Using Program Analysis to Identify the Use of Vulnerable Functions

Rasmus Hagberg

1,2

, Martin Hell

and Christoph Reichenbach

Department of Computer Science, Lund University, Box 118 Lund, Sweden

Debricked AB, Malm

o, Sweden

Department of Electrical and Information Technology, Lund University, Box 118 Lund, Sweden

Keywords:

Software Security, Vulnerabilities, Call Graphs, Open-source Software, Vulnerability Analysis.

Abstract:

Open-Source Software (OSS) is increasingly used by software applications. It allows for code reuse, but

also comes with the problem of potentially being affected by the vulnerabilities that are found in the OSS

libraries. With large numbers of OSS components and a large number of published vulnerabilities, it becomes

challenging to identify and analyze which OSS components need to be patched and updated. In addition

to matching vulnerable libraries to those used in software products, it is also necessary to analyze if the

vulnerable functionality is actually used by the software. This process is both time-consuming and error-

prone. Automating this process presents several challenges, but has the potential to signiﬁcantly decrease

vulnerability exposure time. In this paper, we propose a modular framework for analyzing if software code is

using the vulnerable part of a library, by analyzing and matching the call graphs of the software with changes

resulting from security patches. Further, we provide an implementation of the framework targeting Java and

the Maven dependency management system. This allows us to identify 20% of the dependencies in our sample

projects as false positives. We also identify and discuss challenges and limitations in our approach.

1 INTRODUCTION

Vulnerabilities in third-party or open-source software

(OSS) is not a new problem, but as organizations,

society, and even our critical infrastructure become

increasingly dependent on software-based systems,

handling such vulnerabilities becomes more impor-

tant. In 2020, Synopsys reported that 99% of au-

dited codebases contained open source components

and on average 70% of the codebase was open-source

code (Synopsys, 2020).

Better understanding and efﬁciently reacting to

vulnerabilities is both a technical and an organiza-

tional challenge (Alomar et al., 2020; H

ost et al.,

2018). From a technical perspective, the increased

use of OSS together with the high increase in reported

vulnerabilities in the last few years (NIST, 2021) re-

quire technical tools for identifying, analyzing, and

prioritizing remediation of vulnerabilities. Fully au-

tomating this process will decrease remediation time

and shrink the attack surface. However, such automa-

tion is difﬁcult due to incompatible data formats, in-

accurate and incomplete data on e.g., NVD, and the

possibility of breaking changes when updating to new

versions (Xavier et al., 2017; Anwar et al., 2020).

Still, recent research has shown that both a compre-

hensible understanding of the problem, as well as

machine learning-based algorithms can facilitate in-

creased automation (W

areus and Hell, 2020).

In this paper, we consider the problem of assess-

ing whether a codebase is using vulnerable function-

ality. More speciﬁcally, we present a framework for

automatically analyzing a codebase that depends on

code with a known vulnerability and determining if

the codebase can execute the vulnerable parts of that

code. Though software might use a vulnerable ver-

sion of a library, if the vulnerable functions are not

called by the software, this should be seen as a false

positive, allowing efforts to instead focus on mitigat-

ing actually exploitable vulnerabilities. Our frame-

work consists of comparing the call graph of software

to the changes made between vulnerable and non-

vulnerable versions of a library. Moreover, we imple-

ment the framework for the Java programming lan-

guage with the Maven dependency management sys-

tem. This allows us to evaluate the performance of

such an automated tool and to identify speciﬁc chal-

lenges to a successful and efﬁcient deployment.

The paper is outlined as follows. Some back-

ground is given in Section 2. The overall framework is

Hagberg, R., Hell, M. and Reichenbach, C.

Using Program Analysis to Identify the Use of Vulnerable Functions.

DOI: 10.5220/0010548205230530

In Proceedings of the 18th International Conference on Security and Cryptography (SECRYPT 2021), pages 523-530

ISBN: 978-989-758-524-1

523

described in Section 3, our implementation is given in

Section 4 and the evaluation results are given in Sec-

tion 5. Section 6 describes limitations and scalability

considerations. We discuss related work in Section 7

and conclude in Section 8.

