Well-Being in Plastic Surgery: Deep Learning

Reveals Patients’ Evaluations

Joschka Kersting

and Michaela Geierhos

Paderborn University, Warburger Str. 100, Paderborn, Germany

Bundeswehr University Munich, Research Institute CODE,

Carl-Wery-Straße 22, Munich, Germany

Keywords:

Aspect-based Sentiment Analysis, Information Extraction, Deep Learning, Transformer Applications.

Abstract:

This study deals with aspect-based sentiment analysis, the correlation of extracted aspects and their sentiment

polarities with metadata. There are millions of review texts on the Internet that cannot be analyzed and thus

people cannot beneﬁt from the contained information. While most research so far has focused on explicit

aspects from product or service data (e.g., hotels), we extract and classify implicit and explicit aspect phrases

from German-language physician review texts. We annotated aspect phrases that indicate ratings about the

doctor’s practice, such as waiting time or general perceived well-being conveyed by all staff members of a

practice. We also apply a sentiment polarity classiﬁer. While we compare several traditional and transformer

networks, we apply the best model, the multilingual XLM-RoBERTa, to a dedicated German-language dataset

dealing with plastic surgeons. We choose plastic surgery as sample domain because it is especially sensitive

with its relation to a person’s self-image and felt acceptance. In addition to standard evaluation measures such

as Precision, Recall, and F1-Score, we correlate our results with metadata from physician review websites,

such as a physician’s gender. We ﬁgure out several correlations and present methods for analyzing unstructured

review texts to enable service improvements in healthcare.

1 INTRODUCTION

Handling unstructured data such as text has made sig-

niﬁcant progress so far. Among others, transformers

(Vaswani et al., 2017) have enabled great improve-

ments when it comes to word representations, infor-

mation extraction, or text classiﬁcation (Devlin et al.,

2019). One ﬁeld of study that has also beneﬁted from

recent developments in natural language processing

is called Aspect-based Sentiment Analysis (ABSA),

which aims to identify ﬁne-grained evaluations in

texts about products and services. ABSA extracts

words or phrases from texts and classiﬁes them ac-

cording to the rated aspects, their targets, and their po-

larities. Sentiment polarity describes whether some-

thing is talked about positively or negatively (Pontiki

et al., 2016a; He et al., 2019). Due to the nature of

natural language, the ABSA task is a challenging one

that has led to numerous studies (Li et al., 2019; Ker-

sting and Geierhos, 2020a; Kersting and Geierhos,

2020b; Kersting and Geierhos, 2021b), surveys (Do

et al., 2019; Zhou et al., 2019; Nazir et al., 2020), and

shared tasks (Pontiki et al., 2014; Pontiki et al., 2015;

Pontiki et al., 2016a; Wojatzki et al., 2017). In addi-

tion to ABSA, there is also sentiment analysis at the

document and sentence level. Both assume one opin-

ion per text or sentence and therefore do not deal with

ambivalence, sentiments on different aspects and the

granularity of human language in general.

Our goal is to investigate patient reviews for

plastic surgeons on German-language Physician Re-

view Websites (PRWs). The reasons for the use of

physician reviews lie not only in the challenging do-

main but more especially in the wording used, which

mostly consists of longer phrases and insertions. Un-

like other studies, we deal with implicit and indirect

aspect mentions. Scholars mostly used exclusively

commercial reviews (Zhou et al., 2019; Nazir et al.,

2020) for ABSA research, in which nouns often ex-

plicitly mention an aspect by its name or a synonym.

Many studies either take nouns and noun phrases for

aspect representation for granted or at least as sufﬁ-

cient (Chinsha and Shibily, 2015; Nguyen and Shirai,

2015; Pontiki et al., 2016a). The reason for this may

lie in the review domains commonly used in research.

As mentioned, these are product and service reviews

(Pontiki et al., 2016a; De Clercq et al., 2017). For

PRW data, for example, the phrase “he didn’t look

Kersting, J. and Geierhos, M.

Well-Being in Plastic Surgery: Deep Lear ning Reveals Patients’ Evaluations.

DOI: 10.5220/0010576002750284

In Proceedings of the 10th International Conference on Data Science, Technology and Applications (DATA 2021), pages 275-284

ISBN: 978-989-758-521-0

275

me in the eye” is more common than a noun-based

construction. Commercial reviews, typically used for

ABSA research, usually feature adjective-noun com-

binations such as “bright display”.

In addition to performing ABSA, we also want

to present our research design and subsequent data

analyses. Thus, we correlate our results with meta-

information from the websites. Therefore, we chose a

speciﬁc physician specialty, plastic surgery. We con-

sider our correlation results to be more valuable when

the extracted aspects, their polarity, etc., are brought

together with metadata such as assigned grades for a

particular medical specialty. This allows us to draw

conclusions if the equipment of a plastic surgeon’s

practice is of particular importance for patients.

Since our data contain indirect, complex, and long

aspect phrases, we train and compare a number of

recent deep learning approaches to ﬁnd the best per-

forming solution. To ﬁnd mentioned aspects in texts,

ABSA research has developed three subtasks: Aspect

Term Extraction (ATE), Aspect Category Classiﬁca-

tion (ACC), and Aspect Polarity Classiﬁcation (APC)

(Chinsha and Shibily, 2015). ATE means to ﬁnd and

extract aspect phrases in texts. ACC focuses on clas-

sifying them into the correct aspect category and APC

classiﬁes the extracted phrases into the appropriate

sentiment polarity class, e.g., positive or negative sen-

timent. ATE and ACC are usually performed together,

which is consistent with our previous work (Kersting

and Geierhos, 2020a; Kersting and Geierhos, 2021b).

For our deep learning approaches, we need to use

supervised deep learning, because implicit mentions

and longer phrases cannot be captured by keyword

spotting. The following sentence exempliﬁes it:

Example 1 (typical physician review). “I want to em-

phasize how well Dr. Myers conducted my plastic

surgery. Appointments are usually made to accom-

modate the wishes of the patients and waiting in the

practice never (except once) takes long. However,

I think that the newest technology is available, they

also own a new apparatus for breast examinations.

