Text Processing Techniques in Approaches for Automated

Composition of Domain Models

Viktorija Gribermane

and Erika Nazaruka

Institute of Applied Computer Systems, Riga Technical University, 1 Setas St., Riga, Latvia

Department of Applied Computer Science, Riga Technical University, 1 Setas St., Riga, Latvia

Keywords: Natural Text Processing, Knowledge Extraction, Unrestricted Language, Domain Model, Software Model.

Abstract: Text processing techniques are critical for automated analysis of domain documentation. Proper domain

analysis may include analysis of a huge number of documents that may describe business procedures, policies,

organizational structures, regulations, etc., as well as minutes of discussions with domain experts. The results

of analysis are also presented as documents with or without supporting graphics, e.g., domain models.

Automated composition of domain models (including software models) should decrease the time necessary

for analysis and would provide traceability to the original documentation. The goal of this research is to

understand how text processing techniques can be applied for composition of those models and what are the

current trends in this field. The result of analysis of 15 approaches showed that Natural Language Processing

features are just the starting point in document processing. The main difficulty is proper analysis of

dependencies among words in sentences and among sentences themselves. The obtained results indicate two

directions in identification of patterns of those dependencies and a complete diversity in their applications.

1 INTRODUCTION

Domain models are simplified representation of one

or many aspects of the real phenomena (e.g., a

system) which are created with a certain purpose.

Composition of the domain models is a

transformation of experts’ knowledge about existing

phenomena into some human understandable form,

e.g., graphical, mathematical, or textual. Usually, this

transformation is a mental work supported by

guidelines that are aimed to make this work more

systematic. However, the development of natural

language processing (NLP) technologies opened an

opportunity to use them for automated composition of

domain models based on textual and graphical-textual

descriptions of phenomena.

The automated composition of domain models is

based on processing verbal descriptions that origin as

a result of discussions with domain experts, tasks

performed, or that are represented by existing

documents. Besides, some knowledge may remain

implicit. Therefore, validation of the composed

domain models by the human expert is also required.

https://orcid.org/0000-0002-8368-9362

https://orcid.org/0000-0002-1731-989X

There are many research results on text processing

as such, but the aim of this research is to find out what

techniques are used mostly in the context of

system/software domain model composition and their

further use. For this purpose, we have selected and

analyzed 15 research papers published from 2005 till

2020 and stored in IEEE and ACM publication bases.

The main criterion of selection was the use of NLP

features for processing textual descriptions of the

problem domain structures and functionality that has

finished in automated composition of the domain

model. We skipped approaches those of using manual

processing of text or manual composition of the

domain models.

The following sections contain information on

domain model characteristics that could be got from

the verbal descriptions (section 2) and analysis of

research works that uses NLP features at the

beginning of the problem domain analysis (section 3).

Conclusion summarizes main results obtained and

describes validity of the research done.

Gribermane, V. and Nazaruka, E.

Text Processing Techniques in Approaches for Automated Composition of Domain Models.

DOI: 10.5220/0010533904890500

In Proceedings of the 16th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2021), pages 489-500

ISBN: 978-989-758-508-1

489

2 COMPOSITION OF DOMAIN

MODELS

The domain most often is understood as an

application area or a field for which software is

developed (Prieto-Diaz, 1990). Domains can be

narrow like a user authentication or broad like a

business. A domain analysis is a process of

identification of information that can be used for

software development with the purpose of making it

reusable (Prieto-Diaz, 1990). If this information is

available, then it will be faster and more effective for

software engineer to decide whether to reuse

components in the software system and understand

the beginning idea of this designed component.

The goal of the domain analysis in the software

development is to understand and specify the

functional, behavioral and structural characteristics of

a domain AS-IS (the problem domain: today’s reality

with existing business processes, existing objects,

existing functionality, etc.) and/or a domain TO-BE

(the solution domain: requirements to software to be

built, information system planned, new business

processes, modified functionality etc.) as well as

conformity among them if the both domains are

analyzed.

The structural characteristics of the domain can be

modelled as concepts and their intra- and inter-

relationships. The behavioral characteristics of the

domain are expressed as activities, control flows, data

flows and interactions with users or other systems.

The functional characteristics of the domain are

expressed as causal dependencies among activities or

functional parts of the domain, or states of the

software systems and transitions between them.

The domain models can be informal, semi-formal

and formal. In order to use models as a source for

further code generation, the models must be formal

(Miller and Mukerji, 2001), i.e., readable by

machines. Otherwise, only manual, or partially

automated transformation into code is possible.

Composition of the domain model starts from

gathering information. Usually, the obtained

information is specified in the form of unstructured

text (text in a formal writing style) and structured

descriptions (user stories, use case specifications,

scenarios, and other formats). Generally, descriptions

are represented as a large number of documents,

which consist of text with figures, tables, and multiple

links to other documents. In practice, preparation of

text and manual knowledge obtaining are too

resource-consuming (Elstermann and Heuser, 2016).

Therefore, the common case is to avoid the step of

preparation of text or to automate or semi-automate

this process. Certainly, the automated process may

require composition of a “transitional” model that can

be used for organizing the knowledge gathered from

the documentation and its further analysis.

The automated processing of structured text

(especially if a language is controlled) is easier than

processing of unstructured prose (Nazaruka, 2020).

However, structuring the text also requires additional

manual processing of information.

3 USE OF TEXT PROCESSING

TECHNIQUES

Analysis of unstructured (uncontrolled) text requires

not only application of basic NLP features such as

tokenization, part-of-speech (POS) tagging, chunking

and Name Entity Recognition (NER) but also analysis

of dependencies between clauses, in complex noun

phrases, in predicates and in verb phrases as well as

one of the most difficult tasks, namely, discourse

analysis (Nazaruka and Osis, 2018). The process is

getting complicated with particularities of a natural

language (Nazaruka et al., 2019). Thus, quality of the

processing depends on the presence of needed

knowledge, different structures of sentences and

implicit synonyms.

