MMU-based Access Control for Libraries

Marinos Tsantekidis

1 a

and Vassilis Prevelakis

Institute of Computer Science - FORTH, Greece

AEGIS IT RESEARCH GmbH, Germany

Keywords:

Runtime Monitoring, Library Calls, Access Control Gates, Security Policies.

Abstract:

Code Reuse Attacks can trick the CPU into performing some actions not originally intended by the running

program. This is due to the fact that the execution can move anywhere within a process’s executable memory

area, as well as the absence of policy checks when a transfer is performed. In our effort to defend against this

type of attacks, in an earlier paper we present a Proof-of-Concept mitigation technique based on a modiﬁed

Linux kernel where each library - either dynamically or statically linked - constitutes a separate code region.

The idea behind this technique is to compartmentalize memory in order to control access to the different mem-

ory segments, through a gate. Taking our previous work one step further, in this paper we present an updated

version of our kernel-side technique, where we implement security policies in order to identify suspicious

behavior and take some action accordingly.

1 INTRODUCTION

As the advancement of technology offers capabilities

which result in attackers on every level getting more

competent and effective, attacks have become more

elaborate. Therefore, we need to establish an ade-

quate level of security in software systems. As the

complexity of these systems is ever-increasing, we

have not seen a commensurate improvement in code

design and development. Hence, systems are becom-

ing ever more vulnerable to attacks at multiple lev-

els. Complete security of a program is unfeasible.

Conceding that vulnerable code will be included in

production systems, there is a need to detect when

one or more of these vulnerabilities is exploited by

an attacker. By monitoring the behavior of a pro-

gram, we can detect any deviations from nominal op-

eration. Once a program goes off-nominal we need to

determine whether the cause is security-related and, if

so, take appropriate action. Our idea is to implement

such actions at an abstract level, between the Operat-

ing System (OS) and a running application.

Unlike most run-time security mechanisms, where

violations in most cases lead to the termination of

the offending process, the call intercept technique

offers a variety of options in dealing with the se-

curity breach. For example, systrace(8) (Provos,

2003) may rewrite function arguments (e.g. truncate

https://orcid.org/0000-0001-6710-5972

or replace strings), or return an error without mak-

ing the call. A key concern is the level at which the

call intercept should be made. Some papers propose

to carry out the checks at the machine code level -

via call graphs (e.g., CFI (Abadi et al., 2005) and

variants), while others at the system call level (e.g.,

systrace(8)). However, because these systems per-

form the checks at fairly low level, they are quite labor

intensive and error prone and exhibit high overhead.

Coarse-grained CFI techniques mainly try to deal

with the increased performance issues of CFI, trad-

ing off security and being left vulnerable to motivated

adversaries. Finer-grained solutions provide higher

security, although even in this case studies (Evans

et al., 2015) have shown that some implementations

prove ineffective in defending against code-reuse at-

tacks (CRAs).

Contributions. In this paper, we present our hy-

pothesis that by carrying out behavioral monitoring

at a higher level, we can create a ﬂow diagram that

is closer to the program logic and hence more under-

standable. We have chosen the library function call

level as the ideal boundary to install our checks, be-

cause libraries are used by the main program but are

not part of its execution logic. We present an updated

version of our previous Proof-of-Concept mitigation

technique, behind which the idea is to compartmen-

talize memory in order to provide access control to

686

Tsantekidis, M. and Prevelakis, V.

MMU-based Access Control for Libraries.

DOI: 10.5220/0010536706860691

In Proceedings of the 18th International Conference on Security and Cryptography (SECRYPT 2021), pages 686-691

ISBN: 978-989-758-524-1

memory segments based on security policies. We ex-

tend our previous approach by installing a special cus-

tom library, a gate, one for each separate segment and

redirect the ﬂow of execution through this gate where

we enforce the relevant security policies. Our mitiga-

tion technique requires kernel support, which is on of

its strengths since we can manipulate the memory se-

curely and efﬁciently. We chose to leverage the Mem-

ory Management Unit (MMU) and speciﬁcally the

NX-bit, because it is easier to us due to our previous

development experience. To the best of our knowl-

edge, it is the ﬁrst time this is performed in this way.