The rooms are full of light, while privacy is main-

tained.”

Example 1 shows common aspect phrases. Pre-

viously, we examined aspect classes dealing with

the doctor and his or her team (Kersting and Geier-

hos, 2021b; Kersting and Geierhos, 2021a). The as-

pect classes we examine in this study deal with the

practice of a physician: “Waiting Time for an Ap-

pointment”, “Waiting Time” (in the practice), “Equip-

ment/Facilities”, and “Well-Being”

. As the example

Translated from these German terms: “Wartezeit auf

einen Termin”, “Wartezeit in der Praxis”, “Ausstattung”,

and “Wohlf

uhlen”. The acronym wtwawo sums them up.

shows, aspect phrases are quite complex and use in-

sertions. In contrast to common product domains, it

is not mentioned that “the battery is good and the

display is bright enough”. Our examples are longer,

more complex, and have many insertions and a dif-

ferent word order because of the use of German. It

is a rather unusual style to say brieﬂy that the “wait-

ing time for an appointment is good”, it is rather said

that “you MUST wait VERY LONG to get just a tiny,

useless 3-minute appointment”.

Contributions. First, we present our annotated

dataset wtwawo, which consists of physician review

sentences that deal with the entire practice as the as-

pect target instead of focusing directly on human em-

ployees (Kersting and Geierhos, 2020a; Kersting and

Geierhos, 2020b; Kersting and Geierhos, 2021a; Ker-

sting and Geierhos, 2021b). Therefore, and second,

we contribute by training and evaluating a number

of recent deep learning architectures such as trans-

formers for ABSA. Third, we collected a dataset from

a German-language PRW that deals exclusively with

plastic surgeons. Fourth, we apply the previously de-

scribed models as well as additional models on the

gathered reviews. Fifth, we correlate and associate

our results with themselves and with metadata ob-

tained from the PRW. To get good correlation data, we

also use domain-trained transformers that have been

additionally trained on a large set of raw physician

reviews to achieve better results with deep learning

models. We also present our solution for polarity clas-

siﬁcation, for which we have also annotated data. Fur-

thermore, we apply our algorithm to determine the

relative importance of aspect phrases (Kersting and

Geierhos, 2021a).

This paper is organized as follows: Section 1 in-

troduces the topic. After that, Section 2 outlines

the relevant state-of-the-art literature, while Section 3

then presents the datasets of this study. Section 4

shows examples of typical physician reviews and de-

scribes the annotation task along with its results. Sec-

tion 5 summarizes the applied methods and their re-

sults before Section 6 concludes.

2 RELATED LITERATURE

The following areas of interest relate to the state-of-

the-art for this study: (physician) reviews, ABSA,

deep learning for ABSA, and correlation and associa-

tion techniques.

2.1 Physician Reviews

There are several studies that have looked at physi-

DATA 2021 - 10th International Conference on Data Science, Technology and Applications

276

cian reviews (Emmert et al., 2013; Kersting et al.,

2019), while most research has dealt with commer-

cial reviews (Mayzlin et al., 2014; Pontiki et al.,

2016a). Perhaps the most important ﬁnding regard-

ing physician reviews is that trust is extremely impor-

tant (Kersting et al., 2019), while ratings are mostly

positive and the PRWs have some shortcomings (Em-

mert et al., 2013). However, medical treatments are

the most difﬁcult domain to rate (Zeithaml, 1981).

2.2 Aspect-based Sentiment Analysis

While most researchers have not looked at ABSA and

physician reviews or comparable data domains, we

have recently attempted to bridge the gap and use so-

phisticated PRW data to perform real-world analyses

(Kersting and Geierhos, 2020a; Kersting and Geier-

hos, 2020b; Kersting and Geierhos, 2021b). That

is, in previous work we have investigated implicitly

mentioned aspect phrases, focusing on a human-like

language understanding. Many other works rely on

nouns, seed words, etc. As an example, scholars write

that “[a]n opinion target expression [...] is an explicit

reference (mention) to the reviewed entity [...]. This

reference can be a named entity, a common noun, or a

multi-word expression” (Pontiki et al., 2016b). Given

the complexity and diversity of human language, such

approaches do not go far enough.

Most previous studies use this understanding

based on commercial review data (Pontiki et al.,

2016a; Pontiki et al., 2015; Pontiki et al., 2014) and

also often do not perform ATE (Zhou et al., 2019). It

is important that most studies use the same data (Zhou

et al., 2019), as the data will shape subsequent pro-

cessing methods and machine learning approaches,

and thus subsequent research. That is, most studies

will take similar approaches for their deep learning

and other machine learning systems for ABSA. Fur-

thermore, as most studies have neglected human-like

language comprehension, they are limited in terms of

methods and data (domains) (Kersting and Geierhos,

2020a; Kersting and Geierhos, 2020b; Kersting and

Geierhos, 2021b) and thus cannot be applied to physi-

cian reviews. We focus here on implicit aspect men-

tions, insertions, and how we have applied human un-

derstanding without limiting the aspects that may be

annotated.

2.3 Deep Learning for ABSA

In this study, we want to compare a number of deep

learning approaches for ABSA. In our previous work

(Kersting and Geierhos, 2021b), we compared neu-

ral networks using (bidirectional) Long-Short Term

Memories ((bi)LSTMs) (Hochreiter and Schmidhu-

ber, 1997; Schuster and Paliwal, 1997) with Condi-

tional Random Fields (CRFs) (Lafferty et al., 2001) or

Attention (Vaswani et al., 2017). We combined them

with word embedding techniques that compute vector

representations for words and n-grams, i.e., parts of

words. We successfully used FastText (Bojanowski

et al., 2017) that equates word representations with

representations for partial word units. However, this

is a static method of embedding computation, newer

approaches compute such embeddings ad-hoc based

on context or they can be ﬁne-tuned directly to down-

stream tasks. Such recent approaches are transform-

ers (Vaswani et al., 2017) such as XLM-RoBERTa

(Conneau et al., 2020) or BERT (Devlin et al., 2019).

