viruses and

applying it to the adversarial defense problem, could

be all we ever needed in order to address it. After all,

both computer viruses and adversarial attacks share

the same goal: To invade a system and cause malfunc-

tion(s), based on the attacker’s aim and purpose. In a

way, adversarial attacks are viruses. They can be seen

as viruses of deep neural networks. Then, why not

try to detect them using the same pattern as the one in

the computer viruses’ case? It only seems rational to

test this approach. The Hoplite Antivirus could be a

practical solution to our problem!

4 CONCLUSIONS

This paper brieﬂy presented the most well-known ad-

versarial attacks and defenses to date. It extracted

three main issues that remain unresolved, regarding

the existing adversarial defenses’ efﬁciency. It then

proposed a potential solution, the Hoplite Antivirus

approach. It is based on the same pattern found in the

majority of antivirus software frameworks for com-

puter viruses. The Hoplite Antivirus shall contain a

series of pre-trained DNNs, on which multiple de-

fense strategies will be already implemented. The

DNNs shall constantly be re-trained with newer ad-

versarial examples, in order to be up-to-date with the

evolving attacks. These deep neural networks will be

made available to the public as secure software pack-

ages, ready for use by consumers / machine learning

engineers. Such an approach could end up being vi-

tal towards the (yet) unresolved problem of making

neural networks fully robust and attack-proof.

Study and research are yet to take place, but this

proposal serves as a very good starting point and

guide. The team behind Hoplite shall soon initiate

a full-scale research and testing phase on this pro-

posal. Using high-end physical machines, capable of

performing the resource and time greedy tasks of big

dataset processing, constant (for long time periods)

DNN training & defense techniques applying, the

team aims to monitor the progress and publish the re-

sults of each research / testing stage. A careful selec-

tion of (different kinds of) datasets will be made ﬁrst.

These datasets will be pre-processed and cleaned.

Then, studied DNN architectures will be matched to

the, now train-ready, datasets. After these steps are

completed, multiple combinations of adversarial de-

fenses will be applied to the DNN-dataset sets. This

will be the process of making the DNNs really ro-

bust, no matter how long and resource-consuming it

might be. The ﬁnal phase shall include the transfor-

mation of the DNNs to encrypted & secure packages,

ready for distribution through the net. A better under-

standing of Hoplite proposal’s potential (based on the

team’s work) is expected during 2022. The main goal

is set, and that is to ﬁnd out if the Hoplite Antivirus

approach can indeed be the ultimate solution against

adversarial attacks.

ACKNOWLEDGEMENTS

The research leading to these results has received

funding from the European Commission under the

H2020 Programme’s project ”DataPorts” (Grant

Agreement No. 871493).

REFERENCES

Athalye, A., Engstrom, L., Ilyas, A., and Kwok, K. (2018).

Synthesizing robust adversarial examples. In Inter-

national conference on machine learning, pages 284–

293. PMLR.

Carlini, N. and Wagner, D. (2017). Towards evaluating the

robustness of neural networks. In 2017 ieee sympo-

sium on security and privacy (sp), pages 39–57. IEEE.

Chakraborty, A., Alam, M., Dey, V., Chattopadhyay,

A., and Mukhopadhyay, D. (2018). Adversarial

attacks and defences: A survey. arXiv preprint

arXiv:1810.00069.

Chen, P.-Y., Zhang, H., Sharma, Y., Yi, J., and Hsieh, C.-J.

(2017). Zoo: Zeroth order optimization based black-

box attacks to deep neural networks without training

substitute models. In Proceedings of the 10th ACM

workshop on artiﬁcial intelligence and security, pages

15–26.

Eykholt, K., Evtimov, I., Fernandes, E., Li, B., Rahmati, A.,

Xiao, C., Prakash, A., Kohno, T., and Song, D. (2018).

Robust physical-world attacks on deep learning visual

classiﬁcation. In Proceedings of the IEEE Conference

on Computer Vision and Pattern Recognition, pages

1625–1634.

