Trusted Enforcement of Application-speciﬁc Security Policies

Marius Schlegel

TU Ilmenau, Germany

Keywords:

Application Security, Security Architecture, Security-Policy-Controlled Applications, Application-speciﬁc

Security Policies, Application-level Policy Enforcement, Trusted Execution, Intel SGX.

Abstract:

While there have been approaches for integrating security policies into operating systems (OSs) for more than

two decades, applications often use objects of higher abstraction requiring individual security policies with

application-speciﬁc semantics. Due to insufﬁcient OS support, current approaches for enforcing application-

level policies typically lead to large and complex trusted computing bases rendering tamperproofness and

correctness difﬁcult to achieve. To mitigate this problem, we propose the application-level policy enforcement

architecture APPSPEAR and a C++ framework for its implementation. The conﬁgurable framework enables

developers to balance enforcement rigor and costs imposed by different implementation alternatives and to easily

tailor an APPSPEAR implementation to individual application requirements. We argue that hardware-based

trusted execution environments offer an optimal balance between effectiveness and efﬁciency of policy protec-

tion and enforcement. This claim is substantiated by a practical evaluation based on a medical record system.

1 INTRODUCTION

The rigorous and correct enforcement of application-

speciﬁc security goals in today’s complex software

systems is far from being an easy task. In order to pro-

tect the conﬁdentiality and integrity of security-critical

resources (e. g. customer information or accounting

information), such systems increasingly rely on a se-

curity policy: an automatically enforced set of rules

that control evaluating, granting, and revoking access

privileges, control tracing, classifying, and conﬁning

potential ﬂows of information, or control isolating do-

mains of users and resources.

For almost two decades the idea has been pursued

to integrate security policies directly into operating

systems (OSs) (Watson, 2013). The control of opera-

tions on OS objects (resources described by abstrac-

tions such as ﬁles, processes, sockets, etc.) is made

possible by the extension of standard OSs by manda-

tory access control (AC) and information ﬂow control

mechanisms (Loscocco and Smalley, 2001; Smalley

and Craig, 2013; Sze et al., 2014).

At application level, for instance, enterprise re-

source planning systems typically use role-based AC

policies that reﬂect a company’s organizational struc-

ture (Alam et al., 2011; Bhatti et al., 2005), workﬂow

management systems use information ﬂow policies

https://orcid.org/0000-0001-6596-2823

(Crampton et al., 2016; Wang and Li, 2010), database

systems use label-based AC policies to control access

to relations and views (Oracle, 2018; IBM, 2016), (so-

cial) information systems use relationship-based AC

policies on user data (Rizvi et al., 2015; Fong, 2011),

and Big Data and IoT platforms rely on attribute-based

AC policies (Gupta et al., 2018; Bezawada et al., 2018).

Compared to OSs, the objects used by applications

are typically subject of security policies on a higher,

application-speciﬁc abstraction level. This requires

policy rules with application-speciﬁc semantics which

typically differ signiﬁcantly from those at OS level and

which are also speciﬁc for each individual application.

Contemporary OSs do not adequately support

application-speciﬁc security policies. For this reason,

developers often integrate security policies directly

into applications which results in large and heteroge-

neous trusted computing base (TCB) implementations.

Due to the close integration of security-relevant func-

tionality and application logic, the identiﬁcation of an

application’s TCB perimeter is hard if not impossible,

rendering correctness properties difﬁcult to achieve.

To enable precisely deﬁned application TCBs as

well as a rigorous and trusted enforcement of individ-

ual application security policies, this paper argues for

an alternative approach. First, the foundation is laid

by strictly separating security-relevant functionality

from (potentially untrusted) application logic. Second,

Schlegel, M.

Trusted Enforcement of Application-speciﬁc Security Policies.

DOI: 10.5220/0010579703430355

In Proceedings of the 18th International Conference on Security and Cryptography (SECRYPT 2021), pages 343-355

ISBN: 978-989-758-524-1

343

this separation is implemented by an isolation mech-

anism. Adjusting the strength of isolation and the

costs for crossing isolation boundaries, the approach

is open for different isolation mechanisms ranging

from language-based (e. g. type-safe programming lan-

guages and compilers) and OS-based mechanisms (e. g.

virtual address spaces via processes) to trusted execu-

tion technologies (e. g. Intel SGX) (Shu et al., 2016).

In particular, SGX provides trusted execution en-

vironments (TEEs), so-called enclaves, which isolate

security-sensitive parts of application code and data

from the OS kernel, hypervisor, BIOS, and other ap-

plications using a hardware-protected memory region

(Intel Corporation, 2021). While this signiﬁcantly re-

duces the size of application TCB implementations,

crossing isolation boundaries typically imposes high

costs compared to conventional isolation mechanisms

(Weisse et al., 2017). Therefore, we examine its suit-

ability for our approach.

Speciﬁcally, we make the following contributions.

(1.) We introduce APPSPEAR – an application-level

security policy enforcement architecture providing a

functional framework for implementing the reference

monitor principles (Anderson, 1972) (

2). (2.) Bal-

ancing rigor of policy enforcement (effectiveness) and

isolation/communication costs (efﬁciency), we discuss

implementation alternatives for APPSPEAR as well as

the consequences of using different isolation mecha-

nisms (

3.1). We have cast this spectrum of implemen-

tation alternatives into a developer framework, which

highlights the developer support provided. Moreover,

we describe our experiences with the integration of

APPSPEAR into the medical record system OpenMRS

using the developer framework (

3.2). (3.) We present

an evaluation of the APPSPEAR framework based

on our implementation showing the practical runtime

costs imposed by the different implementation alterna-

tives (§ 4).

2 ARCHITECTURE DESIGN

This section introduces APPSPEAR. Its purpose is

to provide a functional framework for the rigorous

enforcement of application-speciﬁc security policies.

In the following, we ﬁrst discuss fundamental security

policy and architecture design principles (

2.1). Based

on those, we describe our architecture, including its

components, their tasks, and interrelationships (

2.2).

2.1 Requirements and Design Principles

Application-speciﬁc Security Policies.

Security poli-

cies are usually well-tailored to their respective appli-

cation domain. While policy rules differ semantically

among different classes of policies, namely AC, in-

formation ﬂow, and noninterference, they all aim at

guarantees towards security properties.

As one of the most prominent policy classes in

practice, we focus on AC policies. Furthermore, to

support a broad range of different model abstractions

(e. g. roles, labels, contexts, risks, relationships, or

attributes in general (Ferraiolo et al., 2007; Biswas

et al., 2016; Shebaro et al., 2014; Ni et al., 2010; Fong,

2011; Jin et al., 2012)), we consider an AC policy from

the perspective of the enforcement mechanisms as a

black box of rules. These rules authorize any opera-

tion

op ∈ OP

(e. g. read from or append to electronic

patient record (EPR) objects) related to a vector of

entities

e = (e

)

i=1

∈ E

(e. g. application users, EPRs

or documents). The interface of an AC policy

can be

deﬁned as a semantically neutral AC function (ACF)

: E

× OP → {true, false}

. For example within an

EPR management system, appending new checkup

results to a patient’s EPR could then by requested by

(hAlice, EPR

Bob

i, append).