2 BACKGROUND

2.1 Software Vulnerabilities

Vulnerabilities can be found in several places,

including issues, advisories, and mailing lists, but

the largest public database is NVD, maintained by

NIST, with a current collection of about 150k vulner-

abilities. These are enumerated using the Common

Vulnerabilities and Exposures (CVE) scheme (The

MITRE Corporation, 2021), maintained by MITRE.

NVD adds information that is useful for analyzing

the vulnerabilities. This includes e.g., CPE (Common

Platform Enumeration) identiﬁers (NIST, 2011). A

CPE is a standardized representation of a software

library. It is given by a string,

cpe:2.3:a:vendor:product:version:*:*:*...

In addition to specifying vendor, product, and ver-

sion, as above, the string supports several additional

attributes, such as update, language, target software

and hardware, etc. In order to identify the use of vul-

nerable libraries, the library version can be matched

against the CPEs for a given vulnerability. This as-

sumes that a correct CPE for a library can be deter-

mined, e.g., from the dependency management sys-

tem. The Maven dependency management system

lists the dependencies of a project in a ﬁle named

pom.xml. This XML ﬁle

deﬁnes a dependency us-

ing three main attributes.

• groupId. This should be unique for an organiza-

tion or project.

• artifactId. This points out the speciﬁc project.

• version. This gives the version of the dependency

or a valid range of versions that Maven can down-

load and link at compilation time.

The discrepancy between CPEs, as used by e.g., NVD

and the Maven dependency data causes additional

challenges when identifying potentially vulnerable li-

braries.

See https://maven.apache.org/pom.html for details.

2.2 Call Graphs

A call graph is a graph that describes which method

(function, subroutine, . . . ) in a program can call

which other methods (Ryder, 1979). The graph repre-

sents each method as a node and each potential call as

an edge from a caller to a (potential) callee. When a

method m

can reach a method m

by following a path

(a sequence of edges) in the call graph, the call graph

predicts that a call to m

might (indirectly) result in a

call to m

In software security, we are mainly interested in

sound call graphs, i.e., call graphs that conservatively

approximate all possible calls. In a sound call graph,

the absence of a path from the node for method m

the node for method m

means that a call to m

can

never result in the call to method m

Program analysis researchers have developed a

number of techniques for automatically extracting

call graphs from software. For example, dynamic call

graph analysis (Xie and Notkin, 2002) computes pre-

cise call graphs by running a program through a test

suite and observing which calls go to which methods;

however, the resultant dynamic call graphs lack any

edges that were not exercised in the test suite, mean-

ing that they are not (generally) sound.

Static call graph analysis, by contrast, examines

the program’s structure and produces conservative ap-

proximations. Much of the work in this area has

been on increasing precision, i.e., eliminating impos-

sible call edges (Smaragdakis et al., 2015). In a re-

cent analysis, Sui et al. provide an overview over

the main static techniques (Sui et al., 2020), but also

observe that the state of the art does not produce

sound call graphs: They report a median recall of

88.4%, or 93.5% with more expensive modeling for

dynamic language features. These algorithms can

miss call edges due to “dynamic” language features

such as reﬂective calls (e.g., Java’s Method::invoke)

or dynamic linking (e.g., POSIX’ dlopen), but espe-

cially due to native (e.g., Java-to-C) calls. For highly

dynamic languages such as JavaScript that heavily

rely on dynamic code loading and code generation,

static call graph construction is particularly challeng-

ing (Antal et al., 2018).

3 FRAMEWORK OVERVIEW

In this section, we describe an overall framework for

determining if a piece of software is using the vulner-

able function. An overview of the framework is given

in Figure 1.

First, we detect which libraries, and versions, are

SECRYPT 2021 - 18th International Conference on Security and Cryptography

524

Figure 1: Vulnerable Functionality Framework.

used by the software. This can be done in sev-

eral ways, e.g., through a software Bill of Materials

(BoM), scanning of the sources, or by analyzing the

dependency ﬁle used by dependency managers. It is

important to detect not only the direct dependencies

used but also all transitive dependencies, as vulnera-

bilities can be located also in these. The next step is

to detect vulnerabilities in the used libraries. Vulner-

abilities can be identiﬁed e.g., using NVD, but other

databases or sources can also be used. With a match

between a CPE and a used library, we proceed with

the library vulnerability marking and client code anal-

ysis respectively in order to detect if vulnerable func-

tionality is being used.

