A New Method of Testing Machine Learning Models

of Detection for Targeted DDoS Attacks

Mateusz Kozlowski

and Bogdan Ksiezopolski

Institute of Computer Science, Maria Curie-Sklodowska University, Akademicka 9, 20-033 Lublin, Poland

Keywords: DDoS, Targeted Attacks, Machine Learning, Testing Methods.

Abstract: Distributed Denial of Service (DDoS) is one of the most popular attacks on the Internet. One of the most

popular classes of DDoS attacks is the flood-based, which sends huge amounts of packets to the victim host

or infrastructure, causing an overload of the system. One of the attack mitigation systems is based on machine

learning (ML) methods, which in many cases has a very high accuracy rate (0.95 – 0.99). Unfortunately, most

ML models are not resistant against targeted DDoS attacks. In this article, we present the targeted attacks to

the DDoS ML-based mitigation models, which have a high accuracy. After this, we propose a new method of

testing ML-based models against targeted DDoS attacks.

1 INTRODUCTION

Distributed Denial of Service attacks have become

one of the biggest problems for technology

companies (Bouyeddou et al., 2020). ENISA reports

indicate (ENISA, 2020) that in 2019 DDoS attacks

increased by 241%. The most popular attacks are

flood-based ones and based mostly on the Layer 4

OSI model (79% of DDoS attacks were syn-floods,

9% were UDP-based floods). One of the key elements

in the mitigation of DDoS attacks is the detection of

unwanted traffic and distinguishing this from legal

traffic. DDoS detection systems are implemented

with one of the following two approaches: signature-

based or anomaly-based detection (Hodo et al., 2017).

The former is based on training detection mechanisms

to identify malicious traffic and the latter is based on

training using the patterns of normal activity. The

training methods can be categorized according to the

detection method used: machine learning models,

artificial-neural-networks, genetic algorithms,

statistics, open flow or deterministic behavioral

analysis. In the literature, such detection systems can

easily be found, and are typically focused on models

where the accuracy is above 0.99 (Braga et al., 2010;

Idhammad et al., 2018; Pei et al., 2019; Santos et al.,

2019; Sood, 2014).

https://orcid.org/0000-0001-8683-402X

https://orcid.org/0000-0003-1904-3222

Accuracy close to 1.00 is a great result and, if so,

has the problem of DDoS attack detection been

solved? The problems with the current DDoS systems

vary, including isolating the attack traffic from the

legal traffic. Systems are able to determine that there

is an attack taking place, but it is difficult to separate

one form of traffic from another and also perform the

appropriate action on the attack traffic. Another

problem is the targeted DDoS attacks (Bouyeddou et

al., 2020; Sood, 2014). In the event of such attacks,

legal traffic patterns are created, and the attack will

be executed in such a way that it follows these

patterns. In the event of such prepared DDoS attacks,

will the effectiveness of the detection models still be

close to 0.99? For this article, we conduct several

targeted DDoS attacks on selected machine learning

detection models that we built, which had been

described in previous literature, and with which we

had an efficiency of nearly 0.99. We found that the

effectiveness of DDoS attack detection models has

significantly decreased and, in many cases, is only a

few percentage points. The results obtained prompted

us to propose a new method of testing machine

learning classifiers, which involves performing

additional tests on the basis of specially-prepared

data.

728

Kozlowski, M. and Ksiezopolski, B.

A New Method of Testing Machine Learning Models of Detection for Targeted DDoS Attacks.

DOI: 10.5220/0010574507280733

In Proceedings of the 18th International Conference on Security and Cryptography (SECRYPT 2021), pages 728-733

ISBN: 978-989-758-524-1

The main contributions of the paper are as

follows:

• performing targeted UDP DDoS attacks on

machine learning models based on single

packets and time series;

• introducing the new framework of testing

ML models with extra tests; and

• creating the algorithm of generating a

directed DDoS attack, which can be used as

extra tests in the proposed framework.

