A Formal Approach Combining Event-B and PDDL for Planning

Problems

Sabrine Ammar

and Mohamed Tahar Bhiri

MIRACL, Faculty of Economics and Management of Sfax, Sfax, Tunisia

MIRACL, Faculty of Science of Sfax, Sfax, Tunisia

Keywords: Code Generation, Correct by Construction, Event-B, PDDL, Formal Modelling, Refinement Strategy.

Abstract: In artificial intelligence, the goal of automatic planning is to structure actions in the form of a plan to achieve

an expressed goal. The PDDL (Planning Domain Definition Language) was designed to allow the common

representation of planning problems during ICAPS (International Conference on Automated Planning and

Scheduling) competitions. PDDL has many verification and validation tools allowing the description,

resolution and validation of planning problems. But they only allow the reliability of PDDL descriptions a

posteriori. In this article, we recommend a rigorous approach coupling Event-B and PDDL favoring obtaining

PDDL descriptions deemed correct, a priori, from an ultimate Event-B model. The formal Event-B method

allows us to obtain, by successive refinements with mathematical proofs, correct by construction formal

models of planning problems. A refinement strategy appropriate to planning problems is, then, proposed. The

ultimate Event-B model, correct by construction, is automatically translated into PDDL using our MDE

Event-B2PDDL tool. The obtained PDDL description is submitted to efficient planners for generation of

correct and efficient plan-solutions.

1 INTRODUCTION

The automatic planning community has developed a

formal de-facto standard Planning Domain Definition

Language (PDDL) (McDermott et. al. 1998) to

formally describe planning problems. In addition, this

community has developed solvers able to calculate

solutions to PDDL-formalized planning problems. In

addition, validation tools were developed for

verifying whether a given plan-solution can be

derived from a PDDL description. In general, PDDL

descriptions are difficult to write, read, and evolve.

Moreover, the tools associated with the PDDL

language, namely planners and validators; do not

allow a rigorous a priori analysis of the PDDL

descriptions. In fact, these tools are used a posteriori

after establishing PDDL descriptions.

In this work, we advocate the opening of the

automatic planning community on the formal

methods community through Event-B (Abrial, 2010).

To achieve this, we suggest a transformation from

Event-B to PDDL. This promotes the development of

planning problems correct by construction. The

ultimate Event-B model, derived from a chain of

refinements with mathematical proofs, is translated

into PDDL in order to generate quality plans through

various planners supporting PDDL.

This article extends our previous short paper

presented in (Ammar and Bhiri, 2018). In fact, we

detail in particular the strategy of refinement with

mathematical proofs recommended for a class of

planning problems. Such a class has state change

operators with complex preconditions: a logical

formula comprising several operands and operators.

In addition, a sub-section (Discussion) is added in the

“Proposed refinement strategy” section in order to

discuss the compatibility of the proposed refinement

strategy for the development of certain planning

problems with respect to what is recommended by the

Event-B method. In addition, the “Related works”

section is added to place our work in relation to

existing works. Finally, the conclusion is enriched by

new research lines pointed out.

This article contains seven sections and one

conclusion. The second section presents and

evaluates the PDDL language. The third section

provides a general overview of modeling in Event-B

method. The fourth section proposes an Event-B and

PDDL coupling approach. The fifth section provides

a refinement strategy for formal modeling of Event-B

planning problems. The sixth section describes our

Ammar, S. and Bhiri, M.

A Formal Approach Combining Event-B and PDDL for Planning Problems.

DOI: 10.5220/0010577102610268

In Proceedings of the 16th International Conference on Software Technologies (ICSOFT 2021), pages 261-268

ISBN: 978-989-758-523-4

261

MDE Event-B2PDDL tool. Finally, the seventh

section is devoted to related works. The conclusion

draws up the balance sheet of this article and proposes

the possible extensions of this work.

2 THE PDDL LANGUAGE

A planning problem formalized using PDDL has two

separate parts: domain and problem. The domain

construction makes it possible to describe all the

common aspects in a class of problems known as

generic domain.. A domain described in PDDL

includes types, constants, predicates, numeric

functions and actions.