While these outperform previous research, methods

such as FastText can keep up to some extent (Kersting

and Geierhos, 2020a; Kersting and Geierhos, 2021b).

Nevertheless, transformers have shifted the perfor-

mance of natural language processing and emerged

a number of different model types. It is not yet

sure which one performs best for German data or for

physician reviews. Therefore, we compare a number

of pre-trained transformers for German and multiple

languages, and also domain-train them on a large cor-

pus of raw physician reviews to improve their perfor-

mance (cf. Section 5).

Here we do not only perform ABSA but also as-

pect phrase weight computation as well as metadata

correlation and association. In a related study, we dis-

cuss algorithms for calculating importance based on

the weight of an aspect phrase (Kersting and Geier-

hos, 2021a). Brieﬂy, we can say that those aspect

phrases with additional adverbs that serve as mod-

iﬁers, for example, are more important than those

without. An example is the phrase: “very pleas-

ant atmosphere” compared to “pleasant atmosphere”.

The same applies to comparative adjectives such

as “longer” or the superlative “longest”. Increased

weight, i.e., importance, means that reviewers or pa-

tients have put more emphasis on what they have writ-

ten and have thus elaborated it a bit more.

2.4 Correlation and Association

There are several methods we introduce to correlate

and associate our data. For correlating numbers, we

used the Spearman’s correlation coefﬁcient (Spear-

man, 1904), which is a standard measure that shows

how two columns of data correlate with each other on

a scale from −1 to +1 (perfect monotonic relation-

ship), where 0 means no association. Correlations are

also called associations and do not indicate a causal

relationship. This means, for example, that a negative

Well-Being in Plastic Surgery: Deep Learning Reveals Patients’ Evaluations

277

correlation indicates that a higher value of x is associ-

ated with a lower value of y (Schober et al., 2018). We

use this measure instead of Pearson’s correlation coef-

ﬁcient because we do not expect to have normally dis-

tributed data (i.e., a bell-shaped curve) (Rodgers and

Nicewander, 1988). For instance, quantitative scores

from PRWs can be used, but our observations show

that they are mostly positive.

For data that are not numerical or cannot be rep-

resented by numbers, we used a (different) measure

of association, Cram

er’s V (Acock and Stavig, 1979),

which measures the association between two cate-

gorical variables. That is, Cram

er’s V describes the

strength, not the direction, of an association (Benning,

2021).

3 DATA

In this section, we ﬁrst brieﬂy describe the raw data

and then the data on plastic surgeons.

3.1 Raw Data from PRWs

All available raw data were crawled from three

German-language PRWs, mostly between March and

July 2018. We aim at a platform-independent ap-

proach and thus collected data from more than one

platform. We started with a crawler that collected all

physician proﬁle links to cause as few website hits

as possible. In total, there are over 400,000 physi-

cian proﬁles on German-language PRWs and over

2,000,000 review texts in the raw dataset. Among

other things, physician reviews with associated rat-

ings, the cumulative ratings per physician, and partici-

pation in continuing medical education were crawled.

The quantitative rating systems use German and Aus-

trian school grades as well as stars. The German PRW

is by far the largest in terms of available data (physi-

cian proﬁles, reviews). Therefore, we use it as the

basis for our investigation. The German school grad-

ing system uses grades 1 − 6, starting with the best. It

should be noted that the German grade 5 means inade-

quate (“mangelhaft”), which is a devastating grade to

receive, while a 6 means insufﬁcient and a total failure

(“ungen

ugend”). The number of quantitative rating

classes varies widely among PRWs (Cordes, 2018;

Kersting and Geierhos, 2020a; Kersting and Geier-

hos, 2020b; Kersting and Geierhos, 2021b).

3.2 Plastic Surgery Data

In our dataset, we have over 1,600 physicians that

were labeled as male or female plastic surgeons. Over

half of them are men, less than 20% are women and

the rest have no gender assigned. However, only

over 800 reviews have cumulative ratings and not all

grades were provided. This is quite normal for plat-

forms with user-generated data that are social net-

works. We applied lower boundaries by selecting

those reviews that had both a text and a title. This

resulted in over 35,000 reviews. Counting these text-

less reviews listed on a physician’s proﬁle page, there

are over 40 ratings per physician. The cumulative

grade is 1.27, where 1.0 would be the best possible

grade. This means that German plastic surgeons are

rated well in quantitative terms. The number of re-

views with the best grade is overwhelming.

We split all collected reviews into sentences be-

fore any annotation step was performed (Kersting and

Geierhos, 2020a). However, due to quality reasons,

sentences were excluded, such as extremely short and

long ones. These quality limits included a minimum

length of the entire review text (280 characters) or

the requirement that multiple quantitative scores were

assigned to the corresponding reviews (e.g., grade

for the physician’s competence). These limits were

previously established to encourage broader research

with the data (Kersting and Geierhos, 2020a; Kersting

and Geierhos, 2020b; Kersting and Geierhos, 2021b).

Since we have a total of over 2,000,000 review texts,

we were conﬁdent that exclusion of some would not

hinder the overall annotation. However, for our plas-

tic surgeon reviews, we adhere to these quality con-

straints to maintain consistency, and remain with less

than 60,000 sentences out of 16,000 reviews.

4 ANNOTATIONS

Here, we explain how we annotated the relevant data.

4.1 Aspect Phrase Annotation

To ﬁnd relevant aspect classes, we evaluated all avail-

able rating categories from the PRWs (Kersting and

Geierhos, 2021b). However, we decided to quantita-

tively combine the available classes into a set where

possible. As described, in this case we aimed at ﬁnd-

ing classes that evaluate entire medical practices. Ex-

amples of the existing classes include team compe-

tence. However, our approach is consistent with the

literature and involves our previous work that focuses

on the physician or his/her team as the aspect target

(Kersting and Geierhos, 2020a; Kersting and Geier-

hos, 2020b; Kersting and Geierhos, 2021b). In the

physician reviews, there are three aspect targets at

all. We intend to perform ATE and ACC together, as

DATA 2021 - 10th International Conference on Data Science, Technology and Applications

278

many scholars have done before (Zhang et al., 2018).