The article is organized as follows. In section 1

the introduction is presented. The section 2 describes

the related work in the field. In section 3 we present

the new method of testing ML models against

targeted DDoS attacks. In section 4 the case studies

are presented, where the UDP-based targeted DDoS

attacks using single packets and time series are

presented. In section 5 we present the conclusions.

2 RELATED WORK

DDoS detection systems can take two approaches to

the data structure: a single packet selection or a flow

data (a time series of packets). In general, the authors

of previous studies rely on the classical method of

splitting datasets, and none of them test their models

on the use case of targeted attacks.

The simplest version of an anomaly-based

detection system used on single packet selection

methods was proposed in (Peraković et al., 2017).

This version focused on building artificial neural

networks using basic parameters like source IP

address, destination IP address, protocol and packet

length. The dataset was split among training,

validation, and test set and model, and achieved a

high accuracy rate of 0.95.

In (Saied et al., 2015), the authors also built an

ANN model to predict the legality of packets based

on 4 parameters: source IP address, port source,

destination port and header length. The authors

trained the model on 80% of the dataset and then

validated on another 20% of samples with 0.95

accuracy. The authors did not use other online

datasets in order to train their approach, as they

wanted to learn about the behavior of the DDoS and

in the context of genuine traffic.

In (Pei et al., 2019), the authors used Random

Forest and SVM algorithms on single packet features,

an approach that has a high detection rate of 0.99

based on the classical testing framework – wherein

the dataset is divided to train and test and use the

cross-validation method to score the model.

The second approach of building DDoS detection

system is focused on analyzing time series data. In

(Braga et al., 2010) six flow features were presented,

inter alia: the average of packets per flow; the average

of bytes per flow; the average of duration per flow;

the percentage of pair-flows; the growth of single-

flows and different ports, all of which were analyzed

using self-organizing maps. The authors achieved a

0.99 accuracy on the KDD-99 dataset.

In (Idhammad et al., 2018), the Random Forest

ensemble learning method was used, and processed

over 14 parameters, such as flow duration, number of

transmitted packets, bytes, etc. The authors used

CIDDS-001, a public dataset, to assess the proposed

approach and achieved results with an accuracy of

0.99. The dataset was split into training and test

subset with a 0.6/0.4 ratio.

In (Sood et al., 2014), the authors built ensemble

learning by using classifiers such as MLP, SVM,

KNN and DT-C4.5, and then combined predictions

by using a majority-voting method to obtain the final

output. They used NSL-KDD and KDD’99 datasets

and extracted 40 features, with a split into three

datasets: training, test and validation, and achieved

0.99 accuracy. NSL-KDD was used as the cross-

validation method.

In (Soodeh et al., 2019) the authors proposed a

novel hybrid framework based on a data stream

approach for detecting attacks with incremental

learning. They used the naïve Bayes, random forest,

decision tree, multilayer perceptron (MLP), and k-

nearest neighbors (K-NN) on the proxy side to

increase the accuracy of their results. The framework

was tested on NSL-KDD and KDCUP’99 datasets,

split into train and test subsets with a 0.85/0.15 ratio.

The authors achieved a high accuracy (more than

0.95) for each algorithm used.

3 A NEW METHOD OF TESTING

OF ML MODELS FOR

TARGETED DDOS ATTACKS

In this section, we propose a new method of testing

ML models with extra tests, which are focused on

testing targeted DDoS attacks. The specific steps are

described in the next section of the article.

3.1 Step 1: Data Processing and

Transformation

The first step of the process is to prepare data for a

machine learning algorithm. This step includes two

A New Method of Testing Machine Learning Models of Detection for Targeted DDoS Attacks

729

phases: in the first phase, data pre-processing is

performed. The second phase, which we introduce for

the first time, is the creation of the targeted set of data.