In order to deal with the uncertainty of a natural

language, machine learning or manual pre-processing

of knowledge can be used (Nazaruka, 2019).

Research on NLP techniques used for discovering

causal dependencies in texts in prose showed two

clear trends (Nazaruka, 2019). The first is increasing

the accuracy of the results using ontology banks,

machine learning and statistical inferring. The second

is decreasing the cost of these activities. In case of

construction of software models using machine

learning or statistical inferring, the main challenge is

a lack of corpuses and statistical datasets for potential

problem domains. Nevertheless, this issue can be

potentially solved by limitation of those source

documents to specifications (requirements, scenario,

etc.) having less variability in expressing causality.

The causal dependencies in text may be expressed

implicitly and explicitly. The explicit representation

means are causal links, causative verbs, resultative

constructions, conditionals as well as causative

adverbs, adjectives, and prepositions (Khoo et al.,

2002). Though, the implicit causality usually is

inferred by a reader associating information in the

text with their background knowledge (Khoo et al.,

2002; Ning et al., 2018; Solstad and Bott, 2017).

MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering

490

Theories attempting to reduce causal reasoning to

a domain-general theory can be grouped as

associative theories, logical theories, and

probabilistic theories (Waldmann and Hagmayer,

2013). Logical theories seem to be more suitable to

software development in processing verbally

expressed information, since they model causal

reasoning as a special case of deductive reasoning.

Logical theories frequently analyze conditionals

(if/when…then constructs) in the text. Although

conditionals do not distinguish between causes and

effects. Temporal priorities can be helpful in

distinguishing them (Pearl, 2019; Solstad and Bott,

2017).

3.1 Domain Model Composition

Approaches

The selected 15 approaches published from 2005 till

2020 and available in IEEE and ACM publication

bases are presented here in brief and are

chronologically ordered from the oldest to the more

recent ones.

Ilieva and Ormandjieva’s Approach (Ilieva &

Ormandjieva, 2006) uses plain text descriptions of

software requirements in unlimited natural language

as a source of knowledge for constructing the domain

TO-BE model with the aim to obtain requirements

engineering models such as a Use Case Path model, a

Hybrid Activity diagram model and a domain model.

Tabular presentation and Semantic Networks are used

as transition models. For extraction, the approach

uses POS recognition and semantic analysis of text.

Relative Extraction Methodology (Krishnan &

Samuel, 2010) uses user requirements or problem

statements as a source of knowledge for constructing

the domain TO-BE model and UML Class diagram as

the target model. A dependency graph is used as the

transition model. For the extraction POS recognition

is used with Breadth First Search (BFS) and Depth

First Search (DFS) algorithms for processing the

graph as well as algorithmic structures for concept,

value and action identification and class diagram

generation. The obtained class diagram lacks

advanced relationships like aggregation and

dependency between classes, as well as multiplicities

between the classes.

DAA4BPM. The Description Analysis Approach for

Business Process Management (DAA4BMP)

presented in (Friedrich et al., 2011) uses informal

textual descriptions of processes (the domain AS-IS

model) for Business Process Model and Notation

(BPMN) models creation as a target model. The

approach uses a dependency graph as a transition

model. The approach uses syntax parsing (factored

model of Stanford Parser, action filtering by example

indicators), semantic and flow analysis as well as a

custom anaphora resolution algorithm.

ReDSeeDS. Requirements Driven Software

Development System (ReDSeeDS) introduced in

2010-2012 by the international researchers’ teams

(Kalnins, 2010; Kalnins et al., 2011; Smialek &

Straszak, 2012) uses domain vocabulary (the class

model with links to WordNet entries) and semi-

formal use case specifications in the Requirements

Specification Language (RSL) as a source of

knowledge. Scenarios are written in Controlled

English. The target model is a platform independent

model based on UML profile, which includes static

structures as classes, components, and interfaces. The

behavior is represented as a sequence diagram.

AnModeler. AnModeler is a tool for generating

domain models from textual specifications (Thakur &

Gupta, 2014). Semi-structured use case specifications

with unrestricted plain text are used for composing

UML Class and Sequence diagrams. The approach

employs NLP, sentence structures and transformation

rules.

Nassar and Khamayseh’s Approach (Nassar &

Khamayseh, 2015) targets the construction of activity

diagrams from Arabic user requirements using NLP

tools. User requirements must follow strict writing

rules (formal short statements SVO and VSO “verb-

subject-object”). The approach uses manually

detected tag patterns to generate UML activity

diagrams as the output model. As the result this

approach allows extracting actions, domain objects

without additional details and actors.

IDM. The Integrated Domain Modeling (IDM)

approach uses semi-formal Use Case specifications as

the domain TO-BE model (Slihte, 2015). The

language is restricted since steps should be in the

form of “subject verb object” (SVO). The approach

produces a topological functioning model (TFM) as

the target model, employing NLP features and

ontology bank for this task. The approach allows

determining actions, objects, actors, preconditions,

and causal dependencies.

Domain Model Extractor (Arora et al., 2016) is

capable of extracting UML Class diagrams as a target

model from software requirements given in

unrestricted natural language form. It uses NLP

features and extraction rules. This approach allows

extracting concepts, associations and generalizations,

cardinalities, and attributes.

DAA4BPM v.2. The modified version of the

DAA4BMP (Leopold et al., 2017). Knowledge is

extracted from business process models given in

Text Processing Techniques in Approaches for Automated Composition of Domain Models

491

BPMN or Event-driven Process Chain (EPC)

notations together with corresponding informal

textual descriptions in plain text. Resource

Description Framework (RDF) triplets are used as the

target model. The approach uses syntax parsing

(Stanford Parser) and semantic analysis (Stanford

Parser, WordNet, and predicates).

AGER. The Automated E-R diagram Generation

System (AGER) presented in (Ghosh et al., 2018) can

generate E-R diagrams from plain text. User

statements are given in VSO form. It employs NLP

features to detect entities, attributes and relations.