3.1 Library Vulnerability Marking

When a piece of software calls a library with a

known vulnerability, the software may be vulnerable.

Whether it is vulnerable depends on whether the soft-

ware calls the vulnerable portion of the library’s code

in a way that exercises the vulnerability. In general,

this property is not decidable, but we can approximate

it e.g. by checking if the client software can ever call

the vulnerable library.

In our framework, we use a more precise tech-

nique, in which we mark library vulnerabilities at the

method level; i.e., we identify which methods may

trigger the vulnerability. Our technique relies on two

versions of the same library: one (referenced by the

client software) with a known vulnerability, and an-

other, later version in which the developers have ﬁxed

that vulnerability. These versions may be different re-

leases of the same library or different commits to the

library’s revision control system. We extract the mod-

iﬁed code by computing the difference between these

two versions and conservatively mark all methods that

have been changed as vulnerable. The result is a set

of potentially vulnerable methods. We then compute

uniquely identifying signatures for these methods and

store these signatures in a database. It can be noted

that this information is independent of the client code

and can be re-used for any number of clients.

Table 1: Language features that interfere with sound call

graph construction for a selection of popular languages.

The below is approximate, due to language extensions (e.g.,

inline assembly for C/C++ adds “Native Calls”-like com-

plexity) and special run-time features (e.g., the POSIX sig-

nal handling facility adds “External Callbacks”-like chal-

lenges).

C/C++ Java Python JavaScript

Not Memory Safe X

eval() X X

Dynamic Code Loading X X X X

Native Calls X X

External Callbacks VM Browser

Reﬂection X X X

Prototype Based X

3.2 Client Code Analysis

To check if a piece of client code may exercise a

known vulnerability, we link the code against its

libraries and compute the code’s call graph. We

then extract all methods that are reachable from the

client code’s entry points, compute the correspond-

ing signatures, and compare them against our signa-

ture database with library vulnerabilities. If there is a

match, we report that the client code is affected by a

vulnerability.

Our database can also track which vulnerabilities

are related to which methods, and how precise we be-

lieve our vulnerability markings to be for this library

(e.g., whether we were able to compute method-level

information at all), to improve reporting.

4 IMPLEMENTATION

Instantiating the framework requires choices and so-

lutions to a set of challenges. In this section, we de-

scribe our implementation and design decisions.

4.1 Language Support

Our techniques depend intrinsically on each program-

ming language’s semantics. Many languages have

features for indirect calls, including calls to dynam-

ically loaded or synthesized code. For example,

C/C++ support function pointers, and the lack of type

safety in C/C++ allows programmers to hide function

pointers in arbitrarily complex encodings. Dynamic

languages (JavaScript, Python etc.) provide eval()

functions (McCarthy, 1960) that execute string values

as code. All these features complicate analysis.

Table 1 provides an overview of likely challenges

in static call graph generation for several popular lan-

Using Program Analysis to Identify the Use of Vulnerable Functions

525

guages. “Dynamic Code Loading”, “Native Calls”

and “External Callbacks” allow calls to or from code

that the static analysis may not be able to see. “Re-

ﬂection” is a weakened form of eval() that allows

e.g. instantiating a class from a string that provides

the class name. “Prototype Based” refers to a dy-

namic form of inheritance that is incompatible with

most static call graph analysis techniques.

While specialized techniques can improve call

graph precision to some degree (Ko et al., 2015),

sound call graph construction may still identify a

very high number of false positives, and practical call

graph construction algorithms may choose to relax

soundness in favor of higher precision. If the extent

of this relaxation is clearly speciﬁed, we refer to the

relaxed analysis as “soundy” (Livshits et al., 2015).