3.1.1

Step 1A: Data Pre-processing

The preparation can be defined as a three-stage

process: selecting data, pre-processing data, and

transforming data. The goal of the selecting data stage

is to define what kind of data can be gathered and

what the format of this data will be.

If the data is to be gathered, the next stage is to

pre-process the data — meaning formatting, cleaning,

and sampling the data. The data gathered may not be

in a format that is suitable for the model; thus, at this

stage, the key is to format the data, remove or fix

missing data due to leaks in the data gathering step,

and finally to select only the important features.

The last stage of ‘transforming data’ is the process

of applying a deterministic mathematical function to

the data in order to improve the interpretability and

appearance of the data.

3.1.2

Step 1B: Generating a Dataset for

Targeted Attacks

The main goal of this step is to generate a dataset

based on the statistical assumptions made on the

similarity of the feature values. This dataset will be

used as the traffic of the targeted DDoS attack. The

dataset of the targeted attacks is generated according

to Formula 1, which is a Cartesian product for a set of

predetermined features used in the model.

𝑆=𝑆





×…× 𝑆





∶= {(

𝑓

𝑣1, … ,

𝑓

𝑣𝑛 ) ∶

𝑓

𝑣1 ∈ 𝑆





∧… ∧

𝑓

𝑣𝑛 ∈ 𝑆





}

(1)

where:

– the cartesian product

F = (f

, …, f

) – the set of the features given to the

ML model;

– the first feature given to the model (for example

IP address);

– elements of i-feature, ex. f

are elements for the

first feature given to the model;

n – the n-th feature given to the model;

SL – similarity level, SL={0.00 – 1.00};

I – the indicator of similarity level: top, least or

bottom, I = {T, L, B};

𝑺

𝒇𝟏

𝑺𝑳𝑰

– the new set of the feature f1 on similarity level

equal SLI.

It is necessary to define a set of values for each of

the features (𝑺

𝒇𝒏

𝑺𝑳𝑰

) and then to define the degree of

similarity (SL). The similarity level is defined as a

percentage share of a given value in the main dataset

(MDS). The similarity may contribute to the most

frequent values (T), the least frequent values (L), or

a value in between the two (B). The similarity level

of the elements in the dataset MDS of the feature f

will be equal to 0.2T, where all the elements in this

new set will be among the 20% most frequent values

in the entire main dataset MDS for a given feature f.

3.2 Step 2: Split Data

If the data is already transformed, the next step is to

split the data into two training and test subsets or a

training, validation and test subset. The first approach

can be used in every algorithm and method. The

second approach can be used in neural networks to

perform additional test to figure out how a neural

network is fitted to data. The majority of authors use

the term ’validation data,’ which is interchangeable

with ‘test set’ incorrectly. In some papers, the authors

split data from the training dataset into 3 parts with

0.6/0.2/0.2 ratios.

3.3 Step 3: Train Model

Once the data is split, the machine learning model can

be defined and implemented. The process of fitting

the model to the data can differ due to the selected

type of algorithm. The most common algorithms used

in DDoS detection problems are classifiers: support

vector machines (SVM), K-nearest neighbors (KNN),

Decision Trees, Random Forest and neural networks.

To use these kinds of algorithms, some of the

parameters need to be defined (ex., batch size, epochs

number, number of layers and neurons).

TRAINING RESULTS. During the data training,

the model returns accuracy for training and validation

data, which in turn shows how the model is fitted to

the data. Accuracy (Acc) is defined as shown in

Formula 2. True positives (TP) is the number of

samples that are correctly predicted as legal traffic;

true negatives (TN) are samples correctly predicting

an attack; condition positive (P) is the number of legal

cases in the data; condition negative (N) is the number

of real attack cases in the data.

𝐴

𝑐𝑐= (𝑇𝑃+𝑇𝑁) / (𝑃+𝑁) (2)

where:

Acc – accuracy of the model;

TP – true positives;

TN – true negatives;

P – condition positive;

N – condition negative.