As an example, Listing 1 from (Bibai, 2010)

describes the domain of the sliding puzzle game in

PDDL. The domain of the sliding puzzle game has

two types: position and tile. In PDDL, a type does not

have a structure and is designated by a name. The

predicates at (having two parameters ?tile of type tile

and ?position of type position), neighbor and empty

allowing to formalize the concept of state of a sliding

puzzle game problem. The move action is the only

state change operator relating to the sliding puzzle

game domain. In PDDL, an action can have

parameters typed (parameters clause) and defined by

a Pre/Post specification: precondition and effect

clauses. An action can be applied in a state if and only

if all preconditions are satisfied in this state. The

effect of a PDDL action is defined by the additions

and withdrawals of atoms in the current state.

(define (domain n-sliding-puzzle)

(:types position tile)

(:predicates

(at ?tile - tile ?position - position)

(neighbor ?p1 - position ?p2 -position)

(empty ?position - position))

(:action move

:parameters (?tile - tile ?from ?to – position)

:precondition (and (neighbor ?from

?to) (at ?tile ?from)(empty ?to))

:effect (and(at ?tile ?to)(empty ?from

(not (at ?tile ?from))(not (empty

?to)))))

Listing 1: State of the application.

The problem construction makes it possible to

formalize a problem belonging to the domain

described by the domain construction. A problem

includes the domain of this problem, typed objects

(objects), an initial state (init) and a goal state

(goal). For example, the Sliding Puzzle game

containing 8 tiles is provided by Listing 2.

(define (problem n-sliding-puzzle-pbl)

(:domain n-sliding-puzzle)

(:objects

p_1_1 p_1_2 p_1_3 p_2_1 p_2_2 p_2_3

p_3_1 p_3_2p_3_3 – position

t_1 t_2 t_3 t_4 t_5 t_6 t_7 t_8 –tile)

(:init (empty p_1_2)

(at t_4 p_1_1)(at t_8 p_1_3)

(at t_6 p_2_1)(at t_3 p_2_2)

(at t_2 p_2_3)(at t_1 p_3_1)

(at t_5 p_3_2)(at t_7 p_3_3)

(neighbor p_1_1 p_1_2)(neighbor p_1_2

p_1_1)(neighbor p_1_2 p_1_3)(neighbor

p_1_3 p_1_2)(neighbor p_2_1 p_2_2)

(neighbor p_2_2 p_2_1)(neighbor p_2_2

p_2_3)(neighbor p_2_3 p_2_2)(neighbor

p_3_1 p_3_2)(neighbor p_3_2 p_3_1)

(neighbor p_3_2 p_3_3)(neighbor p_3_3

p_3_2)(neighbor p_1_1 p_2_1)(neighbor

p_2_1 p_1_1)(neighbor p_1_2 p_2_2)

(neighbor p_2_2 p_1_2)(neighbor p_1_3

p_2_3)(neighbor p_2_3 p_1_3)(neighbor

p_2_1 p_3_1)(neighbor p_3_1 p_2_1)

(neighbor p_2_2 p_3_2)(neighbor p_3_2

p_2_2)(neighbor p_2_3 p_3_3)(neighbor

p_3_3 p_2_3))

(:goal (and (at t_1 p_1_1)

(at t_2 p_1_2)(at t_3 p_1_3)

(at t_4 p_2_1) (at t_5 p_2_2)

(at t_6 p_2_3) (at t_7 p_3_1)

(at t_8 p_3_2))))

Listing 2: Sliding puzzle game with 8 tiles.

A planning problem described using PDDL is

solved by a software item called planner. A planner

combines exploration and logic. In fact, it can be seen

either as a program that calculates a solution called

plan-solution or as a program that demonstrates the

existence of a solution. For example, the Sliding

Puzzle game planning problem described by both

Listings 1 and 2 submitted to the LPG planner

(Gerevini, Saetti and Serina, 2003) provides a plan-

solution comprising 52 actions. Listing 3 illustrates

an extract of this plan solution.

0: (move t_8 p_1_3 p_1_2)

1: (move t_2 p_2_3 p_1_3)

2: (move t_3 p_2_2 p_2_3)

3: (move t_8 p_1_2 p_2_2)

4: (move t_2 p_1_3 p_1_2)

Listing 3: Plan-solution extract associated with the 8-tile

problem of the Sliding Puzzle game.