Kashmira and Sumathipala’s Approach

(Kashmira & Sumathipala, 2018) is targeted at

generation of Entity Relationship (E-R) diagrams

from requirements specification using NLP. The

source model is semi-structured use case

specifications. The approach uses NLP, machine

learning, ontology, and web-mining to achieve its

goals. As the result this approach identifies entities,

attributes, and relationships between entities/sub

entities-attributes, entities-entities (association),

entities-sub entities (generalization), attributes-

attributes, cardinalities (One to One, One to Many,

Many to Many).

Shweta, Sanyal and Ghoshal’s Approach (Shweta

et al., 2018) uses Use Case specifications in a semi-

structured plain text form with keywords specified.

The target model is UML Class diagrams. The

approach uses NLP features and rules for extraction

of classes, attributes, and methods. This approach

allows extracting actions, domain objects and

attributes and relationships between objects without

additional information.

AR2AA. Automated Requirements to Assertions

Analyzer (AR2AA) uses plain text Requirement

specifications as a source of knowledge for

constructing the domain TO-BE model (Anwar et al.,

2020). The target model for the approach is a triplet

<Requirements, Actions, Conditions>. The approach

employs NLP for identification of nouns, verbs and

adjectives, and rules to identify actions and

conditions.

DoMoRe. Domain Modeling Recommender

(DoMoRe) introduced in (Agt-Rickauer, 2020) is

author’s own implementation of the DoMoRe system

that “generates context-sensitive modeling

suggestions using SemNet Nad OntoConnector”. The

approach uses a large text corpus in plain text as input

and Semantic Term Network as the target model. N-

Grams constructs are used as an intermediate model.

It employs Stanford NLP toolkit, syntactic POS

patterns for 5-Grams, and statistics of term

occurrence.

Mirończuk’s Approach or Fire Report Analysis

(Mirończuk, 2020) uses fire service reports as a

source that is the combination of structured data and

unrestricted text. The target model is a database with

structured data as the records in it. The author

employed classification by using supervised machine

learning, creation of terms DB, manually created

taxonomy, and extraction rules based on manually

created patterns. As the result the author extracts

concept values from text using predefined extraction

patterns.

3.2 Characteristics to Compare

In order to determine what of these techniques and

principles are used for composition of domain models

which should be applied for software development

the following characteristics are analyzed:

 Source model is a description of a domain,

which is used as a source of knowledge about

the domain’s characteristics at the very

beginning of analysis. It can be considered

from two viewpoints:

o Domain AS-IS model represents the

problem domain that describes existing

processes in the domain,

o Domain TO-BE model represents the

solution domain that that describes

demanding processes as system or

software requirements and improvements.

 Mapping indicates whether an approach has a

support of providing formal conformity

between domains AS-IS and TO-BE.

 Source model type indicates in which form of

specification a source model is presented.

 Source model format indicates in which

format (e.g., plain text, formatted text,

hyperlink text, PDF, WORD, etc.) of

specification a source model is presented.

 Target model represents the target

specifications after knowledge extraction and

transformation.

 Transition model is the transitional

knowledge representation (specification)

during transformation to the target model.

 Knowledge extraction techniques are

methods or approaches used for getting

knowledge from the source model.

 Techniques for extraction of relationships

between elements are methods or approaches

used for discovering relationships between

elements of the source model.

MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering

492

 Declarative knowledge extraction indicates

whether an approach analyzes the structural

characteristics of the domain.

 Procedural knowledge extraction indicates

whether an approach analyzes the functional

and behavioral characteristics of the domain.

 Synonym processing indicates whether an

approach processes anaphors, synonyms, and

homonyms.

3.3 Comparison of Approaches

Domains and Mappings Between Them. Most of

the 15 approaches are focused on analysis of

specifications of the required solution, i.e.,

composing the model of the domain TO BE. Three

of them DAA4BPM (Friedrich et al., 2011), its

modification DAA4BPM v.2 (Leopold et al., 2017)

and the Fire Report Analysis are dedicated for the

domain AS IS analysis and do not consider the

domain TO BE at all. The DoMoRe approach is a

universal and can be applied for analysis of both the

domains. Therefore, none of these approaches

provides conformity between models of the domains

just because none of them considers both domains.

Source Model Formats. Most of the considered

approaches proceed the source documents in the plain

text format (Table 1). Just two exceptions are

presented, namely, the ReDSeeDS where hyperlinks

are also acceptable and the DAA4BPM v.2 where the

text is an informal textual description of processes

that supplements BPMN (Business Process Model

and Notation) or EPC (Event Process Chain)

diagrams.

Source documents in approaches that analyze the

domain AS IS – the DAA4BPM, its modification

DAA4BPM v.2 and the Fire Report Analysis – are

textual descriptions of processes such as policies,

reports, forms, manuals, e-mail messages, etc.

Reports may combine structured and unstructured

data and text in the unrestricted language.

Source Model Types. Source documents on the

domain TO BE are requirement specifications of

different types: unstructured text and semi- or

completely structured text in the form of use cases

like in the IDM approach, AnModeler, and

ReDSeeDS as well as domain vocabularies with

hyperlinks to the ontology bank entries in the

ReDSeeDS.

Table 1: Source documents type and format. Denotation: SVO – subject verb object, VSO – verb subject object.

Approaches Source model type Source model

format

Ilieva and Ormandjieva SR descriptions Plain text

Relative Extraction

Methodology

A large collection of sentences Plain text

DAA4BPM Informal textual descriptions:

policies, reports, forms, manuals, e-mail messages etc.