Furthermore, our mechanism can be implemented on

top of other defense mechanisms.

The remainder of this paper is organized in the

following manner: Section 2 offers a brief summary

of the timeline of CRAs and related defenses. In

Section 3 we detail the design of our approach. In

Section 4, we describe the implementation speciﬁcs.

In Section 5, we evaluate our custom kernel both in

terms of effectiveness and performance. Discussion

and conclusion are provided in Section 6.

2 BACKGROUND AND RELATED

WORK

Code Reuse Attacks (CRA) work on the premise that

an adversary can use code already present in a pro-

gram’s memory space in order to mislead the CPU

to perform unintended by the program actions. So-

phisticated approaches, such as Return Oriented Pro-

gramming (ROP) (Shacham, 2007; Checkoway et al.,

2010; Roemer et al., 2012) and Jump Oriented Pro-

gramming (JOP) (Bletsch et al., 2011), form snippets

of code, “gadgets”, chaining together legitimate com-

mands already in memory, eventually forming a se-

quence of gadgets that perform the unauthorized ac-

tion desired by the attacker. Initially, CRAs were

based on the principle that gadgets are located at

known addresses in memory. Address Space Lay-

out Randomization (ASLR) (PaX, 2001) was intro-

duced as a defense measure, but was eventually by-

passed (Shacham et al., 2004).

Furthermore, Snow et al. introduced “Just-In-

Time” ROP (JIT-ROP) (Snow et al., 2013) which

maps an application’s memory layout on-the-ﬂy, thus

bypassing ASLR. Next, it constructs and delivers a

ROP payload based on collected gadgets.

Later, Bittau et al. presented Blind Return Ori-

ented Programming (BROP) (Bittau et al., 2014).

BROP works against modern 64-bit Linux with

ASLR, NX memory and stack canaries (Wagle and

Cowan, 2003) enabled. It can remotely ﬁnd enough

gadgets to perform the write(2) system call and then

transfer the application’s binary from memory to the

attacker’s socket.

Over the years, important work has been carried

out with respect to defenses against CRAs. Backes

and N

urnberger developed Oxymoron (Backes and

urnberger, 2014) to counter JIT-ROP attacks. Oxy-

moron combines two methods: ﬁne-grained memory

randomization with the ability to share the entire code

among other processes. However, in order for this

defense to be effective, an executable along with all

of its shared libraries need to be instrumented us-

ing Oxymoron (Mithra and Vipin P., 2015). In con-

trast, our approach is completely transparent, since

we require no access to the executable or its shared

libraries.

Venkat, et al. (Venkat et al., 2016) propose a se-

curity defense called HIPStR to thwart (JIT-)ROP.

HIPStR performs dynamic randomization of run-time

program state. However, this measure requires ex-

tensive run-time support to piece the randomized in-

structions back together, imposing signiﬁcant over-

head (around 15% at best), counter to our mechanism

which leaves only a minimal performance footprint.

The systrace(8) (Provos, 2003) system which

supports ﬁne-grained policy generation, guards the

calls to the operating system at the lowest level, en-

forcing policies that restrict the actions an attacker

can take to compromise a system. However, this

ﬁne-grain control is overly verbose. Additionally, it

may leave a library in an inconsistent state if a mis-

conﬁguration interrupts the sequence of these calls in

the middle of execution (Kim and Prevelakis, 2006).

Later research (Watson, 2007) showed that concur-

rency vulnerabilities were discovered, that gave an at-

tacker the ability to construct a race between the en-

gine and a malicious process to bypass protections.

Our technique operates at a higher level, away from

low level calls, closer to the application logic, fa-

cilitating the generation of policies and being more

lightweight in this way.

Access Controls For Libraries and Modules (Sec-

Module) (Kim and Prevelakis, 2006) forces user-level

code to perform library calls only via a library pol-

icy enforcement engine providing mandatory policy

checks over not just system calls, as in the case of

systrace(8), but calls to user-level libraries as well.