SECRYPT 2021 - 18th International Conference on Security and Cryptography

730

3.4 Step 4: Testing Model

If the model is fitted, it can be tested on the test subset.

The model is tested on the last 20% of data from the

main dataset (MDS) and for the generated targeted

dataset.

3.4.1 Step 4A: Evaluate Model with Test

Subset – Testing Results

The test is performed in the same way as during

training (Step 3) and then the accuracy is calculated

according to formula 2. This way of testing models is

easy to develop and achieves an accuracy score

near 1.0 – the most common range is between 0.92

and 0.99. However, a model fitted in this way can be

easily attacked by a targeted dataset because it can

only predict an attack if the attack comes with the

same parameters as in the training data. In this

case, we can assume that the model is fitted to the

specific data and is not able to predict new attack

vectors.

3.4.2 Step 4B: Evaluate Model with

Targeted DDoS Dataset – Extra

Testing Results

In this step, the model is tested according to the extra

prepared dataset (Step 1B), which represents the

targeted DDoS attack. The test is prepared the same

way as in Step 3 and Step 4A, and the accuracy is

calculated according to formula 2. In this step, the

model is tested according to the targeted DDoS

attack.

4 CASE STUDIES: THE TESTING

ML MODELS WITH

TARGETED DDOS ATTACKS

In this section, we would like to present our case

studies for testing ML models using the proposed

testing methods with targeted DDoS attacks. Each

case study was tested by 5 different targeted DDoS

attacks, which are represented by 5 different datasets.

The datasets were generated according to formula 1

and are presented in Tab. 1. The datasets from 1-4

were created based on the data, which was used for

model training (Step 3). Dataset number 5 was

generated from the data, which was taken from

publicly available data. Dataset number 5 can be

created without any knowledge from the training

dataset.

Table 1: The parameters of the targeted DDoS attack

datasets.

Datasets – Similarity Level Features

Dataset 1: SLI = 0.2T for F

(Top 20% from trainin

data)

= (f

, f

)

– source IP

– source port

– destination port

– header length

Dataset 2: SLI = 0.5T for F

(Top 50% from trainin

data)

Dataset 3: SLI = 0.8T for F

(Top 80% from trainin

data)

Dataset 4: SLI = 0.2L for F

(Last 20% from trainin

data)

Dataset 5: SLI = 1T for F

(Top 100% from most

popular public data)

– (f

, f

)

– source IP

– source port

– destination port

– header length =

constan

4.1 UDP Targeted DDoS Attack using

Single Packets

In the first case study, we wanted to test the model for

UDP targeted DDoS attack. In (Saied et al., 2015), the

authors used a simple multi-layer perceptron

classifier for their single packet selection approach to

DDoS detection. In this section, we tested the model

according to the proposed method.

STEP 1A. In the case study presented, we used a

dataset that was captured in the network infrastructure

of Maria Curie-Sklodowska University in Lublin,

Poland. We pre-processed this dataset by separating

data using a protocol filter – only UDP packets were

selected and four features extracted: IP source

address, source port, destination port, and header

length of the packet. Once the data was prepared,

transformation was performed only on IP addresses,

transforming four octets into one number.

STEP 1B. In this step, we generate five datasets as

described in section 4.1.

STEP 2. The dataset from STEP 1A was split into

three subsets: train, validation, and test with a

0.6/0.2/0.2 ratio.

STEP 3. Based on the model parameters from the

(Saied et al., 2015) article, we built a multi-layer

perceptron. The aim of building the model is to have

the availability of classifying the packets as illegal or

legal. Hence, we defined two hidden neural layers

with 4 and 3 neurons and one output layer with a

A New Method of Testing Machine Learning Models of Detection for Targeted DDoS Attacks

731

single neuron. The results of the training models are

presented in Tab. 2 (TRAINING RESULTS)

STEP 4A. Once the model was fitted, we performed

the cross-validation on the test subset. The test results

are presented in Tab. 3. One can notice that our model

has an accuracy equal to 0.97.