A productionized version of our approach could com-

bine soundy call graph analysis with a sound detector

for all sources of unsoundness, for manual inspection.

Our implementation targets Java, due to the ma-

turity of Java tooling. Java is memory safe and has

no built-in eval(), but supports dynamic loading and

reﬂection (Li et al., 2019).

4.2 Library and Vulnerability Detection

To favor simplicity and ease of use, as much of the

process as possible should be automated. Thus, an

implementation should be integrated with a devel-

oper’s existing toolchain. In modern development,

delivering and deploying new software versions and

services is automated through Continuous Integration

and Continuous Deployment (CI/CD). The CI/CD

ﬂow automates the software development ﬂow, from

design to testing and deployment, enabling incremen-

tal roll-out of new software. This allows e.g., vulner-

able libraries to be updated without waiting for other

code to ﬁnish. Assuming such a modern, and agile,

development process, we use information that is al-

ready being submitted to the CI/CD pipeline and in-

tegrate our analysis framework with the version man-

agement system. This way, we parse the same ﬁles

that the version management system does, ensuring

that the user only needs to supply ﬁles readily avail-

able and that are anyway uploaded to version manage-

ment and CI/CD systems. This has the additional ad-

vantage of ensuring that the vulnerability ﬁlter fetches

exactly the same libraries that the code normally uses,

eliminating a potential source of error. In particu-

lar, we implement support for the Maven dependency

management system. Maven is a popular dependency

management system for Java, used for dependency

resolution, including transitive dependencies, as well

as some version management.

We use NVD for ﬁnding vulnerabilities that affect

the libraries in use. If the CPE information for a given

vulnerability matches the library version given by the

Maven dependency management system, then this li-

brary will be subject to our library analysis.

4.3 Implementing Library Analysis

With a known vulnerability, we also know the latest

vulnerable version from the CPE list on NVD. Us-

ing Maven, we fetch the ﬁrst non-vulnerable version

and compare these two. The comparison is done in

two steps. First, we use the java-diff-utils

li-

brary to produce the diff between the versions, and

the list of line numbers that are changed, added, or

removed, as well as if any new ﬁles are added to the

library. Then we use ExtendJ (Ekman and Hedin,

2007) to translate this list of ﬁles and lines into a list

of Java classes and methods. Then, these classes and

methods are converted into unique signatures. These

signatures uniquely identify a method or class, and so

we are able to know which methods and classes have

changed between the vulnerable and ﬁxed versions.

This list is stored in a database for later use.

This process of library analysis is fully automated,

from determining the non-vulnerable version to pro-

ducing the output with signatures. However, automa-

tion here comes with a cost. Versions susceptible to a

vulnerability (and by the method of elimination which

versions are not) are available from the vulnerability

database. Which speciﬁc commit includes the ﬁx is

however not available. Because of this, we limit our-

selves to analyzing released versions, possibly intro-

ducing some false positives when the releases include

more updates than just the vulnerability patch.

4.4 Implementing Client Code Analysis

For client code analysis, we construct a call graph of

the client code. As we detail in Section 5, test cover-

age is very low for many projects. Thus, we choose

the static approach over a dynamic one.

We create the call graph using the Soot (Vall

ee-

Rai et al., 1999) static analyzer, using the Class Hier-

archy Analysis algorithm (Dean et al., 1995). Soot is

a framework for Java code analysis, transformation,

and optimization, but we use it only for its ability to

generate call graphs of Java programs.

Once we have constructed a call graph over the

client code (with the included library code) we can

check this to see if it contains any of the vulnerable

signatures that we found in the library analysis phase.

Here, the Soot output is used to create signatures that

https://java-diff-utils.github.io/java-diff-utils/

SECRYPT 2021 - 18th International Conference on Security and Cryptography

526

can be matched with those computed in the library

analysis. If there is a match, we have shown that the

client is using the part of a library that changed be-

tween a vulnerable and a ﬁxed version. Thus, they are

not only using a vulnerable library but likely the spe-

ciﬁc vulnerable part of that library. We also present

the execution path to the code to inform the user

which part or parts of their codebase that is affected.