Access to a speciﬁc function or procedure is con-

trolled by the kernel, however the overhead of two

context switches per function invocation (caller to

kernel and kernel to caller), makes the technique quite

expensive for more general use. One of the issues

identiﬁed by the authors of the SecModule paper is

the difﬁculty in encapsulating library modules which

MMU-based Access Control for Libraries

687

was error prone and extremely labor intensive. An-

other issue is the inability to evaluate call arguments.

Although they are contained in a known structure

pointed to by a stack pointer, their examination re-

quires lots of casting in the C++ functions. In con-

trast, our approach automatically encloses libraries in

a seamless generic way, with low overhead as well as

the ability to evaluate call arguments.

Abadi et al. proposed Control-Flow Intetegrity

(CFI) (Abadi et al., 2005) which enforces the execu-

tion of a program to adhere to a control ﬂow graph

(CFG), which is statically computed at compile time.

If the ﬂow of execution does not follow the prede-

termined CFG, an attack is detected. CRAs such as

ROP and JOP by deﬁnition divert the program ﬂow,

hence they are discovered. This approach, however,

suffers from two main disadvantages. First, comput-

ing a complete and accurate CFG is difﬁcult since

there are many indirect control ﬂow transfers (jumps,

returns, etc.) or libraries dynamically linked at run-

time. Furthermore, the interception and checking of

all the control transfers incur substantial performance

overhead. Our mechanism, although implementing

a kind of CFI, deals with high-level calls to library

functions (away from the low level instructions) with

minimal run-time performance cost.

In (Kayaalp et al., 2012) Kayaalp et al. propose

Branch Regulation (BR) which limits control ﬂow

transfers to speciﬁc legitimate points, disallowing -

in effect - arbitrary transfers from one function into

the middle of another. However, it annotates the bi-

nary, resulting in increased code size. In addition, the

shadow stack used by the mechanism is not secure

since it resides in mapped memory (Christoulakis

et al., 2016). Moreover, when a legitimate direct jump

is performed (e.g. longjmp(3)) it may transfer the

control ﬂow in the middle of a function, thus throw-

ing a false-positive exception. The main advantage of

our mechanism is that it is source/binary-agnostic.

In our previous work (Tsantekidis and Prevelakis,

2017), we implement access control similar to the

work presented above. Under our scheme, each call

to an external function of a library is intercepted and

its arguments are examined to determine whether the

control ﬂow transfer is warranted. This allows high-

level checks to be carried out in a similar fashion

to the systrace(8) engine (Provos, 2003) – which,

however operates at the system call level – and Sec-

Module (Kim and Prevelakis, 2006) that introduces a

form of authentication when calling functions from a

library. Our approach is transparent to the user appli-

cations, since it can work in the background without

the applications ever knowing its existence. Further-

more, there is no need to have or modify the source

code of any application, making the mechanism suit-

able for legacy applications as well as binary pro-

grams. Since this is a user-space mechanism, there

is no need to invoke the kernel, meaning there are no

context switches, which saves performance overhead.

Additionally, it can be easily adopted in real-life en-

vironments. However, our approach is not without its

disadvantages. It relies on dynamic library hooking,

so it is unsuitable to trace statically-linked applica-

tions. There is, also, a slight increase in code size

compared to the original library version. Moreover,

it can only protect programs written in C/C++ and it

can be bypassed by a highly-skilled attacker who is

aware of its existence and is able to manipulate the

program’s memory.

3 DESIGN

The goal of our proposed approach is to thwart

control-ﬂow hijacking attacks by segregating a pro-

cess’s executable areas which correspond to exter-

nal libraries or the main executable and by impos-

ing strict control over any attempt to invoke such an

area, through a policy enforcement engine. In order

to achieve this, we set a number of requirements that

our mechanism must fulﬁll:

(R1) Effectiveness: Intercept every attempt to access

a protected region and redirect it inside the asso-

ciated gate.

(R2) Transparency: Allow applications to continue

working as originally intended by the developer,

while our access control mechanism delivers a se-

cure run-time environment.