Table 2: The training results for the MLP classifier.

Metric Accuracy

Accuracy on the train data 0.93

Loss on the train data 0.20

Accuracy on the validation data 0.97

Loss on the validation data 0.12

Table 3: The test results for the MLP classifier.

Metric Accuracy

Accuracy on the test data 0.97

Loss on the test data 0.12

STEP 4B. In this step, we tested the model for a

targeted attack. The results are presented in Tab. 4.

One can notice that the highest accuracy is equal to

only 0.2 for dataset 5, which was created without any

knowledge about the training dataset. If we create the

targeted dataset with knowledge about training

datasets (1-4), then the highest accuracy is equal to

0.07.

Table 4: The extra test results for the MLP classifier.

Dataset – Similarity Level Accuracy

Dataset 1: SLI = 0.2T for F

(Top 20% from training data)

0.00

Dataset 2: SLI = 0.5T for F

(Top 50% from training data)

0.05

Dataset 3: SLI = 0.8T for F

(Top 80% from training data)

0.04

Dataset 4: SLI = 0.2L for F

(Last 20% from training data)

0.07

Dataset 5: SLI = 1T for F

(Top 100% from most popular public

data)

0.20

4.2 UDP Targeted DDoS Attack using

Time Series

In this approach we decide to use the similar neural

network architecture as in section 4.1. and use part of

the features described in these publications. The

packets are classified as time series for attack and

legal traffic. In this section, we would like to test the

presented model according to the targeted DDoS

attacks generated based on the proposed method.

STEP 1A. In our case study, we used the public

dataset FGRP_SSDP DDos Attack (Dataset

FGRP_SSDP DDos Attack, 2020). We pre-processed

this argus dataset by extracting features into a csv file:

IP source address, source port, destination port,

number of packets in flow, total packet size in bytes

and flow duration. Once the data was prepared, the

transformation was performed only on the IP

addresses, transforming four octets into one number.

STEP 1B. In this step we generate five datasets, as

described in section 4.1.

STEP 2. The dataset from STEP 1A was split into

three subsets: train, validation, and test with a

0.6/0.2/0.2 ratio.

STEP 3. Based on the model parameters from section

4.1, we built a multi-layer perceptron. The model

configuration used in this case study is the same as in

the previous section. The results are presented in Tab.

5. The accuracy is very high.

Table 5: The training results for the MLP classifier for case

study 2.

Metric Accuracy

Accuracy on the train data 0.97

Loss on the train data 0.09

Accuracy on the validation data 0.99

Loss on the validation data 0.01

STEP 4A. Once the model was fitted, we performed

the cross-validation on the test dataset. The result of

this step is presented in Tab. 6. The accuracy for the

test is very high and is equal to more than 0.99.

Table 6: The test results for the MLP classifier for case

study 2.

Metric Results

Accuracy on the test data 0.99

Loss on the test data 0.01

STEP 4B. In this step, we tested the model for a

targeted attack. Similar to case study number one, we

used the five datasets described in Tab.1. The results

are presented in Tab. 7. One can notice that the

SECRYPT 2021 - 18th International Conference on Security and Cryptography

732

highest accuracy is equal to 0.50 for dataset 1. In this

case, we need to have information about the 0.20 of

the most popular traffic in the tested network. If we

have knowledge about 0.50 of the traffic, then the

accuracy is equal to 0.16. For dataset number 3

(knowledge about 0.80 of traffic), the accuracy is

equal only to 0.05. If we create the targeted dataset

without any knowledge about the training datasets,

then the accuracy is equal to 0.41.

Table 7: The extra test results for the MLP classifier for case

study 2.