This is useful in case the library is not updated, but

the vulnerability is mitigated in another way, e.g., if

the update introduces breaking changes.

5 RESULTS

Projects using Maven were selected by searching

GitHub for projects with a pom.xml ﬁle in the root

directory of the repository and sorting by the time

GitHub indexed them. This produces a reasonably

random result and we chose 200 programs to analyze.

In the following, a “project” is a repository cloned

from GitHub, and a “dependency” is one version of

an artifact in Maven used by a project, either directly

or transitively.

We ﬁrst remove projects that are not interesting

or even possible to analyze. Out of the 200 projects,

50 failed to compile, 9 had no code to analyze, and

an additional 11 had to be excluded due to having er-

roneous or no longer working Maven conﬁgurations.

This leaves us with a total of 130 projects that can

potentially be analyzed.

5.1 Analyzable Projects

The version of Soot we use can only analyze Java ver-

sion 8 or lower code. Thus, 15 projects had to be ex-

cluded due to Soot not being able to analyze them.

One program was manually excluded since the

repository supposedly containing many of the depen-

dencies of the said program no longer did so. This left

us with a total of 114 projects that compiled, had code

to analyze, and that Soot was capable of analyzing.

5.2 Dependencies with Matching

Vulnerabilities

Of the 114 projects that we could analyze, 111 had

third-party dependencies, while 3 did not. Further,

102 projects were analyzed to have at least one depen-

dency with a CVE listed against the version in use.

In other words, 89% of the projects used dependen-

cies with known vulnerabilities, while 11% (12 out of

114) did not have any dependencies with known vul-

nerabilities (CVEs).

Table 2: Test coverage for the sampled projects.

Category Projects Can calc. Test

coverage coverage

Total projects 200 23 26.8%

Static analysis 114 20 27.2%

Vuln. dependency 76 14 16.4%

Looking at the 111 projects with dependencies, there

were in total 8701 usages of 3117 unique dependen-

cies and versions. Of the 8701 usages, 2741 were of a

dependency with a CVE listed against it, meaning that

about 32% of the time a dependency was included that

dependency had a CVE listed against it. These usages

of vulnerable dependencies represented in total 299

unique dependencies and versions.

5.3 Analyzable Dependencies

Of these 2741 usages of dependencies with CVEs

listed against them, we were not able to analyze 514

of them (19%). Out of the 2227 that we were able to

analyze, 1682 used the dependency in such a way as

to expose the vulnerable parts of the dependency. The

other 545 uses were analyzed not to use the vulnerable

functionality. This means that about 20% (545 out of

2741) of dependencies with a matching vulnerability

(CVE) were not vulnerable since the vulnerable func-

tionality was not used. If we exclude dependencies

that we could not analyze, 24% (545 out of 2227) did

not use the vulnerable functionality.

5.4 Test Coverage

Our choice of static analysis for creating the call

graph is motivated by the test coverage for the ana-

lyzed projects. To measure the test coverage, the Ja-

CoCo Maven plugin was used. Of the 200 projects,

only 32 had tests that passed and 23 of these produced

valid test coverage with JaCoCo, with an average of

26.8% reported coverage. For projects with vulnera-

ble dependencies, we found that the test coverage was

only 16.4% on average, see Table 2. This shows the

importance of using static call graph generation as op-

posed to a dynamic approach.

6 LIMITATIONS AND

SCALABILITY

In this section, we identify why some (514 out of

2741) of the dependency usages with a listed CVE

Using Program Analysis to Identify the Use of Vulnerable Functions

527

Table 3: Dependency usages that could not be analyzed for

some packages.

Project Usages that could not be analyzed

postgresql 190

jetty 75

javax mail 50

dom4j 25

apache poi 20

other 154

Total 514

Table 4: Most common reasons for why a vulnerable de-

pendency could not be analyzed.

Reason Vuln. that could

not be analyzed

Version not available 82

Versioning Scheme Mismatch 81

Dependency moved 73

Program limitations 67

No end version 26

Modiﬁer changed 12

Other 11

Total 352

could not be analyzed. Then, we also analyze the scal-

ability of our approach.