The reason for this is the mutual inﬂuence between

ATE and ACC.

Our newly annotated dataset is called wtwawo,

which is an acronym for the German names of the

aspect classes it contains. As described in Section 1,

these are: “Waiting Time for an Appointment”, “Wait-

ing Time” (in the practice), “Equipment/Facilities”,

and “Well-Being”. However, patients are extremely

concerned about how long they must wait to get an

appointment. Furthermore, they do not want to spend

a lot of time waiting when they have arrived at a prac-

tice (cf. Section 5). The following list explains the

used annotation labels and their topics:

• “Waiting Time for an Appointment” deals with the

perceived duration of time a patient has to accept

to get an appointment: “Got an appointment the

next day!”

• “Waiting Time” (in the practice) also describes the

subjectively perceived time a patient has to wait in

the physician’s practice: “It took more than one

hour for my name to be called.

• Patients use “Equipment/Facilities” to describe

a physician’s technological equipment and tools:

“Her practice has the latest X-ray machine.”

• “Well-Being” describes the subjective well-being

felt in the practice and how comfortable visitors

feel in its rooms: “The treatment took place in a

very pleasant, relaxed atmosphere.” “The prac-

tice is also very nice and spacious, there is water

and tea in the waiting room.”

PRWs focus on doctors and reviews about them.

This may be the reason why most sentences do not

contain aspect phrases that deal with the practice. As

can be seen in the list above, the classes are quite

broad, especially the last two. However, there were

classes related to similar topics, which encouraged us

to merge them into one global “Well-Being” class. We

also felt that the well-being factor of a practice should

be presented after reading review texts.

Active learning was performed once for all pack-

ages before annotations began, consistent with previ-

ous work (Kersting and Geierhos, 2021b). Our goal

was to ﬁnd sentences that generally contain an evalu-

ative statement. Therefore, a neural network classiﬁer

was used. Then, the annotations for wtwawo started.

The process was carried out mostly by one per-

son and followed the general approach of our pre-

vious work (Kersting and Geierhos, 2020a; Kersting

and Geierhos, 2021b). Because we looked for exter-

nal help, two external persons were involved in the

annotation. Three internal staff members took turns

reviewing the annotations of the two external persons.

All were trained German linguists and language spe-

cialists. The ﬁrst external person was only available

for a short period of time. Since we were unsure

about the quality of his annotations, we kept only the

sentences that contained aspect phrases (several hun-

dred) and reviewed them. In the following, we ex-

cluded all sentences without aspect phrases from this

ﬁrst phase. This, and the fact that we applied ac-

tive learning, caused the number of sentences without

aspect phrases in them to shrink dramatically. Con-

sistent with out earlier studies, we applied an active

learning approach several times, in agreement with

our previous studies (Kersting and Geierhos, 2021b)

(multi-label, multi-class classiﬁcation) to pre-select

sentences with a higher probability of containing one

of the four aspect classes. The reason is that, in part,

we had to annotate several dozen sentences until a

sentence with aspect phrases appeared. In the end,

we have over 8,000 sentences, most of which, i.e.,

over 7,000, contain aspect phrases. This contrasts our

earlier work (Kersting and Geierhos, 2020a; Kersting

and Geierhos, 2021b), where we were dealing with a

higher number of sentences.

The annotations were consistently monitored dur-

ing the annotation process by discussing them in the

annotation team. In the end, we scanned almost all

sentences with aspect phrases for errors and deleted

them generously from the dataset (< 400), resulting

in higher data quality. Examples of errors include

missing attention to context, incorrectly assigned la-

bels or annotated phrases that are either too short or

too long. During annotation, it was possible to label

multiple aspect phrases in a sentence and most sen-

tences tended to be colloquial and thus unstructured.

Users tend to write as they would speak. Annotation

at the sentence level was sufﬁcient for this type of data

(Kersting and Geierhos, 2020a; Kersting and Geier-

hos, 2021b). Many also contain insertions making

the annotation task more difﬁcult: “I love visiting his

practice because the atmosphere, and this is some-

thing interesting (after last Thursday), is lovely and

charming, because of the beautiful pictures that hang

everywhere.”

Table 1: Inter-Annotator Agreement (IAA) for our anno-

tated wtwawo dataset.

Annotators Cohen’s Kappa Krippendorff’s

Alpha

R & Y 0.710

0.768R & J 0.871

Y & J 0.727

The nature of the review texts made the annotation

task highly difﬁcult. Inter-annotator agreement (IAA)

was calculated based on the tagged words, so we as-

Well-Being in Plastic Surgery: Deep Learning Reveals Patients’ Evaluations

279

signed a tag to each word in a sentence indicating a

class. All words that were not annotated with one of

the wtwawo classes were assigned a “no class” tag. We

compared the annotations of the second external an-

notator, who performed the majority of annotations,

and randomly selected about 340 sentences (Kersting

and Geierhos, 2020a). The scores of all IAAs can be

found in Table 1. The Cohen’s Kappa values (Cohen,

1960) show a “substantial” agreement (0.61–0.80) for

two of three pairs of annotators. “R & J” achieved

an “almost perfect” agreement (0.871) (Landis and

Koch, 1977). Krippendorff’s Alpha (Krippendorff,

2011) is considered to be good, being close to 1.0.

All in all, the agreements are more than satisfactory

and reward the challenging annotation task and the

amount of manual effort involved.

4.2 Sentiment Polarity Annotation

We performed the sentiment polarity annotations in a

different way. For instance, in most cases the distinc-

tion between aspect phrases and sentiment words is

not possible for physician reviews, which the exam-

ples demonstrate: “A friendly doctor.” Another ex-

ample could be that “water and tea”, as shown in the

list above, are an implicit indicator of the class “Well-

Being”. These words convey the feeling that it would

not be possible to identify a polarity word and a word

indicating the aspect class in the phrase. Therefore,

we extracted aspect phrases from the wtwawo dataset

and annotated them with respect to polarity. As it

turned out, it is only possible to assign positive or neg-

ative polarity, another scale is not adequate

5 METHODS AND RESULTS

In the following, we present our extraction and polar-

ity classiﬁcation approaches for aspect phrases before

discussing the results obtained on plastic surgery data.