In recent years, research rendered a number of

modeling schemes for context-aware AC policies that

model adaptive authorization decisions based on phys-

ical or logical features, represented by local context

variables. Values of such variables may be either com-

puted, e. g. time, date, and resource usage, or perceived

by sensors, e. g. temperature, geolocation, and NFC

device proximity (Hsu and Ray, 2016; Shebaro et al.,

2014). By considering a vector of context values

v =

)

j=1

∈ V

(e. g. time or geolocation) additionally to

, the interface of a context-aware AC policy

can

be deﬁned by an ACF

: E

×V

× OP → {true,

false}

. These context values may be input for a risk

evaluation metric (as typically used in risk-based AC

models) which may calculate a numerical value (Ni

et al., 2010). In the simplest case, this value is com-

pared with a risk-threshold to assess the risk as either

acceptable (permitting the original access request) or

unacceptable (denying the original request).

Reference Monitor Principles.

In general, security

policies are part of a system’s TCB. Subsequently, we

consider a TCB from a functional perspective as the

set of all functions that are necessary and sufﬁcient for

implementing a system’s security properties. The part

of a software architecture that implements the TCB

forms the security architecture.

For more than four decades, the reference monitor

principles (Anderson, 1972) have provided fundamen-

tal guidelines for the design and implementation of

security architectures. These principles include three

rules requiring a security architecture core (referred to

SECRYPT 2021 - 18th International Conference on Security and Cryptography

344

as reference monitor) that is (1.) inevitably involved

in any security-related interaction (RM 1, total media-

tion), (2.) protected from unauthorized manipulation

(RM 2, tamperproofness), and (3.) as small and sim-

ple as possible in terms of functional complexity and

amount of code (RM 3, veriﬁability).

According to RM 1, it must be guaranteed that

any actions on security-relevant objects are inevitably

controlled by the policy. In case of security-policy-

controlled OSs, this is achieved by calling the policy

within the OS kernel services (e. g. process manage-

ment, ﬁlesystem, or I/O subsystem) before the actual

execution of any action (e. g. fork, read, or send) on

an OS object (i. e. a resource described by abstractions

such as processes, ﬁles, or sockets) (Smalley et al.,

2001). At the application level, RM 1 can be achieved

by the separation of any functions relevant to the policy

enforcement and the application object management,

on the one hand, from functions solely responsible

for the application logic, on the other hand. Conse-

quently, any security-relevant object and any function

for accessing such an object belong to the TCB. If an

application object is accessed by an application logic

function, an immediate entry into the TCB takes place.

Accordingly, by calling the security policy before any

security-relevant object access within the TCB bound-

aries, the policy cannot be bypassed.

Moreover, the precise delineation of the TCB paves

the way for protecting the integrity of an application

security policy from unauthorized manipulation (cf.

RM 2). The functional separation is implemented by

isolation mechanisms (Shu et al., 2016), which, de-

pending on the assumed attacker model and the degree

of tamperproofness required, range from language-

based isolation (e. g. policy execution in a class in-

stance separated by type-safety-checking compilers) to

OS-based isolation (e. g. policy execution in a separate

virtual address space) and virtualization techniques

(e. g. policy execution in a virtual machine), as well as

hardware-based isolation (e. g. policy execution in an

SGX enclave) to total physical separation (e. g. policy

execution on a dedicated server).

By adapting RM 3, it generally holds that the

smaller a TCB’s functional perimeter and the lower

its complexity, the better a TCB can be analyzed re-

garding correctness properties. A precise functional

perimeter reduces TCB size and complexity because

the functions solely associated with the application

logic are no longer part of the TCB. Furthermore, to

facilitate the veriﬁability of certain parts of the TCB,

in particular security policies, w. r. t. model proper-

ties, such as dynamic state reachability in dynamic AC

models (Stoller et al., 2011; Tripunitara and Li, 2013;

Schlegel and Amthor, 2020; Schlegel and Amthor,

2021), an additional separation within the TCB bound-

aries of policy-speciﬁc from policy-independent TCB

functions should be anchored within the architecture.

Application Layer

OS/Kernel Layer



PEP



TOM

Resource

Application



PDP



TPS



PIP



Policy



EPP



TEP

System Call Interface



PEP



Kernel Service



PDP



Security Server

Resource



PIP



Policy

Call

Result

Enforcement

Call

Result

Update

Query

Call

Result

Request

Decision

Call

Result

Access

Event Trigger

Context

Enforcement

Update

Query

Request

Decision

Figure 1: Functional architecture for mutually independent policy enforcement on application layer (APPSPEAR) and OS layer

(SELinux/Flask).

Trusted Enforcement of Application-speciﬁc Security Policies

345

2.2 APPSPEAR Design

An important representative of security architectures

that implements the reference monitor principles is

the Flask security architecture (Spencer et al., 1999).

Motivated by enabling the ﬂexible interchangeability

of security policies, the policy logic, referred to as

policy decision point (PDP), is separated from the pol-

icy enforcement, distributed over policy enforcement

points (PEPs). This key idea has been adopted by

SELinux (Loscocco and Smalley, 2001), extending

the Linux kernel by mandatory AC, and followed by

a wide range of OSs (Watson, 2013). The SELinux

architecture comprises PEPs located in the OS kernel

services (referred to as object managers) and a singu-

lar PDP (referred to as security server) providing an

OS security policy runtime environment (see Fig. 1).

Comparing Flask’s/SELinux’ objective of rigorous

and ﬂexible policy enforcement on OS level with ours

for the application level, we argue to adapt these princi-

ples. The general idea is to instantiate Flask/SELinux-

alike architecture components for each policy-con-

trolled application which complement the architecture

(and policy) at the kernel level. This idea is illustrated

in Fig. 1. Moreover, we consider state of the art in

the enforcement of context-/attribute-based AC poli-

cies as represented by the Policy Machine (Ferraiolo

et al., 2015) and its successor, Next-Generation Access

Control (NGAC) (Ferraiolo et al., 2016).

Trusted Object Managers.

In order to implement

our architecture at the application level according to

the discussed design principles, in general, a separation

between security-relevant functionality and security-

irrelevant application logic is required. Trusted ob-

ject managers (TOMs) are architecture components to

rigorously isolate trusted and non-trusted application

parts and comprise all functions which are required for

establishing authenticity, integrity, and conﬁdentiality

of application objects.

Consequently, a TOM provides an encapsulated

object access interface for actions such as reading or

modifying security-relevant application objects (e. g.

patient record objects or customer record objects).