6.1 Dependencies That Could Not Be

Analyzed

We see that a small number of dependencies that are

listed in many CVEs are responsible for a large share

of these. For example, PostgreSQL alone is responsi-

ble for over a third of the vulnerability usages we are

unable to analyze, 190 of the 514. Table 3 summa-

rizes the dependencies that caused most problems.

Many of these 514 dependency usages refer to the

same 299 vulnerable dependencies, but possibly to

different vulnerabilities. We, therefore, combine ref-

erences to the same vulnerabilities in our summary in

Table 4, for a total of 352 references to different vul-

nerabilities that we could not analyze.

In 82 cases the speciﬁc version that we need for

the analysis is not available in the Maven repository,

i.e., a version referenced in NVD is not listed by

Maven at all. Similarly, we found 81 cases where

there was a versioning scheme mismatch between

NVD and Maven. This case was speciﬁc to Post-

greSQL. In some cases, we noticed that the groupId

or artifactId changed between two software versions.

Such changes in the dependency naming occurred in

73 cases. We identiﬁed 67 cases that we attribute

to limitations in the software, e.g., handling of ad-

ditional qualiﬁers and build dates in version informa-

tion. In 26 cases, NVD does not have any information

about in which version a vulnerability is ﬁxed, i.e., no

end version CPE is provided for the vulnerable soft-

ware. Finally, in 12 cases we found that a modiﬁer

changed between versions. A modiﬁer is the part of

the version string that is not dot-separated numbers.

For example, we want to compare 24.2-jre with 24.3-

jre, not with 24.3-android.

6.2 General Limitations

False positives can be introduced when computing the

diff between the last vulnerable and ﬁrst ﬁxed ver-

sion of a library, either due to more being marked

as changed than actually is changed or more being

changed than is required to ﬁx the vulnerability.

Sometimes, there is a discrepancy between the

naming schemes in the vulnerability database and the

dependency management system. This can lead to

both false negatives and false positives when names

are interpreted and matched. An example of a poten-

tial error is the spring framework. In Maven, Spring

implementations are distributed as separate packages

with the org.springframework group ID and with

artifact IDs like spring-web, spring-orm etc. In

NVD, however, no such distinction is made and CVEs

are just ﬁled against “spring framework”. Any call

graph of reasonable precision for a language such as

Java will not be sound in the general case. In other

words, errors can be introduced when creating the

call graph. The exact error depends on many de-

sign choices in the call graph analysis. We, therefore,

opted for a highly conservative call graph algorithm.

Still, some of the challenges identiﬁed in this study,

such as call graph algorithms failing to fully model

callbacks from native code may also affect the recall

of our approach.

6.3 Efﬁciency and Scalability

To be viable for larger projects, the approach needs

to scale well with project size. Large projects are

here seen as either projects with a large number of

classes and methods, or as projects with a large num-

ber of dependencies. Due to dependencies possibly

being transitive, importing one library could result in

several hundred dependencies, where some of them

can be matched against a CVE. Thus, when looking

at scaling, we analyzed two factors, namely (a) the

number of vulnerable dependencies (before analysis),

and (b) the size of the call graph.

SECRYPT 2021 - 18th International Conference on Security and Cryptography

528

0 1 2 3 4

·10

100

Call graph size

Runtime (s)

Figure 2: Call graph size vs. runtime, zoomed in on projects

with at most 500,000 call graph edges.

We ran these experiments on a Dell XPS 9350 lap-

top. Considering the running time as a function of

the number of vulnerable dependencies, the correla-

tion coefﬁcient is 0.11, indicating a very weak corre-

lation.

If we instead consider the number of edges in the

call graph, we see a much stronger correlation to the

running time. The correlation coefﬁcient is here 0.96.

For the vast majority of projects, the call graph has

fewer than 500,000 edges, with only a few outliers

in our sample. Looking at only projects with up to

500,000 call graph edges, the correlation coefﬁcient

is 0.71, still a rather strong correlation. This is shown

in Figure 2, together with linear regression. The lower

correlation is due to the library analysis not being in-

cluded in the call graph size, and for large projects this

is negligible. For smaller projects, the library analy-

sis will affect the running time, but will still not be

visible when looking at the program call graph.