Plain text

ReDSeeDS Semi-formal equivalent of the domain class model with

links to WordNet entries, use cases for scenarios in

controlled language

Plain text with

hyperlinks

Nassar and Khamayseh Formal short statements SVO, VSO Plain text

IDM Use case specifications with steps in the form of SVO Plain text

Domain Model Extractor Unrestricted NL requirements Plain text

AnModeler Semi-structure unrestricted software requirement

specification

Plain text

DAA4BPM v.2 BPMN or EPC diagram and its informal textual description Plain text and

BPMN / EPC

AGER User statements SVO Plain text

Kashmira and Sumathipala Requirement specifications Plain text

Shweta, Sanyal and

Ghoshal

Semi-structured software requirement specification with

keywords

Plain text

AR2AA Textual Design Requirements Plain text

DoMoRe A large text corpus Plain text

Mirończuk (Fire Report

Analysis)

The combinations of structured data and unrestricted text Plain text

Text Processing Techniques in Approaches for Automated Composition of Domain Models

493

Target Models. The target domain models are also

quite diverse (Table 2) and can be grouped to UML

or UML like models presented in 7 approaches, E-R

diagrams presented in 2 approaches, BPMN models

(just in one approach), Topological Functioning

Models (in one approach) and others in 4 approaches.

Transitional Models. The transition models are

required in 4 approaches – Ilieva and Ormandjieva’s

approach, Relative Extraction Methodology,

DAA4BPM, DoMoRe – mainly for analysis of the

semantical relationships between concepts (Table 2).

Knowledge Extracting Techniques. Let us look at

the knowledge extracting techniques used in the

provided approaches (Table 3). The first step in the

most approaches is parsing of sentences using

standards NLP techniques. Thus, tokenization,

chunking, POS recognition and dependencies

identification are applied. The exception is

ReDSeeDS that uses Keyword Based Analysis for the

domain TO-BE model (RSL) since the language of

the source model is Controlled English.

After syntax analysis, the semantic analysis is

performed using dependencies between word pairs in

the parsed sentences. In most of the approaches these

dependencies are described in the form of lexical

syntactical patterns. Their implementation differs in

the approaches:

 Algorithmic structure for processing

dependency graph as in the Relative Extraction

Methodology as well as BFS and DFS

traversals;

 Semantic analysis algorithm that uses

ontologies and some predefined lists of

“keywords”:

o FrameNet and WordNet, lists of order

indicators such as ConditionIndicators,

ParallelIndicators, ExceptionIndicators,

SequenceIndicators, as well as anaphora

resolution algorithm in the DAA4BPM;

o WordNet in the ReDSeeDS for domain

vocabulary and in the Kashmira and

Sumathipala’s approach, as well as

together with predicates in the

DAA4BPM v.2;

 Rules for detecting and extracting separate

elements: in the “Domain Model Extractor”

AnModeler, AGER (for entities, attributes, and

relations), Shweta Sanyal and Ghoshal’s

approach (for classes, attributes, relations, and

methods), AR2AA (for actions and

conditions), and Fire Report Analysis (for

values for terms used in the database).

Table 2: Target model and transition model representation.

Approaches Target model Transition model

Ilieva and Ormandjieva Use Case Path model,

Hybrid Activity Diagram model,

Domain model

Tabular

presentation,

Semantic Network

Relative Extraction Methodology UML class diagram Dependency graph

DAA4BPM BPMN model World Model

ReDSeeDS PIM model based on UML profile:

-Static structure as classes, components, and

interfaces,

-Draft behavior as sequence diagram.

N/U

Nassar and Khamayseh UML Activity diagram N/U

IDM TFM N/U

Domain Model Extractor UML class diagram N/U

AnModeler UML class diagram, UML sequence diagram N/U

DAA4BPM v.2 RDF triplets N/U

AGER E-R Diagram N/U

Kashmira and Sumathipala E-R Diagram N/U

Shweta, Sanyal and Ghoshal UML class diagram N/U

AR2AA Triplet <R, A, C> N/U

DoMoRe Semantic Term Network N-Grams constructs

Mirończuk (Fire Report Analysis) Database record with structured data N/U

* Donotation used: N/U – not used; TFM – Topological Functioning Model; UML – Unified Modeling Language; BPMN –

usiness Process Modeling and Notation; PIM – Platform Independent Model; E-R – Entity Relationships; R –

equirements; A – actions; C – conditions; RDF – Resource Description Framework.

MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering

494

Classification of sentences according to the

lexical syntactical patterns can be performed either

manually as it is done in most of the approaches, or

by using machine learning as in the Kashmira and

Sumathipala’s approach and the Fire Report Analysis.

Techniques for Extraction of Relationships. The

extraction of relationships implements the part of the

techniques discussed above and is quite diverse in the

approaches.

The triads, heuristics and mappings are used

sequentially in the Ilieva and Ormandjieva’s

approach for automated extraction of relationships

between elements:

 from text to tabular presentation using POS

tagger and their own labeling;

 from tabular presentation to semantic network

using relations (triads) and heuristic;

 from semantic network to three target models

using mappings between semantic network and

models.

The analysis of dependencies in the dependency

graph is used in the Relative Extraction Methodology:

 from text to dependency graph using BFS

traversal on the syntactic tree for concept and

value identification and DFS traversal on the

Verb Phrase (VP) sub-tree of the syntactic tree

for action identification;

 from the dependency graph to UML class

diagram using BFS traversal on the

dependency graph by searching a link between

concept and its corresponding elements (value

and action) for identification of classes with

their attributes and methods.

The syntax parsing and semantic analysis are

applied in the DAA4BPM (Friedrich et al., 2011) in

the following way:

 Syntax parsing applies the factored model of

Stanford Parser as well as action filtering by

example indicators;

Semantic analysis investigates meanings of

words and phrases (synonyms, homonyms,

etc.) searching the ontologies FrameNet and

WordNet as well as lists of indicators of

conditions (ConditionIndicators), parallel

execution (ParallelIndicators), possible

exceptions (ExceptionIndicators), and the

sequential order (SequenceIndicators);

Table 3: Knowledge Extraction Techniques.