(R3) Efﬁciency: Minimize run-time and memory

overhead imposed by our implementation.

To abide by these requirements, we propose a cus-

tomized Linux kernel that leverages the MMU in or-

der to separate the memory of a process into regions,

based on the libraries that are loaded upon a pro-

gram’s execution. When an untrusted, user-space ap-

plication issues a call to a protected library, our cus-

tom kernel intercepts it and redirects it through a gate

library - which stands as a policy decision mechanism

- before allowing it to continue.

In order to meet requirement (R1) and intercept all

calls, our system marks all the executable regions (e.g

.text/code region) that correspond to a linked library

or the main executable as non-executable. Further-

more, for each region it maps a special custom library

- which we designate as gate - in the running process’s

address space. When an application or other region

issues a call to a non-executable region, a deliberate

SECRYPT 2021 - 18th International Conference on Security and Cryptography

688

Kernel space

Install one gate/region

Mark Executable (X) regions

as Non-Executable (NX)

Process

Library call

(lands in NX memory)

Page

fault

handler

Page

fault

Redirect ﬂow

inside the gate

Mark the NX

region as X

Invoke the library

Figure 1: Design overview.

page fault occurs. The Page Fault Exception Handler

(PFEH) (Bovet and Cesati, 2005) is, then, invoked to

resolve the issue. In order to continue executing, we

modify the PFEH so it redirects the ﬂow inside the as-

sociated gate library that we had previously mapped

in the process’s memory area. If the policy check is

passed, it marks the speciﬁc non-executable region as

executable and continues with the call, starting the

whole procedure from the beginning. Figure 1 shows

this sequence of events. This way we are able to inter-

cept all the calls inside the libraries that an application

uses and enforce the execution ﬂow through the pol-

icy decision engine.

Threat Model. We consider an adversary model

which is composed of two classes of threats. The

ﬁrst class of threats comprises the bugs/vulnerabil-

ities that an application contains. These can be ei-

ther (a) already discovered and known without, how-

ever, a security patch being available or having be-

ing applied by the system administrator or (b) zero-

day/undiscovered, without anyone knowing about

their presence. An adversary is in possession of a

technique (e.g. BROP, JIT-ROP, etc.) that can ex-

ploit one ore more of these vulnerabilities and mount

a CRA that eventually compromises the application.

Our mechanism can detect and immediately mitigate

any attempt to exploit these bugs until a patch can be

applied, by hindering the execution of collected gad-

gets.

The second threat class is the behavior of a pro-

gram. At run-time, an application can present ab-

normal behavior that opposes what is nominally ex-

pected. Our mechanism can observe not only the oc-

currence of calls, but also the number of calls to a par-

ticular service or function, as well as the sequence of

these calls (similarly to our previous work in (Tsan-

tekidis and Prevelakis, 2019)), in order to create an

understanding of the different states that an applica-

tion is going through during its execution.

Security Policies. The main challenge of our ap-

proach is to create comprehensive security policies

that include the complete list of communication paths

among the different segments (libraries/executables)

in which we compartmentalize the running applica-

tion. This challenge originates from the complexity of

the library/application (i.e. its development as well as

its functionality), the way that the paths are provided

(e.g., by the developers of the library/application) and

the effort required to track these paths.

Based on the value of a property (e.g., the access

rights of a ﬁle, the number/sequence of function calls,

etc.), if our mechanism detects a suspicious activity

which is further characterized as malicious, it applies

the corresponding security measure deﬁned in the pol-

icy. The evaluation of the security policies is continu-

ous, throughout the execution of the monitored appli-

cation and is triggered whenever a call to a separate

memory region is performed.

4 IMPLEMENTATION

We provide an updated version of the Proof-of-

Concept (PoC) implementation of our previous proto-

type mechanism (Tsantekidis and Prevelakis, 2019),

using Linux kernel version 4.16.7, the latest one at

the start of the development phase.