7 RELATED WORK

In our work, we focus on utilizing static call graphs to

improve the precision of vulnerability discovery. Our

static approach is similar to Plate et al.’s dynamic ap-

proach (Plate et al., 2015), which collects call graphs

while running tests. Thus, their approach requires a

high-quality test suite. Existing techniques for au-

tomatic test generation can aid such approaches, but

cannot supplant hand-written tests (Sui et al., 2020).

Ponta et al. expand on Plate et al.’s approach, com-

bining static and dynamic analysis (Ponta et al., 2018)

to address this limitation in a productionized tool used

internally at SAP and exploring mitigation strategies.

Their ﬁndings show that on SAP code, 7.9% of the

vulnerabilities that they detect require both static and

dynamic analysis. It is not clear how their ﬁndings

translate to software developed outside of this speciﬁc

industrial environment; for instance, the low degree of

unit test coverage that we found (Section 5.4) would

severely limit their dynamic techniques. They do not

describe their call graph construction algorithm, so

we cannot make a more detailed comparison.

Our approach relies on CPE information to iden-

tify vulnerable versions of libraries. However, that

information may be incomplete or inaccurate. If the

CPE does not specify the earliest vulnerable version

of a library, we currently make the conservative as-

sumption that all versions prior to the reported ﬁx (if

any) are vulnerable. Dashevskyi et al. introduce a

technique for tracing a vulnerability backward in time

through an affected piece of software to ﬁnd out at

what point that vulnerability was ﬁrst introduced (Da-

shevskyi et al., 2019). This approach could comple-

ment our technique and reduce the false positive rate.

8 CONCLUSIONS

We have described a framework for analyzing the use

of vulnerable functionality in libraries containing vul-

nerable code. We instantiated the framework for an-

alyzing Java libraries, using data from the Maven de-

pendency management system, and evaluated them on

randomly chosen GitHub projects. Of 111 analyz-

able projects with dependencies, we identiﬁed 2741

usages of dependencies with known vulnerabilities

and successfully analyzed 2227 of these usages, of

which 545 uses did not use the vulnerable function-

ality. Though our implementation has limitations, it

provides a promising step towards fully automating

vulnerability identiﬁcation, removing false positives

stemming from a pure CPE match.

ACKNOWLEDGEMENTS

This work was partially supported by the Wallen-

berg Artiﬁcial Intelligence, Autonomous Systems and

Software Program (WASP), funded by the Knut and

Alice Wallenberg Foundation, and partially by the

Swedish Foundation for Strategic Research, grant

RIT17-0035.

REFERENCES

Alomar, N., Wijesekera, P., Qiu, E., and Egelman, S.

(2020). ”You’ve got your nice list of bugs, now

Using Program Analysis to Identify the Use of Vulnerable Functions

529

what?” vulnerability discovery and management pro-

cesses in the wild. In Sixteenth Symposium on Usable

Privacy and Security (SOUPS) 2020, pages 319–339.

Antal, G., Heged

us, P., T

oth, Z., Ferenc, R., and Gyim

othy,

T. (2018). Static JavaScript Call Graphs: a Compara-

tive Study. In Proceedings of the 18th IEEE Interna-

tional Working Conference on Source Code Analysis

and Manipulation. IEEE.

Anwar, A., Abusnaina, A., Chen, S., Li, F., and Mo-

haisen, D. (2020). Cleaning the NVD: Comprehen-

sive quality assessment, improvements, and analyses.

arXiv:2006.15074.

Dashevskyi, S., Brucker, A. D., and Massacci, F. (2019).

A screening test for disclosed vulnerabilities in foss

components. IEEE Transactions on Software Engi-

neering, 45(10):945–966.

Dean, J., Grove, D., and Chambers, C. (1995). Optimiza-

tion of object-oriented programs using static class hi-

erarchy analysis. In European Conference on Object-

Oriented Programming, pages 77–101. Springer.