5.1 Aspect Phrase Extraction

We trained supervised learning algorithms on the ba-

sis of previous research and investigated neural net-

work approaches. In addition to our biLSTM al-

gorithms (Kersting and Geierhos, 2021b), we also

used numerous transformers. As tests revealed, we

do not have enough PRW data to train a transformer

We also extracted aspect phrases from related datasets

dealing with a physician as the aspect target (Kersting and

Geierhos, 2021a; Kersting and Geierhos, 2021b).

The generation of this dataset and the classiﬁcation

methods are prior work (Kersting and Geierhos, 2021a).

from scratch (no useful results). Here, we turned to

those available for German data from Huggingface

and a multilingual model (XLM-RoBERTa). These

were further domain-trained on raw physician review

texts (Kersting and Geierhos, 2021a). That is, as Ta-

ble 2 shows, we have ﬁne-tuned both: pre-trained

transformers and further domain-adapted transform-

ers. The domain-trained models are marked with a

“+”. FastText can keep up with transformers to some

extent, as described, which is why we included it here.

We want to further explore the use of transformer

models for our case.

Our experimental setup refers to IO (Inside, Out-

side) tags for ATE and ACC (Kersting and Geierhos,

2020a), e.g., “I-waiting time T”. During domain-

training transformers, the loss for XLM-RoBERTa

(base) was about 0.37 after 4 epochs, while for most

German-language models such as BERT (bert-base

cased) it was about 1.1–1.3 after 10 epochs. This is

different for Electra (loss above 6.7), which also per-

formed poorly in the aspect extraction task (cf. Ta-

ble 2). Parameters were tuned before the ﬁnal runs.

We used a train-test split of 90%/10% of the sentences

extracted from the raw data (cf. Section 3.1).

As shown in Table 2, XLM-RoBERTa achieves

the best scores (F1: 0.86). Interestingly, it also sig-

niﬁcantly outperforms models with self-trained Fast-

Text embeddings (F1: 0.79), which in some cases per-

formed better than transformers in our previous work

(Kersting and Geierhos, 2020a; Kersting and Geier-

hos, 2021b). To obtain the best results, we performed

parameter tuning and tested different train-test splits.

Since our goal was also to maintain comparability, we

mostly used a train-test split of 80%/20% for trans-

formers (epochs: 10) and 90%/10% for the other

neural networks (epochs: 6). Because our previous

work suggested an advantage of training uncased em-

beddings (Kersting and Geierhos, 2020a), we trained

FastText vectors uncased. The reasons for this lie in

the nature of our data: Physician reviews are error-

prone and contain user-generated text with medical

terms. However, we cannot see any advantage from

this. The other models in Table 2 that are not explic-

itly labeled as (un-)cased are cased. However, some

of them are not well-documented, e.g., for MedBERT

a reference was published long after the model was

used for this study, unlike XLM-RoBERTa (Conneau

et al., 2020). Precision, Recall, and the F1-Score are

preferred over Accuracy, because Accuracy is likely

to show fuzzy results: Most words are not in an as-

pect phrase and thus labeled as “O”, so our classes are

very unbalanced. Computing Accuracy would lead to

Besides Huggingface, we thank several developers (Pe-

dregosa et al., 2011; Biewald, 2020; Hugging Face, 2020).

DATA 2021 - 10th International Conference on Data Science, Technology and Applications

280

Table 2: Results for the extraction and classiﬁcation of aspect phrases (ATE, ACC) using broadly pre-trained and domain-

trained transformers for the wtwawo dataset

Model P R F1

xlm-roberta-base+ 0.81 0.91 0.86

x biLSTM-CRF+ 0.83 0.79 0.81

x biLSTM-Attention+ 0.84 0.77 0.80

xlm-roberta-base 0.79 0.89 0.83

MedBERT+ 0.80 0.90 0.84

MedBERT 0.80 0.89 0.84

electra-base uncased+ 0.15 0.20 0.17

electra-base uncased 0.79 0.90 0.84

distilbert-base cased+ 0.81 0.89 0.85

distilbert-base cased 0.80 0.88 0.84

dbmdz bert-base uncased+ 0.81 0.90 0.85

dbmdz bert-base uncased 0.80 0.90 0.85

dbmdz bert-base cased+ 0.82 0.90 0.85

dbmdz bert-base cased 0.80 0.90 0.85

bert-base cased+ 0.81 0.90 0.85

bert-base cased 0.80 0.88 0.84

FastText biLSTM-CRF+ 0.84 0.75 0.79

FastText biLSTM-Attention+ 0.83 0.77 0.79

very high values for most models; Precision, Recall,

and F1-Score averaged across aspect classes show a

clearer picture here. To reduce the imbalance and

achieve better results, we used only the sentences con-

taining aspect phrases for training the models. As the

tests have shown, this is not an obstacle for use with

unseen data. The reason could be that the “O” tag is

disproportionately represented and hence the models

can easily identify irrelevant words.

5.2 Aspect Phrase Polarity Detection

The polarity classiﬁcation is not described in detail

here. We performed it as a binary classiﬁcation. Qual-

itative testing has shown that there are almost no

neutral aspect phrases and that there are not enough

nuances (e.g., highly positive, moderately positive,

etc.) to assign polarity scores. The models were

given the aspect phrase and the sentence as the con-

text for training. We annotated several thousand sen-

tences for this task and achieved an IAA of three times

over 0.91 for Cohen’s Kappa and over 0.91 for Krip-

pendorff’s Alpha. This is considered as almost per-

fect. For the application, we chose XLM-RoBERTa,

which achieved an F1-Score of 0.94 (Precision: 0.93,

Recall: 0.95). XLM-RoBERTa outperformed other

transformers trained for German.