PDDL offers interesting ways to represent

planning problems. In fact, PDDL supports various

representations such as propositional representations,

first order logic and both numeric and temporal. This

makes it possible to describe the states and actions of

ICSOFT 2021 - 16th International Conference on Software Technologies

262

a planning problem. The tools associated with the

PDDL language are: planners and validators. Unlike

a planner who performs a plan-solution production

activity, a validator (Howey, Long and Fox, 2004)

performs a verification activity. From the functional

point of view, a validator accepts as input: a PDDL

description (domain and problem file) and one or

more plan-solution files and gives a verdict as an

output. 'YES' means that the plan-solution can be

obtained from the subject PDDL description.

However, 'NO' means a failure. Validators can be

used in a profitable way to appreciate PDDL domains

by adopting the functional test. In addition, validators

allow double verification by checking the plan-

solutions generated by various planners. Finally, a

validator can be used as a tool to objectively compare

the abilities of various planners. The dynamic

analysis tools associated with PDDL, namely

planners and validators, are insufficient for the

verification and validation of PDDL descriptions. In

fact, complex PDDL descriptions involving actions

with elaborated preconditions and post conditions are

subject to errors that are hard to detect a priori. In

fact, the dynamic analysis tools associated with

PDDL makes it possible to detect errors a posteriori

by means of a test activity.

3 MODELING IN EVENT-B

An Event-B model can contain contexts (construction

CONTEXT) only, machines (construction

MACHINE) only or both. Contexts are modeling

static properties of the model. Machines (construction

MACHINE) are modeling the dynamic behavior of

the system. A machine may refine and see another

one or more contexts. The state of the machine is

defined by variables introduced by the VARIABLES

clause. The invariance properties related to these

variables are grouped together in the INVARIANT

clause. They are considered as predicates in the sense

of Event-B as described by its logico-set language.

An Event-B machine is grouping events that affect its

state. An event consists of two parts: a “guard” that

defines the condition according to it the event may or

may not be triggered, and an "action" called event

body permitting the evolution of state variables. An

event may have parameters called local parameters.

The Event-B language offers a simple action

language to describe the processing (event body):

simple assignment ( :=), non-deterministic set

assignment (:∈), non-deterministic assignment

governed by a predicate ( :|), parallel assignment (||),

and skip that does nothing.

4 FROM EVENT-B TO PDDL

We advocate a rigorous approach combining Event-

B and PDDL for automatic planning. Event-B is

used for formal modeling by successive refinements

with mathematical proofs of planning problems. The

refinement of data supported by Event-B can be

used in a profitable way in order to refine the notion

of state of a planning problem step-by-step. In

addition, the one-to-many refinement provided by

Event-B is very useful for determining the state

change operators of a planning problem. Finally, the

possibility of reinforcing the guard of an Event

supported by Event-B during a refinement step is

very useful to incrementally identify the

applicability conditions of a state change operator of

a planning problem. Proof tools associated with

Event-B (generator of proof obligations and

provers) guarantee in particular the verification of

the coherence of a planning problem described by

Event-B. The ProB (Leuschel and Butler, 2003) tool

that accepts Event-B offers the possibility of

checking the dynamics of a planning problem. The

use of Event-B coupled to ProB allows to obtain

Event-B model correct by construction (thanks to

the Event-B theory) and valid (thanks to ProB)

describing a planning problem. Then we have to

translate this Event-B model into a PDDL. To

achieve this, several refinement steps are required in

order to have a model described by an Event-B

subset: the data are described by the language of the

first-order predicates of Event-B (the theory of sets

is discarded because it is not translatable to PDDL)

and the processing are described only through

deterministic action ( :=).

5 PROPOSED REFINEMENT

STRATEGY

Following numerous Event-B modeling of various

planning problems, we have established a refinement

strategy that could be reused for modeling various

planning problems with Event-B in several areas. In

fact, all planning problems can be formalized by the

concept of state space: initial state, goal states,

intermediate states and state change operators. Based

on all of its common aspects of planning problems,

we propose the refinement strategy that includes the

steps as outlined and justified below. The purpose of

this problem is to transfer three cannibals and three

missionaries from one side of a river to another via a

boat. The requirement of this problem is that the

A Formal Approach Combining Event-B and PDDL for Planning Problems

263

number of missionaries must always be greater than

or equal to the number of cannibals.