Our mechanism identiﬁes the regions of contigu-

ous virtual memory (Virtual Memory Areas - VMAs)

that are executable and correspond to a linked li-

brary or the main executable and maps the custom

gate library in the process’s memory, one for each

identiﬁed VMA. Then, these VMAs are marked as

non-executable wich is computationally inexpensive,

moving towards meeting requirement (R3). From

then on, when a process tries to perform a library

call, it will land on an address in a non-executable

area, which will deliberately produce a page fault.

Before handling it, we redirect the execution ﬂow in-

side our policy enforcement engine in order to check

the security policies associated with the running pro-

gram. This procedure is performed automatically on

the kernel side, without requiring access to the source

code/binary of the application or linked libraries, thus

making our approach completely transparent, fulﬁll-

ing requirement (R2).

In this updated version of our previous work, we

introduce the notion of gate libraries as a policy en-

forcement engine, which we install one for each iden-

tiﬁed executable area. Every call originating from

a region different than the destination one (i.e. be-

MMU-based Access Control for Libraries

689

tween different libraries) is intercepted and analyzed,

even if the same call was previously checked again

at another point during execution. We can express

the security policies based on the outline presented

in Section 3, using a policy deﬁnition language (such

as KeyNote (Blaze et al., 1999)). Alternatively, the

library/application designer can provide us with the

policy in a similar format/language.

5 USE CASE

In order to evaluate the applicability and efﬁciency of

our proposed prototype, we analyze a use-case where

the NGINX HTTP server is compromised by Denial-

of-Service (DoS)/arbitrary code execution attack, af-

ter a vulnerability is triggered.

CVE-2013-2028 (Common Vulnerabilities and

Exposures, 2013) is a stack-based buffer overﬂow re-

lated to the chunk size of an HTTP request with the

header Transfer- Encoding:chunked. Although it

was addressed in versions later than 1.4.0, we can use

it to examine the effectiveness our prototype in de-

fending against CRAs. Due to its simplicity, we chose

the CRA (ROP) attack described in (sorbo, 2013),

which is a generic exploit for the 64-bit NGINX server

and uses the Blind ROP attack technique (Bittau et al.,

2014). Here we use our previous technique in (Tsan-

tekidis and Prevelakis, 2019) to extract the legitimate

addresses from the vulnerable NGINX binary, in or-

der to form the minimal security policy.

Additionally, as the exploitation unfolds, we mon-

itor its progress and we manage to identify a charac-

teristic sequence of calls to executables/libraries (in-

cluding the internal ones) and produce a trail of it.

The security policy can subsequently be updated to

reﬂect this information, so when the gate enforces the

policy, it will recognize the same ﬁngerprint and be

able to intercept and mitigate the attack.

We leverage the Phoronix Test Suite (PTS) (pts,

2021) to evaluate the efﬁciency of our mechanism.

Speciﬁcally, we run the OpenSSL benchmark test.

Our test-bed is a machine with 16Gb of RAM

and an AMD FX-8370 Eight-Core processor, run-

ning Ubuntu 16.04 x86 64 and Linux kernel version

4.16.7. We run the benchmark test for both cases: (a)

default untouched kernel, (b) kernel customized with

our mechanism. The outcome reports on the num-

ber of RSA 4096-bit sign operations per second. Fig-

ure 2 summarizes the results of the tests. As expected,

the default setup is performing better. However, there

is only minimal decrease in performance when using

our custom kernel, of about 2%.

680 685 690 695

Default kernel

Custom kernel

RSA 4096-bit signs per second

Figure 2: Performance evaluation of our mechanism using

the OpenSSL benchmark of PTS.

6 DISCUSSION AND

CONCLUSION

In this paper, we present a Proof-of-Concept pro-

totype mitigation technique as an extension of our

previous work in (Tsantekidis and Prevelakis, 2017;

Tsantekidis and Prevelakis, 2019) that segregates the

memory of a running process into regions at the gran-

ularity of executables/external libraries (irregardless

of them being statically or dynamically linked), lever-

aging the MMU. With each of these regions we as-

sociate a special gate library that enforces security

policies and redirect execution through it after inter-

cepting calls to the regions. This way, we are able

to monitor access to executables/libraries and change

their functionality when there is suspicion/detection

of foul play, based on security policies. Our approach

is efﬁcient and transparent and can be used on bina-

ry/legacy applications and existing environments, as

well as serve as a complimentary measure of defense

alongside already implemented mechanisms.