P = Precision, R = Recall, F1 = F1-Score. All pre-

trained transformer models are in German and are accessi-

ble with their names on https://huggingface.co/models, ac-

cessed 2020-12-28. BiLSTM-CRF and Attention models

are based on previous work (Kersting and Geierhos, 2021b).

5.3 Application to Plastic Surgery Data

Our aspect phrase importance calculation works by

identifying phrases that may indicate increased rela-

tive weight, e.g., by superlative adjectives, compara-

tives, and the use of adverbs. We also tested statistical

approaches that did not succeed (Kersting and Geier-

hos, 2021a). Overall, we applied the XLM-RoBERTa

models for ATE, ACC, and APC and the aspect phrase

importance algorithm to all extracted sentences for

plastic surgeons. The results are as follows: Out

of about 60,000 sentences, almost 14,000 had aspect

phrases of the wtwawo dataset in them. This affects

over 8,000 out of 16,000 reviews (cf. Table 3).

The number of labels that appeared in plastic

surgery reviews (cf. Table 3) demonstrates the im-

portance of each label. Most notably, “Well-Being”

is featured by far the most often, followed by “Wait-

ing Time for an Appointment”. Phrases that may

be mentioned more often are more important to re-

viewers. However, mentioning things may not au-

tomatically make them important, as mentioning the

“Well-Being” can be a standard behavior of patients

Table 3: Number of appearances of each aspect class of the

wtwawo dataset after application to plastic surgery reviews.

Labels #

Waiting Time for an Appointment 3,720

Waiting Time 1,727

Well-Being 10,914

Equipment/Facilities 967

Well-Being in Plastic Surgery: Deep Learning Reveals Patients’ Evaluations

281

Table 4: Number of appearances of each aspect class related to its importance and polarity.

Labels Importance # Polarity #

Waiting Time for high 1,315 positive 3,168

an Appointment low 2,405 negative 552

Waiting Time high 755 positive 1,089

low 972 negative 638

Well-Being high 4,327 positive 10,035

low 6,587 negative 879

Equipment/ high 131 positive 902

Facilities low 836 negative 65

reviewing plastic surgeons. Hence, we applied our

aspect phrase importance algorithm that determines

the true importance on the basis of linguistic features

such as superlatives (Kersting and Geierhos, 2021a).

The results can be found in Table 4. Apart from

importance, it is notable whether aspect phrases are

rather positive or negative, i.e. how patients rate plas-

tic surgeons in their evaluative texts, apart from as-

signed grades. This is equally shown in Table 4.

As Table 4 shows, there are constantly more

aspect phrases of low or normal importance than

phrases with high importance. The same applies to

positive aspect phrases, compared to negative ones.

This is not surprising, as reviews are generally very

positive. Moreover, it can be seen that the “Equip-

ment/Facilities” are generally less important, as the

ratio of high and low importance reveals. This is

different for the “Waiting Time for an Appointment”,

“Waiting Time”, and “Well-Being”.

5.4 Association and Correlation Results

We applied a Spearman’s correlation (Spearman,

1904) in order to investigate whether labels have an

association with polarity scores. They do have a slight

positive correlation of 0.18, when transforming polar-

ity scores to 0 = negative and 1 = positive. A stronger

association can be observed when applying Cram

er’s

V (Acock and Stavig, 1979) (0.26). There is, also an

association between polarity and importance scores

(0.13). But this is not the case for a Spearman’s corre-

lation of polarity and importance. We see correlation

scores of ≥ 0.10 as notable (Xiao et al., 2016), though

larger values indicate a stronger relationship.

However, there is a negative correlation when

bringing together each occurring aspect phrase label

with the corresponding accumulated grades of physi-

cians (−0.10). Equally, when taking the average po-

larity per sentence and the accumulated grades of

physicians, they are negatively correlated (−0.11).

That is, a higher (more positive) polarity of observed

aspect phrases in the reviews comes with a better

grade. Cram

er’s V shows that polarity and accumu-

lated grades are quite notably associated (0.29).

We made other ﬁndings when organizing the data

per review. Unsurprisingly, the overall grade of a re-

view is strongly positively correlated with the physi-

cian’s accumulated grade (Spearman: 0.26; Pearson:

0.50). This is indeed a ﬁnding, because not all re-

views received a text and we only considered those

containing one of our aspect classes. There seems

to be a discrepancy between reviews with texts and

wtwawo phrases compared to those without texts. Fur-

thermore, we found that negative sentiment polarities

among the aspect phrases in a review are slightly asso-

ciated with a poorer overall grade for each review, as

Cram

er’s V reveals (0.14). This is less or almost not

the case for the physician’s accumulated grade (0.08).

When correlating the accumulated grade per

physician with the polarity of each aspect phrase

in the surgery reviews, we ﬁnd that “Well-Being”

and “Waiting Time for an Appointment” (−0.15,

−0.12) are less strongly correlated than “Equip-

ment/Facilities” or “Waiting Time” (−0.24, −0.29).

Separating the data by important aspect phrases does

not reveal new ﬁndings.

Moreover, we selected each label and the gen-

der of the physician. Then we correlated each as-

pect phrase’s polarity with the cumulative grade of

a physician. For “Equipment/Facilities”, we found

a strong difference because for males the correla-

tion was −0.23 and for females −0.46. For the

“Well-Being” class this was different (−0.27, −0.35).

There is a smaller number of female plastic sur-

geons, but in general, the observed scores for “Equip-

ment/Facilities” are applicable (−0.21, −0.45).

6 CONCLUSION

In our study, we annotated a dataset of physician re-

views that have the physician’s practice as the aspect

target. We calculated the IAA and achieved good re-

sults, which encouraged us to train and compare a

number of transformers and other neural networks to

extract implicit aspect phrases from texts, categorize

them, and assess their polarity. These ABSA steps

(ATE, ACC, and APC) were applied together with an

DATA 2021 - 10th International Conference on Data Science, Technology and Applications

282

importance weighting on a dataset of plastic surgery

reviews. We found indicators that patients care about

a physician’s practice, so they rate it quite frequently,

especially perceived well-being. In addition, gender

appears to have a strong association with the polarity

of reviews, according to our data. What is new is that

we were able to compare and correlate the polarity of

ratings with assigned scores on rating portals. Here

we found that assigned quantitative grades and polar-

ity in review texts are associated with each other.