Approaches Knowledge extraction techniques

Ilieva and Ormandjieva NLP(POS), Semantic analysis of text

Relative Extraction

Methodology

NLP(POS), BFS traversal, DFS traversal, algorithmic structures for

processing the dependency graph

DAA4BPM NLP: Syntax parsing (factored model of Stanford Parser, action filtering by

example indicators), Semantic analysis (FrameNet and WordNet; lists of

indicators ConditionIndicators, ParallelIndicators, ExceptionIndicators,

SequenceIndicators), authors’ original anaphora resolution algorithm

ReDSeeDS Keyword Based Analysis for RSL; WordNet for domain vocabulary;

Nassar and Khamayseh Manually detected tags patterns

IDM NLP, ontology bank

Domain Model Extractor NLP, extraction rules

AnModeler NLP, sentence structure and transformation rules

DAA4BPM v.2 NLP: Syntax parsing (Stanford Parser), Semantic analysis (Stanford Parser,

WordNet, and predicates)

AGER NLP, Detection rules for Entities, Attributes and Relations

Kashmira and Sumathipala NLP, machine learning, ontology, and web-mining

Shweta, Sanyal and Ghoshal NLP, rules for extraction of classes, attributes, relation, and operations

AR2AA NLP; Identification of Noun, Verb and Adjectives; Rules to identify Actions

and Conditions

DoMoRe Stanford NLP toolkit, Syntactic POS patterns for 5-Grams; Statistics of term

occurrence

Mirończuk (Fire Report

Analysis)

Classification by using supervised machine learning; creation of terms of the

database; Manually created taxonomy; Extraction rules based on manually

created patterns

Text Processing Techniques in Approaches for Automated Composition of Domain Models

495

 Anaphora resolution algorithm, i.e.,

identification of a grammatical substitute (such

as pronouns “we”, “he”, “it”, certain articles

“this”, “that” or a pro-verb) to refer to the

denotation of a preceding word or group of

words.

In the ReDSeeDS project (Kalnins, 2010; Kalnins

et al., 2011; Smialek and Straszak, 2012) the authors

use analysis of basic dependencies between words

and keywords as well as synsets analysis by using

ontology WordNet. The analysis is done in the step of

transforming the model of the domain TO BE – RSL-

into the platform independent one:

 each step of a use case in the Subject-Verb-

Object (SVO) format;

 analysis of the SVO sentence type;

 analysis of keywords in SVO sentences;

 lexicographic term matching;

 WordNet-based similarity measures for

comparing synsets (groups of synonyms that

express the same concept).

The analysis of the SVO sentence type determines

the direction of behavior described in the sentence by

using the following rules:

 Actor – system sentence. An actor is the

subject, and a system is the recipient of the

SVO sentence;

 System – actor sentence. A system is the

subject, and an actor is the recipient of the SVO

sentence;

 System – system sentence. A system is the

subject and the recipient of the SVO sentence.

The Nassar and Khamayseh’s approach

transforms text in Arabic (Nassar and Khamayseh,

2015) as a sample is free to apply the algorithm which

uses tags patterns and heuristic in order to create the

UML activity diagrams

In the IDM approach (Slihte, 2015) the classic

NLP features are used and for the outcome other

techniques are applied: extraction rules for entities,

descriptions of and dependencies between functional

features based on the sequence of steps in certain

scenario.

The approach using “Domain Model Extractor”

(Arora et al., 2016) in order to extract relationships

required for the UML class diagram apply the

standard NLP features, extraction rules, which use

determined dependencies for concepts, associations,

generalization, cardinalities, and attributes.

The AnModeler approach (Thakur and Gupta,

2014, 2016a, 2016b) that uses the tool with the same

name uses the Stanford NL Parser API to obtain type

dependencies (TDs) and parts of speech tags (POS-

tags) of each sentence in the specification. The

identified sentence structure and the semantic

relationships between the words in the sentence

obtained from the TDs and POS-tags are used by the

tool to identify domain elements with domain objects,

their attributes, operations, and interactions between

the objects.

Analysis of individual sentences and extracted

RSF triples are used in the modified DAA4BPM

approach that we refer as DAA4BPM v.2 (Leopold et

al., 2017). First, RDF specification is obtained from

the informal textual specification in the following

way:

 Stanford Parser is used to automatically

transform a text into a list of individual

sentences, identify the grammatical entities

(the subject, object, predicate, and adverbial)

and the relations between them;

 WordNet is used in conversion of all words into

their base form;

 Then, RDF triples are used for specifying the

obtained information;

The RDF specification is obtained from process

models in the following way:

 Using extraction, linguistic analysis,

normalization, and transformation of activity

labels with its components (action, business

object, additional information) into RDF;

 By extracting the inter-relations between

activity records.

The inter-relations between activity records in the

DAA4BPM v.2 are extracted in the following way:

 pair-wise relations are identified;

 relations are propagated;

 behavioral relations are transformed into RDF

In the AGER (Ghosh et al., 2018) the algorithm

for detecting entities, attributes and relations is

performed by using the entity, attribute and relation

synonyms tables. However, to generate the E-R

diagram the BFS algorithm is used.

In the Kashmira and Sumathipala’s approach

(Kashmira and Sumathipala, 2018) supervised

machine learning module (the “Weka” model), as

well ontology and web-mining are used to identify

entities, attributes, and relationships from the given

text as well as to filter out the relevant attributes into

extracted entities. In order to train the “Weka” model,

the authors considered four classifier algorithms

namely Random Forest, Naive Bayes, Decision

Table, and SMO.

MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering

496

In the Shweta Sanyal and Ghoshal’s approach

(Shweta et al., 2018) Implementation Rules based on

the universal dependencies between words (provided

by the NLP tools) and authors’ keywords are used for

the sequential extraction of classes, attributes,

methods, and relations.

In the AR2AA (Anwar et al., 2020) the rules are

developed to identify actions and conditions in the

textual requirements to the design. These rules

analyze the POS tagging in the sentences and extracts

all actions (verbs) and the corresponding conditions

(nouns and adjectives) based on them.