Step 1: Initial Abstract Model. The initial abstract

model of a planning problem includes elements

related to the notion of state, the initial state, and the

goal states. These elements are formalized

respectfully in Event-B by typed variables. They have

invariant properties, INITIALISATION event and an

event called goal having a guard to see if the current

state is a goal state. The goal event does nothing (skip

action). For example, Listing 4 models the notion

state, the initial state, and the goal states of the

problem of three cannibals and three missionaries. In

addition, the initial abstract model of a planning

problem shall involve an overly abstract and non-

deterministic modeling of the notion of state change

operator. This is made possible by the

ANTICIPATED status. Listing 5 provides the state

change operator related to the problem of three

cannibals and three missionaries.

VARIABLES

nbc_shore1,nbc_shore2,nbm_shore1,nbm_shore2

INVARIANTS

inv1: nbc_shore1∈0..3

inv2: nbc_shore2∈0..3

inv3: nbm_shore1∈0..3

inv4: nbm_shore2∈0..3

INITIALISATION=

nbc_shore1,nbc_shore2,nbm_shore1,

nbm_shore2:=3,0,3,0

goal =

WHEN

grd1: nbc_shore1=0

grd2: nbc_shore2=3

grd3: nbm_shore1=0

grd4: nbm_shore2=3

THEN

Skip

END

Listing 4: State, Initial state and Goals states.

cross = STATUS anticipated

act1: nbc_shore1:∈0..3

act2: nbc_shore2:∈0..3

act3: nbm_shore1:∈0..3

act4: nbm_shore2:∈0..3

END

Listing 5: Non-deterministic specification of the event

cross.

Step 2: Determination of Actions by Successive

Refinements. This step includes several successive

refinements permitting, ultimately, to get an Event-B

model with state change operators having

deterministic behaviors. Each operator contains a

guard modeling the operator‘s applicability condition

and its action. Refinement techniques supported by

Event-B as an event decomposition (one to many) and

the reinforcing guards are very useful for

implementing this step. For example, Listing 6 shows

how to refine the abstract operator to introduce two

types of operators. The state change operators are

modeled by events in Event-B whose guards indicate

the conditions of application of these operators and

the actions that are modeling the changes of state:

transition from one state to another in state spaces. To

list all of the state change operators related to

application, we recommend using parameterized non-

deterministic events. For example, Listing 7 shows

the refinement of the event cross_shore1_shore2 by

introducing two local parameters c and m. The first is

modeling the transfer of cannibals and the second is

modeling the transfer of missionaries.

VARIABLES

nbc_shore1,nbc_shore2,nbm_shore1,

nbm_shore2,boat

INVARIANTS

inv1: boat∈BOAT

cross_shore1_shore2 =

REFFINE cross

WHEN

grd1: boat=left

THEN

act1: nbc_shore1:∈0..3

act2: nbc_shore2:∈0..3

act3: nbm_shore1:∈0..3

act4: nbm_shore2:∈0..3

act5: boat:=right

END

cross_shore2_shore1 =

REFFINE cross

WHEN

grd1:boat=right

THEN

act1: nbc_shore1:∈0..3

act2: nbc_shore2:∈0..3

act3: nbm_shore1:∈0..3

act4: nbm_shore2:∈0..3

act5: boat:=left

END

Listing 6: Introduction of two types of state change

operators.

cross_shore1_shore2 =

REFFINE cross_shore1_shore2

ANY

WHEN

grd1: m∈0..2

ICSOFT 2021 - 16th International Conference on Software Technologies

264

grd2: c∈0..2

grd3: m+c∈1..2

grd4: c≤nbc_shore1

grd5: m≤nbm_shore1

grd6: boat=left

THEN

act1: nbc_shore1:=nbc_shore1- c

act2: nbm_shore1:=nbm_shore1- m

act3: nbc_shore2:=nbc_shore2+c

act4: nbm_shore2:=nbm_shore2+m

act5: boat:=right

END

Listing 7: Introduction of parameters.