ACKNOWLEDGEMENTS

This work is supported by the European Commission

through the following H2020 projects: SENTINEL

under Grant Agreement No. 101021659, ROXANNE

under Grant Agreement No. 833635, THREAT-

ARREST under Grant Agreement No. 786890 and

CONCORDIA under Grant Agreement No. 830927.

REFERENCES

(2021). Phoronix Test Suite. https://www.

phoronix-test-suite.com.

Abadi, M., Budiu, M., Erlingsson, U., and Ligatti, J.

(2005). Control-Flow Integrity. In Proceedings of

the 12th ACM Conference on Computer and Com-

munications Security, CCS ’05, pages 340–353, New

York, NY, USA. ACM. http://doi.acm.org/10.1145/

1102120.1102165.

Backes, M. and N

urnberger, S. (2014). Oxymoron: Mak-

SECRYPT 2021 - 18th International Conference on Security and Cryptography

690

ing ﬁne-grained memory randomization practical by

allowing code sharing. In Proceedings of the 23rd

USENIX Conference on Security Symposium, SEC’14,

page 433–447, USA. USENIX Association.

Bittau, A., Belay, A., Mashtizadeh, A., Mazi

eres, D., and

Boneh, D. (2014). Hacking Blind. In 2014 IEEE Sym-

posium on Security and Privacy, pages 227–242.

Blaze, M., Feigenbaum, J., Ioannidis, J., and Keromytis, A.

(1999). The keynote trust-management system ver-

sion 2. RFC, 2704:1–37.

Bletsch, T., Jiang, X., Freeh, V. W., and Liang, Z. (2011).

Jump-oriented programming: A new class of code-

reuse attack. In Proceedings of the 6th ACM Sym-

posium on Information, Computer and Communica-

tions Security, ASIACCS ’11, pages 30–40, New

York, NY, USA. ACM. http://doi.acm.org/10.1145/

1966913.1966919.

Bovet, D. P. and Cesati, M. (2005). Page Fault Exception

Handler. In Understanding the Linux Kernel, 3rd Edi-

tion, chapter 9.4. O’Reilly.

Checkoway, S., Davi, L., Dmitrienko, A., Sadeghi, A.-

R., Shacham, H., and Winandy, M. (2010). Return-

oriented programming without returns. In Proceed-

ings of the 17th ACM Conference on Computer and

Communications Security, CCS ’10, pages 559–572,

New York, NY, USA. ACM. http://doi.acm.org/10.

1145/1866307.1866370.

Christoulakis, N., Christou, G., Athanasopoulos, E., and

Ioannidis, S. (2016). HCFI: Hardware-enforced

Control-Flow Integrity. In Proceedings of the Sixth

ACM Conference on Data and Application Security

and Privacy, CODASPY ’16, pages 38–49, New

York, NY, USA. ACM.

Common Vulnerabilities and Exposures (2013). CVE-

2013-2028. https://www.cvedetails.com/cve/

CVE-2013-2028/.

Evans, I., Fingeret, S., Gonzalez, J., Otgonbaatar, U., Tang,

T., Shrobe, H., Sidiroglou-Douskos, S., Rinard, M.,

and Okhravi, H. (2015). Missing the point(er): On

the effectiveness of code pointer integrity. In IEEE

Symposium on Security and Privacy, pages 781–796.

Kayaalp, M., Ozsoy, M., Abu-Ghazaleh, N., and Pono-

marev, D. (2012). Branch regulation: Low-overhead

protection from code reuse attacks. In Proceedings

of the 39th Annual International Symposium on Com-

puter Architecture (ISCA), pages 94–105.

Kim, J. W. and Prevelakis, V. (2006). Base Line Perfor-

mance Measurements of Access Controls for Libraries

and Modules. In Proceedings of the 20th International

Conference on Parallel and Distributed Processing,

IPDPS’06, pages 356–356, Washington, DC, USA.