Ekman, T. and Hedin, G. (2007). The JastAdd extensi-

ble java compiler. In Proceedings of the 22nd An-

nual ACM SIGPLAN Conference on Object-Oriented

Programming, Systems, Languages, and Applications,

pages 1–18.

ost, M., S

onnerup, J., Hell, M., and Olsson, T. (2018).

Industrial practices in security vulnerability manage-

ment for iot systems–an interview study. In Proceed-

ings of the International Conference on Software En-

gineering Research and Practice (SERP), pages 61–

67.

Ko, Y., Lee, H., Dolby, J., and Ryu, S. (2015). Practi-

cally tunable static analysis framework for large-scale

javascript applications (T). In 30th IEEE/ACM In-

ternational Conference on Automated Software Engi-

neering (ASE), pages 541–551. IEEE.

Li, Y., Tan, T., and Xue, J. (2019). Understanding and

analyzing java reﬂection. ACM Trans. Softw. Eng.

Methodol., 28(2):7:1–7:50.

Livshits, B., Sridharan, M., Smaragdakis, Y., Lhot

ak, O.,

Amaral, J. N., Chang, B.-Y. E., Guyer, S. Z., Khed-

ker, U. P., Møller, A., and Vardoulakis, D. (2015). In

defense of soundiness: A manifesto. Commun. ACM,

58(2):44–46.

McCarthy, J. (1960). Recursive functions of symbolic ex-

pressions and their computation by machine, part i.

Communications of the ACM, 3(4):184–195.

NIST (2011). Common Platform Enumeration: Naming

Speciﬁcation, Version 2.3, NIST Interagency Report

7695.

NIST (2021). National vulnerability database.

https://nvd.nist.gov/.

Plate, H., Ponta, S. E., and Sabetta, A. (2015). Impact as-

sessment for vulnerabilities in open-source software

libraries. In 2015 IEEE International Conference on

Software Maintenance and Evolution (ICSME), pages

411–420.

Ponta, S. E., Plate, H., and Sabetta, A. (2018). Be-

yond metadata: Code-centric and usage-based anal-

ysis of known vulnerabilities in open-source software.

In 2018 IEEE International Conference on Software

Maintenance and Evolution (ICSME).

Ryder, B. G. (1979). Constructing the call graph of a pro-

gram. IEEE Transactions on Software Engineering,

SE-5(3):216–226.

Smaragdakis, Y., Balatsouras, G., Kastrinis, G., and

Bravenboer, M. (2015). More sound static handling of

java reﬂection. In Feng, X. and Park, S., editors, Pro-

gramming Languages and Systems, pages 485–503,

Cham. Springer International Publishing.

Sui, L., Dietrich, J., Tahir, A., and Fourtounis, G. (2020).

On the recall of static call graph construction in prac-

tice. In 2020 IEEE/ACM 42nd International Confer-

ence on Software Engineering (ICSE), pages 1049–

1060. IEEE.

Synopsys (2020). Open source security and risk analysis

report. Online.

The MITRE Corporation (2021). Common Vulnerabilities

and Exposures.

Vall

ee-Rai, R., Co, P., Gagnon, E., Hendren, L. J., Lam,

P., and Sundaresan, V. (1999). Soot - a Java byte-

code optimization framework. In Proceedings of the

1999 Conference of the Centre for Advanced Studies

on Collaborative Research, CASCON ’99.

areus, E. and Hell, M. (2020). Automated cpe labeling

of cve summaries with machine learning. In Inter-

national Conference on Detection of Intrusions and

Malware, and Vulnerability Assessment, pages 3–22.

Springer.

Xavier, L., Brito, A., Hora, A., and Valente, M. T.

(2017). Historical and impact analysis of api break-

ing changes: A large-scale study. In 2017 IEEE 24th

International Conference on Software Analysis, Evo-

lution and Reengineering (SANER), pages 138–147.

IEEE.

Xie, T. and Notkin, D. (2002). An empirical study of java

dynamic call graph extractors. University of Washing-

ton CSE Technical Report 02-12, 3.

SECRYPT 2021 - 18th International Conference on Security and Cryptography

530