Step 3: Determination of Parameters by

Successive Refinements. This step aims to remove

the non-determinism related to the parameters

introduced in the clause ANY of each states change

operator. Eventually, we obtain events without

parameters. Technically in this step, the “one to

many” refinement technique and the WITH clause are

used in a profitable way. The problem of three

cannibals and three missionaries has 10 state change

operators with deterministic actions and no

parameters (see Listing 8).

cross_one_cannibal_shore1_shore2 =

REFFINE cross_shore1_shore2

WHEN

grd1: boat=left

grd2: 1≤nbc_shore1

WITH

c: c=1

m: m=0

THEN

act1: nbc_shore1:=nbc_shore1-1

act2: boat:=right

END

Listing 8: State change operator without parameters.

Step 4: Reinforcing Applicability Conditions. This

step consists in reinforcing applicability conditions of

the state change operators (WHERE clause)

introduced in the previous step. The ultimate model

from this step must have well-defined state change

operators. Technically, this step introduces new

invariant properties (reinforcement of the invariant)

and guards (reinforcement of guards). For example,

the problem of three cannibals and three missionaries

shall make it inaccessible for the states where the

number of cannibals is greater than that of

missionaries (see Listing 9).

INVARIANTS

inv:nbm_shore1≠0⇒nbm_shore1≥nbc_shore1

inv2:3−nbm_shore1≠0⇒3−nbm_shore1≥

3−nbc_shore1

cross_one_cannibal_shore1_shore2 =

REFFINE cross_one_cannibal_shore1_shore2

WHEN

grd1: boat=left

grd2: 1≤nbc_shore1

grd3: (3−nbm_shore1=0)∨(3−nbm_shore1≥

3–nbc_shore1+1)

WITH

c: c=1

m: m=0

THEN

act1: nbc_shore1:=nbc_shore1-1

act2: boat:=right

END

Listing 9: Applicability conditions of

cross_one_cannibal_shore1_shore2.

Step 5: Data Concretization. The purpose of this

step is to eventually provide an Event-B model

translatable into PDDL. All Event-B set constructions

must be realized using the Event-B predicative

constructions. To achieve this, data refinement is used

via Event-B gluing invariant. Note in passing that this

step is not applicable to the problem of three

cannibals and three missionaries. Recently, we have

successfully applied this step on the MICONIC

domain (Haslum et. al. 2019).

Step 6: Translating a Reduced Event-B into

PDDL. The reduced Event-B model from Step 4 is

translated using our Event-B2PDDL tool introduced

later. Listing 9 gives an extract of the ultimate Event-

B model translatable into PDDL. Listing 10 provides

an excerpt from the translation of the problem of three

cannibals and three missionaries into PDDL.

(:types SHORE CANNIBAL MISSIONARY)

(:constants left right - SHORE)

(:predicates (boat ?x - SHORE)

(pos_cann ?x - CANNIBAL ?y - SHORE)

(pos_miss ?x -MISSIONARY ?y -SHORE)

(diffc ?x ?y - CANNIBAL)

(diffm ?x ?y - MISSIONARY))

(:functions nbc_shore1) (nbm_shore1))

(:action

cross_one_cannibal_shore1_shore2

:parameters (?cc - CANNIBAL)

:precondition (and (boat left)(<= 1

(nbc_shore1))(or (= (- 3 (nbm_shore1))

0)(>= (- 3 (nbm_shore1))(+ (- 3

(nbc_shore1)) 1)))(pos_cann ?cc left))

:effect (and (boat right)(not(boat

left))(decrease (nbc_shore1)1)(pos_cann

?cc right)(not (pos_cann ?cc left))))

Listing 10: PDDL translation excerpt.

5.1 Discussion

In this section we take a look at the development of

A Formal Approach Combining Event-B and PDDL for Planning Problems

265

our refinement strategy applied to the problem of three

missionaries and three cannibals as a planning

problem. Invariant properties other than typing

properties are not introduced into the initial abstract

model. In fact, the state change operator: cross is

defined in a non-deterministic way. The determination

of the state operator: cross is carried out progressively

by introducing constraints linking the variables which

forms the state of the machine and decomposes it. Such

constraints define the invariant properties to be

preserved by the state change operators.