IEEE Computer Society. http://dl.acm.org/citation.

cfm?id=1898699.1898911.

Mithra, Z. and Vipin P. (2015). Evaluating the theoreti-

cal feasibility of an srop attack against oxymoron. In

2015 International Conference on Advances in Com-

puting, Communications and Informatics (ICACCI),

pages 1872–1876.

PaX, T. (2001). Address Space Layout Randomization.

https://pax.grsecurity.net/docs/aslr.txt.

Provos, N. (2003). Improving host security with system call

policies. In Proceedings of the 12th Conference on

USENIX Security Symposium - Volume 12, SSYM’03,

pages 18–18, Berkeley, CA, USA. USENIX Asso-

ciation. http://dl.acm.org/citation.cfm?id=1251353.

1251371.

Roemer, R., Buchanan, E., Shacham, H., and Savage, S.

(2012). Return-oriented programming: Systems, lan-

guages, and applications. ACM Trans. Inf. Syst. Secur.,

15(1):2:1–2:34. http://doi.acm.org/10.1145/2133375.

2133377.

Shacham, H. (2007). The geometry of innocent ﬂesh on

the bone: Return-into-libc without function calls (on

the x86). In Proceedings of the 14th ACM Conference

on Computer and Communications Security, CCS ’07,

pages 552–561, New York, NY, USA. ACM. http:

//doi.acm.org/10.1145/1315245.1315313.

Shacham, H., Page, M., Pfaff, B., Goh, E.-J., Modadugu,

N., and Boneh, D. (2004). On the effectiveness

of address-space randomization. In Proceedings of

the 11th ACM Conference on Computer and Com-

munications Security, CCS ’04, pages 298–307, New

York, NY, USA. ACM. http://doi.acm.org/10.1145/

1030083.1030124.

Snow, K. Z., Monrose, F., Davi, L., Dmitrienko, A.,

Liebchen, C., and Sadeghi, A.-R. (2013). Just-In-

Time Code Reuse: On the Effectiveness of Fine-

Grained Address Space Layout Randomization. In

Proceedings of the 2013 IEEE Symposium on Secu-

rity and Privacy, SP ’13, pages 574–588, Washington,

DC, USA. IEEE Computer Society. http://dx.doi.org/

10.1109/SP.2013.45.

sorbo (2013). Nginx 1.4.0 (Generic Linux x64) - Re-

mote Overﬂow. https://www.exploit-db.com/exploits/

32277.

Tsantekidis, M. and Prevelakis, V. (2017). Library-

Level Policy Enforcement. In SECURWARE 2017,

The Eleventh International Conference on Emerg-

ing Security Information, Systems and Technologies,

Rome, Italy. http://www.thinkmind.org/index.php?

view=article&articleid=securware 2017 2 20 30034.

Tsantekidis, M. and Prevelakis, V. (2019). Efﬁcient Mon-

itoring of Library Call Invocation. In Sixth In-

ternational Conference on Internet of Things: Sys-

tems, Management and Security (IOTSMS), pages

387–392, Granada, Spain. https://doi.org/10.1109/

IOTSMS48152.2019.8939203.

Venkat, A., Shamasunder, S., Shacham, H., and Tullsen,

D. M. (2016). HIPStR: Heterogeneous-ISA Pro-

gram State Relocation. In Proceedings of the Twenty-

First International Conference on Architectural Sup-

port for Programming Languages and Operating Sys-

tems, ASPLOS ’16, pages 727–741, New York, NY,

USA. ACM.

Wagle, P. and Cowan, C. (2003). Stackguard: Simple stack

smash protection for gcc. In Proc. of the GCC Devel-

opers Summit, pages 243–255.

Watson, R. N. M. (2007). Exploiting concurrency vulner-

abilities in system call wrappers. In Proceedings of

the First USENIX Workshop on Offensive Technolo-

gies, WOOT ’07, pages 2:1–2:8, Berkeley, CA, USA.

USENIX Association. http://dl.acm.org/citation.cfm?

id=1323276.1323278.

MMU-based Access Control for Libraries

691