With the methods and analyses presented here, we

are able to analyze patient reviews on a large scale

and provide physicians, their practices and hospitals

with deep insights and relevant information that can

help to improve their medical services. This can lead

to an improved curative process. Here, our goal was

to present general capabilities for further analysis that

can help medical providers understand and improve

their services in the future. Together with related

studies that address aspects targeting the physician

and his or her team, we can fully cover the topics re-

lated to healthcare providers in review texts. We can

also apply our ﬁndings to other domains in the future,

since implicit expressions indicating aspects are also

present in other challenging domains, such as every-

thing related to interpersonal communication.

ACKNOWLEDGEMENTS

This work was partially supported by the German

Research Foundation (DFG) within the Collabora-

tive Research Center On-The-Fly Computing (SFB

901). We thank F. S. B

aumer, M. Cordes, and R. R.

ulfarth for their assistance with data collection.

REFERENCES

Acock, A. C. and Stavig, G. R. (1979). A Measure of As-

sociation for Nonparametric Statistics. Social Forces,

57(4):1381–1386.

Benning, V. (2021). Cramer’s V Verstehen, Berechnen

und Interpretieren. https://www.scribbr.de/statistik/

cramers-v/. Accessed 2021-04-20.

Biewald, L. (2020). Experiment Tracking with Weights &

Biases. Technical report. Software available from

wandb.com.

Bojanowski, P., Grave, E., Joulin, A., and Mikolov, T.

(2017). Enriching Word Vectors with Subword Infor-

mation. Transactions of the ACL, 5:135–146.

Chinsha, T. C. and Shibily, J. (2015). A Syntactic Approach

for Aspect Based Opinion Mining. In Proceedings of

the 9th IEEE International Conference on Semantic

Computing, pages 24–31. IEEE.

Cohen, J. (1960). A Coefﬁcient of Agreement for Nominal

Scales. Educational and Psychological Measurement,

20(1):37–46.

Conneau, A., Khandelwal, K., Goyal, N., Chaudhary, V.,

Wenzek, G., Guzm

an, F., Grave, E., Ott, M., Zettle-

moyer, L., and Stoyanov, V. (2020). Unsupervised

Cross-lingual Representation Learning at Scale. In

Proceedings of the 58th Annual Meeting of the ACL,

pages 8440–8451, Online. ACL.

Cordes, M. (2018). Wie bewerten die anderen? Eine

ubergreifende Analyse von Arztbewertungsportalen in

Europa. Master’s thesis, Paderborn University.

De Clercq, O., Lefever, E., Jacobs, G., Carpels, T., and

Hoste, V. (2017). Towards an Integrated Pipeline

for Aspect-based Sentiment Analysis in Various Do-

mains. In Proceedings of the 8th ACL Workshop on

Computational Approaches to Subjectivity, Sentiment

and Social Media Analysis, pages 136–142. ACL.

Devlin, J., Chang, M.-W., Lee, K., and Toutanova, K.

(2019). BERT: Pre-training of Deep Bidirectional

Transformers for Language Understanding. In Pro-

ceedings of the 2019 Conference of the North Ameri-

can Chapter of the ACL: Human Language Technolo-

gies, Volume 1 (Long and Short Papers), pages 4171–

4186. ACL.

Do, H. H., Prasad, P. W. C., Maag, A., and Alsadoon, A.

(2019). Deep Learning for Aspect-Based Sentiment

Analysis: A Comparative Review. Expert Systems

with Applications, 118:272–299.

Emmert, M., Sander, U., and Pisch, F. (2013). Eight Ques-

tions About Physician-Rating Websites: A System-

atic Review. Journal of Medical Internet Research,

15(2):e24.

He, R., Lee, W. S., Ng, H. T., and Dahlmeier, D. (2019). An

Interactive Multi-Task Learning Network for End-to-

End Aspect-Based Sentiment Analysis. In Proceed-

ings of the 57th Annual Meeting of the ACL, pages

504–515. ACL.

Hochreiter, S. and Schmidhuber, J. (1997). Long Short-

Term Memory. Neural Computation, 9(8):1735–1780.

Hugging Face (2020). Hugging Face – On a Mission to

Solve NLP, One Commit at a Time. [Pretrained Mod-

els]. https://huggingface.co/models. Accessed 2020-

05-14.

Kersting, J., B

aumer, F., and Geierhos, M. (2019). In Re-

views We Trust: But Should We? Experiences with

Physician Review Websites. In Proceedings of the 4th

International Conference on Internet of Things, Big

Data and Security, pages 147–155. SCITEPRESS.

Kersting, J. and Geierhos, M. (2020a). Aspect Phrase Ex-

traction in Sentiment Analysis with Deep Learning.

In Proceedings of the 12th International Conference

on Agents and Artiﬁcial Intelligence: Special Session

on Natural Language Processing in Artiﬁcial Intelli-

gence, pages 391–400. SCITEPRESS.

Kersting, J. and Geierhos, M. (2020b). Neural Learning for

Aspect Phrase Extraction and Classiﬁcation in Senti-

ment Analysis. In Proceedings of the 33rd Interna-

tional FLAIRS, pages 282–285. AAAI.

Well-Being in Plastic Surgery: Deep Learning Reveals Patients’ Evaluations

283

Kersting, J. and Geierhos, M. (2021a). Human Lan-

guage Comprehension in Aspect Phrase Extraction

with Importance Weighting. In Kapetanios, E., Ho-

racek, H., M

etais, E., and Meziane, F., editors, Nat-

ural Language Processing and Information Systems,

vol. 12801 of LNCS. Springer. In Press.