This interface is implemented by local or remote pro-

cedures, functions, or methods. Inspired by object-

oriented software design, a generic TOM provides a

generic object abstraction and abstract basic functions

for its management, such as create, read, write, and de-

stroy. For a concrete application, type-speciﬁc TOMs

have to be derived from that generic TOM, which im-

plement the abstract object and functions according

Since we focus on policy enforcement, we omit a policy

administration point as an entry point for administration.

to the type of object. Hence, a separate TOM is im-

plemented for each object type analogous to the OS

kernel services acting OS object managers.

When an application requests to perform a particu-

lar action on a TOM-managed object, the correspond-

ing application security policy is immediately involved

through the interface between a TOM and the trusted

policy server (TPS). In this way, (1.) any security-rele-

vant subject-object interaction is inevitably controlled

by the policy and (2.) decisions can be enforced tam-

perproof, because the TOMs are part of the TCB and,

thus, are isolated from the untrusted application logic.

Finally, depending on the granted or denied access, the

corresponding output of the object access is returned

to the calling application logic function.

For many applications, it is practically inevitable to

use OS objects in addition to the application-speciﬁc

ones. Actions on OS objects are controlled by the

OS security policy, if present. Scattering application

policy rules on both OS and application layers would

contradict the TCB properties we aim for. Further-

more, if there is no OS policy present, such accesses

would not be controlled at all. To maintain the respon-

sibility of application policies and to not require an OS

policy for each object type an application uses, a sim-

ple wrapper for OS objects in form of a separate TOM

is established. To reduce development effort, these

may be reused (or generated automatically) based on

a reference implementation. These TOMs may also be

used by other TOMs to control accesses to OS objects

and system calls at the application level.

In order to ensure the authenticity of application

objects appearing as policy entities, TOMs are respon-

sible for managing entity identiﬁcations (comparable

with SELinux security identiﬁers) and for assigning

them correctly as well as irrevocably to their imple-

mentations as runtime or persistent application objects

such that they can be clearly identiﬁed at any time.

If we isolate architectural components from each

other according to the design principles discussed in

2.1, the communication between these components

requires the crossing of isolation boundaries, which

in turn causes certain costs depending on the type

of isolation (e. g. IPC when isolating via virtual ad-

dress spaces). To reduce those costs, for instance for

the communication of TOMs and the TPS, a caching

mechanism may be used for policy decisions, simi-

lar to the SELinux access vector cache. However, it

should be noted in particular that when implementing

a stateful application policy, it may be necessary to

explicitly manage cache consistency by invalidating

cached access decisions which may become invalid

due to policy state changes.

SECRYPT 2021 - 18th International Conference on Security and Cryptography

346

Trusted Policy Server.

The TPS represents

APPSPEAR’s PDP. Its main task is to provide a policy

runtime environment including data structures that

represent any policy abstractions and components.

Because of the wide range of different modeling

schemes for application policies, it is not reasonable

to limit the TPS to speciﬁc implementations. In

contrast, providing the TPS with a wide range of

model implementations would lead to a universal

range of functions, which counteracts the principle of

a small TCB perimeter.

Here, the approach is to support exclusively the

present policy and to provide only functions necessary

for that policy. Therefore, a policy implementation is

speciﬁcally tailored to its application while maintain-

ing the interfaces for TOM-to-TPS and TPS-to-TOM

communication. To reduce the implementation effort,

developer support is provided in the form of TPS li-

braries implementing the data structures and function-

ality of frequently used security models. Beyond that,

we aim to extend developer support even further: By

providing a convenient policy speciﬁcation language

(Amthor and Schlegel, 2020) and a compiler to gen-

erate policy-speciﬁc TPSs, the effort is reduced to the

speciﬁcation of policy rules.

Finally, to deal with application and system fail-

ures, crashes, or reboots, the TPS comprises functions

for the persistent and secure storage of the policy’s

state. Depending on the required guarantees, different

strategies (e. g. logging diffs, complete state backups,

etc.) are applied at different points in time (e. g. ﬁxed

times, after each state change, etc.).

Trusted Event Processor.

The trusted event proces-

sor (TEP) is an optional add-on to provide context-

based security policies information about the physical

and logical context of a system according to their in-

terface (cf.

2.1). The TEP may be implemented

based on asynchronous triggers instead of function

calls, which may originate from local hard- and soft-

ware components, e. g. GPS, clock, or temperature sen-

sors, typically implemented by an OS interrupt mecha-

nism. Any access decision of the TPS may also trigger

an event that is needed for logging and auditing.

3 ARCHITECTURE

IMPLEMENTATION

APPSPEAR provides a functional framework for im-

plementing the reference monitor principles at the ap-

plication layer. The ﬂexibility of APPSPEAR enables

the separation of its architecture components and their

implementation by means of isolation mechanisms in

a variety of ways.

3.1 discusses multiple architecture

instantiation alternatives and their individual charac-

teristics regarding application TCB size. Each variant

has, on the one hand, a certain degree of possible rigor

in terms of TCB isolation (effectiveness) and, on the

other hand, certain costs in terms of required resources

and communication effort for crossing isolation bound-

aries (efﬁciency). To implement these instantiation

alternatives, a selection of isolation mechanisms and

developer support provided by a conﬁgurable devel-

oper framework are discussed.

3.2 then describes a

practical case study integrating APPSPEAR into the

electronic medical record system OpenMRS.

3.1 Balancing Effectiveness and

Efﬁciency

Architecture Instantiation.

APPSPEAR’s design

provides different alternatives for instantiating and im-

plementing its components. Fig. 2 shows reasonable

variants illustrating boundaries at which the architec-

ture components may be isolated from one another.

Since the TEP realizes parts of the implementation of

context-based security policies (e. g. risk analysis and

estimation), TPS and TEP are explicitly not isolated

from each other.

If a large application TCB comprising the po-

tentially untrusted application logic as well as all

APPSPEAR components (see Fig. 2a), then the im-

plementation is both in terms of strictness and costs

at the level of application-integrated security policies.

From a qualitative point of view, APPSPEAR enables

a structured software engineering of applications to be

equipped with individual security policies.

Beyond this simple low-cost but low-quality imple-

mentation, APPSPEAR supports several alternatives

with greater effectiveness. Taking advantage of the

functional encapsulation of the TPS and the TEP, the

security policy and its runtime environment can be im-

plemented isolated from the rest of the application (see

Fig. 2b). This paves the way for a tamperproof – natu-

rally depending on the strength of the used isolation

mechanism – and analyzable policy implementation.

In quantitative terms, compared with the previous al-

ternative, the application TCB comprises still the same

set of functions, but here, the policy integrity is pro-

tected by more effective isolation.