The ultimate Event-B model includes

semantically well-defined state change operators

(events): applicability condition and effect. The

properties that transcend these operators are

factorized in the invariant of the ultimate model. The

proof obligations discharged from the ultimate model

are ensuring its static correction with respect to the

invariant properties. The dynamics of the ultimate

model is formally verified with the ProB toolbox:

animation and model-checking. Both

INITIALISATION and goal events modeling the

initial state and the logical condition of the goal states

in a planning problem remain unchanged during the

application of the refinement strategy. We can see

that the number of events is increasing as we apply

our refinement strategy: it goes from 3 to 13.

6 THE EVENT-B2PDDL TOOL

Our Event-B2PDDL tool takes as input a reduced

Event-B model that is translatable into PDDL and

gives as output a PDDL description acceptable to

planners. Event-B2PDDL is based on simple intuitive

rules allowing the systematic translation of Event-B

elements to PDDL elements. Event-B2PDDL is made

according to MDE technology.

6.1 Event-B to PDDL Transformation

Rules

The PDDL description coming from the Event-

B2PDDL tool has two domain and problem

constructions (see section Event-B overview). Thus,

in (Fourati, Bhiri and Robbana 2016), we have

respectively established rules allowing the translation

of Event-B elements related to the planning domain

and the planning problem. The translation rules for

Event-B elements related to the planning domain

concern: translation of abstract sets (see Table 1),

constants (see table 2), Boolean constants or variables

(see Table 3), Boolean functions (see Table 4), events

Table 1: Schemes of translations of abstract set.

Event-B PDDL

SETS

TYPE1

TYPE2

…

TYPEn

(:types

type1

type2

…

)

Table 2: Schemes of translations of constants.

Event-B PDDL

CONSTANTS

cst1, cst2, …, cstn

AXIOMS

axm1:partition(TYPE,{cst1},{cst2},

…, {cstn})

(:constants

cst1 cst2 …

cstn -TYPE )

Table 3: Schemes of translations of Boolean constants or

variables.

Event-B PDDL

CONSTANTS

cst

AXIOMS

axm1: cst∈BOOL

(:predicates

(cst)

(var)

)

VARIABLES

var

INVARIANTS

inv1: va

∈BOOL

Table 4: Schemes of translations of Boolean functions.

Event-B PDDL

VARIABLES

fnc

INVARIANTS

inv_fnc: fnc∈TYPE1 × TYPE2

×...×TYPEn→BOOL

(:predicates

(fnc ?var1 - TYPE1

?var2 - TYPE2 ...

?varn - TYPEn)

)

Table 5: Schemes of translations of Event-B Events.

Event-B PDDL

evt_name =

STATUS ordinary

ANY

var1

var2

…

WHERE

grd1: var1∈TYPE1

grd2: var2∈TYPE2

…

grdn: <GDn>

grdn1: <GDn1>

....

THEN

act1: <ACT1>

act2: <ACT2>

....

END

( :action <evt_name>

:parameters ( ?var1 -

TYPE1 ?var2 - TYPE2

...)

:precondition (and

(<GDn>)

(<GDn1>)

.....)

:effect (and (<ACT1>)

(<ACT2>)

.....)

)

ICSOFT 2021 - 16th International Conference on Software Technologies

266

(see Table 5) and formulas (see Table 6). The

translation rules of Event-B elements related to the

planning problem are about translation of constants

linked to the sets defined by enumeration (see Table

7), translation of axioms of initialization (see Table 8)

and translation of both INITIALISATION and

GOAL events (see Table 9 and Table 10).

Table 6: Schemes of translation of Event-B formulas

retained in PDDL.

Event-B PDDL

P ∧ Q

(and P Q)

P ∨ Q

(or P Q)

P ⇒ Q

(imply P Q)

¬P (not P)

∀z.P⇒ Q

(forall ( ?z) (imply P Q))

∃z.P∧ Q

(exists ( ?z) (and P Q))

E = F

(

= E F

)

E ≠ F (not (= E F))

:=TRUE (b)

:=FALSE (not(b))

(

)

:=TRUE

(

f ?x

)

(

)

:=FALSE

(

not

(

f ?x

))

f:=f<+{ x|->TRUE, y|-

>FALSE

}

(and (f ?x) (not (f ?y)))

Table 7: Schemes of translations of constants.