Dataset – Similarity Level Accuracy

Dataset 1: SLI = 0.2T for F

(Top 20% from training data)

0.50

Dataset 2: SLI = 0.5T for F

(Top 50% from training data)

0.16

Dataset 3: SLI = 0.8T for F

(Top 80% from training data)

0.05

Dataset 4: SLI = 0.2L for F

(Last 20% from training data)

0.02

Dataset 5: SLI = 1T for F

(Top 100% from most popular public

data)

0.41

5 CONCLUSIONS

The machine learning methods used for the detection

and mitigation of DDoS attacks are very effective,

especially for unknown attacks. Many models exist in

the literature, which have very high accuracies,

according to the tests based on the datasets split into

train and test or train, validation and test subsets. In

this article, we performed targeted UDP DDoS

attacks on machine learning models based on single

packets and time series. We have shown that models

with very high accuracy (0.97 and 0.99) in standard

tests are not resistant to a targeted DDoS attack. The

prepared tests require different levels of knowledge

about the traffic, and one of the levels assumes that

the attacker has no knowledge about the network. For

ML models, which analyze single packets, the

accuracy for targeted attacks is equal to a maximum

of only 0.20. In accuracy for ML models, which

analyze traffic as the time series, the accuracy for

targeted attacks is a maximum equal to 0.50. In our

article, we have proposed a new method of testing

ML models for targeted DDoS attacks. We have

created the algorithm for generating a targeted DDoS

attack, which assumes different knowledge levels

about the tested traffic. In this article, we would like

to show that it is important to extend the testing of the

machine learning.

REFERENCES

Bouyeddou, B., Kadri, B., Harrou, F., Sun, Y.: DDOS-

attacks detection using an effi-cient measurement-

based statistical mechanism. In: Engineering Science

and Technol-ogy, an International Journal, Volume 23,

Issue 4 (2020).

ENISA Threat Landscape 2020 - Distributed denial of

service. https://www.enisa.europa.eu/publications/enisa-

threat-landscape-2020-distributed-denial-of-service

Hodo, E., Bellekens, X., Hamilton, A., Tachtatzis, C.,

Atkin, R. – son: Shallow and deep networks intrusion

detection system: A taxonomy and survey,” In: arXiv

preprint arXiv:1701.02145 (2017).

Braga, R., Mota, E., & Passito, A.: Lightweight DDos

Flooding Attack Detection Using NOX/OpenFlow. In:

35th Annual IEEE Conference on Local Computer

Networks. Denver, Colorado (2010).

Idhammad, M., Adfel, K., & Belouch, M.: Detection

System of HTTP DDoS Attacks in a Cloud

Environment Based on Information Theoretic Entropy

and Random Forest. In: Security and Communication

Networks, Volume 2018.

Pei, J., Chen, Y., & Ji, W.: A DDoS Attack Detection

Method Based on Machine Learning. In: Journal of

Physics, Conference Series 1237 032040 (2019).

Santos, R., Souza, D., Santo, W., Ribeiro, A., Moreno, E.:

Machine learning algorithms to detect DDoS attacks in

SDN. In: Concurrency Computat Pract Exper. 2019;

e5402. John Wiley & Sons, Ltd. (2019).

Sood, A., Enbody, R.: Targeted Cyber Attacks. In: Syngress

(2014).

Peraković, D., Periša, M., Cvitić, I., & Husnjak, S.: Model

for Detection and Classifica-tion of DDoS Traffic

Based on Artificial Neural Network. In: Telfor Journal,

Vol. 9, No. 1 (2017).

Saied, A., Overill, R. E., & Radzik, T.: Detection of known

and unknown DDoS attacks using Artificial Neural

Networks. In: Elsevier B.V (2015).

Soodeh, H., Mehrdad, A.: The hybrid technique for DDoS

detection with supervised learning algorithms. In:

Elsevier B.V (2019).

Dataset FGRP_SSDP DDos Attack. University of Southern

California-Information Sci-ences Institute (2020).

A New Method of Testing Machine Learning Models of Detection for Targeted DDoS Attacks

733