A further qualitative improvement of the effective-

ness is achieved by also isolating the TOMs as part

of the application TCB from the untrusted applica-

tion (see Fig. 2c). The isolation boundary between

the TOMs and the TPS/TEP is moved between the

untrusted application logic and the TOMs. This re-

Trusted Enforcement of Application-speciﬁc Security Policies

347

sults in a smaller application TCB perimeter because

only security-relevant functions are part of the TCB.

From a conceptual perspective, the costs are compara-

ble to the second variant (see Fig. 2b) due to a single

isolation border and an equally frequent crossing of

the TCB boundary. Nevertheless, the software engi-

neering effort that is required for existing software

architectures to create the technical prerequisites, i. e.

a well-deﬁned interface between untrusted application

logic and TOMs, is also relevant when considering the

isolation of TOMs. Since many applications typically

use a database system and access stored object data,

there is often already a functionally separated object

management as intended by TOMs, which puts the

costs into perspective at this point.

The example of an application utilizing a database

already shows that due to the size and complexity of

today’s application TCBs and, consequently, the high

veriﬁcation effort, not the entire TCB can always be

proven to be correctly implemented using conventional

methods. Analogous to the principle of separate server

processes in microkernel-based OSs, the TPS can be

isolated as an essential part of the TCB from the rest of

the TCB (see Fig. 2d) for security and robustness rea-

sons (e. g. preventing unintended changes to the policy

data structures due to reference errors). Thus, correct-

ness properties of the security policy can be analyzed

easier by formal models and methods (e. g. security

properties such as right proliferation (safety) in dy-

namic AC models). This qualitative improvement also

implies additional costs, since isolation mechanisms

are used at two borders and these have to be overcome

in a controlled manner for each policy request.

Isolation Mechanisms.

In order to get beyond the

weak security guarantees of application-integrated se-

curity policies (cf. Fig. 2a), harder measures are nec-

essary. Based on the classiﬁcation of isolation mech-

anisms in (Shu et al., 2016), we select and discuss

the implementation of APPSPEAR (cf. Fig. 2b – 2d)

by means of two mechanisms that go beyond purely

software-based, intra-application-enforced isolation.

At the OS level, the virtual memory management

provides one of the most fundamental isolation mecha-

nisms. Each process has its own private virtual address

space so that the memory of executed programs is

isolated. This allows not only to allocate memory

resources as optimally as possible according to pro-

cesses’ needs, but also to avoid the propagation of

errors, faults, and failures to other processes or the

entire system. Furthermore, even if a process is com-

promised, the adversary cannot breach the security of

other processes without extensive efforts. By isolat-

ing the APPSPEAR components from the potentially

untrusted application logic and each other using vir-

tual address spaces via processes as in Fig. 2b – 2d,

vulnerabilities of the untrusted application part can

no longer affect the trusted parts. To enable commu-

nication across process boundaries, communication

mechanisms controlled by the OS are necessary, such

as local domain sockets, messages queues, pipes etc.

Beyond that, Intel SGX enables applications to

protect private code and data from privileged system

software such as the OS kernel, hypervisor, and BIOS

as well as other applications. To achieve this, SGX

uses protected TEEs called enclaves. An enclave is a

protected area within an application process’s address

space. To meet integrity and conﬁdentiality require-

(a)



PEP



TOM

Untrusted

Application Logic



PDP



TPS



EPP



TEP

(b)



PEP



TOM

Untrusted

Application Logic



PDP



TPS



EPP



TEP

(c)



PEP



TOM

Untrusted

Application Logic



PDP



TPS



EPP



TEP

(d)



PEP



TOM

Untrusted

Application Logic



PDP



TPS



EPP



TEP

Figure 2: APPSPEAR instantiations with different separation/isolation of the architecture components.

SECRYPT 2021 - 18th International Conference on Security and Cryptography

348

ments, protected application code is loaded into an

enclave after measuring using hardware-based attesta-

tion, and enclave data is automatically encrypted when

leaving the CPU package into memory. Consequently,

this design signiﬁcantly reduces the TCB to only code

executed inside the enclave (as well as the CPU, which

in the end must always be trusted).

Since enclave memory cannot be read directly from

outside of an enclave, data, which needs to be passed

between trusted and untrusted application parts, has to

be copied explicitly from and to an enclave. The SGX

SDK provides mechanisms to create corresponding

bridge functions, ecalls, which dispatch enclave en-

try calls to corresponding functions inside the enclave

deﬁning an enclave’s interface. Corresponding func-

tions that reside in the untrusted application part are

called ocalls and invoked inside the enclave to request

services outside of the enclave (e. g. system calls).

Software Framework and Developer Support.

The implementation of APPSPEAR is supported by a

software developer framework. As discussed, trusted

execution mechanisms provide a promising basis for

the trusted enforcement of application security poli-

cies. Speciﬁcally, we include support for Intel SGX

due to its popularity and availability in current Intel

CPUs. Since the ofﬁcial SDK is only available in

C++, we implemented the framework in C++ as well.

Our APPSPEAR developer framework comprises the

following features: (1.) transparent and ﬂexibly conﬁg-

urable isolation according to the APPSPEAR instantia-

tion variants and the selection of isolation mechanisms

discussed,

(2.) transparent and ﬂexibly conﬁgurable

communication via proxy objects, (3.) transparent re-

duction of communication effort via in-proxy caching.

The key idea for implementing these features lies

in an RPC/RMI-alike communication model: Any

communication between the components of a policy-

controlled application is handled via pairs of proxy

objects, similar to stubs known from RPC/RMI im-

plementations. Those proxies act as intermediaries

representing the callee on the caller side and the caller

on the callee side. Consequently, any communication

handled by these proxies is be performed transparently,

so that the consideration of isolation-mechanism-spe-

ciﬁc needs is not required to be considered by devel-

opers, such as the serialization of application-speciﬁc

data structures and accordingly their deserialization.

In addition, techniques for securing communication,

such as encryption, hashing, or integrity certiﬁcates,

and reducing communication effort, such as caching

Note that the framework implementation is conceptually

not limited to this selection and can be easily extended.

of access requests and corresponding decisions, are

transparently integrated into proxies.

The developer framework provides a set of re-

quester/responder proxy pair implementations, one

for each APPSPEAR component taking the speciﬁc

characteristics of each isolation and corresponding

communication mechanism into account:

•

language/compiler-based isolation and communi-

cation via local procedure/function/method calls,

•

process-based isolation and IPC-based communi-

cation via local domain sockets

, and

•

TEE-based isolation via SGX enclaves and

boundary-crossing communication (ecalls/ocalls).

For implementing the APPSPEAR components, base

classes provide basic functionality (according to

2.2

and abstract member objects for proxy-based commu-

nication. Concrete implementations are derived from

those base classes where their instantiation also conﬁg-

ures the particular isolation and communication mech-

anisms to be used, which is usually done at compile

time. Alternatively, to be able to compare different

implementation variants (e. g. for testing purposes),

the conﬁguration can be done ﬂexibly at runtime.