Reducing N-grams to terms and counting their

frequency of occurrence in text are techniques for

extraction of relationships between elements in

DoMoRe (Agt-Rickauer, 2020):

 N-Grams are a sequence of n consecutive

words. It is used for derivation of semantic

relationships between co-occurring words and

terms.

 Redundancy and Paraphrases. The authors

focus on identification of relationships on a

conceptual level and use mentions of concepts

that occur redundantly and paraphrased as well.

 Word Co-occurrences and Distributions. The

authors derive the latent semantic relationship

between domain-specific terms from

frequently co-occurring words and phrases, as

well as identify technical terms with the help of

collocations.

Mind maps and formal concept analysis (FCA)

are used for manual extraction of the relationships in

the Fire Report Analysis approach (Mirończuk,

2020).

Declarative Knowledge Extraction (Table 4).

Since, all the target models include the concept of an

object or a group of objects (a class) all the analyzed

approaches support extraction of the declarative

knowledge, i.e., identification of classes/objects,

attributes and relations in pairs class-attribute, object-

attribute, class-class, and object-object.

Procedural Knowledge Extraction (Table 4). The

elements describing the dynamic characteristics of

the domain are also extracted in all the considered

approaches. The approaches, where the target model

is an E-R diagram, express the procedural knowledge

as an element Relation between entities – the AGER

and the Kashmira and Sumathipala’s approach. In

their turn, in the Relative Extraction Methodology

and the Shweta Sanyal and Ghoshal’s approach –

where the target model is just an UML Class

diagram – the procedural knowledge is expressed as

class operations.

Synonym Processing (Table 4). Most of the

approaches provides automated processing of

synonyms by using corresponding ontology banks.

Table 4: Extraction of the certain knowledge type and processing synonyms.

Approaches Knowledge Type Synonyms Processing

Declarative Procedural

Ilieva and Ormandjieva Y Y Y, belonging

Relative Extraction Methodology Y Y, class operations N/I

DAA4BPM Y Y Y

ReDSeeDS Y Y Y

Nassar and Khamayseh Y Y N/I

IDM Y Y Y, theoretically

Domain Model Extractor Y Y Y

AnModeler Y Y Y

DAA4BPM v.2 Y Y Y

AGER Y Y, relations Y

Kashmira and Sumathipala Y Y, relations Y

Shweta, Sanyal and Ghoshal Y Y, class operations N/I

AR2AA Y Y N/I

DoMoRe Y N Y, link to ontology bank

Mirończuk (Fire Report Analysis) Y Y Y, manually

*“Y”-yes; “N” – no; N/I – not indicated.

Text Processing Techniques in Approaches for Automated Composition of Domain Models

497

The exceptions are the Fire Report Analysis

where the processing is done manually by the author,

and the IDM approach where the authors described

such an option theoretically. In the descriptions of

four approaches – the Nassar and Khamayseh’s

approach, the Relative Extraction Methodology, the

Shweta Sanyal and Ghoshal’s approach and the

Shweta Sanyal and Ghoshal’s approach – this

question is not even discussed.

3.4 Discussion on Findings

As mentioned in the beginning of section 3, to

minimize the uncertainty of natural languages manual

pre-processing of text can be applied. The result of

the review approves the same fact, just 6 of 15

considered approaches take as input unrestricted

texts. Other approaches either use predefined

structures of the sentences (SVO and VSO), or

organize the content within some structure

supplemented by pre-defined keywords. Most of

approaches compose the domain model based on

requirements specifications thus assuming further

generation of application code or database schemes.

Another way how to deal with the semantical

uncertainty is application of ontology banks, machine

learning and statistical inferring. The presented

approaches demonstrated this fact. Six of them use

machine learning, ontology banks WordNet and

FrameNet, statistics of term occurrence and even

web-mining like in the Kashmira and Sumathipala’s

approach. However, if the ontology banks were

applied even in research published in 2011, then

machine learning is the new thing: among the

observed approaches the first mention is in 2018.

Ontology banks are also applied for automated

synsets analysis.

The target models are quite diverse. They are

represented by such “traditional notations” of the

domain models as UML (behavioral and structural

diagrams), BPMN, E-R and such rare used as RDF

triplets, semantic networks, database schemes and

TFMs. Thus, this diversity approves that knowledge

in all the dimensions of domain models could be

automatically extracted and modeled. Besides that, it

illustrates that both procedural and declarative

knowledge can be processed in the automated way.

The applied knowledge extraction techniques are

mostly algorithmic solutions that implements

knowledge extracting rules based on keyword

analysis, determined word dependencies and lexical

semantic patterns. As an input these algorithmic

solutions use outcomes of NLP of texts or a

transitional model and as an output produce a target

model or a transitional model. A part of rules may

share the same patterns. In this activity, machine

learning models are used for the sentence

classification task.

All the approaches have been validated by their

authors. Most of them – manually. The main

measurements were the accuracy and the

completeness of the extracted knowledge. The results

evaluated can be considered as satisfactory, and in a

large degree depends on the quality of the patterns

and extracting rules.

4 CONCLUSIONS

The research has provided the short overview of 15

approaches for automated domain model composition

those of using automated knowledge extraction. The

compared characteristics have been selected to

understand the trends in application of the knowledge

extraction techniques for analysis of documentation

needed for composing the software domain model.

Main findings are the following:

 Still there is a small number of works that

investigate processing of text in unrestricted

languages;

 Approaches deal with behavioral, functional

and structural dimensions of the problem

domain that is approved by the target models

used;

 It is not enough just to apply NLP feature for

text: analysis of the NLP outcomes is required;

 The analysis of the NLP outcomes mostly is

algorithmic and assumes a use of lexical

semantic patterns based on dependencies and

POS tags of words as well as keyword analysis

for structures text and synsets analysis.

 Application of machine learning models is a

new thing in the field.

The main manageable issues in the presented

approaches relate to the quality of lexical semantic

patterns and algorithmic processing of NLP

outcomes. However, natural languages uncertainty

remains and may affect the results in an unexpected

way.