Kersting, J. and Geierhos, M. (2021b). Towards Aspect Ex-

traction and Classiﬁcation for Opinion Mining with

Deep Sequence Networks. In Loukanova, R., editor,

Natural Language Processing in Artiﬁcial Intelligence

– NLPinAI 2020, volume 939 of SCI, pages 163–189.

Springer.

Krippendorff, K. (2011). Computing Krippendorff’s Alpha-

Reliability. Technical Report 1-25-2011, University

of Pennsylvania.

Lafferty, J., McCallum, A., and Pereira, F. C. N. (2001).

Conditional Random Fields: Probabilistic Models for

Segmenting and Labeling Sequence Data. In Pro-

ceedings of the 18th International Conf. on Machine

Learning, pages 282–289. ACM.

Landis, J. R. and Koch, G. G. (1977). The Measurement

of Observer Agreement for Categorical Data. Biomet-

rics, 33(1):159–174.

Li, X., Bing, L., Zhang, W., and Lam, W. (2019). Exploiting

BERT for End-to-End Aspect-based Sentiment Anal-

ysis. In Proceedings of the 2019 EMNLP Workshop

W-NUT: The 5th Workshop on Noisy User-generated

Text, pages 34–41. ACL.

Mayzlin, D., Dover, Y., and Chevalier, J. (2014). Promo-

tional Reviews: An Empirical Investigation of Online

Review Manipulation. The American Economic Re-

view, 104(8):2421–2455.

Nazir, A., Rao, Y., Wu, L., and Sun, L. (2020). Issues and

Challenges of Aspect-based Sentiment Analysis: A

Comprehensive Survey. IEEE Transactions on Affec-

tive Computing, pages 1–1.

Nguyen, T. H. and Shirai, K. (2015). PhraseRNN: Phrase

Recursive Neural Network for Aspect-based Senti-

ment Analysis. In Proceedings of the 2015 Conference

on Empirical Methods in Natural Language Process-

ing, pages 2509–2514. ACL.

Pedregosa, F., Varoquaux, G., Gramfort, A., Michel, V.,

Thirion, B., Grisel, O., Blondel, M., Prettenhofer, P.,

Weiss, R., Dubourg, V., Vanderplas, J., Passos, A.,

Cournapeau, D., Brucher, M., Perrot, M., and Duch-

esnay, E. (2011). Scikit-learn: Machine Learning

in Python. Journal of Machine Learning Research,

12:2825–2830.

Pontiki, M., Galanis, D., Papageorgiou, H., Manandhar, S.,

and Androutsopoulos, I. (2015). SemEval-2015 Task

12: Aspect Based Sentiment Analysis. In Proceedings

of the 9th International Workshop on Semantic Evalu-

ation, pages 486–495. ACL.

Pontiki, M., Galanis, D., Papageorgiou, H., Manandhar, S.,

and Androutsopoulos, I. (2016a). SemEval-2016 Task

5: Aspect Based Sentiment Analysis. In Proceedings

of the 10th International Workshop on Semantic Eval-

uation, pages 19–30. ACL.

Pontiki, M., Galanis, D., Papageorgiou, H., Manandhar, S.,

and Androutsopoulos, I. (2016b). SemEval-2016 Task

5: Aspect Based Sentiment Analysis (ABSA-16) An-

notation Guidelines.

Pontiki, M., Galanis, D., Pavlopoulos, J., Papageorgiou,

H., Androutsopoulos, I., and Manandhar, S. (2014).

SemEval-2014 Task 4: Aspect Based Sentiment Anal-

ysis. In Proceedings of the 8th International Workshop

on Semantic Evaluation, pages 27–35. ACL.

Rodgers, J. L. and Nicewander, W. A. (1988). Thirteen

Ways to Look at the Correlation Coefﬁcient. The

American Statistician, 42(1):59–66.

Schober, P., Boer, C., and Schwarte, L. A. (2018). Correla-

tion Coefﬁcients: Appropriate Use and Interpretation.

Anesthesia & Analgesia, 126(5):1763–1768.

Schuster, M. and Paliwal, K. K. (1997). Bidirectional Re-

current Neural Networks. IEEE Transactions on Sig-

nal Processing, 45(11):2673–2681.

Spearman, C. (1904). The Proof and Measurement of Asso-

ciation between Two Things. The American Journal

of Psychology, 15(1):72–101.

Vaswani, A., Shazeer, N., Parmar, N., Uszkoreit, J., Jones,

L., Gomez, A. N., Kaiser, Ł., and Polosukhin, I.

(2017). Attention is All You Need. In Proceedings of

the 31st Conference on Neural Information Process-

ing Systems, pages 5998–6008. Curran Associates.

Wojatzki, M., Ruppert, E., Holschneider, S., Zesch, T., and

Biemann, C. (2017). GermEval 2017: Shared Task

on Aspect-based Sentiment in Social Media Customer

Feedback. In Proceedings of the GermEval 2017 –

Shared Task on Aspect-based Sentiment in Social Me-

dia Customer Feedback, pages 1–12. Springer.

Xiao, C., Ye, J., Esteves, R. M., and Rong, C. (2016). Using

Spearman's Correlation Coefﬁcients for Exploratory

Data Analysis on Big Dataset. Concurrency and

Computation: Practice and Experience, 28(14):3866–

3878.

Zeithaml, V. (1981). How Consumer Evaluation Processes

Differ between Goods and Services. Marketing of Ser-

vices, 9(1):186–190.

Zhang, L., Wang, S., and Liu, B. (2018). Deep Learning

for Sentiment Analysis: A Survey. Wiley Interdisci-

plinary Reviews: Data Mining and Knowledge Dis-

covery, 8(4):1–25.

Zhou, J., Huang, J. X., Chen, Q., Hu, Q. V., Wang, T., and

He, L. (2019). Deep Learning for Aspect-Level Sen-

timent Classiﬁcation: Survey, Vision, and Challenges.

IEEE Access, 7:78454–78483.

DATA 2021 - 10th International Conference on Data Science, Technology and Applications

284