In order to reduce communication effort and mul-

tiple processing of the same inputs, caching mecha-

nisms can be used. In principle, caching is possible

for (1.) application-logic-to-TOM communication, and

(2.) TOM-to-TPS communication.

Since the applica-

tion logic is assumed to be untrusted, caching of TOM

calls and results on the application logic side coun-

teracts our goals for rigorous and trustworthy policy

enforcement. Nevertheless as argued in

3.1, many

applications use databases to store application objects

such that DBMS caches can achieve an overhead re-

duction when retrieving application object data.

Caching of TPS requests and decisions on the TOM

side avoids multiple identical requests (if the policy

has not changed compared to the initial request) and

reduces the runtime overhead to the level of local func-

tion/method calls – especially for implementation vari-

ants with stricter TPS/TEP isolation (see Fig. 2b and

2d). To also keep access times to cache entries as low

as possible, the cache is implemented using a container

organized based on a hash table. If, in the case of a

stateful policy, the execution of an operation results

in the modiﬁcation of the policy state (Schlegel and

Sockets were chosen based on the out-of-the box com-

promise of ﬂexibility (in terms of message content/size),

performance, simplicity, and availability in commodity OSs.

Communication between the TPS and the TEP is asyn-

chronous based on callbacks or periodic updates (see

2.2).

Since received context values are temporarily stored anyway,

a separate cache is not useful here.

Trusted Enforcement of Application-speciﬁc Security Policies

349

Amthor, 2020; Schlegel and Amthor, 2021), it may be

necessary to invalidate corresponding cache entries.

3.2 Case Study: OpenMRS

This section describes a case study in which we apply

the APPSPEAR framework to an existing database-

backed application. The studied subject is OpenMRS,

an electronic medical record (EMR) and medical infor-

mation management system (OpenMRS Inc., 2021a).

OpenMRS is an optimal representative for a policy-

controlled application since the AC policy is part of its

architecture and directly visible in the source code.

Software and Security Architecture.

OpenMRS

aims at being adaptable to resource-constrained en-

vironments such as healthcare facilities of low-income

countries (Wolfe et al., 2006). This motivation is re-

ﬂected in the web application architecture consisting

of three logical layers: (1.) the UI layer, providing

the user interface with input and query forms, (2.) the

service layer, implementing the basic functionality,

data model interaction, and a corresponding API, and

(3.) the database layer, realizing the data model.

A tightly integrated role-based AC (RBAC) policy

is responsible for controlling accesses to application

objects such as EMRs or medication plans. The pol-

icy semantics are similar to the RBAC model family

(Ferraiolo et al., 2007): a logged-in user’s accesses to

objects are regulated according to her assigned and ac-

tivated roles (e. g. physician or nurse), to which certain

permissions for actions are assigned (e. g. read/modify

EMR or create/delete patient).

RBAC policy and enforcement are implemented

through an AOP mechanism (

AuthorizationAdvice

)

that wraps each service layer method call with a policy

call, and custom Java annotations (“

@Authorized

”)

which initiate checking the privileges of the currently

authenticated user. Since required permissions are di-

rectly attached to each service layer method, the policy

is hard-coded and distributed over 635 points (Open-

MRS core version 2.3.1). This renders the policy as

well as its underlying model static, contradicting the

goal of simple adaptability and ﬂexible conﬁgurabil-

ity. Beyond that, policy decision and enforcement

functionality are isolated from application logic only

via language-based mechanisms and, thus, misses the

opportunity of using stronger isolation.

Applying the APPSPEAR Framework.

While

OpenMRS is implemented in Java, the ofﬁcial SGX

SDK and the APPSPEAR developer framework are

implemented in C++. Therefore, for the scope of this

study, we decided to prototype OpenMRS in C++.

While the basic software architecture is the same,

few functional differences exist. On the UI layer, we

have implemented a minimal command line interface

for requesting service layer functionality. On the ser-

vice layer, we have implemented a selection of core

services for data model interaction: the (system) user

service (login, activate/deactivate role, logout), the

person service (create/delete person object, get/set ad-

dress), and the patient (EMR) service (create/delete

patient object, get/set patient diagnosis), each derived

in an OOP manner from an abstract service class. On

the database layer, SQLite (Hipp et al., 2020) is used

as relational DBMS because of its ability to fully store

a database in-memory enabling its trusted execution

within an SGX enclave. We modiﬁed SQLite version

3.32.3 for in-enclave execution by wrapping system

calls through trampoline functions that temporarily

exit an enclave (ocalls) or, where possible, by an SGX-

compatible variant provided by the SDK.

Each service forms a TOM and manages its own

objects (users, patients, EMRs, etc.) stored in the

database and provides corresponding operations on

them (generally such as create/destroy object and read/

modify object attribute). When using the communica-

tion proxies provided by the developer framework, op-

erations on TOM-managed objects called within the UI

layer are transparently forwarded to the proxy counter-

part of the respective TOM; depending on the isolation

mechanism used, either via function/method calls, lo-

cal domain socket send/receive (IPC) or SGX enclave

calls. An analogous pattern applied for the TOM-to-

TPS communication initiates requests to the RBAC

policy regarding access permission or denial for each

TOM operation to be executed. The TPS realizes the

security policy by means of either a database or, lead-

ing to a smaller TCB, model-tailored data structures.

4 EVALUATION

The evaluation addresses the practical feasibility of the

application-level policy enforcement approach. We

compare the different architecture instantiation alter-

natives in terms of their runtime performance. Each

alternative is implemented by conﬁguring our devel-

oper framework to use each of the following isolation

mechanisms: (1.) language/compiler-based isolation

serving as a baseline, (2.) process-based isolation as

a basic OS-level mechanism, and (3.) SGX/enclave-

based isolation as a widely available trusted execution

mechanism. Subsequently,

4.1 describes the evalua-

tion method and § 4.2 discusses the results.

SECRYPT 2021 - 18th International Conference on Security and Cryptography

350

4.1 Evaluation Methodology

Test Cases.

We study two test cases: A basic appli-

cation with an always-allow AC policy highlights the

baseline for the runtime to be considered for isolation

and communication in each architecture implemen-

tation variant (baseline microbenchmark). The ap-

plication only comprises a single synthetic operation

passing an operation identiﬁer (required to determine

the minimum costs). The prototypical reimplementa-

tion of OpenMRS comprising an RBAC policy (see

3.2 for details) serves as a real-world use case. In

particular, the layered software architecture and the

usage of a database are representative for a multitude

of applications and yields an impression of potential

costs also relevant for other scenarios. The database

provided by the OpenMRS community comprises an

anonymized data set of 5,000 patients and 500,000

observations (OpenMRS Inc., 2021b).