Construct Validity: Since various methods for

extraction of domain models from text exist, the

question about the format of the input information is

open – should it be unrestricted or controlled

language and what means do we have to process text

in it. Thus, this research reviews existing results of

other authors’ works that have been published from

2005 till 2020 by IEEE and ACM.

MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering

498

In order to evaluate the current state in the field,

the characteristics of the source models, transition

models and target models were evaluated, as well as

methods or approaches used for procedural and

declarative knowledge extraction including synonym

analysis. The quality of extraction of knowledge is

not analyzed since the diversity of input models and

output models as well as a lack of precise information

on implementation of extracting rules and algorithms

do not allow to make objective conclusions about the

degree of validity of the presented approaches.

Internal Validity: The presented research works

are limited by publication period (15 years) and

publication databases (IEEE and ACM). The search

of related works has been done using a limited

number of keywords: “Knowledge Extraction,”

“Domain model extraction,” “Natural Language

Processing.” The result of the search was filtered by

relevance to the research question and the target

model as well as manual processing and composing

approaches have been ignored. Multiple publications

of the same authors were reviewed, and the most

complete publications were taken for the analysis.

External Validity: The presented results

illustrate that despite having quite advanced NLP

features, the main difficulty is processing of NLP

outcomes. Language ambiguity, multiple possible

constructs for expressing one and the same

statements, multiple possible interpretations of a

statement require huge work on processing text and

does not guarantee that the results of application of

any method will be the same or at least will have

similar quality for all cases.

Future research directions can be related to

investigation on how to obtain more complete set of

lexical semantic patterns and extraction rules as well

as to techniques used for discourse understanding in

specifications written in unrestricted languages and

having informal structure. Besides that, the important

question is how one can discover the fact that some

knowledge is missed and what this knowledge is.

REFERENCES

Agt-Rickauer, H. 2020. Supporting Domain Modeling with

Automated Knowledge Acquisition and Modeling

Recommendation, Technischen Universitat Berlin.

Anwar, M. W., Ahsan, I., Azam, F., Butt, W. H., and Rashid,

M. 2020. A Natural Language Processing (NLP)

Framework for Embedded Systems to Automatically

Extract Verification Aspects from Textual Design

Requirements. In Proceedings of the 2020 12th

International Conference on Computer and Automation

Engineering, 7–12. ACM. https://doi.org/10.1145/

3384613.3384619

Arora, C., Sabetzadeh, M., Briand, L., and Zimmer, F. 2016.

Extracting domain models from natural-language

requirements: Approach and Industrial Evaluation. In

Proceedings of the ACM/IEEE 19th International

Conference on Model Driven Engineering Languages

and Systems - MODELS ’16, 250–260. ACM/IEEE.

https://doi.org/10.1145/2976767.2976769

Asnina, E. 2006a. Formalization of Problem Domain

Modeling within Model Driven Architecture, Riga

Technical University.

Asnina, E. 2006b. The Computation Independent Viewpoint:

a Formal Method of Topological Functioning Model

Constructing. In Applied Computer Systems, 26, 21–32.

RTU Press.

Donins, U. 2012. Doctoral thesis “Topological Unified

Modeling Language: Development and Application,”

Riga Technical University.

Elstermann, M., and Heuser, T. 2016. Automatic Tool

Support Possibilities for the Text-Based S-BPM Process

Modelling Methodology. In Proceedings of the 8th

International Conference on Subject-Oriented Business

Process Management - S-BPM ’16, 1–8. ACM.

https://doi.org/10.1145/2882879.2882882

Friedrich, F., Mendling, J., and Puhlmann, F. 2011. Process

Model Generation from Natural Language Text. In

Proceedings of the 23rd International Conference on

Advanced Information Systems Engineering (CAiSE

2011), 482–496. Springer-VerlagBerlin, Heidelberg.

https://doi.org/10.1007/978-3-642-21640-4_36

Ghosh, S., Mukherjee, P., Chakraborty, B., and Bashar, R.

2018. Automated Generation of E-R Diagram from a

Given Text in Natural Language. In 2018 International

Conference on Machine Learning and Data Engineering

(ICMLDE), 91–96. IEEE.

https://doi.org/10.1109/iCMLDE.2018.00026

Ilieva, M. G., and Ormandjieva, O. 2006. Models Derived

from Automatically Analyzed Textual User

Requirements. In Fourth International Conference on

Software Engineering Research, Management and

Applications (SERA’06), 13–21. IEEE.

https://doi.org/10.1109/SERA.2006.51

Kalnins, A. 2010. A Model-Driven Path from Requirements

to Code. Computer Science and Information

Technologies, 756, 33–57. Horizon Research Publishing.

Kalnins, A., Smialek, M., Kalnina, E., Celms, E.,

Nowakowski, W., and Straszak, T. 2011. Domain-

Driven Reuse of Software Design Models. In J. Osis and

E. Asnina (Eds.), Model-Driven Domain Analysis and

Software Development, 177–200. IGI Global.

https://doi.org/10.4018/978-1-61692-874-2.ch009

Kashmira, P. G. T. H., and Sumathipala, S. 2018. Generating

Entity Relationship Diagram from Requirement

Specification based on NLP. In 2018 3rd International

Conference on Information Technology Research

(ICITR), 1–4. IEEE. https://doi.org/

10.1109/ICITR.2018.8736146

Khoo, C., Chan, S., and Niu, Y. 2002. The Many Facets of

the Cause-Effect Relation. In R. Green, C. A. Bean, and

Text Processing Techniques in Approaches for Automated Composition of Domain Models