Event-B PDDL

CONSTANTS

cst1, cst2, …, cstn

AXIOMS

axm1:partition(TYPE,{cst1},{cst2},

…, {cstn})

(:objects

cst1 cst2 …

cstn - TYPE

)

Table 8: Schemes of translations of Axioms of

Initialization.

Event-B PDDL

axm1:fnc1:=((TYPE1×TYPE2×

…×TYPEn)×{FALSE})<+({cst1

›→cst2›→...cstn, …}×{TRUE})

( :init

(fnc1 cst1 cst2...

cstn)

...

)

Table 9: Schemes of translations of the event

INITIALISATION.

Event-B PDDL

INITIALISATION=

STATUS ordinary

act1:fnc2:=((TYPE1×TYPE2×

. . .×TYPEn)×{FALSE})<+(

{cst1›→cst2›→...

cstn,…}×{TRUE})...

END

(:init

(fnc2 cst1 cst2 ...

cstn)

...

)

Table 10: Schemes of translations of the event GOAL.

Event-B PDDL

GOAL =

STATUS ordinary

WHEN

grd1:fnc2=fnc2<+

{cst1›→cst2›→...›→cstn

›→TRUE, ...}

...

THEN

skip

END

(:goal (and

(fnc2 cst1 cst2 ... cstn)

...

)

7 RELATED WORKS

There exist several “Integrated Development

Environments” supporting PDDL (Magnaguagno et.

al. 2017; Strobel and Kirsch, 2014; Muise and

Lipovetzky 2020). Such environments offer

functionalities allowing the editing of PDDL

descriptions, lexico-syntactic verification of PDDL

text, generation of plans-solution and visualization of

states space associated with the planning problem.

This last functionality allows, among other things, to

provide information to the user, related to the

"execution" of PDDL actions. This allows the user to

detect errors related to the specification of a PDDL

action such as incorrect precondition, incorrect post

condition and incorrect precondition and post

condition. In addition, the visualization of the state

space makes it possible to make the behavior of the

PDDL planner explicit in order to find a plan solution.

This reduces the opacity of PDDL planners. In fact,

without visualization, these planners are used as black

boxes. In our opinion, this work supports the analysis

of PDDL descriptions a posteriori without correction

certification. From among Platforms covering the

design of planning domains and problems, we note

itSIMPLE (Vaquero et. al. 2009) and GIPO

(Simpson, Kitchin, and McCluskey, 2002). On one

hand, itSIMPLE platform uses UML (class and object

diagram, OCL constraint language, and time

diagram) to describe planning domains and problems.

In addition, this platform provides a tool for

transforming UML to PDDL. On the other hand,

GIPO platform uses Object-Centred-Language

(OCL) to describe planning domains and problems. It

provides a translation tool from OCL to PDDL. In

addition, it provides static and dynamic validation

capabilities for planning domains.

The work described in (West, Kitchin and

McCluskey, 2002) explores the use of formal model-

oriented methods based on successive refinements

A Formal Approach Combining Event-B and PDDL for Planning Problems

267

with mathematical proofs and supporting the

paradigm correct by construction. Such work is the

closest to our concerns but it does not lead to a PDDL

code generation. Moreover, it uses B which has a

notion of refinement less rich than that of Event-B.

8 CONCLUSIONS

PDDL is a declarative language. It offers quite

significant means for domain modeling areas and

planning problems. In addition, PDDL is endowed

with powerful software tools - called planners –

permitting the automatic generation of plan-solutions

from a PDDL description. But PDDL descriptions are

often difficult to write, read and evolve. Also, they are

subject to several types of errors: data typing,

initialization of static and dynamic predicates and

pre-condition / post-condition specification of action

schemes. To deal with these faults; in this work, we

proposed an Event-B to PDDL coupling approach.

The transition from Event-B to PDDL makes it

possible to model correct by construction and

efficient planning problems. Event-B ensures the

correct by construction of the states change operators.

Whereas PDDL ensures the effectiveness of the plan-

solutions obtained thanks to the planners associated

with PDDL. We proposed, in addition, a refinement

strategy which may be appropriate for a class of

planning problems whose actions have complex

preconditions. Technically, a complex precondition is

a big logical formula comprising atoms connected by

logical operators such as: not, and, or, imply, exists

and forall. The ultimate Event-B model from our

refinement strategy is translated into PDDL using our

MDE Event-B2PDDL tool.