We run two types of benchmarks: four microbench-

marks show efforts for typical create, read, update, and

destroy (CRUD) operations, whereas a mixed mac-

robenchmark based on an OpenMRS workload ex-

tracted from logs (Chen et al., 2019) (called “Action”

there) puts the execution of individual operations into

a bigger context. Our adapted workload assumes the

following occurrences of patient service CRUD opera-

tions: 25 % of create patient, 38 % of read patient di-

agnosis, 12 % of update patient diagnosis, and 25 % of

delete patient. The individual operations appear mixed

over the entire execution. For comparability reasons,

the measured runtimes are divided by 100 (number of

executed operations within the macrobenchmark).

Since especially enclave-based isolation involves

high communication costs, we have also implemented

and evaluated two techniques for decreasing runtime

overhead: (1.) caching of policy decisions in TPS

proxies located in the TOMs (see

3.1) and (2.) asyn-

chronous enclave calls (Weisse et al., 2017) which are

provided by the SGX SDK as switchless calls because

they do not involve costly enclave switches.

Metrics and Measurements.

The runtimes are mea-

sured in CPU clock cycles by using the RDTSCP in-

struction. To avoid the typical behavior of “cold” CPU

caches, each measurement is preceded by a warm-

up phase of 1,000,000 iterations. To ﬁlter out po-

tential outliers, we perform 1,000,000 iterations for

each measurement and calculate medians. All mea-

surements were performed on desktop hardware with

an Intel Core i7-7700K CPU at 4.2 GHz and 32 GiB

DDR4 RAM at 2,400 MHz. The machine runs Ubuntu

18.04.4 LTS with Linux kernel 5.3.0 including mitiga-

tions for critical CPU vulnerabilities. We use the Intel

SGX driver, SDK, and platform software in version

2.7.1 (Intel Corporation, 2019). We compile using

GCC 9.2, SGX hardware mode, and SGX SDK Prere-

lease conﬁguration known to have production enclave

performance (Johnson et al., 2016). The Enclave Page

Cache (EPC) size is set to the maximum of 128 MiB of

which ca. 93 MiB are usable. During all experiments,

we disable dynamic CPU frequency scaling, Turbo

Boost, and Hyper-Threading to avoid erratic runtime

behavior and reduce potential outliers, by adjusting

scheduling priorities and interrupt afﬁnities.

4.2 Evaluation Results

Figs. 3a – 3d show the measurement results. The imple-

mentation variants (x-axis) are labeled according to the

type of isolation/communication between (1.) applica-

tion logic and TOMs, and (2.) TOMs and TPS/TEP. In

each subﬁgure, absolute runtimes are illustrated in the

upper part (unit

clock cycles on the left y-axis, unit

microseconds calculated for the Intel i7 CPU with 4.2

GHz on the right y-axis) and in the lower part the rela-

tive runtime overhead compared to the fully integrated,

intra-application implementation of APPSPEAR. The

error bars show 95 % conﬁdence intervals.

First of all, Fig. 3a illustrates the results of the

baseline microbenchmarks showing the runtime of

each of the considered unoptimized APPSPEAR im-

plementations. Each variant requires at least a relative

runtime overhead of more than 2 orders of magni-

tude compared to the intra-application implementation

of APPSPEAR. Due to isolation and communication

effort occurring twice in the IPC/IPC and IPC/SGX

variants, the costs are also about twice as high com-

pared to the single process- and SGX-isolated variants

(ca. 30k cycles vs. ca. 55k/60k cycles).

Considering the CRUD microbenchmarks, in the

LPC/LPC implementation, the read operation requires

only about half of the runtime of create, update, and

destroy operations (ca. 10,5k cycles vs. 18,2k/21,5k/

25,8k cycles) because no changes to application ob-

jects stored in the database are made. Using process-

based isolation in the LPC/IPC, IPC/LPC, and IPC/IPC

implementation variants, the results are comparable

considering the costs for isolation and communication.

The LPC/IPC and IPC/LPC variants yield a similar

level of runtime overhead, while the IPC/IPC variant

has an increased amount of additional overhead due

to isolation using two separate processes which nev-

ertheless does not double the costs due to a compact

small-volume TOM-to-TPS communication.

While for the same reason, the SGX-based isola-

tion of the TPS/TEP (LPC/SGX variant) has a runtime

overhead comparable with the LPC/IPC variant, the

Trusted Enforcement of Application-speciﬁc Security Policies

351

SGX/LPC variant highlights that the joint isolation

of TOMs and TPS/TEP, and the resulting in-enclave

code execution can lead to a considerable additional

overhead beyond pure isolation/communication costs:

The approximately twice as high runtime effort results

from the execution of SQLite within the isolated en-

clave, since temporary enclave exits (ocalls) may occur

several times (see also § 3.2).

The hybrid IPC/SGX variant shows a middle way

solution in terms of rigor and costs compared to the

previously discussed variants: TOMs are separated

from the application logic by process-based isolation

and only the TPS/TEP is completely trusted through

isolation via SGX. Although the baseline overhead is

the highest in the ﬁeld of comparison, the CRUD mi-

crobenchmark results rank between the IPC/IPC and

SGX/LPC variants because SQLite is executed in a

regular process. Moreover, the macrobenchmark re-

sults ﬁt into the picture of results drawn so far. The

runtimes for the CUD operations in favor of the R oper-

ation are relativized in all APPSPEAR implementation

variants according to a real-world workload.

In order to reduce the runtime overhead (especially

caused by communication), we have implemented and

evaluated two techniques for runtime reduction, whose

impact we will now discuss: caching of policy requests

and decisions within TOMs (see Fig. 3b) as well as

SGX switchless calls (see Fig. 3c). The runtimes of

cache-optimized APPSPEAR implementations assume

caches already ﬁlled with corresponding entries (done

in measurement warm-up).

It can be seen in Fig. 3b that especially those im-

100

150

LPC/LPC

LPC/IPC

LPC/SGX

IPC/LPC

IPC/IPC

IPC/SGX

SGX/LPC

Relative Runtime Overhead / Runtime (10

Clock Cycles)

(a)

Runtime ( s)

LPC/LPC

LPC/IPC

LPC/SGX

IPC/LPC

IPC/IPC

IPC/SGX

SGX/LPC

(b)

100

150

LPC/LPC

LPC/IPC

LPC/SGX

IPC/LPC

IPC/IPC

IPC/SGX

SGX/LPC

Relative Runtime Overhead / Runtime (10

Clock Cycles)

(c)

Runtime ( s)

LPC/LPC

LPC/IPC

LPC/SGX

IPC/LPC

IPC/IPC

IPC/SGX

SGX/LPC

(d)

Baseline Microbenchmark

Create Patient Microbenchmark

Read Patient Diagnosis Microbenchmark

Update Patient Diagnosis Microbenchmark

Delete Patient Microbenchmark

Normalized Mixed Macrobenchmark

Figure 3: Benchmarking results: (a) standard/unoptimized implementations, (b) implementations optimized by caching,

SECRYPT 2021 - 18th International Conference on Security and Cryptography

352

plementation variants that separate the TPS/TEP from

TOMs via process- or SGX-based isolation (LPC/IPC,

LPC/SGX, IPC/IPC, and IPC/SGX implementation

variants) beneﬁt from this measure: A cache hit ef-

fectively results in a signiﬁcant reduction of the run-

time overhead by eliminating IPC or enclave-boundary

crossing. For the LPC/IPC and LPC/SGX variants, the

runtime is reduced to the level of the intra-application

implementation (LPC/LPC variant) and for the IPC/

SGX and IPC/IPC variants to the cost level of IPC/

LPC. For all other implementation variants (IPC/LPC,

IPC/IPC, and SGX/LPC) querying the cache requires

a little more runtime.