Goodfellow, I. J., Shlens, J., and Szegedy, C. (2014). Ex-

plaining and harnessing adversarial examples. arXiv

preprint arXiv:1412.6572.

Hinton, G., Vinyals, O., and Dean, J. (2015). Distilling

the knowledge in a neural network. arXiv preprint

arXiv:1503.02531.

Katz, G., Barrett, C., Dill, D. L., Julian, K., and Kochender-

fer, M. J. (2017). Reluplex: An efﬁcient smt solver for

verifying deep neural networks. In International Con-

ference on Computer Aided Veriﬁcation, pages 97–

117. Springer.

Kurakin, A., Goodfellow, I., and Bengio, S. (2016a). Ad-

versarial machine learning at scale. arXiv preprint

arXiv:1611.01236.

Hoplite Antivirus for Adversarial Attacks: A Theoretical Approach

591

Kurakin, A., Goodfellow, I., Bengio, S., et al. (2016b). Ad-

versarial examples in the physical world.

Moosavi-Dezfooli, S.-M., Fawzi, A., Fawzi, O., and

Frossard, P. (2017). Universal adversarial perturba-

tions. In Proceedings of the IEEE conference on

computer vision and pattern recognition, pages 1765–

1773.

Moosavi-Dezfooli, S.-M., Fawzi, A., and Frossard, P.

(2016). Deepfool: a simple and accurate method to

fool deep neural networks. In Proceedings of the IEEE

conference on computer vision and pattern recogni-

tion, pages 2574–2582.

Ozdag, M. (2018). Adversarial attacks and defenses against

deep neural networks: a survey. Procedia Computer

Science, 140:152–161.

Papernot, N., McDaniel, P., Goodfellow, I., Jha, S., Celik,

Z. B., and Swami, A. (2017). Practical black-box at-

tacks against machine learning. In Proceedings of the

2017 ACM on Asia conference on computer and com-

munications security, pages 506–519.

Papernot, N., McDaniel, P., Jha, S., Fredrikson, M., Celik,

Z. B., and Swami, A. (2016a). The limitations of deep

learning in adversarial settings. In 2016 IEEE Euro-

pean symposium on security and privacy (EuroS&P),

pages 372–387. IEEE.

Papernot, N., McDaniel, P., Wu, X., Jha, S., and Swami,

A. (2016b). Distillation as a defense to adversarial

perturbations against deep neural networks. In 2016

IEEE symposium on security and privacy (SP), pages

582–597. IEEE.

Shafahi, A., Huang, W. R., Najibi, M., Suciu, O., Studer,

C., Dumitras, T., and Goldstein, T. (2018). Poison

frogs! targeted clean-label poisoning attacks on neural

networks. arXiv preprint arXiv:1804.00792.

Szegedy, C., Zaremba, W., Sutskever, I., Bruna, J., Er-

han, D., Goodfellow, I., and Fergus, R. (2013). In-

triguing properties of neural networks. arXiv preprint

arXiv:1312.6199.

Tram

er, F., Kurakin, A., Papernot, N., Goodfellow, I.,

Boneh, D., and McDaniel, P. (2017). Ensemble adver-

sarial training: Attacks and defenses. arXiv preprint

arXiv:1705.07204.

Xiao, C., Zhu, J.-Y., Li, B., He, W., Liu, M., and Song, D.

(2018). Spatially transformed adversarial examples.

arXiv preprint arXiv:1801.02612.

Xu, H., Ma, Y., Liu, H.-C., Deb, D., Liu, H., Tang, J.-L., and

Jain, A. K. (2020). Adversarial attacks and defenses in

images, graphs and text: A review. International Jour-

nal of Automation and Computing, 17(2):151–178.

Yuan, X., He, P., Zhu, Q., and Li, X. (2019). Adversar-

ial examples: Attacks and defenses for deep learning.

IEEE transactions on neural networks and learning

systems, 30(9):2805–2824.

DMMLACS 2021 - 2nd International Special Session on Data Mining and Machine Learning Applications for Cyber Security

592