499

S. H. Myaeng (Eds.), In The Semantics of Relationships:

An Interdisciplinary Perspective (pp. 51–70). Springer

Netherlands. https://doi.org/10.1007/ 978-94-017-0073-

3_4

Krishnan, H., and Samuel, P. 2010. Relative Extraction

Methodology for class diagram generation using

dependency graph. In 2010 International conference on

communication control and computing technologies,

815–820. IEEE. https://doi.org/10.1109/

ICCCCT.2010.5670730

Leopold, H., van der Aa, H., Pittke, F., Raffel, M., Mendling,

J., and Reijers, H. A. 2017. Searching textual and model-

based process descriptions based on a unified data

format. Software & Systems Modeling, 18(2), 1179–

1194. https://doi.org/10.1007/s10270-017-0649-y

Miller, J., and Mukerji, J. 2001. Model Driven Architecture

(MDA). In Architecture Board ORMSC.

http://www.omg.org/cgi-bin/doc?ormsc/2001-07-01

Mirończuk, M. M. 2020. Information Extraction System for

Transforming Unstructured Text Data in Fire Reports

into Structured Forms: A Polish Case Study. Fire

Technology, 56(2), 545–581. Springer.

https://doi.org/10.1007/s10694-019-00891-z

Nassar, I. N., and Khamayseh, F. T. 2015. Constructing

Activity Diagrams from Arabic User Requirements using

Natural Language Processing Tool. In 2015 6th

International Conference on Information and

Communication Systems (ICICS), 50–54. IEEE.

https://doi.org/10.1109/IACS.2015.7103200

Nazaruka, E. 2020. Processing Use Case Scenarios and Text

in a Formal Style as Inputs for TFM-based

Transformations. Baltic J. Modern Computing, 8(1), 48–

68. https://doi.org/10.22364/bjmc.2020.8.1.03

Nazaruka, E. 2019. Identification of Causal Dependencies by

using Natural Language Processing: A Survey. In E.

Damian, G. Spanoudakis, and L. Maciaszek (Eds.), In

Proceedings of the 14th International Conference on

Evaluation of Novel Approaches to Software

Engineering - Volume 1: MDI4SE, 603–613. SciTePress.

https://doi.org/10.5220/0007842706030613

Nazaruka, E., and Osis, J. 2018. Determination of Natural

Language Processing Tasks and Tools for Topological

Functioning Modelling. In Proceedings of the 13th

International Conference on Evaluation of Novel

Approaches to Software Engineering, 501–512.

SciTePress.

Nazaruka, E., Osis, J., and Griberman, V. 2019. Extracting

Core Elements of TFM Functional Characteristics from

Stanford CoreNLP Application Outcomes. In E. Damian,

G. Spanoudakis, and L. Maciaszek (Eds.), Proceedings

of the 14th International Conference on Evaluation of

Novel Approaches to Software Engineering - Volume 1:

MDI4SE, 591–602. SciTePress.

https://doi.org/10.5220/0007831605910602

Ning, Q., Feng, Z., Wu, H., and Roth, D. 2018. Joint

Reasoning for Temporal and Causal Relations. In

Proceedings of the 56th Annual Meeting of the

Association for Computational Linguistics (Long

Papers), 2278–2288. Association for Computational

Linguistics.

Osis, J., Asnina, E., and Grave, A. 2007. Formal computation

independent model of the problem domain within the

MDA. In J. Zendulka (Ed.), Proceedings of the 10th

International Conference on Information System

Implementation and Modeling, Hradec nad Moravicí,

Czech Republic, April 23-25, 2007 (Vol. 252, pp. 47–54).

Jan Stefan MARQ.

Pearl, J. 2019. The Seven Tools of Causal Inference, with

Reflections on Machine Learning. Communications of

Association for Computing Machinery, 62

(3), 54–60.

ACM. https://doi.org/10.1145/3241036

Prieto-Diaz, R. 1990. Domain Analysis: An Introduction.

Software Engineering Notes, 15(2), 47–54. ACM

SIGSOFT.

Shweta, Sanyal, R., and Ghoshal, B. 2018. Automatic

Extraction of Structural Model from Semi Structured

Software Requirement Specification. In 2018 IEEE/ACIS

17th International Conference on Computer and

Information Science (ICIS), 543–558. IEEE.

https://doi.org/10.1109/ICIS.2018.8466406

Slihte, A. 2015. The Integrated Domain Modeling: an

Approach & Toolset for Acquiring a Topological

Functioning Model, Riga Technical University.

Smialek, M., and Straszak, T. 2012. Facilitating transition

from requirements to code with the ReDSeeDS tool. In

2012 20th IEEE International Requirements Engineering

Conference (RE), 321–322. IEEE.

https://doi.org/10.1109/RE.2012.6345825

Solstad, T., and Bott, O. 2017. Causality and causal reasoning

in natural language. In M. R. Waldmann (Ed.), The

Oxford Handbook of Causal Reasoning, Oxford

University Press. http://www.oxfordhandbooks.com/

view/10.1093/oxfordhb/9780199399550.001.0001/oxfo

rdhb-9780199399550-e-32

Thakur, J. S., and Gupta, A. 2014. Automatic generation of

analysis class diagrams from use case specifications. In

ISEC '14: Proceedings of the 7th India Software

Engineering Conference, 1-6. ACM.

https://doi.org/10.1145/2590748.2590768.

Thakur, J. S., and Gupta, A. 2016a. AnModeler: a tool for

generating domain models from textual specifications. In

Proceedings of the 31st IEEE/ACM International

Conference on Automated Software Engineering - ASE

2016, 828–833. ACM/IEEE.

https://doi.org/10.1145/2970276.2970289

Thakur, J. S., and Gupta, A. 2016b. Identifying domain

elements from textual specifications. In Proceedings of

the 31st IEEE/ACM International Conference on

Automated Software Engineering - ASE 2016, 566–577.

ACM/IEEE. https://doi.org/10.1145/2970276.2970323

Waldmann, M. R., and Hagmayer, Y. 2013. Causal

reasoning. In D. Reisberg (Ed.), Oxford Handbook of

Cognitive Psychology. Oxford University Press.

https://doi.org/10.1093/oxfordhb/9780195376746.013.0

046

MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering

500