Compared to the APPSPEAR standard implemen-

tations, switchless calls improve runtimes in all consid-

ered implementation variants which use enclave-based

isolation, i. e. LPC/SGX, IPC/SGX, and SGX/LPC

(see Fig. 3c). For the LPC/SGX and SGX/LPC vari-

ants, this approach leads to a reduction of the basic

runtime overhead by more than one order of magni-

tude, while for the IPC/SGX variant it is more than

half of the runtime. The results of the CRUD micro-

and macrobenchmarks also show a runtime reduction

on average by more than half for the LPC/SGX vari-

ant and by less than two-thirds for the other two IPC/

SGX and SGX/LPC variants. The results of all other

variants remain unchanged compared to Fig. 3a.

Finally, Fig. 3d shows the results of combining

the two previously discussed optimizations. Taking

into account both caching (assuming cache hits) and

switchless calls, the runtimes for TPS/TEP isolating

implementation variants via processes or SGX (LPC/

IPC and LPC/SGX) are reduced to the cost level of an

intra-application implementation (LPC/LPC variant).

Although the other implementation variants have 3 to

4 times higher runtimes, due to a much higher effort

for communication and isolation, they also allow for

much stronger isolation guarantees (see also

3.1).

In particular, the trusted execution of all APPSPEAR

components within an enclave (SGX/LPC variant) is

now possible almost at the run-time level of process-

based isolation, putting the expected costs of using

SGX trusted execution technology for our application-

level policy enforcement approach into perspective.

5 RELATED WORK

This section summarized works related to our

application-level policy enforcement approach con-

sidering a precise TCB perimeter.

A step towards more precisely identiﬁable appli-

cation TCB perimeters is observable in SELinux with

user-space object managers (Loscocco and Smalley,

2001). The approach is based on auxiliary applica-

tion-level constructs for managing application objects

as SELinux policy objects and for supplementing the

system-wide policy with application policy rules based

on OS-speciﬁc policy semantics (Carter, 2007; Walsh,

2007). Although collecting and locating all policy

rules in the kernel’s policy runtime environment is ef-

fective in terms of policy protection and analyzability,

this approach causes an increase of each application

TCB by the OS policy as well as its runtime function-

ality and gives up any policy individuality.

An approach beyond is the SELinux Policy Server

Architecture (Tresys Technology, 2014; MacMillan

et al., 2006). With the goal of a clear separation

between OS-level and application-level policies, the

user-space security server (USSS) is placed at the ap-

plication level running all application-speciﬁc poli-

cies. Although the USSS fulﬁlls a comparable role to

the APPSPEAR TPS, the USSS exists only once at

the application level and is not instantiated individu-

ally per application in contrast to APPSPEAR TPSs.

This approach leads to considerably larger application

TCBs and, additionally, has to deal with problems

known from multi- and meta-policy systems (Bonatti

et al., 2002). Due to unknown reasons, the project

was abandoned.

6 CONCLUSION

This paper tackles the problem of large and com-

plex TCBs of current approaches for application-level

security policy enforcement. We propose the secu-

rity architecture framework APPSPEAR: By isolating

APPSPEAR components from untrusted application

logic and by applying isolation between APPSPEAR

components using mechanisms on different hardware/

software levels, implementation variants enable a ﬁne-

grained balancing of rigor regarding the reference

monitor principles as well as isolation/communication

costs, and thus, adjusting an APPSPEAR implementa-

tion to speciﬁc application requirements. The practical

evaluation shows that the expected runtime overhead

of using TEE/enclave-based isolation can be signif-

icantly reduced by using caching and asynchronous

enclave calls. While considerably reducing TCB im-

plementation size and complexity compared to con-

ventional mechanisms such as process-based isolation,

SGX enables trusted enforcement of application-level

policies in APPSPEAR implementations.

Ongoing work focuses on two main areas: (1.) We

are investigating approaches for increasing memory

safety of APPSPEAR implementations. The ﬁrst step

is being taken by implementing our framework in Rust.

Trusted Enforcement of Application-speciﬁc Security Policies

353

(2.) We are extending developer support: By enabling

compiler-supported code generation of policy and pol-

icy runtime environments (TPSs) from policy repre-

sentations in domain-speciﬁc languages (Amthor and

Schlegel, 2020), we aim to embed our approach into

model-based security policy engineering workﬂows.

REFERENCES

Alam, M., Zhang, X., Khan, K., and Ali, G. (2011). xDAuth:

A Scalable and Lightweight Framework for Cross Do-

main Access Control and Delegation. In SACMAT ’11,

pages 31–40.

Amthor, P. and Schlegel, M. (2020). Towards Language

Support for Model-based Security Policy Engineering.

In SECRYPT ’20, pages 513–521.

Anderson, J. P. (1972). Computer Security Technology Plan-

ning Study. Tech. Rep. ESD-TR-73-51, Vol. II.

Bezawada, B., Haefner, K., and Ray, I. (2018). Securing

Home IoT Environments with Attribute-Based Access

Control. In ABAC ’18, pages 43–53.

Bhatti, R., Ghafoor, A., Bertino, E., and Joshi, J. B. D.

(2005). X-GTRBAC: An XML-based Policy Speciﬁca-

tion Framework and Architecture for Enterprise-wide

Access Control. TISSEC, 8(2):187–227.

Biswas, P., Sandhu, R., and Krishnan, R. (2016). Label-

Based Access Control: An ABAC Model with Enu-

merated Authorization Policy. In ABAC ’16, pages

1–12.

Bonatti, P. A., De Capitani di Vimercati, S., and Pierangela,

S. (2002). An Algebra for Composing Access Control

Policies. TISSEC, 5(1):1–35.

Carter, J. (2007). Using GConf as an Example of How to

Create an Userspace Object Manager. In SEinux Symp.

’07.

Chen, J., Shang, W., Hassan, A. E., Wang, Y., and Lin,

J. (2019). An Experience Report of Generating Load

Tests Using Log-recovered Workloads at Varying Gran-

ularities of User Behaviour. In ASE ’19.