Currently, we are working in two directions: The

first direction consists of the experimentation of the

refinement strategy proposed on various more or less

complex planning problems. Recently, we have

successfully applied our refinement strategy to the

MICONIC planning domain (Haslum et. al. 2019).

This domain describes the operation of an elevator in

a building. Passengers of various categories are

waiting on the different floors and the goal is to

transport each passenger to his/her floor of

destination. The second direction is about the

development of refinement schemes allowing the

translation of Event-B data into PDDL: from set

representations to predictive representations.

Eventually, such schemes could be automated by

adopting the technique of automatic refinement like

the BART tool (Requet, 2008) associated with the

formal method B.

REFERENCES

Abrial, J. R. (2010). Modeling in Event-B: Systems and

Software Engineering. Cambridge University Press.

Ammar, S., Bhiri, M. T. (2018). Automatic Planning: From

Event-B to PDDL. International Conference on. Model

and Data Engineering. Marrakesh. Morocco.

Bibai, J. (2010). Segmentation et Evolution pour la

Planification : Le Système DivideAndEvolve.

THALES Research and Technology France. Paris Sud

University, Paris XI.

Fourati, F., Bhiri, M. T., Robbana, R. (2016). Verification

and validation of PDDL descriptions using Event-B

formal method. International Conference on

Multimedia Computing and Systems, pp. 770-776.

Gerevini, A., Saetti, A., Serina, I. (2003). Planning through

Stochastic Local Search and Temporal Action Graphs

in lpg. J Artif Intell Res 20:239-290.

Haslum, P., Lipovetzky, N., Magazzeni, D., and Muise, C.

(2019). An Introduction to the Planning Domain

Definition Language. In Synthesis Lectures on

Artificial Intelligence and Machine Learning.

Howey, R., Long, D., Fox, M. (2004). VAL: Automatic

Plan Validation, Continuous Effects and Mixed

Initiative Planning using PDDL. In Tools with Artificial

Intelligence, ICTAI. doi: 10.1109/ICTAI.2004.120.

Leuschel, M., Butler, M. (2003). ProB: A Model Checker

for B. In International Symposium of Formal Methods.

Magnaguagno, M. C., Pereira, R. F., More, M. D., and

Meneguzzi, F. (2017). WEB PLANNER: A Tool to

Develop Classical Planning Domains and Visualize

Heuristic State-Space Search. ICAPS 2017. User

Interfaces for Scheduling & Planning (UISP).

McDermott, D., Ghallab, M., Howe, A., Knoblock, C.,

Ram, A., Veloso, M., Weld, D., Wilkins, D. (1998).

PDDL-The Planning Domain Definition Language.

Yale Center for Computational Vision and Control.

Technical Report CVC TR- 98-003/DCS TR-1165.

New Haven, CI, USA.

Muise, C., Lipovetzky, N. (2020). KEPS BOOK:

Planning.Domains. In book: Knowledge Engineering

Tools and Techniques for AI Planning, pp.91-105.

Requet, A. (2008). BART: A tool for Automatic

Refinement. In ABZ. doi: 10.1007/978-3-540-87603-

8_33

Simpson, R. M., Kitchin, D.E., McCluskey, T.L. (2002).

Planning Domain Definition Using GIPO. The

Knowledge Engineering Review 22(02): 117 – 134.

Strobel, V., Kirsch, A. (2014). Planning in the Wild:

Modeling Tools for PDDL. 37th German Conference

on Artificial Intelligence, Stuttgart. Germany.

Vaquero, T.S., Silva, J.R., Ferreira, M., Tonid, F., Beck, J.

c. (2009). From Requirements and Analysis to PDDL

in itSIMPLE3.0. In Proceedings of the 3rd International

Competition on, 2009.

West, M.M., Kitchin, D.E., McCluskey, T.L. (2002).

Validating Planning Domain Models using B-AMN. In:

PlanSIG 2002, 21st/22nd Nov 2002, Delft University of

Technology, Holland.

ICSOFT 2021 - 16th International Conference on Software Technologies

268