Crampton, J., Gutin, G., and Watrigant, R. (2016). Resiliency

Policies in Access Control Revisited. In SACMAT ’16,

pages 101–111.

Ferraiolo, D., Kuhn, D. R., and Chandramouli, R. (2007).

Role-Based Access Control. Artech House. Sec. Ed.

Ferraiolo, D. F., Chandramouli, R., Kuhn, R., and Hu,

V. C. (2016). Extensible Access Control Markup Lan-

guage (XACML) and Next Generation Access Control

(NGAC). In ABAC ’16, pages 13–24.

Ferraiolo, D. F., Gavrila, S. I., and Jansen, W. (2015). Policy

Machine: Features, Architecture, and Speciﬁcation.

Tech. Rep. NISTIR 7987 Rev 1.

Fong, P. W. L. (2011). Relationship-Based Access Control:

Protection Model and Policy Language. In CODASPY

’11, pages 191–202.

Gupta, M., Patwa, F., and Sandhu, R. (2018). An Attribute-

Based Access Control Model for Secure Big Data Pro-

cessing in Hadoop Ecosystem. In ABAC ’18, pages

13–24.

Hipp, D. R., Kennedy, D., and Mistachkin, J. (2020). SQLite

Version 3.32.3. https://www.sqlite.org/src/info/7ebdfa

80be8e8e73.

Hsu, A. C. and Ray, I. (2016). Speciﬁcation and Enforcement

of Location-Aware Attribute-Based Access Control for

Online Social Networks. In ABAC ’16, pages 25–34.

IBM (2016). Db2 11.1 – Label-based Access Control

Overview. https://www.ibm.com/support/knowledgec

enter/en/SSEPGG 11.1.0/com.ibm.db2.luw.admin.se

c.doc/doc/c0021114.html.

Intel Corporation (2019). Intel

SGX SDK for Linux* OS –

Developer Reference. https://download.01.org/intel-

sgx/sgx-linux/2.7.1/docs/Intel SGX Developer Refer

ence Linux 2.7.1 Open Source.pdf.

Intel Corporation (2021). Intel

Software Guard Extensions.

https://software.intel.com/en-us/sgx.

Jin, X., Krishnan, R., and Sandhu, R. S. (2012). A Uniﬁed

Attribute-Based Access Control Model Covering DAC,

MAC and RBAC. In DBSec ’12, pages 41–55.

Johnson, S., Zimmerman, D., and B., D. (2016). Intel

SGX: Debug, Production, Pre-release. https://software

.intel.com/en-us/blogs/2016/01/07/intel-sgx-debug-

production-prelease-whats-the-difference.

Loscocco, P. A. and Smalley, S. D. (2001). Integrating

Flexible Support for Security Policies into the Linux

Operating System. In ATC ’01, pages 29–42.

MacMillan, K., Brindle, J., Mayer, F., Caplan, D., and Tang,

J. (2006). Design and Implementation of the SELinux

Policy Management Server. In SELinux Symp. ’06.

Ni, Q., Bertino, E., and Lobo, J. (2010). Risk-Based Ac-

cess Control Systems Built on Fuzzy Inferences. In

AsiaCCS ’10, pages 250–260.

OpenMRS Inc. (2021a). OpenMRS. https://openmrs.org.

OpenMRS Inc. (2021b). OpenMRS Demo Data. https:

//wiki.openmrs.org/display/RES/Demo+Data.

Oracle (2018). Oracle Label Security Administrator’s Guide,

18c. https://docs.oracle.com/en/database/oracle/oracle-

database/18/olsag/index.html.

Rizvi, S. Z. R., Fong, P. W., Crampton, J., and Sellwood,

J. (2015). Relationship-Based Access Control for an

Open-Source Medical Records System. In SACMAT

’15, pages 113–124.

Schlegel, M. and Amthor, P. (2020). Beyond Administration:

A Modeling Scheme Supporting the Dynamic Analysis

of Role-based Access Control Policies. In SECRYPT

’20, pages 431–442.

Schlegel, M. and Amthor, P. (2021). The Missing Piece of

the ABAC Puzzle: A Modeling Scheme for Dynamic

Analysis. In SECRYPT ’21.

Shebaro, B., Oluwatimi, O., and Bertino, E. (2014). Context-

based Access Control Systems for Mobile Devices.

TDSC, 12(2):150–163.

Shu, R., Wang, P., Gorski III, S. A., Andow, B., Nadkarni, A.,

Deshotels, L., Gionta, J., Enck, W., and Gu, X. (2016).

A Study of Security Isolation Techniques. Comp. Surv.,

49(3):50:1–50:37.

Smalley, S. and Craig, R. (2013). Security Enhanced (SE)

Android: Bringing Flexible MAC to Android. In NDSS

’13.

SECRYPT 2021 - 18th International Conference on Security and Cryptography

354

Smalley, S. D., Vance, C., and Salamon, W. (2001). Imple-

menting SELinux as a Linux Security Module. NAI

Labs Rep. 01-043.

Spencer, R., Smalley, S. D., Loscocco, P. A., Hibler, M.,

Andersen, D., and Lepreau, J. (1999). The Flask Secu-

rity Architecture: System Support for Diverse Security

Policies. In Secur. ’99, pages 123–139.

Stoller, S. D., Yang, P., Gofman, M. I., and R., R. C.

(2011). Symbolic Reachability Analysis for Param-

eterized Role-Based Access Control. Comp. & Secur.,

30(2–3):148–164.

Sze, W. K., Mital, B., and Sekar, R. (2014). Towards More

Usable Information Flow Policies for Contemporary

Operating Systems. In SACMAT ’14, pages 75–84.

Tresys Technology (2014). SELinux Policy Server. http:

//oss.tresys.com/archive/policy-server.php.

Tripunitara, M. V. and Li, N. (2013). The Foundational

Work of Harrison-Ruzzo-Ullman Revisited. TDSC,

10(1):28–39.

Walsh, E. F. (2007). Application of the Flask Architecture to

the X Window System Server. In SELinux Symp. ’07.

Wang, Q. and Li, N. (2010). Satisﬁability and Resiliency in

Workﬂow Authorization Systems. TISSEC, 13(4):40:1–

40:35.

Watson, R. N. M. (2013). A Decade of OS Access-control

Extensibility. Queue, 11(1):20:20–20:41.

Weisse, O., Bertacco, V., and Austin, T. (2017). Regaining

Lost Cycles with HotCalls: A Fast Interface for SGX

Secure Enclaves. In ISCA ’17, pages 81–93.

Wolfe, B. A., Mamlin, B. W., Biondich, P. G., Fraser, H. S. F.,

Jazayeri, D., Allen, C., Miranda, J., and Tierney, W. M.

(2006). The OpenMRS System: Collaborating Toward

an Open Source EMR for Developing Countries. In

AMIA Ann. Symp. ’06, page 1146.

Trusted Enforcement of Application-speciﬁc Security Policies

355
